EBM-BDW

5th Gen Intel® Core™ SoC Processor i7/i5/i3

5.25” Mini Module

User’s Manual

1st Ed – 21 July 2015

Part No. E2047582400R

EBM-BDW User’s Manual

FCC Statement

Notice

Trademark Acknowledgement

Disclaimer

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

This guide is designed for experienced users to setup the system within the shortest time. For detailed information, please always refer to the electronic user's manual.

No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.

Brand and product names are trademarks or registered trademarks of their respective owners.

Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the use of the described product(s), conveys no license or title under any patent, copyright, or masks work rights to these products, and makes no representations or warranties that

2 EBM-BDW User’s Manual

User’s Manual

Life Support Policy

A Message to the Customer

these products are free from patent, copyright, or mask work right infringement, unless otherwise specified. Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.

Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS I N LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL OF Avalue Technology Inc.

As used herein:

1. Life support devices or systems are devices or systems which, (a) are intended for

surgical implant into body, or (b) support or sustain life and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness.

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial environments. Whether your new Avalue device is destined for the laboratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into technical difficulties, we are here to help. For the most frequently asked questions, you can easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

EBM-BDW User’s Manual

Product Warranty

Avalue warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Avalue, or which have been subject to misuse, abuse, accident or improper installation. Avalue assumes no liability under the

terms of this warranty as a consequence of such events. Because of Avalue’s high

quality-control standards and rigorous testing, most of our customers never need to use our repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time, and freight. Please consult your dealer for more details. If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example,

CPU type and speed, Avalue’s products model name, hardware & BIOS

revision number, other hardware and software used, etc.) Note anything abnormal and list any on-screen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information available.

3. If your product is diagnosed as defective, obtain an RMA (return material

authorization) number from your dealer. This allows us to process your good return more quickly.

4. Carefully pack the defective product, a complete Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it

prepaid to your dealer.

4 EBM-BDW User’s Manual

User’s Manual

Content

1. Getting Started .................................................................................................... 8

1.1 Safety Precautions ............................................................................................. 8

1.2 Packing List ....................................................................................................... 8

1.3 Document Amendment History............................................................................ 9

1.4 Manual Objectives................................ ............................................................ 10

1.5 System Specifications ...................................................................................... 11

1.6 Architecture Overview—Block Diagram ............................................................. 14

2. Hardware Configuration .................................................................................... 15

2.1 Product Overview............................................................................................. 16

2.2 Jumper and Connector List ............................................................................... 17

2.3 Setting Jumpers & Connectors .......................................................................... 19

2.3.1 Multi-function select (SW1) .................................................................................................... 19

2.3.2 Serial port 1/2 - RS-485 mode selector (SW2)......................................................................... 19

2.3.3 Serial port 1/ 2 - RS-422 mode selector (SW3)........................................................................ 20

2.3.4 Serial port 1/ 2 pin9 signal select (JRI1/ JRI2) ......................................................................... 20

2.3.5 SATA Power select (JP1) ...................................................................................................... 21

2.3.6 Clear CMOS (JP4) ................................................................................................................ 21

2.3.7 LCD backlight brightness adjustment (JVR) ................................ ................................ ............ 22

2.3.8 LED indicator connector (JLED) ................................ ................................ ............................. 22

2.3.9 LCD Inverter connector 1 (JBKL1).......................................................................................... 23

2.3.10 LCD Inverter connector 2 (JBKL2)...................................................................................... 23

2.3.11 CPU fan connector (CPU_FAN) ................................................................ ......................... 24

2.3.12 System fan connector (SYS_FAN) ..................................................................................... 24

2.3.13 Serial port 2 connector (JCOM2) ........................................................................................ 25

2.3.14 Serial port 3/4/5/6 connector (JCOM3/JCOM4/JCOM5/JCOM6) ........................................... 26

2.3.15 General purpose I/O connector (JDIO) ............................................................................... 26

2.3.16 Touch panel connector (JTOUCH) ..................................................................................... 27

2.3.17 SATA Power connector (SPWR) ........................................................................................ 27

2.3.18 Power connector (PWR1) ................................................................ .................................. 28

2.3.19 LPC connector (JLPC) ...................................................................................................... 28

2.3.20 LVDS connector (JLVDS) .................................................................................................. 29

2.3.21 USB connector 1 (JUSB1) ................................ ................................ ................................. 30

2.3.22 USB connector 2 (JUSB2) ................................ ................................ ................................. 30

2.3.23 AMPLIFIER_R (JAMP_R)................................................................ ................................ .. 31

2.3.24 AMPLIFIER_L (AMP_L) .................................................................................................... 31

2.3.25 SPI connector (JSPI)......................................................................................................... 32

EBM-BDW User’s Manual

2.3.26 Audio connector (JAUDIO) ................................................................................................ 32

2.3.26.1 Signal Description – Audio connector (JAUDIO) .............................................................. 32

2.3.27 EC_Program (JEC_SPI) .................................................................................................... 33

2.3.28 Battery connector (BT) ................................ ................................ ...................................... 33

2.3.29 OSD for front panel key (JKEY).......................................................................................... 34

3.BIOS Setup ............................................................................................................ 35

3.1 Introduction................................ ................................................................ ...... 36

3.2 Starting Setup .................................................................................................. 36

3.3 Using Setup ..................................................................................................... 37

3.4 Getting Help .................................................................................................... 38

3.5 In Case of Problems ......................................................................................... 38

3.6 BIOS setup ................................................................ ...................................... 39

3.6.1 Main Menu ........................................................................................................................... 39

3.6.1.1 System Language ......................................................................................................... 40

3.6.1.2 System Date ................................................................................................................. 40

3.6.1.3 System Time ................................................................................................................ 40

3.6.2 Advanced Menu .................................................................................................................... 40

3.6.2.1 CPU Configuration ........................................................................................................ 41

3.6.2.2 Trusted Computing ....................................................................................................... 41

3.6.2.3 APCI Settings ............................................................................................................... 42

3.6.2.4 PCH-FW Configuration .................................................................................................. 43

3.6.2.4.1 Firmware Update Configuration...................................................................................... 44

3.6.2.5 AMT Configuration ........................................................................................................ 44

3.6.2.6 Super IO Configuration .................................................................................................. 45

3.6.2.6.1 Serial Port 1 Configuration ............................................................................................. 46

3.6.2.6.2 Serial Port 2 Configuration ............................................................................................. 47

3.6.2.6.3 Serial Port 3 Configuration ............................................................................................. 48

3.6.2.6.4 Serial Port 4 Configuration ............................................................................................. 49

3.6.2.6.5 Serial Port 5 Configuration ............................................................................................. 50

3.6.2.6.6 Serial Port 6 Configuration ............................................................................................. 51

3.6.2.7 H/W Monitor ................................................................................................................. 52

3.6.2.8 S5 RTC Wake Settings................................................................................................ .. 52

3.6.2.9 SATA Configuration ...................................................................................................... 53

3.6.2.10 Thermal Configuration ................................................................................................... 54

3.6.2.10.1 Platform Thermal Configuration................................................................ ...................... 54

3.6.2.11 Network Stack Configuration................................ ................................ .......................... 55

3.6.2.12 CSM Configuration........................................................................................................ 56

3.6.2.13 USB Configuration ................................................................ ........................................ 57

3.6.3 Chipset ............................................................................................................................... 57

3.6.3.1 System Agent (SA) Configuration ................................................................................... 58

6 EBM-BDW User’s Manual

User’s Manual

3.6.3.1.1 Graphics Configuration .................................................................................................. 58

3.6.3.1.1.1 LCD Control ................................................................................................................. 59

3.6.3.1.2 Memory Configuration ................................................................................................... 61

3.6.3.2 PCH-IO Configuration ................................................................................................... 61

3.6.3.2.1 PCI Express Configuration............................................................................................. 62

3.6.3.2.2 USB Configuration ........................................................................................................ 62

3.6.3.2.3 PCH Azalia Configuration .............................................................................................. 63

3.6.4 Security .............................................................................................................................. 64

3.6.4.1 Secure Boot menu ........................................................................................................ 64

3.6.4.1.1 Key Management ............................................................................................................ 65

3.6.5 Boot ................................................................ ................................ ................................... 66

3.6.6 Save and exit ................................................................ ...................................................... 67

3.6.6.1 Save Changes and Reset .............................................................................................. 67

3.6.6.2 Discard Changes and Reset ................................ .......................................................... 67

3.6.6.3 Restore Defaults ........................................................................................................... 68

3.6.6.4 Launch EFI Shell from filesystem device......................................................................... 68

4. Drivers Installation ................................ ............................................................... 69

4.1 Install Chipset Driver ................................................................ ........................ 70

4.2 Install Ethernet Driver ................................................................ ....................... 71

4.3 Install IRST Driver ................................................................ ............................ 73

4.4 Install ME Driver .............................................................................................. 75

4.5 Install VGA Driver ............................................................................................ 76

4.6 Install Audio Driver (For Realtek ALC892).......................................................... 78

5. Mechanical Drawing ................................................................ ............................. 79

EBM-BDW User’s Manual

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.

Caution!

Always ground yourself to remove any static charge before touching the CPU card. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis.

1.2 Packing List

Before you begin installing your single board, please make sure that the following materials have been shipped:

 1 x EBM-BDW 5th Generation intel Core Processor 5.25” Mini Module  1 x Driver/Utility DVD-ROM

8 EBM-BDW User’s Manual

Revision

Date

Comment

1st

July 2015

Avalue

Initial Release

1.3 Document Amendment History

User’s Manual

EBM-BDW User’s Manual

1.4 Manual Objectives

This manual describes in details Avalue Technology EBM-BDW Single Board.

We have tried to include as much information as possible but we have not duplicated information that is provided in the standard IBM Technical References, unless it proved to be necessary to aid in the understanding of this board.

We strongly recommend that you study this manual carefully before attempting to set up EBM-BDW or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.

Please be aware that it is possible to create configurations within the CMOS RAM that make booting impossible. If this should happen, clear the CMOS settings, (see the description of the Jumper Settings for details).

If you have any suggestions or find any errors regarding this manual and want to inform us of these, please contact our Customer Service department with the relevant details.

10 EBM-BDW User’s Manual

1.5 System Specifications

System

CPU

Intel® Boardwell ULT 2 Cores BGA w/ integrated Boardwell PCH-LP (MCP) (Co-layout w/ Core i7/ i5/ i3)

BIOS

AMI uEFI BIOS(*1), 128 Mbit SPI Flash ROM(*2) iAMT 10 supported

System Chipset

Intel Boardwell PCH-LP (MCP; Integrated in Processor)

I/O Chip

EC(IT8528E) Fintek F81216AD for 4 COMs

System Memory

2 x 204-pin DDR3L SO-DIMM (up to 2 DIMMs), 8GB per DIMM, total 16GB

SSD

1 x CF (via JMB368 ) 3 x SATA ports, 1 x mSATA (mPCIe connector), 1 x 15+7 pin SATA connector, 1 x 7 pin SATA(7th Pin ) ( cowork w/ 2-pin 5V power)

Watchdog

Timer

H/W Reset, 1sec. – 65535sec. and 1sec./step

H/W Status

Monitor

CPU & system temperature monitoring Voltages monitoring

Expansion

1 x mPCIe w/ SIM slot 1 x mPCIe supports mSATA only

I/O

MIO

1 x HDMI, 1 x CF (via JMB368) 1 x Lockable DC Jack 2 x LAN 2 x USB 3.0 (compatible with USB 2.0) 1 x COM D-Sub 9-pin (RS232/422/485 selected by BIOS), 1 x box wafer behind external I/O and 4 x box wafer (90-degree box wafer same as EBM-CDV) 1 x dual deck LED(green color for power-on indication/ Yellow color for HDD active indication) Audio jack (output)

USB

2 x USB 3.0 Type A (including 2 x USB 2.0) 2 x USB 2.0 10-pin box wafer 1 x USB 2.0 for Touch controller 1 x USB through mPCIe port

GPIO

16-bit General Purpose I/O for DI (8bit) and DO(8bit) IC: PCA9555

Touch Interface

1 x USB 2.0 (EETI ETP-CP-MER4485XRU support 5 wire)

Display

User’s Manual

EBM-BDW User’s Manual

Chipset

Intel Boardwell GT2 integrated w/ CPU

Resolution

HDMI: 4000 x 2000@24Hz (single display) LVDS via CH7511: 1920 x 1200@60Hz

Multiple Display

Dual-display supported: HDMI+LVDS

HDMI

1 x HDMI

LCD

Interface

1 x eDP via CH7511 supports 24bit Dual Channel LVDS

Audio

AC97 Codec

Realtek ALC892 supports 5.1 CH Audio

Audio Amp

TI TPA3005D2

Ethernet

LAN Chip

1 x Intel I210AT GbE controller 1 x Intel I218LM GbE PHY

Ethernet Interface

10/100/1000 Base-Tx compatible

Touch

Chipset

EETI ETP-CP-MER4485XRU support 5 wire

Touch Interface

1 x 5-pin 2.0mm pin header

Internal I/O

Connectors

Fan

Fanless (System fan and CPU fan reserved)

CMOS Battery

Cable type battery CR-2032

Audio

1 x Audio output (external I/O) 2 x 2-pin Speak out connector Jaudio 2 x 6 header (Line in, Line out & Mic in)

Rear I/O

Connectors

USB

2 x USB 3.0 Type A (including 2 x USB 2.0)

LAN

2 x RJ-45 LAN

HDMI

1 x HDMI

LED

1 x dual deck LED(green color for power-on indication/ Yellow color for HDD active indication)

Power

1 x Lockable DC Jack

Audio

1 x Headphone Audio Jack

COM

1 x COM1

Mechanical &

Environmental

Power

Requirement

+12 ~ +26V, ErP

12 EBM-BDW User’s Manual

User’s Manual

Power Type

AT or ATX mode

Operating

Temp.

0°C ~ 60°C (32°F ~ 140°F)

Operating

Humidity

0% ~ 90% relative humidity, non-condensing

Size (L x W)

8" x 5.75" (203mm x 146mm x 19mm)

Weight

TBD

Safety

CE FCC Class B

Others

4 screw holes for fixing heatsink without covering RAM

Certifications

Certification

Information

CE FCC Class B

Software

Support

OS Information

Win8, Win7, Linux

Note: Specifications are subject to change without notice.

EBM-BDW User’s Manual

1.6 Architecture Overview—Block Diagram

The following block diagram shows the architecture and main components of EBM-BDW.

14 EBM-BDW User’s Manual

User’s Manual

2. Hardware Configuration

EBM-BDW User’s Manual

2.1 Product Overview

16 EBM-BDW User’s Manual

User’s Manual

Jumpers

Label

Function

Note

JRI1

Serial port 1/2 pin9 signal select

3 x 2 header, pitch 2.00mm

JVR

LCD backlight brightness adjustment

3 x 1 header, pitch 2.00mm

SW1

Multi-function select

DIP switch 6pin

SW2

Serial port 1/2 - RS-485 mode selector

DIP switch 6pin

SW3

Serial port 1/2 - RS-422 mode selector

DIP switch 4pin

JP1

SATA Power select (SATA1- Serial ATA connector)

3 x 1 header, pitch 2.00mm

JP4

SATA 2 Pin 7 Power Mode selector

3 x 1 header, pitch 2.00mm

Connectors

Label

Function

Note

CPU_FAN

CPU fan connector

4 x 1 wafer, pitch 2.54mm

2.2 Jumper and Connector List

You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that

slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.

To “open” a jumper you remove the clip. Sometimes a jumper will have t hree pins, labeled 1,

2, and 3. In this case, you would connect either two pins.

The jumper settings are schematically depicted in this manual as follows:

A pair of needle-nose pliers may be helpful when working with jumpers. Connectors on the board are linked to external devices such as hard disk drives, a keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to configure your system to suit your application. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes.

The following tables list the function of each of the board’s jumpers and connectors.

EBM-BDW User’s Manual

SYS_FAN

System fan connector

4 x 1 wafer, pitch 2.54mm

JBKL1

LCD Inverter connector 1

5 x 1 wafer, pitch 2.00mm

JBKL2

LCD Inverter connector 2

2 x 1 wafer, pitch 2.00mm

COM1

Serial Port 1 connector

D-sub 9 pin, male

JCOM2

Serial Port 2 connector

5 x 2 wafer, pitch 2.00mm

JCOM3/4/5/6

Serial Port 3/4/5/6 connector

5 x 2 wafer, pitch 2.00mm

JDIO

General purpose I/O connector

10 x 2 wafer, pitch 2.00mm

JLED

LED indicator connector

5 x 2 wafer, pitch 2.00mm

LED1

HDD/Power LED indicator

JLVDS

LVDS Connector

DIN 40-pin wafer, pitch 1.25mm

JTOUCH

Touch panel connector

5 x 1 header, pitch 2.54mm

USB1

2 x USB3.0 connector

JUSB1

USB connector 1

5 x 2 wafer, pitch 2.00mm

JUSB2

USB connector 2

5 x 2 wafer, pitch 2.00mm

JAUDIO

Audio connector

6 x 2 wafer, pitch 2.00mm

LAN1/2

RJ-45 Ethernet 1/2

Battery connector

2 x 1 wafer, pitch 1.25mm

JKEY

OSD for front panel key

8 x 1 wafer, pitch 2.00mm

SODIMM1/2

DDR3 SODIMM socket

JAMP_R

AMPLIFIER_R

2 x 1 wafer, pitch 2.00mm

JAMP_L

AMPLIFIER_L

2 x 1 wafer, pitch 2.00mm

MPCIE

Mini-PCIe connector

MSATA

SMBUS & SATA connector

JLPC

LPC connector

5 x 2 header, pitch 2.00mm

PWR1

Power connector

2 x 2 wafer, pitch 4.20mm

PWR2

Power connector

RSTBTN

Reset button

JSPI

SPI connector

4 x 2 header, pitch 2.00mm

JEC_SPI

EC_Program

4 x 2 header, pitch 2.00 mm

SPWR

SATA Power connector

2 x 1 wafer, pitch 2.00mm

SATA1

Serial ATA connector 1

SIM

SIM card slot

HDMI

HDMI connector

HP_OUT

Audio line-out connector

CFCARD

Compact Flash card slot

18 EBM-BDW User’s Manual

2.3 Setting Jumpers & Connectors

OFF

AT SEL

ATX SEL

CF Slave

CF Master

Touch off

Touch on

Touch: 5W

BKLT: Negative

BKLT: Positive

GPIO: Low

GPIO: High

In Serial Port 1 mode

OFF

Auto Direction

RTS# Control

External biasing

resistor

OPEN

External biasing

resistor

OPEN

In Serial Port 2 mode

OFF

Auto Direction

RTS# Control

External biasing

resistor

OPEN

External biasing

resistor

OPEN

2.3.1 Multi-function select (SW1)

User’s Manual

2.3.2 Serial port 1/2 - RS-485 mode selector (SW2)

EBM-BDW User’s Manual

In Serial Port 1 mode

OFF

External biasing

resistor

OPEN

External biasing

resistor

OPEN

In Serial Port 2 mode

OFF

External biasing

resistor

OPEN

External biasing

resistor

OPEN

* Default

Ring*

+5V

+12V

JRI1

JRI2

2.3.3 Serial port 1/ 2 - RS-422 mode selector (SW3)

2.3.4 Serial port 1/ 2 pin9 signal select (JRI1/ JRI2)

20 EBM-BDW User’s Manual

* Default

Signal

SATA_PWR1

SATA1_P7

GND

* Default

Protect*

Clear CMOS

2.3.5 SATA Power select (JP1)

User’s Manual

2.3.6 Clear CMOS (JP4)

EBM-BDW User’s Manual

* Default

PWM Mode*

DC Mode

Signal

PWR_LED_FP#

2 1 +5VSB

HDD_LED#

4 3 +5V

LAN1_ACT#

6 5 +V3P3M

LAN2_ACT#

8 7 +V3P3A

PWR_BTN_IN_EC#

10 9 GND

2.3.7 LCD backlight brightness adjustment (JVR)

2.3.8 LED indicator connector (JLED)

22 EBM-BDW User’s Manual

Signal

+12V

GND

BKLEN

VBRIGHT

+5V

Signal

+12V

GND

2.3.9 LCD Inverter connector 1 (JBKL1)

User’s Manual

Note:

For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JVR. Please see the JVR section for detailed circuitry information.

2.3.10 LCD Inverter connector 2 (JBKL2)

EBM-BDW User’s Manual

Signal

FAN_PWM0

EC_TACH0

+12V

GND

Signal

FAN_PWM1

EC_TACH1

+12V

GND

2.3.11 CPU fan connector (CPU_FAN)

2.3.12 System fan connector (SYS_FAN)

24 EBM-BDW User’s Manual

RS-232 Mode

Signal

NRXDB#

2 1 NDCDB

NDTRB#

4 3 NTXDB

NDSRB#

6 5 GND

NCTSB#

8 7 NRTSB#

10 9 NRIB#

RS-422 Mode

Signal

485TXP

2 1 485TXN

485RXN

4 3 485RXP

6 5 GND

8 7 NC

10 9 NC

RS-485 Mode

Signal

485TXP

2 1 485TXN

4 3 NC

6 5 GND

8 7 NC

10 9 NC

2.3.13 Serial port 2 connector (JCOM2)

User’s Manual

EBM-BDW User’s Manual

Signal

COM_RI#

COM_RTS#

7 8 COM_CTS#

GND

5 6 COM_DSR#

COM_TXD

3 4 COM_DTR#

COM_DCD#

1 2 COM_RXD#

Signal

DI0

DO0

DI1

DO1

DI2

DO2

DI3

DO3

DI4

DO4

DI5

DO5

DI6

DO6

DI7

DO7

I2C-SMB_CLK_VCC

I2C-SMB_DATA_VCC

GND

+5V

JCOM6

JCOM5

JCOM4

JCOM3

2.3.14 Serial port 3/4/5/6 connector (JCOM3/JCOM4/JCOM5/JCOM6)

2.3.15 General purpose I/O connector (JDIO)

26 EBM-BDW User’s Manual

Signal

THX-

THX+

THPROBE_R

THY+

THY-

Signal

+5V

GND

2.3.16 Touch panel connector (JTOUCH)

User’s Manual

2.3.17 SATA Power connector (SPWR)

EBM-BDW User’s Manual

Signal

GND

1 2 GND

+V_DCIN

3 4 +V_DCIN

Signal

GND

+5VSB

GND

+5V

GND

10 9 SERIRQ

CLK_PCI_JLPC

8 7 LPC_AD3

LPC_LFRAME#

6 5 LPC_AD2

PLTRST#

4 3 LPC_AD1

+3V

2 1 LPC_AD0

2.3.18 Power connector (PWR1)

2.3.19 LPC connector (JLPC)

28 EBM-BDW User’s Manual

Signal

+3V

1 2 +5V

+3V

3 4 +5V

LVDS_DDC_CLK

5 6 LVDS_DDC_DATA

GND

7 8 GND

LVDS_DATA1_P

LVDS_DATA0_P

LVDS_DATA1_N

LVDS_DATA0_N

GND

LVDS_DATA3_P

LVDS_DATA2_P

LVDS_DATA3_N

LVDS_DATA2_N

GND

LVDS_DATA5_P

LVDS_DATA4_P

LVDS_DATA5_N

LVDS_DATA4_N

GND

LVDS_DATA7_P

LVDS_DATA6_P

LVDS_DATA7_N

LVDS_DATA6_N

GND

LVDS_CLK2_P

LVDS_CLK1_P

LVDS_ CLK2_N

LVDS_ CLK1_N

GND

+12V

2.3.20 LVDS connector (JLVDS)

User’s Manual

EBM-BDW User’s Manual

Signal

+VCC_USB23

2 1 +VCC_USB23

USB_DN2

4 3 USB_DN3

USB_DP2

6 5 USB_DP3

GND

8 7 GND

GND

10 9 GND

Signal

+VCC_USB45

2 1 +VCC_USB45

USB_DN4

4 3 USB_DN5

USB_DP4

6 5 USB_DP5

GND

8 7 GND

GND

10 9 GND

2.3.21 USB connector 1 (JUSB1)

2.3.22 USB connector 2 (JUSB2)

30 EBM-BDW User’s Manual

Signal

AMP_ROUT-

AMP_ROUT+

Signal

AMP_LOUT-

AMP_LOUT+

2.3.23 AMPLIFIER_R (JAMP_R)

User’s Manual

2.3.24 AMPLIFIER_L (AMP_L)

EBM-BDW User’s Manual

Signal

7 HOLD#

SPI_SI

6 5 SPI_SO

SPI_CLK

4 3 SPI_CS0#

GND

2 1 +V3P3A_SPI

Signal

LINEOUT_R

2 1 LINEOUT_L

GND

4 3 GND

LINE1_RIN

6 5 LINE1_LIN

MIC_RIN

8 7 MIC_LIN

FRONT_JD

10 9 LINE1_JD

MIC1_JD

GND

Signal

Signal Description

LINE1_JD

AUDIO IN (LINE_RIN/LIN)sense pin

FRONT_JD

AUDIO Out(ROUT/LOUT) sense pin

MIC1_JD

MIC IN (MIC_RIN/LIN) sense pin

2.3.25 SPI connector (JSPI)

2.3.26 Audio connector (JAUDIO)

2.3.26.1 Signal Description – Audio connector (JAUDIO)

32 EBM-BDW User’s Manual

Signal

EC_SMDAT

EC_SMCLK

EC_SMDAT_DEBUG

10 9 EC_SMCLK_DEBUG

8 7 EC_HOLD#

EC_FMOSI

6 5 EC_FMISO

EC_FSCK

4 3 EC_FSCE#

GND

2 1 +VSPI_EC

Signal

GND

+VBAT

2.3.27 EC_Program (JEC_SPI)

User’s Manual

2.3.28 Battery connector (BT)

EBM-BDW User’s Manual

Signal

GND

+V3P3EC

EC_PWM

EC_GPIOJ1

EC_GPIOJ2

EC_GPIOJ3

EC_GPIOJ4

EC_DC

2.3.29 OSD for front panel key (JKEY)

34 EBM-BDW User’s Manual

User’s Manual

3.BIOS Setup

EBM-BDW User’s Manual

Introduction

3.1 Introduction

The BIOS setup program allows users to modify the basic system configuration. In this following chapter will describe how to access the BIOS setup program and the configuration options that may be changed.

3.2 Starting Setup

The AMI BIOS™ is immediately activated when you first power on the computer. The BIOS

reads the system information contained in the NVRAM and begins the process of checking out the system and configuring it. When it finishes, the BIOS will seek an operating system on one of the disks and then launch and turn control over to the operating system.

While the BIOS is in control, the Setup program can be activated in one of two ways: By pressing <Del> or <F2> immediately after switching the system on, or By pressing the <Del> or <F2> key when the following message appears briefly at the bottom of the screen during the POST (Power On Self Test).

Press <DEL> or <F2> to enter SETUP

If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case or restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.

36 EBM-BDW User’s Manual

User’s Manual

Button

Description

↑

Move to previous item

↓

Move to next item

←

Move to the item in the left hand

→

Move to the item in the right hand

Esc key

Main Menu -- Quit and not save changes into NVRAM Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu

PGUP/HOME key

Go to Top of Screen

PGDN/END key

Go to Bottom of Screen

+ key

Increase the numeric value or make changes

- key

Decrease the numeric value or make changes

F1 key

General help, only for Status Page Setup Menu and Option Page Setup Menu

F2 key

Previous Values. F3 key

Optimized defaults

F4 key

Save & Exit Setup

3.3 Using Setup

In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard.

 Navigating Through The Menu Bar

Use the left and right arrow keys to choose the menu you want to be in.

Note: Some of the navigation keys differ from one screen to another.

 To Display a Sub Menu

Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus.

EBM-BDW User’s Manual

3.4 Getting Help

Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Windows press <Esc> or <Enter> key.

3.5 In Case of Problems

If, after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the AMI BIOS supports an override to the NVRAM settings which resets your system to its defaults.

The best advice is to only alter settings which you thoroughly understand. To this end, we strongly recommend that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override.

38 EBM-BDW User’s Manual

User’s Manual

3.6 BIOS setup

Once you enter the Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and exit choices. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.

3.6.1 Main Menu

This section allows you to record some basic hardware configurations in your computer and set the system clock.

EBM-BDW User’s Manual

3.6.1.1 System Language

This option allows choosing the system default language.

3.6.1.2 System Date

Use the system date option to set the system date. Manually enter the day, month and year.

3.6.1.3 System Time

Use the system time option to set the system time. Manually enter the hours, minutes and seconds.

Note: The BIOS setup screens shown in this chapter are for reference purposes

only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information.

3.6.2 Advanced Menu

This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus.

40 EBM-BDW User’s Manual

User’s Manual

Item

Options

Description

Active Processor Cores

All[Default],

1 2 3

Number of cores to enable in each processor package.

3.6.2.1 CPU Configuration

Use the CPU configuration menu to view detailed CPU specification and configure the CPU.

3.6.2.2 Trusted Computing

EBM-BDW User’s Manual

Item

Options

Description

Security Device Support

Disabled

Enabled[Default]

Enable or Disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.

TPM State

Disabled[Default]

Enabled

Enable/Disable Security Device. NOTE: Your Computer will reboot during restart in order to change State of the Device.

Device Select

TPM 1.2 TPM 2.0

Auto[Default]

TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM 2.0 device, Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated.

Note:

TPM 2.0 is not backward compatible with TPM 1.2 and only fully functional under pure UEFI OSes. H/W TPM 2.0 is an optional function. If H/W TPM 2.0 function is required, please contact your distributer or our contact window.

Item

Options

Description

Enable ACPI Auto Configuration

Disabled[Default]

Enabled

Enables or Disables BIOS ACPI Auto Configuration.

Enable Hibernation

Disabled

Enabled[Default]

Enables or Disables System ability to Hibernate (OS/S4 Sleep State.) This option may be not effective with some OS.

APCI Sleep State

Suspend Disabled

S3 (Suspend to RAM)[Default]

Select ACPI sleep state the system will enter when the SUSPEND button is pressed.

S3 Video Repost

Disabled[Default]

Enabled

Enable or Disable S3 Video Repost.

ErP Function

Disabled[Default]

Enabled

ErP Function (Deep S5).

3.6.2.3 APCI Settings

42 EBM-BDW User’s Manual

Watch Dog

Disabled[Default]

30 sec 40 sec 50 sec

1 min

2 min 10 min 30 min

Select Watch Dog Timer(WDT) Mode.

PWR-On After PWR-Fail

Always Off[Default]

Always On

Last state

Select AC power state when power is re-applied after a power failure.

USB Power state in S3-S5

Disabled

Enabled[Default]

Enable/Disable USB Power delivery in S3(Sleep), S4(Hibernate), S5(Shut down) Modes.

Item

Options

Description

ME Unconfig on RTC Clear

State

Disabled

Enabled[Default]

Enable/Disable ME firmware un-configuration On RTC Clear State.

3.6.2.4 PCH-FW Configuration

User’s Manual

EBM-BDW User’s Manual

Item

Options

Description

Me FW Image Re-Flash

Disabled[Default]

Enabled

Enable/Disable Me FW Image Re-Flash function.

Item

Options

Description

Intel AMT

Disabled

Enabled[Default],

Enable/Disable Intel® Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled. This option just controls the

3.6.2.4.1 Firmware Update Configuration

3.6.2.5 AMT Configuration

44 EBM-BDW User’s Manual

User’s Manual

BIOS extension execution. If enabled, this requires additional firmware in the SPI device.

Un-Configure ME

Disabled[Default],

Enabled

OEMFlag Bit 15: Un-Configure ME without password.

Disable ME

Disabled[Default],

Enabled

Set ME to Soft Temporary Disabled.

Item

Description

Serial Port 1 Configuration

Set Parameters of Serial Port 1 (COMA).

Serial Port 2 Configuration

Set Parameters of Serial Port 2 (COMB).

Serial Port 3 Configuration

Set Parameters of Serial Port 3 (COMC).

Serial Port 4 Configuration

Set Parameters of Serial Port 4 (COMD).

Serial Port 5 Configuration

Set Parameters of Serial Port 3 (COME).

Serial Port 6 Configuration

Set Parameters of Serial Port 4 (COMF).

3.6.2.6 Super IO Configuration

You can use this item to set up or change the Super IO configuration for serial ports. Please refer to 3.6.2.6.1~6 for more information.

EBM-BDW User’s Manual

Item

Option

Description

Serial Port

Enabled[Default],

Disabled

Enable or Disable Serial Port (COM).

Change Settings

Auto[Default]

IO=3F8h; IRQ=4; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;

Select an optimal setting for Super IO Device.

UART 232 422 485

RS232[Default],

RS485 RS422

Change the Serial Port mode.

UART SLEW

Enabled[Default],

Disabled

Enable or Disable 250kbps slew limiting.

UART THRM

Enabled

Disabled[Default],

Enable or Disable RS-485/422 receiver termination.

3.6.2.6.1 Serial Port 1 Configuration

46 EBM-BDW User’s Manual

3.6.2.6.2 Serial Port 2 Configuration

Item

Option

Description

Serial Port

Enabled[Default],

Disabled

Enable or Disable Serial Port (COM).

Change Settings

Auto[Default]

IO=2F8h; IRQ=3; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;

Select an optimal setting for Super IO Device.

UART 232 422 485

RS232[Default],

RS485 RS422

Change the Serial Port mode.

UART SLEW

Enabled[Default],

Disabled

Enable or Disable 250kbps slew limiting.

UART THRM

Enabled

Disabled[Default],

Enable or Disable RS-485/422 receiver termination.

User’s Manual

EBM-BDW User’s Manual

Item

Option

Description

Serial Port

Enabled[Default],

Disabled

Enable or Disable Serial Port (COM).

Change Settings

Auto[Default]

IO=3E8h; IRQ=10; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=200h; IRQ=3,4,5,6,7,9,10,11,12; IO=208h; IRQ=3,4,5,6,7,9,10,11,12;

Select an optimal setting for Super IO Device.

3.6.2.6.3 Serial Port 3 Configuration

48 EBM-BDW User’s Manual

3.6.2.6.4 Serial Port 4 Configuration

Item

Option

Description

Serial Port

Enabled[Default],

Disabled

Enable or Disable Serial Port (COM).

Change Settings

Auto[Default]

IO=2E8h; IRQ=11; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=200h; IRQ=3,4,5,6,7,9,10,11,12; IO=208h; IRQ=3,4,5,6,7,9,10,11,12;

Select an optimal setting for Super IO Device.

User’s Manual

EBM-BDW User’s Manual

Item

Option

Description

Serial Port

Enabled[Default],

Disabled

Enable or Disable Serial Port (COM).

Change Settings

Auto[Default]

IO=200h; IRQ=10; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=200h; IRQ=3,4,5,6,7,9,10,11,12; IO=208h; IRQ=3,4,5,6,7,9,10,11,12;

Select an optimal setting for Super IO Device.

3.6.2.6.5 Serial Port 5 Configuration

50 EBM-BDW User’s Manual

3.6.2.6.6 Serial Port 6 Configuration

Item

Option

Description

Serial Port

Enabled[Default],

Disabled

Enable or Disable Serial Port (COM).

Change Settings

Auto[Default]

IO=208h; IRQ=11; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=200h; IRQ=3,4,5,6,7,9,10,11,12; IO=208h; IRQ=3,4,5,6,7,9,10,11,12;

Select an optimal setting for Super IO Device.

User’s Manual

EBM-BDW User’s Manual

Item

Options

Description

Smart Fan Function

Disabled[Default]

Enabled,

Enable or Disable Smart Fan.

3.6.2.7 H/W Monitor

3.6.2.8 S5 RTC Wake Settings

52 EBM-BDW User’s Manual

Item

Options

Description

Wake system from S5

Disabled[Default],

Fixed Time

Dynamic Time

Enable or disable System wake on alarm event. Select Fixed Time, system will wake on the hr::min::sec specified. Select Dynamic Time, System will wake on the current time + Increase minute(s).

Item

Options

Description

SATA Controller(s)

Disabled

Enabled[Default]

Enable or disable SATA Device.

SATA Mode Selection

IDE

AHCI[Default]

RAID

Determines how SATA controller(s) operate.

SATA Controller Speed

Default[Default]

Gen1 Gen2 Gen3

Indicates the maximum speed the SATA controller can support.

Port 0/1/2

Disabled

Enabled[Default]

Enable or Disable SATA Port.

SATA Device Type

Hard Disk Drive[Default]

Solid State Drive

Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.

3.6.2.9 SATA Configuration

User’s Manual

EBM-BDW User’s Manual

Item

Options

Description

Critical Trip Point

POR[Default]

80C

90C 100C 110C

This value controls the temperature of the ACPI Critical Trip Point – the point in which the OS will shut the system off. NOTE:100C is the Plan Of Record (POR) for all Intel mobile processors.

Passive Trip Point

Disabled,

This value controls the temperature of the

3.6.2.10 Thermal Configuration

3.6.2.10.1 Platform Thermal Configuration

54 EBM-BDW User’s Manual

80C

90C[Default]

100C 110C

ACPI Passive Trip Point – the point in which the OS will begin throttling the processor.

Passive TC1 Value

1-16

1[Default]

This value sets the TC1 value for the ACPI Passive Cooling Formula. Range 1 – 16.

Passive TC2 Value

1-16

5[Default]

This value sets the TC2 value for the ACPI Passive Cooling Formula. Range 1 – 16.

Passive TSP Value

2 – 32

10[Default],

This item sets the TSP value for the ACPI Passive Cooling Formula. It represents in tenths of a second how often the OS will read the temperature when passive cooling is enabled. Range 2 – 32.

Item

Options

Description

Network Stack

Disabled[Default]

Enabled

Enable/Disable UEFI Network Stack.

3.6.2.11 Network Stack Configuration

User’s Manual

EBM-BDW User’s Manual

Item

Options

Description

CSM Support

Disabled,

Enabled[Default]

Enable/Disable CSM Support.

GateA20 Active

Upon Request[Default]

Always

UPON REQUEST – GA20 can be disabled using BIOS services. ALWAYS – go not allow disabling GA20; this option is useful when any RT code is executed above 1MB.

Option ROM Messages

Force BIOS

Keep Current[Default]

Set display mode for Option ROM.

Boot option filter

UEFI and Legacy[Default]

Legacy only

UEFI only

This option controls Legacy/UEFI ROMs priority.

Network

Do not launch[Default]

UEFI

Legacy

Controls the execution of UEFI and Legacy PXE OpROM.

Storage

Do not launch

UEFI

Legacy[Default]

Controls the execution of UEFI and Legacy Storage OpROM.

Video

Do not launch

UEFI

Legacy[Default]

Controls the execution of UEFI and Legacy Video OpROM.

Other PCI devices

Do not launch UEFI[Default]

Legacy

Determines OpROM execution policy for devices other than Network, Storage, or Video.

3.6.2.12 CSM Configuration

56 EBM-BDW User’s Manual

User’s Manual

Item

Options

Description

Hp v220w 1100

Auto[Default]

Floppy

Forced FDD

Hard Disk

CD-ROM

Mass storage device emulation type. ‘AUTO’ enumerates devices according to their media format. Optical drives are emulated as ‘CDROM’, drives with no media will be emulated according to a drive type.

3.6.2.13 USB Configuration

The USB Configuration menu helps read USB information and configures USB settings.

3.6.3 Chipset

EBM-BDW User’s Manual

Item

Option

Description

VT-d

Disabled

Enabled[Default]

Check to enable VT-d function on MCH.

Item

Option

Description

Aperture Size

128MB

256MB[Default]

Select the Aperture Size. Note: Above 4GB MMIO BIOS assignment

3.6.3.1 System Agent (SA) Configuration

3.6.3.1.1 Graphics Configuration

58 EBM-BDW User’s Manual

512MB 1024MB 2048MB 4096MB

is automatically enabled when selecting 2048 aperture. To use this feature, please disable CSM Support.

CD C1k Frequency

337.5Mhz 450Mhz 540Mhz 675Mhz

Auto[Default]

Select CD C1k Frequency.

DVMT Pre-Allocated

32M[Default]/64M/96M128M/160M/

192M/224M/256M/288M/320M/352M/

384M/416M/448M/480M/512M/

1024M/2016M

Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device.

DVMT Total Gfx Mem

128M

256M[Default]

Max

Select DVMT 5.0 Total Graphics Memory size used by the Internal Graphics Device.

GFx Low Power Mode

Disabled

Enabled[Default]

This option is applicable for SFF only.

Item

Option

Description

Primary IGFX Boot Display

VBIOS Default[Default]

HDMI

LVDS

Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display.

CH7511 EDID Panel Option

1024x768 24/1[Default]

800x600 18/1

Port1-EDP to LVDS (Chrotel 7511) Panel EDID Option.

User’s Manual

3.6.3.1.1.1 LCD Control

EBM-BDW User’s Manual

1024x768 18/1 1366x768 18/1 1024x600 18/1 1280x800 18/1

1920x1200 24/2

640x480 18/1

800x480 18/1 1920x1080 18/2 1280x1024 24/2

1440x900 18/2

1600x1200 24/2

1366x768 24/1 1920x1080 24/2 1680x1050 24/2

Backlight brightness (%)

00% 25% 50% 75%

100%[Default]

Select LVDS back light PWM duty.

LVDS Back Light PWM

Frequency

200Hz[Default]

300Hz 400Hz 500Hz

700 Hz

1kHz 2kHz 3kHz 5kHz

Select LVDS back light PWM Frequency.

Active LFP

No LVDS

eDP Port-A[Default]

Select the Active LFP Configuration. No LVDS: VBIOS does not enable LVDS. eDP Port-A:LFP Driven by Int-DisplayPort encoder from Port-A. (through PCH).

60 EBM-BDW User’s Manual

Item

Option

Description

PCH LAN(PHY) Controller

Disabled

Enabled[Default]

Enable or disable LAN1 NIC.

3.6.3.1.2 Memory Configuration

User’s Manual

3.6.3.2 PCH-IO Configuration

EBM-BDW User’s Manual

Item

Option

Description

DMI Link ASPM Control

Disabled

Enabled[Default]

The control of Active State Power Management on both NB side and SB side of the DMI Link.

Subtractive Decode

Disabled[Default]

Enabled

Enable or disable PCI Express Subtractive Decode.

3.6.3.2.1 PCI Express Configuration

3.6.3.2.2 USB Configuration

62 EBM-BDW User’s Manual

Item

Option

Description

XHCI Mode

Smart Auto[Default],

Auto Enabled Disabled

Mode of operation of xHCI controller.

USB Ports Per-Port Disable

Control

Enabled,

Disabled[Default]

Control each of the USB ports (0~13) disabling.

Item

Option

Description

Azalia

Disabled

Enabled[Default]

Auto

Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled Enabled = Azalia will be unconditionally Enabled Auto = Azalia will be enabled if present, disabled otherwise.

Amplifier Gain

15.3 dB[Default],

21.1 dB

27.2 dB

31.8 dB

Select Amplifier Gain (dB).

3.6.3.2.3 PCH Azalia Configuration

User’s Manual

EBM-BDW User’s Manual

3.6.4 Security

 Administrator Password Set setup Administrator Password

 User Password Set User Password

3.6.4.1 Secure Boot menu

64 EBM-BDW User’s Manual

User’s Manual

Item

Option

Description

Secure Boot

Disabled[Default]

Enabled

Secure Boot can be enabled if 1.System running in User mode with enrolled Platform Key(PK) 2.CSM function is disabled.

Secure Boot Mode

Standard

Custom[Default]

Secure Boot mode selector. ‘Custom’ Mode enables users to change Image Execution policy and manage Secure Boot Keys.

Item

Option

Description

Default Key Provision

Enabled,

Disabled[Default]

Install Factory default Secure Boot Keys when System is in Setup Mode.

3.6.4.1.1 Key Management

EBM-BDW User’s Manual

Item

Option

Description

Setup Prompt Timeout

1~ 65535

Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.

Bootup NumLock State

On[Default]

Off

Select the Keyboard NumLock state

Quiet Boot

Disabled[Default]

Enabled

Enables or disables Quiet Boot option

Fast Boot

Disabled[Default]

Enabled

Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options.

Boot Option #1/2

Sets the system boot order.

3.6.5 Boot

66 EBM-BDW User’s Manual

3.6.6 Save and exit

User’s Manual

3.6.6.1 Save Changes and Reset

Reset the system after saving the changes.

3.6.6.2 Discard Changes and Reset

Any changes made to BIOS settings during this session of the BIOS setup program are

EBM-BDW User’s Manual

discarded. The setup program then exits and reboots the controller.

3.6.6.3 Restore Defaults

This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting.

3.6.6.4 Launch EFI Shell from filesystem device

Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices.

68 EBM-BDW User’s Manual

User’s Manual

4. Drivers Installation

Note: Installation procedures and screen shots in this section are

for your reference and may not be exactly the same as shown on your screen.

EBM-BDW User’s Manual

Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the

index page of Avalue’s products

automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Driver_Chipset\Intel\EBM-BDW.

Note: The installation procedures and

screen shots in this section are based on Windows 8 operation system. If the warning message appears while the installation process, click Continue to go on.

Step 3. Wait while installing.

Step1. Click Next.

Step 4. Click Restart Now or Restart Later to complete setup.

Step 2. Click Accept.

4.1 Install Chipset Driver

70 EBM-BDW User’s Manual

4.2 Install Ethernet Driver

Insert the Supporting DVD-ROM to DVD-ROM

drive, and it should show the index page of Avalue’s

products automatically. If not, locate Index.htm and choose the product from the menu left, or link to

\Driver_Gigabit\Intel\I210AT_I218LM\EBM-BDW_LAN.

Note: The installation procedures and screen shots

in this section are based on Windows 8 operation system. If the warning message appears while the installation process, click Continue to go on.

Step 3. Click Next.

Step1. Click Next to start installation.

Step 4. Click Install.

Step 2. Click Next to proceed setup.

Step 5. Wait while installing.

User’s Manual

EBM-BDW User’s Manual

Step 6. Wait while installing.

Step 7. Click Finish to complete setup.

72 EBM-BDW User’s Manual

4.3 Install IRST Driver

Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the

index page of Avalue’s products

automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Utility\EBM-BDW_IRST.

Note: The installation procedures and

screen shots in this section are based on Windows 8 operation system. If the warning message appears while the installation process, click Continue to go on.

Step 3. Click Next.

Step1. Click Next to start installation.

Step 4. Click Next. Step 2. Click Next to proceed setup.

Step 5. Click Next.

User’s Manual

EBM-BDW User’s Manual

Step 6. Wait while installing.

Step 7. Click Finish to complete setup.

74 EBM-BDW User’s Manual

4.4 Install ME Driver

Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the

index page of Avalue’s products

automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Utility\EBM-BDW_ME.

Note: The installation procedures and

screen shots in this section are based on Windows 8 operation system. If the warning message appears while the installation process, click Continue to go on.

Step 3. Click Next.

Step1. Click Next to start installation.

Step 4. Wait while installing. Step 2. Click Next to proceed setup.

Step 5. Click Finish to complete setup.

User’s Manual

EBM-BDW User’s Manual

Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \VGA\EBM-BDW.

Note: The installation procedures and

screen shots in this section are based on Windows 8.1 operation system.

Step 3. Click Next.

Step 1. Click Next to continue installation.

Step 4. Click Next.

Step 2. Click Yes to accept license agreement.

Step 5. Click Next.

4.5 Install VGA Driver

76 EBM-BDW User’s Manual

User’s Manual

Step 6. Click Finish to complete setup.

EBM-BDW User’s Manual

Insert the Supporting CD-ROM to CD-ROM drive,

and it should show the index page of Avalue’s

products automatically. If not, locate Index.htm and choose the product from the menu left, or link to

\Driver_Audio\Realtek\ALC892\EBM-BDW_Audio.

Note: The installation procedures and screen shots in

this section are based on Windows 8 operation system.

Step 3. Click Next to continue setup.

Step 1. Click Next to continue setup.

Step 4. Wait while installing.

Step 2. Click Next.

Step 5. Click Finish to complete the setup.

4.6 Install Audio Driver (For Realtek ALC892)

78 EBM-BDW User’s Manual

User’s Manual

5. Mechanical Drawing

EBM-BDW User’s Manual

Unit: mm

80 EBM-BDW User’s Manual

User’s Manual

Unit: mm

EBM-BDW User’s Manual

Avalue Technology EBM-BDW User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
