Authinx VT37A Users manual

VGA Video Sender

OWNER'S MANUAL

MODEL VK72A

(INCLUDES VT37A USB SENDER AND VR30A

ECEIVER)

R

VT37AVR30A

INTRODUCTION

FCC CAUTION

Your Wireless VGA Video Sender kit consists of a Sender base unit
which connects to the audio out jack, the VGA output, and the USB
port on your PC, and a Receiver unit which you connect to your TV.
The Sender converts the audio signal from your PC's sound card,
and the VGA video from your PC's video card into a radio
frequency (RF) signal and transmits it (even through walls) to the
Receiver unit. The Receiver converts the signals back to their
original form and passes them to your TV. The USB port allows you
to use the VGA sender with X10 RF remote controls, (sold
separately) to control your PC wirelessly.

WARNING:

To reduce the risk of fire or electric shock, do not expose this product
to rain or moisture.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

This equipment generates and uses radio frequency energy, and if not installed and
used properly, that is, in strict accordance with the manufacturers instructions, it may
cause interference to radio and television reception. It has been type tested and found
to comply with the limits for remote control devices in accordance with the
specifications in Sub-Parts B and C of Part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio or television reception,
which can be determined by unplugging the equipment, try to correct the interference
by one or more of the following measures.

• Reorient the antenna of the radio/TV experiencing the interference.

• Relocate the equipment with respect to the radio/TV.

• Move the equipment away from the radio/TV.

• Plug the equipment into an outlet on a different electrical circuit from the radio/TV
experiencing the interference.

• If necessary, consult your local Dealer for additional suggestions.

NOTE: Modifications to this product will void the user's authority to operate this
equipment.

SYSTEM REQUIREMENTS

To use the VGA Video Sender system your PC must have a USB
port, a VGA out port (that normally connects to your monitor) and a
sound card with mono or stereo output. Max resolution is 1024 x
768, but 800 x 600 is recommended.

32

CONTENTS

CONTROLS AND CONNECTIONS

C

ONTROLS AND CONNECTIONS

ENDER

..........................................................................6

S
R

ECEIVER

........................................................................7

B

EFORE YOU START

ONNECTING UP

C

H

OOKING UP THE SENDER

H

OOKING UP THE RECEIVER

F

INE TUNING YOUR SYSTEM
ROUBLESHOOTING

T

.................................................................8

..................................................................9

...............................................................13

...................................................5

....................................................9

.................................................10

....................................................12
