LSISAS9205-8e
PCI Express to 6Gb/s Serial Attached SCSI (SAS)
Host Bus Adapter
User Guide
Version 1.1
May 2011
DB15-000735-01
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
Revision History
Version and Date Description of Changes
Version 1.1, May 2011 Final release of this document.
Version 1.0, November 2010 Initial release of this document as Preliminary.
LSI, the LSI & Design logo, and Fusion-MPT are trademarks or registered trademarks of LSI Corporation or its subsidiaries. All other brand and product names may be trademarks of their respective
companies.
LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of
the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation; nor does the purchase, lease, or use of a product or service from LSI Corporation
convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Corporation or of third parties. LSI products are not intended for use in life-support
appliances, devices, or systems. Use of any LSI product in such applications without written consent of the appropriate LSI officer is prohibited.
Corporate Headquarters Email Website
Milpitas, CA globalsupport@lsi.com www.lsi.com
800-372-2447
Document Number: DB15-000735-01
Copyright © 2011 LSI Corporation
All Rights Reserved
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
Table of Contents
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 PCI Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.1 Quick Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.2 Detailed Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6 Characteristics of the LSI PCIe-to-SAS HBA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.1 Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.2 AVSO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.3 LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.4 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.5 Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Electrical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.1 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.2 Thermal and Atmospheric Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.3 Safety Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
LSI Corporation
- 1 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
LSI Corporation
- 2 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
User Guide
1Overview
The LSISAS9205-8e PCI Express® (PCIe®)-to-Serial Attached SCSI (SAS) host bus adapter (HBA) provides high
performance storage connectivity to computers, workstations, and servers via the new LSISAS2308 controller chip.
The low profile design of the 8-lane HBA includes a low profile mounting bracket that makes it easy to add SAS 2.0
interface devices to PCI Specification Revision 2.0 hosts. The HBA stores BIOS information and its own Fusion-MPT™
operating firmware in onboard non volatile memory. The associated Fusion-MPT software drivers assure the
LSISAS9205-8e is compatible with all major operating systems.
The LSISAS9205-8e provides 8-lanes of 6Gb/s SAS connectivity via two external, 4-lane SFF8088 Multilane connectors.
The HBA supports over 1000 SAS addresses and has processing power to support over 500,000 I/Os per second.
2Features
This section lists the LSI PCIe-to-SAS HBA features.
Supports serial SCSI protocol (SSP), serial ATA tunneling protocol (STP), and serial management protocol (SMP), as
defined, in the Serial Attached SCSI (SAS) Specification, version 2.0.
Supports SATA, as defined in the Serial ATA Specification Revision 2.6.
Provides configurable drive spin-up sequencing on a per-phy basis.
Simplifies cabling with a point-to-point, serial architecture.
Provides smaller and thinner cables that promote unrestricted airflow.
Provides a serial, point-to-point, enterprise-level storage interface.
Transfers data using SCSI information units.
Provides compatibility with SATA target devices.
Supports CRC generation and checking on the PCIe buses and the SAS buses.
Supports narrow ports and wide ports, as described in the following table.
Table 1 6Gb/s SAS Bandwidths
Half Duplex Full Duplex
Narrow Port (1 Lane), 600 MB/s Narrow Port (1 Lane), 1200 MB/s
Wide Port (4 Lanes), 2400 MB/s Wide Port (4 Lanes), 4800 MB/s
3PCI Performance
The LSI PCIe-to-SAS HBA supports the following features of the PCIe interface.
A single-phy (one lane) link transfer rate up to 5Gb/s in each direction.
Link widths of x8, x4, x2, and x1.
Automatic downshift. The HBA automatically downshifts to a x4 link if plugged into a x8 connector that is wired
as a x4 connector.
LSI Corporation
- 3 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
A scalable interface.
Table 2 Aggregate Bandwidth
Lanes Single Direction Dual Direction
Single-lane (x1) 5Gb/s 10Gb/s
Quad-lane (x4) 20Gb/s 40Gb/s
Eight-lane (x8) 40Gb/s 80Gb/s
Serial, point-to-point interconnections between devices.
— Reduces the electrical load of the connection
— Enables higher transmission and reception frequencies
Lane reversal and polarity inversion.
PCIe hot plug.
Power management.
— Supports PCI Power Management 1.2
— Supports active-state power management (ASPM), including the L0 states, by placing links in a power-saving
mode when there is no link activity
A replay buffer that preserves a copy of the data for retransmission in case a cyclic redundancy check (CRC) error
occurs.
PCIe advanced error-reporting capabilities.
Packetized and layered architecture.
High bandwidth per pin with low overhead and low latency.
Software compatibility with PCI and PCI-X software.
— Leverages existing PCI device drivers
— Supports the memory, I/O, and configuration address spaces
— Supports memory read/write transactions, I/O read/write transactions, and configuration read/write
transactions
Four kilobytes of PCI configuration address space per device.
Posted transactions and non-posted transactions.
Quality-of-service (QOS) link configuration and arbitration policies.
Traffic Class 0 and one virtual channel.
Message-signaled interrupts (both MSI and MSI-X), and INTx interrupt signaling for legacy PCI support.
End-to-end CRC (ECRC) and advanced error reporting.
LSI Corporation
- 4 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
4Software
The following table shows all of the available software drivers for the different operating systems that the LSI
PCIe-to-SAS HBA supports.
Table 3 Operating System (OS) Drivers
OS Support Versions
Windows® Server 2003/2008, XP/Vista/Windows 7
Linux®: Red Hat® Enterprise Linux® (RHEL) 4 and 5
Linux: SUSE® Enterprise Server (SLES) 9, 10, and 11
Sun™ SPARC® Solaris™ Solaris 10, Update 8
VMware® (ESXi) 4.1 and 5.0
FreeBSD® 8.1 or 8.2-Release
Utilities Flash and BIOS Configuration Utility
The LSI HBA uses the Fusion-MPT architecture for all major operating systems, which permits thinner drivers for better
performance. To obtain a device driver that supports your operating system, contact the LSI Technical Support team
or visit the LSI website.
5 Hardware Installation
This section provides both quick instructions and detailed instructions on how to install your LSI PCIe-to-SAS HBA.
5.1 Quick Installation Instructions
Use the following quick installation instructions to install your LSI PCIe-to-SAS HBA if you are comfortable with the
abbreviated installation instructions. The following section provides detailed installation instructions.
1. Unpack the HBA and inspect it for damage.
2. Turn off the system and disconnect any power cords.
3. Remove the cover from the chassis.
4. Insert the HBA into an available and appropriate sized PCIe slot.
5. Secure the bracket to the system’s chassis.
6. Connect serial cables between the HBA and any serial hard disk drives (HDDs) or external enclosure. Figure1
shows the locations of the connectors on your HBA.
7. Replace the cover and any power cords, and power up the system.
The hardware installation of your LSI HBA is complete.
LSI Corporation
- 5 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
85050-00
PCI Slot
Mini-SAS
Connectors
Mini-SAS
Connectors
Edge of
Host Board
5.2 Detailed Installation Instructions
Detailed installation instructions for the LSI PCIe-to-SAS HBA follow.
1. Unpack the HBA and inspect it for damage. Unpack the HBA in a static-free environment. Remove the HBA
from the antistatic bag and carefully inspect it for damage. If you notice any damage, or if any component is
missing, contact LSI or your reseller support representative.
CAUTION Make a backup of your data before changing your system configuration.
2. Prepare the computer. Turn off the computer and disconnect the power cord from the back of the power supply.
3. Remove the cover from the chassis.
WARNING Be certain to disconnect the computer from the power supply and from any networks before
installing the HBA.
4. Replace the mounting bracket (system dependent). If required for your system, replace the full-length
mounting bracket that ships on the LSISAS9205-8e HBA with the shorter bracket supplied. Save and reuse the
two screws that attach the long bracket to attach the short bracket.
5. Insert the HBA in an available PCIe slot. Locate an empty PCIe slot. Remove the blank bracket panel on the back
of the computer that aligns with the empty PCIe slot. Save the bracket screw, if applicable.
Align the HBA to a PCIe slot. Press down gently but firmly to properly seat the HBA in the slot. The following figure
shows how to insert the HBA in a PCIe slot.
Figure 1 Installing an LSI PCIe to SAS x8 HBA in a PCI Express Slot
NOTE The shape, size, and locations of components on your HBA and its bracket might vary from this
illustration. The LSISAS9205-8e HBA requires a x8 PCIe slot.
LSI Corporation
- 6 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
6. Secure the bracket to the system’s chassis. Install the bracket screw, if applicable, or engage the system
retention mechanism to secure the HBA to the system’s chassis.
7. Connect serial cables between the HBA and any serial HDDs. Connect serial cables between the host adapter
and any HDDs. Figure1 shows the locations of the HBA connectors.
8. Replace the cover and any power cords and power up the system. Replace the system’s cover, reconnect any
power cords, and reconnect any network cables. Turn on the power.
The installation of your LSI PCIe-to-SAS HBA is complete.
6 Characteristics of the LSI PCIe-to-SAS HBA
The LSISAS2308 controller brings 6Gb/s SAS performance to HBA, workstation, and server designs, making it easy to
add a SAS interface to any PCIe system. Each of the eight SAS phys on the LSISAS2308 controller is capable of up to
6Gb/s SAS or SATA link rates.
6.1 Flash
The LSISAS9205-8e HBA has onboard Flash ROM for firmware and BIOS. The LSI PCIe-to-SAS HBA provides one 8M x
8-bit Flash ROM for storing the BIOS and firmware.
6.2 AVSO
The LSISAS9205-8e supports Adaptive Voltage Scaling and Optimization (AVSO). AVSO dynamically adjusts voltage
based on process monitors to reduce a high power value and achieve the required performance at a minimum
voltage.
6.3 LED
The LSISAS9205-8e HBA heartbeat LED blinks green to indicate that the HBA is capable of general activity.
6.4 Connectors
This section describes the different connectors on the LSISAS9205-8e HBA. See Figure2 for connector locations.
PCIe Connector (EC1). The LSISAS9205-8e HBA supports a x8 interface. The PCIe connection is through the edge
connector (EC1) which provides connections on both the top (EC1B) and bottom (EC1A) of the board. The signal
definitions and pin numbers conform to the PCIe specification.
SAS/SATA Connectors (J5 and J6). The LSISAS9205-8e HBA supports SAS/SATA connections through connectors J5
and J6, which are SFF-8088 mini-SAS, external, right-angle connectors.
ICE JTAG Connector (J1) The LSISAS9205-8e HBA supports an ICE JTAG header for debug through the edge
connector, J1.
Table 4 LSISAS9205-8e ICE JTAG Header Pinout
Pin Function Pin Function
1 ICE_TDO 9 ICE_TMS
2NC10NC
3 ICE_TDI 11 HDR_SYS_HALT_L
LSI Corporation
- 7 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
LSISAS2308
J5
J4
J6
EC1
J1
Controller
Table 4 LSISAS9205-8e ICE JTAG Header Pinout
Pin Function Pin Function
4 R_ICE_TRST_L 12 NC
5NC13NC
61.8 V14NC
7 ICE_TCK 15 NC
8NC16Gnd
UART Connector (J4) The UART connector debug port requires a special cable and LSI support to gather detailed IOC
status.
Table 5 LSISAS9205-8e UART Pinout
Pin Function
1UART_TX
2Gnd
3UART_RX
4+1.8 V
6.5 Physical Characteristics
The LSISAS9205-8e HBA is a 6.6-in. x 2.713-in., low-profile board. The component height on the top and bottom of the
LSISAS9205-8e HBA follows the PCIe specification. The following figure shows the board connectors.
Figure 2 LSISAS9205-8e Board Layout
EC1: PCIe x8-lane board edge connector
J1: ICE JTAG debug connection
J4: UART connection
J5, J6: SFF-8088 mini-SAS, external, right-angle connectors
LSI Corporation
- 8 -
LSISAS9205-8e PCI Express to 6Gb/s SAS HBA User Guide May 2011
7 Electrical and Environmental Specifications
The design and implementation of the LSI PCIe-to-SAS HBA minimizes electromagnetic emissions, susceptibility to
radio frequency energy, and the effects of electrostatic discharge. The board carries the CE mark, C-Tick mark,
Canadian Compliance Statement, Korean KCC, Taiwan BSMI, Japan VCCI, and FCC Class B, and it is marked with the FCC
Self-Certification logo. The board also meets the requirements of CISPR Class B.
7.1 Electrical Characteristics
The maximum power requirements for the LSISAS9205-8e HBA under normal operation are as follows:
PCIe 12.0 V = 1.26 A
Power = 15.15 W
Operation range = 0 °C to 55 °C
7.2 Thermal and Atmospheric Characteristics
The atmospheric characteristics for the LSI PCIe-to-SAS HBA are as follows:
Temperature range: 0 °C to 55 °C (dry bulb)
Relative humidity range: 5% to 90% non-condensing
Maximum dew point temperature: 32 °C
The following parameters define the storage and transit environment for the LSI PCIe-to-SAS HBA:
Temperature range: −45 °C to +105 °C (dry bulb)
Relative humidity range: 5% to 90% non-condensing
7.3 Safety Characteristics
All LSI PCIe-to-SAS HBAs meet or exceed the requirements of UL flammability rating 94V-0. Each bare board is marked
with the supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in a PCIe
bus slot, all voltages are below the SELV 42.4-V limit.
LSI Corporation
- 9 -
Loading...
