Part No. E201721W3A1R
MPC 21” Series
21” Multifunctional Touch Panel PC
Quick Reference Guide
1st Ed – 28 october 2010
.
MPC 21” Series
2 MPC 21W Series Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
z 1 x MPC 21" Series Panel PC
z 1 x Quick Reference Guide
z 1 x DVD-ROM contains the followings:
— User’s Manual (this manual in PDF file)
— Ethernet driver and utilities
— VGA drivers and utilities
— Audio drivers and utilities
— WiFi drivers and utilities
— Touch controller drivers and utilities
— Chipset drivers and utilities
z 1 x Power Adapter (12V/7A)
z 4 x screws for VESA (M4 x 6mm)
z 4 x screws for 2.5" HDD device (M3 x 5mm)
z 4 x screws for mPCIe device (M2 x 4mm)
Quick Reference Guide
MPC 21W Series Quick Reference Guide
3
1.3 System Specifications
Panel
Model
MPC-21W3 MPC-21W5
LCD size
21.6”, 16:9
Display type
Full HD
Resolution
1920 x 1080
Color
16.7M
Pixel pitch
0.248mm(H) x 0.248mm(V)
Luminance
300 cd/m²
Contrast ratio
1000
Viewing angle
80(U), 80(D), 85(L), 85(R)
Response time
5 ms
Backlight
CCFL
Touch type (Optional)
Optional 5 Wires resistive
Touch interface
USB
System
Board
EBM-945GSE EBM-PNV
CPU
Onboard Intel Atom N270 1.6GHz
(2.5W)
Onboard Intel® Atom™ Dual Core 1.8GHz
CPU
BIOS Award 8 Mbit Flash BIOS
AMI 8Mbit Flash BIOS
System Chipset Intel 945GSE + ICH7-M
Intel® ICH8M Chipset (2.4 W)
I/O Chipset ITE 8712F
Winbond W83627DHG-P
System Memory
Onboard 1GB DDR2, extra one
SODIMM supports up to 2GB 400/533
SDRAM
Onboard 1GB, one 200-pin SODIMM
supports up to 3GB
SSD One CF socket supports Type I / II Compact Flash Card.
HDD
Optional 2.5” SATA HDD or 44-pin
enhanced IDE HDD
1 x 2.5" SATA HDD
WiFi Optional USB WiFi 802.11b/g Optional USB WiFi 802.11b/g/n
Watchdog Timer Reset: 1 ~ 65535 sec./min. and 1 min./step
Display
Intel 945GSE GMCH integrated
GMA950 graphics
Intel Pineview integrated, Gen3.5 + GFX
Core @ 400MHz
Audio Realtek ALC 655 supports 5.1-CH Audio
Realtek ALC888 supports 5.1-CH Audio
Ethernet
Dual Realtek RTL8111C Gigabit LAN,
supports wake on LAN
Intel® 82574L Gigabit LAN (optional dual
82574L Gigabit LAN)
MPC 21” Series
4 MPC 21W Series Quick Reference Guide
External I/O Ports
COM Port
1 x RS-232/422/485 setting by BIOS*, optional extra 1 x RS-232/422/485
Ethernet Port
2 x RJ-45 1 x RJ-45
VGA / LCD Port
1 x DB-15
Audio Port
Line-out Line-out
USB Port
2 x USB 2.0
Power Supply Unit
Power Input
12V
Power Output
7A (84W)
Environment & Mechanical
Operating Temperature
0~50°C (32~122°F) 0 to 50°C (32 to 122°F)
Storage Temperature
-20 to +75°C (-4~167°F)
Relative Humidity
5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H)
508 x 301 x 49 mm
Weight
6 Kgs
Mounting
Desktop (VESA Compliance)
Note: *To know more detail of RS232/422/485 setting by BIOS, please refer to chapter 2.1.
Quick Reference Guide
MPC 21W Series Quick Reference Guide
5
1.4 System Overview
1.4.1 Front View
1.4.2 Rear View
Connectors
Label Function Note
POWER
Power on button
CF
CF Type I/II Socket with Ejector Optional for 2nd COM port
COM
Serial port DB-9 male connector
LINE OUT
Line-out audio jack
USB
2 x USB 2.0 connector Dock USB
LAN1
RJ-45 Ethernet connector 1
LAN2
(KB/MS)
RJ-45 Ethernet connector 2
(LAN2 is default for MPC-21W3, KB/MS is
default for MPC-21W5)
HDD
HDD indicator
PWR
System power indicator
VGA
CRT connector DB-15 female connector
RESET
Reset button
DC-IN
DC Power-in connector
POWER
MPC 21” Series
6 MPC 21W Series Quick Reference Guide
1.5 System Dimensions
Quick Reference Guide
MPC 21W Series Quick Reference Guide
7
2. Hardware
Configuration
Note: If you need more information, please visit our website:
http://www.avalue.com.tw
MPC 21” Series
8 MPC 21W Series Quick Reference Guide
2.1 BIOS settings
2.1.1 MPC-21W3 RS232/422/485 setting by BIOS
The COM port setting of MPC-21W3, which applies for EBM-945GSE M/B, can be
configured by BIOS; the path is shown as below.
[BIOS Menu] Æ [Integrated Peripherals] Æ [Super IO Device]
Æ [COMPORT 232/422/485]
The panel backlight of MPC-21W3, which applying EBM-945GSE M/B, can as well be
configured by;
[BIOS Menu] Æ [Advanced Chipset Features] Æ [LVDS Back Light]
To know more about other settings, please refer to EBM-945GSE Quick Installation Guide
or User’s Manual.
Quick Reference Guide
MPC 21W Series Quick Reference Guide
9
2.1.2 MPC-21W5 backlight control setting by BIOS
The Backlight control setting for MPC-21W5, which applies for EBM-PNV M/B, can be
configured by BIOS; the path is shown as below.
[Chipset] Æ [North Bridge Configuration] Æ [Video Function Configuration]
Panel 2 Back light mode: PWM mode
Panel 2 Back light control: 100%
Note:
Panel 1 Back light mode : DC mode
Panel 1 Back light control : 50%
Panel 1 control for 18bit LVDS panel.
To know more about other settings, please refer to EBM-PNV Quick Installation Guide or
User’s Manual.
MPC 21” Series
10 MPC 21W Series Quick Reference Guide
2.2 Installing Hard Disk & Memory
Step 1. Memory Installation: Unfasten 6 screws from the case to take off the top chassis.
Step 2. Insert the SODIMM into the memory socket.
Step 3-1. HDD Installation: Unfasten 2 screws of the HDD bracket and take it off.
Quick Reference Guide
MPC 21W Series Quick Reference Guide
11
Step 3-2. Insert the HDD into the bracket and fasten 4 screws.
Step 3-3. Insert the cable to connect HDD and SATA connectors.
Step 3-4. SATA HDD Installation: By default, SATA cables had been inserted to
respective connectors. Connect to SATA HDD with the two cables.
SATA wire
SATA cable
IDE Connector
SATA Connector
MPC 21” Series
12 MPC 21W Series Quick Reference Guide
Step 3-5. Insert the HDD back and fasten 2 screws.
Step 4. Place back the chassis with 6 screws locked.
HDD
