Autel Intelligent Tech TPRF201A User Manual

Quick Guide:

INSTALLATION GUIDE:

! IMPORTANT: Before operating or maintaining this unit, please read

these instructions carefully and pay extra attention to the safety

warnings and precautions. Use this unit correctly and with care. Failure

to do so may cause damage and/or personal injury and will void the

warranty.

Warranty:

AUTEL guarantees that the TR201 is free from material and

manufacturing defects for a period of 24 months or for 24,000 miles,

whichever comes first. AUTEL will at its discretion replace any

merchandise during the warranty period. The warranty shall be void if

any of the following occurs:

1. . Improper installation of the product;

2. Improper use;

3. Product damage due to collision, man-made damage or natural

disasters;

4. Exceed the product-specific use restrictions.

CAUTION:

1. The Autel TPMS ECU needs to be used with the Autel standard cable.

Otherwise, it may cause a short circuit on the vehicle.

2. When using the original TPMS ECU, avoid using the Autel standard

cable. Otherwise, it may cause a short circuit on the vehicle.

3. Before installing the TPMS ECU, please confirm that the installation

model is correct. Otherwise, it may cause a short circuit on the vehicle.

Instruction Guide:

Procedures:

1. Program the TR201 TPMS ECU using the TPMS programming tool

2. Code the vehicle and retrofit TPMS function

3. Install the TPMS ECU and sensor

4. Relearn the TPMS system according to the relearning steps

Operations Guide:

1. Take MX808TS and VCI Mini as an example, connect TR201 and VCI

Mini to the corresponding interface of ECU_DPL_01 programming cable,

and supply 12V to the programming cable, then connect MX808TS and

VCI Mini via Bluetooth. The specific connection is as follows:

2. Tap the TPMS icon in the MX808TS main menu

3. Select the Model ė Ye ar in turn

4. Tap the Retrofit button in the navigation bar at the top of the screen

to display the installation interface. Tap the Autel ECU Relearn button at

the bottom of the screen to program the TR201 TPMS ECU.

5. In the installation interface, detailed operation guide is displayed,

including the relearn function, TR201 installation position and so forth.
