Avalue XTX-PNV User Manual

XTX-PNV
Intel Pineview XTX Module
User’s Manual
1st Ed – 27 December 2010
Part No. E2047275400R
XTX-PNV
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Copyright Notice
Copyright © 2011 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
2 XTX-PNV User’s Manual
User’s Manual
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used here in:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure to
perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Avalue’s products. In
XTX-PNV User’s Manual
3
XTX-PNV
fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Avalue’s engineers every business day.
We are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or e-mail
us.
Headquarters and Branch Avalue USA
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Chung Ho City, Taipei,
Taiwan
Tel:+886-2-8226-2345
Fax: +886-2-8226-2777
Information:sales@avalue.com.tw
Service: service@avalue.com.tw
BCM Advanced Research
BCM Advanced Research an Avalue Company
7 Marconi, Irvine, CA92618
Tel: +1-949-470-1888
Fax: +1-949-470-0971
Information: BCMSales@bcmcom.com
Web: www.bcmcom.com
Avalue Technology Inc.
200 Tornillo Way, Suite 210, Tinton Falls,
NJ 07712
Tel: +1-732-578-0200
Fax: +1-732-578-0250
Information: sales@avalue-usa.com
Service: support@avalue-usa.com
Avalue Europe
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: +45-7025-0310
Fax:+45-4975-5026
Information: sales.europe@avalue.com.tw
Service: service.europe@avalue.com.tw
Avalue China
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: +86-21-5169-3609
Fax:+86-21-5445-3266
Information: sales.china@avalue.com.cn
Service: service@avalue.com.tw
Avalue Japan
Avalue Technology Inc.
2F keduka-Bldg, 2-27-3 Taito,
Taito-Ku, Tokyo 110-0016 Japan
Tel: +81-3-5807-2321
Fax: +81-3-5807-2322
Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw
4 XTX-PNV User’s Manual
User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Avalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.
XTX-PNV User’s Manual
5
XTX-PNV
Contents
1.1 Safety Precautions ....................................................................................................8
1.2 Packing List...............................................................................................................8
1.3 Document Amendment History .................................................................................9
1.4 Manual Objectives...................................................................................................10
1.5 System Specifications .............................................................................................11
1.6 Architecture Overview – Block Diagram..................................................................13
2.1 Product Overview....................................................................................................15
2.2 Installation Procedure .............................................................................................16
2.2.1 Main Memory.................................................................................................................................. 17
2.3 Jumper and Connector List .....................................................................................19
2.4 Setting Jumpers & Connectors ...............................................................................20
2.4.1 AT/ATX mode/ AT/ATX power selection (SW1)............................................................................. 20
2.4.1.1 Signal Description –AT/ATX mode/ AT/ATX power selection ................................................... 20
2.4.2 Bypass / scaler Mode selection for LCD Mode (SW2)................................................................... 21
2.4.2.1 Signal description- Bypass / scaler Mode selection .................................................................. 21
3.1 Introduction .............................................................................................................23
3.2 Starting Setup .........................................................................................................23
3.3 Using Setup ............................................................................................................24
3.4 Getting Help ............................................................................................................25
3.5 In Case of Problems................................................................................................25
3.6 Main Menu ..............................................................................................................26
3.6.1 Main Menu and System information............................................................................................... 27
3.6.1.1 Main Menu Selection...........................................................................................................................27
3.6.2 Advanced BIOS Settings................................................................................................................ 28
3.6.2.1 Configure advanced CPU settings........................................................................................................29
3.6.2.2 IDE Configuration................................................................................................................................31
3.6.2.3 Floppy Configuration...........................................................................................................................33
3.6.2.4 Super I/O configuration........................................................................................................................34
3.6.2.5 Hardware Health configuration............................................................................................................36
3.6.2.6 ACPI configuration..............................................................................................................................37
3.6.2.6.1 General ACPI settings.....................................................................................................................38
3.6.2.6.2 Advanced ACPI Configuration....................................................................................................... 39
3.6.2.6.3 South Bridge ACPI configuration...................................................................................................40
3.6.2.7 AHCI Settings......................................................................................................................................41
3.6.2.7.1 AHCI Port0 .....................................................................................................................................42
3.6.2.7.2 AHCI Port1 .....................................................................................................................................43
3.6.2.7.3 AHCI Port2 .....................................................................................................................................44
6 XTX-PNV User’s Manual
User’s Manual
3.6.2.8 USB configuration ...............................................................................................................................45
3.6.2.8.1 USB mass storage configuration.....................................................................................................46
3.6.2.9 APM configuration ..............................................................................................................................47
3.6.3 Advanced PCIPnP Settings ........................................................................................................... 48
3.6.4 Boot settings................................................................................................................................... 50
3.6.4.1 Boot settings configuration.................................................................................................................. 51
3.6.4.2 Boot device Priority.............................................................................................................................52
3.6.4.3 Hard Disk Drives .................................................................................................................................52
3.6.4.4 Removable Drives................................................................................................................................53
3.6.5 Security settings ............................................................................................................................. 53
3.6.6 Advanced Chipset Settings ............................................................................................................ 54
3.6.6.1 North bridge Chipset configuration......................................................................................................55
3.6.6.2 Video Function configuration..............................................................................................................56
3.6.6.3 South bridge Chipset configuration......................................................................................................58
3.6.7 Exit Options .................................................................................................................................... 59
3.6.7.1 Save Changes and Exit.............................................................................................................................59
3.6.7.2 Discard Changes and Exit ........................................................................................................................59
3.6.7.3 Discard Changes.......................................................................................................................................59
3.6.7.4 Load Optimal Defaults.............................................................................................................................59
3.6.7.5 Load Failsafe Defaults.........................................................................................................................59
4.1 Install Chipset Driver (For Intel ICH8M) ..................................................................61
4.2 Install Ethernet Driver (For Realtek 8103EL) ..........................................................62
4.3 Install Audio Driver (For Realtek ALC888) ..............................................................63
4.4 Install VGA Driver (For Pineview)............................................................................64
5. Mechanical Drawing.......................................................................................................65
XTX-PNV User’s Manual
7
XTX-PNV
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
Caution!
Always ground yourself to remove any static charge before touching the CPU card. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
z 1 x XTX-PNV Intel Pineview XTX Module
z 1 x Quick Installation Guide
z 1 x DVD-ROM contains the followings:
User’s Manual (this manual in PDF file) Ethernet driver and utilities VGA drivers and utilities Audio drivers and utilities
8 XTX-PNV User’s Manual
1.3 Document Amendment History
Revision Date Comment
User’s Manual
1st December
Initial Release
2010
XTX-PNV User’s Manual
9
XTX-PNV
1.4 Manual Objectives
This manual describes in detail the Avalue Technology XTX-PNV Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with XTX-PNV series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.
10 XTX-PNV User’s Manual
1.5 System Specifications
System
User’s Manual
CPU
BIOS System Chipset I/O Chip
System Memory
Watchdog Timer
H/W Status Monitor
Expansion
I/O
MIO USB IrDA
Display
Onboard Intel PNV-M N455 1.66GHz
Onboard Intel PNV-D D525 1.8GHz (Optional)
AMI 8Mbit
Intel ICH8-M Chipset
Winbond W83627DHG-P
One 204-pin SODIMM socket supports up to 2GB DDR3 SDRAM,
supports 800/1066 MHz
Reset: 1 ~ 255 min. and 1 sec. or 1 min./step
Monitoring system temperature, voltage, and cooling fan status. Auto
trotting control when CPU overheats
4 PCIex1, 4 PCI, 1 LPC Bus, I2C Bus
1 x EIDE, 3 x SATA, 1 x FDD/LPT, 2 x TTL Serial, 1 x K/B & Mouse
6 x USB 2.0 ports
115k bps, IrDA 1.0 Compliant
Chipset
Resolution
Multiple Display LCD Interface
Audio
AC97 Codec
Audio Interface
Ethernet
LAN Ethernet Interface
Intel Pineview integrated, Gen3.5 + GFX Core @ 400MHz (PNV-D)
Intel Pineview integrated, Gen3.5 + GFX Core @ 200MHz (PNV-M)
VGA mode : up to 2048 x 1536 @ 60 Hz (PNV-D)
VGA mode : up to 1400 x 1050 @ 60 Hz (PNV-M)
VGA + LVDS
Dual-Channel 18/24-bit LVDS (from Scaler)
Realtek ALC888
Line in, Line out & Mic in
AC97 Rev2.2 Compatible, Digital High Definition Audio Interface with
support for multiple audio codecs
Realtek 8103EL
10/100Base-Tx Fast Ethernet compatible
XTX-PNV User’s Manual
11
XTX-PNV
Mechanical & Environmental
Power Requirement ACPI Power Type Operation Temperature
Storage Temp.
Operating Humidity Size ( L x W ) Weight
+5V, 5Vsb (for ATX only)
ACPI 3.0 Compliant
AT/ ATX
0 ~ 60°C (32~140°F)
-20~80°C
0% ~ 90% Relative Humidity, Non-condensing
4.5" x 3.7" (114mm x 95mm)
0.44lbs (0.2kg)
12 XTX-PNV User’s Manual
User’s Manual
1.6 Architecture Overview – Block Diagram
The following block diagram shows the architecture and main components of XTX-PNV
XTX-PNV User’s Manual
13
XTX-PNV
2. Hardware Configuration
14 XTX-PNV User’s Manual
2.1 Product Overview
User’s Manual
XTX-PNV User’s Manual
15
XTX-PNV
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the SODIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change CMOS settings to support
flat panel.
4. Connect power supply to the board via the ATXPWR.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the “LOAD BIOS
DEFAULTS” feature. The Integrated Peripheral Setup and the Standard CMOS Setup
Window must be entered and configured correctly to match the particular system
configuration.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.
16 XTX-PNV User’s Manual
User’s Manual
2.2.1 Main Memory
XTX-PNV provides one 204-pin SODIMM sockets to support DDR3 SDRAM. The total
maximum memory size is 2GB.
SODIMM
Make sure to unplug the power supply before adding or removing SODIMMs
or other system components. Failure to do so may cause severe damage to
both the board and the components.
XTX-PNV User’s Manual
17
XTX-PNV
Locate the SODIMM socket on the board.
Hold two edges of the SODIMM module carefully. Keep away of touching its
connectors.
Align the notch key on the module with the rib on the slot.
Firmly press the module into the socket which automatically snaps into the mounting
notch. Do not force the SODIMM module in with extra force as the SODIMM module
only fits in one direction.
Mounting Notch Notch Key
Ejector
204-pin DDR3 SODIMM
To remove the SODIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the SODIMM module.
Note:
(1) Please do not change any DDR3 SDRAM parameter in BIOS setup to increase
your system’s performance without acquiring technical information in advance.
(2) Static electricity can damage the electronic components of the computer or
optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.
18 XTX-PNV User’s Manual
User’s Manual
2.3 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board's jumpers and connectors.
Connectors
Label Function Note SW1
SW2
XTX1 XTX2
AT/ATX mode/ AT/ATX power select
Bypass / scaler Mode selection for LCD mode
PIN
XTX connector 1
XTX connector 2
XTX3 XTX4 DIMM1
XTX connector 3
XTX connector 4
204-pin DDR3 SDRAM DIMM socket
XTX-PNV User’s Manual
19
XTX-PNV
2.4 Setting Jumpers & Connectors
2.4.1 AT/ATX mode/ AT/ATX power selection (SW1)
*Default
AT/ATX Power
AT power
OFF
OFF
1
2
ATX power*
1
2
=
>
ON
ON
AT/ATX mode
AT mode
OFF
1
>
2
ATX mode*
ON
OFF
1
=
2
ON
2.4.1.1 Signal Description –AT/ATX mode/ AT/ATX power selection
AT/ATX power / AT/ATX mode Description
AT mode/ AT power
AT mode/ ATX power
ATX mode/ AT power
ATX mode/ ATX power
Use AT power input, and set the board in AT
mode.
Use ATX power input, and set the board in AT
mode.
Use AT power input, and set the board in ATX
mode.
Use ATX power input, and set the board in ATX
mode.
20 XTX-PNV User’s Manual
2.4.2 Bypass / scaler Mode selection for LCD Mode (SW2)
Bypass Mode selection
User’s Manual
*Default
XX
ON
ON
ON
Scaler Mode selection
XX
=
Scaler Mode selection*
XX
=
4
3
>
2
>
1
>
4
3
>
2
1
>
4
3
2
>
1
>
OFF
OFF
OFF
2.4.2.1 Signal description- Bypass / scaler Mode selection
Bypass / scaler enable Description
Bypass Mode is enabled
Scaler Mode is enabled
Scaler Mode is enabled
XTX-PNV User’s Manual
Enable 1 LCD/48bit
Enable 2 LCD/24bit
Enable 2 LCD/18bit
21
XTX-PNV
3. BIOS Setup
22 XTX-PNV User’s Manual
User’s Manual
3.1 Introduction
The BIOS setup program allows users to modify the basic system configuration. In this
following chapter will describe how to access the BIOS setup program and the
configuration options that may be changed.
3.2 Starting Setup
The AMIBIOS™ is immediately activated when you first power on the computer. The BIOS
reads the system information contained in the CMOS and begins the process of checking
out the system and configuring it. When it finishes, the BIOS will seek an operating system
on one of the disks and then launch and turn control over to the operating system.
While the BIOS is in control, the Setup program can be activated in one of two ways:
By pressing <Del> immediately after switching the system on, or
By pressing the <Del> key when the following message appears briefly at the bottom of the
screen during the POST (Power On Self Test).
Press DEL to enter SETUP
If the message disappears before you respond and you still wish to enter Setup, restart the
system to try again by turning it OFF then ON or pressing the "RESET" button on the
system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete>
keys. If you do not press the keys at the correct time and the system does not boot, an error
message will be displayed and you will again be asked to.
Press F1 to Continue, DEL to enter SETUP
XTX-PNV User’s Manual
23
XTX-PNV
3.3 Using Setup
In general, you use the arrow keys to highlight items, press <Enter> to select, use the
PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to
quit. The following table provides more detail about how to navigate in the Setup program
using the keyboard.
Button Description
↑↓ Select item
Select screen
+/- Change Option /Field
Enter Go to Sub Screen
PgUp key Previous page
PgDn key Next page
Home Go to top of screen
End Go to bottom of Screen
F2 , F3 key Change colors
F7 key Discard changes
F8 key Load Failsafe Defaults
F9 key Load Optimal Defauls
F10 key Save and Exit
Esc key Exit current page and return to Main Menu
Navigating Through The Menu Bar
Use the left and right arrow keys to choose the menu you want to be in.
Note: Some of the navigation keys differ from one screen to another.
To Display a Sub Menu
Use the arrow keys to move the cursor to the sub menu you want. Then press
<Enter>. A “¾” pointer marks all sub menus.
24 XTX-PNV User’s Manual
User’s Manual
3.4 Getting Help
Press F1 to pop up a small help window that describes the appropriate keys to use and the
possible selections for the highlighted item. To exit the Help Window press <Esc> or the F1
key again.
3.5 In Case of Problems
If, after making and saving system changes with Setup, you discover that your computer no
longer is able to boot, the AMIBIOS™ supports an override to the CMOS settings which
resets your system to its defaults.
The best advice is to only alter settings which you thoroughly understand. To this end, we
strongly recommend that you avoid making any changes to the chipset defaults. These
defaults have been carefully chosen by both Award and your systems manufacturer to
provide the absolute maximum performance and reliability. Even a seemingly small change
to the chipset setup has the potential for causing you to use the override.
XTX-PNV User’s Manual
25
XTX-PNV
3.6 Main Menu
Once you enter the AMIBIOS™ CMOS Setup Utility, the Main Menu will appear on the
screen. The Main Menu allows you to select from several setup functions and two exit
choices. Use the arrow keys to select among the items and press <Enter> to accept and
enter the sub-menu.
Note that a brief description of each highlighted selection appears at the bottom of the
screen.
Note: The BIOS setup screens shown in this chapter are for reference purposes
only, and may not exactly match what you see on your screen.
Visit the Avalue website (www.avalue.com.tw) to download the latest
product and BIOS information.
26 XTX-PNV User’s Manual
User’s Manual
3.6.1 Main Menu and System information
This section shows information about the BIOS, processor, System Memory as well as time
and date.
3.6.1.1 Main Menu Selection
This reference table shows the selections that you may make on the Main Menu.
Item Options Description
Time HH : MM : SS Set the system time Date Day/ Month/ year Set the system date
XTX-PNV User’s Manual
27
XTX-PNV
3.6.2 Advanced BIOS Settings
This section allows you to configure your CPU and other system devices for basic operation
through the following sub-menus.
28 XTX-PNV User’s Manual
User’s Manual
3.6.2.1 Configure advanced CPU settings
Use the CPU Configuration menu to view detailed CPU specifications and configuration.
XTX-PNV User’s Manual
29
XTX-PNV
This item allows you to setup the CPU thermal management function.
Item Options Description
In order to mask the physical CPUID for
Proscott core when running WinNT, Award
BIOS provides "Limit CPUID MaxVal" feature.
Max CPUID Value Limit
Execute-Disable Bit Capability
Hyper Threading Technology
Intel ® SpeedStep ™ tech
Intel ® C-STATE tech
Disabled,
Enabled
Disabled,
Enabled
Disabled,
Enabled
Disabled,
Enabled
Disabled,
Enabled
Enabling this feature will make the main board
BIOS respond "suitable", "virtual" CPUID to
OS kernel. So WinNT or the legacy OS can
use the masked CPUID to work well with the
new CPU design.
It can help prevent certain classes of malicious
buffer overflow attacks when combined with a
supporting operating system.
To enable or disable Intel® Hyper Threading
technology. This item allows you improve
parallelization of computations
This item allows you to enable or disable Intel
® SpeedStep ™ tech for high performance
and power-conservation
This item allows you to enable or disable Intel
® C-STATE tech in order for the software to
independently manage each core while the
actual power management adheres to the
Enhanced C-States
Disabled,
Enabled
platform and CPU shared resources
This item allows you to enable or disable
Enhanced C-States
30 XTX-PNV User’s Manual
User’s Manual
3.6.2.2 IDE Configuration
Use the IDE Configuration menu to change and/or configure installed IDE devices
XTX-PNV User’s Manual
31
XTX-PNV
This item allows you to set the boot priority of the hard drives installed in the system.
Item Options Description
ATA/ IDE Configuration
Configure SATA as
Primary/ Secondary/ Third/
Fourth IDE Master
Primary/ Secondary/ Third/
Fourth IDE Slave
Hard Disk Write Protect
Disabled,
Compatible,
Enhanced
IDE,
AHCI
Not detected
Not detected
Disabled,
Enabled
This can be configured as Disabled,
Compatible or Enhanced.
Use this option to configure the SATA port as
an IDE drive or a SATA drive (AHCI mode)
Use the IDE Master and IDE Slave
configuration menu to view both primary and
secondary IDE device details and configure
the IDE devices connected to the system.
Use the IDE Master and IDE Slave
configuration menu to view both primary and
secondary IDE device details and configure
the IDE devices connected to the system.
Disable/ Enable device write protection. This
will effective only if device is accessed through
BIOS.
IDE Detect Time Out (Sec)
ATA (PI) 80Pin Cable Detection
0/ 5/ 10/ 15/ 20/ 25/ 30/
35
Host & Device,
Host,
Device
This allows you to select the time out value for
detecting ATA/ ATAPI devices.
This item allows you to select ATA cable
detection mode.
32 XTX-PNV User’s Manual
3.6.2.3 Floppy Configuration
Use the Floppy Configuration menu to set or change the configurations
for floppy disk drives.
User’s Manual
Floppy A [Disabled]
Floppy B [Disabled]
Item Options Description
Disabled (default)
360 KB 5¼”
1.2 MB 5¼”
720 KB 3 ½”
1.44 MB 3½”
The Floppy A configuration option determines
the type of installed floppy drives. The following
configuration options are available.
2.88 MB 3½”
Disabled (default)
360 KB 5¼”
1.2 MB 5¼”
The Floppy B configuration option determines
720 KB 3 ½”
the type of installed floppy drives. The following
configuration options are available.
1.44 MB 3½”
2.88 MB 3½”
XTX-PNV User’s Manual
33
XTX-PNV
3.6.2.4 Super I/O configuration
Use the Super IO Configuration menu for FDD controllers, parallel ports and serial ports.
34 XTX-PNV User’s Manual
User’s Manual
Item Options Description
On Board Floppy Controller
[Enabled]
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port Address [378]
Disabled
Enabled (DEFAULT)
Disabled
3F8/IRQ4 (DEFAULT)
3E8/IRQ4
2E8/IRQ3
Disabled
2F8/IRQ3 (DEFAULT)
3E8/IRQ4
2E8/IRQ3
Normal (DEFAULT)
IrDA
ASK IR
Disabled
378 (DEFAULT)
278
3BC
Allows BIOS to disable the floppy controller
Use the Serial Port1 Address option to select
the Serial Port 1 base address.
Use the Serial Port2 Address option to select
the Serial Port 2 base address.
Use the Serial Port2 Mode option to select the
Serial Port2 operational mode.
Use the Parallel Port Address option to select
the parallel port base address.
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
FDD
Normal (DEFAULT)
Bi-directional
ECP
EPP
ECP & EPP
IRQ5
IRQ7 (DEFAULT)
Use the Parallel Port Mode option to select the
mode the parallel port operates in.
Use the Parallel Port IRQ selection to set the
parallel port interrupt address.
XTX-PNV User’s Manual
35
XTX-PNV
3.6.2.5 Hardware Health configuration
This section shows the operating temperature, fan speed and system voltage.
The following system temperature, fan speed and voltage are monitored.
System Temperature:
z System Temperature
z CPU Temperature
Voltage:
z Vcore
z AVCC
z 3VCC
z V5.0
z VDDR
z VGFX
z V1.05
z USB
z VBAT
CPUFAN mode setting: Configures CPUFAN for CPU temperature monitoring
CPUFAN PWM Control: Configures Voltage control function
36 XTX-PNV User’s Manual
User’s Manual
3.6.2.6 ACPI configuration
The ACPI Configuration menu configures Advanced Configuration and Power Interface
(ACPI) options.
XTX-PNV User’s Manual
37
XTX-PNV
3.6.2.6.1 General ACPI settings
Use this option to select the ACPI state when the system is suspended.
Item Options Description
Suspend Mode [Auto]
Repost Video on S3 Resume
[No]
S1 (POS),
S3 (STR),
Auto (
No (
DEFAULT)
DEFAULT)
Yes
Use the Suspend Mode option to specify the
sleep state the system enters when it is not being
used.
This item allows you to invoke VA BIOS POST
on S3/ STR resume.
38 XTX-PNV User’s Manual
3.6.2.6.2 Advanced ACPI Configuration
Use this menu to select ACPI state when system is suspended.
User’s Manual
Item Options Description
ACPI Version Features [ACPI
v1.0]
ACPI APIC support [Enabled]
AMI OEMB table [Enabled]
Headless mode [Disabled]
ACPI v1.0 (
ACPI v2.0,
ACPI v3.0,
ACPI v4.0
Enabled (
Disabled
Enabled (
Disabled
Disabled (
Enabled
DEFAULT)
DEFAULT)
DEFAULT)
DEFAULT)
This item allows you to enable RSDP pointers
to 64-bit fixed system description tables.
to add a pointer to an ACPI APIC table in the
RSDT (Root System Description Table)
to add a pointer to an OEMB table in the RSDT
table and
the Extended System Description Table (XSDT).
Enable/ Disable Headless operation mode
through ACPI.
XTX-PNV User’s Manual
39
XTX-PNV
3.6.2.6.3 South Bridge ACPI configuration
Use the South Bridge ACPI Configuration menu to select the ACPI state when system is
suspended.
Item Options Description
Energy Lake Feature [Disabled]
APIC ACPI SCI IRQ [Disabled]
USB device Wakeup From S3/S4
High Performance Event Timer
[Enabled]
HPET Memory Address
[FED00000h]
Disabled (
Enabled
Disabled (
Enabled
Disabled,
Enabled (
Disabled,
Enabled (
FED00000h (
FED01000h,
FED02000h
FED03000h
DEFAULT)
DEFAULT)
DEFAULT)
DEFAULT)
DEFAULT)
This item allows energy lake feature mode
selection.
To enable/ disable APIC ACPI SCI IRQ.
To enable/disable USB device Wake up From
S3/S4
This section helps to set high performance
event timer.
This item is for HPET memory address
selection
40 XTX-PNV User’s Manual
User’s Manual
3.6.2.7 AHCI Settings
This option is a system memory structure for data exchange between host system memory
and attached storage devices.
Note:
If SATA was set as “AHCI” instead of “IDE” in 3.6.2.2, “Hard Disk” would be shown for
“AHCI Port”. Therefore, “AHCI Port” shows not detected.
XTX-PNV User’s Manual
41
XTX-PNV
3.6.2.7.1 AHCI Port0
This option helps select the type of connected device
Item Options Description
SATA Port0 [Auto]
S.M.A.R.T. [Enabled]
Auto (
DEFAULT)
Not Installed
Disabled,
Enabled (
DEFAULT)
Serial port 0 mode selection.
Select the smart monitoring, analysis, and
reporting technology.
42 XTX-PNV User’s Manual
3.6.2.7.2 AHCI Port1
This option helps select the type of connected device
User’s Manual
Item Options Description
SATA Port1 [Auto]
S.M.A.R.T. [Enabled]
Auto (
DEFAULT)
Not Installed
Disabled,
Enabled (
DEFAULT)
Serial port 1 mode selection.
Select the smart monitoring, analysis, and
reporting technology.
XTX-PNV User’s Manual
43
XTX-PNV
3.6.2.7.3 AHCI Port2
This option helps select the type of connected device
Item Options Description
SATA Port2 [Auto]
S.M.A.R.T. [Enabled]
Auto (
DEFAULT)
Not Installed
Disabled,
Enabled (
DEFAULT)
Serial port 2 mode selection.
Select the smart monitoring, analysis, and
reporting technology.
44 XTX-PNV User’s Manual
User’s Manual
3.6.2.8 USB configuration
Use the USB Configuration menu to read USB information and configure settings.
Item Options Description
Legacy USB Support
[Enabled]
USB 2.0 Controller Mode
[Hi speed]
BIOS EHCI Hand-Off [Enabled]
Enabled (
HiSpeed (480Mbps)
FullSpeed (12Mpbs)
Enabled (
DEFAULT)
Disabled,
Auto
DEFAULT)
(
DEFAULT)
Disabled
Use this option to enable USB mouse and
USB keyboard support. Normally if this option
is not enabled, attached USB mouse or USB
keyboard is not available until a USB
compatible operating system is fully booted
with all USB drivers loaded. When this option
is enabled, any attached USB mouse or USB
keyboard can control the system even when
there is no USB driver loaded onto the
system.
This item allows you to select HiSpeed
(480Mbps) or FullSpeed (12Mpbs).
This is a workaround for OSs without EHCI
hand-off support. The EHCI ownership
change should be claimed by EHCI driver.
Hotplug USB FDD Support
Auto (
DEFAULT)
The USB FDD is a slim type floppy disk drive
(FDD) with a Universal Serial Bus (USB)
interface.
XTX-PNV User’s Manual
45
XTX-PNV
3.6.2.8.1 USB mass storage configuration
This Screen appears if a USB drive is connected to one of the USB ports or connectors. If
this option is selected the below menu appears.
Item Options Description
USB Mass Storage Reset Delay
Device #1
Emulation Type
Device #2
Emulation Type
Emulation type
[Auto]
[Auto]
10, 20
30, 40
Auto, Floppy, Forced
FDD, Hard-Disk,
CD-ROM.
Auto, Floppy, Forced
FDD, Hard-Disk,
CD-ROM.
If Auto, USB devices less than 530MB will be emulated as a floppy drive
and the remaining as hard drive. Force FDD option can be used to force a
FDD formatted drive to boot as FDD (Ex. ZIP drive).
Time the BIOS will wait for the USB flash drive
to initialize
This item allows you to set up mass storage
devices.
This item allows you to set up mass storage
devices.
46 XTX-PNV User’s Manual
3.6.2.9 APM configuration The APM menu configures the advanced power management options.
User’s Manual
Item Options Description
Power Management/ APM
[Enabled]
Power Button Mode
Restore on AC Power Loss by
IO
[Power off]
Resume On Ring [Disabled]
Resume on PCI [Disabled]
Enabled (
Disabled
On/ Off,
Suspend
Power On,
Power Off (
Last State
Disabled (
Enabled
Disabled (
Enabled
DEFAULT)
DEFAULT)
DEFAULT)
DEFAULT)
This item helps to select power management
mode.
This section allows you to select power button
mode.
Use this to set up the system response after a
power failure.
Use this option to enable activity on the RI
(ring in) modem line to arouse the system from
a suspended or standby state.
Use this option to enable activity on the PCI
signal to arouse the system from a suspended
or standby state.
Resume On PCIE [Disabled]
Resume On RTC Alarm
[Disabled]
Disabled (
Enabled
Disabled (
Enabled
DEFAULT)
DEFAULT)
Use this option to enable activity on the PCIE
signal to arouse the system from a suspended
or standby state.
Use this option to specify the time the system
should be roused from a suspend state.
XTX-PNV User’s Manual
47
XTX-PNV
3.6.3 Advanced PCIPnP Settings
The settings in this section specifically deal with the PCI bus and Plug and Play (PnP).
48 XTX-PNV User’s Manual
Item Options Description
Clear NVRAM [No]
Plug & Play O/S [No]
No (
DEFAULT)
No (
DEFAULT)
Yes
Yes
User’s Manual
Set this value to force the BIOS clear
Non-volatile Random Access Memory
(NVRAM). The Original and Fail-Safe default
setting is No.
Choose No to let the BIOS configure all
devices in the system. This setting is
appropriate when using a Plug and Play
operating system.
PCI latency timer [64]
Allocate IRQ to PCI VGA [yes]
Palette Snooping [Disabled]
PCI IDE BusMaster [Enabled]
Off board PCI/ISA IDE Card
[Auto]
IRQ3/ 4/ 5/ 7/ 9/ 10/
11/12/13/14/15 [Available]
32, 64, 96, 128,
160, 192, 224, 248
No,
Yes (
DEFAULT)
Enabled/Disabled
(
DEFAULT)
Enabled(
Auto (
PCI Slot 1/ 2/ 3/ 4/ 5/ 6
Available (
DEFAULT)/
Disabled
DEFAULT)
DEFAULT)
Reserved
This feature controls how long a PCI device
can hold the PCI bus before another takes
over. It is set to 64 clock cycles.
If this item is enabled, an IRQ will be assigned
to the PCI VGA graphics system. You set this
value to No to free up an IRQ.
This item is designed to solve problems
caused by some non-standard VGA card.
When set to enabled, BIOS uses PCI bus
mastering for reading/writing to IDE drives.
Some PCI IDE cards may require this to be
set to the PCI slot number that is holding the
card. When set to auto will works for most PCI
IDE cards.
Use the IRQ# address to specify what IRQs
can be assigned to a particular peripheral
device.
DMA Channel 0/1/3/5/6/7
Reserved Memory size
Available (
16K, 32K, 64K
DEFAULT)
Reserved
Disabled
Use this selection to adjust DMA mode options.
Use Default value if the IDE disk drive support
cannot be determined.
Use this option to specify the amount of memory
that should be reserved for legacy ISA devices.
XTX-PNV User’s Manual
49
XTX-PNV
3.6.4 Boot settings
Use the Boot menu to configure system boot options.
50 XTX-PNV User’s Manual
User’s Manual
3.6.4.1 Boot settings configuration Use Boot Settings Configuration menu to configure advanced boot options.
Item Options Description
Quick Boot [Enabled]
Quiet Boot [Disabled]
AddOn ROM Display Mode
[Force BIOS]
Bootup Num-Lock [On]
PS/2 Mouse support [Auto]
Wait For “F1” If Error
Disabled,
Enabled (
Disabled (
Enabled
Force BIOS (
Keep Current
On (
DEFAULT)
Off
Auto (
DEFAULT)
Disabled,
Enabled
Disabled,
DEFAULT)
DEFAULT)
DEFAULT)
This item allows BIOS to skip certain tests
while booting. This will decrease the time
needed to boot the system.
If set to Disabled, the BIOS displays normal
POST messages. If Enabled, an OEM Logo is
shown instead of POST messages.
This option allows add-on ROM (read-only
memory) messages to be displayed.
This option allows the number Lock setting to
be modified during boot up.
This interface utilizes a bidirectional serial
protocol to communicate with the computer's
auxiliary device controller
When set to enable, the system waits for the
[Enabled]
Hit “DEL” Message Display
[Enabled]
Interrupt 19 capture
[Disabled]
Enabled (
Disabled,
Enabled (
Disabled (
Enabled
DEFAULT)
DEFAULT)
DEFAULT)
F1 key to be pressed when error occurs.
This BIOS feature allows you to control the
display of the Hit “DEL” to enter setup
message during memory initialization.
This item allows options for ROMs to trap
interrupt 19.
XTX-PNV User’s Manual
51
XTX-PNV
3.6.4.2 Boot device Priority
Use the Boot Device Priority to specify the boot sequence from the available devices.
3.6.4.3 Hard Disk Drives
This option specifies boot sequence from the available devices
52 XTX-PNV User’s Manual
3.6.4.4 Removable Drives
This option specifies boot sequence from the available devices
User’s Manual
3.6.5 Security settings
Security Setup options such as password protection and virus protection are described in
this section.
XTX-PNV User’s Manual
53
XTX-PNV
Change Supervisor / User Password
Use the Change User/ Supervisor Password to set or change a User/supervisor password.
The default for this option is Not Installed. If a User/ supervisor password must be installed,
select this field and enter the password. After the password has been added, Install
appears next to Change User/ Supervisor Password.
Clear User password
Use Clear User Password to delete a user password.
Item Options Description
Boot Sector Virus protection
[Disabled]
Disabled (Default)
Enabled
The boot sector virus protection will warn if
any program tries to write to the boot sector.
3.6.6 Advanced Chipset Settings
Use Advanced Chipset Settings menu to access Northbridge and Southbridge
Configuration menus
54 XTX-PNV User’s Manual
User’s Manual
3.6.6.1 North bridge Chipset configuration
Use the Northbridge chipset configuration menu to configure the Northbridge chipset.
Item Option Description
DRAM Frequency [Auto]
Configure DRAM Timing by
SPD [Enabled]
Initiate Graphic Adapter [IGD]
Internal Graphics Mode Select
[Enabled]
Auto (Default)
Max MHz
Disabled,
Enabled (Default)
IGD, PCI/IGD, PCI/PEG,
PEG/IGD, PEG/PCI
Enabled 8MB
This item allows you to manually
change DRAM frequency.
This item allows you to enable or
disable by DRAM SPD.
This item allows you to select
which graphics controller to use
as the primary boot device.
This option determines the
amount of system memory that
can be used by the internal
graphics device.
XTX-PNV User’s Manual
55
XTX-PNV
3.6.6.2 Video Function configuration
Use this menu to configure Video display and LCD backlight.
56 XTX-PNV User’s Manual
User’s Manual
Item Option Description
DVMT Mode Select
DVMT/ FIXED Memory
Boot Display Device
Flat Panel Type
Fixed Mode,
DVMT Mode
64MB,
128MB,
Maximum DVMT
VBIOS-DEFAULT
CRT,
LVDS,
CRT+LVDS (Default)
640 x 480,
800 x 600,
1024 x 768,
1024 x 600,
1024 x 576,
800 x 480,
1280 x 720,
1280 x 768,
Displays the active system
memory mode.
Specifies the amount of DVMT/
FIXED system memory to allocate
for video memory.
This option selects the display
device the system uses when it
boots.
This item
PC type being used.
specifies the flat panel
Spread Spectrum Clock
[Disabled]
LCD Backlight Mode
PWM value [128]
PWM clock [24Mhz]
PWM PreScale
PWM type
800 x 600,
1024 x 600,
1024 x 768
1024 x 768,
1024 x 768,
1280 x 800,
1280 x 600,
1366 x 768
Disabled (Default)
Enabled
PWM mode
0 ~ 255
24M or 180khz
090
Pushpull (Default)
OpenDrain
This item allows you to enable or
disable spread spectrum clock.
This item configures the settings
for Backlight control
XTX-PNV User’s Manual
57
XTX-PNV
3.6.6.3 South bridge Chipset configuration Use the Southbridge chipset configuration menu to configure Southbridge chipset
Item Option Description
USB Functions
USB 2.0 Controller [Enabled]
HAD Controller [Enabled]
SMBUS Controller [Enabled]
OnBoard LAN Boot [Disabled]
Advanced Power control
[Disabled]
PCIE Port 0/ 1/ 2/ 3/ 4 [Auto]
Disables,
2/ 4/ 6/ 8/ 10 USB Ports
Disabled,
Enabled
Disabled,
Enabled
Disabled,
Enabled
Disabled,
Enabled
Disabled
0/ 3/ 6/ 10
Disabled,
Enabled,
Auto
Enables the number of desired
ports or disables USB function.
This option is disabled by default.
Enable the Southbridge high
definition audio controller.
This option is enabled by default.
This item helps to set onboard
LAN boot mode.
This option disables access to
Advanced Power control
This section allows selecting
PCIE port 0/ 1/ 2/ 3/ 4 mode.
PCIE High Priority Port
[Disabled]
PCIE Port 0/ 1/ 2/ 3/ 4 IOxAPIC
Enable [Disabled]
58 XTX-PNV User’s Manual
Disabled,
Enabled,
Auto
Disabled,
Enabled
This item helps to set PCIE high
priority port.
This helps to enable or disable
PCIE port 0/ 1/ 2/ 3/ 4 IOxAPIC.
User’s Manual
3.6.7 Exit Options
Use the Exit menu to load default BIOS values, optional failsafe values and to save
configuration changes.
3.6.7.1 Save Changes and Exit
Use the save changes and reset option to save the changes made to the BIOS options and
to exit the BIOS configuration setup program.
3.6.7.2 Discard Changes and Exit
Use the Discard changes and Exit option to exit the system without saving the changes
made to the BIOS configuration setup program.
3.6.7.3 Discard Changes
Use the Discard Changes option to discard the changes and remain in the BIOS
configuration setup program.
3.6.7.4 Load Optimal Defaults
Use the Load Optimal Defaults option to load the optimal default values for each of the
parameters on the setup menus. F9 key can be used for this operation.
3.6.7.5 Load Failsafe Defaults
Select this option to replace most of the current BIOS settings with predefined settings
(coded into the BIOS) that are intended to put the system into as stable a state as possible
XTX-PNV User’s Manual
59
XTX-PNV
4. Drivers Installation
Note: Installation procedures and screen shots in this section are
for your reference and may not be exactly the same as
shown on your screen.
60 XTX-PNV User’s Manual
4.1 Install Chipset Driver (For Intel ICH8M)
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \Driver_Chipset\ Intel\ ICH8M.
Note: The installation procedures and
screen shots in this section are based on Windows XP operation system. If the warning message appears while the installation process, click Continue to go on.
Step 3. Click Next.
User’s Manual
Step1. Welcome to setup and click next Step 4. Click Next
Step 2. Click Next to accept license
Step 5. Click Finish to complete setup.
agreement
XTX-PNV User’s Manual
61
XTX-PNV
4.2 Install Ethernet Driver (For Realtek 8103EL)
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \Driver_Network\Realtek\RTL8103E.
Note: The installation procedures and
screen shots in this section are based on Windows XP operation system.
Step 3. Installing driver...
Step 1. welcome to the Install Shield, click Next
Step 2. Click Install to begin
Step 4. Click Finish to complete
62 XTX-PNV User’s Manual
4.3 Install Audio Driver (For Realtek ALC888)
User’s Manual
Insert the Supporting CD-ROM to
CD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \Driver_Audio\ Realtek\ ALC888.
Note: The installation procedures and
screen shots in this section are based on Windows 2000 operation system.
.
Step 2. The program automatically
executes the Setup.
Step 1. welcome to the Install Shield, click Next
Step 3. Click Finish to complete the setup
XTX-PNV User’s Manual
63
XTX-PNV
4.4 Install VGA Driver (For Pineview)
Insert the Supporting CD-ROM to
CD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \Driver_Video\ Intel\ Pineview.
Note: The installation procedures and
screen shots in this section are based on Windows 2000 operation system.
Step 3. Click Next
Step 1. welcome to Setup program , click Next
Step 2. click yes to accept agreement
64 XTX-PNV User’s Manual
Step 4. Click Next to continue setup
Step 5. Click Finish to complete setup
User’s Manual
5. Mechanical Drawing
XTX-PNV User’s Manual
65
XTX-PNV
66 XTX-PNV User’s Manual
Unit: mm
User’s Manual
XTX-PNV User’s Manual
67
Loading...
