Page 1
DEXTER-V43-RG
Features
• Solid ash wood frame
• Plywood panels
• 2 soft-close doors
• 2 pull out drawers with removable trays
• Black finish hardware
• Adjustable height levelers
Colors / Couleurs
• Rustic Gray / Gris rustique
Nominal Dimension / Dimension Nominale
• 43W x 22D x 32H inches | 1092 x559 x 814 mm
Product Diagrams / Diagrammes Produit
Solid wood
Caractéristiques
• Cadre en bois de frêne massif
• Panneau de contreplaqué
• 2 portes à fermeture douce
• 2 tiroirs à tiroirs avec plateaux amovibles
• Quincaillerie au finior noir
• Patinsréglablesen hauteur
Front / Devant
Plywood
Plywood
Plywood
Solid wood
Plywood
Plywood
Back / Derrière
Side / Côté
Top / Haut
For customer support, please call Avanity Corporation at 866-522-5578 weekdays 9:00 to 6:00 PST
Pour le support client, s'il vous plaît appelez au 866-522-5578 Avanity Corporation jours de semaine 9:00-6:00 PST
Page 2
SUT43BK-R / SUT43CW -R / SUT43GB-R
Features Colors / Finishes
• Single 20" rectangular sink cutout
• 8" widespread faucet holes
• 4" backsplash included
• Sink clips included
• BK - Natural Black Granite
• CW - Natural Carrera White marble
• GB - Natural Galala Beige marble
Nominal Dimension
• 43W x 22D x 1H inches
• 1092 x 560 x 25 mm
Components
Sink CUM20WT-R
Vanity
BROOKS-V42 HAMILTON-V42
Product Diagrams
Top
Side
For customer support please call 866 522 5578 weekdays 9:00 to 6:00 PST
Page 3
CUM20WT-R
Features
• Vitreous China
• Undermount application
Components
Drain VC-DRAIN-CP VC-DRAIN-BN
Product Diagrams
Colors / Finishes
• White
Nominal Dimension
• 20W x 15D x 7.7H inches
• 510 x 381 x 196mm
510 [ 20” ]
460 [ 18.1” ]
196 [ 7.7” ]
Top
381 [ 15” ]
510 [ 20” ]
331 [ 13” ]
381 [ 15” ]
196 [ 7.7” ]
Front
Side
For customer support please call 866 522 5578 weekdays 9:00 to 6:00 PST
