AU Optronics M201UN03-V0 Product Specification

) Preliminary Specification
( V ( ) Final Specification
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
Module Model Name
20.1 UXGA Color TFT-LCD with LED BL M201UN03 V0
Customer Date
www.jxlcd.com
www.jxlcd.com
Approved by
Checked &
Approved by
CC Chiu
Prepared by
Date
2006/06/13
Note: This Specification is subject to change
without notice.
document version 0.2 1/28
Chris Peng
Desktop Display Business Group /
AU Optronics corporation
2006/06/12
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
Contents
1. Handling Precautions......................................................................................4
2. General Description.......................................................................................5
2.1 Display Characteristics...............................................................................5
2.2 Optical Characteristics...............................................................................6
3. Functional Block Diagram...............................................................................10
4. Absolute Maximum Ratings.............................................................................11
5. Electrical characteristics................................................................................12
5.1 TFT LCD Module.......................................................................................12
5.1.1 Power Specification.............................................................................12
5.2 Backlight Unit.........................................................................................13
5.2.1 Power Specification.............................................................................13
6. Signal Characteristic......................................................................................14
6.1 Pixel Format Image...................................................................................14
6.2 The Input Data Format..............................................................................15
6.3 Signal Description....................................................................................16
6.4 Interface Timing......................................................................................19
6.4.1 Timing Characteristics..........................................................................19
6.4.2 Timing diagram..................................................................................20
6.5 Power ON/OFF Sequence............................................................................21
7. Connector & Pin Assignment...........................................................................22
7.1 TFT LCD Module.......................................................................................22
7.1.1 Connector.........................................................................................22
7.1.2 Pin Assignment...................................................................................22
7.2 Backlight Unit.........................................................................................23
7.2.1 Signal for LED connector.......................................................................24
8. Reliability Test.............................................................................................25
9. Shipping Label.............................................................................................26
10. Mechanical Characteristic.............................................................................27
www.jxlcd.com
www.jxlcd.com
document version 0.2 2/28
28
Record of Revision
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
Version &
Date
2
6/12
Page
All First edition for customer All
2.1 Display Characteristics Power Consumption (VDD line + LED line)
5
55W (typ.) (w/o Inverter, All white pattern)
4. Absolute Maximum Ratings
11
LED Pulse current and LED current
5.1 TFT LCD Module
12
5.1.1 Power Specification VDDns
5.1 TFT LCD Module
12
5.1.1 Power Specification NA
5.2 Backlight Unit
13
1) Backlight power 2) Backlight I2C
www.jxlcd.com
6.5 Power ON/OFF Sequence
www.jxlcd.com
21
1) Diagram: Vin/Signal/Lamp
2) Power Sequence Timing: V1~V7
Old Description New Description Remark
2.1 Display Characteristics Power Consumption (VDD line + LED line)
50.2W (typ.) (with Driver, All white pattern)
4. Absolute Maximum Ratings Added LED Driver Voltage: Vdd and Vcc
5.1 TFT LCD Module
5.1.1 Power Specification NA
5.1 TFT LCD Module
5.1.1 Power Specification
1) Circuit schematic
2) VDD rising time diagram
5.2 Backlight Unit
5.2.1 Power Specification
1) Vdd 2) Vcc 3) Venable
6.5 Power ON/OFF Sequence
1) Diagram: VDD/Vcc/Vdd/Signal/I2C/Venable
2) Power Sequence Timing: T1~T9
Modified
Modified
Deleted
Added
Modified
Modified
7.2 Backlight Unit
1) Backlight Power J08: Mating Type Part# CW3084-AAG1Z (8 pins)
23
2) LED Sensor J09
3) Backlight I2C J10: Mating Type Part# CW3054-AAG1Z (5 pins)
7.2.1 Signal for LED connector Backlight Power: Pin7: Venable
24
Pin8: Vcc
27
10. Mechanical Characterisitc Old version
document version 0.2 3/28
7.2 Backlight Unit
1) Backlight Power J08: Mating Type Part# P24268 (8 pins)
2) NA
3) Backlight I2C J10: Mating Type Part# P24265 (5 pins)
7.2.1 Signal for LED connector Backlight Power: Pin7: Vcc Pin8: Venable
10. Mechanical Characterisitc Update 2D drawing
Modified
Modified
Updated
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a module has to be put back into the packing container slot after once it was taken out from the container. Instead of pressing at the edge softly. Otherwise the TFT module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface Connector of the TFT module.
11) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for example), do not twist nor bend
the TFT Module even momentary. At designing the enclosure, it should be taken into consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise the TFT module may be damaged.
www.jxlcd.com
www.jxlcd.com
document version 0.2 4/28
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
2. General Description
This specification applies to the 20.1 inch Color TFT-LCD Module M201UN03 v.0. The display supports the UXGA (1600(H) x 1200(V)) screen format and 16.7M colors (RGB 8-bits data). All input signals are 2 Channel LVDS interface compatible. This module contains a driver card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 510(20.1") Active Area [mm] 408.0 (H) x 306.0 (V) Pixels H x V 1600(x3) x 1200 Pixel Pitch [mm] 0.255 (per one triad) x 0.255 Pixel Arrangement R.G.B. Vertical Stripe Display Mode Normally Black White Luminance [cd/m2] Contrast Ratio 1000 : 1 (Typ) Optical Response Time
( Raising + Falling)
( Gray to Gray) Nominal Input Voltage VDD [Volt] +5.0 V Power Consumption (VDD line + LED line) Weight [Grams] 3300 (Typ) Physical Size [mm] 432(W) x 331.5(H) x 40(D) Electrical Interface Even/Odd R/G/B data, 3 sync signal,
Support Color 16.7M colors (RGB 8-bit data) Surface treatment Anti-glare (3H) Temperature Range Operating Storage (Shipping) RoHS Compliance RoHS Compliance
www.jxlcd.com
www.jxlcd.com
[msec]
[Watt] 50.2W(typ.) (with Driver, All white pattern)
[oC] [oC]
250 cd/m2 (Typ)
16 (Typ)
8 (Typ)
Clock
0 to +50
-20 to +60
document version 0.2 5/28
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
[degree] Horizontal (Right) 89 -
75
[degree] CR = 10 (Left)
Viewing Angle
[degree] Vertical (Up) 89 -
75
[degree] CR = 10 (Down)
Contrast ratio Normal Direction 700 1000
89 -
89 -
1
Response Time (Note 1)
[msec] Gray to Gray - 8
www.jxlcd.com
Color / Chromaticity
Coordinates (CIE)
Color Coordinates (CIE)
www.jxlcd.com
White
[msec] Raising Time - 11 15
[msec] Falling Time - 5 7
[msec] Raising + Falling - 16 22
Red x 0.661 0.691 0.721
Red y 0.271 0.301 0.331
Green x 0.151 0.181 0.211 Green y 0.671 0.701 0.731
Blue x 0.116 0.146 0.176 Blue y 0.053 0.083 0.113
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
4,6
4,6
4,6
4,6
4
White Luminance at LED
(central point)
Luminance Uniformity [%] 75 80 - 4
Crosstalk (in 60Hz) (Note 3)
document version 0.2 6/28
[cd/m2] 200 250
[%] 1.5
5
Product Specification
Minimum
Luminance
of 9 points
=
Max
imum
Luminance
of 9 points
50 %
90 %
90 %
5
0 % 10 %
10 %
AU OPTRONICS CORPORATION
Optical Equipment: BM-5A, PR880, SR3, CS1000 or equivalent. Note 1: Definition of viewing angle
Viewing angle is the measurement of contrast ratio 10, at the screen center, over a 180° horizontal and 180° vertical range (off-normal viewing angles). The 180° viewing angle range is broken down as follows;
90° (θ) horizontal left and right and 90° (Φ) vertical, high (up) and low (down). The measurement direction is typically perpendicular to the display surface with the screen rotated about its center to develop the
desired measurement viewing angle.
M201UN03 V0
www.jxlcd.com
Note 2: 9 points position
www.jxlcd.com
Note 3: The luminance uniformity of 9 points is defined by dividing the maximum luminance values by the minimum test point luminance
document version 0.2 7/28
δ
W9
Product Specification
TFT-LCD
LCD Panel
AU OPTRONICS CORPORATION
Note 4: Measurement method The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change during measuring. In order to stabilize the luminance, the measurement should be executed after lighting Backlight for 30 minutes in a stable, windless and dark room.
M201UN03 V0
Photo detector
Field=2°
50 cm
www.jxlcd.com
Note 5: Definition of Cross Talk (CT) CT = | YB – YA | / YA × 100 (%)
Where
YA = Luminance of measured location without gray level 0 pattern (cd/m2) YB = Luminance of measured location with gray level 0 pattern (cd/m2)
www.jxlcd.com
Center of the screen
document version 0.2 8/28
Product Specification
G B R G B R G B R G B
Level
DC
Time
AU OPTRONICS CORPORATION
100%
90%
10%
Optical Response Driving Signal
B
A
0%
Note 6: Definition of response time:
M201UN03 V0
Time
TrTf
Algorithm:
16 B Level - A Level then the average of Grey-to-Grey response time is 8ms. ( F= 60 Hz).
TrR(rising time; from All Black to All White) + TrF(Falling time; from All White to All Black ) = 16ms(typ).
Note 7: Subchecker Pattern
Method: Record dBV & DC value with (WESTAR)TRD-100
Amplitude
www.jxlcd.com
www.jxlcd.com
R
G B R G B
DC
log20(dB)Flicker =
Gray Level = L127
Gray Level = L0
Hz) 30Level(at AC
AC
Time
document version 0.2 9/28
Product Specification
G1
D4800
I/F + X
-
PCB
+5V
LVDS
AU OPTRONICS CORPORATION
M201UN03 V0
3. Functional Block Diagram
The following diagram shows the functional block of the 20.1 inches Color TFT-LCD Module:
LVDS
Over
AU ASIC
Gamma
Correction
Timing
Controlle
G1200
D1
DC POWER
+24V, +5V Venable
document version 0.2 10/28
Connector
Converter
www.jxlcd.com
www.jxlcd.com
Receiver
Driving
DC/DC
TFT-LCD
1600*(3)*1200
Pixels
LED
LED Driver
Photo sensor
Product Specification
AU OPTRONICS CORPORATION
4. Absolute Maximum Ratings
Absolute maximum ratings of the module is as following:
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VDD -0.3 +6.0 [Volt]
Select LVDS data order SELLVDS
LED Drive Voltage LED Drive Voltage
Operating Temperature TOP 0 +50 [
Operating Humidity HOP 8 90 [%RH] Note 2,3
Storage Temperature TST -20 +60 [
Storage Humidity HST 8 90 [%RH] Note 2,3
Note 1: Duration= 0.1 msec.
NC NC [Volt]
Vdd Vcc
-0.3 +28.0 [Volt] Note 1
-0.3 +6.0 [Volt]
M201UN03 V0
o
C] Note 2,3
o
C] Note 2,3
Note 2: Maximum Wet-Bulb should be 39and no condensation. Note 3: For quality performance, please refer to AUO IIS (Incoming Inspection Standard).
www.jxlcd.com
www.jxlcd.com
Operating Range Storage Range
document version 0.2 11/28
Product Specification
90%
VDD rising time
0V 5.0V
470 us
AU OPTRONICS CORPORATION
5. Electrical characteristics
5.1 TFT LCD Module
5.1.1 Power Specification
Input power specifications are as follows:
Symbol Parameter Min Typ Max Units
VDD
IDD VDD current
IIDD Inrush VDD current
PDD VDD Power
VDDrp
+5.0V
Logic/LCD Drive
Voltage
Allowable
Logic/LCD Drive
Ripple Voltage
R1 47K
4.5 5 5.5 [Volt] ±10% 1300 1500 [mA] VDD=5V, All White Pattern
7.0 [A] t < 470us
6.5 8.3 [Watt]
Q3 AO6402
100
G
D6 D5 D2 S D1
M201UN03 V0
Condition
VDD=5V, All White Pattern
[mV]
p-p
F1
C1 1uF/16V
VCC
(LCD Module Input)
(High to Low) Control Signal
SW
+12.0V
D2SD1D5
www.jxlcd.com
www.jxlcd.com
C2 1uF/25V
R2
1K
VR1
47K
G
C3
0.01uF/25V
D6
Q3
AO6402
document version 0.2 12/28
Product Specification
Dimming brightness Max.
AU OPTRONICS CORPORATION
M201UN03 V0
5.2 Backlight Unit
5.2.1 Power Specification
Parameter guideline for LED driving board is under stable conditions at 25 (Room Temperature):
Symbol Parameter Min Typ Max Units
Vdd
IDD1 Vdd current
IIDD1 Inrush Vdd current PDD1 Vdd Power
Symbol Parameter Min Typ Max Units
Vcc
IDD2 Vcc current
IIDD2 Inrush Vcc current PDD2 Vcc Power
Backlight Drive
Input Voltage
Backlight Drive
Input Voltage
21.6 24.0 26.4 [Volt] 1800 2400 [mA]
8.0 [A] t < 470us
43.2 55.2 [Watt]
4.5 5.0 5.5 [Volt] 100 200 [mA]
1.0 [A] t < 470us
0.5 1.0 [Watt] Dimming brightness Max.
Condition
Vdd=24V; Vcc=5V ;
Condition
Vdd=24V; Vcc=5V ;
Symbol Parameter Min Typ Max Units Venable
www.jxlcd.com
www.jxlcd.com
Backlight Drive
ON Voltage
1.0 5.0 5.5 [Volt] Vdd=24V; Vcc=5V
Condition
document version 0.2 13/28
Product Specification
R G B R G B R G B R G B R G B R G B R G B R G B 1 2 1
599
1600
1st Line
1200
Line
AU OPTRONICS CORPORATION
6. Signal Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
M201UN03 V0
th
www.jxlcd.com
www.jxlcd.com
document version 0.2 14/28
6.2 The Input Data Format
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
www.jxlcd.com
www.jxlcd.com
Note: R/G/B data 7:MSB, R/G/B data 0:LSB
O = First Pixel Data
E = Second Pixel Data
document version 0.2 15/28
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
6.3 Signal Description
The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels.
PIN # SIGNAL NAME DESCRIPTION 1 RxO0- Negative LVDS differential data input (Odd data) 2 RxO0+ Positive LVDS differential data input (Odd data) 3 RxO1- Negative LVDS differential data input (Odd data) 4 RxO1+ Positive LVDS differential data input (Odd data) 5 RxO2- Negative LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG) 6 RxO2+ Positive LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG) 7 GND Power Ground 8 RxOC- Negative LVDS differential clock input (Odd clock) 9 RxOC+ Positive LVDS differential clock input (Odd clock) 10 RxO3- Negative LVDS differential data input (Odd data) 11 RxO3+ Positive LVDS differential data input (Odd data) 12 RxE0- Negative LVDS differential data input (Even clock) 13 RxE0+ Positive LVDS differential data input (Even data) 14 GND Power Ground
www.jxlcd.com
15 RxE1- Positive LVDS differential data input (Even data) 16 RxE1+ Negative LVDS differential data input (Even data) 17 GND Power Ground 18 RxE2- Negative LVDS differential data input (Even data) 19 RxE2+ Positive LVDS differential data input (Even data) 20 RxEC- Negative LVDS differential clock input (Even clock) 21 RxEC+ Positive LVDS differential clock input (Even clock) 22 RxE3- Negative LVDS differential data input (Even data) 23 RxE3+ Positive LVDS differential data input (Even data) 24 GND Power Ground 25 NC ­26 NC -
www.jxlcd.com
27 NC ­28 POWER Power 29 POWER Power 30 POWER Power
Note: Input signals of odd and even clock shall be the same timing.
document version 0.2 16/28
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
LVDS DATA Name DSP Display Timing: When the signal is high, the pixel data shall be valid to be displayed V-S Vertical Sync: Both Positive and Negative polarity are acceptable H-S Horizontal Sync: Both Positive and Negative polarity are acceptable
TI LVDS Xmitter
SN75LVDS83
Description
Module LVDS signal
(interface connector pin7)
Signal Name Low(open)
D0 Red0 D1 Red1 D2 Red2 D3 Red3 D4 Red4 D5 Red7 D6 Red5 D7 Green0 D8 Green1
D9 Green2 D10 Green6 D11 Green7 D12 Green3 D13 Green4 D14 Green5 D15 Blue0 D16 Blue6 D17 Blue7 D18 Blue1
www.jxlcd.com
www.jxlcd.com
D19 Blue2 D20 Blue3 D21 Blue4 D22 Blue5 D23 NA D24 H Sync D25 V Sync D26 Display Timing D27 Red6
document version 0.2 17/28
Connector
RxO0
-
VDD
Note2: Start from left side
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
www.jxlcd.com
www.jxlcd.com
30
document version 0.2 18/28
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
6.4 Interface Timing
6.4.1 Timing Characteristics
Basically, interface timings described here is not actual input timing of LCD module but output timing of SN75LVDS82DGG (Texas Instruments) or equivalent.
Signal Item Symbol Min Typ Max Unit
Period Tv 1211 1250 1300 Th
Vertical
Section
Horizontal
Section
Frame Rate Frequency Freq/(Tv x Th) 55 60 75 Hz
www.jxlcd.com
www.jxlcd.com
Clock
Note : DE mode only
Active Tdisp(v) 1200 1200 1200 Th
Blanking Tbp(v)+Tfp(v)+PWvs 11 50 100 Th
Period Th 880 1080 1160 Tclk
Active Tdisp(h) 800 800 800 Tclk
Blanking Tbp(h)+Tfp(h)+PWhs 80 280 360 Tclk
Period Tclk 12.0 12.3 17.1 ns
Frequency Freq 59 81 83 MHz
document version 0.2 19/28
6.4.2 Timing diagram
RGB Data
(Even)
RGB Data
(Odd)
Invalid Data
Invalid Data
DE
Tbp(h)
Product Specification
AU OPTRONICS CORPORATION
RGB Data
Line LineLineLineLine Line
N
Invalid Data
PWhs
Hsync
CLK
Tclk
M201UN03 V0
DE
Hsync
Tfp(v)
Vsync
PWvs
Tbp(v)
Pixel
Pixel
2
1
PixelPixel
Pixel
3 9 M-1
4
65
8
10
www.jxlcd.com
12
Pixel
PixelPixelPixel PixelPixelPixel
7
www.jxlcd.com
11
Tdisp(h)
2
Tdisp(v)
43
Tv
M-4
M-2
M
PixelPixelPixelPixel
M-5
M-3
PixelPixel
N1
Th
Invalid Data
Invalid Data
Tfp(h)
Invalid Data
Note :1600X1200 at 60 Hz (VESA STANDARD)
document version 0.2 20/28
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
6.5 Power ON/OFF Sequence
Input power and LED on/off sequence is as follows. Interface signals are also shown in the chart. Signals from any system shall be Hi-Z state or low level when power off.
www.jxlcd.com
www.jxlcd.com
Power Sequence Timing
Symbol
T1 0.5 - 10 [ms] T2 0.5 - 10 [ms]
T3 0.5 40 50 [ms]
T4 400 - - [ms] T5 400 - - [ms]
T6 0.5 16 50 [ms]
T7 0.5 - 10 [ms] T8 0.5 - 10 [ms] T9 1000 - - [ms]
document version 0.2 21/28
Min Typ Max
Values
Unit
Product Specification
AU OPTRONICS CORPORATION
M201UN03 V0
7. Connector & Pin Assignment
Physical interface is described as for the connector on module.These connectors are capable of accommodating the following signals and will be following components.
7.1 TFT LCD Module
7.1.1 Connector
Connector Name / Designation Interface Connector / Interface card Manufacturer JAE or compatible Type Part Number FI-XB30SSL-HF15 or MDF76TW-30S-1H58 Mating Housing Part Number FI-X30S-H
7.1.2 Pin Assignment
Pin# Signal Name Pin# Signal Name
1 RxO0- 2 RxO0+
3 RxO1- 4 RxO1+
5 RxO2- 6 RxO2+
7 GND 8 RxOC-
9 RxOC+ 10 RxO3-
www.jxlcd.com
www.jxlcd.com
11 RxO3+ 12 RxE0­13 RxE0+ 14 GND 15 RxE1- 16 RxE1+ 17 GND 18 RxE2­19 RxE2+ 20 RxEC­21 RxEC+ 22 RxE3­23 RxE3+ 24 GND 25 NC 26 NC 27 NC 28 Power 29 Power 30 Power
document version 0.2 22/28
Product Specification
Venable
Vdd V33 SB
GND
SCL
J08
J09
J10
AU OPTRONICS CORPORATION
M201UN03 V0
7.2 Backlight Unit
Physical interface is described as for the connector on module. These connectors are capable of accommodating the following signals and will be following components.
Connector Name / Designation Connector / Backlight Power
Backlight Power J08
Backlight I2C J10
Note1: Start from upper side
Manufacturer P-Two Type Part Number CW3084-AAG1Z (8 pins)
Mating Type Part Number P24268 (8 pins)
Connector Name / Designation Connector / Backlight I2C Manufacturer P-Two Type Part Number CW3054-AAG1Z (5 pins)
Mating Type Part Number
P24265 (5 pins)
www.jxlcd.com
www.jxlcd.com
document version 0.2 23/28
Product Specification
AU OPTRONICS CORPORATION
7.2.1 Signal for LED connector
Connector No.
Backlight Power
LED sensor
Backlight
I2C(Note 1, 2)
www.jxlcd.com
www.jxlcd.com
Pin No. Label Function
1 Vdd 24V 2 Vdd 24V 3 Vdd 24V 4 GND GND 5 GND GND 6 GND GND 7 Vcc 5V 8 Venable 5V 1 SB Analog signal 2 SR Analog signal 3 SG Analog signal 4 GND GND 5 Vcc 5V 6 V33 3.3V 1 GND GND 2 WP Write Protect (connect to GND enable) 3 Vin 4 SDA Serial Data Line 5 SCL Serial Clock Line
M201UN03 V0
5V(connect to Vcc)
Note 1: Typical application diagram
GND
GND
5V5V
Vcc
Vcc
5V
1
XRST
2
SLEEP
3
CLK_SEL
4
A1
5
A0
6
SDA
7
SCL
8
TEST
9
COLOR
10
BRIGHT CLK_EXT11PWM_B
12
DVDD
HDJD-J822
AVDD SENSE_X SENSE_Y SENSE_Z
VREF_EXT
ROSC
AVSS
ERR_FLAG
PWM_R PWM_G
DVSS
24 23 22 21 20 19 18 17 16 15 14 13
WRITE
Vcc
R/68K
PWMB
GND
PWMG
R/68K R/68K R/68K
PWMR
V33
3.3V
SR SG SB
1
A0
VCC
2
A1
WP
3
A2
SCL
GND4SDA
2K EEPROM
5V
Vcc Vin
R/4.7K
R/4.7K
8 7 6 5
R/4.7K
GND
R/82K
R/10K
GND
Vin
Scalar I2C
H-WRITE
Connecter
READ
I2C BUS
Note 2: Please refer to AVAGO HDJD-J822 in detail.
document version 0.2 24/28
1 2 3 4 5
GND H-WRITE Vin SDA SCL
Product Specification
AU OPTRONICS CORPORATION
8. Reliability Test
Environment test conditions are listed as following table.
Items Required Condition
Temperature Humidity Bias (THB) Ta= 50, ℃ 80%RH, 300hours
M201UN03 V0
Note
High Temperature Operation (HTO) Ta= 50, ℃ 50%RH, 300hours Low Temperature Operation (LTO) Ta= 0, 300hours High Temperature Storage (HTS) Ta= 60, 300hours Low Temperature Storage (LTS) Ta= -20, 300hours
Acceleration: 1.5 G Vibration Test (Non-operation)
Shock Test (Non-operation)
Drop Test Height: 60 cm, package test Thermal Shock Test (TST) -20/30min, 60/30min, 100 cycles On/Off Test On/10sec, Off/10sec, 30,000 cycles
ESD (ElectroStatic Discharge)
www.jxlcd.com
www.jxlcd.com
Wave: Random
Frequency: 10 - 200 - 10 Hz
Sweep: 30 Minutes each Axis (X, Y, Z)
Acceleration: 50 G
Wave: Half-sine
Active Time: 20 ms
Direction: ±X, ±Y, ±Z (one time for each Axis)
Contact Discharge: ± 8KV, 150pF(330Ω ) 1sec,
8 points, 25 times/ point.
Air Discharge: ± 15KV, 150pF(330Ω ) 1sec
8 points, 25 times/ point.
1
2
Altitude Test
Note 1: The TFT-LCD module will not sustain damage after being subjected to 100 cycles of rapid
temperature change. A cycle of rapid temperature change consists of varying the temperature from
-20 to 60, and back again. Power is not applied during the test. After temperature cycling, the unit is placed in normal room ambient for at least 4 hours before power on.
Note 2: According to EN61000-4-2 , ESD class B: Some performance degradation allowed. No data lost.
Self-recoverable. No hardware failures.
document version 0.2 25/28
Operation:10,000 ft Non-Operation:30,000 ft
Product Specification
AU OPTRONICS CORPORATION
9. Shipping Label
The shipping label format is shown as below.
M201UN03 V0
www.jxlcd.com
www.jxlcd.com
document version 0.2 26/28
Product Specification
AU OPTRONICS CORPORATION
10. Mechanical Characteristic
www.jxlcd.com
www.jxlcd.com
M201UN03 V0
document version 0.2 27/28
Product Specification
AU OPTRONICS CORPORATION
www.jxlcd.com
www.jxlcd.com
M201UN03 V0
document version 0.2 28/28
Loading...
