Autoleads ControlPRO CP2-UNI User Manual

User Manual

CP2-UNI

Steering Wheel Control Interface

email - [e-mail]

www.autoleads.co.uk

email - [e-mail]

Introduction

Key Features

Interface & Wiring Overview

The Autoleads ControlPro CP2-UNI is a universal
interface that allows retention of steering wheel
controls, and retained accessory power whenever
replacing a factory radio. Use of this interface also
allows you to program two radio functions to each
steering wheel control button by using short
press/long press dual command functionality.
The CP2 is compatible with vehicles that use data
or analog steering wheel controls.

u Compatible in vehicles equipped with LAN, LIN,

CAN, Class II, Analog or Serial Data Steering
wheel controls

u Easily congurable using either a PC or manually
u Retains memory even if power is lost
u Ability to assign two radio functions to one

steering wheel button

u Updatable via the Autoleads PC Application.
u Create and save custom vehicle conguration les

for later use.

u Highly visible tri-colour LED to keep the user

informed of the modules status.

u Equipped with a manual learning function for

compatibility with unlisted vehicles equipped with
analog steering wheel controls

Please visit www.autoleads.co.uk/controlpro to
download the PC application or phone app that
provides vehicle specic wiring and vehicle
dipswitch congurations

email - [e-mail]

www.autoleads.co.uk

Installation

Interface & Wiring Overview (continued)

Please visit www.autoleads.co.uk/controlpro
to download the PC application or phone app that
provides vehicle specic wiring and vehicle dipswitch
congurations

Conguration & Programming

This is the fastest and most convenient way to
program the module. This method only requires you to
look up the dipswitches and wiring via the PC, Android
or Apple application, set the dipswitches and then
connect it to the vehicle/radio for it to function. Both

vehicle and radio dipswitch settings must be set
before the module is connected to the vehicle.

(-) Chassis Ground

(+) Constant 12v Input

White/Red

Pink

White/Black

Red

Red/White

Black

(-) Analog SWC Ground

Black

Yellow

(-) Analog SWC Input 3

Data 1 Input

(LAN, MSCAN, SWCAN, LEFT)

(-) Analog SWC Input 2

(+) Accessory 12v Input

(+) Accessory 12v Output

Blue/Yellow

SWC Output - Kenwood/Newer JVC

Purple

White

Light Green

Data 2 Input

(LIN, IBUS, CLASSII, SERIAL)

(-) Analog SWC Input 1

(+) 12v Analog SWC Input

3.5mm Jack

SWC Output - Alpine, JVC, Clarion,
Pioneer, Sony, Boyo, Dual, Advent,

Lightning Audio or Visteon

Programming

Button

Status LED

Vehicle

Dipswitches

Radio

Dipswitches USB Port

Pink/Black

Data 2 Input

(CAN-low)

email - [e-mail]

www.autoleads.co.uk

email - [e-mail]

Manual Conguration Mode (continued)

With this method, the Autoleads CP2 uses a
pre-determined dipswitch conguration to assign the
vehicle and steering control button functionality. The

dipswitches on the side of the interface must be
manually set to the proper vehicle conguration by
the user. These vehicle specic dipswitch settings can

be found by downloading the Autoleads ControlPro
application from www.autoleads.co.uk/controlpro

If you wish to re-assign button functions or use short
press/long press dual command functionality, please
follow the PC application or manual re-assignment
procedure.

1. Please Visit www.autoleads.co.uk/controlpro to
download the Autoleads ControlPro application
Launch the application and nd your vehicle/radio
combination.

2. Set the vehicle dipswitches according to the
application.

3. Set the radio dipswitches according to the radio
dipswitch chart below.

4. Connect the interface according to the installation
instructions.

With this method, the CP2 can be connected to a PC
in which the application assigns the vehicle and
steering wheel button functionality. To congure using

a PC, the dipswitches on the side of the interface
must all be set to the down/on position which is
the default position. When using this method, it is not

required to manually program the steering wheel
buttons when programming via App mode.

1. Visit www.autoleads.co.uk/controlpro to
download the Autoleads ControlPro PC application.

2. Connect the CP2 to the PC. When using a PC to

congure, it is not required to power the CP2
module via the 11 pin connector.

PC Application Mode

email - [e-mail]

www.autoleads.co.uk

PC Application Mode

3. PLEASE NOTE: It may be necessary to update
your Microsoft .NET Framework. If you require this
update your PC will automatically notify you. If you
do not get a notication, then you do not require
the update.

4. Launch the application or software and follow the
on screen prompts

Manual Programming Mode

With this method the steering wheel button values
must be manually programmed into the CP2 by using
either the PC application or the programming button
located on the module. The vehicle dipswitches on

the side of the interface must all be set to the up
(off) position.

PLEASE NOTE: This mode is only compatible in
vehicles with both analog steering controls and a
12v Accessory wire. Vehicles with CAN-Bus buttons
cannot be manually programmed.

The radio dipswitches must be set to the correct
radio conguration.

1. Visit www.autoleads.co.uk/XXXXXX to download
the Autoleads ControlPro PC application.

2. Launch the application and nd the installation
instructions for your vehicle

3. Set the radio dipswitches according to the chart
on the next page

4. Connect the interface according to the installation
instructions.

5. You can now either connect the CP2 to your PC
and use the application to program the steering
control values or follow the programming
instructions on the next page

email - [e-mail]

www.autoleads.co.uk

email - [e-mail]

Radio Dipswitch Settings

Manually Mapping the Steering
Wheel Buttons

PLEASE NOTE: This section only applies to button
programming in manual programming mode.

If you are using the CP2 in manual conguration
mode (specic vehicle dipswitch settings) and wish
to re-assign button functions, please follow the

“Steering Wheel Button Re-Assignment” section
Please read each of the following steps to familiarise
yourself with the process before beginning.

Radio Dipswitch Settings

Alpine Clarion/Nakamichi

Fusion JVC

Kenwood Other

Pioneer Sony

email - [e-mail]

www.autoleads.co.uk

The interface must be programmed in the specic
order shown in the diagram on page 8.

1. Turn the key to the ignition position. The LED
on the CP2 module will illuminate red.

2. Press and hold the programming button on the
side of the CP2 interface until the LED illuminates
green Release the programming button.

3. Within 7 seconds, press the button that is to be
learned on the steering wheel.

At this point you have two options:

a. For short press functionality: Hold the button on

the steering wheel until the LED changes from green to
red. Release the button.

b. For long press functionality: Continue to hold the

button until the LED ashes between red and amber
once. Release the button.

4. If you need to program more buttons, repeat step
3 for each additional audio function on the steering
wheel.

5. If you come across a function in the chart that your
steering wheel does not have, or you do not want
to program, press and release the program button
on the side of the CP2 interface to skip that
function. The LED will turn off then back on when
the skip has been done successfully.

6. Once programming is completed, wait seven
seconds. The LED will ash green 3 times
indicating the end of programming.

7. Test the interface for proper functionality.
Whenever a SWC button is pressed the LED on
the interface should blink green. If any function
does not work, repeat the programming steps

Manually Mapping the Steering
Wheel Buttons (continued)

email - [e-mail]

www.autoleads.co.uk

email - [e-mail]

Radio

Alpine JVC Kenwood Clarion / Nakamichi Other* Sony Pioneer Fusion

1 Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume +

2 Volume - Volume - Volume - Volume - Volume - Volume - Volume - Volume -

3 Mute Mute Mute Mute Mute Mute Mute Mute

4 Preset + Source Source Source Preset + Preset + Preset + Source

5 Preset - Track + Play Search + Preset - Preset - Preset - Track +

6 Source Track - Track + Search - Source Source Source Track -

7 Track + Band/Disc + Track - Band Track + Track + Track + Audio

8 Track - Preset/Disc - Disc/FM + Send/End Track - Track - Track - Power

9 Power Select Disc/AM - Send Band Band Band

10 Enter/Play Attenuation Answer End

Reject Call/Source

(Bluetooth equipped

radios only)

Phone Menu

11 Band/Program Phone Receive Voice Dial Answer/End Call Answer Call

12 Receive Phone Reject On Hook End Call

13 End Voice Dial Off Hook Voice Activation

14 Power

Mute (Multimedia

units only)

*Other = Advent, Boyo, Dual, Lightning Audio, Rockford Fosgate, & Visteon

Radio Function Mapping Order

email - [e-mail]

www.autoleads.co.uk

SWC Button Re-Assignment Procedure

PLEASE NOTE: This section only applies to button
re-assignment within a conguration. If you are using
the CP2 in manual programming mode (all vehicle
dipswitches up) please refer to the “Manually Mapping
the Steering Wheel Buttons” section.

If you wish to re-assign the Steering wheel control
functions or utilise short press long press dual com­mand functionality you will need to follow the steps
outlined in this section.

Please read each of the following steps to familiarise
yourself with the process before beginning. The inter­face must be programmed in the specic order shown
in the chart below.

1. Turn the key to the ignition position. The LED will
illuminate red.

2. Press and hold the programming button on the
side of the interface until the LED illuminates green
Release the programming button.

3. Within 7 seconds, press the button that is to be
learned on the steering wheel. At this point you
have two options:

a. For short press functionality:

Hold the button on the steering wheel until the LED
changes from green to red.
Release the button.

b. For long press functionality:

Continue to hold the button until the LED ashes
be-tween red and amber once. Release the button.

4. If you need to program more buttons, repeat step
3 for each additional audio function on the steering
wheel.

5. If you come across a function in the chart that
your steering wheel does not have, or you do not want
to program, press and release the program button on
the side of the interface to skip that function. The LED

email - [e-mail]

www.autoleads.co.uk

Autoleads is a Power brand of AAMP Global.
