ECM-QM77
Intel® Ivy Bridge Processors 3.5” Micro Module
with Intel® QM77 Chipset
User’s manual
4th Ed – 03 September 2013
Copyright Notice
Copyright 2013 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2047391203R
ECM-QM77
FCC Statement
Notice
Copyright Notice
Trademark Acknowledgement
Disclaimer
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright 2013 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Brand and product names are trademarks or registered trademarks of their respective
owners.
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that
2 ECM-QM77 User’s Manual
User’s Manual
Life Support Policy
A Message to the Customer
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/
ECM-QM77 User’s Manual 3
ECM-QM77
Headquarters and Branch
Avalue USA
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Zhonghe Dist.,
New Taipei City 235, Taiwan
Tel:+886-2-8226-2345
Fax : +886-2-8226-2777
Information :sales@avalue.com.tw
Service: service@avalue.com.tw
Avalue Technology Inc.
9 Timber Lane, Marlboro, NJ 07746-1443
Tel : (732) 414-6500
Fax : (732) 414-6501
Information : sales@avalue-usa.com
Service : support@avalue-usa.com
BCM Advanced Research
Avalue Europe
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: +1-949-470-1888
Fax: +1-949-470-0971
Information: BCMSales@bcmcom.com
Web: www.bcmcom.com
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: +45-7025-0310
Fax:+45-4975-5026
Information: sales.europe@avalue.com.tw
Service: service.europe@avalue.com.tw
Avalue China
Avalue Japan
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: +86-21-5169-3609
Fax:+86-21-5445-3266
Information: sales.china@avalue.com.cn
Service: service@avalue.com.tw
Avalue Technology Inc.
3F Ishiyama-Bldg, 1-6-1 Taito,
Taito-ku, Tokyo 110-0016 Japan
Tel : +81-3-5807-2321
Fax : +81-3-5807-2322
Information : sales.japan@avalue.com.tw
Service : service@avalue.com.tw
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Avalue’s products. In
fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Avalue’s engineers every business day.
We are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or e-mail
us.
4 ECM-QM77 User’s Manual
User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Avalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.
ECM-QM77 User’s Manual 5
ECM-QM77
Content
1. Getting Started ........................................................................................................... 9
1.1 Safety Precautions ................................................................................................ 9
1.2 Packing List ........................................................................................................... 9
1.3 Document Amendment History ................................................................ ............ 10
1.4 Manual Objectives ............................................................................................... 11
1.5 System Specifications ......................................................................................... 12
1.6 Architecture Overview – Block Diagram .............................................................. 14
2. Hardware Configuration .......................................................................................... 15
2.1 Product Overview ................................................................................................ 16
2.2 Installation Procedure .......................................................................................... 18
2.2.1 Main Memory ........................................................................................................................... 19
2.3 Jumper and Connector List.................................................................................. 21
2.4 Setting Jumpers & Connectors ............................................................................ 23
2.4.1 Clear CMOS (JBAT1) .............................................................................................................. 23
2.4.2 COM 1 pin 9 signal select (JRI1) ............................................................................................. 23
2.4.3 AT/ ATX Input power select (JAT1) ......................................................................................... 24
2.4.4 5VSB connector in ATX (PWR_SB1) ...................................................................................... 24
2.4.5 Battery connector (BAT1) ........................................................................................................ 25
2.4.6 CPU fan connector (CPU_FAN1) ............................................................................................ 25
2.4.7 System fan connector (SYS_FAN1) ........................................................................................ 26
2.4.8 COM 1 RS-422-485 mode (J422/1) ......................................................................................... 26
2.4.9 Audio connector (JAUDIO1) .................................................................................................... 27
2.4.9.1 Signal Description – Audio connector (JAUDIO1) ............................................. 27
2.4.10 LCD inverter connector (JBKL1) ............................................................................................. 28
2.4.11 LCD backlight brightness adjustment (JVR1).......................................................................... 28
2.4.12 Low pin count connector (JLPC1) ........................................................................................... 29
2.4.13 Serial port 2 connector (JCOM2) ............................................................................................. 29
2.4.14 General purpose I/O connector (JDIO1) ................................................................................. 30
2.4.15 Miscellaneous setting connector (JFP1) ................................................................................. 30
2.4.16 SPI connector (JSPI1) ............................................................................................................. 31
2.4.17 Power connector (PWR1) ........................................................................................................ 31
2.4.18 LVDS connector (JLVDS1) ...................................................................................................... 32
2.4.19 On-board box header for USB3.0 (JUSB3/1) .......................................................................... 33
2.4.20 On-board box header for USB2.0 (JUSB1) ............................................................................. 33
2.4.21 PS/2 keyboard & mouse connector (JKB/ MS1) ..................................................................... 34
2.4.22 HD power connector (HD_PWR1) ........................................................................................... 34
6 ECM-QM77 User’s Manual
User’s Manual
2.5 Audio / USB Daughter Board User’s Guide ......................................................... 35
2.5.1 Jumper and Connector Layout ................................................................................................ 35
2.5.2 Jumper and Connector List ..................................................................................................... 35
2.5.3 Setting Jumper and Connector ................................................................................................ 36
2.6 Installing the CPU ................................................................................................ 37
2.6.1 Locate the CPU socket on the board. ...................................................................................... 37
2.6.2 Separate CPU cooler and its base first by screw drawer ........................................................ 38
3. BIOS Setup ................................................................................................................... 40
3.1 Introduction .......................................................................................................... 41
3.2 Starting Setup ...................................................................................................... 41
3.3 Using Setup ......................................................................................................... 42
3.4 Getting Help......................................................................................................... 43
3.5 In Case of Problems ............................................................................................ 43
3.6 BIOS setup .......................................................................................................... 44
3.6.1 Main Menu ............................................................................................................................... 44
3.6.1.1 System Language .............................................................................................. 45
3.6.1.2 System Date ...................................................................................................... 45
3.6.1.3 System Time ...................................................................................................... 45
3.6.2 Advanced Menu ....................................................................................................................... 45
3.6.2.1 APCI Settings .................................................................................................... 46
3.6.2.2 S5 RTC Wake Settings ...................................................................................... 46
3.6.2.3 Trusted Computing ............................................................................................ 47
3.6.2.4 CPU Configuration ............................................................................................. 48
3.6.2.5 SATA Configuration ........................................................................................... 49
3.6.2.6 Thermal Configuration ....................................................................................... 49
3.6.2.7 Intel(R) Rapid Start Technology ........................................................................ 51
3.6.2.8 Intel TXT (LT) Configuration .............................................................................. 51
3.6.2.9 PCH-FW Configuration ...................................................................................... 52
3.6.2.10 Intel(R) Anti-Theft Technology Configuration .................................................... 53
3.6.2.11 AMT Configuration ............................................................................................. 54
3.6.2.12 USB Configuration ............................................................................................. 55
3.6.2.13 Super IO Configuration ...................................................................................... 56
3.6.2.13.1 Serial Port 0 Configuration ................................................................................ 57
3.6.2.13.2 Serial Port 1 Configuration ................................................................................ 58
3.6.2.14 Hardware Monitor .............................................................................................. 59
3.6.2.15 Intel® Smart Connect Technology .................................................................... 60
3.6.2.16 CPU PPM Configuration .................................................................................... 60
3.6.3 Chipset ................................................................................................................................... 61
3.6.3.1 PCH-IO Configuration ...................................................................................... 62
3.6.3.1.1 PCI Express Configuration .............................................................................. 63
ECM-QM77 User’s Manual 7
ECM-QM77
3.6.3.1.1.1 PCI Express Root Port 1 ................................................................................... 63
3.6.3.1.1.2 PCI Express Root Port 6 ................................................................................... 64
3.6.3.1.1.3 PCI Express Root Port 7(82574 LAN) ............................................................... 65
3.6.3.1.2 USB Configuration ........................................................................................... 66
3.6.3.1.3 PCH Azalia Configuration ................................................................................ 67
3.6.3.2 System Agent (SA) Configuration .................................................................... 67
3.6.3.2.1 Memory Configuration ..................................................................................... 68
3.6.3.2.2 GT – Power Management Control ................................................................... 69
3.6.3.3 Graphics Configuration .................................................................................... 70
3.6.4 Boot ........................................................................................................................................ 72
3.6.4.1 CSM parameters .................................................................................................................... 73
3.6.5 Security .................................................................................................................................. 74
3.6.6 Save and exit ......................................................................................................................... 75
3.6.6.1 Save Changes and Exit ..................................................................................... 75
3.6.6.2 Discard Changes and Exit ................................................................................. 75
3.6.6.3 Save Changes and Reset .................................................................................. 76
3.6.6.4 Discard Changes and Reset ............................................................................. 76
3.6.6.5 Save Changes ................................................................................................... 76
3.6.6.6 Discard Changes ............................................................................................... 76
3.6.6.7 Restore Defaults ................................................................................................ 76
3.6.6.8 Save as User Defaults ....................................................................................... 76
3.6.6.9 Restore as User Defaults .................................................................................. 76
4. Drivers Installation ....................................................................................................... 77
4.1 Install Chipset Driver (For Intel QM77) ................................................................ 78
4.2 Install ME Driver (For Intel QM77) ....................................................................... 79
4.3 Install USB 3.0 Driver (For Intel QM77) ............................................................... 81
4.4 Install VGA Driver (For Intel QM77) ..................................................................... 82
4.5 Install Audio Driver (For Realtek ALC892) ........................................................... 84
4.6 Install Ethernet Driver (For Intel 82579LM and 82574L) ...................................... 85
5. Mechanical Drawing .................................................................................................... 87
8 ECM-QM77 User’s Manual
User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x 3.5” ECM-QM77 Micro Module
1 x Quick Installation Guide for ECM-QM77
1 x AUX-056 daughter board
1 x DVD-ROM contains the followings:
— User’s Manual (this manual in PDF file)
— Ethernet driver and utilities
— VGA drivers and utilities
— Audio drivers and utilities
1 x Cable set contains the followings:
— 1 x Audio cable (12pin,2.0 pitch)
— 1 x USB 2.0 cable (10P/2.0mm-10P/2.0mm)
— 1 x USB 3.0 cable ((20P/2.0mm-20P/2.0mm)
— 1 x Serial ATA cable (7-pin, standard)
— 1 x Wire SATA power cable (15-pin,4P/2.5mm)
— 1 x Flat cable 9P(M)-PHD 10P/2.0mm)
3M foam (VHB-4622 10mm*20mm*1.1mm)
ECM-QM77 User’s Manual 9
ECM-QM77
Revision
Date
Comment
1st
October 2012
Initial Release
2nd
December 2012
Connector List Update
3rd
January 2013
Increase Installing the CPU
4th
September 2013
Update Mechanical Drawing
1.3 Document Amendment History
10 ECM-QM77 User’s Manual
User’s Manual
1.4 Manual Objectives
This manual describes in detail the Avalue Technology ECM-QM77 Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with ECM-QM77 series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.
ECM-QM77 User’s Manual 11
ECM-QM77
System
CPU
Intel® rPGA988B（Socket G2）supports Intel® Ivy Bridge Processors （35 ～ 45W
CPU）
BIOS
AMI uEFI BIOS, 64Mbit SPI Flash ROM
iAMT8.0 Supported
System Chipset
Intel® QM77 Chipset
I/O Chip
Nuvoton NCT6776F
System Memory
One 204-pin DDR3 SODIMM Socket Supports Up to
8GB DDR3 1333/ 1600 SDRAM
Watchdog Timer
Reset: 1sec. ~ 255sec./min. and 1sec. or 1min./step
H/W Status
Monitor
Monitoring System Temperature, Voltage with
Auto Throttling Control
Expansion
1 x Mini PCIe
TPM
TPM 1.2 supported
I/O
MIO
1 x RS-232, 1 x RS-232/ 422/ 485, LPC, 2 x SATA III
USB
2 x USB 2.0, 4 x USB 3.0
DIO
4-bit GPI, 4-bit GPO
Display
Chipset
Intel® QM77
Resolution
VGA Mode: 1920 x 1200 @ 60Hz
HDMI Mode: 1920 x 1200 @ 60Hz
LVDS Mode: 1920 x 1200 @ 60Hz
Multiple
Display
VGA + LVDS + HDMI
LCD
Interface
Dual-channel 18/ 24-bit LVDS
Audio
HD Codec
Realtek ALC892 Supports 7.1-CH Audio
Audio Interface
Mic-in, Line-in, Line-out
Ethernet
LAN Chip
1 x Intel® 82574L Gigabit Ethernet
1 x Intel® 82579 Gigabit Ethernet
Ethernet Interface
10/ 100/ 1000 Base-Tx Gigabit Ethernet Compatible
Mechanical &
Environmental
1.5 System Specifications
12 ECM-QM77 User’s Manual
User’s Manual
Power Requirement
+12V
ACPI
Single Power ATX Support S0, S1, S3, S4, S5
ACPI 3.0 Compliant
Power Type
AT/ATX
Operating Temp.
0 ~ 60°C (32 ~ 140°F)
Storage
Temperature
-40 ~ 75°C (-40 ~ 167°F)
Operating Humidity
0%~90% Relative Humidity, Non-condensing
Size (L x W)
5.7" x 4" (146mm x 101mm)
Weight
0.44lbs (0.2kg)
ECM-QM77 User’s Manual 13
ECM-QM77
1.6 Architecture Overview – Block Diagram
The following block diagram shows the architecture and main components of ECM-QM77.
14 ECM-QM77 User’s Manual
User’s Manual
2. Hardware
Configuration
ECM-QM77 User’s Manual 15
ECM-QM77
2.1 Product Overview
16 ECM-QM77 User’s Manual
User’s Manual
ECM-QM77 User’s Manual 17
ECM-QM77
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the SODIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change CMOS settings to support
flat panel.
4. Connect power supply to the board via the ATXPWR.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the “LOAD BIOS
DEFAULTS” feature. The Integrated Peripheral Setup and the Standard CMOS Setup
Window must be entered and configured correctly to match the particular system
configuration.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.
Note: Make sure the heat sink and the CPU top surface are in total contact to
avoid CPU overheating problem that would cause the system to hang or
unstable
18 ECM-QM77 User’s Manual
User’s Manual
SODIMM
2.2.1 Main Memory
ECM-QM77 provides one 204-pin DDR3 SODIMM socket, supports up to 8GB DDR3
1333/1600 SDRAM.
(Rear side)
Make sure to unplug the power supply before adding or removing SODIMMs
or other system components. Failure to do so may cause severe damage to
both the board and the components.
Locate the SODIMM socket on the board.
Hold two edges of the SODIMM module carefully. Keep away of touching its
connectors.
Align the notch key on the module with the rib on the slot.
Firmly press the modules into the socket automatically snaps into the mounting notch.
Do not force the SODIMM module in with extra force as the SODIMM module only fit
in one direction.
ECM-QM77 User’s Manual 19
ECM-QM77
To remove the SODIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the SODIMM module.
Note:
(1) Please do not change any DDR3 SDRAM parameter in BIOS setup to increase
your system’s performance without acquiring technical information in advance.
(2) Static electricity can damage the electronic components of the computer or
optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.
20 ECM-QM77 User’s Manual
User’s Manual
Jumpers
Label
Function
Note
JBAT1
Clear CMOS
3 x 1 header, pitch 2.54 mm
JRI1
COM 1 pin 9 signal select
3 x 2 header, pitch 2.00 mm
JAT1
AT/ ATX Input power select
3 x 1 header, pitch 2.00 mm
2.3 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board's jumpers and connectors.
ECM-QM77 User’s Manual 21
ECM-QM77
Connectors
Label
Function
Note
BAT1
Battery connector
2 x 1 wafer, pitch 1.25 mm
COM1
Serial port 1 connector
D-sub 9-pin, male
CPU_FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54 mm
HDMI1
HDMI connector
J422/1
COM 1 RS-422-485 mode
3 x 2 header, pitch 2.00 mm
JAUDIO1
Audio connector
6 x 2 header, pitch 2.00 mm
JBKL1
LCD inverter connector
5 x 1 wafer, pitch 2.00 mm
JCOM2
Serial port 2 connector
5 x 2 header, pitch 2.00 mm
JDIO1
General purpose I/O connector
6 x 2 header, pitch 2.00 mm
JFP1
Miscellaneous setting connector
5 x 2 header, pitch 2.00 mm
JLPC1
Low pin count interface
7 x 2 header, pitch 2.00 mm
JLVDS1
LVDS connector
20 x 2 header, pitch 1.25 mm
JSPI1
SPI connector
4 x 2 header, pitch 2.00 mm
JUSB1
On-board box header for USB2.0
5 x 2 header, pitch 2.00 mm
JUSB3/1
On-board box header for USB3.0
10 x 2 wafer, pitch 2.00 mm
JVR1
LCD backlight brightness adjustment
3 x 1 header, pitch 2.54 mm
LAN1/S_LAN1
RJ-45 Ethernet connector
LED3
LED connector
PWR_SB1
5VSB connector in ATX
3 x 1 wafer, pitch 2.54 mm
PWR1
Power connector
2 x 2 wafer, pitch 4.2 mm
JKB/MS1
PS/2 keyboard & mouse connector
2 x 3 wafer, pitch 2.00 mm
HD_PWR1
HD power connector
1 x 4 wafer, pitch 2.50 mm
SATA1
Serial ATA connector 1
SATA2
Serial ATA connector 2
SYS_FAN1
System fan connector
4 x 1 wafer, pitch 2.54 mm
USB1_1
On-board connector for USB3.0
VGA1
VGA connector
D-sub 15-pin, female
MPCIE1
Mini-PCI connector
CN4
DDR3 SODIMM connector
22 ECM-QM77 User’s Manual
* Default
Protect*
Clear CMOS
* Default
Ring*
+5V
+12V
2.4 Setting Jumpers & Connectors
2.4.1 Clear CMOS (JBAT1)
User’s Manual
2.4.2 COM 1 pin 9 signal select (JRI1)
ECM-QM77 User’s Manual 23
ECM-QM77
* Default
AT*
ATX
Signal
PIN
SIO_PSON#
1
GND
2
+ATX5VSB
3
2.4.3 AT/ ATX Input power select (JAT1)
2.4.4 5VSB connector in ATX (PWR_SB1)
24 ECM-QM77 User’s Manual
Signal
PIN
+3.3V
1
GND
2
Signal
PIN
GND
1
+12V
2
CPUFANIN0
3
CPUFANOUT0
4
2.4.5 Battery connector (BAT1)
User’s Manual
2.4.6 CPU fan connector (CPU_FAN1)
ECM-QM77 User’s Manual 25
ECM-QM77
Signal
PIN
GND
1
+12V
2
SYSFANIN
3
SYSFANOUT
4
Signal
PIN
PIN
Signal
485_422TX-
2 1 422RX-
485_422TX+
4 3 422RX+
+5V
6 5 GND
Note:
J422/485 is available after modify the mode of COM1
in BIOS setting
2.4.7 System fan connector (SYS_FAN1)
2.4.8 COM 1 RS-422-485 mode (J422/1)
26 ECM-QM77 User’s Manual
Signal
PIN
PIN
Signal
GND
11
12
MIC1-JD
LINE1-JD
9
10
FRONT-JD
MIC1-L-IN
7 8 MIC1-R-IN
LINE1-L-IN
5 6 LINE1-R-IN
GND
3 4 GND
FRONT-L-OUT
1 2 FRONT-R-OUT
Signal
Signal Description
LINE1_JD
AUDIO IN (LINE_RIN/LIN)sense pin
FRONT_JD
AUDIO Out(ROUT/LOUT) sense pin
MIC1_JD
MIC IN (MIC_RIN/LIN) sense pin
2.4.9 Audio connector (JAUDIO1)
User’s Manual
2.4.9.1 Signal Description – Audio connector (JAUDIO1)
ECM-QM77 User’s Manual 27
ECM-QM77
Signal
PIN
+12V
1
GND
2
BKLEN
3
BRIADJ
4
+5V
5
Signal
PIN
+5V
1
BRIGHT
2
GND
3
Variation Resistor
(Recommended: 4.7KΩ, >1/16W)
2.4.10 LCD inverter connector (JBKL1)
2.4.11 LCD backlight brightness adjustment (JVR1)
28 ECM-QM77 User’s Manual
Signal
PIN
PIN
Signal
LPC_AD0
1 2 +3.3V
LPC_AD1
3 4 LPC_RST#
LPC_AD2
5 6 LPC_FRAME#
LPC_AD3
7 8 CLK_PCI_LPC
INT_SERIRQ
9
10
GND
+V5S
11
12
GND
+V5A
13
14
PCH_DRQ#1
Signal
PIN
PIN
Signal
DCD2
1 2 RxDD2
TxDD2
3 4 DTR2
GND
5 6 DSR2
RTS2
7 8 CTS2
RI2
9
10
NC
2.4.12 Low pin count connector (JLPC1)
User’s Manual
2.4.13 Serial port 2 connector (JCOM2)
ECM-QM77 User’s Manual 29
ECM-QM77
Signal
PIN
PIN
Signal
GND
11
12
GND
SMB_DATA_9555
9
10
SMB_CLK_9555
DIO_GP13
7 8 DIO_GP23
DIO_GP12
5 6 DIO_GP22
DIO_GP11
3 4 DIO_GP21
DIO_GP10
1 2 DIO_GP20
Signal
PIN
PWBT
1
2
RST#
3
4
PWR-LED
5
6
HDD-LED
7
8
COPEN#
9
10
2.4.14 General purpose I/O connector (JDIO1)
2.4.15 Miscellaneous setting connector (JFP1)
30 ECM-QM77 User’s Manual
Signal
PIN
PIN
Signal
7 HOLD#
SPI_SI
6 5 SPI_SO
SPI_CLK
4 3 SPI_CS0#
GND
2 1 +3.3V
Signal
PIN
PIN
Signal
GND
1 2 GND
+12V
3 4 +12V
2.4.16 SPI connector (JSPI1)
User’s Manual
2.4.17 Power connector (PWR1)
ECM-QM77 User’s Manual 31
ECM-QM77
Signal
PIN
PIN
Signal
+12V
39
40
+12V
GND
37
38
GND
LVDS_CLK2_N
35
36
LVDS_CLK1_N
LVDS_CLK2_P
33
34
LVDS_CLK1_P
GND
31
32
GND
LVDS_DATA7_N
29
30
LVDS_DATA6_N
LVDS_DATA7_P
27
28
LVDS_DATA6_P
GND
25
26
GND
LVDS_DATA5_N
23
24
LVDS_DATA4_N
LVDS_DATA5_P
21
22
LVDS_DATA4_P
GND
19
20
GND
LVDS_DATA3_N
17
18
LVDS_DATA2_N
LVDS_DATA3_P
15
16
LVDS_DATA2_P
GND
13
14
GND
LVDS_DATA1_N
11
12
LVDS_DATA0_N
LVDS_DATA1_P
9
10
LVDS_DATA0_P
GND
7 8 GND
NC
5
6
NC
+3.3V
3 4 +5V
+3.3V
1 2 +5V
2.4.18 LVDS connector (JLVDS1)
32 ECM-QM77 User’s Manual
2.4.19 On-board box header for USB3.0 (JUSB3/1)
Signal
PIN
PIN
Signal
+5V
1
USB3_RXN3_L
2
19
+5V
USB3_RXP3_L
3
18
USB3_RXN4_L
GND
4
17
USB3_RXP4_L
USB3_TXN3_L
5
16
GND
USB3_TXP3_L
6
15
USB3_TXN4_L
GND
7
14
USB3_TXP4_L
USB_PN_Z_2
8
13
GND
USB_PP_Z_2
9
12
USB_PN_Z_3
NC
10
11
USB_PP_Z_3
Signal
PIN
PIN
Signal
+5V
1 2 +5V
USB_PN_Z_5
3 4 USB_PN_Z_4
USB_PP_Z_5
5 6 USB_PP_Z_4
GND
7 8 GND
GND
9
10
GND
User’s Manual
2.4.20 On-board box header for USB2.0 (JUSB1)
ECM-QM77 User’s Manual 33
ECM-QM77
Signal
PIN
PIN
Signal
KBCK
1 2 KBDT
KBVCC
3 4 GND
MSCK
5 6 MSDT
Signal
PIN
GND
1
GND
2
+5V
3
+5V
4
2.4.21 PS/2 keyboard & mouse connector (JKB/ MS1)
2.4.22 HD power connector (HD_PWR1)
34 ECM-QM77 User’s Manual
Connectors
Label
Function
Note
AUSB2
USB connector 2.0
AUSB3
USB connector 3.0
MIC1
Mic in connector
Phone Jack
LINEOUT1
Line out connector
Phone Jack
LINEIN1
Line in connector
Phone Jack
AJAUDIO1
Audio connector
6 x 2 header, pitch 2.00mm
AJUSB2
2.00mm USB connector
5 x 2 header, pitch 2.00mm
AJUSB3
2.00mm USB connector
10 x 2 header, pitch 2.00mm
2.5 Audio / USB Daughter Board User’s Guide
2.5.1 Jumper and Connector Layout
User’s Manual
2.5.2 Jumper and Connector List
ECM-QM77 User’s Manual 35
ECM-QM77
Audio Connector (AJAUDIO1)
2.00mm USB Connector (AJUSB2)
Signal
PIN
PIN
Signal
AFRONT1-L-OUT
1 2 AFRONT1-R-OUT
GND
3 4 GND
ALINE1-L-IN
5 6 ALINE1-R-IN
AMIC1-L-IN
7 8 AMIC1-R-IN
ALINE1-JD
9
10
AFRONT1-JD
GND
11
12
AMIC1-JD
Signal
PIN
PIN
Signal
USB2VCC
1 2 USB2VCC
AUSB_PN2
3 4 AUSB_PN1
AUSB_PP2
5 6 AUSB_PP1
GND
7 8 GND
GND
9
10
GND
2.00mm USB Connector (AJUSB3)
Signal
PIN
PIN
Signal
AUSBVCC2
1
AUSB3_RXN1_L
2
19
AUSBVCC3
AUSB3_RXP1_L
3
18
AUSB3_RXN2_L
GND
4
17
AUSB3_RXP2_L
AUSB3_TXN1_L
5
16
GND
AUSB3_TXP1_L
6
15
AUSB3_TXN2_L
GND
7
14
AUSB3_TXP2_L
AUSB_PN3
8
13
GND
AUSB_PP3
9
12
AUSB_PN4
NC
10
11
AUSB_PP4
2.5.3 Setting Jumper and Connector
36 ECM-QM77 User’s Manual
Before installing the CPU, make sure that the socket box is facing
towards you and the load lever is on your left.
2.6 Installing the CPU
2.6.1 Locate the CPU socket on the board.
User’s Manual
ECM-QM77 User’s Manual 37
ECM-QM77
CPU Socket triangle
Gold triangle
2.6.2 Separate CPU cooler and its base first by screw drawer
1. Position the CPU over the socket, making sure that the gold triangle is the same side
as CPU Socket triangle
38 ECM-QM77 User’s Manual
The CPU fits in only one correct orientation. DO NOT force the CPU
into the socket to prevent bending the connectors on the socket and
damaging the CPU!
2. turn the CPU lock clockwise to lock CPU
User’s Manual
ECM-QM77 User’s Manual 39
ECM-QM77
3. BIOS Setup
40 ECM-QM77 User’s Manual
User’s Manual
3.1 Introduction
The BIOS setup program allows users to modify the basic system configuration. In this
following chapter will describe how to access the BIOS setup program and the
configuration options that may be changed.
3.2 Starting Setup
The AMI BIOS™ is immediately activated when you first power on the computer. The BIOS
reads the system information contained in the CMOS and begins the process of checking
out the system and configuring it. When it finishes, the BIOS will seek an operating system
on one of the disks and then launch and turn control over to the operating system.
While the BIOS is in control, the Setup program can be activated in one of two ways:
By pressing <Del> immediately after switching the system on, or
By pressing the <Del> key when the following message appears briefly at the bottom of the
screen during the POST (Power On Self Test).
Press DEL to enter SETUP
If the message disappears before you respond and you still wish to enter Setup, restart the
system to try again by turning it OFF then ON or pressing the "RESET" button on the
system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete>
keys. If you do not press the keys at the correct time and the system does not boot, an error
message will be displayed and you will again be asked to.
Press F1 to Continue, DEL to enter SETUP
ECM-QM77 User’s Manual 41
ECM-QM77
Button
Description
↑
Move to previous item
↓
Move to next item
←
Move to the item in the left hand
→
Move to the item in the right hand
Esc key
Main Menu -- Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu -- Exit current page and
return to Main Menu
PgUp key
Increase the numeric value or make changes
PgDn key
Decrease the numeric value or make changes
+ key
Increase the numeric value or make changes
- key
Decrease the numeric value or make changes
F1 key
General help, only for Status Page Setup Menu and Option Page Setup Menu
F2 key
Previous Values.
F3 key
Optimized defaults
F4 key
Save & Exit Setup
3.3 Using Setup
In general, you use the arrow keys to highlight items, press <Enter> to select, use the
PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to
quit. The following table provides more detail about how to navigate in the Setup program
using the keyboard.
Navigating Through The Menu Bar
Use the left and right arrow keys to choose the menu you want to be in.
Note: Some of the navigation keys differ from one screen to another.
To Display a Sub Menu
Use the arrow keys to move the cursor to the sub menu you want. Then press
<Enter>. A “” pointer marks all sub menus.
42 ECM-QM77 User’s Manual
User’s Manual
3.4 Getting Help
Press F1 to pop up a small help window that describes the appropriate keys to use and the
possible selections for the highlighted item. To exit the Help Window press <Esc> or the F1
key again.
3.5 In Case of Problems
If, after making and saving system changes with Setup, you discover that your computer no
longer is able to boot, the AMI BIOS supports an override to the CMOS settings which
resets your system to its defaults.
The best advice is to only alter settings which you thoroughly understand. To this end, we
strongly recommend that you avoid making any changes to the chipset defaults. These
defaults have been carefully chosen by both Award and your systems manufacturer to
provide the absolute maximum performance and reliability. Even a seemingly small change
to the chipset setup has the potential for causing you to use the override.
ECM-QM77 User’s Manual 43
ECM-QM77
3.6 BIOS setup
Once you enter the AMI BIOS CMOS Setup Utility, the Main Menu will appear on the
screen. The Main Menu allows you to select from several setup functions and exit choices.
Use the arrow keys to select among the items and press <Enter> to accept and enter the
sub-menu.
3.6.1 Main Menu
This section allows you to record some basic hardware configurations in your computer and
set the system clock.
44 ECM-QM77 User’s Manual
User’s Manual
3.6.1.1 System Language
This option allows choosing the system default language.
3.6.1.2 System Date
Use the system date option to set the system date. Manually enter the day, month and
year.
3.6.1.3 System Time
Use the system time option to set the system time. Manually enter the hours, minutes and
seconds.
Note: The BIOS setup screens shown in this chapter are for reference purposes
only, and may not exactly match what you see on your screen.
Visit the Avalue website (www.avalue.com.tw) to download the latest
product and BIOS information.
3.6.2 Advanced Menu
This section allows you to configure your CPU and other system devices for basic operation
through the following sub-menus.
ECM-QM77 User’s Manual 45
ECM-QM77
Item
Options
Description
APCI Sleep State
Suspend Disabled
S1 only(CPU Stop Clock)
S3 only(Suspend to RAM)[Default]
Select ACPI sleep state the system
will enter when the SUSPEND button
is pressed.
S3 Video Repost
Disabled[Default]
Enabled
Enable or Disable S3 Video Repost.
3.6.2.1 APCI Settings
3.6.2.2 S5 RTC Wake Settings
46 ECM-QM77 User’s Manual
Item
Options
Description
Wake system with Fixed Time
Disabled[Default],
Enabled
Enable or disable System wake on alarm
event. When enabled, System will wake on the
hr::min::sec specified.
Wake system with Dynamic Time
Disabled[Default],
Enabled
Enable or disable System wake on alarm
event. When enabled, System will wake on the
current time + Increase minute(s).
3.6.2.3 Trusted Computing
Item
Options
Description
Security Device Support
Disable[Default],
Enable
Enables or Disables BIOS support for security
device. O.S will not show Security Device.
TCG EFI protocol and INT1A interface will not
be available.
User’s Manual
ECM-QM77 User’s Manual 47
ECM-QM77
Item
Options
Description
Hyper-threading
Disabled
Enabled[Default]
Enabled for Windows XP and Linux (OS
optimized for Hyper-Threading Technology)
and Disabled for other OS (OS not optimized
for Hyper-Threading Technology). When
Disabled only one thread per enabled core is
enabled.
Active Processor Cores
All[Default]
1/2/3
Number of cores to enable in each processor
package
Limit CPUID Maximum
Disabled[Default]
Enabled
Disabled for Windows XP
Execute Disable Bit
Disabled
Enabled[Default]
XD can prevent certain classes of malicious
buffer overflow attacks when combined with a
supporting OS (Windows Server 2003 SP1,
Windows XP SP2, SuSE Linux 9.2, RedHat
Enterprise 3 Update 3.)
Intel Virtualization Technology
Disabled[Default]
Enabled
When enabled, a VMM can utilize the
additional hardware capabilities provided by
Vanderpool Technology.
3.6.2.4 CPU Configuration
Use the CPU configuration menu to view detailed CPU specification and configure the
CPU.
48 ECM-QM77 User’s Manual
Item
Options
Description
SATA Controller(s)
Enabled[Default]
Disabled
Enable or disable SATA Device.
SATA Mode Selection
IDE[Default]
AHCI
RAID
Determines how SATA controller(s) operate.
SATA Test Mode
Enabled
Disabled[Default]
Enable or disable Test Mode.
3.6.2.5 SATA Configuration
It allows you to select the operation mode for SATA controller.
User’s Manual
3.6.2.6 Thermal Configuration
ECM-QM77 User’s Manual 49
ECM-QM77
Item
Options
Description
Automatic Thermal Reporting
Disabled,
Enabled[Default]
Configure _CRT, _PSV and _AC0
automatically based on values recommended
in BWG’s Thermal Reporting for Thermal
Management settings. Set to Disabled for
manual configuration.
Active Trip Point 0 Fan Speed
0 ~ 100[Default]
Active Trip Point 0 Fan Speed in percentage.
Value must be between 0 (Fan off) -100 (Max
fan speed). This is the speed at which fan will
run when Active Trip Point 0 is crossed.
Active Trip Point 1
Disabled
15/23/31/39/47/55[Defau
lt]/63/71/79/87/95
/103/111/119C
This value controls the temperature of the
ACPI Active Trip Point 1 - the point in which
the OS will turn the processor fan on Active
Trip Point 1 Fan Speed.
Active Trip Point 1 Fan Speed
0 ~ 100
(75 [Default])
Active Trip Point 1 Fan Speed in percentage.
Value must be between 0 (Fan off) – 100 (Max
fan speed). This value must be less than
Active Trip Point 0 Fan speed. This is the
speed at which fan will run when Active Trip 1
is crossed.
Passive TC1 Value
1-16
(1 [Default])
This value sets the TC1 value for the ACPI
Passive Cooling Formula. Range 1-16
Passive TC2 Value
1-16
(5 [Default])
This value sets the TC2 value for the ACPI
Passive Cooling Formula. Range 1-16
Passive TSP Value
2 ~ 32
(10 [Default])
This item sets the TSP value for the ACPI
Passive Cooling Formula. It represents in
tenths of a second how often the OS will read
the temperature when passive cooling is
enabled. Range 2- 32
PCH Thermal Device
Enable or Disable PCH Thermal Device (D31:F6)
PCH Temp Read
Disabled,
Enabled[Default]
PCH Temperature Read Enable
CPU Energy Read
Disabled,
Enabled[Default]
CPU Energy Read Enable
CPU Temp Read
Disabled,
Enabled[Default]
CPU Temperature Read Enable
50 ECM-QM77 User’s Manual
Alert Enable Lock
Disabled,
Enabled[Default]
Lock all Alert Enable settings
PCH Alert
Disabled[Default],
Enabled
PCH Alert pin enable
DIMM Alert
Disabled[Default],
Enabled
DIMM Alert pin enable
3.6.2.7 Intel(R) Rapid Start Technology
User’s Manual
3.6.2.8 Intel TXT (LT) Configuration
ECM-QM77 User’s Manual 51
ECM-QM77
Item
Options
Description
MDES BIOS Status Code
Disabled[Default]
Enabled
Enable/Disable MDES BIOS Status Code.
Firmware Update Configuration
Configure Management Engine Technology Parameters.
Item
Options
Description
Me FW Image Re-Flash
Disabled[Default]
Enabled
Enable/Disable Me FW Image Re-Flash
function.
3.6.2.9 PCH-FW Configuration
52 ECM-QM77 User’s Manual
Item
Options
Description
Intel(R) Anti-Theft Technology
Enabled
Disabled[Default]
Enable/Disable Intel(R) AT in BIOS for testing
only
Intel(R) Anti-Theft Technology
Recovery
1 ~ 64
Set the number of times Recovery attemped
will be allowed
Enter Intel(R) AT Suspend Mode
Enabled
Disabled[Default]
Request that platform enter Intel(R) AT
Suspend Mode
3.6.2.10 Intel(R) Anti-Theft Technology Configuration
User’s Manual
ECM-QM77 User’s Manual 53
ECM-QM77
Item
Options
Description
Intel AMT
Enabled[Default]
Disabled
Enable/Disable Intel ® Active Management
Technology BIOS Extension. Note: iAMT H/W
is always enabled. This option just controls the
BIOS extension execution. If enabled, this
requires additional firmware in the SPI device
BIOS Hotkey Pressed
OEMFLag Bit 1: Enable/Disable BIOS hotkey press.
MEBx Selection Screen
OEMFLag Bit 2: Enable/Disable MEBx selection screen
Hide Un-Configure ME
Confirmation
OEMFLag Bit 6: Hide Un-Configure ME without password Confirmation
Prompt.
MEBx Debug Message Output
OEMFLag Bit 14: Enable MEBx debug message output
Un-configure ME
OEMFLag Bit 15: Un-Configure ME without password
Amt Wait Timer
0
Set time to wait before sending
ASF_GET_BOOT_OPTIONS.
Disable ME
Enabled[Default]
Disabled
Set ME to Soft Temporary Disabled.
ASF
Enabled[Default]
Disabled
Enable/Disable Alert Specification Format.
Active Remote Assistance
Process
Trigger CIRA boot.
USB Configure
Enabled[Default]
Disabled
Enable/Disable USB Configure function.
PET Progress
Enabled[Default]
Disabled
User can Enable/Disable PET Events
progress to recieve PET events or not..
WatchDog
Enabled
Disabled[Default]
Enable/Disable WatchDog Timer.
3.6.2.11 AMT Configuration
Intel AMT allows hardware-based remote management, security, power-management, and
remote-configuration features.
54 ECM-QM77 User’s Manual
User’s Manual
Item
Options
Description
Legacy USB Support
Enabled[Default]
Disabled
Auto
Enables Legacy USB support. AUTO option
disables legacy support if no USB devices are
connected. DISABLE option will keep USB
devices available only for EFI applications.
USB3.0 Support
Enabled[Default]
Disabled
Enable/Disable USB3.0 (XHCI) Controller
support.
XHCI Hand-off
Enabled[Default]
Disabled
This is a workaround for OSew without XHCI
hand-off support. The XHCI ownership change
should be claimed by XHCI driver.
EHCI Hand-off
Enabled
Disabled[Default]
This is a workaround for OSes without EHCI
hand-off support. The EHCI ownership change
should be claimed by EHCI driver.
USB transfer time-out
1 sec
5 sec
10 sec
20 sec[Default]
The time-out value for Control, Bulk, and
Interrupt transfers.
Device reset time-out
10 sec
20 sec[Default]
30 sec
40 sec
USB mass storage device Start Unit command
time-out.
Device power-up delay
Auto[Default]
Manual
Maximum time the device will take before it
properly reports itself to the Host Controller.
‘Auto’ uses default value: for a Root port it is
100ms, for a Hub port the delay is taken form
Hub descriptor.
3.6.2.12 USB Configuration
The USB Configuration menu helps read USB information and configures USB settings.
ECM-QM77 User’s Manual 55
ECM-QM77
Item
Options
Description
Restore AC Power Loss
Power Off[Default]
Power On
Specify what state to go to when power is
re-applied after a power failure (G3 state)
Watch Dog
Disabled[Default]
30 sec
40 sec
50 sec
60 sec
2 min
10 min
30 min
Set SIO watch dog timer.
ERP Deep S5
Enabled
Disabled[Default]
Deep S5 for power saving.
3.6.2.13 Super IO Configuration
You can use this item to set up or change the Super IO configuration for serial ports. Please
refer to 3.6.2.13.1 and 3.6.2.13.2 for more information.
56 ECM-QM77 User’s Manual
3.6.2.13.1 Serial Port 0 Configuration
Item
Option
Description
Serial Port
Enabled,
Disabled[Default]
Enable or Disable Serial Port
(COM)
Change Settings
Auto[Default]
IO=3F8h; IRQ=4,
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12
Select an optimal setting for
Super IO device.
UART 232 422 485
UART 232[Default],
UART 422,
UART 485
Change the Serial Port as
RS232/ 422/ 485
User’s Manual
ECM-QM77 User’s Manual 57
ECM-QM77
Item
Option
Description
Serial Port
Enabled,
Disabled[Default]
Enable or Disable Serial Port
(COM)
Change Settings
Auto[Default]
IO=2F8h; IRQ=3
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12
Select an optimal setting for
super IO device.
3.6.2.13.2 Serial Port 1 Configuration
58 ECM-QM77 User’s Manual
3.6.2.14 Hardware Monitor
Item
Description
Smart Fan Function
Enable or Disable Smart Fan.
Displays system health status
User’s Manual
The following system temperature, fan speed and voltage are monitored.
Temperature:
System Temperature
CPU Thermistor Temperature
Fan Speed:
System Fan Speed
CPU Fan speed
Voltage:
VCORE
+12V
+5V
+5VSB
AVCC
3VCC
VSB3
VBAT
ECM-QM77 User’s Manual 59
ECM-QM77
Item
Description
ISCT Configuration
Enabled
Disabled[Default]
Enable/Disable ISCT Configuration.
3.6.2.15 Intel® Smart Connect Technology
3.6.2.16 CPU PPM Configuration
60 ECM-QM77 User’s Manual
User’s Manual
Item
Option
Description
EIST
Disabled
Enabled[Default]
Enable or Disable Intel
Speedstep.
Turbo Mode
Turbo Mode.
CPU C3/6/7 Report
Enable or Disable CPU C3(ACPI
C2)/6(ACPI C3)/7(ACPI C3)
report to OS.
Config TDP LOCK
Disabled[Default]
Enabled
Lock the Config TDP Control
register.
Long duration power limit
Long duration power limit in Watts, 0 means use factory default.
Long duration maintained
Time window which the long duration power is maintained.
Short duration power limit
Short duration power limit in Watts, 0 means use factory default.
ACPI T State
Disabled[Default]
Enabled
Enable/Disable ACPI T state
support.
3.6.3 Chipset
ECM-QM77 User’s Manual 61
ECM-QM77
Item
Option
Description
PCI Express Configuration
PCI Express Configuration settings.
USB Configuration
USB Configuration settings.
PCH Azalia Configuration
PCH Azalia Configuration settings.
Intel 82579 LAN (PHY)
Disabled
Enabled[Default]
Enable or disable onboard NIC.
Wake on LAN (PHY)
Disabled
Enabled[Default]
Enable or disable integrated LAN
to wake the system. (The Wake
On LAN cannot be disabled if ME
is on at Sx state.)
High Precision Timer
Disabled
Enabled[Default]
Enable or Disable the High
Precision Event Timer.
3.6.3.1 PCH-IO Configuration
62 ECM-QM77 User’s Manual
Item
Description
PCI Express Root Port 1
PCI Express Root Port 1 Settings.
PCI Express Root Port 6
PCI Express Root Port 6 Settings.
PCI Express Root Port 7(82574 Lan)
PCI Express Root Port 7 Settings.
3.6.3.1.1 PCI Express Configuration
User’s Manual
3.6.3.1.1.1 PCI Express Root Port 1
ECM-QM77 User’s Manual 63
ECM-QM77
Item
Option
Description
PCI Express Root Port 1
Disabled
Enabled[Default]
Control the PCI Express Root Port.
ASPM Support
Disabled
L0s
L1
L0sL1
Auto[Default]
Set the ASPM Level: Force L0s-Force
all links to L0s State: AUTO-BIOS auto
configure: DISABLE-Disables ASPM.
PCIe Speed
Auto[Default]
Gen1
Gen2
Select PCI Express port speed.
Detect Non-Compliance Device
Disabled[Default]
Enabled
Detect Non-Compliance PCI Express
Device, If enable, it will take more time
at POST time.
Item
Option
Description
PCI Express Root Port 6
Disabled
Enabled[Default]
Control the PCI Express Root
Port.
ASPM Support
Disabled
L0s
L1
L0sL1
Auto[Default]
Set the ASPM Level: Force
L0s-Force all links to L0s State:
AUTO-BIOS auto configure:
DISABLE-Disables ASPM.
PCIe Speed
Auto[Default]
Gen1
Gen2
Select PCI Express port speed.
Detect Non-Compliance Device
Disabled[Default]
Enabled
Detect Non-Compliance PCI
Express Device, If enable, it will
take more time at POST time.
3.6.3.1.1.2 PCI Express Root Port 6
64 ECM-QM77 User’s Manual
Item
Option
Description
PCI Express Root Port 7
Disabled
Enabled[Default]
Control the PCI Express Root Port.
ASPM Support
Disabled
L0s
L1
L0sL1
Auto[Default]
Set the ASPM Level: Force L0s-Force
all links to L0s State: AUTO-BIOS auto
configure: DISABLE-Disables ASPM.
PCIe Speed
Auto[Default]
Gen1
Gen2
Select PCI Express port speed.
Detect Non-Compliance Device
Disabled[Default]
Enabled
Detect Non-Compliance PCI Express
Device, If enable, it will take more time
at POST time.
3.6.3.1.1.3 PCI Express Root Port 7(82574 LAN)
User’s Manual
ECM-QM77 User’s Manual 65
ECM-QM77
Item
Option
Description
XHCI Pre-Boot Driver
Disabled
Enabled[Default]
Enable or disable XHCI Pre-Boot
Driver support.
xHCI Mode
Smart Auto[Default]
Auto
Enabled
Disabled
Mode of operation of xHCI
controller.
HS Port #1/#2/#3/#4 Switchable
Disabled
Enabled[Default]
Allows for HS port switching
between xHCI and EHCI. If
disabled, port is routed to EHCI. If
HS port is routed to xHCI, the
corresponfing SS port is enabled.
xHCI Streams
Disabled
Enabled[Default]
Enable or disable xHCI Maximum
Primary Stream Array Size.
EHCI1/2
Disabled
Enabled[Default]
Control the USB EHCI (USB 2.0)
functions. One EHCI controller
must always be enabled.
USB Ports Per-Port Disable Control
Disabled[Default]
Enabled
Control each of the USB ports
(0~13) disabling.
3.6.3.1.2 USB Configuration
66 ECM-QM77 User’s Manual
3.6.3.1.3 PCH Azalia Configuration
Item
Option
Description
Azalia HDMI codec Port C
Disabled
Enabled[Default]
Enable or disable internal HDMI
codec Port for Azalia.
User’s Manual
3.6.3.2 System Agent (SA) Configuration
ECM-QM77 User’s Manual 67
ECM-QM77
Item
Option
Description
VT-d
Disabled
Enabled[Default]
Check to enable VT-d function on
MCH.
CHAP Device ( B0:D7:F0)
Disabled[Default]
Enabled
Enable or Disable SA CHAP
Device.
Thermal Device ( B0:D4:F0)
Enable or Disable SA Thermal
Device.
Memory Configuration
Memory Configuration Parameters.
GT – Power Management Control
GT – Power Management Control Options.
Item
Option
Description
Memory Frequency Limiter
Auto[Default]
1067
1333
1600
1867
2133
2400
2667
Maximum Memory Frequency
Selections in Mhz.
3.6.3.2.1 Memory Configuration
68 ECM-QM77 User’s Manual
Item
Option
Description
RC6 (Render Standby)
Disabled[Default]
Enabled
Check to enable render standby
support.
RC6+(Deep RC6)
Check to enable Deep
RC6(RC6+) support.
GT Overclocking Support
Enable or disable GT
OverClocking Support.
3.6.3.2.2 GT – Power Management Control
User’s Manual
ECM-QM77 User’s Manual 69
ECM-QM77
Item
Option
Description
Graphics Turbo IMON Current
14 ~31[Default]
Graphics turbo IMON current
values (14 -31)
Primary Display
Auto
IGFX[Default]
Select which of IGFX/PEG
Graphics device should be
Primary Display Or select SG for
Switchable Gfx.
Internal Graphics
Auto[Default]
Disabled
Enabled
Keep IGD enabled based on the
setup options.
GTT Size
1MB
2MB[Default]
Select the GTT size
Aperture Size
[128MB]
[256MB] [Default]
[512MB]
Select the Aperture Size
DVMT Pre-Allocated
[32M] [64M] [Default]
[96M] [128M] [160M] [192M]
[224M] [256M] [288M] [320M]
[352M] [384M] [416M] [448M]
[480M] [512M] [1024M]
Select DVMT 5.0 Pre-Allocated
(Fixed) Graphics Memory size
used by the Internal Graphics
Device.
DVMT Total Gfx Mem
[128MB]
[256MB] [Default]
[MAX]
Select DVMT5.0 Total Graphic
Memory size used by the Internal
Graphics Device.
Gfx Low Power Mode
Disabled
Enabled[Default]
This option is applicable for SFF
only.
Graphics Performance
Analyzers
Disabled[Default]
Enabled
Enable or disable Intel Graphics
Performance Analyzers Counters.
3.6.3.3 Graphics Configuration
70 ECM-QM77 User’s Manual
User’s Manual
Primary IGFX Boot Display
VBIOS Default[Default]
CRT
LVDS
HDMI
Select the Video Device which will
be activated during POST. This
has no effect if external graphics
present. Secondary boot display
selection will appear based on
your selection. VGA modes will be
supported only on primary
display.
Spread Spectrum clock Chip
Off[Default]
Hardware
Software
>>Hardware : Spread is controlled
by chip;>>Software : Spread is
controlled by BIOS.
ALS Support
Disabled[Default]
Enabled
Valid only for ACPI. Legacy= ALS
Support through the IGD INT10
function. ACPI= ALS support
through an ACPI ALS driver.
Active LFP
No LVDS
eDP Port-A[Default]
Select the Active LFP
Configuration. No LVDS: VBIOS
does not enable LVDS. Int-LVDS:
VBIOS enables LVDS driver by
Integrated encoder. SDVO LVDS:
VBIOS enables LVDS driver by
SDVO encoder. eDP Port-A: LFP
Driven by Int-DisplayPort encoder
from Port-A. eDP Port-D: LFP
Driven by Int-DisplayPort encoder
from Port-D (through PCH).
CH7511 EDID Panel Option
1024x768 24/1[Default]
800x600 18/1
1024x768 18/1
1366x768 18/1
1024x600 18/1
1280x800 18/1
1920x1200 24/2
640x480 18/1
800x480 18/1
1920x1080 18/2
1280x1024 24/2
1440x900 18/2
1600x1200 24/2
1366x768 24/1
1920x1080 24/2
1680x1050 24/2
Port1-EDP to LVDS(Chrotel
7511) Panel EDID Option.
LVDS Back Light PWM
00%
25%
50%[Default]
75%
100%
Select LVDS back light PWM
duty.
LVDS Back Light PWM
Frequency
200 Hz[Default]/330 Hz/500 Hz
1 kHz/2 kHz/3 kHz
5 kHz/10 kHz/24 kHz
31 kHz/47 kHz/94 kHz
Select LVDS back light PWM
Frequency.
ECM-QM77 User’s Manual 71
ECM-QM77
Item
Option
Description
Setup Prompt Timeout
1~ 65535
Number of seconds to wait for
setup activation key.
65535(0xFFFF) means indefinite
waiting.
Bootup NumLock State
On
Off[Default]
Select the Keyboard NumLock
state
Quiet Boot
Disabled[Default]
Enabled
Enables or disables Quiet Boot
option
Fast Boot
Enables or disables boot with initialization of a minimal set of devices
required to launch active boot option. Has no effect for BBS boot
options.
GateA20 Active
Upon Request[Default]
Always
UPON REQUEST –GA20 can be
disabled using BIOS services.
ALWAYS – do not allow disabling
GA20; this option is useful when
any RT code is executed above
1MB.
Option ROM Messages
Force BIOS[Default]
Keep Current
Set display mode for Option
ROM.
INT19 Trap Response
Immediate[Default]
Postponed
BIOS reaction on INT19 trapping
by Option ROM: IMMEDIATE –
execute the trap right away;
POSTPONED – execute the trap
during legacy boot.
Boot Option #1/2/3
Sets the system boot order
CSM parameters
OpROM execution, boot options filter,etc.
3.6.4 Boot
72 ECM-QM77 User’s Manual
Item
Option
Description
Launch CSM
Always[Default]
Never
This option controls if CSM will be
launched.
Boot option filter
UEFI and Legacy[Default]
Legacy only
UEFI only
This option controls what devices
system can boot to.
Launch PXE OpROM policy
Do not launch
UEFI only[Default]
Legacy only
Controls the execution of UEFI
and Legacy PXE OpROM.
Launch Storage OpROM policy
Do not launch
UEFI only[Default]
Legacy only
Controls the execution of UEFI
and Legacy Storage OpROM.
Launch Video OpROM policy
Do not launch[Default]
UEFI only
Legacy only
Controls the execution of UEFI
and Legacy Video OpROM.
Other PCI device ROM priority
UEFI OpROM[Default]
Legacy OpROM
For PCI devices other than
Network, Mass storage or Video
defines which OpROM to launch.
3.6.4.1 CSM parameters
User’s Manual
ECM-QM77 User’s Manual 73
ECM-QM77
3.6.5 Security
Administrator Password
Set setup Administrator Password
User Password
Set User Password
74 ECM-QM77 User’s Manual
3.6.6 Save and exit
User’s Manual
3.6.6.1 Save Changes and Exit
Exit system setup after saving the changes.
3.6.6.2 Discard Changes and Exit
Exit system setup without saving any changes.
ECM-QM77 User’s Manual 75
ECM-QM77
3.6.6.3 Save Changes and Reset
Reset the system after saving the changes.
3.6.6.4 Discard Changes and Reset
Any changes made to BIOS settings during this session of the BIOS setup program are
discarded. The setup program then exits and reboots the controller.
3.6.6.5 Save Changes
Save Changes done so far to any of the setup options.
3.6.6.6 Discard Changes
Discard Changes done so far to any of the setup options.
3.6.6.7 Restore Defaults
This option restores all BIOS settings to the factory default. This option is useful if the
controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting.
3.6.6.8 Save as User Defaults
This option saves a copy of the current BIOS settings as the User Defaults. This option is
useful for preserving custom BIOS setup configurations.
3.6.6.9 Restore as User Defaults
This option restores all BIOS settings to the user defaults. This option is useful for restoring
previously preserved custom BIOS setup configurations.
76 ECM-QM77 User’s Manual
User’s Manual
4. Drivers Installation
Note: Installation procedures and screen shots in this section are
for your reference and may not be exactly the same as
shown on your screen.
ECM-QM77 User’s Manual 77
ECM-QM77
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \
Driver_Chipset\Intel\ECM-QM77_INF.
Note: The installation procedures and
screen shots in this section are
based on Windows 7 operation
system. If the warning message
appears while the installation
process, click Continue to go on.
Step 3. Click Next.
Step1. Click Next..
Step 4. Click Next.
Step 2. Click Yes.
Step 5. Click Finish to complete setup.
4.1 Install Chipset Driver (For Intel QM77)
78 ECM-QM77 User’s Manual
4.2 Install ME Driver (For Intel QM77)
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \ Utility\ECM-QM77_ME
Note: The installation procedures and
screen shots in this section are
based on Windows 7 operation
system. If the warning message
appears while the installation
process, click Continue to go on.
Step 3. Click Next to proceed setup.
Step1. Click Next to start installation.
Step 4. Click Install.
Step 2. Click Yes to accept license
agreement.
Step 5. Click Next to continue.
User’s Manual
ECM-QM77 User’s Manual 79
ECM-QM77
Step 6. Click Finish to complete setup.
80 ECM-QM77 User’s Manual
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to\ Utility\ECM-QM77_USB3.0.
Note: The installation procedures and
screen shots in this section are
based on Windows 7 operation
system. If the warning message
appears while the installation
process, click Continue to go on.
Step 3. Click Next to continue installation.
Step1. Click Next to start installation.
.
Step 4. Click Next to continue installation.
Step 2. Click Yes.
Step 5. Click Finish to complete setup.
4.3 Install USB 3.0 Driver (For Intel QM77)
User’s Manual
ECM-QM77 User’s Manual 81
ECM-QM77
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to \ VGA\ECM-QM77_VGA.
Note: The installation procedures and
screen shots in this section are
based on Windows XP operation
system.
Step 3. Click Next.
Step 1. Click Next to continue installation.
Step 4. Click Install.
Step 2.
Click Yes to accept license agreement.
Step 5. Click Next.
4.4 Install VGA Driver (For Intel QM77)
82 ECM-QM77 User’s Manual
User’s Manual
Step 6. Click Finish to complete setup.
ECM-QM77 User’s Manual 83
ECM-QM77
Insert the Supporting CD-ROM to CD-ROM drive,
and it should show the index page of Avalue’s
products automatically. If not, locate Index.htm and
choose the product from the menu left, or link to \
Driver_Audio\Realtek\ALC892\ECM-QM77_Audio.
Note: The installation procedures and screen shots in
this section are based on Windows 7 operation
system.
Step 1. Click Next to continue setup.
Step 2. Click Finish to complete the setup.
4.5 Install Audio Driver (For Realtek ALC892)
84 ECM-QM77 User’s Manual
Insert the Supporting DVD-ROM to
DVD-ROM drive, and it should show the
index page of Avalue’s products
automatically. If not, locate Index.htm and
choose the product from the menu left, or
link to
D:\
Driver_Gigabit\Intel\82579\ECM-QM77_LA
N.
Note: The installation procedures and
screen shots in this section are based
on Windows 7 operation system.
Step 3. Click Next after choosing
features to install.
Step 1. Click Next.
Step 4. Click Install to proceed.
Step 2. Click Next to accept license
agreement.
Step 5. Click Next to continue installation
4.6 Install Ethernet Driver (For Intel 82579LM and 82574L)
User’s Manual
ECM-QM77 User’s Manual 85
ECM-QM77
Step 6. Click Finish to complete the setup.
86 ECM-QM77 User’s Manual
User’s Manual
5. Mechanical Drawing
ECM-QM77 User’s Manual 87
ECM-QM77
Unit: mm
88 ECM-QM77 User’s Manual
User’s Manual
Unit: mm
ECM-QM77 User’s Manual 89
Loading...
