autocad 2013 Customization Guide

Download
AutoCAD 2013
Customization Guide
January 2012
©
2012 Autodesk, Inc. All Rights Reserved. Except as otherwise permitted by Autodesk, Inc., this publication, or parts thereof, may not
be reproduced in any form, by any method, for any purpose.
Certain materials included in this publication are reprinted with the permission of the copyright holder.
Trademarks
All other brand names, product names or trademarks belong to their respective holders.
Disclaimer
THIS PUBLICATION AND THE INFORMATION CONTAINED HEREIN IS MADE AVAILABLE BY AUTODESK, INC. "AS IS." AUTODESK, INC. DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE REGARDING THESE MATERIALS.

Contents

Chapter 1 Basic Customization . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview of Customization . . . . . . . . . . . . . . . . . . . . . . . . 1
Organize Program and Support Files . . . . . . . . . . . . . . . . . . . . 3
Overview of File Organization . . . . . . . . . . . . . . . . . . . . 3
Multiple Drawing Folders . . . . . . . . . . . . . . . . . . . . . . 5
Locate Customized Files . . . . . . . . . . . . . . . . . . . . . . . 7
Locate Plot Style Files . . . . . . . . . . . . . . . . . . . . . . 8
Locate Plotter Files . . . . . . . . . . . . . . . . . . . . . . . 8
Locate Support Files . . . . . . . . . . . . . . . . . . . . . . 9
Locate Drawing Template Files . . . . . . . . . . . . . . . . 12
Locate Texture Files . . . . . . . . . . . . . . . . . . . . . . 13
Create Command Aliases . . . . . . . . . . . . . . . . . . . . . . . . . 14
Create Command Aliases . . . . . . . . . . . . . . . . . . . . . . 15
Chapter 2 Custom Linetypes . . . . . . . . . . . . . . . . . . . . . . . . . 17
Overview of Linetype Definitions . . . . . . . . . . . . . . . . . . . . . 17
Simple Custom Linetypes . . . . . . . . . . . . . . . . . . . . . . . . . 18
Simple Custom Linetypes . . . . . . . . . . . . . . . . . . . . . . 20
Text in Custom Linetypes . . . . . . . . . . . . . . . . . . . . . . . . . 21
Text in Custom Linetypes . . . . . . . . . . . . . . . . . . . . . . 23
Shapes in Custom Linetypes . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 3 Custom Hatch Patterns . . . . . . . . . . . . . . . . . . . . . . 27
iii
Overview of Hatch Pattern Definitions . . . . . . . . . . . . . . . . . . 27
Overview of Hatch Pattern Definitions . . . . . . . . . . . . . . . 29
Hatch Patterns with Dashed Lines . . . . . . . . . . . . . . . . . . . . 29
Hatch Patterns with Dashed Lines . . . . . . . . . . . . . . . . . 31
Hatch Patterns with Multiple Lines . . . . . . . . . . . . . . . . . . . . 31
Hatch Patterns with Multiple Lines . . . . . . . . . . . . . . . . . 33
Chapter 4 User Interface Customization . . . . . . . . . . . . . . . . . . . 35
Understand User Interface Customization . . . . . . . . . . . . . . . . 35
Overview of the Customization . . . . . . . . . . . . . . . . . . . 35
Customization Glossary . . . . . . . . . . . . . . . . . . . . . . . 36
Customize Commands . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Overview of Commands . . . . . . . . . . . . . . . . . . . . . . 36
Create, Edit, and Reuse Commands . . . . . . . . . . . . . . . . . 37
Create, Edit, and Reuse Commands . . . . . . . . . . . . . 38
Create Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Overview of Macros . . . . . . . . . . . . . . . . . . . . . . 40
Use Special Control Characters in Macros . . . . . . . . . . 42
Pause for User Input in Macros . . . . . . . . . . . . . . . . 44
Provide International Support in Macros . . . . . . . . . . . 46
Use Built-in Commands in Macros . . . . . . . . . . . . . . 46
Repeat Commands in Macros . . . . . . . . . . . . . . . . . 46
Use Single Object Selection Mode in Macros . . . . . . . . . 47
Use Conditional Expressions in Macros . . . . . . . . . . . 47
Use AutoLISP in Macros . . . . . . . . . . . . . . . . . . . . 48
Control the Display of Command Items . . . . . . . . . . . . . . 50
Create Tooltips for Commands . . . . . . . . . . . . . . . . . . . 51
Create and Manage Images for Commands . . . . . . . . . . . . . 51
Assign Images to a Command . . . . . . . . . . . . . . . . 52
Customize User Interface Elements . . . . . . . . . . . . . . . . . . . . 52
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Overview of Menus . . . . . . . . . . . . . . . . . . . . . . 52
Create and Manage Pull-down Menus . . . . . . . . . . . . 53
Tool Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Overview of Tool Sets and Tool Groups . . . . . . . . . . . 56
Create and Manage Tool Sets . . . . . . . . . . . . . . . . . 57
Chapter 5 DIESEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
DIESEL Expressions in Macros . . . . . . . . . . . . . . . . . . . . . . 63
Catalog of DIESEL Functions . . . . . . . . . . . . . . . . . . . . . . . 66
+ (addition) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
- (subtraction) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
* (multiplication) . . . . . . . . . . . . . . . . . . . . . . . . . . 67
/ (division) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
= (equal to) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
iv | Contents
< (less than) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
> (greater than) . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
!= (not equal to) . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
<= (less than or equal to) . . . . . . . . . . . . . . . . . . . . . . 68
>= (greater than or equal to) . . . . . . . . . . . . . . . . . . . . 68
and . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
angtos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
edtime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
eq . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
eval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
fix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
getenv . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
getvar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
if . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
nth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
or . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
rtos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
strlen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
substr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
upper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
xor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
DIESEL Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Chapter 6 Command Scripts . . . . . . . . . . . . . . . . . . . . . . . . . 75
Create Command Scripts . . . . . . . . . . . . . . . . . . . . . . . . . 75
Overview of Command Scripts . . . . . . . . . . . . . . . . . . . 75
Overview of Command Scripts . . . . . . . . . . . . . . . . 76
Run Scripts at Startup . . . . . . . . . . . . . . . . . . . . . . . . 77
Run Scripts at Startup . . . . . . . . . . . . . . . . . . . . . 78
Chapter 7 Introduction to Programming Interfaces . . . . . . . . . . . . . 79
AutoLISP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Overview of AutoLISP . . . . . . . . . . . . . . . . . . . . . . . . 79
Use AutoLISP Applications . . . . . . . . . . . . . . . . . . . . . 80
Automatically Load and Run AutoLISP Routines . . . . . . . . . . 82
Overview of AutoLISP Automatic Loading . . . . . . . . . . 82
The ACAD.LSP File . . . . . . . . . . . . . . . . . . . . . . 83
The ACADDOC.LSP File . . . . . . . . . . . . . . . . . . . . 84
The MNL File for an AutoLISP Menu . . . . . . . . . . . . . 85
Prevent AutoLISP Errors When Loading Startup Files . . . . 85
S::STARTUP Function: Postinitialization Execution . . . . . 86
ObjectARX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Overview of ObjectARX . . . . . . . . . . . . . . . . . . . . . . . 88
Use ObjectARX Applications . . . . . . . . . . . . . . . . . . . . 88
Contents | v
Install and Uninstall Plug-In Applications . . . . . . . . . . . . . . . . 89
PackageContents.xml Format . . . . . . . . . . . . . . . . . . . . 90
ApplicationPackage Element . . . . . . . . . . . . . . . . . 93
CompanyDetails Element . . . . . . . . . . . . . . . . . . . 95
Components Element . . . . . . . . . . . . . . . . . . . . . 96
Supported Locale Codes . . . . . . . . . . . . . . . . . . . 103
Example of Basic .bundle Folder Structure . . . . . . . . . . . . 104
Example of Using Folders to Organize Components . . . . . . . 105
Chapter 8 Shapes and Shape Fonts . . . . . . . . . . . . . . . . . . . . . 109
Overview of Shape Files . . . . . . . . . . . . . . . . . . . . . . . . . 109
Overview of Shape Files . . . . . . . . . . . . . . . . . . . . . . 110
Create Shape Definition Files . . . . . . . . . . . . . . . . . . . . . . 110
Shape Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . 111
Vector Length and Direction Code . . . . . . . . . . . . . . . . 112
Special Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Use Special Codes . . . . . . . . . . . . . . . . . . . . . . 114
Codes 0, 1, and 2: End of Shape and Draw Mode
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Codes 3 and 4: Size Control . . . . . . . . . . . . . . . . . 115
Codes 5 and 6: Location Save/Restore . . . . . . . . . . . . 115
Code 7: Subshape . . . . . . . . . . . . . . . . . . . . . . 116
Codes 8 and 9: X-Y Displacements . . . . . . . . . . . . . 116
Code 00A: Octant Arc . . . . . . . . . . . . . . . . . . . . 117
Code 00B: Fractional Arc . . . . . . . . . . . . . . . . . . 118
Codes 00C and 00D: Bulge-Specified Arcs . . . . . . . . . . 119
Code 00E: Flag Vertical Text Command . . . . . . . . . . . 120
Text Font Descriptions . . . . . . . . . . . . . . . . . . . . . . . 121
Sample Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Extended Simplex Roman . . . . . . . . . . . . . . . . . . 123
Extended Standard Font for UNICODE . . . . . . . . . . . 151
Big Font Descriptions . . . . . . . . . . . . . . . . . . . . . . . 171
Define a Big Font . . . . . . . . . . . . . . . . . . . . . . 171
Define an Extended Big Font File . . . . . . . . . . . . . . 172
Use Big Font Text in a Drawing . . . . . . . . . . . . . . . 178
Use a Big Font to Extend a Font . . . . . . . . . . . . . . . 179
Unicode Font Descriptions . . . . . . . . . . . . . . . . . . . . 180
Superscripts and Subscripts in SHX Files . . . . . . . . . . . . . 181
Superscripts and Subscripts in SHX Files . . . . . . . . . . 181
vi | Contents
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Basic Customization

1
AutoCAD® is a general-purpose drafting system designed with an open architecture so you can customize and extend its many features. As a result, you can expand and shape AutoCAD according to your needs.

Overview of Customization

AutoCAD can be customized in simple ways. For example, you can change the directory structure or create a custom title block to use on a layout. If you want to change the interface further, you can edit the Tool Sets palette or menu bar, and use DIESEL statements to create custom commands.
You can also use a number of powerful application programming interfaces (APIs) to add to and modify AutoCAD to suit your needs.
The list that follows is arranged from least to most complex:
■ Organize files. You can organize program, support, and drawing files. For
example, you can make a separate folder for each project that includes only the support files that project needs.
■ Create custom drawing templates (DWTs). You can create custom
drawing templates to use when creating a new drawing. Drawing templates are used to store the layers, blocks, and styles that you might use across all your drawings.
■ Run external programs and utilities from within AutoCAD. You
can, for example, copy a disk or delete a file from within AutoCAD by adding the appropriate external command to the program parameters (PGP) file, acad.pgp.
■ Define command aliases. You can define simple abbreviations, or aliases,
for frequently used commands from within AutoCAD by adding the command to the PGP file acad.pgp. For example, you might want to start the BLOCK command by entering b.
1
■ Create custom linetypes, hatch patterns, shapes, and text fonts.
You can create linetypes, hatch patterns, shapes, and text fonts that conform to your company standards and working methods.
■ Customize the user interface. You can control many aspects of the
user interface, including the functionality and appearance of the Tool Sets palette and menu bar. You use the CUI command to create and edit commands, and assign them to a menu on the menu bar or a tab on the Tool Sets palette.
■ Customize the status line. You can toggle the display of the controls
on the status bar. Right-click an empty area of the status bar and choose which controls to turn on or off.
■ Automate repetitive tasks by writing scripts. A script is an ASCII
text file containing commands that are processed like a batch file when you run the script. For example, if a set of drawings needs to be plotted a certain way, you can write a script that opens each drawing, hides and displays various layers, and issues PLOT commands.
■ Redefine or disable selected AutoCAD commands, either at the
command prompt or as part of an AutoLISP or ObjectARX
®
program. You can redefine certain AutoCAD commands to issue supplementary messages and instructions or, for example, to create a drawing management system in which the QUIT command is redefined to write billing information to a log file before ending the editing session.
In addition to the methods described in the Customization Guide, there are application programming interfaces (APIs) available for customizing AutoCAD.
Introduction to Programming Interfaces (page 79) briefly describes these APIs
and provides cross-references to more information.
See also:
Organize Program and Support Files (page 3)
Create Command Aliases (page 14)
Custom Linetypes (page 17)
Custom Hatch Patterns (page 27)
DIESEL (page 63)
Introduction to Programming Interfaces (page 79)
Command Scripts (page 75)
2 | Chapter 1 Basic Customization

Organize Program and Support Files

You can change the default directory structure for the program and support files to suit your needs.

Overview of File Organization

AutoCAD uses support files for purposes such as storing customization definitions, loading AutoLISP and ObjectARX applications, and describing text fonts.
The default directory structure for the AutoCAD program and support files is designed to efficiently organize those files into logical groups. If this organization does not suit your needs, you can change it. However, some applications look for certain files in specific locations, and you should verify that your modifications do not conflict with the requirements of those applications. Without the full path, including drive and directory, AutoCAD can locate only those files that are found in the library search path.
The location of local customizable files is stored in the LOCALROOTPREFIX system variable. The location of roamable customizable files is stored in the ROAMABLEROOTPREFIX system variable. If a network supports roaming, customizable files in the user's roaming profile are available on the machine the user is logged onto.
Library Search Path
The library search path specifies where the program searches for files when you do not specify a full path name, as follows:
■ Current directory.
■ Directory that contains the current drawing file.
■ Directories listed in the search path specified on the Applications tab in
OPTIONS. (See Specify Search Paths and File Locations in the User's Guide.)
■ Directory that contains the AutoCAD program files.
Depending on the current environment, two or more directories may be the same.
If a file is not in this search path, you must specify both its path name and file name before AutoCAD can find it. For example, if you want to insert the part5.dwg drawing into your current drawing and it is not in the library search path, you must specify its full path name, as shown here:
Organize Program and Support Files | 3
Command: insert Enter block name or [?]: /files2/olddwgs/part5
If the drawing exists in that location, AutoCAD prompts you to finish the INSERT command in the usual manner.
Directory Structure
AutoCAD uses tree-structured directories and subdirectories. It is recommended that you keep supplemental files (such as AutoLISP applications and customization files) separate from the AutoCAD program and support files. This makes it easier to track possible conflicts and to upgrade each application without affecting the others.
The default location for AutoCAD is in the Applications folder. You can create a new directory on the same level (for example, /AcadApps) and store your custom AutoLISP and ObjectARX application files, custom linetypes and hatch pattern files, and other third-party applications in subdirectories on the next level. If you want to maintain multiple drawing directories (for separate job files), you can create a directory such as /AcadJobs with subdirectories for each job.
Command Search Procedure
When you enter a command, AutoCAD goes through a series of steps to evaluate the validity of the command name. A command can be a built-in command or system variable, an external command or alias defined in the acad.pgp file, or a user-defined AutoLISP command. Commands can also be defined by ObjectARX applications or a device driver command. You can enter a command on the command prompt or choose a command from the appropriate menu. Commands can also be entered from a script file or by an AutoLISP or ObjectARX application.
The following list describes the search order AutoCAD uses to validate a command name.
1 If the input is a null response (Spacebar or Enter), AutoCAD uses the
name of the last command issued.
2 AutoCAD checks the command name against the list of built-in
commands. If the command is in the list and is not preceded by a period (.), AutoCAD then checks the command against a list of undefined commands. If the command is undefined, the search continues. Otherwise, the command is run, unless another reason prevents it from
4 | Chapter 1 Basic Customization
doing so. Running it transparently or in Perspective mode might be impossible.
3 AutoCAD checks the command name against the names of commands
defined by a device driver, and then by those defined by the display driver.
4 AutoCAD checks the command name against the external commands
defined in the program parameters file (acad.pgp). If the command name corresponds to a defined external command, that command runs, and the search is complete.
5 AutoCAD checks the command name against the list of commands
defined by AutoLISP or ObjectARX applications. At this point, an autoloaded command is loaded.
6 AutoCAD checks the command name against the list of system variables.
If the command name is in the list, AutoCAD executes the SETVAR command, using the input as the variable name.
7 If the command name corresponds to a command alias defined in the
program parameters file, AutoCAD uses the expanded command name and continues the search, starting a new search against the list of built-in commands.
8 If all the preceding steps fail, the search terminates with a warning
message about illegal command names.
See also:
Overview of AutoLISP Automatic Loading (page 82)
Specify Search Paths and File Locations in the User's Guide

Multiple Drawing Folders

Keeping your drawing and other associated files in separate directories makes it easier to perform basic file maintenance.
Keeping your drawing files and other associated files in separate directories makes it easier to perform basic file maintenance. The scenario described in this topic is based on the sample directory structure described in Overview of
File Organization (page 3), but you can expand or alter it to meet your needs.
You can set up the /AcadJobs directory to contain your drawing subdirectories. The drawing subdirectories can contain other subdirectories that hold related support files for a particular drawing type or job. The /AcadJobs/Job1/Support directory can contain blocks and AutoLISP files specific to the drawing files
Organize Program and Support Files | 5
in /AcadJobs/Job1. Specifying support (with no path prefix) in the Support path adds the support directory within the current directory to the Support path.
To make sure that the required drawing directory is the current directory when you start AutoCAD, and that all files and subdirectories in that directory are easily accessible, you can create a program icon or a Start menu item that specifies the correct working directory for each job. This functionality works only if you set the AutoCAD system variable REMEMBERFOLDERS to 0.
You can use a batch program to create new job directories automatically. The following batch program verifies that a specified directory exists, sets that directory to be current, and then runs AutoCAD.
#!/bin/sh prj="$1" #Switch to the project folder and start AutoCAD function startACAD() {
cd /AcadJobs/Jobs/$prj echo "Starting AutoCAD" "/Applications/Autodesk/AutoCAD 2013/AutoCAD
2013.app/Contents/MacOS/AutoCAD 2013" } #Clear Terminal and check for the existence of the folder clear cd . if [ -d /AcadJobs/Jobs/$prj ] then
startACAD fi #Prompt to create folder echo . echo Creating /AcadJobs/Jobs/$prj echo 'Press Y to continue (or A to abort)' echo . cont="True" answer=""while [ "$cont" = "True" ] do
read -n1 -t10 answer
echo
if [ "$answer" = "y" ] || [ "$answer" = "Y" ] || [ "$answer" = "a" ] || [ "$answer" = "A" ]
then
cont="False"
fi
6 | Chapter 1 Basic Customization
done #Check to see if the user requested to abort or continue if [ "$answer" = "a" ] || [ "$answer" = "A" ] then
exit 1
else
mkdir -p /AcadJobs/Jobs/$prj fi #Switch to the project folder and start AutoCAD startACAD
Using an ASCII text editor (such as TextEdit), save the batch program to a file named acad.sh. Be sure to change the drive and directory names to match those on your system.
Place this file in your home directory or a shared location that is on your system. You can run this shell script program using the Terminal window in /Applications/Utilities on the drive the operating system is installed. If you saved the file as acad.sh, use the following syntax:
./acad.sh jobname
where jobname is the name of the job directory to make current.

Locate Customized Files

AutoCAD supports a wide range of files that can be customized. The program stores files that can be customized by user profile, as well as allow you to add your own customized file locations. The following locations are defined by the program:
■ Local profiles. Local profiles are used to log on a computer and they
store settings and files that are not available when roaming. Some files, such as materials and drawing templates are stored under your local profile because of their size, they do not follow you from computer to computer.
■ Roaming profiles. Roaming profiles allow you to log on to any computer
within a network and retain your user settings. Some files, such as your personal settings and documents, follow you from computer to computer.
If roaming profiles are allowed on your network, your “roamable” files are located in the <user>/Library/Application Support/Autodesk/Roaming/<Product
Version> folder, and your “nonroamable” files are located in the <user>/Application Support/Autodesk/Local/<Product Version> folder.
Organize Program and Support Files | 7
Locate Plot Style Files
The location AutoCAD uses for plot style files defines on how the program was installed and configured. You can use the OPTIONS command to locate which folder is being used to store your plot styles.
To locate your plot style files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Printer Support File Path.
5 Click the arrow to the left of the Plot Style Table Search Path file.
6 Under Plot Style Table Search Path, click the path name to view the
location of your plot style files.
NOTE You can also locate your plot style files by entering stylesmanager on the AutoCAD command line.
Locate Plotter Files
The location AutoCAD looks in for custom printer settings is stored in the Application Preferences dialog box. You can use the OPTIONS command to locate which folder is being used to store your plot configuration files.
To locate your plotter files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
8 | Chapter 1 Basic Customization
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Printer Support File Path.
5 Click the arrow to the left of Printer Configuration Search Path.
6 Under Printer Configuration Search Path, click the path name to view
the location of your plotter files.
NOTE You can also locate your plotter files by entering plottermanager on the AutoCAD command line.
Locate Support Files
Support files include the following:
■ Configuration file (acad.cfg)
■ Custom icon files
■ Help and miscellaneous files
■ Font mapping file (acad.fmp)
■ Alternate font file (simplex.shx)
■ Support path files (acad.lin, acad.mln, acad.mnl,acad.pat, acad.pgp, acad.psf,
acad.unt, acadiso.lin, acadiso.pat, gdt.shx, inches.pss, and mm.pss)
Locate Support Files
To find the default location of the configuration file
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
Organize Program and Support Files | 9
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Help and Miscellaneous File Names.
5 Click the arrow to the left of Configuration File.
6 Under Configuration File, click the path name to view the location of
your configuration file.
To find the default location of the customization files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Customization Files.
5 Click the arrow to the left of Main Customization File.
6 Under Main Customization File, click the path name to view the location
of your main customization file.
To find the default location of the custom icon files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Customization Files.
5 Under Custom Icon Location, click the path name to view the location
for the custom button image files used with your customization files.
10 | Chapter 1 Basic Customization
To find the default location of the Help and miscellaneous files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Help and Miscellaneous File Names.
5 Click the arrow to the left of the file you want to locate, and then click
the path name to view the location of the files.
To find the default location of the font mapping file
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Text Editor, Dictionary, and Font File Names.
5 Click the arrow to the left of Font Mapping File.
6 Under Font Mapping File, click the path name to view the location of
your font mapping file.
To find the default location of the alternate font file
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
Organize Program and Support Files | 11
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Text Editor, Dictionary, and Font File Names.
5 Click the arrow to the left of Alternate Font File.
6 Under Alternate Font File, click the path name to view the location of
your alternate font file.
To find the default location of the support path files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Support File Search Path.
5 Under Support File Search Path, click a path name to view the location
of your support files.
Locate Drawing Template Files
The location AutoCAD looks in for drawing templates is stored in the Application Preferences dialog box. You can use the OPTIONS command to locate which folder is being used to store your drawing templates.
Locate Drawing Template Files
To locate your drawing template files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
12 | Chapter 1 Basic Customization
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Template Settings.
5 Under Template Settings, click the arrow sign (+) to the left of Drawing
Template File Location.
6 Under Drawing Template File Location, click the path name to view the
location of your drawing template files.
Locate Texture Files
The locations AutoCAD looks in for material texture files are stored in the Application Preferences dialog box. You can use the OPTIONS command to locate which folders are being used to store your material texture files.
Locate Texture Files
To locate your texture files
1 From the Finder menu bar, click Go ➤ Applications. 2 In the Applications window, double-click Autodesk ➤ AutoCAD
2013 ➤ AutoCAD.
3 From the Mac OS menu bar, click AutoCAD ➤ Preferences.
NOTE
A drawing must be open to see the Preferences menu item.
4 In the Application Preferences dialog box, Application tab, click the
arrow to the left of Texture Maps Search Path.
5 Under Texture Maps Search Path, click the path name to view the location
of your texture files.
Organize Program and Support Files | 13

Create Command Aliases

A command alias is an abbreviation that you enter at the command prompt instead of entering the entire command name.
For example, you can enter c instead of circle to start the CIRCLE command. An alias is not the same as a keyboard shortcut, which is a combination of keystrokes, such as Ctrl-S for SAVE.
The acad.pgp file defines command aliases. You can change existing aliases or add new ones by editing acad.pgp in an ASCII text editor. In addition to command aliases in acad.pgp, you will also find comment lines which are preceded by a semicolon (;). Comment lines allow you to add textual information to acad.pgp, such as when or who revised the file last.
NOTE Before you edit acad.pgp, create a backup so that you can restore it later, if necessary.
To define a command alias, add a line to the acad.pgp file using the following syntax:
abbreviation,*command
abbreviation is the command alias that you enter at the command prompt and command is the command being abbreviated. You must enter an asterisk (*)
before the command name to identify the line as a command alias definition.
If you can enter a command transparently, you can also enter its alias transparently. When you enter the command alias, the full command name is displayed at the command prompt and the command is executed.
You can create command aliases that include the special hyphen (-) prefix, such as those listed here, that accesses the version of a command that displays command prompts instead of a dialog box.
BH, *-BHATCH BD, *-BOUNDARY
NOTE You cannot use command aliases in command scripts. Using command aliases in custom commands is not recommended.
Restarting AutoCAD automatically reloads the file.
14 | Chapter 1 Basic Customization

Create Command Aliases

To open the program parameters file (acad.pgp)
1 From the Finder menu bar, click Go ➤ Home.
2 In the Finder window, double-click Library. Continue to navigate to
Application Support/Autodesk/Roaming/AutoCAD 2013/<version>/<language>/Support and double-click acad.pgp. If prompted
for an application to use, select TextEdit.
Create Command Aliases | 15
16

Custom Linetypes

2
AutoCAD® provides a library of standard linetypes in the acad.lin and acadiso.lin files. You can use the linetypes as they are, modify them, or create your own custom linetypes.

Overview of Linetype Definitions

Linetypes are defined in one or more linetype definition files that have a .lin file extension.
The linetype name and definition determine the particular dash-dot sequence, the relative lengths of dashes and blank spaces, and the characteristics of any included text or shapes. You can use any of the standard linetypes that AutoCAD provides, or you can create your own linetypes.
Examples of linetypes
A LIN file can contain definitions of many simple and complex linetypes. You can add new linetypes to an existing LIN file, or you can create your own LIN file. To create or modify linetype definitions, edit the LIN file using a text editor or word processor or use LINETYPE at the command prompt.
When you create a linetype, you must load the linetype before you can use it.
The LIN files included in AutoCAD are acad.lin and acadiso.lin. You can display or print these text files to better understand how to construct linetypes.
17

Simple Custom Linetypes

Each linetype is defined on two lines in a linetype definition file. The first line contains the linetype name and an optional description. The second line is the code that defines the actual linetype pattern.
The second line must begin with the letter A (alignment), followed by a list of pattern descriptors that define pen-up lengths (spaces), pen-down lengths (dashes), and dots. You can include comments in an LIN file by beginning the line with a semicolon (;).
Linetype Definition Format
The format of the linetype definition is
*linetype_name,description A,descriptor1,descriptor2, ...
For example, a linetype called DASHDOT is defined as
*DASHDOT,Dash dot __ . __ . __ . __ . __ . __ . __ . __ A,.5,-.25,0,-.25
This indicates a repeating pattern starting with a dash 0.5 drawing units long, a space 0.25 drawing units long, a dot, and another space 0.25 drawing units long. This pattern continues for the length of the line, ending with a dash 0.5 drawing units long. The linetype would be displayed as shown below.
__ . __ . __ . __ . __ . __ . __ . __
LIN files must be saved in ASCII format and use an .lin file extension. Additional information about each field in a linetype definition follows.
Linetype Name
The linetype name field begins with an asterisk (*) and should provide a unique, descriptive name for the linetype.
Description
The description of the linetype should help you visualize the linetype when you edit the LIN file. The description is also displayed in the Linetype Manager and in the Load or Reload Linetypes dialog box.
The description is optional and can include
■ A simple representation of the linetype pattern using ASCII text
18 | Chapter 2 Custom Linetypes
■ An expanded description of the linetype
■ A comment such as "Use this linetype for hidden lines"
If you omit the description, do not insert a comma after the linetype name. A description cannot exceed 47 characters.
Alignment Field (A)
The alignment field specifies the action for pattern alignment at the ends of individual lines, circles, and arcs. Currently, AutoCAD supports only A-type alignment, which guarantees that the endpoints of lines and arcs start and stop with a dash.
For example, suppose you create a linetype called CENTRAL that displays the repeating dash-dot sequence commonly used as a centerline. AutoCAD adjusts the dash-dot sequence on an individual line so that dashes and line endpoints coincide. The pattern fits the line so that at least half of the first dash begins and ends the line. If necessary, the first and last dashes are lengthened. If a line is too short to hold even one dash-dot sequence, AutoCAD draws a continuous line between the endpoints. For arcs also, the pattern is adjusted so that dashes are drawn at the endpoints. Circles do not have endpoints, but AutoCAD adjusts the dash-dot sequence to provide a reasonable display.
You must specify A-type alignment by entering a in the alignment field.
Pattern Descriptors
Each pattern descriptor field specifies the length of segments making up the linetype, separated by commas (no spaces are allowed):
■ A positive decimal number denotes a pen-down (dash) segment of that
length.
■ A negative decimal number denotes a pen-up (space) segment of that
length.
■ A dash length of 0 draws a dot.
You can enter up to 12 dash-length specifications per linetype, provided they fit on one 80-character line in the LIN file. You need to include only one complete repetition of the linetype pattern defined by pattern descriptors. When the linetype is drawn, AutoCAD uses the first pattern descriptor for the starting and ending dashes. Between the starting and ending dashes, the pattern dash specifications are drawn sequentially, beginning with the second dash specification and restarting the pattern with the first dash specification when required.
Simple Custom Linetypes | 19
A-type alignment requires that the first dash length be 0 or greater (a pen-down segment). The second dash length should be less than 0 if you need a pen-up segment and more than 0 if you are creating a continuous linetype. You must have at least two dash specifications for A-type alignment.

Simple Custom Linetypes

To create a simple linetype from the Command prompt
1 At the command prompt, enter -linetype.
2 Enter c (Create).
3 Enter a name for the linetype and press Enter.
The linetype name can include up to 255 characters. Linetype names can contain letters, digits, and the special characters dollar sign ($), hyphen (-), and underscore (_). Linetype names cannot include blank spaces.
4 In the Create or Append Linetype File dialog box, select a location from
the Where drop-down list and specify a LIN linetype library file. Click Save.
If you select an existing file, the new linetype name is added to the linetype names in the file.
5 Enter text that describes the new linetype (optional).
6 At the Enter Pattern prompt, specify the pattern of the line. Follow these
guidelines:
■ All linetypes must begin with a dash.
■ Enter zeros for dots.
■ Enter negative real numbers for spaces. The value defines the length
of the space in drawing units.
■ Enter positive real numbers for dashes. The value defines the length
of the dash in drawing units.
■ Separate each dot, dash, or space value from the next with a comma.
■ Use a space between a dot and a dash.
7 Press Enter to end the command.
20 | Chapter 2 Custom Linetypes
NOTE
When you create a linetype, it is not loaded into your drawing automatically. Use the Load option of LINETYPE.
To add a simple linetype to a LIN file
1 Open the acad.lin or acadiso.lin file in a text editor that saves in ASCII
format.
2 Create a header line that includes an asterisk and a linetype pattern
name. The name of the linetype pattern is limited to 31 characters.
3 (Optional) To include a description in the header line, follow the linetype
pattern name with a comma and description text.
4 Create a descriptor line that includes:
■ All linetypes must begin with a dash.
■ Enter zeros for dots.
■ Enter negative real numbers for spaces. The value defines the length
of the space in drawing units.
■ Enter positive real numbers for dashes. The value defines the length
of the dash in drawing units.
■ Separate each dot, dash, or space value from the next with a comma.
■ Use a space between a dot and a dash.

Text in Custom Linetypes

Characters from text fonts can be included in linetypes.
Characters from text fonts can be included in linetypes. Linetypes with embedded characters can denote utilities, boundaries, contours, and so on. As with simple linetypes, lines are dynamically drawn as you specify the vertices. Characters embedded in lines are always displayed completely; they are never trimmed.
Embedded text characters are associated with a text style in the drawing. Any text styles associated with a linetype must exist in the drawing before you load the linetype.
The format for linetypes that include embedded characters is similar to that for simple linetypes in that it is a list of pattern descriptors separated by commas.
Text in Custom Linetypes | 21
Character Descriptor Format
The format for adding text characters in a linetype description is as follows:
["text",textstylename,scale,rotation,xoffset,yoffset]
This format is added as a descriptor to a simple linetype. For example, a linetype called HOT_WATER_SUPPLY is defined as
*HOT_WATER_SUPPLY,---- HW ---- HW ---- HW ---- HW ---- HW
----
A,.5,-.2,["HW",STANDARD,S=.1,U=0.0,X=-0.1,Y=-.05],-.2
This indicates a repeating pattern starting with a dash 0.5 drawing units long, a space 0.2 drawing units long, the characters HW with some scale and placement parameters, and another space 0.2 drawing units long. The text characters come from the text font assigned to the STANDARD text style at a scale of 0.1, an upright rotation of 0 degrees, an X offset of -0.1, and a Y offset of -0.05. This pattern continues for the length of the line, ending with a dash
0.5 drawing units long. The linetype would be displayed as shown below.
Notice that the total upstroke length is 0.2 + 0.2 = 0.4 and that the text origin is offset -.01 units in the X direction from the end of the first upstroke. An equivalent linetype would be
*HOT_WATER_SUPPLY,---- HW ---- HW ---- HW ---- HW ---- HW
----
A,.5,-.1,["HW",STANDARD,S=.1,U=0.0,X=0.0,Y=-.05],-.3
The total upstroke is still 0.1 + 0.3 = 0.4, but the text origin is not offset in the X direction.
Additional information about each field in the character descriptor follows. The values to be used are signed decimal numbers such as 1, -17, and 0.01.
text The characters to be used in the linetype.
text style name The name of the text style to be used. If no text style is
specified, AutoCAD uses the currently defined style.
22 | Chapter 2 Custom Linetypes
scale S=value. The scale factor to be used for the text style relative to the scale of the linetype. The height of the text style is multiplied by the scale factor. If the height is 0, the value for S=value alone is used as the height.
rotation U=value, R=value, or A=value. U= specifies upright or easy-to-read text. R= specifies relative or tangential rotation with respect to the line. A= specifies absolute rotation of the text with respect to the origin; that is, all text has the same rotation regardless of its position relative to the line. The value can be appended with a d for degrees (degrees is the default value), r for radians, or g for grads. If rotation is omitted, 0 relative rotation is used.
Rotation is centered between the baseline and the nominal cap height.
NOTE Drawings containing legacy linetypes that do not use the U (upright) rotation flag can be updated to the latest linetype definition by reloading the linetype from the LIN files. Custom linetypes can be updated by changing the R (rotation) flag to the U (upright) flag prior to reloading a linetype definition. For information on loading a linetype, see Load Linetypes.
xoffset X=value. The shift of the text on the X axis of the linetype, which is along the line. If xoffset is omitted or is 0, the text is elaborated with no offset. Use this field to control the distance between the text and the previous pen-up or pen-down stroke. This value is not scaled by the scale factor defined by S=value, but it is scaled to the linetype.
yoffset Y=value. The shift of the text in the Y axis of the linetype, which is at a 90-degree angle to the line. If yoffset is omitted or is 0, the text is elaborated with no offset. Use this field to control the vertical alignment of the text with respect to the line. This value is not scaled by the scale factor defined by S=value, but it is scaled to the linetype.

Text in Custom Linetypes

To include text characters in linetypes
1 Create a simple linetype, as described in To add a simple linetype to a
LIN file (page 21).
2 Add the text character descriptor within the linetype pattern, using the
following format:
["text",textstylename,scale,rotation,xoffset,yoffset]
Text in Custom Linetypes | 23

Shapes in Custom Linetypes

A complex linetype can contain embedded shapes that are saved in shape files. Complex linetypes can denote utilities, boundaries, contours, and so on.
As with simple linetypes, complex lines are dynamically drawn as the user specifies vertices. Shapes and text objects embedded in lines are always displayed completely; they are never trimmed.
The syntax for complex linetypes is similar to that of simple linetypes in that it is a comma-delimited list of pattern descriptors. Complex linetypes can include shape and text objects as pattern descriptors, as well as dash-dot descriptors.
The syntax for shape object descriptors in a linetype description is as follows:
[shapename,shxfilename] or [shapename,shxfilename,transform]
where transform is optional and can be any series of the following (each preceded by a comma):
R=## Relative rotation
A=## Absolute rotation
U=## Upright rotation
S=## Scale
X=## X offset
Y=## Y offset
In this syntax, ## is a signed decimal number (1, -17, 0.01, and so on), the rotation is in degrees, and the remaining options are in linetype-scaled drawing units. The preceding transform letters, if they are used, must be followed by an equal sign and a number.
The following linetype definition defines a linetype named CON1LINE that is composed of a repeating pattern of a line segment, a space, and the embedded shape CON1 from the ep.shx file. (Note that the ep.shx file must be in the support path for the following example to work properly.)
*CON1LINE, --- [CON1] --- [CON1] --- [CON1] A,1.0,-0.25,[CON1,ep.shx],-1.0
Except for the code enclosed in square brackets, everything is consistent with the definition of a simple linetype.
24 | Chapter 2 Custom Linetypes
As previously described, a total of six fields can be used to define a shape as part of a linetype. The first two are mandatory and position-dependent; the next four are optional and can be ordered arbitrarily. The following two examples demonstrate various entries in the shape definition field.
[CAP,ep.shx,S=2,R=10,X=0.5]
The code above draws the CAP shape defined in the ep.shx shape file with a scale of two times the unit scale of the linetype, a tangential rotation of 10 degrees in a counterclockwise direction, and an X offset of 0.5 drawing units before shape elaboration takes place.
[DIP8,pd.shx,X=0.5,Y=1,R=0,S=1]
The code above draws the DIP8 shape defined in the pd.shx shape file with an X offset of 0.5 drawing units before shape drawing takes place, and a Y offset
of one drawing unit above the linetype, with 0 rotation and a scale equal to the unit scale of the linetype.
The following syntax defines a shape as part of a complex linetype.
[shapename,shapefilename,scale,rotate,xoffset,yoffset]
The definitions of the fields in the syntax follow.
shapename The name of the shape to be drawn. This field must be included. If it is omitted, linetype definition fails. If shapename does not exist in the specified shape file, continue drawing the linetype but without the embedded shape.
shapefilename The name of a compiled shape definition file (SHX). If it is omitted, linetype definition fails. If shapefilename is unqualified (that is, no path is specified), search the library path for the file. If shapefilename is fully qualified and not found at that location, remove the prefix and search the library path for the file. If it is not found, continue drawing the linetype but without the embedded shape.
scale S=value. The scale of the shape is used as a scale factor by which the shape's internally defined scale is multiplied. If the shape's internally defined scale is 0, the S=value alone is used as the scale.
rotate U=value, R=value or A=value. R= signifies relative or tangential rotation with respect to the line's elaboration. A= signifies absolute rotation of the shape with respect to the origin; all shapes have the same rotation regardless of their relative position to the line. The value can be appended with a d for degrees (if omitted, degree is the default), r for radians, or g for grads. If rotation is omitted, 0 relative rotation is used.
Shapes in Custom Linetypes | 25
NOTE Drawings containing legacy linetypes that do not use the U (upright) rotation
flag can be updated to the latest linetype definition by reloading the linetype from the LIN files. Custom linetypes can be updated by changing the R (rotation) flag to the U (upright) flag prior to reloading a linetype definition. For information on loading a linetype, see Load Linetypes.
xoffset X=value. The shift of the shape in the X axis of the linetype computed from the end of the linetype definition vertex. If xoffset is omitted or is 0, the shape is elaborated with no offset. Include this field if you want a continuous
line with shapes. This value is not scaled by the scale factor defined by S=.
yoffset Y=value. The shift of the shape in the Y axis of the linetype computed from the end of the linetype definition vertex. If yoffset is omitted or 0, the shape is elaborated with no offset. This value is not scaled by the scale factor
defined by S=.
See also:
Shapes and Shape Fonts (page 109)
26 | Chapter 2 Custom Linetypes

Custom Hatch Patterns

3
AutoCAD® provides a library of standard hatch patterns in the acad.pat and acadiso.pat files. You can use the hatch patterns as they are, modify them, or create your own custom hatch patterns.

Overview of Hatch Pattern Definitions

In addition to using the predefined hatch patterns that are supplied, you can design and create your own custom hatch patterns.
Developing a hatch pattern definition requires knowledge, practice, and patience. Because customizing hatches requires familiarity with hatch patterns, it is not recommended for new users.
The hatch patterns supplied by AutoCAD are stored in the acad.pat and acadiso.pat text files. You can add hatch pattern definitions to this file or create your own files.
Regardless of where the definition is stored, a custom hatch pattern has the same format. It has a header line with a name, which begins with an asterisk and is no more than 31 characters long, and an optional description:
*pattern-name, description
It also has one or more line descriptors of the following form:
angle, x-origin,y-origin, delta-x,delta-y,dash-1,dash-2, …
The default hatch pattern ANSI31 shown in the Boundary Hatch and Fill dialog box looks like this:
and is defined as follows:
27
*ANSI31, ANSI Iron, Brick, Stone masonry 45, 0,0, 0,.125
The pattern name on the first line, *ANSI31, is followed by a description: ANSI
Iron, Brick, Stone masonry. This simple pattern definition specifies a line
drawn at an angle of 45 degrees, that the first line of the family of hatch lines is to pass through the drawing origin (0,0), and that the spacing between hatch lines of the family is to be 0.125 drawing units.
Hatch pattern definitions follow these rules:
■ Each line in a pattern definition can contain up to 80 characters. You can
include letters, numbers, and the special characters underline (_), hyphen (-), and dollar sign ($). However, you must begin a pattern definition with a letter or number, not a special character.
■ AutoCAD ignores both blank lines and text to the right of a semicolon.
■ Each pattern line is considered to be the first member of a line family,
created by applying the delta offsets in both directions to generate an infinite family of parallel lines.
■ The delta-x value indicates the displacement between members of the family
in the direction of the line. It is used only for dashed lines.
■ The delta-y value indicates the spacing between members of the family;
that is, it is measured perpendicular to the lines.
■ A line is considered to be of infinite length. A dash pattern is superimposed
on the line.
NOTE A blank line must be placed after the last hatch pattern definition in a PAT file. If a blank line is not placed after the last hatch pattern definition, the last hatch pattern definition will not be accessible when creating a hatch fill.
The process of hatching consists of expanding each line in the pattern definition to its infinite family of parallel lines. All selected objects are checked for intersections with any of these lines; any intersections cause the hatch lines to be turned on and off as governed by the hatching style. Each family of hatch lines is generated parallel to an initial line with an absolute origin to guarantee proper alignment.
If you create a very dense hatch, AutoCAD may reject the hatch and display a message indicating that the hatch scale is too small or its dash length too short. You can change the maximum number of hatch lines by setting the MaxHatch environment variable using (setenv “MaxHatch” “n”) where n is a number between 100 and 10000000 (ten million).
28 | Chapter 3 Custom Hatch Patterns
NOTE When changing the value of MaxHatch, you must enter MaxHatch with
the capitalization as shown.

Overview of Hatch Pattern Definitions

To create a simple hatch pattern
1 Open the acad.pat or acadiso.pat file in a text editor that saves in ASCII
format.
2 Create a header line that includes an asterisk and a pattern name. The
name of the hatch pattern is limited to 31 characters.
3 (Optional) To include a description in the header line, follow the pattern
name with a comma and description text.
4 Create a descriptor line that includes
■ An angle at which the line is drawn
■ An X,Y origin point
■ A delta-x of 0
■ A delta-y of any value

Hatch Patterns with Dashed Lines

To define dashed-line patterns, you append dash-length items to the end of the line definition item.
To define dashed-line patterns, you append dash-length items to the end of the line definition item. Each dash-length item specifies the length of a segment making up the line. If the length is positive, a pen-down segment is drawn. If the length is negative, the segment is pen-up, and it is not drawn. The pattern starts at the origin point with the first segment and cycles through the segments in circular fashion. A dash length of 0 draws a dot. You can specify up to six dash lengths per pattern line.
The hatch pattern ANSI33, looks like this:
and is defined as follows:
Hatch Patterns with Dashed Lines | 29
*ANSI33, ANSI Bronze, Brass, Copper 45, .176776695,0, 0,.25, .125,-.0625
For example, to modify a pattern for 45-degree lines to draw dashed lines with a dash length of 0.5 units and a space between dashes of 0.5 units, the line definition would be
*DASH45, Dashed lines at 45 degrees 45, 0,0, 0,.5, .5,-.5
This is the same as the 45-degree pattern shown in Overview of Hatch Pattern
Definitions (page 27), but with a dash specification added to the end. The
pen-down length is 0.5 units, and the pen-up length is 0.5, meeting the stated objectives. If you wanted to draw a 0.5-unit dash, a 0.25-unit space, a dot, and a 0.25-unit space before the next dash, the definition would be
*DDOT45,Dash-dot-dash pattern: 45 degrees 45, 0,0, 0,.5, .5,-.25, 0,-.25
The following example shows the effect of delta-x specifications on dashed-line families. First, consider the following definition:
*GOSTAK 0, 0,0, 0,.5, .5,-.5
This draws a family of lines separated by 0.5, with each line broken equally into dashes and spaces. Because delta-x is zero, the dashes in each family member line up. An area hatched with this pattern would look like this:
Now change the pattern to
*SKEWED 0, 0,0, .5,.5, .5,-.5
It is the same, except that you have set delta-x to 0.5. This offsets each successive family member by 0.5 in the direction of the line (in this case, parallel to the X axis). Because the lines are infinite, the dash pattern slides down the specified amount. The hatched area would look like this:
30 | Chapter 3 Custom Hatch Patterns

Hatch Patterns with Dashed Lines

To create a hatch pattern with dashed lines
1 Open the acad.pat or acadiso.pat file in a text editor that saves in ASCII
format.
2 Create a header line that includes an asterisk and a pattern name. The
name of the hatch pattern is limited to 31 characters.
3 (Optional) To include a description in the header line, follow the pattern
name with a comma and description text.
4 Create a descriptor line that includes
■ An angle at which the line is drawn
■ An X,Y origin point
■ A delta-x of any value if you want to offset alternating lines in the line
family
■ A delta-y of any value
■ A value for a dash length
■ A value for a dot length
■ An optional second value for a different dash length
■ An optional second value for a different dot length

Hatch Patterns with Multiple Lines

Complex hatch patterns can have an origin that passes through offsets from the origin and can have multiple members in the line family.
Not all hatch patterns use origin points of 0,0. Complex hatch patterns can have an origin that passes through offsets from the origin and can have multiple members in the line family. In composing more complex patterns, you need to carefully specify the starting point, offsets, and dash pattern of each line family to form the hatch pattern correctly.
The hatch pattern AR-B816 looks like this:
and is defined as follows with multiple lines describing the pattern:
Hatch Patterns with Multiple Lines | 31
*AR-B816, 8x16 Block elevation stretcher bond 0, 0,0, 0,8 90, 0,0, 8,8, 8,-8
The following figure illustrates a squared-off, inverted-U pattern (one line up, one over, and one down). The pattern repeats every one unit, and each unit is 0.5 high and wide.
This pattern would be defined as follows:
*IUS,Inverted U's 90, 0,0, 0,1, .5,-.5 0, 0,.5, 0,1, .5,-.5 270, .5,.5, 0,1, .5,-.5
The first line (the up bar) is a simple dashed line with 0,0 origin. The second line (the top bar) should begin at the end of the up bar, so its origin is 0,.5. The third line (the down bar) must start at the end of the top bar, which is at .5,.5 for the first instance of the pattern, so its origin is at this point. The third line of the pattern could be the following:
90, .5,0, 0,1, .5,-.5
or
270, .5,1, 0,1, -.5,.5
The dashed pattern starts at the origin points and continues in the vector direction given by the angle specification. Therefore, two dashed-line families that are opposed 180 degrees are not alike. Two solid-line families are alike.
The following pattern creates six-pointed stars.
32 | Chapter 3 Custom Hatch Patterns
This example can help you refine your skills at pattern definition. (Hint: 0.866 is the sine of 60 degrees.)
The following is the AutoCAD definition of this pattern:
*STARS,Star of David 0, 0,0, 0,.866, .5,-.5 60, 0,0, 0,.866, .5,-.5 120, .25,.433, 0,.866, .5,-.5

Hatch Patterns with Multiple Lines

To create a hatch pattern with multiple lines
1 Open the acad.pat or acadiso.pat file in a text editor that saves in ASCII
format.
2 Create a header line that includes an asterisk and a pattern name. The
name of the hatch pattern is limited to 31 characters.
3 (Optional) To include a description in the header line, follow the pattern
name with a comma and description text.
4 Create a descriptor line that includes
■ An angle at which the line is drawn
■ An X,Y origin point
■ A delta-x of any value if you want to offset alternating lines in the
line family
■ A delta-y of any value
■ A value for a dash length
■ A value for a dot length
■ An optional second value for a different dash length
■ An optional second value for a different dot length
5 Create a second line including all the parameters in the previous step.
6 (Optional) Create additional lines to complete the multiple-line hatch
pattern.
Hatch Patterns with Multiple Lines | 33
34
User Interface Customiz­ation
4
When you work in the program, you use a variety of menus, tool sets, and shortcut menus to help you accomplish your tasks efficiently. You can also streamline your environment by customizing these elements.

Understand User Interface Customization

Using the customization tools of AutoCAD, you can tailor your drawing environment to suit your needs. The Customize dialog box helps you to easily create and modify the menus and tool sets that make up the user interface.

Overview of the Customization

Customization of the user interface is done with the Customize dialog box. From the Customize dialog box, you can
■ Create new custom commands or modify existing commands
■ Assign commands to various user interface elements
■ Add or change menus that are displayed on the Mac OS menu bar
■ Add or change tool sets that are displayed on the Tool Sets palette
Customizable User Interface Elements
The Customize dialog box allows you to create and manage commands that are used by the user interface. Along with commands, you are able to customize the following user interface elements
■ Menu bar menus
35
■ Tool sets

Customization Glossary

You should know several terms for customizing AutoCAD 2013.
Interface element An object that can be customized, such as a menu or tool set.
Interface item The individual parts of a user interface element, such as a menu item or tool set tool.
Macro A series of commands that are run in a defined sequence to accomplish a drawing task.
Palette A modeless interface element that can be docked or floating outside of the drawing area. Palettes include the Properties Inspector, Reference Manager, Command Line, and so on.
Tool set An interface element that displays tool groups made up of commands and flyouts (or drop-downs) that are displayed vertically outside the drawing area.
Tool group An organizational structure used to lay out commands and flyouts (or drop-downs) for display on the Tool Sets palette.

Customize Commands

Commands in the Customize dialog box are used to define custom macros which are used to start standard and custom commands which can be executed from the command prompt in AutoCAD.

Overview of Commands

You can easily create, edit, and reuse commands. The Commands tab of the Customize dialog box allows you to create and modify existing commands that can then be added to a user interface element.
When you change the properties of a command in the Commands list, the properties of the command are changed everywhere the command is referenced. Each property of a command in the Commands list controls which
36 | Chapter 4 User Interface Customization
actions are taken when the command is used and how the command looks when added to a user interface element.
The following table shows the properties of the Scale command as they appear in the Properties section.
Properties for the Scale command in the Commands list
ExampleDescriptionProperty
Name
or as a tooltip on the Tool Sets palette. The string must include alphanumeric characters with no punctuation other than a hyphen (-) or an under­score (_).
Description
Macro
String displayed as a tooltip when the cursor hovers over the tool on the Tool Sets palette.
macro syntax.
bitmap). The string must include alphanumeric characters with no punctuation other than a hyphen (-) or an underscore (_). It can also be a user-defined raster image file. Click the […] button to open the Select Image File dialog box.

Create, Edit, and Reuse Commands

ScaleString displayed as the caption of a menu item
Enlarges or reduces se­lected objects, keeping the proportions of the object the same after scaling
^C^C_scaleThe command macro. It follows the standard
RCDATA_16_SCALEID string of the small-image resource (16 × 16
You can create a new command from scratch, copy an existing command to create a new command, or edit the properties of an existing command.
When you change the properties of a command in the Commands list, the command is updated for all user interface elements that reference the command.
Customize Commands | 37
See also:
Create Macros (page 40)
Create, Edit, and Reuse Commands
To create a custom command
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Commands tab, click Create New Command
(+).
A new command (named Command1) is added to the Commands list and properties for the new command are displayed in the Properties section.
3 In the Properties section, do the following:
■ In the Name box, enter a name for the command.
The name is displayed in a tooltip on the Tool Sets palette and used as the caption for a menu item.
■ In the Description box, enter a description for the command.
The description is displayed in a tooltip on the Tool Sets palette.
■ In the Macro box, enter a macro for the command.
■ In the Image box, click the […] button to display the Select an Image
File dialog box. Select the raster image you want to assign to the command, it should be 16x16 pixels
To edit a command
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Commands tab, Commands list, select the
command to edit.
NOTE
When you make a change to a command, the change is applied to all instances of the command in all menus and tool sets.
3 In the Properties section, do any of the following to edit the command:
■ In the Name box, enter a name for the command.
38 | Chapter 4 User Interface Customization
The name is displayed in a tooltip on the Tool Sets palette and used
as the caption for a menu item.
■ In the Description box, enter a description for the command.
The description is displayed in a tooltip on the Tool Sets palette.
■ In the Macro box, enter a macro for the command.
■ In the Image box, click the […] button to display the Select an Image
File dialog box. Select the raster image you want to assign to the command, it should be 16x16 pixels
To delete a command
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Commands tab, Commands list, select the
command to delete.
NOTE
Commands assigned to a menu, tool set, shortcut key, or accelerator cannot be deleted.
3 Click the Options action menu below the Commands list, Gear icon,
and click Delete.
To duplicate a command
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Commands tab, Commands list, select the
command to duplicate.
3 Click the Options action menu below the Commands list, Gear icon,
and click Duplicate.
Make the desired changes to the new copy of the command.
To use a command
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, click the Menus or Tool Sets tab.
3 In the Commands list, locate the command you want to use and drag
it to the menu or tool set you want to add the command to.
Customize Commands | 39

Create Macros

A macro defines the action that results when an interface element is selected. A macro accomplishes a drawing task that would otherwise take a series of actions by a user.
Overview of Macros
A macro can contain commands, special characters, DIESEL (Direct Interpretively Evaluated String Expression Language) or AutoLISP programming code.
NOTE
As AutoCAD is revised and enhanced, the sequence of prompts for various commands (and sometimes command names) might change. Therefore, your custom macros might require minor changes when you upgrade to a new release of AutoCAD.
You add macros to interface elements by using the Customize dialog box. Select an existing command or create a new command in the Commands list on the Commands tab. Enter a macro in the Macros text box under the Properties section. There are no length limitations for macros. However, you do need to know how specific characters are used in macros and be aware of other considerations or limitations.
Macro Basics
A macro in a user interface element can be as simple as a command (such as circle) and some special characters (such as ^C^C).
For example, the macro ^C^C_circle \1, draws a circle with a radius of 1 unit. The components that define this macro are explained in the table below.
Components in CIRCLE macro
^C^C
ter
40 | Chapter 4 User Interface Customization
ResultComponent typeComponent
Cancels any running commandsSpecial control charac-
Components in CIRCLE macro
_
\
1
Special control charac­ter
Special control charac­ter
Special control charac­ter
Automatically translates the command that follows into other languages
Starts the CIRCLE commandCommandCIRCLE
Creates a pause for the user to specify the center point
Responds to the prompt for the circle's radius (1)
For a list of special control characters that you can use in macros, see Use
Special Control Characters in Macros (page 42).
Cancel Running Commands
Make sure that you have no AutoCAD commands in progress before you execute a macro. To automatically cancel a command before executing a macro, enter ^C^C at the beginning of the macro (which is the same as pressing ESC twice). Although a single ^C cancels most commands, ^C^C is required to return to the command prompt from a dimensioning command and ^C^C^C is required based on the current option of the -LAYER command. ^C^C handles canceling out of most command sequences and therefore is the recommended sequence used to ensure no command is active before the macro is started.
Verify Macro Characters
Every character in a macro is significant, even a blank space.
When you place a space at the end of the macro, AutoCAD processes the macro as though you had entered a command (circle, for example) and then pressed the Spacebar to complete the command.
Terminate Macros
Some macros require special terminators. Some commands (TEXT, for example) require you to press Enter rather than Spacebar to terminate the command. Some commands require more than one space (or Enter) to complete, but some text editors cannot create a line with trailing blanks.
Customize Commands | 41
Two special conventions resolve these problems.
■ A semicolon (;) in a macro automatically issues Enter at the Command
prompt.
■ If a line ends with a control character, a backslash (\), a plus sign (+), or a
semicolon (;), AutoCAD does not add a blank space after it.
An item that ends with a backslash (\) pauses a macro for user input.
Compare the following macros:
ucs ucs ;
The first example enters ucs at the command prompt and presses Spacebar. The following prompt is displayed.
Specify origin of UCS or [Face/NAmed/OBject/Previous/View/World/X/Y/Z/ZAxis] <World>:
The second example enters ucs, presses Spacebar, and presses Enter, which accepts the default value (World).
Suppress Echoes and Prompts in Macros
Characters in a macro appear at the command line as though you had typed the characters on the keyboard. This display duplication is called “echoing”. You can suppress the “echoed” displays with the MENUECHO system variable. If echoes and prompts from item input are turned off, a ^P in the item turns them off.
Use Special Control Characters in Macros
You can use special characters, including control characters, in macros. In a macro, the caret (^) is equivalent to pressing the Command key on the keyboard. You can combine the caret with another character to construct macros that do such things as turn the grid on and off (^G) or cancel a command (^C).
The macro for the Address command below uses the backslash (\) to pause for user input and the semicolon (;) for Enter.
text \.4 0 DRAFT Inc;;;Main St.;;;City, State;
42 | Chapter 4 User Interface Customization
The macro starts the TEXT command, pauses for the user to specify a start point, and then enters the address on three lines. In the triple semicolon (;;;), the first semicolon ends the text string, the second repeats TEXT, and the third accepts the default placement below the previous line.
Macros use the special characters listed in the following table.
Special characters used in macros
DescriptionCharacter
Issues Enter;
Issues Enter^M
Issues Tab^I
[blank space]
.
Enters a space; a blank space between command sequences in a com­mand is equivalent to pressing the Spacebar
Pauses for user input (cannot be used with accelerators)\
Allows you to access a built-in AutoCAD command even if it was un­defined using the UNDEFINE command.
Translates AutoCAD commands and options that follow_
Repeats a command until another command is chosen*^C^C
Introduces a conditional DIESEL macro expression ($M=)$
Turns Snap on or off (equivalent to Command-B)^B
Cancels the active command or command option (equivalent to Esc)^C
Turns Dynamic UCS on or off (equivalent to Control-D)^D
Sets the next isometric plane^E
Customize Commands | 43
Special characters used in macros
DescriptionCharacter
Turns Grid on or off (equivalent to Control-G)^G
Issues Backspace^H
Turns Ortho on or off^O
Turns MENUECHO on or off^P
Echoes all prompts, status listings, and input to the printer^Q
^R
^Z
Turns command versioning on or off. Command versioning is required for some commands to ensure command macros written in an older release work properly in the latest release.
Changes the current viewport^V
Null character that suppresses the automatic addition of Spacebar at the end of a command
Pause for User Input in Macros
To accept input from the keyboard or pointing device in the middle of a command, place a backslash (\) in the macro at the point where you want input.
circle \1
In the circle example, \1 pauses for the user to specify the center point and then reads a radius of 1. Note that there is no space after the backslash.
-layer off \;
44 | Chapter 4 User Interface Customization
In this example, the macro starts -LAYER at the Command prompt, enters the Off option (off), and then pauses for the user to enter a layer name (\). The macro then turns that layer off and exits the -LAYER command (;).
NOTE
LAYER normally prompts for another operation and exits only if you press Spacebar or Enter. In the macro, the semicolon (;) is the equivalent of pressing Enter.
A macro typically resumes after one user input, such as a single point location. Therefore, you cannot construct a macro that accepts a variable number of inputs (as in object selection) and then continues. However, an exception is made for SELECT: a backslash (\) suspends the SELECT command until object selection has been completed. Consider the following example:
select \change previous ;properties color red ;
In this macro, SELECT creates a selection set of one or more objects (select \). The macro then starts CHANGE (change), references the selection set using the Previous option (previous;), and changes the color of all selected objects to red (properties color red ;).
NOTE
The backslash character (\) causes a macro to pause for user input. You cannot use a backslash for any other purpose in a macro. When you need to specify a file directory path, use a forward slash (/) as the path delimiter: for example, /direct/file.
The following circumstances delay resumption of a macro after a pause:
■ If input of a point location is expected, object snap modes may be used
before the point is specified.
■ If X/Y/Z point filters are used, the command remains suspended until the
entire point has been accumulated.
■ For SELECT only, the macro does not resume until object selection has
been completed.
■ If the user responds with a transparent command, the suspended macro
remains suspended until the transparent command is completed and the originally requested input is received.
■ If the user responds by choosing another command (to supply options or
to execute a transparent command), the original macro is suspended, and
Customize Commands | 45
the newly selected item is processed to completion. Then, the suspended macro is resumed.
NOTE When command input comes from a command, the settings of the PICKADD and PICKAUTO system variables are assumed to be 1 and 0, respectively. This preserves compatibility with previous releases of AutoCAD and makes customization easier because you are not required to check the settings of these variables.
Provide International Support in Macros
To develop menus that can be used with a non-English-language version of AutoCAD, precede each command or option with the underscore character (_). The underscore character allows the standard commands and options to be translated automatically.
Use Built-in Commands in Macros
To develop macros that use built-in commands that are part of AutoCAD, precede each command with the period character (.). The period character allows the built-in command to be used even if it has been undefined with the UNDEFINE command making the macro predicable when it is used on other systems that share the same customization file.
Repeat Commands in Macros
You can use a leading asterisk (*) to repeat a command in a macro until you choose another command.
Once you have selected a command, you might want to use it several times before moving on to another command. In a macro, you can repeat a command until you choose another command. You cannot use this feature to choose options.
If a macro begins with *^C^C, the command is repeated until you terminate by pressing Esc on the keyboard or by selecting another command.
NOTE
Do not use ^C (Cancel) within a macro that begins with the string *^C^C; this cancels the repetition.
46 | Chapter 4 User Interface Customization
The macros in the following examples repeat the commands:
*^C^Cmove Single *^C^Ccopy Single *^C^Cerase Single *^C^Cstretch Single Crossing *^C^Crotate Single *^C^Cscale Single
Each macro in the example starts a command and then prompts you to select an object. Any other prompts necessary to complete the command are displayed, and then the command ends and starts again.
NOTE
Command repetition cannot be used in macros for image tile menus.
Use Single Object Selection Mode in Macros
Single Object Selection mode cancels the normal repetition of the Select Objects prompt in editing commands. After you select one object and respond to any other prompts, the command ends.
Consider the macro in the following example:
*^C^Cerase single
This macro terminates the current command and starts ERASE in Single Object Selection mode. After you choose this command, you either select a single object to be erased or click a blank area in the drawing and specify window selection. Any objects selected in this way are erased, and the command is repeated (due to the leading asterisk) so that you can erase additional objects. Press Esc to exit this mode.
Use Conditional Expressions in Macros
You can add conditional expressions to a macro by using a command that introduces macro expressions written in DIESEL (Direct Interpretively Evaluated String Expression Language).
The format is:
Customize Commands | 47
$M=expression
Introducing the macro with $M= tells AutoCAD to evaluate a string as a DIESEL expression, and that expression is the DIESEL expression. The following example defines a conditional expression in a macro:
FILLMODE $M=$(-,1,$(getvar,fillmode))
The macro switches the FILLMODE system variable on and off by subtracting the current value of FILLMODE from 1 and returning the resulting value to the FILLMODE system variable. You can use this method to toggle system variables whose valid values are 1 or 0.
Termination of Macros That Contain Conditional Expressions
If you use the DIESEL string language to perform “if-then” tests, conditions might exist where you do not want the normal terminating space or semicolon (resulting in Enter). If you add ^Z to the end of the macro, AutoCAD does not automatically add a space (Enter) to the end of the macro expression.
As with other control characters in commands, the ^Z used here is a string composed of ^ (a caret) and Z and is not equivalent to pressing Cmd-Z.
In the following examples, ^Z is used as a macro terminator.
^C^C$M=$(if,$(=,$(getvar,tilemode),0),$S=mview _mspace )^Z ^C^C$M=$(if,$(=,$(getvar,tilemode),0),$S=mview _pspace )^Z
If these macros did not end with ^Z, AutoCAD would automatically add a space (Enter), repeating the last command entered.
See also:
Use Special Control Characters in Macros (page 42)
DIESEL (page 63)
Use AutoLISP in Macros
Creating commands that use AutoLISP is a more advanced way to use the AutoCAD customization feature.
You can use AutoLISP variables and expressions to create macros that perform complex tasks. To use AutoLISP efficiently in macros, place AutoLISP code in
48 | Chapter 4 User Interface Customization
a separate MNL file. AutoCAD loads the MNL file when it loads a customization file with the same name and in the same location.
Creating commands that use AutoLISP is a more advanced way to use the AutoCAD customization feature. Carefully study the following examples and the information in the AutoLISP Reference and the AutoLISP Developer's Guide.
Preset Values
An application that uses block insertion presets could provide commands like these: [Set WINWID][Set WALLTHK][Insert Window]
^C^C^P(setq WINWID (getreal "Enter window width: ")) ^P ^C^C^P(setq WALLTHK (getreal "Enter wall thickness: ")) ^P ^C^C_INSERT window XScale !WINWID YScale !WALLTHK
This code inserts the block named “window,” scaling its X axis to the current window width and its Y axis to the current wall thickness. In this example, the actual values come from the user-defined AutoLISP symbols WINWID and WALLTHK. The rotation is up to the user to decide so that the window can be rotated in the wall.
Resize Grips
With the following commands, grip size adjustment can be done on the fly:
^P(setvar "gripsize"(1+ (getvar "gripsize")))(redraw)(princ) ^P(setvar "gripsize"(1- (getvar "gripsize")))(redraw)(princ)
To add validity checking to these commands, values less than 0 and greater than 255 cannot be used for the GRIPSIZE system variable.
Prompt for User Input
The following item prompts for two points and draws a rectangular polyline with the specified points as its corners.
^P(setq a (getpoint "Enter first corner: "));\+ (setq b (getpoint "Enter opposite corner: "));\+ pline !a (list (car a)(cadr b)) !b (list (car b)(cadr a))
c;^P
Customize Commands | 49

Control the Display of Command Items

The way a menu item is displayed indicates its availability in the program.
A menu item can be displayed as:
■ Grayed out (disabled)
■ Marked with a check marker or border
■ Both grayed out and marked
Gray Out (Disable) Menu Items
You gray out a menu item by doing one of the following:
■ Beginning a name with a tilde (~)
■ Using a DIESEL string expression
For more information about using DIESEL expressions, see DIESEL Expressions in Macros. When grayed out, the macro and submenus associated with the menu item are made inaccessible.
DIESEL string expressions are used to conditionally disable or enable a menu item each time they are displayed. For example, the DIESEL string expression in the Macro text box in the Properties section disables the MOVE command while any other command is active.
$(if,$(getvar,cmdactive),~)MOVE^C^C_move
Mark Menu Items
You can mark a menu item by doing one of the following:
■ Beginning a command name with an exclamation point and a period (!.)
■ Using a DIESEL string expression
A menu item is marked with or without a check mark.
Menu items can contain DIESEL string expressions to conditionally mark them each time they are displayed. When the following DIESEL string is added to the Macro text box for the applicable command in the Properties section on the Commands tab, a check mark is placed to the left of the menu item whose related system variable is currently enabled.
$(if,$(getvar,orthomode),!.)Ortho^O
50 | Chapter 4 User Interface Customization
$(if,$(getvar,snapmode),!.)Snap^B $(if,$(getvar,gridmode),!.)Grid^G
Simultaneously Disable and Mark Command Items
You can mark and disable commands at the same time using either of the following formats:
~!.labeltext !.~labeltext
The tilde (~) is the special character code to disable a command and an exclamation point and period (!.) is the special character code to mark a command.
See also:
DIESEL Expressions in Macros (page 63)

Create Tooltips for Commands

Tooltips are descriptive messages that are displayed near the cursor when it hovers over a tool set tool.
The Description property associated to a command provides a simple description for what the command does. The value of the Description property is displayed as part of a basic tooltip that is displayed when the cursor hovers over a tool set tool. Along with the description, the name of the command is also displayed.
See also:
Customize Commands (page 36)

Create and Manage Images for Commands

Images can be assigned to commands, and can be of two different types: standard and custom. Standard images come with AutoCAD in a library, while external raster images can be assigned to commands in the Customize dialog box.
Customize Commands | 51
Assign Images to a Command
Standard and custom images can be assigned to a command.
When a command is added to a tool set, the assigned image is displayed on the tool.
AutoCAD comes with a library of standard images that are used for the standard commands; these can be assigned to your own custom commands. You can create your own custom commands using an external image editor.
See also:
Customize Commands (page 36)

Customize User Interface Elements

User interface elements in the Customize dialog box are used to control how commands can be started.

Menus

Menus are displayed on the Mac OS menu bar and are used to organize commands by general task.
Overview of Menus
Each menu can contain both standard and custom commands. Commands can be grouped with separators and sub-menus. If a menu is longer than the current display resolution in the vertical direction, it is truncated to fit.
When a menu is truncated, two arrows are added to the menu; one is added at the top and another to the bottom. With the arrows, you can scroll through the list of menu items. Sub-menus areindicated on a menu by an arrow that points to the right. When using a sub-menu, it appears to the right of its associated menu item normally. If a sub-menu reaches the edge of the display, additional nested sub-menus will be displayed to the left of the menu item.
Menu items on the Mac OS menu bar are executed by clicking it. Unlike a menu item, you do not need to click a sub-menu to access the assigned menu
52 | Chapter 4 User Interface Customization
items. Position the cursor over the sub-menu to expand it and then click the menu item you want to use.
Create and Manage Pull-down Menus
You can create pull-down menus, and add commands and sub-menus for display on the Mac OS menu bar.
You can create and modify menus to display and organize the commands to best match the way you work. Commands are added to a menu from the Commands list in the Customize dialog box. Once commands are added to a menu, you can reposition commands, and organize commands using separators and sub-menus.
Sub-menus and Separators
Sub-menus are used to organize and group similar commands together. You create sub-menus in much the same way that you create a menu. Separators can also be inserted to group similar commands without adding an additional navigation level. There is no clear decision that can be made as to when you might use a sub-menu over a separator. Some possible reason why you might consider to use a sub-menu over a separator is the current length of the menu and how frequently a command might be used.
See also:
Customize Commands (page 36)
Create and Manage Pull-down Menus
To create a pull-down menu
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus List, select the menu
in which you want to create the new menu after.
3 Click the Create Menu Element (+) button below the Menus list and
click Add Menu.
A new menu (named Menu1) is created. The default name changes based on the number of menus you previously created.
4 Enter a name for the new menu.
Customize User Interface Elements | 53
The name entered is what will appear on the Mac OS menu bar. Click a menu name twice to rename it.
5 In the Commands list, drag a command to the new menu.
6 Release the button on the pointer device when the menu or sub-menu
is highlighted, or the desired location for the command is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To create a sub-menu
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus list, expand the menu
you want to add a sub-menu to.
3 Select the menu item you want to insert the new sub-menu after.
4 Click the Create Menu Element (+) button below the Menus list and
click Add Sub-menu.
A new sub-menu (named Sub-menu1) is created. The default name changes based on the number of sub-menus you previously created.
5 Enter a name for the new menu.
The name entered is what will appear on the Mac OS menu bar. Click a sub-menu name twice to rename it.
6 In the Commands list, drag a command to the new sub-menu.
7 Release the button on the pointer device when the menu or sub-menu
is highlighted, or the desired location for the command is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To add a command to a pull-down menu or sub-menu
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, click Menus tab.
3 In the Commands list, drag a command to the menu or sub-menu which
you want to add a command.
54 | Chapter 4 User Interface Customization
NOTE
If you hold the cursor over a menu or sub-menu, it will expand over a short interval of time.
4 Release the button on the pointer device when a menu or sub-menu is
highlighted, or the desired location for the command is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To change the display name for a pull-down menu, sub-menu, or command
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus list, select a menu,
sub-menu, or menu item so it is highlighted.
3 You need to click in the Display Name column to edit the name displayed
for a menu item.
4 Click the menu or menu item again to edit its name or display name.
5 Enter the new name and press Enter.
To insert a separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus list, select a sub-menu
or menu item to insert a separator after.
3 Click the Options action menu below the Menus list, Gear icon, and
click Insert Separator.
To duplicate a pull-down menu, sub-menu, command, or separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus list, select a menu,
sub-menu, command, or separator item to duplicate.
3 Click the Options action menu below the Menus list, Gear icon, and
click Duplicate.
4 Enter a new name for the duplicated item.
Customize User Interface Elements | 55
To delete a pull-down menu, sub-menu, command, or separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus list, select a menu,
sub-menu, command, or separator item to delete.
3 Click the Options action menu below the Menus list, Gear icon, and
click Delete.
NOTE
Be careful which item is selected because you cannot undo the deletion of the item. Click Cancel to abort the changes you made.
To reposition a pull-down menu, sub-menu, command, or separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Menus tab, Menus list, select a menu,
sub-menu, command, or separator item to reposition.
3 Click and drag the selected item to its new location in the Menus list.
4 Release the button on the pointer device when the menu or sub-menu
is highlighted, or the desired location for the command is indicated by a horizontal line.

Tool Sets

You can customize the Tool Sets palette by creating and modifying tool sets and tool groups.
Overview of Tool Sets and Tool Groups
Tool Sets are made up of tool groups that contain tools. A tool can be either a command or flytout (also known as a drop-down). Tool sets are accessed from the Tool Sets palette. Each tool group is a maximum of two tools wide and has two different display states: collapsed and expanded.
Position the cursor over a tool on the Tool Sets palette and click to use it. If the tool is a flyout (or drop-down), click and hold the button on the pointer device, and release over the tool you want to use.
56 | Chapter 4 User Interface Customization
Tools are not the only interactions that you will interact on the Tool Sets palette. When the cursor is positioned over a tool group, a disclosure triangle might appear that indicates the tool group can be expanded. Click the disclosure triangle to expand the panel to access additional tools. After a tool group is expanded, click the Lock icon to keep the tool group from collapsing.
See also:
Customize Commands (page 36)
Create and Manage Tool Sets
Tool sets are created to organize tool groups on the Tool Sets palette. AutoCAD comes with three tool sets that are used to organize drafting, annotation, and modeling tools. You create and manage tool sets on the Tool Sets tab of the Customize dialog box. After a tool set is created, you click the Tool Sets button near the top of the Tool Sets palette to set it current and use the commands and flyouts (drop-downs) assigned to it.
Tool Groups
Tool sets are often made up of multiple tool groups which are used to organize commands and flyouts (drop-downs). Each tool group is divided into two different parts, commands that are displayed by default and those that are displayed when the tool group is expanded.
You insert a separator to divide a tool group into the two parts, by default a tool group is not divided. Tools above the separator are those displayed by default. When using the Tool Sets palette, click the disclosure triangle to expand a tool group so you can access the tools that are hidden by default. Click the Lock icon when the tool group is expanded to keep the tool group from collapsing.
The order tool groups are displayed on the Tool Sets palette are controlled by the Customize dialog box. Drag a tool set up or down on the Tool Sets tab to change the order it appears on the Tool Sets palette.
Flyouts and Separators
Flyouts (or drop-downs) are used to help reduce the amount of space that related commands take up. Commands on a flyout are displayed by pressing and holding the button to display a menu with all the commands assigned
Customize User Interface Elements | 57
to the flyout. Release the button over a tool from the flyout to execute the associated macro.
Separators can be added to a flyout to help provide an additional level of organize. When a separator is added to a flyout, a solid horizontal line is created across the flyout when it is displayed. A separator can be added to a tool group, but it is used to control which commands and flyouts are displayed by default and those that are available only when the tool group is expanded.
See also:
Customize Commands (page 36)
Create and Manage Tool Sets
To create a tool set
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, select the tool
set in which you want to create the new tool set after.
3 Click the Create Tool Set Element (+) button below the Tool Sets list and
click Add Tool Set.
A new tool set (named Tool Set1) is created. The default name changes based on the number of tool sets you previously created.
4 Enter a name for the new tool set.
The name entered is what will appear on drop-down menu when the Tool Sets button is clicked near the top of the Tool Sets palette. Click a tool set name twice to rename it.
5 Expand the new tool set.
6 In the Commands list, drag a command to the default tool group under
the new tool set.
7 Release the button on the pointer device when the tool group or flyout
is highlighted, or the desired location for the command is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To create a tool group
1 At the Command prompt, enter cui and press Enter.
58 | Chapter 4 User Interface Customization
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, expand the
tool set you want to add a tool group to.
3 Select the tool group you want to insert the new tool group after.
4 Click the Create Tool Set Element (+) button below the Tool Sets list and
click Add Tool Group.
A new panel (named Panel1) is created. The default name changes based on the number of panels you previously created.
5 Enter a name for the new tool group.
The name entered is displayed on the title bar of the tool group when it is expanded.
6 In the Commands list, drag a command to the new tool group.
7 Release the button on the pointer device when the tool group or flyout
is highlighted, or the desired location is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To create a flyout
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, expand the
tool set and then the tool group you want to add a flyout to.
3 Select the command or flyout you want to insert the new flyout after.
4 Click the Create Tool Set Element (+) button below the Tool Sets list and
click Add Drop-down.
A new flyout (named Drop-down1) is created. The default name changes based on the number of flyouts you previously created.
5 Enter a name for the new flyout.
The name entered is not displayed on the Tool Sets palette.
6 In the Commands list, drag a command to the new flyout.
7 Release the button on the pointer device when the flyout is highlighted,
or the desired location is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To add a command to a tool group or flyout
1 At the Command prompt, enter cui and press Enter.
Customize User Interface Elements | 59
2 In the Customize dialog box, click Tool Sets tab.
3 In the Commands list, drag a command to the tool group or flyout which
you want to add a command.
NOTE
If you hold the cursor over a tool group or flyout, it will expand after a short interval of time.
4 Release the button on the pointer device when a tool group or flyout is
highlighted, or the desired location is indicated by a horizontal line.
For information about creating a command, see Create, Edit, and Reuse
Commands (page 37).
To insert a separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, select a tool
group, flyout, or command to insert a separator after.
3 Click the Options action menu below the Tool Sets list, Gear icon, and
click Insert Separator.
To duplicate a tool group, flyout, command, or separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, select a tool
group, flyout, command, or separator to duplicate.
3 Click the Options action menu below the Tool Sets list, Gear icon, and
click Duplicate.
4 Enter a new name for the duplicated item.
To delete a tool group, flyout, command, or separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, select a tool
group, flyout, command, or separator to delete.
3 Click the Options action menu below the Tool Sets list, Gear icon, and
click Delete.
60 | Chapter 4 User Interface Customization
NOTE
Be careful which item is selected because you cannot undo the deletion of the item. Click Cancel to abort the changes you made.
To reposition a tool group, flyout, command, or separator
1 At the Command prompt, enter cui and press Enter.
2 In the Customize dialog box, Tool Sets tab, Tool Sets list, select a tool
group, flyout, command, or separator to reposition.
3 Click and drag the selected item to its new location in the Tool Sets list.
4 Release the button on the pointer device when the tool group or flyout
is highlighted, or the desired location is indicated by a horizontal line.
Customize User Interface Elements | 61
62

DIESEL

5
Expressions in DIESEL (Direct Interpretively Evaluated String Expression Language) take strings as input and generate string results. DIESEL can be used in menu macros to make complex decisions.
You can also use DIESEL in menu items as a macro language instead of AutoLISP®. DIESEL expressions accept strings and generate string results.
Because DIESEL expressions handle strings exclusively, the USERS1-5 system variables are useful for passing information from an AutoLISP routine to a DIESEL expression. DIESEL expressions are evaluated by AutoLISP routines through the use of the AutoLISP menucmd function.

DIESEL Expressions in Macros

You can use DIESEL string expressions in customization (CUIx) files as an additional method of creating macros.
These expressions can return string values (text strings) in response to standard AutoCAD commands, AutoLISP and ObjectARX® routines, and other macros. They can also return string values to the menu itself, thereby altering the appearance or content of a menu label.
A DIESEL expression that you use in a menu item must follow the
$section=submenu format where the section name is M and the submenu is the
DIESEL expression you want. Frequently, you can implement a macro more easily with AutoLISP.
The following examples show two menu items that produce the same result; one uses DIESEL, and the other uses AutoLISP.
This menu item uses the DIESEL expression:
^C^C^P$M=$(if,$(=,$(getvar,cvport),1),mspace,pspace)
63
This menu item uses the AutoLISP expression:
^C^C^P(if (= (getvar "cvport") 1)(command "mspace")+ (command "pspace"))(princ) ^P
Both menu items provide a way to switch between paper space and model space (if TILEMODE is set to 0), but the DIESEL expression is shorter and is evaluated transparently, not requiring the call to the AutoLISP princ function. If the special character ^P (which switches MENUECHO on and off) is omitted in both cases, the DIESEL expression displays only the issued command, whereas the AutoLISP expression displays the entire line of code.
Because the value returned by a DIESEL expression is a text string, it can be used in response to an AutoLISP getxxx function call. This functionality enables menu items to evaluate current drawing conditions and to return a value to an AutoLISP routine.
The next example is based on these assumptions:
■ The AutoLISP routine is loaded into memory.
■ The CUIx excerpt is included in the current customization file.
■ The symbols to insert are one unit high by one unit wide.
■ The DIMSCALE variable is set to the drawing's scale factor (that is, a drawing
to be plotted at a scale of 1" = 10' would have a scale factor of 120, or a 1/4" = 1' scale drawing would have a scale factor of 48).
If you load and execute the sample AutoLISP routine, AutoCAD inserts the symbol at the size and location you have specified. When plotted, the symbols are the specified size (if the drawing is plotted at the same scale as that specified by DIMSCALE).
The following is a sample AutoLISP routine.
(defun C:SYMIN ( )
(setq sym
(getstring
) ; Display the custom toolbar named Symsize (command "._-toolbar" "SymSize" "_show") (setq
siz (getreal
size
p1 (getpoint
64 | Chapter 5 DIESEL
"\nEnter symbol name: ") ; Prompts for a symbol name
"\nSelect symbol size: ") ; Prompts for a symbol
"\nInsertion point: ") ; Prompts for insertion
point
)
(command "._insert" ; Issues the INSERT command
sym ; using the desired symbol
p1 siz siz 0) ; insertion point, and size ; Hide the custom toolbar named Symsize (command "._-toolbar" "SymSize" "_hide") (princ) ; Exits quietly
)
NOTE
An AutoLISP routine that you use regularly should include error checking to verify the validity of user input.
The DIESEL expressions in the following example multiply the current value of DIMSCALE by the specified value, and return an appropriate scale factor.
This cannot be done with similar AutoLISP code; a value returned by an AutoLISP expression cannot typically be used as a response to a getxxx function call (such as, the getreal function in the preceding sample).
$M=$(*,$(getvar,dimscale),0.375) $M=$(*,$(getvar,dimscale),0.5) $M=$(*,$(getvar,dimscale),0.625)
DIESEL expressions can also return string values to pull-down menu item labels, so that you can make menus unavailable or otherwise alter the way they are displayed. To use a DIESEL expression in a pull-down menu label, make sure that the first character is the $ character.
In the next example, the current layer is set to BASE and the following DIESEL expression is used as the label.
$(eval,"Current layer: " $(getvar,clayer))
The result is that the appropriate pull-down menu is displayed and updated whenever the current layer changes.
Current Layer: BASE
You can also use this method to interactively change the text displayed in a pull-down menu. You use an AutoLISP routine that sets the USERS1-5 system variables to the selected text, which can be retrieved by a DIESEL macro in a menu label.
DIESEL Expressions in Macros | 65
NOTE The width of pull-down and shortcut menus is determined when the
customization file is being loaded. Menu labels generated or changed by DIESEL expressions after a menu is loaded are truncated to fit within the existing menu width.
If you anticipate that a DIESEL-generated menu label will be too wide, you can use the following example to ensure that the menu width will accommodate your labels. This example displays the first 10 characters of the current value of the USERS3 (USERS1-5) system variable.
$(eval,"Current value: " $(getvar,users3))+
$(if, $(eq,$(getvar,users3),""), 10 spaces )^C^Cusers3
You cannot use trailing spaces in a menu label to increase the menu width, because trailing spaces are ignored while the menu is being loaded. Any spaces you use to increase the width of a menu label must be within a DIESEL expression.
The next example uses the same DIESEL expression as the label and a portion of the menu item. It provides a practical way to enter the current day and date into a drawing.
$(edtime,$(getvar,date),DDD", "D MON YYYY)^C^Ctext + \\\ $M=$(edtime,$(getvar,date),DDD", "D MON YYYY);
Also, you can use a DIESEL macro to mark pull-down menu labels or make them unavailable. The following pull-down menu label displays an unavailable ERASE while a command is active. The text is displayed normally when a command is not active.
$(if,$(getvar,cmdactive),~)ERASE
You can use a similar approach to place a mark beside a pull-down menu item or to interactively change the character used for the mark.

Catalog of DIESEL Functions

Status retrieval, computation, and display are performed by DIESEL functions. All functions have a limit of 10 parameters, including the function name itself. If this limit is exceeded, you get a DIESEL error message.

+ (addition)

Returns the sum of the numbers val1, val2, …, val9.
66 | Chapter 5 DIESEL
$(+, val1 [, val2, …, val9])
If the current thickness is set to 5, the following DIESEL string returns 15.
$(+, $(getvar,thickness),10)

- (subtraction)

Returns the result of subtracting the numbers val2 through val9 from val1.
$(-, val1 [, val2 , …, val9])

* (multiplication)

Returns the result of multiplying the numbers val1, val2, …, val9.
$(*, val1 [, val2, …, val9])

/ (division)

Returns the result of dividing the number val1 by val2, …, val9.
$(/, val1 [, val2, …, val9])

= (equal to)

If the numbers val1 and val2 are equal, the string returns 1; otherwise, it returns
0.
$(=, val1, val2)

< (less than)

If the number val1 is less than val2, the string returns 1; otherwise, it returns
0.
$(<, val1, val2)
Catalog of DIESEL Functions | 67
The following expression gets the current value of HPANG; if the value is less than the value stored in the system variable USERR1, it returns 1. If the value
10.0 is stored in USERR1 and the current setting of HPANG is 15.5, the following string returns 0.
$(<, $(getvar,hpang),$(getvar,userr1))

> (greater than)

If the number val1 is greater than val2, the string returns 1; otherwise, it returns
0.
$(>, val1, val2)

!= (not equal to)

If the numbers val1 and val2 are not equal, the string returns 1; otherwise, it returns 0.
$(!=, val1, val2)

<= (less than or equal to)

If the number val1 is less than or equal to val2 , the string returns 1; otherwise, it returns 0.
$(<=, val1, val2)

>= (greater than or equal to)

If the number val1 is greater than or equal to val2, the string returns 1; otherwise, it returns 0.
$(>=, val1, val2)
68 | Chapter 5 DIESEL
and
Returns the bitwise logical AND of the integers val1 through val9.
$(and, val1 [, val2,…, val9])

angtos

Returns the angular value in the format and precision specified.
$(angtos, value [, mode, precision])
Edits the given value as an angle in the format specified by the mode and precision as defined for the analogous AutoLISP function. (The values for mode are shown in the following table.) If mode and precision are omitted, it uses the current values chosen by the UNITS command.
Angular units values
String formatMode value
Degrees0
Degrees/minutes/seconds1
Grads2
Radians3
Surveyor's units4

edtime

Returns a formatted date and time based on a given picture.
$(edtime, time, picture)
Edits the AutoCAD Julian date given by time (obtained, for example, from
$(getvar,date) according to the given picture). The picture consists of format
Catalog of DIESEL Functions | 69
phrases replaced by specific representations of the date and time. Characters not interpretable as format phrases are copied literally into the result of
$(edtime). Format phrases are defined as shown in the following table. Assume
that the date and time are Saturday, 5 September 1998 4:53:17.506.
edtime format phrases
OutputFormatOutputFormat
4H5D
04HH05DD
53MMSatDDD
17SSSaturdayDDDD
506MSEC9M
AMAM/PM09MO
amam/pmSepMON
Enter the entire AM/PM phrase as shown in the preceding table; if AM is used alone, the A will be read literally and the M will return the current month.
If any AM/PM phrases appear in the picture, the H and HH phrases edit the time according to the 12-hour civil clock (12:00-12:59 1:00-11:59) instead of the 24-hour clock (00:00-23:59).
The following example uses the date and time from the preceding table. Notice that the comma must be enclosed in quotation marks because it is read as an argument separator.
$(edtime, $(getvar,date),DDD"," DD MON YYYY - H:MMam/pm)
70 | Chapter 5 DIESEL
AA/PSeptemberMONTH
aa/p98YY
1998YYYY
It returns the following:
Sat, 5 Sep 1998 - 4:53am
If time is 0, the time and date at the moment that the outermost macro was executed is used. This avoids lengthy and time-consuming multiple calls on
$(getvar,date) and guarantees that strings composed with multiple $(edtime)
macros all use the same time.
eq
If the strings val1 and val2 are identical, the string returns 1; otherwise, it returns 0.
$(eq, val1, val2)
The following expression gets the name of the current layer; if the name matches the string value, it returns 1.
$(eq,"PART12",$(getvar,clayer))
Returns 1

eval

Passes the string str to the DIESEL evaluator and returns the result of evaluating it.
$(eval, str)
fix
Truncates the real number value to an integer by discarding any fractional part.
$(fix, value)

getenv

Returns the value of the environment variable varname.
$(getenv, varname)
Catalog of DIESEL Functions | 71
If no variable with that name is defined, it returns the null string.

getvar

Returns the value of the system variable with the given varname.
$(getvar, varname)
if
Conditionally evaluates expressions.
$(if, expr, dotrue [, dofalse])
If expr is nonzero, it evaluates and returns dotrue. Otherwise, it evaluates and returns dofalse. Note that the branch not chosen by expr is not evaluated.

index

Returns the specified member of a comma-delimited string.
$(index, which, string)
Assumes that the string argument contains one or more values delimited by the macro argument separator character, the comma. The which argument selects one of these values to be extracted, with the first item numbered 0.
This function is most frequently used to extract X, Y, or Z coordinate values from point coordinates returned by $(getvar).
Applications can use this function to retrieve values stored as comma-delimited strings from the USERS1-5 system variables.
nth
Evaluates and returns the argument selected by which.
$(nth, which, arg0 [, arg1,…, arg7])
72 | Chapter 5 DIESEL
If which is 0, nth returns arg0, and so on. Note the difference between $(nth) and $(index); $(nth)returns one of a series of arguments to the function, while
$(index) extracts a value from a comma-delimited string passed as a single
argument. Arguments not selected by which are not evaluated.
or
Returns the bitwise logical OR of the integers val1 through val9.
$(or, val1 [, val2,…, val9])

rtos

Returns the real value in the format and precision specified.
$(rtos, value [, mode, precision])
Edits the given value as a real number in the format specified by the mode and
precision as defined by the analogous AutoLISP function. If mode and precision
are omitted, it uses the current values selected with the UNITS command.

strlen

Returns the length of string in characters.
$(strlen, string)

substr

Returns the substring of string, starting at character start and extending for
length characters.
$(substr, string, start [, length])
Characters in the string are numbered from 1. If length is omitted, it returns the entire remaining length of the string.
Catalog of DIESEL Functions | 73

upper

Returns the string converted to uppercase according to the rules of the current locale.
$(upper, string)
xor
Returns the bitwise logical XOR of the integers val1 through val9.
$(xor, val1 [, val2,…, val9])

DIESEL Error Messages

Generally, if you make a mistake in a DIESEL expression, what went wrong will be obvious. Depending on the nature of the error, DIESEL embeds an error indication in the output stream.
DIESEL error messages
DescriptionError message
$?
74 | Chapter 5 DIESEL
Syntax error (usually a missing right parenthesis or a runaway string)
Incorrect arguments to func$(func,??)
Unknown function func$(func)??
Output string too long—evaluation truncated$(++)

Command Scripts

6
A script reads and executes commands from a text file.
You can run a script when you start AutoCAD®, or you can run a script from within AutoCAD using the SCRIPT command.

Create Command Scripts

A script is a text file that contains a series of commands. Common uses for scripts are to customize startup and to automate repetitive tasks.

Overview of Command Scripts

A script is a text file with one command on each line.
You can invoke a script at startup, or you can run a script during a work session by using the SCRIPT command. A script also provides an easy way to create continuously running displays for product demonstrations and trade shows.
You create script files outside the program using a text editor (such as TextEdit) that can save the file in ASCII format. The file extension must be .scr.
Each line of the script file contains a command. Each blank space in a script file is significant because Spacebar is accepted as a command or data field terminator. You must be very familiar with the sequence of prompts to provide an appropriate sequence of responses in the script file.
NOTE Keep in mind that prompts and command names may change in future releases, so you may need to revise your scripts when you upgrade to a later version of this program. For similar reasons, avoid the use of abbreviations; future command additions might create ambiguities.
75
A script can execute any command at the command prompt except a command that displays a dialog box. In most cases, a command that displays a dialog box has an alternative version of the command that displays command prompts instead of a dialog box.
Script files can contain comments. Any line that begins with a semicolon (;) is considered a comment, and it is ignored while the script file is being processed. The last line of the file must be blank.
All references to long file names that contain embedded spaces must be enclosed in double quotes. For example, to open the drawing my house.dwg from a script, you must use the following syntax:
open "my house"
The following commands are useful in scripts:
'DELAY Provides a timed pause within a script (in milliseconds)
RESUME Continues an interrupted script
RSCRIPT Repeats a script file
When command input comes from a script, it is assumed that the settings of the PICKADD and PICKAUTO system variables are 1 and 0, respectively; therefore, you do not have to check the settings of these variables.
A script is treated as a group, a unit of commands, reversible by a single U command. However, each command in the script causes an entry in the undo log, which can slow script processing. If you like, you can use UNDO Control None to turn off the undo feature before running the script, or you can write it at the beginning of the script itself. Remember to turn it back on (UNDO Control All) when the script is finished.
The script that is running stops when another script command is invoked.
Overview of Command Scripts
To create a script that changes settings in a drawing
This script turns on the grid, sets the global linetype scale to 3.0, and sets layer 0 as the current layer with red as the color.
1 In a text editor, enter grid on.
2 On the next line, enter ltscale 3.0.
3 On the next line, enter layer set 0 color red 0.
76 | Chapter 6 Command Scripts
4 Add a blank line.
5 Save the file as ASCII text (TXT file), with a file extension of .scr.
The script file may contain comments, as follows:
; Turn grid on grid on ; Set scale for linetypes ltscale 3.0 ; Set current layer and its color layer set 0 color red 0
; Blank line above to end LAYER command

Run Scripts at Startup

A script that runs at startup can open a drawing and change its settings.
Suppose that every time you begin a new drawing, you turn on the grid, set the global linetype scale to 3.0, and set layer 0 as your current layer, with red as the color. You can do this using a drawing template, but you could do it instead with the following script and store it in a text file called setup.scr.
grid on ltscale 3.0 layer set 0 color red 0
The first line turns on the grid. The second line sets the global scale for linetypes. The third line sets the current layer to layer 0 and sets its default color to red. AutoCAD assumes that in a script you want to use the version of LAYER command that displays command prompts rather than the palette version. The result is equivalent to entering -layer at the command prompt. The fourth line is blank, ending LAYER.
You could run a script at startup to open a drawing by using the following syntax in a Terminal window:
AutoCAD drawing_name -b setup
All file names that contain embedded spaces must be enclosed in double quotes, for example, “guest house”.
Including the file extensions .app, .dwg, .dwt, and .scr is optional. If AutoCAD cannot find the script file, AutoCAD reports that it cannot open the file.
Create Command Scripts | 77
To run the same script at startup but create a new drawing using the MyTemplate.dwt file as the template, enter the following in a Terminal window:
AutoCAD -t MyTemplate -b setup
This command creates a new drawing and issues a sequence of setup commands from the setup.scr file. When the script has finished running, the command prompt is displayed.
If you want to use the default template for the new drawing, you can omit the -t switch and the template file name.
Run Scripts at Startup
To run a script at startup
1 Click local drive ➤ Applications ➤ Utilities ➤ Terminal.
2 In the Terminal window, enter AutoCAD drawing_name -b
script_name.
NOTE AutoCAD listed above is the path to the AutoCAD executable. By default it is located at:
/Applications/Autodesk/<release>/AutoCAD.app/Contents/MacOS/AutoCAD
To start a new file, instead of a drawing file name, enter the -t switch and the name of a template file: -t template_drawing.
The name of the script file must be the last parameter listed. The file extensions are optional.
3 Press Enter.
AutoCAD opens the drawing and executes the commands in the script file. When the script has been completed, the Command prompt is displayed.
78 | Chapter 6 Command Scripts
Introduction to Program­ming Interfaces

AutoLISP

AutoLISP is based on the LISP programming language, which is simple to learn and very powerful. Because AutoCAD has a built-in LISP interpreter, you can enter AutoLISP code at the command prompt or load AutoLISP code from external files.

Overview of AutoLISP

AutoLISP is an application interface in AutoCAD that automating of design tasks. When an AutoLISP application or routine is loaded, it functions in its own namespace for each drawing that is open. A namespace is an insulated environment keeping AutoLISP routines that are specific to one drawing from having symbol or variable name and value conflicts with those in another drawing. For example, the following line of code sets a different value to the symbol a for different documents.
7
(setq a (getvar "DWGNAME"))
AutoLISP applications or routines can interact with AutoCAD in many ways. These routines can prompt the user for input, access built-in AutoCAD commands directly, and modify or create objects in the drawing database. By creating AutoLISP routines you can add discipline-specific commands to AutoCAD. Some of the standard AutoCAD commands are actually AutoLISP applications.
79
AutoLISP provides two file formats for applications:
■ Reading an LSP file (.lsp)—an ASCII text file that contains AutoLISP program
code.
■ Reading an FAS file (.fas)—a binary, compiled version of a single LSP
program file.
NOTE
Like-named AutoLISP application files are loaded based on their Modified time stamp; the LSP or FAS file with the most recent time stamp is loaded unless you specify the full file name (including the file name extension).
Because AutoCAD can read AutoLISP code directly, no compiling is required. This makes AutoLISP an easy language to experiment with, regardless of your programming experience.
Even if you are not interested in writing AutoLISP applications, your AutoCAD package includes many useful routines. Routines are also available as shareware through third-party developers. Knowing how to load and use these routines can enhance your productivity.
NOTE When command input comes from the AutoLISP command function, the settings of the PICKADD and PICKAUTO system variables are assumed to be 1 and 0, respectively. This preserves compatibility with previous releases of AutoCAD and makes customization easier (because you don't have to check the settings of these variables).
For information about AutoLISP programming, see the AutoLISP Developer's Guide, and for information about AutoLISP, see the AutoLISP Reference in the
Help system.

Use AutoLISP Applications

AutoLISP applications are stored in ASCII text files that you can edit. Before you can use an AutoLISP application, it must first be loaded.
AutoLISP applications are stored in ASCII text files with the .lsp extension. These files generally have a header portion that describes a routine, its use, and any specific instructions. This header might also include comments that document the author and the legal information regarding the use of the routine. Comments are preceded by a semicolon (;). You can view and edit these files with a text editor or word processor that can produce an ASCII text file.
80 | Chapter 7 Introduction to Programming Interfaces
Before you can use an AutoLISP application, it must first be loaded. You can use the APPLOAD command or the AutoLISP load function to load an application. Loading an AutoLISP application loads the AutoLISP code from the LSP file into your system's memory.
Loading an application with the load function involves entering AutoLISP code at the command prompt. If the load function is successful, it displays the value of the last expression in the file at the command prompt. This is
usually the name of the last function defined in the file or instructions on using the newly loaded function. If load fails, it returns an AutoLISP error message. A load failure can be caused by incorrect coding in the file or by entering the wrong file name at the command prompt. The syntax for the
load function is
(load
filename
[onfailure]
)
This syntax shows that the load function has two arguments: filename, which is required, and onfailure, which is optional. When loading an AutoLISP file at the command prompt, you typically supply only the filename argument. The following example loads the AutoLISP file newfile.lsp.
Command: (load "newfile")
The .lsp extension is not required. This format works for any LSP file in the current library path.
To load an AutoLISP file that is not in the library path, you must provide the full path and file name as the filename argument.
Command: (load "/files/morelisp/newfile")
NOTE When specifying a directory path, you must use a slash (/) or two backslashes (\\) as the separator, because a single backslash has a special meaning in AutoLISP.
See also:
Overview of File Organization (page 3)
AutoLISP | 81

Automatically Load and Run AutoLISP Routines

You can load AutoLISP routines each time you run AutoCAD. You can also execute certain commands or functions at specific times during a drawing session.
Overview of AutoLISP Automatic Loading
AutoCAD loads the contents of two user-definable files automatically: acad.lsp and acaddoc.lsp.
By default, the acad.lsp file is loaded only once, when AutoCAD starts, whereas acaddoc.lsp is loaded with each individual document (or drawing). This lets you associate the loading of the acad.lsp file with application startup, and the acaddoc.lsp file with document (or drawing) startup. The default method for loading these startup files can be modified by changing the setting of the ACADLSPASDOC system variable.
If one of these files defines a function of the special type S::STARTUP, this routine runs immediately after the drawing is fully initialized. The S::STARTUP function is described in S::STARTUP Function: Postinitialization Execution
(page 86). As an alternative, the APPLOAD command provides a Startup Suite option that loads the specified applications without the need to edit any files.
The acad.lsp and acaddoc.lsp startup files are not provided with AutoCAD. It is up to the user to create and maintain these files.
Command Autoloader
When you load an AutoLISP file, the command definitions in the file take up memory whether or not you actually use the commands. The AutoLISP
autoload function makes a command available without loading the entire
routine into memory. Adding the following code to your acaddoc.lsp file automatically loads the commands CMD1, CMD2, and CMD3 from the cmds.lsp file and the NEWCMD command from the newcmd.lsp file.
(autoload "CMDS" '("CMD1" "CMD2" "CMD3")) (autoload "NEWCMD" '("NEWCMD"))
The first time you enter an automatically loaded command at the command prompt, AutoLISP loads the entire command definition from the associated
82 | Chapter 7 Introduction to Programming Interfaces
file. AutoLISP also provides the autoarxload function for ObjectARX applications. See autoload and autoarxload in the AutoLISP Reference.
NOTE
Like-named AutoLISP startup files are loaded based on their Modified time stamp; the LSP file with the most recent time stamp is loaded unless you specify the full file name (including the file name extension).
See also:
S::STARTUP Function: Postinitialization Execution (page 86)
The ACAD.LSP File
You can create an acad.lsp file if you regularly use specific AutoLISP routines. When you start AutoCAD, it searches the support file search path for an acad.lsp file. If an acad.lsp file is found, it is loaded into memory.
The acad.lsp file is loaded at each drawing session startup when AutoCAD is launched. Because the acad.lsp file is intended to be used for application-specific startup routines, all functions and variables defined in an acad.lsp file are only available in the first drawing. You will probably want to move routines that should be available in all documents from your acad.lsp file into the acaddoc.lsp file.
The recommended functionality of acad.lsp and acaddoc.lsp can be overridden with the ACADLSPASDOC system variable. If the ACADLSPASDOC system variable is set to 0 (the default setting), the acad.lsp file is loaded just once: upon application startup. If ACADLSPASDOC is set to 1, the acad.lsp file is reloaded with each new drawing.
The acad.lsp file can contain AutoLISP code for one or more routines, or just a series of load function calls. The latter method is preferable, because modification is easier. If you save the following code as an acad.lsp file, the files mysessionapp1.lsp, databasesynch.lsp, and drawingmanager.lsp are loaded every time you start AutoCAD.
(load "mysessionapp1") (load "databasesynch") (load "drawingmanager")
AutoLISP | 83
WARNING Do not modify the reserved acad2012.lsp file. Autodesk provides the
acad2012.lsp file, which contains AutoLISP defined functions that are required by AutoCAD. This file is loaded into memory immediately before the acad.lsp file is loaded.
See also:
Overview of File Organization (page 3)
Prevent AutoLISP Errors When Loading Startup Files (page 85)
The ACADDOC.LSP File
The acaddoc.lsp file is intended to be associated with each document (or drawing) initialization. This file is useful if you want to load a library of AutoLISP routines to be available every time you start a new drawing (or open an existing drawing).
Each time a drawing opens, AutoCAD searches the library path for an acaddoc.lsp file. If it finds one, it loads the file into memory. The acaddoc.lsp file is always loaded with each drawing regardless of the settings of ACADLSPASDOC.
Most users will have a single acaddoc.lsp file for all document-based AutoLISP routines. AutoCAD searches for an acaddoc.lsp file in the order defined by the library path; therefore, with this feature, you can have a different acaddoc.lsp file in each drawing directory, which would load specific AutoLISP routines for certain types of drawings or jobs.
The acaddoc.lsp file can contain AutoLISP code for one or more routines, or just a series of load function calls. The latter method is preferable, because modification is easier. If you save the following code as an acaddoc.lsp file, the files mydocumentapp1.lsp, build.lsp, and counter.lsp are loaded every time a new document is opened.
(load "mydocumentapp1") (load "build") (load "counter")
WARNING Do not modify the reserved acad2012doc.lsp file. Autodesk provides the acad2012doc.lsp file, which contains AutoLISP-defined functions that are required by AutoCAD. This file is loaded into memory immediately before the acaddoc.lsp file is loaded.
84 | Chapter 7 Introduction to Programming Interfaces
See also:
Overview of File Organization (page 3)
Prevent AutoLISP Errors When Loading Startup Files (page 85)
The MNL File for an AutoLISP Menu
When AutoCAD loads a customization file, it searches for an MNL file with a matching file name. If it finds the file, it loads the file into memory. This function ensures that AutoCAD loads the AutoLISP functions that are needed for proper operation of a menu.
This function ensures that AutoCAD loads the AutoLISP functions that are needed for proper operation of a menu. For example, the default AutoCAD customization file, acad.cuix, relies on the file acad.mnl. This file defines numerous AutoLISP functions used by the menu. The MNL file is loaded after the acaddoc.lsp file.
Prevent AutoLISP Errors When Loading Startup Files
If an AutoLISP error occurs while you are loading a startup file, the remainder of the file is ignored and is not loaded.
Files specified in a startup file that do not exist or that are not in the AutoCAD library path generally cause errors. Therefore, you may want to use the onfailure argument with the load function. The following example uses the onfailure argument:
(princ (load "mydocapp1" "\nMYDOCAPP1.LSP file not loaded.")) (princ (load "build" "\nBUILD.LSP file not loaded.")) (princ (load "counter" "\nCOUNTER.LSP file not loaded.")) (princ)
If a call to the load function is successful, it returns the value of the last expression in the file (usually the name of the last defined function or a message regarding the use of the function). If the call fails, it returns the value of the onfailure argument. In the preceding example, the value returned by the
load function is passed to the princ function, causing that value to be displayed
at the command prompt.
AutoLISP | 85
For example, if an error occurs while AutoCAD loads the mydocapp1.lsp file, the princ function displays the following message and AutoCAD continues to load the two remaining files:
MYDOCAPP1.LSP file not loaded.
If you use the command function in an acad.lsp or acaddoc.lsp, it should be called only from within a defun statement. Use the S::STARTUP function to define commands that need to be issued immediately when you begin a
drawing session.
See also:
S::STARTUP Function: Postinitialization Execution (page 86)
S::STARTUP Function: Postinitialization Execution
You can define an S::STARTUP function to perform any needed setup operations after the drawing is initialized.
The startup LISP files (acad.lsp, acaddoc.lsp, and MNL) are all loaded into memory before the drawing is completely initialized. Typically, this does not pose a problem, unless you want to use the command function, which is not guaranteed to work until after a drawing is initialized.
If the user-defined function S::STARTUP is included in an acad.lsp, acaddoc.lsp, or MNL file, it is called when you enter a new drawing or open an existing drawing. Thus, you can include a definition of S::STARTUP in the AutoLISP startup file to perform any setup operations.
For example, if you want to override the standard HATCH command by adding a message and then switching to the BHATCH command, use an acaddoc.lsp file that contains the following:
(defun C:HATCH ( )
(alert "Using the BHATCH command!")
(princ "\nEnter OLDHATCH to get to real HATCH command.\n")
(command "BHATCH")
(princ) ) (defun C:OLDHATCH ( )
(command ".HATCH")
(princ)
86 | Chapter 7 Introduction to Programming Interfaces
) (defun-q S::STARTUP ( )
(command "undefine" "hatch") (princ "\nRedefined HATCH to BHATCH!\n")
)
Before the drawing is initialized, new definitions for HATCH and OLDHATCH are defined with the defun function. After the drawing is initialized, the
S::STARTUP function is called and the standard definition of HATCH is
undefined.
NOTE To be appended, the S::STARTUP function must have been defined with the defun-q function rather than defun.
Because an S::STARTUP function can be defined in many places (an acad.lsp, acaddoc.lsp, or MNL file or any other AutoLISP file loaded from any of these),
it's possible to overwrite a previously defined S::STARTUP function.
The following example shows one method of ensuring that your startup function works with other functions.
(defun-q MYSTARTUP ( )
... your startup function ...
) (setq S::STARTUP (append S::STARTUP MYSTARTUP))
The previous code appends your startup function to that of an existing
S::STARTUP function and then redefines the S::STARTUP function to include
your startup code. This works properly regardless of the prior existence of an
S::STARTUP function.

ObjectARX

ObjectARX technology provides the foundation for design software applications to share intelligent object data. You can run third-party ObjectARX application programs or write your own.
ObjectARX | 87

Overview of ObjectARX

ObjectARX® (AutoCAD Runtime Extension) is a compiled-language programming environment for developing AutoCAD applications. The ObjectARX programming environment allows you to load and run your compiled projects in the same address space as AutoCAD. This allows your programs to operate directly with core AutoCAD data structures and code.
The ObjectARX libraries allow you to take advantage of the AutoCAD open architecture, providing direct access to the AutoCAD database structures, graphics system, and AutoCAD geometry engine to extend AutoCAD classes and capabilities at runtime. Additionally, you can define new commands that operate exactly the same way as native AutoCAD commands.
You can use ObjectARX libraries in conjunction with AutoLISP, enabling cross-API integration.
The ObjectARX programming environment is described in the ObjectARX Developer's Guide. The documentation is part of the ObjectARX Software Development Kit (SDK), which can be downloaded from the Development Tools section of the Autodesk website.

Use ObjectARX Applications

To load an ObjectARX application, you use the Load option of the ARX command. After loading, all commands defined by this application are available at the command prompt.
Some ObjectARX applications use large amounts of system memory. If you are finished using an application and want to remove it from memory, use the Unload option of ARX.
You can also load an ObjectARX application with the arxload AutoLISP function. The syntax for the arxloadfunction is almost identical to that of the load function used with AutoLISP files. If the arxload function loads the ObjectARX program successfully, it returns the program name. The syntax for the arxload function is as follows:
(arxload
filename [onfailure]
)
88 | Chapter 7 Introduction to Programming Interfaces
The two arguments for the arxload function are filename and onfailure. As with the load function, the filename argument is required and must be the complete path name description of the ObjectARX program file to load. The onfailure argument is optional and typically not used when you load ObjectARX
programs from the command prompt. The following example loads the ObjectARX application myapp.arx.
(arxload "myapp")
As with AutoLISP files, AutoCAD searches the library path for the specified file. If you need to load a file that is not in the library path, you must provide the full path name description of the file.
NOTE
When specifying a directory path, you must use a slash (/) or two backslashes (\\) as the separator, because a single backslash has a special meaning in AutoLISP.
Attempting to load an application that has previously been loaded results in an error. Before using arxload you should use the arx function to check the currently loaded applications.
To unload an application with AutoLISP, use the arxunload function. The following example unloads the myapp application.
(arxunload "myapp")
Using the arxunload function not only removes the application from memory but also removes the command definitions associated with that application.
See also:
Overview of File Organization (page 3)

Install and Uninstall Plug-In Applications

The plug-in auto loader mechanism allows for the easy deployment of custom applications using a package format.
The package format is a common folder structure that has the extension .bundle in its name and has an XML file that defines the various components of the plug-in. By deploying custom applications as a BUNDLE, it makes it easier to
Install and Uninstall Plug-In Applications | 89
target multiple operating systems and product releases since the parameters of your plug-in are defined in the XML file of the package. A BUNDLE can be used as a replacement to creating complex installer scripts when deploying a plug-in.
The plug-in defined by each package is loaded into AutoCAD by placing it in the /Applications/Autodesk/ApplicationAddins folder on your local drive. When AutoCAD starts, the ApplicationAddins folder is checked for plug-in applications. The packages found are automatically registered and loaded based on the metadata in the XML file of each package.
Install Plug-in Packages
A package can be deployed using an installer or manually copying the files and folder structure to the ApplicationAddins folder.
Loading Plug-ins
By default, plug-ins are automatically registered with AutoCAD and when a new plug-in is installed during the current session. The load behavior for plug-ins is controlled with the APPAUTOLOAD system variable. When APPAUTOLOAD is set to 0, no plug-ins are loaded.
Uninstall Plug-in Packages
A package can be uninstalled by removing the appropriate folder with a .bundle extension from the ApplicationAddins folder.

PackageContents.xml Format

The PackageContents.xml file contains information about the application package, including information about the developer that authored it.
The information contained in the file can be used to specify which AutoCAD-based products and releases the plug-in can be loaded into, their supported Operating System, and how the application should be loaded, such as load on startup or when a command is invoked.
The following elements are used to define and describe the plug-in:
■ ApplicationPackage (page 93)
■ CompanyDetails (page 95)
■ Components (page 96)
90 | Chapter 7 Introduction to Programming Interfaces
PackageContents.xml for Download versus Local Deployment
How you plan to deploy your plug-in determines what should be in the PackageContents.xml file. You need to supply more information when providing a plug-in for download versus a local deployment. The following table explains which elements and attributes are required, optional, or recommended for the deployment you want to use.
For Local DeploymentFor Distributed Apps
ApplicationPackage element
SchemaVersion
CompanyDetails element
RequiredRequired
RequiredRequiredAppVersion
OptionalRequiredAuthor
RecommendedRequiredName
RecommendedRequiredDescription
RecommendedRequiredIcon
RecommendedRequiredHelpfile
RequiredRequiredProductCode
OptionalRequiredUpgradeCode
OptionalRequiredName
OptionalOptionalPhone
OptionalOptionalURL
Install and Uninstall Plug-In Applications | 91
For Local DeploymentFor Distributed Apps
OptionalRequiredEmail
RuntimeRequirements element – Required, if Components element present
OptionalOptionalOS
OptionalOptionalPlatform
OptionalOptionalSeriesMin
OptionalOptionalSeriesMax
OptionalOptionalSupportPath
ComponentEntry element – Required, if Components element present
RequiredRequiredAppName
OptionalOptionalAppDescription
Commands element
Command element – Required, if Commands element present
92 | Chapter 7 Introduction to Programming Interfaces
OptionalOptionalAppType
RequiredRequiredModuleName
OptionalOptionalPerDocument
OptionalOptionalLoadReasons
OptionalRequiredGroupName
For Local DeploymentFor Distributed Apps
RequiredRequiredGlobal
RequiredRequiredLocal
OptionalOptionalHelpTopic
OptionalOptionalStartupCommand
ApplicationPackage Element
Each PackageContents.xml file must contain an ApplicationPackage element. The ApplicationPackage element, in the form of XML attributes, contains general information about the plug-in. It also encapsulates other the element types that help to define the contents of the plug-in.
An ApplicationPackage element can have any of the following attributes attached to it:
DescriptionAttribute
SchemaVersion
AppVersion
PackageContents.xml format version number. The value should always be 1.0 until a newer version of the schema is introduced.
Application version number. AutoCAD uses this value to determine if the installed version is the latest version. If an updated version is available, the user is informed and able to download and install the latest version. It is re­commended to use an application version that includes major and minor values, such as “1.0.0.0”.
Name of the plug-in author.Author
Plug-in name.Name A localized plug-in name can be specified by combining Name with a locale code. See Supported Locale Codes (page 103) for a full list of supported locale codes.
Install and Uninstall Plug-In Applications | 93
DescriptionAttribute
Short description of the plug-in.Description Localized descriptions can be specified by combining Description with a locale code. See Supported Locale
Codes (page 103) for a full list of supported locale codes.
Icon
Helpfile
ProductCode
Icon for the plug-in; used in the installer and the Apps section on Autodesk Exchange. The icon should be 32x32 pixels in size and support 32-bit (Truecolor) color depth. Recommend using a BMP or ICO file format.
NOTE All path specifiers are '/' and not '\', and paths are relative to the root .bundle folder.
Help file that explains how to use the plug-in and provides additional information about the plug-in. It is recommended to place a How To section that ex­plains how to use the plug-in. The file can be an ASCII text file, an HTML document, or PDF that contains all the full documentation for the plug-in or contains a set of redirects to where the content might be located on­line. Localized help files can be specified by combining Help­file with a locale code. See Supported Locale Codes (page
103) for a full list of supported locale codes.
NOTE All path specifiers are '/' and not '\', and paths are relative to the root .bundle folder.
Unique GUID for the plug-in. A GUID must be generated for each unique plug-in, and is used for first run notifica­tions and as the installer ID for Add/Remove Programs in Windows when installed from the Apps tab on Autodesk Exchange. ProductCode should be updated if the AppVersion is changed. This is so upgrade installs work properly and a notification is displayed for the upgrade when loaded into AutoCAD. On Windows, you can use the MSI installer ProductCode or generate a GUID using an application such as
94 | Chapter 7 Introduction to Programming Interfaces
