Chapter 1 Introduction
This chapter describes the LSI Logic PCI-X to 3.0 Gbit/s Serial Attached SCSI (SAS) host adapters and consists of the following sections:
Section 1.1, “Overview”
Section 1.2, “Features”
Section 1.3, “PCI Performance”
Section 1.4, “Software”

1.1 Overview

The LSI PCI-X to 3.0 Gbit/s Serial Attached SCSI host adapters provide four or eight serial ports for connection to SAS/SATA (Serial ATA) devices. Each port is capable of 3.0 Gbit/s SAS link rates and 3.0 Gbit/s SATA link rates. The PCI-X interface operates as a zero wait state bus master with data bursts up to 1064 Mbytes/s on a 64-bit PCI-X 133 MHz bus.
These LSI host adapters contain Flash ROM for storing the BIOS and firmware, and NVSRAM for storing nonvolatile RAID information. The LEDs on the host adapters report a heartbeat and activity and fault conditions when detected by firmware. Fusion-MPT™ firmware operates the host adapter.
The PCI/PCI-X interface is compliant with the PCI-X Specification, revision 2.0, and backwards compliant with previous versions of the PCI/PCI-X specifications. The host adapter is keyed for 3.3 V PCI/PCI-X add-in card slots. The LSI PCI-X to 3.0 Gbit/s SAS host adapters use either a standard PCI or a low-profile PCI bracket type. The host adapter SAS interface is compatible with the ANSI Serial Attached SCSI
Specification, revision 1.0 and the Serial ATA Specification, revision 1.0a.
PCI-X to 3.0 Gbit/s SAS Host Adapters User’s Guide 1-1
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
The functionality of these host adapters comes from either the LSISAS1064 controller chip or the LSISAS1068 controller chip. The LSISAS1064 integrates four high-performance SAS/SATA phys and a 64-bit, 133 MHz PCI-X bus master DMA core. The LSISAS1068 integrates eight high-performance SAS/SATA phys and a 64-bit, 133 MHz PCI-X bus master DMA core. The design of these host adapters make it easy to add SAS interfaces to any computer, workstation, or server with a PCI/PCI-X bus.
Ta bl e 1 .1 shows the LSI SAS controllers and their associated host
adapters that support SAS/SATA devices. Boards without an “L” after the number in their name use a standard PCI bracket type. Boards with an “L” after the number in their name use a low-profile PCI bracket type.
Table 1.1 PCI-X to 3.0 Gbit/s Host Adapters and Controllers
Controllers PCI-X to 3.0 Gbit/s Host Adapters
LSISAS1064 LSISAS3041X, LSISAS3041XL
LSISAS1068 LSISAS3442X, LSISAS3442XL,
LSISAS3080X, LSISAS3080XL, LSISAS3800X, LSISAS3801X LSISAS3801XL
1-2 Introduction
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

1.2 Features

This section lists features of the LSI PCI-X to 3.0 Gbit/s SAS host adapters:
Supports narrow port and wide port as shown in Tab l e 1.2 .
Table 1.2 SAS Bandwidths
Half Duplex Full Duplex
Narrow Port (1 Lane)—300 Mbytes/s Narrow Port (1 Lane)—600 Mbytes/s
Wide Port (2 Lanes)—600 Mbytes/s Wide Port (2 Lanes)—1200 Mbytes/s
Wide Port (4 Lanes)—1200 Mbytes/s Wide Port (4 Lanes)—2400 Mbytes/s
Supports SSP, STP, and SMP as defined in the Serial Attached SCSI
(SAS) Specification, version 1.0.
Supports SATA as defined in the Serial ATA Specification, version
1.0.
Provides configurable drive spin-up sequencing on a per-phy basis.
Simplifies cabling with a point-to-point, serial architecture.
Provides smaller and thinner cables that do not restrict airflow.
Provides a serial, point-to-point, enterprise-level storage interface.
Transfers data using SCSI information units.
Provides two LEDs for each phy to indicate link activity and faults for
the LSISAS3041X, LSISAS3041XL, LSISAS3442X, LSISAS3442XL, LSISAS3800X, LSISAS3801X, and LSISAS3801XL host board adapters (HBAs).
Provides two light pipes routed through the PCI bracket for the
LSISAS3442X, LSISAS3442XL, LSISAS3080X, LSISAS3080XL, and LSISAS3800X host board adapters. One light pipe indicates activity on any phy. The other light pipe indicates a heartbeat or a fault condition. The LSISAS3801X and LSISAS3801XL do not include these two light pipes.
Provides compatibility with SATA target devices.
Features 1-3
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

1.3 PCI Performance

PCI features of the LSI PCI-X to 3.0 Gbit/s SAS host adapters include:
Supports a 133 MHz, 64-bit PCI/PCI-X interface that does the
following:
Operates up to 133 MHz PCI-X
Operates at 33 MHz or 66 MHz PCI
Supports 32-bit or 64-bit data transfers
Supports 32-bit or 64-bit addressing through Dual Address
Cycles (DAC)
Provides a theoretical 1064 Mbytes/s PCI bandwidth
Complies with the PCI Local Bus Specification, revision 3.0
Complies with the PCI-X Addendum to the PCI Local Bus
Specification, revision 2.0
Complies with the PCI Bus Power Management Interface
Specification, revision 1.2
Complies with the PC2001 Specification
Provides unequalled performance through the Fusion-MPT
architecture
Provides high throughput and low CPU utilization to offload the host
processor
Presents a single electrical load to the PCI Bus
Reduces Interrupt Service Routine (ISR) overhead with interrupt
coalescing
Supports 32-bit or 64-bit data bursts with variable burst lengths
Supports the PCI Cache Line Size register
Supports the PCI Memory Write and Invalidate, Memory Read Line,
and Memory Read Multiple commands
Supports the PCI-X Memory Read Dword, Split Completion, Memory
Read Block, and Memory Write Block commands
Supports 16 PCI-X Split Transaction cycles
1-4 Introduction
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

1.4 Software

Supports backwards compatibility with previous revisions of the PCI
specification
Provides a full 32-bit or 64-bit PCI-X DMA bus master
Reduces time-to-market with the Fusion-MPT architecture that
provides:
Single driver binary for SAS/SATA, SCSI, and Fibre Channel
products
One firmware build that supports all Integrated RAID™
capabilities
Thin and easy to develop drivers
Reduced integration and certification effort
The LSI PCI-X to 3.0 Gbit/s SAS host adapters support all major operating systems, as shown in Ta bl e 1 .3.
Table 1.3 Software Support
OS Support Versions
Windows XP, 2000, Server 2003 32-bit and 64-bit (x86 and AMD64)
Red Hat Linux RHEL 3
SuSE Linux 9
Novel NetWare 5.1, 6.5
Sun Sparc Solaris 2.6, 2.7, 2.8, 2.9, 2.10
Utilities Install, Flash, BIOS Configuration
These host adapters use the Fusion-MPT architecture for all major operating systems, which allows for thinner drivers for better performance. To obtain a device driver that supports your operating system, contact the LSI Technical Support team at 719-533-7230 or visit our web site at http://www.lsilogic.com.
Software 1-5
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
1-6 Introduction
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Chapter 2 Hardware Installation
This chapter provides both quick instructions and detailed instructions on how to install the PCI-X to 3.0 Gbit/s SAS host adapter. This chapter consists of the following sections:
Section 2.1, “Quick Installation Instructions”
Section 2.2, “Detailed Installation Instructions”

2.1 Quick Installation Instructions

The following steps summarizes the installation instructions.
Use these instructions to install your PCI-X to 3.0 Gbit/s SAS host adapter if you are comfortable with the installation procedure. Section 2.2 provides detailed installation instructions.
Step 1. Unpack the host adapter and inspect it for damage.
Step 2. Turn off the system and remove the power cord(s).
Step 3. Remove the cover from the system.
Step 4. Insert the host adapter in an available PCI/PCI-X slot.
Step 5. Secure the bracket to the system’s chassis.
Step 6. Connect the serial cable(s) between the host adapter and the
serial hard disk drive(s). Figure 2.1 and Figure 2.2 illustrates the locations of the connectors on your host adapter.
Step 7. Replace the cover and the power cord(s), then power-up the
system.
The PCI-X to 3.0 Gbit/s SAS host adapter hardware installation is complete.
PCI-X to 3.0 Gbit/s SAS Host Adapters User’s Guide 2-1
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

2.2 Detailed Installation Instructions

The following steps provide detailed installation instructions:
Step 1. Unpack the host adapter and inspect it for damage.
Unpack the host adapter in a static-free environment. Remove the host adapter from the anti-static bag and inspect it for damage. Contact LSI or your OEM support representative if the host adapter appears damaged.
Step 2. Turn off the system and disconnect the power cord(s).
Turn off the system’s power and physically remove the power cord(s) from the system.
Step 3. Remove the cover from the system.
Remove the cover from the system’s chassis. Disconnect the system from any networks.
Step 4. Insert the host adapter in an available PCI/PCI-X slot.
Locate an empty PCI/PCI-X slot. Remove the blank bracket panel on the back of the computer that is aligned with the PCI/PCI-X slot you have selected. Save the bracket screw when present.
Align the host adapter to a PCI/PCI-X slot. Press down gently but firmly to properly seat the host adapter in the slot.
Figure 2.1 and Figure 2.2 illustrate how to insert the host
adapter in a PCI/PCI-X slot.
Note:
The HBA is keyed for a 3.3 V slot. The keying of edge connector J1 prevents the card from being installed in a 5 V slot.
Step 5. Secure the bracket to the system’s chassis.
Install the bracket screw, when present, or engage the system’s retention mechanism to secure the host adapter to the system’s chassis.
Step 6. Connect the serial cable(s) between the host adapter and the
serial hard disk drive(s) (HDD). Figure 2.1 and Figure 2.2 illustrate the locations of the connectors on your host adapter.
2-2 Hardware Installation
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Step 7. Replace the cover and the power cord(s), then power-up the
system.
Replace the system’s cover, reconnect the power cord(s) and any network cables. Turn power on to the system.
The PCI-X to 3.0 Gbit/s SAS host adapter hardware installation is complete.
Figure 2.1 Installing a PCI-X to 3.0 Gbit/s SAS x4 Host Adapter in
a PCI-X Slot
Serial Signal
Cable
Bracket
Screw
Press Here
HDD
Connector
HBA Single Lane Connector
Press Here
32-bit Slots (3.3 V)
Edge of
Host Board
64-bit Slots (3.3 V)
Detailed Installation Instructions 2-3
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Note: The HBA shape, size, and locations of components on your
x4 HBA and its bracket may vary from this illustration.
Figure 2.2 Installing a PCI-X to 3.0 Gbit/s SAS x8 Host Adapter in
a PCI-X Slot
HDD
Connector
Serial Signal
Bracket
Screw
Press Here
Press Here
Cables
HBA to HDD Breakout Cable
4 Lane
External
PCB
Receptacle
and Cable
with
Jackscrews
SFF-8470
Edge of
Host Board
Note:
The HBA shape, size, and locations of components on your x8 HBA and its bracket may vary from this illustration.
2-4 Hardware Installation
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
4 Lane Internal
HBA Connector
SFF-8484
32-bit Slots (3.3 V)
64-bit Slots (3.3 V)
Chapter 3 Host Adapter Characteristics
This chapter describes the characteristics of the LSI PCI-X to 3.0 Gbit/s SAS host adapters. The chapter includes these topics:
Section 3.1, “Characteristics of the PCI-X to 3.0 Gbit/s SAS Host
Adapters”
Section 3.2, “Electrical and Environmental Specifications”

3.1 Characteristics of the PCI-X to 3.0 Gbit/s SAS Host Adapters

The PCI-X to 3.0 Gbit/s SAS host adapters use either the LSISAS1064 controller or the LSISAS1068 controller. The LSISAS1064 controller connects up to four SAS/SATA devices to a computer system through the PCI/PCI-X interface. The LSISAS1068 controller connects up to eight SAS/SATA devices to a computer system through the PCI/PCI-X interface. In both cases, the use of LSI expanders provides substantially more connectivity. The LSISAS1064 and the LSISAS1068 support a 133 MHz, 64-bit PCI-X bus and are backwards compatible with revisions of the PCI/PCI-X bus.
The LSISAS1064 and the LSISAS1068 controller chips contain the PCI/PCI-X functionality for the PCI-X to 3.0 Gbit/s SAS host adapters. The controller chip connects directly to the PCI/PCI-X bus and generates timing and protocol in compliance with the PCI and PCI-X specifications.
The LSISAS1064 and the LSISAS1068 controller chips contain the SAS/SATA functionality for the PCI-X to 3.0 Gbit/s SAS host adapters. The controller chips connect channels directly to the SAS/SATA devices.
The PCI-X to 3.0 Gbit/s SAS host adapters provide up to 2 M x 8-bit Flash ROM for storing the configuration settings, as well as the BIOS and
PCI-X to 3.0 Gbit/s SAS Host Adapters User’s Guide 3-1
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
firmware. The PCI-X to 3.0 Gbit/s SAS host adapters provide up to 32 K x 8-bit of a NVSRAM device for storing the nonvolatile RAID information when a system failure happens.

3.1.1 LSISAS3041X and LSISAS3041XL Host Adapters Characteristics

The LSISAS3041X and LSISAS3041XL are the same HBA with the exception of the PCI bracket. The LSISAS3041X uses a standard PCI bracket and the LSISAS3041XL uses the low-profile (LPPCI) PCI bracket. Figure 3.1 shows the HBAs and their brackets.
3.1.1.1 LEDs
The LSISAS3041X and LSISAS3041XL host adapters have four LEDs that turn green to indicate an activity condition on any of the four phys. There are four LEDs that turn yellow to indicate a fault condition on any of the four phys. See Figure 3.1 for LED locations. There is one LED that flashes green to indicate the LSISAS1064 heartbeat.
3.1.1.2 Connectors
This section provides a description of the five different connectors on the LSISAS3041X and LSISAS3041XL host adapters. See Figure 3.1 for connector locations.
PCI/PCI-X Connector (J1) – The PCI/PCI-X interface operates as a 32-bit or 64-bit DMA bus master. The connection is made through the edge connector J1, which is a +3.3 V type board edge connector. The signal definitions and pin numbers conform to the PCI/PCI-X specifications.
SAS/SATA Connectors (J2–J5) – The LSISAS3041X supports SAS/SATA connections through connectors J2, J3, J4, and J5. These connectors are SATA internal right-angle connectors.
3-2 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Figure 3.1 LSISAS3041X and LSISAS3041XL Board Layout
LSISAS3041X
Standard PCI
Bracket
Link
LSISAS3041XL
Low-Profile
(LPPCI)
PCI Bracket
Not Present
J2 J3 J4 J5
Activity
Heart beat
LSISAS1064
J1
J1: PCI/PCI-X 64-bit, +3.3 V type board edge connector
J2–J5: SATA internal right-angle connectors
Por t 0Por t 1Por t 2Po rt 3
3.1.1.3 Physical Characteristics
The LSISAS3041X and LSISAS3041XL boards are 6.6 inches x 2.536 inches. PCI/PCI-X connection is made through the edge connector J1. The component height on the top and bottom of the LSISAS3041X and LSISAS3041XL boards follows the PCI/PCI-X specifications.
Characteristics of the PCI-X to 3.0 Gbit/s SAS Host Adapters 3-3
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

3.1.2 LSISAS3442X and LSISAS3442XL Host Adapters Characteristics

The LSISAS3442X and LSISAS3442XL are the same HBA with the exception of the PCI bracket. The LSISAS3442X uses a standard PCI bracket and the LSISAS3442XL uses a low-profile (LPPCI) PCI bracket.
Figure 3.2 shows the HBAs and their brackets.
3.1.2.1 LEDs
The LSISAS3442X and LSISAS3442XL host adapters have eight LEDs that turn green to indicate an activity condition on any of the eight phys. There are eight LEDs that turn yellow to indicate a fault condition on any of the eight phys. See Figure 3.2 for LED locations.
The LSISAS3442X and LSISAS3442XL host adapters have two light pipes routed through the PCI bracket. One light pipe turns green to indicate activity on any phy. The other light pipe is bi-color. It flashes green to indicate the LSISAS1068 heartbeat, or it turns yellow when the LSISAS1068 firmware detects a fault condition.
3.1.2.2 Connectors
This section provides a description of the three different connectors on the LSISAS3442X and LSISAS3442XL host adapters. See Figure 3.2 for connector locations.
PCI/PCI-X Connector (J1) – The PCI/PCI-X interface operates as a 32-bit or 64-bit DMA bus master. The connection is made through the edge connector J1, which is a +3.3 V type board edge connector. The signal definitions and pin numbers conform to the PCI/PCI-X specifications.
SAS/SATA Connectors (J2 and J5) – The LSISAS3442X and LSISAS3442XL support SAS connections through connectors J2 and J5. The J5 connector is an SFF-8484 SAS internal right-angle connector with four sideband lines. The J2 connector is an SFF-8470 SAS external right-angle connector.
J5 contains four Serial General Purpose Input Output (SGPIO) signals. SGPIO is a method to serialize general-purpose IO signals. SGPIO defines the communication between an initiator (for example, a host bus adapter) and a target (for example, a backplane holding disk drives). The
3-4 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
target typically converts the output signals into multiple parallel LED signals and provides the input signals from general-purpose inputs. The SGPIO signals are SCLOCK on pin 14, SLOAD on pin 15, SDATAOUT on pin 18, and SDATAIN on pin 19.
Figure 3.2 LSISAS3442X and LSISAS3442XL Board Layout
LSISAS3442X
Standard PCI Bracket
LSISAS3442XL
Low-Profile
(LPPCI)
PCI Bracket
Link Not
Present
J2
LEDs
Activity
LEDs
LSISAS1068
J1
Two Light Pipes,
One Green and
One Bi-color
J5
J1: PCI/PCI-X 64-bit, +3.3 V type board edge connector
J2: SFF-8470 SAS external right-angle connector
J5: SFF-8484 SAS internal right-angle connector with four sideband
lines
3.1.2.3 Physical Characteristics
The LSISAS3442X and LSISAS3442XL boards are 6.6 inches x 2.536 inches. PCI/PCI-X connection is made through the edge connector J1. The component height on the top and bottom of the LSISAS3442X and LSISAS3442XL boards follows the PCI/PCI-X specifications.
Characteristics of the PCI-X to 3.0 Gbit/s SAS Host Adapters 3-5
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

3.1.3 LSISAS3080X and LSISAS3080XL Host Adapters Characteristics

The LSISAS3080X and LSISAS3080XL are the same HBA with the exception of the PCI bracket. The LSISAS3080X uses a standard PCI bracket and the LSISAS3080XL uses a low-profile (LPPCI) PCI bracket.
Figure 3.3 shows the HBAs and their brackets.
3.1.3.1 LEDs
The LSISAS3080X and LSISAS3080XL host adapters have two light pipes routed through the PCI bracket. One light pipe turns green to indicate activity on any phy. The other light pipe is bi-color. It flashes green to indicate the LSISAS1068 heartbeat, or it turns yellow when the LSISAS1068 firmware detects a fault condition.
3.1.3.2 Connectors
This section provides a description of the three different connectors on the LSISAS3080X and LSISAS3080XL host adapters. See Figure 3.3 for connector locations.
PCI/PCI-X Connector (J1) – The PCI/PCI-X interface operates as a 32-bit or 64-bit DMA bus master. The connection is made through the edge connector J1, which is a +3.3 V type board edge connector. The signal definitions and pin numbers conform to the PCI/PCI-X specifications.
SAS/SATA Connectors (J2 and J5) – The LSISAS3080X and LSISAS3080XL support SAS/SATA connections through connectors J2 and J5. The J2 and J5 connectors are SFF-8484 SAS internal right-angle connectors with four sideband lines.
J2 and J5 contain four Serial General Purpose Input Output (SGPIO) signals. SGPIO is a method to serialize general-purpose IO signals. SGPIO defines the communication between an initiator (for example, a host bus adapter) and a target (for example, a backplane holding disk drives). The target typically converts the output signals into multiple parallel LED signals and provides the input signals from general-purpose inputs. The SGPIO signals are SCLOCK on pin 14, SLOAD on pin 15, SDATAOUT on pin 18, and SDATAIN on pin 19.
3-6 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Figure 3.3 LSISAS3080X and LSISAS3080XL Board Layout
LSISAS3080X
Standard
PCI Bracket
LSISAS3080XL
Low-Profile
(LPPCI)
PCI Bracket
Two Light Pipes,
One Green and
One Bi-color
J1: PCI/PCI-X 64-bit, +3.3 V type board edge connector
J2 and J5: SFF-8484 SAS internal right-angle connectors with four
sideband lines
3.1.3.3 Physical Characteristics
The LSISAS3080X and LSISAS3080XL are 6.6 inches x 2.536 inches. PCI/PCI-X connection is made through the edge connector J1. The component height on the top and bottom of the LSISAS3080X and LSISAS3080XL boards follows the PCI/PCI-X specifications.
J2 J5
LSISAS1068
J1
Characteristics of the PCI-X to 3.0 Gbit/s SAS Host Adapters 3-7
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

3.1.4 LSISAS3800X Host Adapter Characteristics

The LSISAS3800X uses a standard PCI bracket as shown in Figure 3.4.
3.1.4.1 LEDs
The LSISAS3800X host adapter has eight LEDs that turn green to indicate an activity condition on any of the eight phys. There are eight LEDs that turn yellow to indicate a fault condition on any of the eight phys. See Figure 3.4 for LED locations.
The LSISAS3800X host adapter has two light pipes routed through the PCI bracket. One light pipe turns green to indicate activity on any phy. The other light pipe is bi-color. It flashes green to indicate the LSISAS1068 heartbeat, or it turns yellow when the LSISAS1068 firmware detects a fault condition.
3.1.4.2 Connectors
This section provides a description of the three different connectors on the LSISAS3800X host adapter. See Figure 3.4 for connector locations.
PCI/PCI-X Connector (J1) – The PCI/PCI-X interface operates as a 32-bit or 64-bit DMA bus master. The connection is made through the edge connector J1, which is a +3.3 V type board edge connector. The signal definitions and pin numbers conform to the PCI/PCI-X specifications.
SAS/SATA Connectors (J2 and J5) – The LSISAS3800X supports SAS connections through connectors J2 and J5. The J2 and J5 connectors are SFF-8470 SAS external right-angle connectors.
J8 – 4-pin, right angle, 0.1-inch pitch, pin header for driving external activity LED.
3-8 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Figure 3.4 LSISAS3800X Board Layout
LSISAS3800X
Standard
PCI Bracket
Two Light Pipes,
One Green and
One Bi-color
J5
J2
J8
Link Not
Present
LEDs
Activity
LEDs
J1
J1: PCI/PCI-X 64-bit, +3.3 V type board edge connector
J2 and J5: SFF-8470 SAS external right-angle connectors
J8: 4-pin, right angle, 0.1-inch pitch, pin header for driving external
activity LED
LSISAS1068
3.1.4.3 Physical Characteristics
The LSISAS3800X board is 6.6 inches x 3.8 inches. PCI/PCI-X connection is made through the edge connector J1. The component height on the top and bottom of the LSISAS3800X board follows the PCI/PCI-X specifications.
Characteristics of the PCI-X to 3.0 Gbit/s SAS Host Adapters 3-9
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

3.1.5 LSISAS3801X and LSISAS3801XL Host Adapters Characteristics

The LSISAS3801X and the LSISAS3801XL use a standard PCI bracket as shown in Figure 3.5.
3.1.5.1 LEDs
The LSISAS3801X and LSISAS3801XL host adapters have eight LEDs that turn green to indicate an activity condition on any of the eight phys. There are also eight LEDs that turn green to indicate a fault condition on any of the eight phys. See Figure 3.5 for LED locations.
The LSISAS3801X and LSISAS3801XL host adapter have two light pipes routed through the PCI bracket. One light pipe turns green to indicate activity on any phy. The other light pipe is bi-color. It flashes green to indicate the LSISAS1068 heartbeat, or it turns yellow when the LSISAS1068 firmware detects a fault condition.
3.1.5.2 Connectors
This section provides a description of the three different connectors on the LSISAS3801X and LSISAS3801XL host adapters. See Figure 3.5 for connector locations.
PCI/PCI-X Connector (J1) – The PCI/PCI-X interface operates as a 32-bit or 64-bit DMA bus master. The connection is made through the edge connector J1, which is a +3.3 V type board edge connector. The signal definitions and pin numbers conform to the PCI/PCI-X specifications.
SAS/SATA Connectors (J2 and J3) – The LSISAS3801X and LSISAS3801XL support SAS connections through connectors J2 and J3. The J2 and J3 connectors are SFF-8088 mini-SAS external right-angle connectors.
J6 – 4-pin, right angle, 0.1-inch pitch, pin header for driving external activity LED.
3-10 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Figure 3.5 LSISAS3801X and LSISAS3801XL Board Layout
LSISAS3801XL
Low-Profile
(LPPCI)
PCI Bracket
SFF-8088
Mini-SAS
Connectors
Link Not Present
Activity
J3
LSISAS1068
J2
J1
J1: PCI/PCI-X 64-bit, +3.3 V type board edge connector
J2 and J3: SFF-8088 mini-SAS external right-angle connectors
J6: 4-pin, right angle, 0.1-inch pitch, pin header for driving external
activity LED
J6
3.1.5.3 Physical Characteristics
The LSISAS3801X and LSISAS3801XL boards are 6.6 inches x 2.536 inches. PCI/PCI-X connection is made through the edge connector J1. The component height on the top and bottom of the LSISAS3801X and LSISAS3801XL board follow the PCI/PCI-X specifications.
Characteristics of the PCI-X to 3.0 Gbit/s SAS Host Adapters 3-11
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

3.2 Electrical and Environmental Specifications

The design and implementation of the PCI-X to 3.0 Gbit/s SAS host adapters minimize electromagnetic emissions, susceptibility to radio frequency energy, and the effects of electrostatic discharge. The board carries the CE mark, C-Tick mark, Canadian Compliance Statement, Korean MIC, Taiwan BSMI, Japan VCCI, FCC Class B and is marked with the FCC Self-Certification logo. The board also meets the requirements of CISPR Class B.

3.2.1 Electrical Characteristics

Ta bl e 3 .1 lists the maximum power requirements for the PCI-X to 3.0
Gbit/s SAS host adapters under normal operation.
Table 3.1 Maximum Power Requirements
Host Adapters
LSISAS3041X, LSISAS3041XL
LSISAS3442X, LSISAS3442XL
LSISAS3080X, LSISAS3080XL
LSISAS3800X LSISAS3801X LSISAS3801XL
PCI/PCI-X
+5.0 V
0.81 A 7.5 W 0 °C to 60 °C
0.97 A 7.5 W 0 °C to 60 °C
0.97 A 7.5 W 0 °C to 60 °C
0.97 A 7.5 W 0 °C to 60 °C
PCI/PCI-X
+3.30 V Power Operating Range
The PCI/PCI-X PRSNT1# and PRSNT2# pins are set to indicate 7.5 W maximum configuration at board build time.

3.2.2 Thermal and Atmospheric Characteristics

The atmospheric characteristics for the PCI-X to 3.0 Gbit/s SAS host adapters are:
Temperature range: 0 °C to 60 °C (dry bulb)
Relative humidity range: 5% to 90% non-condensing
Maximum dew point temperature: 32 °C
3-12 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
The following parameters define the storage and transit environment for the PCI-X to 3.0 Gbit/s SAS host adapters:
Temperature range: -40 °C to +105 °C (dry bulb)
Relative humidity range: 5% to 90% non-condensing

3.2.3 Safety Characteristics

All PCI-X to 3.0 Gbit/s SAS host adapters meet or exceed the requirements of UL flammability rating 94V-0. Each bare board is marked with the supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in a PCI or PCI-X bus slot, all voltages are below the SELV 42.4 V limit.
Electrical and Environmental Specifications 3-13
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
3-14 Host Adapter Characteristics
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.

Customer Feedback

We would appreciate your feedback on this document. Please copy the following page, add your comments, and fax it to us at the number shown.
If appropriate, please also fax copies of any marked-up pages from this document.
Important:
Thank you for your help in improving the quality of our documents.
Please include your name, phone number, fax number, and company address so that we may contact you directly for clarification or additional information.
PCI-X to 3.0 Gbit/s SAS Host Adapters User’s Guide
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Reader’s Comments
Fax your comments to: LSI Logic Corporation
Technical Publications M/S E-198 Fax: 408.433.4333
Please tell us how you rate this document: PCI-X to 3.0 Gbit/s SAS Host Adapters User’s Guide. Place a check mark in the appropriate blank for each category.
Excellent Good Average Fair Poor
Completeness of information ____ ____ ____ ____ ____ Clarity of information ____ ____ ____ ____ ____ Ease of finding information ____ ____ ____ ____ ____ Technical content ____ ____ ____ ____ ____ Usefulness of examples and
illustrations
Overall manual ____ ____ ____ ____ ____
____ ____ ____ ____ ____
What could we do to improve this document?
If you found errors in this document, please specify the error and page number. If appropriate, please fax a marked-up copy of the page(s).
Please complete the information below so that we may contact you directly for clarification or additional information.
Name Date
Telephone
Fax
Title
Department Mail Stop
Company Name
Street City, State, Zip
Customer Feedback
Version 2.1 Copyright © 2005, 2006 by LSI Logic Corporation. All rights reserved.
Loading...
