Autel Intelligent Tech MAXISYSMS906TS Users Manual

Chapter 6 MaxiFix Operations

The MaxiFix application launches the on-line troubleshooter database, which not only provides you virtually all common diagnostic trouble code (DTC) database for most vehicles, but also serves as a forum allowing you to network with other MaxiSys users, and gives you access to a vast database of repair and diagnostic tips along with proven filed fixes.

While the MaxiFix provides the abundant troubleshooter information available, the database keeps growing with daily troubleshooting resources by recording the reported solution cases, and the advisory reports of the MaxiSys users from all over the world.

Information in the MaxiFix database is organized into a series of diagnostic tips that are designed to quickly lead you to the root cause of a particular problem on the test vehicle, which will help you quickly find solutions for various diagnostic problems.

6.1 Navigation

You need to register the device to your online account before launching the MaxiFix platform, see 12.1 Product Registration on page 99 for details.

Figure 6-1 Sample MaxiFix Home Page

MaxiFix Operations Navigation

The MaxiFix screen layout consists of 3 main areas:

1. The Header –the tool bar across the top of the screen which allows you to select vehicles and perform searches.

2. The Main Screen –located at the center of the screen displaying content based on the vehicle attributes and keywords specified. The tabs on the main screen vary in accordance with the section selected on the Navigation Menu, allowing you to switch between functions.

3. The Navigation Menu –the main menu at the bottom of the screen, which provides you access to different sections of MaxiFix.

The Header

The Header at the top of the screen features:

 A Select Vehicle button to open the vehicle identification window, and

vehicle information bar, for example “2014>Hyundai> Accord Coupe > L4-2.4L (K24W1)”.

 A search field to find relevant information by entering keywords, codes,

or problems.

Select Vehicle Button

The “Select Vehicle” button on the Header allows you to specify the vehicle

which you want to reference on MaxiFix, by selecting each of the vehicle attribute from a sequence of option lists. This feature helps to filter out the searches that allow only the information that applies to the identified vehicle to display.

Note: All attributes must be specified to make a complete vehicle selection for the most efficient search results.

 To select a vehicle

Follow the procedure below to select a vehicle:

1. If you haven’t already done so, click the “Select Vehicle” button on

the Header.

2. Select the year of the vehicle from the list.

3. Select the make of the vehicle from the list.

4. Select the model of the vehicle from the list.

MaxiFix Operations Navigation

5. Select the submodel of the vehicle from the list.

6. Select the engine of the vehicle from the list. After completing the vehicle selection procedure, the identified vehicle is

shown on the Header.

6.1.1 Terminology

MaxiFix Tip

A MaxiFix Tip provides practical information of real fix of a specific vehicle repair issue with detailed descriptions. It is combined with proven fix and vehicle specific data, and filed into an all-in-one information source to provide you with quick and easy repair solutions.

On MaxiFix community you can find Tips or share your own Tip to help other community members solve vehicle issues.

 To search for a MaxiFix Tip

1. Select a Vehicle:

a) Click the “Select Vehicle” button on the Header at the top of

the page. b) Select the year of the vehicle from the list. c) Select the make of the vehicle from the list. d) Select the model of the vehicle from the list. e) Select the submodel of the vehicle from the list. f) Select the engine of the vehicle from the list. After completing the vehicle selection procedure, the identified

vehicle is shown on the Header.

2. Enter a Search Term. MaxiFix has an exclusive one-stop lookup that helps you find all of

MaxiFix resources by one click. Simply enter a search term into the search bar on the Header to begin the search.

3. Proven Results! The powerful MaxiFix database gives you proven results! The

typical MaxiFix Tips combine actual workshop fixes and data which may include:

MaxiFix Operations Operations

a) OBDII Fault Codes description and reference—helps in

diagnostic assessment by making clear the nature of an automotive problem so that beginner and advanced technicians can make effective repairs

b) Real Fix Tips—provides repair tips from actual shop

practices and are presented in an easy to understand Complaint, Cause, Correction format.

If you still can’t find the information you want, you can ask the MaxiFix community for help by clicking “Ask” on the Navigation Menu at the bottom of the screen.

Adopted!

The “Adopted!” icon that displays at the top right side of a Tip page indicates

that the related Tip has been adopted by at least 1 technician in the community. If a tip has helped you to solve a repair problem, you are encouraged to give an Adopted! count to the tip. Each member is allowed to click the “Adopted!” once for a tip, and each click will add 1 count to the total number of “Adopted!” The “Adopted!” count helps you easily identify which tips are really helpful for repairing vehicle issues. You can also post a comment about how the tip has helped you as reference to other members.

6.2 Operations

The Navigation Menu is at the bottom of the screen. Selecting the items on the Navigation Menu allows you to switch between the main sections on MaxiFix. These main sections include:

 Home –shows all questions and allows you to specify questions about

one or multiple makes.

 Search Fix –allows you to search for information from all available

resources on MaxiFix, including: Open Questions, Tips, and Real Fixes, and displays search results.

 Ask –allows you to ask a question in the community.  My MaxiFix –shows all your posts including Questions and Fixes in the

community, and allows you to view your personal profile, select your vehicle preference, and share your tips.

 My Messages – shows a list of message notifications which is relevant

MaxiFix Operations Operations

to your activities in the Question section.

 Support – opens the FAQ page, or a message box for contacting

Customer Service by email.

6.2.1 Home

Home is the first option on the Navigation Menu at the bottom of the screen. Tapping it opens your MaxiFix home page. There is a list of questions posted on the community, and you can scroll down the page to the bottom and view

more questions by tapping “View More”. Click on any question and you will be

linked to the detailed page in the Ask section. You can configure your main screen to display questions only related to the

vehicle makes you are interested in, by clicking the “Filter” button on the main

page of Home, and select the desired vehicle makes. This filter can be

canceled anytime by clicking the “Remove All Filters” button, and the default

setting will be restored to display questions about all vehicle makes.

6.2.2 Search Fix Features

Search Fix, the second option on the Navigation Menu at the bottom of the screen, presents search results for the specified vehicle. Search results are listed in various categories:

 All – includes all search results, including related Questions, Tips, and

 Questions – presents a list of open Question discussed in the

 Tips – presents a list of Tips that directly correlate to your search criteria.

 Real Fixes –presents a list of Tips that have been collected from actual

6.2.3 Ask

Ask, the third option on the Navigation Menu at the bottom of the screen, allows you to ask a question about a particular vehicle repair issue in the community.

Real Fixes to your search.

community that may be pertinent to your search.

Select a Tip from the list to open and review the complete Tip.

shop repair orders and are presented in an easy-to-understand Complaint, Cause, and Correction format.

MaxiFix Operations Operations

 To ask a MaxiFix Question

1. If not already done, click Select Vehicle on the Header to specify the vehicle you are asking about.

2. Click Ask on the Navigation Menu at the bottom of the screen to open the Ask page.

3. On the Ask page find Ask for Help, fill in the following sections to ask a question.

The Ask page has 4 sections:

 Subject – this is where you enter a brief subject for the

question.

 My Question – ask a clear and concise question that you want

to ask the community. Be sure to be descriptive and concise when asking your question.

 Problem Description –describe how the vehicle is behaving.  Repair History – include any previous diagnostic tests that you

performed, including the results of the tests. Also list any parts that were replaced during previous diagnostic work.

Tap the “Cancel” button to cancel your question and return to the Ask page.

Tap the “Submit” button to post your question to the community. Tap the “Attach File” button to include images or reference files with

your question. You are requested to select one Adopted Answer from all of the

responses and then close the question. For details, please refer to My Messages section.

6.2.4 My MaxiFix

My MaxiFix, the fourth option on the Navigation Menu at the bottom of the screen, opens your personal MaxiFix page. To access the features on My MaxiFix page you can select from the tabs:

 My Questions – opens a list with links to the opened questions that you

have posted to the community

 My Cases – opens a list with links to the closed questions and tips that

you have contributed to the community.

MaxiFix Operations Operations

 Marked Posts – opens a list with links to Tips and discussions that you

are actively participating in.

 My Profile –allows you to view your Autel account information including:

your Autel ID, personal information, MaxiFix score, phone number and register time, and edit your portrait.

 Vehicle Preference –used to set up a list of preferred vehicles. The

preferred list allows you to limit the choices that displayed on the “Select Vehicle” list to specific years, and makes. Click “Set Year” or “Set Make”

to set your preferred models. The preferred makes will also be displayed in the “Filter” options on the Home page.

 Share a Tip – allows you to share your personal repair experience with

the community.

Click My MaxiFix on the Navigation Menu at the bottom of the screen, to display all questions and tips that you have contributed to the community.

Create a Tip

A “Tip” is a concise and complete description of the fix for a particular vehicle repair issue.

 To create a new MaxiFix Tip

1. Select My MaxiFix from the Navigation Menu.

2. Select Select Vehicle from the Header and enter the identifying

attributes of the vehicle you are writing the Tip about.

3. On the My MaxiFix page find Share a Tip; click this link to open the

My Tips page.

4. Enter the Tip subject in the Subject field.

5. Compose your Tip in the Description field. Include as much

information as possible, while keeping the information concise and to the point. A Tip should provide accurate information that is reader-friendly.

Use the Cancel button at the right-side bottom of the page to cancel your tip and return to the My MaxiFix page. Or,

Use the Submit button at the right-side bottom of the page to contribute your tip to the community.

Use the Attach File button at the left-side bottom of the page to include images or other supporting data with your question.

MaxiFix Operations Operations

View Profile Information

You can view your personal profile by clicking on your account ID or “My

Profile” in My MaxiFix section or edit portrait where applicable, and visit other

community members’ profile by clicking their portrait. Information included in

your profile determines how you are presented to the community, and what type of information will be sent to you from the community.

6.2.5 My Messages

My Messages, the fifth option on the Navigation Menu at the bottom of the screen, shows a list of message notification which is relevant to your activities in the Question section. A notification icon will appear on the top-right corner of

“My Messages” if there is any new or unread message in the Question section.

The number on the notification icon indicates the total number of the new and unread messages. The displayed number will be reduced correspondingly after viewing. The message notification will appear under the following two conditions:

1. Your question or answer is replied by other MaxiFix community members.

2. Your answer is marked as the “Adopted!” by the MaxiFix community member who asked the question.

Tap My Messages, select and open the message you want to read from the list. If your problem is solved according to the reply, you should select one Adopted Answer and close the question. If your answer is marked as “Adopted!”, the prompt “Adopted! + 4” will be displayed permanently.

Tap Clear to delete all message notifications.

Select “Adopted Answers”

Members are requested to select one Adopted Answer from all of the

responses on “My Messages” page before closing a question. The community

members who provided the Adopted Answer are rewarded with scores for their contribution.

About Adopted Answer:

 Only one answer can be selected as “Adopted Answer”.  Answers can only be rated by the MaxiFix member who asked the

question.

MaxiFix Operations Operations

Close a Question

When a repair question that you've posted to the community is resolved, you are encouraged to write down the case as a way to share a good solution. This will help the other MaxiFix members to find useful information for practical fix.

To close a question, you need to select the question’s response message from the message list on “My Messages” page first, then tap “Adopted Answer” and select “Close Question”. Tap the “Cancel” button to cancel your submission and return to My Messages page. It is strongly recommended to share your repair solutions before closing a question. Your question will be converted to a MaxiFix Community Tip after closing.

Score Rewarding System

1. A score of 3 is awarded when you close a question.

2. A score of 2 is awarded if your closed question is marked as "Adopted!" by no less than 20 community members.

3. A score of 4 is awarded if your answer is selected as the “Adopted Answer”.

4. A score of 1 is awarded if your answer is selected as the "Adopted Answer" for a closed question which is marked as "Adopted!" by no less than 20 community members.

5. A score of 1 is awarded to each of the first three respondents.

6.2.6 Support

Support, the last option on the Navigation Menu at the bottom of the screen, opens a page that provides 2 ways to gain support from MaxiFix:

1. A message form to contact the administrator of MaxiFix.

2. A Frequently Asked Questions (FAQ) link that answers the most frequent

questions we hear from MaxiFix community members.

If you wish to contact the administrator of this site please use the contact form. Select “Support” from the Navigation Menu to open the comment window. To allow the administrator to respond to your question or issue, the following information should be provided:

 Your name  A contact email address  A contact phone number

Button

Name

Description

Back

Returns to the previous screen.

Diagnostics

Touching this button directs you to the vehicle’s Diagnostics screen to activate a direct test session.

Enter Edit

Touching this button shows the editing toolbar to print or delete the selected file.

Delete

Touching this button deletes the selected vehicle record item from the list.

Quickly locates the vehicle record by entering the vehicle name or test path.

Cancel

Touching this button to cancel edit or file search.

Edit

Touching this button allows you to edit information for the displayed file.

Add Account

Touching this button to create a new customer account file.

Chapter 7 Shop Manager Operations

The Shop Manager application helps you to manage the workshop information, customer information records, and keep test vehicle history records, which can be a great assist in dealing with daily workshop business and improves customer service. There are three main functions available:

 Vehicle History  Workshop Information  Customer Manager

The operations of these functions of the Shop Manager application are mainly manipulated by the toolbar buttons, which are listed and described in the table below:

Table 7-1 Top Toolbar Buttons in Shop Manager

Shop Manager Operations Vehicle History

Button

Name

Description

History Notes

Touching this button opens a note form, which allows you to create audio record, attach picture or video, or edit text notes, etc.

Vehicle History

Touching this button opens the Vehicle History screen which displays the correlated test vehicle records.

Done

Complete editing and save the file.

7.1 Vehicle History

This function stores records of test vehicle history, including vehicle information and the retrieved DTCs from previous diagnostic sessions, and displays all information in an easy-to-check table list, on which you can view summarized details and manually input other information about the test vehicle and diagnostic loggings, etc. The Vehicle History also provides direct access to the previously tested vehicle and allows you to restart a diagnostic session without the need to do vehicle identification again.

Figure 7-1 Sample Vehicle History Screen

1. Top Toolbar Buttons – navigates and makes various controls of the

application.

2. Main Section – displays all the vehicle history records information.

Shop Manager Operations Vehicle History

 To activate a test session for the recorded vehicle

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Vehicle History

3. Tap the Diagnostics button at the bottom of the thumbnail of a vehicle record item. Or,

4. Select a vehicle record item by tapping the thumbnail.

5. A Historical Test record sheet displays, check the recorded information of the recorded test vehicle, and tap the Diagnostics button on the upper right corner.

6. The vehicle’s Diagnostics screen displays, now a new diagnostic session is activated, see 4.6 Diagnosis on page 32 for detailed instructions on vehicle diagnostic operations.

7.1.1 Historical Test Record

The Historical Test record sheet of the tested vehicle is a detailed data form, which includes all general information of the vehicle such as vehicle year, make and model, etc., and the diagnostic trouble codes retrieved from the previous test sessions, as well as other service details which can be added manually by the technician himself.

Figure 7-2 Sample Historical Test Record Sheet

Shop Manager Operations Workshop Information

 To edit the Historical Test record sheet

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Vehicle History.

3. Select the specific vehicle history record thumbnail from the main section. The Historical Test record sheet displays.

4. Tap the Edit button to start editing.

5. Tap on each item to input the corresponding information or add attaching files or images.

NOTE: The vehicle VIN number, or license and the customer information account are correlated by default. Adding one of the information will automatically associate the other item in the record sheet, provided that the later one exists.

6. Tap Add to Customer to correlate the Historical Test record sheet to an existing customer account, or add a new associating account to be correlated with the test vehicle record. See 7.3 Customer

Manager on page 80 for more information.

7. Tap Done to save the updated record sheet, or tap Cancel to exit without saving.

7.2 Workshop Information

The Workshop Information form allows you to edit, input and save the detailed workshop information, such as shop name, address, phone number and other remarks, which, when printing vehicle diagnostic reports and other associated test file, will appear as the header of the printed documents.

Shop Manager Operations Customer Manager

Figure 7-3 Sample Workshop Information Sheet

 To edit the Workshop Information sheet

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Workshop Information.

3. Tap the Edit button on the top toolbar.

4. Tap on each field to input the appropriate information.

5. Tap Done to save the updated workshop information sheet, or tap

Cancel to exit without saving.

7.3 Customer Manager

The Customer Manager function allows you to create and edit customer accounts. It helps you to save and organize all customer information accounts that are correlated with the associated test vehicle history records, which is a great support for the arrangement of daily workshop business.

 To create a customer account

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Customer Manager.

3. Tap the Add Account button. An empty information form displays, tap each field to input the appropriate information.

NOTE: The items that must be filled are indicated as required fields.

Shop Manager Operations Customer Manager

4. Tap the □+ photo frame beside the Name chart to add a photo. A sub menu displays, select Take Photo to take a new photo for the account, or select Choose Photo to choose from the existing files.

5. Some customers may have more than one vehicle for service; you can always add new vehicle information to the account to be correlated. Tap Add New Vehicle Information, and then fill in the vehicle information. Tap the ○x button to cancel adding.

6. Tap Done to save the account, or tap Cancel to exit without saving.

 To edit a customer account

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Customer Manager.

3. Select a customer account by tapping the corresponding name card. A Customer Information sheet displays.

4. Tap the Edit button on the top toolbar to start editing.

5. Tap on the input field where needs to be altered or supplemented, and enter updated information.

6. Tap Done to save the updated information, or tap Cancel to exit without saving.

 To delete a customer account

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Customer Manager.

3. Select a customer account by tapping the corresponding name card. A Customer Information sheet displays.

4. Tap the Edit button on the top toolbar to start editing.

5. Tap the Delete Customer Information button. A confirmation message displays.

6. Tap OK to confirm the command, and the account is deleted. Tap Cancel to cancel the request.

Shop Manager Operations Customer Manager

7.3.1 History Notes

The History Notes function allows you to add audio and video records, text notes and photos, to keep multi-media work logs for the associated customer account, which can be very helpful when dealing with repeat customers. Keeping notes for each vehicle serviced for each customer will keep you always on track and well organized in business.

 To access History Notes

1. Tap the Shop Manager application on the MaxiSys Job Menu.

2. Select Customer Manager or Vehicle History.

3. Select a customer account by tapping the corresponding name card. A Customer Information sheet displays (if Customer Manager is selected). Or, select a vehicle history record item to open the Historical Test record sheet (if Vehicle History is selected).

4. Tap the History Notes button on the top bar. Now the History Notes screen displays.

Figure 7-4 Sample History Notes Screen

1. Functional Buttons – navigates and make various controls of the function

2. Main Section – displays the note list on the left column and the detail information of the selected note on the right column

Shop Manager Operations Customer Manager

Button

Name

Description

Back

Returns to the previous screen.

Delete

Touching this button deletes the selected note.

Quickly locates the required note by entering the note title.

Cancel

Touching this button to cancel edit or file search.

Edit

Touching this button opens an edit window allowing you to edit notes and

Add Notes

Touching this button to add new note in History Notes.

Audio Record

Performs audio recording and creates audio files.

Add Photos

Opens the image file for selection, and adds the selected photos to History Notes.

Take a Video

Records a video and adds the file to History Notes.

Take a Photo

Takes photos and adds the files to History Notes.

Save

Saves notes.

Table 7-2 Function Buttons in History Notes

 To add a note in History Notes

1. Access History Notes.

2. Tap the Add Notes button. An edit window displays.

3. Tap on the Title bar to input a note title.

4. Tap on the blank space below to edit a text note or remark.

5. Select a function button on the top to add files in any form you

choose.

6. Tap Save to save the note; tap Discard or Cancel to exit without

saving.

Chapter 8 Data Manager Operations

The Data Manager application is used to store, print, and review the saved files. Most operations are controlled through the toolbar.

Selecting the Data Manager application opens the file system menu. Different file types are sorted separately under different options, there are six types of information files to be viewed or played back.

Figure 8-1 Sample Data Manager Main Screen

8.1 Operations

Data Manager Operations are based on toolbar controls. Details are explained in the following sections.

8.1.1 Image Files

The Image section is a JPG database containing all captured screenshot images.

Data Manager Operations Operations

Button

Name

Description

Back

Returns to the previous screen.

Enter Edit

Tapping this button shows the editing toolbar to print, delete or view image information.

Cancel

Tapping this button close the editing toolbar or cancels file search.

Quickly locates the image file by entering the vehicle name, test path, file name or file info.

Info

Tapping this button opens a window displaying the details of the image.

Tapping this button prints the selected image.

Delete

Tapping this button deletes the selected image.

Figure 8-2 Sample Image Database Screen

1. Toolbar Buttons – used to edit, print and delete the image files. See

Table 8-1 Toolbar Buttons in JPG Database on page 85 for detailed

information.

2. Main Section – displays the stored images.

Table 8-1 Toolbar Buttons in JPG Database

Data Manager Operations Operations

 To edit image information

1. Select Data Manager application from the MaxiSys Job Menu.

2. Select Image to access the JPG database.

3. Select an image to display it in full screen.

4. Tapping the screen once displays the editing toolbar.

5. Tap the Info button to open a window displaying the image

information.

6. Tap the Edit button on the top right corner of the window. The editing

screen displays.

7. Edit the image information by entering the new file name, and file

information.

8. Tap Done to save the information and exit, or tap Cancel to exit

without saving.

 To delete selected images

1. Select Data Manager application from the MaxiSys Job Menu.

2. Select Image to access the JPG database.

3. Tap the Enter Edit button to display the editing toolbar.

4. Select the images that need to be deleted by tapping the thumbnail

images, the selected thumbnail displays a tick icon at the bottom right corner.

5. Tap the Delete button, and then Delete Selected, then the selected

images will be deleted.

8.1.2 PDF Files

The PDF section stores and displays all PDF files of saved data. After entering the PDF database, select a PDF file to view the stored information.

This section uses the standard Adobe Reader application for file viewing and editing, please refer to the associated Adobe Reader manual for more detailed instructions.

Data Manager Operations Operations

8.1.3 Review Data

The Review Data section allows you to playback the recorded data frames of live data streams.

On the Review Data main screen, select a record file to playback.

Figure 8-3 Sample Data Playback Screen

1. Drop-down Toolbar – tap the button at the top center of the screen to open the Drop-down Toolbar

2. Main Section – displays the recorded data frames

3. Navigation Toolbar – allows you to manipulate data playback

Use the Navigation Toolbar buttons to playback the record data from frame to frame.

Tap Back to exit data playback.

8.1.4 Apps Manager

This section allows you to manage the firmware applications installed on the MaxiSys Diagnostics System. Selecting this section opens a managing screen, on which you can check all the available vehicle diagnostic applications.

Select the vehicle firmware you want to delete by tapping on the car brand icon, the selected item will display a blue tick at the upper right corner. Tap the Delete button on the top bar to delete the firmware from the system database.

Data Manager Operations Operations

8.1.5 Data Logging

The Data Logging section allows you to launch Support platform directly to view all records of all sent or unsent (saved) data loggings on the diagnostic system. For more details, please refer to12.5 Data Logging 12.5on Page 104.

Chapter 9 Settings Operations

Selecting Settings application opens a setup interface, on which you can adjust default setting and view information about the MaxiSys system. There are seven options available for the MaxiSys system settings:

 Unit  Language  Printing Setting  Notification Center  About  System Settings

9.1 Operations

This section describes the operation procedures for the settings.

9.1.1 Unit

This option allows you to adjust the measurement unit for the diagnostic system.

 To adjust the unit setting

1. Tap the Settings application on the MaxiSys Job Menu.

2. Tap the Unit option on the left column.

3. Select the required measurement unit, Metric or English. A tick icon

will display to the right of the selected unit.

4. Tap the Home button on the top left corner to return to the MaxiSys

Job Menu. Or select another setting option for the system setup.

9.1.2 Language

This option allows you to adjust the display language for the MaxiSys system.

Settings Operations Operations

 To adjust the language setting

1. Tap the Settings application on the MaxiSys Job Menu.

2. Tap the Language option on the left column.

3. Select the required language. A tick icon will display to the right of

the selected language.

4. Tap the Home button on the top left corner to return to the MaxiSys

Job Menu. Or select another setting option for the system setup.

9.1.3 Printing Setting

This option allows you to print any data or information anywhere and anytime via Wi-Fi connection. For more information about printing, see 3.3.1 Printing Operation on page 17.

 To setup the printer connection

1. Tap the Settings application on the MaxiSys Job Menu.

2. Tap the Printing Setting option on the left column.

3. Tap the Print via Network item to activate the printing function,

which enables the device to send files to the printer through the PC via Wi-Fi connection.

4. Tap the Home button on the top left corner to return to the MaxiSys

Job Menu. Or select another setting option for the system setup.

9.1.4 Notification Center

This option allows you to turn the Notification Center function on or off. The Notification Center function configures the MaxiSys tablet to receive regular on-line messages from the server for system update notifications or other service information via the Internet. It is highly recommended to keep this function on all the time, so you won’t miss out any new update for MaxiSys or event from Autel. Internet access is required for receiving on-line messages.

 To enable the Notification Center function

1. Tap the Settings application on the MaxiSys Job Menu.

+ 54 hidden pages

Autel Intelligent Tech MAXISYSMS906TS Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
