Avago Technologies eXtremeRAID 2000 User Manual
eXtremeRAID 2000
Installation Guide
DB11-000028-00 First Edition
08P5517
Electromagnetic Compatibility Notices
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Shielded cables for SCSI connection external to the cabinet are used in the
compliance testing of this Product. LSI Logic is not responsible for any radio
or television interference caused by unauthorized modification of this
equipment or the substitution or attachment of connecting cables and
equipment other than those specified by LSI Logic. The correction of
interferences caused by such unauthorized modification, substitution, or
attachment will be the responsibility of the user.
The LSI Logic Mylex eXtremeRAID 2000 is tested to comply with FCC
standards for home or office use.
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.
This is a Class B product based on the standard of the Voluntary Control
Council for Interference from Information Technology Equipment (VCCI).
If this is used near a radio or television receiv er in a domestic en vironment, it
may cause radio interference. Install and use the equipment according to the
instruction manual.
LSI Logic Corporation
North American Headquarters
Milpitas, CA
408.433.8000
Declaration of Conformity
Per FCC Part 2, Section 2.1077(a)
Manufacturer’s Name: LSI Logic Corporation
Manufacturer’s Address:
Declares that the product:
Product Name: High Performance RAID Controller
Model Number(s): eXtremeRAID 2000
Year of Manufacture: 2000
Conforms to the following Product Specification(s):
FCC: CFR 47 Part 15, Subpart B, Section 15.107(e)
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
North American Headquarters
Milpitas, CA
USA
and Section 15.109(g) Class B Digital Device
tested per ANSI C63.4–1992 procedures
Declaration of Conformity
Per 89\336\EEC
Responsible Party
Name:
Address:
Trade Name: High Performance Caching RAID Controller
Model Number(s):eXtremeRAID 2000 Fab. 550154-00 Rev. A
Standards: EN 50081-1:1992, Emissions
LSI Logic Corporation
North American Headquarters
Milpitas, CA
U.S.A.
hereby declares that the product
conforms to the following specifications
EN 55022 Class B (Radiated), Class B (Conducted)
EN 50082-1:1992, Immunity
EN 61000-4-2:1995 Electrostatic Discharge
EN 61000-4-3:1996 Radiated Susceptibility
EN 61000-4-4:1995 Electrical Fast Transients/Burst
Community of Europe
CE mark is rated for the eXtremeRAID 2000 as follows:
CISPR 22 Radiated Emission
EN55022, Generic immunity standard for the following:
IEC 801-2 ESD, IEC 801-3 Radiated, and IEC 801-4 EFT/Burst
Warning!
This is a Class B product. In a residential environment this product may
cause radio interference, in which case the user may be required to take
adequate measures.
Achtung!
Dieses ist ein Gerät der Funkstörgrenzwertklasse B. In Wohnbereichen
können bei Betrieb dieses Gerätes Rundfunkstörungen aufreten, in welchen
Fällen der Benutzer für entsprechende Gegenmaßnahmen verantwortlich ist.
Avertissement!
Cet appareil est un appareil de Classe B. Dans un environnement résidentiel
cet appareil peut provoquer des brouillages radioélectriques. Dans ce cas, il
peut être demandé à l’utilisateur de prendre des mésures appropriées.
Underwriters Laboratories Statement and Warning
WARNING! This controller is furnished with a
nonvolatile RAM (NVRAM) chip that uses a sealed
lithium battery/crystal module. Replace the module
only with the same or equivalent type
recommended by the manufacturer. Dispose of the
used battery/crystal module according to the
manufacturer's instructions. Never incinerate a
battery as it could explode and cause serious
injury.
Proprietary Rights Notice
This document contains proprietary information of LSI Logic
Corporation. The information contained herein is not to be used by
or disclosed to third parties without the express written permission
of an officer of LSI Logic Corporation. Any product(s) described
herein is/are a licensed product of LSI Logic Corporation.
Document Description
Document DB11-000028-00 First Edition. November 2002
This document describes the LSI Logic Corporation’s Mylex
eXtremeRAID 2000 product for Software Kit 5.20 and will remain
the official reference source for all revisions/releases of this product
until rescinded by an update.
Disclaimer
It is the policy of LSI Logic to improve products as new technology ,
components, software, and firmware become available. LSI Logic
Corporation reserves the right to make changes to any products
herein at any time without notice. All features, functions, and
operations described herein may not be marketed by LSI Logic in
all parts of the world. In some instances, photographs and figures
are of equipment prototypes. Therefore, before using this
document, consult your LSI Logic representative for information
that is applicable and current. LSI LOGIC DOES NOT ASSUME
ANY RESPONSIBILITY OR LIABILITY FOR THE USE OF
ANY PRODUCT(S) DESCRIBED HEREIN EXCEPT AS
EXPRESSLY AGREED TO IN WRITING BY LSI LOGIC.
License Restriction
The purchase or use of an LSI Logic product does not convey a
license under any patent, copyright, trademark, or other intellectual
property right of LSI Logic or third parties.
Copyright Notice
Copyright © 2001, 2002. LSI Logic Corporation. All rights
reserved.
Trademark Acknowledgments
LSI Logic, the LSI Logic logo, MORE, Mylex, and SANmapping
are trademarks or registered trademarks of LSI Logic Corporation.
All other brand and product names may be trademarks of their
respective companies.
About This Manual
This installation guide covers hardware setup and configuration procedures
necessary for the installation of a Mylex eXtremeRAID™ 2000 PCI to Ultra
160 SCSI RAID Controller.
Chapter 1 describes the controller, standard package contents, and usersupplied items necessary for installation.
Chapter 2 describes the steps to be performed prior to controller installation
and the physical installation of the eXtremeRAID 2000 four channel RAID
controller.
Chapter 3 describes controller startup and the BIOS options.
Appendix A describes the memory and battery backup module.
Appendix B provides hardware and environmental specifications.
Appendix C describes error messages and problem correction.
Appendix D describes the PCI Hot Plug feature.
Appendix E provides enclosure management information.
Conventions
Throughout this manual, the following conventions are used to describe user
interaction with the product:
prompt This style of type indicates screen display messages
Enter Press the key labeled “Enter” (or “Delete”, etc.)
☛Note
Supplementary information that can have an effect on
system performance
Caution
Notification that a proscribed action has the potential
to adversely affect equipment operation, system
performance, or data integrity
WARNING
Notification that a proscribed action will definitely
result in equipment damage, data loss, or personal
injury
