Aurora AS1540CD User Manual [en, es, fr]
INSTALLATION
:
Operating Instructions
Installation
Operation
Caution
Trouble Shooting Aurora Paper Shredders
Maintenance
Limited Warranty
Manuel de fonctionnement
Installation
Fonctionnement
Avertissement
Dépannage des déchiquteuses
à papier Aurora
Entretien
Garantie limitée
Instrucciones para operar
Instalaciones
Operación
Avertencia
Solucionar Problemas de la Máquina
Trituradora de Documentos Aurora
Mantenimiento
Garantía Limitada
Sheet Capacity
Credit Card & CD Capacity 1 at a time
Paper Shred Size
Voltage 120V-60Hz 6.5A
Capacité de passage
à la fois
Capacité de CD et
les cartes de crédit
Dimensions des déchets
Tension 120V-60Hz 6.5A
Capacidad de
destruccióna la vez
Capacidad de CDs y
tarjetas de crédito
Tomaño de corte
Voltaje 120V-60Hz 6.5A
en morceaux de 0.08” x 0.39”
en morceaux de 2 mm x 10 mm
15 sheets of
20lb. bond paper
0.08” x 0.39” pieces
2 mm x 10 mm pieces
15 feuilles de papier
bond de 75g/m2 (20lb.)
les introduire un par un
15 hojas de papel de
cartes de 20 libras
introdúzcalos en la ranura
uno por uno
en pedazos de 0.08” x 0.39”
en pedazos de 2 mm x 10 mm
Carefully unpack shredder and connect the power cord to any standard 120 volt AC outlet (FIGURE 1).
Pull open the shredder door and slide in the wastebasket. After installation, make sure the shredder
door is properly closed shut. This shredder features a safety power cut off and will not operate if door
is open. Shredders with pull-out wastebaskets feature a safety power cut off upon bin removal (FIGURE 2).
Caution: MicroShred shredders have very sharp, exposed blades on the underside.
FIGURE 1
OPERATION
FIGURE 2
:
FIGURE 3
POWER: Using the power button or switch, turn on the shredder (FIGURE 4).
The green light will indicate whether if the shredder is powered on.
This button turns off all features of the shredder. For safety reasons,
we recommend that you leave the shredder in the Off position
whenever the shredder is unattended or not in use.
FIGURE 4
I
Power On
O
Power Off
REV: In the unlikely event of a paper jam, the reverse setting can be used to help clear the cutters of
paper that has not passed through. Never attempt to clear a jam by using the reverse function
until you have emptied the wastebasket (FIGURE 3).
Please read these operating instructions before using the unit.
Customer Service: 1
-
800-327-8508 or INFO@AURORACORP.COM
Avant d’utiliser cet appareil, Veuillez lire toutes les instructions.
Service à la clientèle : 1
-
800-327-8508 OU INFO@AURORACORP.COM
Antes de operar esta unida, por favor lea todas las instrucciones.
Servicio al Consumidor: 1
-
800-327-8508 O INFO@AURORACORP.COM
1
(
)
U.S.A. ONLY
(
ETATS-UNIS SEULEMENT
(
LOS ESTADOS UNIDOS SÓLO)
FW: The forward setting can also be used to help clear the cutters in the event of a paper jam.
This allows to manually activate the shredder into cutting mode (FIGURE 3).
Never shred plastic (except credit cards and only by inserting them, one at a time,
through the special credit card slot), continuous forms, anything with adhesive including
)
labels and envelopes, newsprint, or any hard materials. While this shredder will shred
staples and small paperclips, it is recommended that you remove them whenever
possible in order to extend the life of your shredder.
continued on next page
2
OPERATION continued
:
CAUTION continued
:
Features a CD/DVD destroyer:
1) Hold the CD/DVD by the edge and feed one at a time,
releasing when shredding begins.
2) Shredder will stop when the entire disc has been destroyed.
CAUTION:
Do not hold CD/DVD with finger through the center ring while
feeding into the shredder. Serious injury may occur.
Never feed more than one credit card or CD/DVD at a time.
LED Status indicators:
Wastebasket FullPaper Overload Power On (Green Light)
Door is Open (Red Light)
CAUTION
:
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Do not insert foreign objects into
the document feed opening.
Do not spray or keep any aerosol
products in or around shredder.
Avoid loose clothing or jewelry
touching the document feed opening.
Avoid getting hair near the
document feed opening.
Shredder Overheat
- RISK OF FIRE. NEVER dispose of flammable chemicals or materials that have come into contact
with flammable chemicals (for example, nail polish, acetone, gasoline) in the shredder basket.
- Always turn the shredder off and unplug the power cord from the AC outlet before cleaning it,
moving it, or emptying the waste basket.
- Never place the shredder near water or any heat source.
- Keep wastebasket emptied so that the shredder output is not impeded.
- Never use any petroleum based or flammable oils or lubricants in or around the machine as some
oils can combust causing serious injury.
- Never shred envelopes, labels or anything with glue or any sticky substance as this will lead to
paper jams.
- Do not use the shredder if the power cord is damaged in any way.
- Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturers warranty.
- Never let the wastebasket become full. This will lead to shredded material being pulled back up into
the shredder and cause jams.
- Never try to clean/clear the shredder blade.
TROUBLE SHOOTING FOR AURORA PAPER SHREDDERS
The shredder does not work at all.
a) Make sure the shredder is plugged into an outlet which is in good working order.
b) Shredders with pull-out wastebaskets features a safety power cut off upon bin removal.
Make sure the pull-out wastebasket is properly set back into place.
c) In the event that the shredder is run continuously for too long and the motor overheats, a thermal
overload switch will automatically shut the power off. If this happens, move the switch to the off
position for 30 minutes or more before continuing.
The shredder only runs in "Rev" and "Fw" mode.
a) The shredder will not start running until paper, CD/DVD, or credit card is inserted into the appropriate
feed slot. It is normal for the motor to run for a moment after the shredder is powered on but it should
stop until paper is inserted. The trigger that activates the shredder is located directly in the center of
the feed slot. If the paper you are inserting is narrow, it may not be hitting the switch. It is possible
that the trigger, which activates the shredder, has become blocked with paper. Insert an index card,
directly in the center of the feed slot, and apply force. This will usually clear any paper blocking the
switch and force the switch closed.
:
continued on next page
3
MAINTENANCE
We recommend you oil your shredder once a month with vegetable or cooking oil (nothing petroleum
based). Drizzle some oil on a few pieces of paper and feed those pages through the shredder. Do not
spray or keep any aersol products in or around shredder
:
4
