ONE KEY SHORTCUTS [SEE PRINTABLE KEYBOARD STICKERS ON PAGE 14]
CANCEL
Esc
~
`
Tab
Caps Lock Enter
Shift Shift
HELP
PAN
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
! @ # $ % ^ & * ( ) —
1
2 3 4 5 6 7 8 9 0
Q
W E R T Y U I O P
A
Z X C V B N M
ZOOM SELECTED
ROTATE
PREVIOUS VIEW
HOME VIEW
SLICE GRAPHICS
SHOW ALL
CONSTRAINTS
HIDE ALL
S D F G H J K L
<
, .
CONSTRAINTS
SKETCH VISIBILITY
-
GROUNDED
WORK POINT
;
WORK POINT WORK AXIS
/
EQUAL
=
{
[ ]
“
‘
Backspace
WORK
PLANE
Ctrl Start Alt Alt Ctrl
= EQUAL / Constrains curves to equal
radius or length.
; GROUNDED WORK POINT / Creates a
grounded work point and activates the
3D Move/Rotate tool.
DELETE
DELETE / Removes the selected item
from the model or drawing.
END ZOOM SELECTED / Zooms in on a
specically selected item.
|
\
PrtScn
SysRq
ScrLK
Home End
Insert
Delete
DELETE
Pause
Break
ZOOM
SELECTED
Page
Up
LOOK AT
Page
Down
/ WORK AXIS / Creates a new work axis.
] WORK PLANE / Creates a new work
plane.
. WORK POINT / Creates a new work
point.
ESC CANCEL / Closes the active tool.
HOME ZOOM ALL / Zooms to the extents of all
objects in the graphics window.
PAGE UP
LOOK AT / Looks at a selected entity.
3
KEYBOARD SHORTCUT COMMANDS
Assembly
ALT-DRAG MOUSE
MATE CONSTRAINT / Applies a mate
constraint.
CTRL-H
REPLACE COMPONENT / Replaces
one assembly component with another
component.
SHIFT-TAB
PROMOTE / Removes a part from a
subassembly and makes it an individual
part in the parent assembly.
Drawing Manager
CTRL-SHIFT-N
NEW SHEET / Inserts a new drawing
sheet.
CTRL-SHIFT-T
LEADER TEXT / Adds notes with leader
lines to a drawing.
General
CTRL-A
SELECT ALL / Selects everything on the
screen.
CTRL-C
COPY / Copies selected items.
CTRL-F
FIND / Presents the Find Part Sketches
dialog box in part les; opens the Find
Assembly Components dialog box in
assembly les.
CTRL-N
NEW / Displays the New File dialog box.
CTRL-O
OPEN / Displays the Open dialog box,
to open an existing le.
CTRL-P
PRINT / Displays the Print dialog box.
CTRL-S
SAVE / Displays the Save As dialog box.
CTRL-V
PASTE / Pastes a cut or copied item from
one location to another.
CTRL-X
CUT / Cuts selected items.
CTRL-Y
REDO / Redoes previously undone
commands.
CTRL-Z
UNDO / Undoes the effects of commands.
SHIFT-RIGHT MOUSE CLICK
SELECT / Activates the select command
menu.
Part
CTRL-SHIFT-K
CHAMFER / Activates the Chamfer tool.
CTRL-SHIFT-L
LOFT / Activates the Loft tool.
CTRL-SHIFT-M
MIRROR / Activates the Mirror tool.
Placed Features
CTRL-SHIFT-O
CIRCULAR PATTERN / Opens the Circular
Pattern dialog box.
CTRL-SHIFT-R
RECTANGULAR PATTERN / Opens the
Rectangular Pattern dialog box.
CTRL-SHIFT-S
SWEEP / Activates the Sweep tool.
DELETE
DELETE / Removes the selected item from
the model or drawing.
QUIT EXIT / Quits the application; prompts to
save documents.
4
KEYBOARD SHORTCUT COMMANDS
Sketch
= EQUAL / Constrains curves to equal radius
or length.
F7 SLICE GRAPHICS / Slices away temporarily
the portion of the model that obscures the
plane.
F8 SHOW ALL CONSTRAINTS / Displays all
constraints.
F9 HIDE ALL CONSTRAINTS / Hides All
constraints.
Tools
ALT-F8
MACROS / Opens the Macros dialog box.
ALT-F11
VISUAL BASIC EDITOR / Launches the
Microsoft Visual Basic Editor.
ESC CANCEL / Closes the active tool.
F1 HELP / Opens the Inventor help les.
View
ALT-. USER WORK POINTS VISIBILITY / Makes
work points visible.
ALT-] USER WORK PLANE VISIBILITY / Makes
work planes visible.
ALT-/ USER WORK AXES VISIBILITY / Makes
work axes visible.
CTRL-. ORIGIN POINTS VISIBILITY / Makes the
default origin points visible.
CTRL-]
ORIGIN PLANE VISIBILITY / Makes the
default origin planes visible.
CTRL-/
ORIGIN AXES VISIBILITY / Makes the
default origin axes visible.
CTRL-0 TOGGLE SCREEN / Toggles screen.
CTRL-SHIFT-E
DEGREES OF FREEDOM / Displays
degrees of freedom.
CTRL-SHIFT-Q
IMATE GLYPH / Activates the iMate Glyph
tool.
CTRL-W
STEERING WHEELS / Displays the Steering
Wheel view tool.
END ZOOM SELECTED / Zooms in on a
specically selected item.
F5 PREVIOUS VIEW / Returns to the last
display.
F6 HOME VIEW / Rotates objects in the
graphics window into an isometric
orientation.
F10 SKETCH VISIBILITY / Makes sketches
visible.
HOME ZOOM ALL / Zooms to the extents of all
objects in the graphics window.
PAGE UP
LOOK AT / Looks at a selected entity.
SHIFT-F3
ZOOM WINDOW / Zooms to the area you
dene with a window.
SHIFT-F5
NEXT VIEW / Advances to the next view.
SHIFT-MIDDLE MOUSE CLICK
ROTATE / Rotates a model.
Work Features
; GROUNDED WORK POINT / Creates a
grounded work point and activates the 3D
Move/Rotate tool.
F2 PAN / Views areas of the graphics
window. (You must hold the [F2] key
down.)
F3 ZOOM SELECTED / Realtime zoom in and
out of the graphics window. (You must
hold the [F3] key down.)
F4 ROTATE / Rotates objects in the graphics
window.
/ WORK AXIS / Creates a new work axis.
] WORK PLANE / Creates a new work
plane.
. WORK POINT / Creates a new work
point.
5
MULTI-CHARACTER COMMAND ALIASES
Annotation
BA AUTO BALLOON / Creates one or more
item balloons used to identify components
in drawing views.
CAT CATERPILLAR / Adds a weld caterpillar
annotation.
CB CENTERLINE BISECTOR / Adds a
centerline bisector.
CL CENTERLINE / Adds a centerline.
CM CENTER MARK / Adds a center mark.
DI DATUM IDENTIFIER SYMBOL / Adds a
datum identier symbol.
EF END FILL / Adds a weld end ll annotation
in a drawing view or on a 3D weld bead
to represent the hatched or lled region
indicating the end of a weld bead.
F FEATURE CONTROL FRAME / Places a
feature control frame in drawing les.
FI FEATURE IDENTIFIER SYMBOL / Adds a
feature identier symbol.
HTF HOLE TABLE-FEATURES / Selects feature
set (all punch center instances from a
single feature).
HTS HOLE TABLE-SELECTION / Selects
recovered punch centers individually.
HTV HOLE TABLE-VIEW / Adds a hole table to
a view.
LE LEADER TEXT / Adds notes with leader
lines to a drawing.
PL PARTS LIST / Creates a parts list.
RT REVISION TAG / Adds revision tags to a
drawing.
RTB REVISION TABLE / Creates a revision
table.
ST SURFACE TEXTURE SYMBOL / Adds a
surface texture symbol.
SY SYMBOLS / Addssketched symbolsto a
drawing sheet.
T TEXT / Activates the text tool in a drawing
le.
TB TABLE / Creates a table.
WS WELDING SYMBOL / Provides annotation
and acts as a grouping mechanism by
referencing multiple beads with a single
welding symbol.
Assembly
C CONSTRAINTS / Adds an assembly
constraint.
CO COPY COMPONENTS / Creates acopyof
thecomponent.
G ROTATE COMPONENT / Activates the
Rotate tool.
IA ANALYZE INTERFERENCE / Analyzes
assemblies for interference.
MI MIRROR COMPONENTS / Creates a
mirror component.
N CREATE COMPONENT / Displays the
Create In-Place Component dialog box.
P PLACE COMPONENT / Places a
component in the current assembly.
PC PATTERN COMPONENT / Selects one
or more components to include in the
pattern.
RA REPLACE ALL / Replaces all occurrences
of the component in the current assembly.
V MOVE COMPONENT / Activates the
Move Component command.
Cable & Harness
AR AUTOMATIC ROUTE / Automatically
routes one or more selected wires into
segments based on the shortest path
through the network and the segment
opening that is closest to the wire start
and endpoints.
BR CHECK BEND RADIUS / Checks for bends
that do not meet the specied minimum
bend radius on segments, and routed and
unrouted wires and cables in the active
harness assembly.
BS BROKEN SKETCH ENTITY / Sets the
start point and endpoint for the length to
remove from the cable, wire, or segment.
CA CONNECTOR AUTHORING / Adds Cable
and Harness-specic data to complete the
denition of connectors for use in Cable
and Harness.
CC CREATE CABLE / Creates a cable
containing multiple wires that are
connected or terminated to selected pins
within a harness assembly.
6
MULTI-CHARACTER COMMAND ALIASES
Cable & Harness
CF CREATE FOLD / Creates fold.
CR CREATE RIBBON CABLE / Creates a
ribbon cable between a start and end
connector.
CS CREATE SEGMENT / Creates a harness
segment.
CV PLACE CONNECTOR VIEWS / Places
connector views.
CW CREATE WIRE / Creates a wire between
selected pins within a harness assembly.
E EDIT / Edits nailboard sketch.
EH EXPORT HARNESS DATA / Exports
harness data .
F FAN IN / Collapses wire stubs on top of
one another to reduce the detail or clutter
in nailboard documentation.
FO FAN OUT / Equally distributes wire stubs
about the endpoint of a segment using
the specied angle and sorting direction.
HA CREATE HARNESS / Adds the harness
subassembly to an assembly le with the
specied name and location, and displays
the Cable and Harness tab.
HD HARNESS DIMENSION / Adds a driven,
aligned dimension between 2 points.
HP HARNESS PROPERTIES / Custom
properties of harness components.
L CABLE & HARNESS LIBRARY / Adds new
library denitions, and modies, copies,
and deletes existing library denitions for
harness objects such as wires, cables, raw
ribbon cables, and virtual parts.
NB NAILBOARD / Species the harness
assembly and setup to create or edit a
nailboard view.
P PIVOT / Fixes segment points so you can
drag the selected segment relative to that
xed point.*
P PLACE PIN / Places a pin.*
PD PROPERTY DISPLAY / Displays properties
for the selected objects.
PG PLACE PIN GROUP / Automatically places
multiple pins with the specied naming,
conguration, and orientation on a part.
RG REPORT / Process reports for the active
harness assembly.
RH REVIEW HARNESS DATA / Reviews
harness data.
RT ROUTE / Routes cables and wires
manually.
RW RECONNECT WIRE PINS / Reconnects
wire pins.
SP CREATE SPLICE / Creates a splice.
TB TABLE / Creates a table.
Dimension
BD BASELINE DIMENSION / Adds baseline
dimensions.
BN BEND NOTES / Creates or edits a bend
note.
CN CHAMFER NOTE / Adds a chamfer note
to a drawing view.
D GENERAL DIMENSION / Adds a
dimension to a sketch or drawing.
HN HOLE/THREAD NOTES / Adds a hole or
thread note with a leader line.
O ORDINATE DIMENSION SET / Activates
the Ordinate Dimension Set command.
OD ORDINATE DIMENSION / Adds an
ordinate dimension.
PN PUNCH NOTES / Creates a punch note.
IH IMPORT HARNESS DATA / Imports
harness data.
*NOTE: The same alias can perform different commands depending on the design environment and object you are working on.
U UNROUTE / Unroutes selected wires from
selected segments.
V ASSIGN VIRTUAL PARTS / Assigns virtual
parts.
7
MULTI-CHARACTER COMMAND ALIASES
Drawing Manager
AV AUXILIARY VIEW / Places an auxiliary
view by projecting from an edge or line in
a parent view.
B BALLOON, BOM / Activates the Balloon
tool or displays the BOM Properties dialog
box, depending on the work environment.
BV BASE VIEW / Creates a base view.
BRV BREAK / Creates a broken, foreshortened
view.
BO BREAK OUT / Removes a dened area
of material to expose obscured parts or
features in an existing drawing view.
CR CROP / Use to set boundary type
and visibility of crop cut lines for crop
operations.
DV DETAIL VIEW / Provides circular and
rectangular shapes of detail prole.
PV PROJECTED VIEW / Creates a projected
view.
RD RETRIEVE DIMENSIONS / Retrieves model
dimensions in a drawing.
SV SECTION VIEW / Creates a section view.
Dynamic Simulation
AVI PUBLISH MOVIE / Creates AVI animation.
CC CONVERT ASSEMBLY CONSTRAINTS /
Converts assembly constraints.
CSA PUBLISH TO STUDIO / Creates studio
animation.
DM DYNAMIC MOTION / Dynamic part
motion.
F FORCE / Applies force on the selected
objects.
FEA EXPORT TO FEA / Exports to FEA.
J INSERT JOINT / Inserts joint.
MS MECHANISM STATUS AND
REDUNDANCIES / Provides model status
information and guides you through the
process of repairingredundant constraints.
OG OUTPUT GRAPHER / Displays graphs
and numerical values of all the input and
output variables in asimulationduring and
after the simulation completes.
RF REFERENCE FRAME / Creates a Reference
Frame from the input provided.
SET DYNAMIC SIMULATION SETTINGS / Sets
options that apply to the entire Dynamic
Simulation session.
TO TORQUE / Applies torque on the selected
objects.
TR TRACE / Creates the absolute or relative
kinematic values (trajectory, velocity, and
acceleration) of one or more points placed
anywhere on a component.
Frame Analysis
A ANIMATE RESULTS / Animates the
selected simulation results.
AM AXIAL MOMENT / Adds an axial moment.
B PROBE / Displays the simulation results for
a specic point on the model.
BC BOUNDARY CONDITIONS / Toggles
display of all boundary conditions.
BD BEAM DETAIL / Displays detailed results
(diagrams, tables) for the selected beams
of a structure.
BM BENDING MOMENT / Applies the
bending moment to the selected beam.
C CREATE SIMULATION / Creates a
simulation.
CB COLOR BAR / Edits color bar.
CL CONTINUOUS LOAD / Applies and
distributes uniform load along the beam
you select.
D DIAGRAM / Adds custom user diagram.
EX EXPORT / Exports to robot structural
analysis.
F FORCE / Applies a force of the specied
magnitude to the selected faces, edges, or
vertices.
FL FLOATING PINNED CONSTRAINT / Adds
oating pinned constraint.
LB BEAM LABELS / Toggles display of beam
labels.
UF UNKNOWN FORCE / Calculates the
required force, torque, or jack to keep a
mechanism in static equilibrium for a given
position
8
MULTI-CHARACTER COMMAND ALIASES
Frame Analysis
LN NODE LABELS / Toggles display of node
labels.
LP PROBE LABELS / Toggles visibility of probe
labels.
LS LOCAL SYSTEMS / Toggles display of
beam local systems.
LV LOAD VALUES / Toggles display of load
values.
MA BEAM MATERIALS / Enables you to
change the material of the beam.
MO MOMENT / Applies the general moment
to the selected beam.
N NO SHADING / Turns off the Shaded
Results display.
P BEAM PROPERTIES / Provides physical
and engineering properties of a frame
member, and enables you to customize
the data.
PN PINNED CONSTRAINT / Applies pinned
constraint when no displacement and free
rotation is allowed on beam or node.
R REPORT / Generates a report.
RE RELEASE / Assigns a release of specied
degrees of freedom to a selected beam in
a structure.
RL RIGID LINK / Enables you to dene a rigid
link between selected nodes in a frame
structure.
Mold Design
2D 2D DRAWING / Creates one or more
drawing documents.
AM ANIMATE RESULTS / Animates the
selected simulation results.
AO ADJUST ORIENTATION / Prompts the
Adjust Orientation dialog box.
AP ADJUST POSITION / Prompts the Adjust
Position dialog box.
AR AUTO RUNNER SKETCH / Creates an
auto runner sketch.
AU MOLD BASE AUTHOR / Assigns
component attributes before inserting
a user dened mold base.
BC BRIDGE CURVE / Connects curves by G2
continuity.
BL MOLD BOOLEAN / Integrates the
interference checking function and the
Boolean calculation.
BR BOUNDED RUNOFF SURFACE / Creates a
runoff surface.
CC COOLING CHANNEL CHECK / Checks
cooling channels for safety, interference,
and distance between cooling system
segments.*
CC PLACE CORE AND CAVITY / Places or
deletes imported core and cavity.*
CD CORE/CAVITY / Core/Cavity design and
analysis environment.
CH CREATE HEEL / Creates one or more heels
on an insert.*
CI CREATE INSERT / Creates an insert.
CM COMBINE CORES AND CAVITIES /
Creates, edits, or deletes a combined core
or cavity.
CP PLACE CORE PIN / Places a core pin into a
mold.
CS COOLING COMPONENT / Species the
components that conduct the coolant
through the cooling channels.
CW COLD WELL / Denes the cold wells that
are at the end of the sprue or on a runner.
DW DEFINE WORKPIECE SETTING / Enables
you to generate a rectangular or cylindrical
workpiece, which is the precondition for
generating the core and cavity.
EJ EJECTOR / Creates an ejector pin to eject
a plastic part.
EM EDIT MOLDABLE PART / Edits a moldable
part.
ES USE EXISTING SURFACE / Creates, edits,
or deletes the existing patching or runoff
surface.
S SIMULATE / Runs a simulation.
X FIXED CONSTRAINT / Applies a xed
constraint on selected faces, edges, or
vertices.
*NOTE: The same alias can perform different commands depending on the design environment and object you are working on.
CH COOLING CHANNEL / Creates a cooling
channel.*
9
MULTI-CHARACTER COMMAND ALIASES
Mold Design
ET EXTEND RUNOFF SURFACE / Extends
runoff surface.
F FINISH CORE/CAVITY / Activates core and
cavity environment.
GC GENERATE CORE AND CAVITY / Creates
the required les for the core and cavity.
GP GATE LOCATION / Sets gate locations.
GT GATE / Adds a gate.
JM JOB MANAGER / Monitors the progress
of analyses and, if necessary, stops an
analysis.
LA LIFTER / Places a lifter assembly into the
mold so the mold can open and close
smoothly.
LR LOCATING RING / Creates a locating ring.
MB MOLD BASE / Provides the tools to create
a mold base.
MF MOLD FILL ANALYSIS / Predicts the
thermoplastic polymer ow inside the
mold during the lling phase.
MP PART PROCESS SETTINGS / Determines
the optimum mold temperature, melt
temperature, and injection time based on
the selected material and part geometry.
MS MANUAL SKETCH / Activates the sketch
environment of a part where you can draw
an insert sketch.
NM CREATE MOLD DESIGN / Creates mold
design.
PH CREATE PLANAR PITCH / Creates planar
pitch.
PI PLACE INSERT / Places a previously
generated insert in the mold assembly.
PP PLASTIC PART/ Places one or more parts
into a Mold Design project.
PR SET PLOT PROPERTY / Sets plot property.
PS CREATE PATCHING SURFACE / Creates
patching surface.*
PS MOLD PROCESS SETTINGS / Opens mold
process settings.*
PT PATTERN / Duplicates one plastic part and
arranges the resulting occurrences in a
rectangular, circular, or variable pattern.
RN RUNNER / Creates a runner.
RR RADIATE RUNOFF SURFACE / Creates,
edits, or deletes a radiated runoff surface.
RS CREATE RUNOFF SURFACE / Creates a
runoff surface.
SA SLIDER / Creates a standard slider.
SB SPRUE BUSHING / Creates a custom or
vendor sprue bushing.
SK MOLD SHRINKAGE / Estimates the
percentage of shrinkage that occurs based
on the mold dimensions.*
SK PART SHRINKAGE / Estimates the
percentage of shrinkage on an individual
part.*
SM SELECT MATERIAL / Selects material.
SP SECONDARY SPRUE / Provides the means
to add a new secondary sprue to the mold
design and to edit, delete, and adjust the
dimensions of the secondary sprue.
UM USER MOLD BASE / Places a user-dened
mold base.
WP WORKPIECE POCKET / Creates pockets
for a rectangular workpiece.
Part
1 TOGGLE SMOOTH / Activates the toggle
smooth command.
E EDIT FORM / Edits an existing form to
add, remove, or modify controls.
PF PART FILL ANALYSIS / Reveals
information about the ow of polymer
through parts.
*NOTE: The same alias can perform different commands depending on the design environment and object you are working on.
SL LOCK SET / Creates a side lock or an
interlock.
10
MULTI-CHARACTER COMMAND ALIASES
Placed Features
CH CHAMFER / Creates a chamfer.
DE DIRECT EDIT / Allows you to make quick
edits to existing solids.
EF END FILL / Adds a weld end ll annotation
in a drawing view or on a 3D weld bead
to represent the hatched or lled region
indicating the end of a weld bead.
F FILLET / Creates a llet in part and
assembly les.
GW GROOVE WELD / Creates a groove weld
feature in a weldment assembly that
connects two face sets with a solid weld
bead.
MI MIRROR / Creates a mirror feature.
Q CREATE IMATE / Displays the Create
iMate dialog box, for developing iMates.
RP RECTANGULAR PATTERN / Creates
rectangular pattern of feature.
S 2D SKETCH / Activates the 2D Sketch
command.
S3 NEW SKETCH / Activates the 3D Sketch
command.
SH SHELL / Removes material from a part
interior, creating a hollow cavity with walls
of a specied thickness.
TH THREAD / Creates threads in holes or on
shafts, studs, or bolts.
W FILLET / Activates the Fillet tool.
WS WELDING SYMBOL / Provides annotation
and acts as a grouping mechanism by
referencing multiple beads with a single
welding symbol.
Presentation
CV CREATE VIEW / Adds a new presentation
view.
T TWEAK COMPONENTS / Tweaks
components in a presentation.
Sheet Metal
BE BEND / Creates a bend.
CC CORNER CHAMFER / Activates the corner
chamfer command.
CF CONTOUR FLANGE / Creates a contour
ange.
CR CORNER ROUND / Adds llets or rounds
to one or more corners of a sheet metal
part.
CS CORNER SEAM / Denes the corner
seams you add to sheet metal faces.
FA FACE / Creates a sheet metal face.
FO FOLD / Denes the fold in a sheet metal
face along a sketched line that terminates
at face edges.
HEM HEM / Creates a folded hem along sheet
metal edges.
PT PUNCHTOOL / Denes the punch of a 3D
shape into a sheet metal face.
ST SHEET METAL DEFAULTS / Changes the
options and parameters for the active
sheet metal part from those options
dened by the selected Sheet Metal Rule.
Sketch
A BASELINE SET, ANIMATE, ARC /
Activates the Baseline Set, Animate, or Arc
tool, depending on the work environment.
A3 THREE POINT ARC / Draws a three-point
arc using dynamic input.
AD AUTO DIMENSION / Prompts the Auto
Dimension dialog box.
BE BEND / Creates a bend.
CE CENTER POINT CIRCLE / Draws a center
point circle using dynamic input.
CH CHAMFER / Creates a chamfer.
CP CIRCULAR PATTERN / Creates circular
pattern of sketch geometry.
EL ELLIPSE / Creates anellipsewith a center
point, a major axis, and a minor axis that
you dene.
EX EXTEND / Makes surfaces larger in one or
more directions.
FI FILLET / Addslletsorroundsto one or
more edges of a part, between two face
sets, or between three adjacent face sets.
H FILL/HATCH SKETCH REGION / Hatches
or color lls an enclosed boundary in a
drawing sketch.
I VERTICAL / Activates the vertical
constraint tool.
L LINE / Creates a line or arc.
MI MIRROR / Mirrors sketch geometry about
a selected plane.
11
MULTI-CHARACTER COMMAND ALIASES
Sketch
MO MOVE / Moves selected sketch geometry
from point to point, or move a copy of the
geometry.
O OFFSET / Duplicates selected sketch
geometry, and positions it an offset
distance from the original.
PO POINT, CENTER POINT / Sketches points
and center points.
POL POLYGON / Creates polygon shapes.
REC TWO POINT RECTANGLE / Draws a
two-point rectangle using dynamic input.
REC3 THREE POINT RECTANGLE / Draws a
three-point rectangle using dynamic input.
RO ROTATE COMPONENT / Activates the
Rotate Component command.
RP RECTANGULAR PATTERN / Creates
rectangular pattern of sketch geometry.
SP SPLINE / Creates a spline.
Sketch Features
BP BEND PART / Bends a portion of a part.
E EXTRUDE / Extrudes a prole.
H HOLE / Creates a hole in a feature.
LO LOFT / Creates lofted features or bodies
by blending multiple proles into smooth
shapes between the proles or part faces.
R REVOLVE / Revolves a sketch.
SW SWEEP / Creates a sweep feature.
Stress Analysis
A ANIMATE RESULTS / Animates the
selected simulation results.
AC AUTOMATIC CONTACTS / Compares
automatic contacts.
CP CONVERGENCE PLOT / Displays the plot
within a dialog box.*
CP PIN CONSTRAINT / Sets the pinned
constraint origin and offset.*
CS FRICTIONLESS CONSTRAINT / Applies a
frictionless constraint on selected faces.
CT CONTOUR SHADING / Displays color
changes using a strict banding between
colors.
FO FORCE LOAD / Applies a force of the
specied magnitude to the selected faces,
edges, or vertices.
GR GRAVITY LOAD / Creates a gravity load.
MAT ASSIGN MATERIALS / Opens the assign
materials dialogue box to assign materials
to a component.
MAX MAXIMUM RESULT / Turns on and off
the display of the point of maximum result
in the mode.
TC TANGENT CIRCLE / Creates circle tangent
to three lines.
X TRIM / Activates the Trim command.
*NOTE: The same alias can perform different commands depending on the design environment and object you are working on.
BC BOUNDARY CONDITIONS / Toggles
display of all boundary conditions.
BE BEARING LOAD / Applies a bearing load
to a full or partial cylindrical surface.
BO BODY LOAD / Denes angular velocity
or angular or linear acceleration for the
model.
CC COLOR BAR / Displays the Color Bar
settings dialog box where you adjust the
color bar display parameters.
CF FIXED CONSTRAINT / Applies a xed
constraint on selected faces, edges, or
vertices.
MC MANUAL CONTACT / Adds manual
contact conditions to selected geometry
elements.
MIN MINIMUM RESULT / Turns on and off the
display of the point of minimum result in
the model.
ML LOCAL MESH CONTROL / Adds a local
mesh control.
MO MOMENT LOAD / Applies a load of the
specied magnitude around the axis and
perpendicular to the face.
MS MESH SETTINGS / Species the mesh
sizing and coarseness.
12
MULTI-CHARACTER COMMAND ALIASES
Stress Analysis
MV MESH VIEW / Displays the element
mesh used in the solution with the result
contours. Also displays the mesh over the
undeformed model.
N CREATE SIMULATION / Creates new
simulation.
NP NO SHADING / Turns off the Shaded
Results display.
P PROBE / Activates the Probe command.
You place probes as needed in areas of
interest to display the stress values for that
point.
PL PROBE LABELS / Toggles the visibility of
probe labels.
PR PRESSURE LOAD / Pressure load.
R REPORT / Generates a report.
RF REMOTE FORCE LOAD / Applies a force
of the specied magnitude to the selected
face.
S SIMULATE / Runs a simulation.
Tools
LA EDIT LAYERS / Species a layer name and
attributes for common display properties
of drawing objects.
M MEASURE DISTANCE / Opens the
Measure Distance window.
OP APPLICATION OPTIONS / Opens the
Application Options settings.
SE EDIT STYLES / Style and Standard Editor.
Tube & Pipe
AT TUBE & PIPE AUTHORING / Authors an
iPart or a normal part for publishing to the
Content Center Library.
CF CONNECT FITTINGS / Connects existing
ttings.
DR DERIVED MOTION / Creates or edits a
derived route.
MN MOVE NODE / Drags node to a new
location.
MS MOVE SEGMENT / Drags segment to a
new location.
NR NEW ROUTE / Adds new rigid piping and
bent tubing routes to a pipe run.
PF PLACE FITTING / Picks up a tting from
your project work space to place into the
active run.
PR CREATE PIPE RUN / Creates pipe run.*
PR POPULATE ROUTE / Populates route.*
RT ROUTE / Starts or continues route
denition.
ST TUBE AND PIPE STYLES / Copies and
modies existing style denitions and
delete styles you no longer use.
WT GROUNDED WORK POINT / Grounded
Work Point.
SC RESULT DISPLACEMENT SCALE /
Adjusts displacement scale.
SET STRESS ANALYSIS SETTINGS / Activates
the stress analysis settings dialog box.
SM SMOOTH SHADING / Displays color
changes using a blended transition.
SS SAME SCALE / Maintains the same scale
while viewing different results.
T PARAMETRIC TABLE / Accesses the
parametric table to specify design
constraints and parameter ranges.
*NOTE: The same alias can perform different commands depending on the design environment and object you are working on.
ES EDIT BASE SKETCH / Edits the base 3D
sketch.
HL HOSE LENGTH / Edits hose length by
changing end tangency weights.
IG INCLUDE GEOMETRY / Introduces
reference geometry to the route sketch.
IN INSERT NODE / Inserts route node into
segment.
IO ISOGEN OUTPUT / Saves a le with a
specied name and ISOGEN le type.
View
ORBIT FREE ORBIT / Rotates a model about
the center of the screen or about axes in
model space.
PAN PAN / Pans the view.
VC VIEWCUBE / Toggles the view of the
ViewCube.
Z ZOOM WINDOW / Zooms in on a
specied area.
13
=
EQUAL
;
GRNDED
WRK PT
/
WRK
AXIS
]
WRK
PLANE
.
WRK PT
DEL END
ZOOM
SELTED
CANCELDELETE
ESC
HOME
ZOOM
ALL
PG UP
LOOK
AT
EQUAL
=
EQUAL
=
EQUAL
=
EQUAL
=
=
EQUAL
=
EQUAL
=
EQUAL
=
EQUAL
=
EQUAL
=
EQUAL
;
GRNDED
WRK PT
;
GRNDED
WRK PT
;
GRNDED
WRK PT
;
GRNDED
WRK PT
;
GRNDED
WRK PT
;
GRNDED
WRK PT
/
WRK
AXIS
/
WRK
AXIS
/
WRK
AXIS
/
WRK
AXIS
/
WRK
AXIS
/
WRK
AXIS
]
WRK
PLANE
]
WRK
PLANE
]
WRK
PLANE
]
WRK
PLANE
]
WRK
PLANE
]
WRK
PLANE
.
WRK PT
.
WRK PT
.
WRK PT
.
WRK PT
.
WRK PT
.
WRK PT
DEL END
DEL END
DEL END
DEL END
DEL END
DEL END
ZOOM
SELTED
ZOOM
SELTED
ZOOM
SELTED
ZOOM
SELTED
ZOOM
SELTED
ZOOM
SELTED
CANCELDELETE
CANCELDELETE
CANCELDELETE
CANCELDELETE
CANCELDELETE
CANCELDELETE
ESC
ESC
ESC
ESC
ESC
ESC
HOME
ZOOM
ALL
HOME
ZOOM
ALL
HOME
ZOOM
ALL
HOME
ZOOM
ALL
HOME
ZOOM
ALL
HOME
ZOOM
ALL
PG UP
LOOK
AT
PG UP
LOOK
AT
PG UP
LOOK
AT
PG UP
LOOK
AT
PG UP
LOOK
AT
PG UP
LOOK
AT
GRNDED
WRK PT
WRK
AXIS
PLANE
WRK
WRK PT
SELTED
ZOOM
;
/
]
.
DEL END
GRNDED
WRK PT
WRK
AXIS
PLANE
WRK
WRK PT
SELTED
ZOOM
;
/
]
.
DEL END
GRNDED
WRK PT
WRK
AXIS
PLANE
WRK
WRK PT
SELTED
ZOOM
;
/
]
.
DEL END
GRNDED
WRK PT
WRK
AXIS
PLANE
WRK
WRK PT
SELTED
ZOOM
;
/
]
.
DEL END
=
EQUAL
=
EQUAL
=
EQUAL
;
GRNDED
WRK PT
;
GRNDED
WRK PT
;
GRNDED
WRK PT
/
WRK
AXIS
/
WRK
AXIS
/
WRK
AXIS
]
WRK
PLANE
]
WRK
PLANE
]
WRK
PLANE
.
WRK PT
.
WRK PT
.
WRK PT
PRINTABLE KEYBOARD STICKERS [14 COMPLETE SETS]
FOR USE WITH: http://www.onlinelabels.com/OL32.htm
DEL END
DEL END
DEL END
ZOOM
SELTED
ZOOM
SELTED
ZOOM
SELTED
CANCELDELETE
CANCELDELETE
CANCELDELETE
ESC
ESC
ESC
HOME
ZOOM
ALL
HOME
ZOOM
ALL
HOME
ZOOM
ALL
PG UP
LOOK
AT
PG UP
LOOK
AT
PG UP
LOOK
AT
ALL
AT
CANCELDELETE
ESC
HOME
ZOOM
PG UP
LOOK
ALL
AT
CANCELDELETE
ESC
HOME
ZOOM
PG UP
LOOK
ALL
AT
CANCELDELETE
ESC
HOME
ZOOM
PG UP
LOOK
ALL
AT
CANCELDELETE
ESC
HOME
ZOOM
PG UP
LOOK
Loading...
