AvaLAN Wireless AW-900i User Manual
AW900i
USER’S MANUAL
Point-to-point
Industrial-grade, ultra-long-range 900 MHz
non-line-of-sight wireless Ethernet systems
AW900i
User’s Manual
Non-line-of-sight :: 900 MHz
Thank you for your purchase of the AW900i
AW900i Kit
point-to-point wireless Ethernet bridge.
Long-range 900 MHz wireless indoor Ethernet
If you have any questions when conguring
your AvaLAN system, please send an e-mail
to support@avalanwireless.com.
For a live technician, please call technical
support at (650) 384-0000.
bridge. Kit includes:
n
— (2) AW900i indoor radios
n
— (2) 110 VAC to 6 VDC power adapters
n
— (2) AW2 2.5 dBi omni-directional antennae
Or upgrade to AW5H-900, AW5P-900, AW6, AW10, AW11, or AW15
— all FCC approved
For advanced installation information,
please visit www.avalanwireless.com.
Operational summary
The AW900i replaces costly wiring with a wireless Ethernet bridge that can enable remote Wi-Fi access points, Ethernet pan/tilt/zoom
security cameras, VoIP phones, or Internet kiosks. AvaLAN’s product offers the ideal combination of price, range, data rate, security,
interference avoidance, quality-of-service, and ease-of-use.
The AW900i is the best solution when:
— a Broadband Ethernet drop will cost too much or is impractical to install
— guaranteed DSL-rate throughput is required (kiosks/Wi-Fi access points/PTZ cameras)
— guaranteed latency for voice or video is required (PTZ cameras/VoIP)
— Wi-Fi is too slow due to saturation or 2.4 GHz interference (airport/mall/PTZ cameras)
— an indoor long-range broadband backhaul is required
n
n
n
n
n
Features include:
— does not interfere with Wi-Fi networks
— Highest Quality of Service (QoS) available — synchronous point-to-point protocol enables extremely low data latency and
n
n
— jitter (surveillance video and VoIP)
— 128 bit encrypted payload protection provides secure data delivery
— simple plug and play — pre-congured as matched pairs with no user programming required
— operates in the 902-928 MHz band and does not require an FCC license to operate or install
— VLAN extensions supported
n
n
n
n
Technical support :: (650) 384.0000
PAGE 2
www.avalanwireless.com
AW900iUser’s Manual
Quick setup
1) Attach an AW2 antenna to each radio.
2) Plug in the AW900i using the power adapter.
3) Connect an Ethernet cable from each AW900i to a network device.
4) Send Ethernet trafc. For troubleshooting, see Page 4.
System diagram
Each AW900i radio automatically selects the best radio channel, encrypts the Ethernet trafc, and transports the data wirelessly to its
mate. Any Ethernet device can be connected to the AW900i. The AW900i functions in place of an Ethernet cable and provides a transparent wireless point-to-point Ethernet cable replacement. Crossover cables are not necessary as the AW900i automatically senses the
device (client or switch).
Power adapter
110 VAC
Ethernet
RJ45/10BaseT
Ethernet
RJ45/10BaseT
Power adapter
110 VAC
AW900i
900 MHz
digital
Ethernet
bridge
AW900i
www.avalanwireless.com
PAGE 3
Technical support :: (650) 384.0000
