AU Optronics T200XW02-V1 Product Specification

Download

Product Description: 20” WXGA Color TFT-LCD Module

AUO Model Name: T200XW02 V1 Customer Part No/Project Name:

Customer Signature AUO 2006/08/16

Approved By: PL Chen

Reviewed By: Hong Jye Hong

Prepared By: Jerry Lee

www.jxlcd.com

Please return one copy with your signature and comments for our confirmation. AU Optronics Corporation Tel: +886-3-563-2899

Fax: +886-3-563-1590

* No Reproduction and Redistribution Allowed

Product Specifications

20” WXGA Color TFT-LCD Module

Model Name: T200XW02 V1

( ) Preliminary Specifications

(*) Final Specifications

www.jxlcd.com

Contents

ITEM No

COVER

RECORD OF REVISIONS

ELECTRICAL SPECIFICATIONS 3

ELECTRICAL CHARACTREISTICS 3-1

www.jxlcd.com

COLOR INPUT DATA REFERNECE 3-5

CONTENTS

GENERAL DESCRIPTION 1

ABSOLUTE MAXIMUM RATINGS 2

INTERFACE CONNECTIONS 3-2

SIGNAL TIMING SPECIFICATIONS 3-3

SIGNAL TIMING WAVEFORMS 3-4

POWER SEQUENCE 3-6

OPTICAL SFECIFICATIONS 4

MECHANICAL CHARACTERISTICS 5

INTERNATIONAL STANDARDS

SAFETY 6-1

EMC 6-2

PACKING (Green Mark Description) 7

PRECAUTIONS 8

To add the **Note of lamps start

Record of Revision

Version Date No Old Description (V0) New Description(V1) Remark

1.0 06’/04/21 4

1.1 06/04/27

1.2 06/08/16

1 Luminance: 450nit (@6.5mA) Luminance: 400nit (@6.5mA)

Color Coordinates: (Wx,Wy) = (0.295,0.305)

3 1 General Information 16.2M à16.7M Color

Color Coordinates: (Wx,Wy) = (0.30,0.31)

voltage.

www.jxlcd.com

1. General Description

This specification applies to the 20.0 inch Color TFT-LCD Module T200XW02. This module supports the WXGA (1366(H) x 768(V)) screen format and 16.7M colors (6-bits + True Color FRC). All input signals are 1 channel LVDS interface compatible. This module is without any inverter card for backlight.

Features

-WXGA 1366(H) x 768(V) resolution

-Fast response Time (8ms)

-50,000 hours lamp life

-6 CCFL Side Light Design (Cold Cathode Fluorescent Lamp)

-High brightness, High contrast ratio

-Wide viewing angle

-Low power consumption

-Green Design (ROHS Compliance)

-HDTV Ready Module

Application

www.jxlcd.com

Personal TV Multi-function media

Video Game Console

* General Information

The following items are characteristics summary on the table 25 ℃ condition:

Items Specification Unit Note

Active Screen Size 20.04 inches 50.9cm diagonal Display Area 443.61(H) x 249.41(V) mm Outline Dimension Resolution Pixel Pitch 0.32475 x 0.32475 Pixel Arrangement RGB vertical stripe Display mode TN mode, Normally White Display Colors 16.7M (6-bit + True Color FRC) Colors Typical White Luminance Contrast Ratio 700:1(typ.) Color Gamut 72%(typ.) of NTSC Response Time 8ms(typ.) (Tr+Tf) ms Viewing Angle (L/R/U/D) 80/80/70/70 CR>10 Power Consumption 44.4 W (typ.)(Vdd line +CCFL line)** Electronic Interface 1ch LVDS

www.jxlcd.com

Frame rate 60Hz(typ.), 75Hz(max.) Hz Weight(g) 3000(max) g Surface Treatment Hard-Coating 3H, AG ROHS ROHS compliance

472.0(H) × 276.5(V) × 23.0(D) (typ.)* 1366(R,G,B×3) x 768

400 nit (typ.) @ 6.5mA [cd/m2]

mm Without inverter

Pixels

W @6.5mA

* The depth of module is 23mm typ. and 24mm max. ** To consider the loss of Inverter’s efficiency.

2. Absolute Maximum Ratings

The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.

Item Symbol Min Max Unit Note

Logic/LCD Drive Voltage Vdd -0.3 6 [Volt] 1 Input Voltage of Signal Vin -0.3 3.6 [Volt] 1 Operating Temperature TOP 0 +50 [ Operating Humidity HOP 10 90 [%RH] 2 Storage Temperature TST -20 +60 [ Storage Humidity HST 10 90 [%RH] 2

Note 1 : Duration = 50msec

Note 2 : Maximum Wet-Bulb should be 39℃ and No condensation.

C] 2

www.jxlcd.com

3. Electrical Specification

The T200XW02 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and liquid crystal. An inverter typically generates the second input, which powers the CCFL.

3-1 Electrical Characteristics

Values Parameter Symbol

Min Typ Max

LCD: Power Supply Input Voltage Vdd 4.5 5.0 5.5 Vdc Power Supply Input Current Idd - 0.72 0.9 A 1 Power Consumption Pc - 3.6 4.5 Watt 1

Unit Notes

Inrush Current I Backlight Power Consumption - 40.8 43.2 Watt 2 Total Power Consumption - 44.4 46.8 Watt 2 Life Time 50000 - - Hours 3

The performance of the Lamp in LCM, for example lifetime or brightness, is extremely influenced by the characteristics of the DC-AC Inverter. So all the parameters of an inverter should be carefully

www.jxlcd.com

designed so as not to produce too much leakage current from high-voltage output of the inverter. When you design or order the inverter, please make sure unwanted lighting caused by the mismatch of the lamp and the inverter (no lighting, flicker, etc) never occurs. When you confirm it, the LCD Assembly should be operated in the same condition as installed in your instrument. Do not attach a conducting tape to lamp connecting wire. If the lamp wire attach to conducting tape, TFT-LCD Module have a low luminance and the inverter has abnormal action because leakage current occurs between lamp wire and conducting tape. The relative humidity must not exceed 80% non-condensing at temperatures of 40 ℃ or less. At temperatures greater than 40℃, the wet bulb temperature must not exceed 39℃. When operate at low temperatures, the brightness of CCFL will drop and the lifetime of CCFL will be reduced.

Note :

1. Vdd=5.0V, Fv=62Hz, fCLK= 88MHz , 25℃, Vdd Duration time= 470

- - 2.0 A 1

RUSH

The Power supply input check pattern definition and dissipation reference as below :

Dot pattern：0.9A (Max.)

White pattern：0.69 A

Black pattern：0.75 A

1366*768*3 Pixel

Dot pattern (Dot)

1366*768*3 Pixel

Gray Level 255 (White Screen)

Pixel Gray Level 0

RGBRGBRGBRGBRGBRGB

Pixel Gray Level 255

RGBRGBRGBRGBRGBRGB

Pixel Gray Level 255

RGBRGBRGBRGBRGBRGB

Pixel Gray Level 0

www.jxlcd.com

Vertical gray scale pattern：0.72 A(Typ.)

2. The lamp power consumption shown above does include loss of external inverter at 25 ℃. The used lamp current is the lamp current typical value. Assumption: the efficiency of Inverter is 80%. BLU actual power is 32.64W, BLU power consumption need to consider the efficiency of Inverter, and should be 32.64 / 80% = 40.8W (typ) and 43.2W (max). TTL Power = 40.8 + 3.6 = 44.4 W . (typ) and 46.8W (max).

3. The life is determined as the time at which luminance of the lamp is 50% compared to that of initial value at the typical lamp current on condition of continuous operating at 25 ±2℃. The lamp current should fix at 6.5mA(typ.) and then keep the 50000hr(typ.) lamp life

1366*768*3 Pixel

Gray Level 0 (Black Screen)

1366*768*3 Pixel

Vertical Gray Scale

R/G/B Level 0~Level 255 Vertical

Grey Scale pattern

3-2 Interface Connections

- LCD connector (CN1): JAE FI-X30SSL-HF or equivalent

- LVDS Transmitter: SN75LVDS83 (Texas Instruments) or equivalent

Note:

1. All GND (ground) pins should be connected together and should also be connected to the

LCD’s metal frame. All Vcc (power input) pins should be connected together.

Pin No Symbol Description Note

1 Reserved Open or High AUO internal test pin 2 Reserved Open or High AUO internal test pin 3 Reserved Open or High AUO internal test pin 4 GND Ground 5 RIN0- LVDS Channel 0 [Polarity: Negative] 6 RIN0+ LVDS Channel 0 [Polarity: Positive] 7 GND Ground 8 RIN1- LVDS Channel 1 [Polarity: Negative] 9 RIN1+ LVDS Channel 1 [Polarity: Positive]

10 GND Ground 11 RIN2- LVDS Channel 2 [Polarity: Negative] 12 RIN2+ LVDS Channel 2 [Polarity: Positive] 13 GND Ground

www.jxlcd.com

14 RINCLK- LVDS Clock [Polarity: Negative] 15 RINCLK+ LVDS Clock [Polarity: Positive] 16 GND Ground 17 RIN3- LVDS Channel 3 [Polarity: Negative] 18 RIN3+ LVDS Channel 3 [Polarity: Positive] 19 GND Ground 20 Reserved Open AUO internal test pin 21 LVDS Option* Low for JEIDA, High/Open for NS 22 Reserved Open 23 GND Ground 24 GND Ground 25 GND Ground 26 Vdd (+5V) 5V, DC, Regulated 27 Vdd (+5V) 5V, DC, Regulated 28 Vdd (+5V) 5V, DC, Regulated 29 Vdd (+5V) 5V, DC, Regulated 30 Vdd (+5V) 5V, DC, Regulated

LVDS Option : H (3.3V) or Open è NS (Default) L (GND) è JEIDA

u LVDS Option = L (GND)

Previous Cycle Current Cycle Next Cycle

RINCLK+

Clock

RINCLK-

RIN0+ RIN0-

RIN1+ RIN1-

RIN2+ RIN2-

RIN3+

RIN3-

R2R7 G2G2R2R3 R4R5R6 R3

G3B2 B3B3G3G4 G5G6 G4

B4NA DEDEB4B5 B6B7NA B5

R0B1 NANAR0R1 G0G1B0 R1

u LVDS Option = H (3.3V) / Open

Previous Cycle Current Cycle Next Cycle

RINCLK+

www.jxlcd.com

Clock

RINCLK-

RIN0+ RIN0-

R0R5 G0G0R0R1 R2R3R4 R1

RIN1+ RIN1-

RIN2+ RIN2-

RIN3+

RIN3-

G1B0 B1B1G1G2 G3G4G5 G2

B2NA DEDEB2B3 B4B5NA

R6B7 NANAR6R7 G6G7B6 R7

Backlight Connector Pin Configuration

Electrical specification (Lamp spec)

Parameter Min Typ Max Units Condition CCFL current(ICFL) 5.0 6.5 7.0 [mA] rms CCFL Frequency(FCFL) 40 55 70 [KHz] CCFL Ignition Voltage(Vs) 1580** [Volt] rms CCFL Ignition Voltage(Vs) 2050** [Volt] rms CCFL Voltage (Reference) (VCFL) 894 837 823 [Volt] rms CCFL Power consumption (PCFL) 32.64* 34.57 [Watt]

Note. * PCFL = ICFL x VCFL x 6 = 6.5 x 837 x 6 = 32.64 W (typ) PCFL = ICFL x VCFL x 6 = 7 x 823 x 6 = 34.57 W (max) ** It means that the inverter start-up voltage should be larger than 1580 Vrms at 25℃ and 2050 Vrms at 0℃ in order to start the lamps.

Lamp connect configuration Mating connector: SM02B-BHS-1-TB (JST)

www.jxlcd.com

SM02B

(Ta=25℃) (Ta=25℃) (Ta= 25℃) (Ta= 0℃) (Ta=25℃) (Ta=25℃)

(pin1)

Connector mating way: Cable Color: Blue/Pink/White

Blue or White

Pink

White or Blue

Blue or White

Pink

White or Blue

3-3 Signal Timing Specifications

This is the signal timing required at the input of the User connector. All of the interface signal

timing should be satisfied with the following specifications for it’s proper operation.

* Timing Table

*1) CLK signal input must be valid while power supply is applied. *2) Display position is specific by the rise of DE signal only.

Horizontal display position is specified by the falling edge of 1st CLK right after the rise of DE, is displayed on the left edge of the screen. Vertical display position is specified by the rise of DE after a “Low” level period equivalent to eight times of horizontal period. The 1st data corresponding to one horizontal line after the rise of DE is displayed at the top line of screen.

www.jxlcd.com

3.) If a period of DE “High” is less than 1366 CLK or less than 768 lines, the rest of the screen displays black.

4.) The display position does not fit to the screen if a period of DE “High” and the effective data period do not synchronize with each other.

3-4 Signal Timing Waveforms

CLK

Tclk

Tdisp(h)

Tclk

CLK

www.jxlcd.com

Tdisp(v)

Tblk(h)

Tblk(v)

1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1

0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1

3-5 Color Input Data Reference

The brightness of each primary color (red, green and blue) is based on the 8 bit gray scale data input for the color; the higher the binary input, the brighter the color. The table below provides a reference for color versus data input.

COLOR DATA REFERENCE

Color

Basic Color

RED

Input Color Data

RED MSB LSB R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0

Black(L0) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Red 1 Green 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 Blue 0 Cyan 0 Magenta 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 Yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0

www.jxlcd.com

White(L255) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 RED 0 RED 0

---RED 1

MSB LSB

GREEN

BLUE MSB LSB

RED 1

GREEN

BLUE

GREEN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 GREEN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0

---GREEN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 GREEN) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 BLUE 0 BLUE 0

------BLUE 0 BLUE 0

3-6 Power Sequence

Power Supply for LCD (Vdd)

LVDS Data & CLK

Power for LAMP

Values

Parameter

t1 0.47 - 20 ms

www.jxlcd.com

t2 20 - 50 ms t3 700 - - ms t4 10 - - ms t5 1 - 50 ms t6 - - 300 ms t7 1000 - - ms

Apply the lamp voltage within the LCD operating range. When the backlight turns on before the LCD operation or the LCD turns off before the backlight turns off, the display may momentarily become abnormal.

Caution : The above on/off sequence should be applied to avoid abnormal function in the display. In case of handling, make sure to turn off the power when you plug the cable into the input connector or pull the cable out of the connector.

Min. Typ. Max.

Units

4. Optical Specification

Optical characteristics are determined after the unit has been ‘ON’ and stable for approximately 30 minutes in a dark environment at 25℃. The values specified are at an approximate distance 50cm from the LCD surface at a viewing angle of Φ and θequal to 0°.

PR880 or equivalent

Fig.4-1 Optical measurement equipment and method

Parameter

Contrast Ratio CR 600 700 1 Surface Luminance, white LWH 320 400 Luminance Variation Response Time Rise Time Tr 6 12 ms Decay Time

www.jxlcd.com

Color Coordinates

Viewing Angle by ELDIM Contrast Ratio>10

RED R R GREEN G G BLUE B B WHITE W W

Symbol

Min. Typ. Max.

WHITE

9 p 1.25 3

Tγ

Tf 2 4 ms

0.640

0.330

0.290

0.600

0.150

0.060

Typ.-0.03

0.30

Values

8 16 ms 4,5 (Ton+Toff)

Typ.+0.03

0.31

Units Notes

cd/㎡

x axis, right(φ=0°) θr x axis, left(φ=180°) θl y axis, up(φ=90°) θu y axis, down (φ=0°) θd

65 80 Degree 6, 7 65 80 65 70 55 70

Contrast ratio (CR)=

Brightness on the

white (L255

) state

Brightness on the black

(L0

) state

Note:

1. Contrast Ratio (CR) is defined mathematically as:

2. Surface luminance is luminance value at point 1 across the LCD surface 50cm from the surface with all pixels displaying white. From more information see FIG 4-2. When IBL = 6.5mA, LWH=450cd/㎡ (typ.) LWH=Lon1, Where Lon1 is the luminance with all pixels displaying white at center 1 location.

V/2

V/6

Fig.4-2 Optical measurement point

3. The variation in surface luminance, δWHITE is defined (center of Screen) as:

www.jxlcd.com

WHITE(9P)

=Maximum(L

on1

, L

on2

,…,L

)/Minimum(L

on9

H/2 H/6

, L

on1

on2

,…L

on9

)

4. Response time is the time required for the display to transition from white(L255) to black(L0) (Decay Time, TrD=Tf ) and from black(L0) to white(L255) (Rise Time, TrR=Tr ). The response time interval is between the 10% and 90% of 1st frame amplitudes. For additional information see FIG 4-3.

TrD

TrR

Fig.4-3 Response time

5. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are

determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the LCD surface. For more information see FIG 4-5.

6. To be measured with a viewing cone of 1°by Topcon luminance meter ELDIM EZ Contrast 160D.

Fig.4-5 Viewing Angle Definition

www.jxlcd.com

5. Mechanical Characteristics

The contents provide general mechanical characteristics for the model T200XW02. In addition the figures in the next page are detailed mechanical drawing of the LCD.

Outline Dimension

Weight 3000g (max.)

Surface Treatment HC, 3H

www.jxlcd.com

Horizontal (typ.) 472.0mm Vertical (typ.) 276.5mm Depth (typ.) 24.0mm(Max.) Horizontal (typ.) 448.0mm Bezel Area Vertical (typ.) 253.8mm Horizontal 443.61mm Active Display Area Vertical 249.41mm

Front View:

www.jxlcd.com

Rear View:

(35)

(98)

)

(

Pin1

0.2

91 (I/F CONNECTOR)

)

(

155+0.2 (REAR MODE)100+0.2 (REAR MODE)

47 (I/F CONNECTOR)

86+0.2(REAR MODE)86+0.2(REAR MODE)

6. International Standard

6-1. Safety

(1) UL6500, Underwriters Laboratories, Inc. (AUO file number : E204356)

Standard for Safety of Information Technology Equipment Including electrical Business Equipment.

(2) CAN/CSA C22.2 No. 950-95 Third Edition, Canadian Standards Association, Jan. 28, 1995

Standard for Safety of Information Technology Equipment Including Electrical Business Equipment.

(3) EN60950 : 1992+A2: 1993+A2: 1993+C3: 1995+A4: 1997+A11: 1997

IEC 950: 1991+A1: 1992+A2: 1993+C3: 1995+A4:1996 IEC 60065 European Committee for Electro technical Standardization (CENELEC) EUROPEAN STANDARD for Safety of Information Technology Equipment Including Electrical Business Equipment.

6-2. EMC

a) ANSI C63.4 “Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and

Electrical Equipment in the Range of 9kHz to 40GHz. “American National standards Institute(ANSI), 1992

b) C.I.S.P.R “Limits and Methods of Measurement of Radio Interface Characteristics of Information

www.jxlcd.com

Technology Equipment.” International Special committee on Radio Interference.

c) EN 55022 “Limits and Methods of Measurement of Radio Interface Characteristics of Information

Technology Equipment.” European Committee for Electrotechnical Standardization. (CENELEC), 1998

7. Packing

Label Sample

Green Mark Description:

For Pb Free products, AUO will add for identification. For RoHS compatible products, AUO will add for identification.

Note. The Green Mark will be present only when the green documents have been ready by AUO Internal Green Team. (The definition of green design follows the AUO green design checklist .)

Carton Label

ptronics

MODEL NO: T200XW02 VX PART NO: 97.20T02.XXX

CUSTOMER NO: CARTON NO:

QTY: 6

www.jxlcd.com

Made in Taiwan

*PM100-01A1600001*

Cushion set Carton Box, 320mm(W)x590mm(L)x410mm(H)

590

Pallet Package

Air Cargo : (3 *2) *3 layers, total 18 boxes with 108 pcs panel in one pallet

320

1000

1350

940

1200

1180

Ocean shipping : (3 *2) *5layers, total 30 boxes with 180 pcs panel in one pellet

960

Top view Side view

www.jxlcd.com

1180

320

1000

960

530

120

2170

1760

1350

1200

940

530

120

Top view Side view

8. PRECAUTIONS

Please pay attention to the followings when you use this TFT LCD module.

8-1 MOUNTING PRECAUTIONS

(1) You must mount a module using holes arranged in four corners or four sides. (2) You should consider the mounting structure so that uneven force (ex. Twisted stress) is not applied to module. And the case on which a module is mounted should have sufficient strength so that external force is not transmitted directly to the module. (3) Please attach the surface transparent protective plate to the surface in order to protect the polarizer. Transparent protective plate should have sufficient strength in order to the resist external force. (4) You should adopt radiation structure to satisfy the temperature specification. (5) Acetic acid type and chlorine type materials for the cover case are not desirable because the former generates corrosive gas of attacking the polarizer at high temperature and the latter causes circuit break by electro-chemical reaction. (6) Do not touch, push or rub the exposed polarizers with glass, tweezers or anything harder than HB pencil lead. And please do not rub with dust clothes with chemical treatment. Do not touch the surface of polarizer for bare hand or greasy cloth. (Some cosmetics are detrimental to the polarizer.)

www.jxlcd.com

(7) When the surface becomes dusty, please wipe gently with absorbent cotton or other soft materials like chamois soaks with petroleum benzene. Normal-hexane is recommended for cleaning the adhesives used to attach front/ rear polarizers. Do not use acetone, toluene and alcohol because they cause chemical damage to the polarizer. (8) Wipe off saliva or water drops as soon as possible. Their long time contact with polarizer causes deformations and color fading. (9) Do not open the case because inside circuits do not have sufficient strength.

8-2 OPERATING PRECAUTIONS

(1) The spike noise causes the mis-operation of circuits. It should be lower than following

voltage: V=±200mV(Over and under shoot voltage)

(2) Response time depends on the temperature. (In lower temperature, it becomes

longer..)

(3) Brightness depends on the temperature. (In lower temperature, it becomes lower.) And

in lower temperature, response time (required time that brightness is stable after turned on) becomes longer.

(4) Be careful for condensation at sudden temperature change. Condensation makes

damage to polarizer or electrical contacted parts. And after fading condensation, smear

or spot will occur. (5) When fixed patterns are displayed for a long time, remnant image is likely to occur. (6) Module has high frequency circuits. Sufficient suppression to the electromagnetic

interference shall be done by system manufacturers. Grounding and shielding methods

may be important to minimize the interface.

8-3 ELECTROSTATIC DISCHARGE CONTROL

Since a module is composed of electronic circuits, it is not strong to electrostatic discharge. Make certain that treatment persons are connected to ground through wrist band etc. And don ’ t touch interface pin directly.

8-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE

Strong light exposure causes degradation of polarizer and color filter.

8-5 STORAGE

When storing modules as spares for a long time, the following precautions are necessary. (1) Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep the

temperature between 5℃ and 35℃ at normal humidity.

www.jxlcd.com

(2) The polarizer surface should not come in contact with any other object. It is recommended that

they be stored in the container in which they were shipped.

8-6 HANDLING PRECAUTIONS FOR PROTECTION FILM

(1) The protection film is attached to the bezel with a small masking tape. When the protection film is

peeled off, static electricity is generated between the film and polarizer. This should be peeled off slowly and carefully by people who are electrically grounded and with well ion-blown equipment or in such a condition, etc.

(2) When the module with protection film attached is stored for a long time, sometimes there remains

a very small amount of flue still on the Bezel after the protection film is peeled off.

(3) You can remove the glue easily. When the glue remains on the Bezel or its vestige is recognized,

please wipe them off with absorbent cotton waste or other soft material like chamois soaked with normal-hexane.

AU Optronics T200XW02-V1 Product Specification

Specifications and Main Features

Frequently Asked Questions

User Manual
