Authinx 24110T User Manual

24110

Universal Remote
Instruction Manual

ON-OFF SETUP

R

C

V

SL

E

E

1

4

79

E

N

T

E

INFO GUIDE

CH

VOLVOL

CH

TV

TV/VCR

P

INPUT

2

5

H

C

.

V

E

R

P

3

6

8

R

0

OKOKOK

M

E

N

U

P

I

P

SWAP

T

I

X

E

E

V

O

M

IntroductionTable of Contents

Introduction ...................................................... 3

Button Functions ............................................... 4

Initial Setup ...................................................... 6

Battery Installation ....................................... 6

Battery Saver ............................................... 6

Code Saver ................................................. 6

Power-On default ........................................ 6

Code Setup ................................................. 6

Direct Code Entry ............................................ 7

Code Search .................................................... 7

Code Identification Feature ............................... 8

Setup ............................................................... 9

Programming Combo Device Codes ............ 9

Controlling Combo Devices ......................... 9

Controlling Devices Requiring Separate

Power On and Off Buttons ........................... 9

VCR/DVD/DVR Punch-Through Feature .. 10

Volume/Mute Control and

Punch-Through Feature .............................. 10

Setting All Volume/Mute Control to

any one Mode ........................................... 11

Setting any Mode to use its

own Volume/Mute Control ......................... 11

Sleep Timer .................................................... 12

Find/Page Feature .......................................... 12

Troubleshooting .............................................. 13

Congratulations on your purchase of this 24110
Universal Remote Control. It is one of the most
unique looking, and easy to use remote controls
available today. With the 24110 juggling multiple
remote controls is a thing of the past! Your 24110
Universal Remote controls up to 5 devices,
including the most popular brands of TV, VCR,
DVD, SAT, CBL, and audio equipment.

The 24110 comes with a convenient base/stand
that you can place the remote in when you’re not
using it. The base/stand also has a Find/Page
feature, which lets you quickly find the remote if
you’ve misplaced it. You simply press the Page
key on the base and the remote sounds with a
tone, making it easy to locate.

Other unique features for this remote are
described in the remainder of this manual.

Note: Some functions from your original remote
may not be controlled by the 24110 remote. Use
the original remote, if available, to control such
functions. Sometimes buttons other than described
in these instructions may actually perform the
function. For example, the CH and VOL buttons
might be used to navigate through menu choices.
We recommend you experiment with the remote
to identify if such situations pertain to your
equipment.

The 24110 Universal Remote is easy to use, easy
to program, and it gives you total control—at the
touch of your fingertips!

32

Button Functions

Button Functions, cont.

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

23.

22.

21.

20.

19.

18.

17.

16.

15.

14.

13.

12.

Note: The Record button must be pressed TWICE to record
from your VCR. For some brands of VCRs, you might need to
press the Record button once, then press it again for three
seconds. Some buttons on the remote might have functions
that are referred to by different names on the device you are
controlling. E.g., PREV.CH may be called RECALL, or
ENTER may be called DISPLAY. These differences depend on
the brand and model of your product. Also, this remote can
only operate features that exist on your product. E.g., your
product must have PREV.CH ability for the PREV.CH button
to operate this feature.

1. ON-OFF: Turns device On or Off.

2. TV, VCR, DVD, SAT/CBL, AUDIO/AUX: Selects

product to be operated.

3. VOL UP/DOWN: Changes the volume level of the
product, normally the TV.

4. CH UP/DOWN: Changes the channels. Also
controls DVD/CD CHAPTER +/- track selection, i.e.,
DVD/CD Track Skip Up/Down. Note the VCR
buttons also control the DVD when in DVD Mode.

5. SLEEP: Turns off the TV after a period of 1 to 99
minutes.

6. NUMBERS: Enter numbers for direct channel
selection. Some products require ENTER to be
pressed after channel selection.

7. ENTER: Used after direct channel number entry to
immediately change to the selected channel.

8. INFO: Displays on-screen channel information, etc.

9. OK: Selects menu items for the device you are

controlling.

10. MENU: Displays the DVD disc menu screen. Use
with the UP, DOWN, LEFT & RIGHT navigation
buttons.

11. PIP: TV Picture-in-Picture control.

12. SWAP: Swaps TV PIP screens.

13. MOVE: Moves the position of the PIP screen.

14. EXIT: Exits On-Screen Menus and/or Returns to

previous On-Screen selection.

15. UP, DOWN, LEFT & RIGHT: Navigation buttons.

16. RECORD, PLAY, STOP, REW, FF, PAUSE: VCR

control buttons operate your VCR even when the
remote is set to operate the TV. Also operates DVD
Scan -/+.

17. GUIDE: Displays satellite or cable on-screen
program guide.

18 ( ) Used for digital channels, e.g., 2.3.

•

19. INPUT Selects the video inputs of your TV if
equipped with that feature. TV/VCR: Operates the
same as the TV/VCR or antenna keys on your
original remotes.

20. PREV CH: Returns to the previously selected
channel or DVD repeat toggle.

21. MUTE: Turns off the TV sound while the picture
remains.

22. Red Indicator: Lights when any button is pressed.

23. SETUP: Used for setting up your remote.

54
