)*$%!,,!%)/*()*$%0".%)/*$(
6:;<=:(><??:@>A@B(A@CDEFFEDA<@(<=(?EA@D:@E@>:G(:@CH=:(:F:>D=A>ADI(AC(CJAD>K:L(<;;(ED(DK:(?EA@CM((
1. A!12V!DC!LED!Driver!must!be!used!with!this!strip.!
2. Ensure!that!the!surface!that!the!LED!strip!will!be!applied!to!is!clean!and!free!from!grease!
3. Peel!of!the!backing!tape!and!fix!the!LED!strip!into!the!required!position!using!the!self-adhesive!backing.!!
4. The!LED!strip!may!be!cut!to!length!with!cut!points!every!50mm.!
5. A!maximum!of!10m!can!be!connected!in!one!length.!Runs!over!10m!must!be!connected!in!parallel.!See!Diagram!1!for!connection!details.!
6. Connect!the!LED!Strips!to!the!12V!DC!Constant!Voltage!LED!Driver!and!ensure!that!the!polarity!is!correct.!Also!refer!to!the!instructions!provided!with!the!
LED!Driver!
7. Connect!the!Constant!Voltage!LED!Driver!to!the!mains!supply.!
8. The!LED!strip!will!now!be!lit.!
!
!
!
!
!
!
! !
!
!
(
(
(
(
!
!
!
!
!
!
!
!
!
!
-@NA=<@?:@DEF(2=<D:>DA<@(OPM-M-M-MQ(R(!H=<=ESC(P---(0:BM*<M(P--86+'&T'5U(
(
Waste!Electrical!&!Electronic!Equipment!Regulations!(WEEE)!requires!that!any!of!our!products!showing!this!marking!(left)!must!not!be!disposed!of!
with!other!household!or!commercial!waste.!Aurora!does!not!levy!any!WEEE!disposal!charges!to!its!customers!for!affected!WEEE!related!products.!
To!prevent!possible!harm!to!the!environment!or!human!health!from!uncontrolled!waste!disposal,!please!separate!any!such!product!from!other!
waste!types!and!recycle!it!responsibly!at!your!local!facilities.!Check!with!your!Local!Authority,!Recycling!Centre!or!retailer!for!recycling!advice.!If,!
when!you!purchased!any!Aurora!product,!your!supplier!included!a!WEEE!disposal!fee,!you!should!then!contact!your!supplier!for!advice!on!his!take!
back!of!the!product!for!the!correct!disposal.!
!
P!00!*%5!
See!www.auroralighting.com!for!full!details!of!warranties!and!Extended!Warranty!Terms!and!Conditions.!The!warranty!is!invalid!in!the!case!of!improper!use,!
tampering,!and!removal!of!the!Q.C.!date!label,!installation!in!an!improper!working!environment!or!installation!not!according!to!the!current!edition!of!the!National!
Wiring!Regulations.!Should!this!product!fail!during!the!warranty!period!it!will!be!replaced!free!of!charge,!this!is!subject!to!correct!installation!and!return!of!the!
faulty!product.!Aurora!does!not!accept!responsibility!for!any!installation!costs!associated!wit h!th e!r ep la ce m en t !of!th is!p ro duct.!This!warranty!is!in!addition!to!the!
statutory!rights!in!your!country!of!purchase.!Aurora!reserves!the!right!to!alter!specifications!without!prior!notice.!
1AEB=E?(&V(%IWA>EF()@CDEFFEDA<@(JADK(X'P(1=AN:=(E@L(&'?(!"#$%&''(
240V!~!50Hz!
AU-ST100!
AU-ST100!
AU-LED5012CV!
Constant!Voltage!
LED!Driver!
12V!DC!
12V!DC!
10m!maximum!
In!one!length!
