Avantco MX60 User Manual

From whipped potatoes to cake batter, the

Avantco MX Series commercial mixer’s direct

drive, 3-speed transmission and powerful motor

make it suitable for a multitude of mixing tasks.

MX Series

Intertek

Commercial Mixers

• Ideal for small bakeries, restaurants
and delis.

• Direct drive transmission ensures
consistent mixing speeds regardless
of bowl contents.

• Powerful air cooled motor

• Gears and shafts made of heat
treated alloy steel.

• Includes mixing bowl, wire whisk, dough

hook and at beater.

• 3 xed speeds with easy shifting.

MX60 - Gear Driven

Intertek

60 Qt. Commercial Mixer w/ Guard

Gear Driven 60 Qt. Commercial Mixer with Guard

Description

Create your most popular confectionery delights
with the Avantco MX60 60 qt. commercial
planetary mixer! Whether you're tackling cake
batter or thick pizza dough, this mixer's 3 hp
motor and 3-speed gear driven transmission will
get the job done without the risk of drive system
slip that can happen with belt driven models.
Its automatic safety overload switch will cut the
power in the event of overdraw to protect your
unit from damage, while the included stainless
steel bowl guard also prevents clothing, utensils,
or your employees' hands from coming in contact
with the agitator when the mixer is in use. Due
to the large size of the bowl, this model also has
a power bowl lift with easy up/down buttons to
eliminate the need to crank the bowl into place
using a manual lift. However, a manual lift is
included as well for convenience. Plus, a bowl
truck on (4) 3 1/2" diameter casters is included
for easy transportation of the bowl from mixing
station to prep area within your kitchen!

In addition to the 60 qt. stainless steel bowl, this
mixer comes with a variety of other accessories,
including a stainless steel wire whip for mixing

liquids and soft foods, a cast aluminum at beater

for mixing dry ingredients, and a cast aluminum
dough hook for kneading bread or pizza dough.
All of these attachments can be easily installed
by raising them onto the mixing axle and simply
rotating them clockwise on the shaft until they
lock into place. This mixer also features a manual
bowl lift that raises the bowl to the proper height
for mixing with just the turn of a wheel!

Features

• 60 qt. capacity

• 3 hp motor

• Gear driven transmission

with 3 xed speeds

• Automatic overload
protection

• Stainless steel bowl guard

• Includes bowl, wire whip,
cast aluminum dough hook,

and at beater

Technical Data

Power (hp) 3

Voltage 220-240

Dimensions 36" x 30" x 63"

Box Dimensions 38.25" x 38.5" x 68.25"

Shipping Weight 937 lbs

Cord Length None; Must be hardwired

This Avantco commercial mixer requires a
220-240V electrical connection and must be
hardwired; it does not come with a cord and plug.
It is ETL Sanitation Listed.

www.AvantcoEquipment.com
