WARNING:
1. This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including
interference that may cause undesired operation.
2. The Manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the User’s authority to operate the
equipment.
USER GUIDE
PREPARATIONS
• CHARGE THE HANDSFREE
Plug the car adapter into the DC
supply & connect the car adapter into DC jack of both Earset and
Phoneset. Earset and Phoneset LED will flash once a second during
charging. LED will flash twice a second upon charging completion.
• CONNECT HANDSFREE TO PHONE
Plug the 2.5mm audio
plug of the Phoneset into audio jack of the phone. Different audio jack
adapter may be required for different phone models. Check with your
suppliers for adapter availability for your phone model.
MODE OF OPERATION
There are three operation modes for handsfree:
• OFF MODE is a power down off mode. LED STATUS: Off.
• STANDBY MODE
is the operating mode readies for user to pick/drop
a call. LED STATUS: Flashes.
• TALK MODE means a link is established for user to talk over the
handsfree system. LED STATUS: On.
TURN ON/OFF THE HANDSFREE
• TURN ON – Press the key over 6 second until LED flashes rapidly for
3 sec. Stop pressing when flash stops and LED will continue to flash
once every second.
• TURN OFF
- Press the key over 6 second until LED flashes rapidly for
3 sec. Stop pressing when flash stops and the LED will stop flashing
completely..
_________________________________________________________________________________
5
PICK & DROP A CALL
• Make sure that Phoneset and Earset is in turned on & within 20m
distance.
• TO PICK-UP A CALL
press the Earset button once – line will be
connected within at an average time of 1.5-sec (3 sec max). If
connection fails, user will hear two beeps tone and need to reconnect the
link again.
• TO DROP A CALL, just press the earset button once further.
OUT OF RANGE REMINDER
• Earset generates a warning tone (1 beep per second for 15-sec) when
distance between Earset & Phoneset exceed communication distance,
approximately 20m.
BATTERY-LOW REMINDER
Earset will remind user of low battery by:
• 4 beep & 4 LED flash every 5 seconds if Earset battery is low
• 2 beep & 2 LED flash every 5 seconds if Phoneset battery is low
• The Handsfree will terminate the communication link after 1-minute
warning. No new calls will be allowed in low battery status before battery
recharge.
RESET
Users can reset the earset or Phoneset by plugging the provided car cigarette
charger into its DC socket if the unit does not work properly.
ID CODE MATCHING
_________________________________________________________________________________
6
All pair is factory programmed and user IS NOT REQUIRED TO DO
ANY ID CODE MATCHING. Users are suggested to use this mechanism
only that Earset & Phoneset are from the different package.
To program a Phoneset to work with another Earset, user shall:
• Put the pair close to each other and press the button on both units
continuously for 3 seconds. LEDs will be continuously fast flashing.
• If the code matches successfully, LEDs will flash 4 times slowly and
Earset will generate 4-beep tone.
• If the code matches fails, the Earset will generate 2 beep-tone.
PRECAUTIONS
• Use ONLY provided car cigarette charger to charge the Handsfree.
• DO NOT CHARGE both Units outside the temperature range of 0 to
+45 degree Celsius.
• DO NOT USE the both Units outside the temperature range of –5 to
+50 degree Celsius.
• DO NOT STORE the Units outside the allowable temperature range of
–10 to +60 degree Celsius.
• DO NOT TEMPER OR REMOVE THE LITHIUM ION
BATTERIES
• SHALL DISPOSE WITH EXTREME CARE. DISPOSE IN FIRE
MAY HIGH POTENTIAL RISK OF EXPLOSION.
_________________________________________________________________________________
7
