Avalon RF TX600, TX618, TX623, TX630 User's Manual & Operating Manual

TX600/TX618/TX623/TX630

2.4GHz Video Transmitters

User's Guide & Operating Manual

AV030201/1-000

REV. C4 - 8 October 2003

FCC ID: Q7ITX600-18-23-30

Authored by Guru Mujumdar

Prepared by Steve Jones

Available Through CP Communications - www.cpcomms.com

AVALON RF, INC. Page ii
TX600 Series User’s Guide & Operating Manual

FCC INFORMATION

FCC ID: Q7ITX600-18-23-30

This unit complies with Parts 74 & 90 of the FCC regulations.

Maximum Permissible Exposure

Any Wireless Equipment can pose health hazards if precaution is not

exercised in its use/operation, especially its proximity to the human body.

Excessive absorption of RF energy in the body is known to cause Cancer

and/or other diseases. The FCC has issued guidelines to determine the

safe distance of a transmitting antenna from the human body, to limit

absorption to safe levels. Please follow the instructions given in this

manual.

WARNING: Refer to Table 4 in Section 3 (Operating the transmitter) to

determine the MINIMUM DISTANCE the Transmitter with Antenna

mounted, or the Antenna itself (if connected via coax to the transmitter),

must be placed away from the body to minimize the health hazard. Also,

note the Warning for TX630 after Table 4. User’s failure to comply with the

instructions in this manual voids the site license granted.

AVALON RF, INC. Page iii
TX600 Series User’s Guide & Operating Manual

Table of Contents

1. General .................................................................................................1

Table 1 – Model/Output Power .............................................................1

Figure A – TX600 Series Controls and Connectors ..............................3

Video.....................................................................................................4

Audio.....................................................................................................4

Talk Back Audio Channel (Optional).....................................................4

Two Way Digital Data Link (DDL) (Optional) ........................................4

Motion Sensor Input (Optional) ............................................................. 4

Telemetry Input (Optional) ....................................................................5

RF Outputs............................................................................................5

2. Specifications ........................................................................................ 6

User Interface ....................................................................................... 6

Setup ....................................................................................................6

Electrical Interface ................................................................................ 7

Table 2 – Current Consumption............................................................7

Table 3 – Power Output ........................................................................ 8

Interconnecting ..................................................................................... 9

Figure B – DB 15 .................................................................................. 9

Figure C – Power/Video......................................................................10

Figure D – Video.................................................................................10

Figure E – Audio .................................................................................10

Figure F – Data Input..........................................................................11

Mounting .............................................................................................12

Mechanical Data .................................................................................13

Environmental Conditions ................................................................... 14

3. Operating the transmitter. ...................................................................15

Operater Controls & Indicators ...........................................................15

General Guidelines .............................................................................16

Table 4 – Minimum Safe Distance ...................................................... 17

4. Ordering information ...........................................................................18

Base Models .......................................................................................18

Options ...............................................................................................19

Recommended Accessories ...............................................................20

Antennas .........................................................................................20

Table 5 – Permissible Antenna/Transmitter Model Combinations...21

Cables .............................................................................................22

Battery Packs ..................................................................................22

Warranty..............................................................................................23
