AU OPTRONICS M201EW01 SPECIFICATION

M201EW01 V3

Document Version: 0.2

Date: 2006/02/06

Product Functional Specification

20.1 inch WSXGA+ Color TFT LCD Module Model Name: M201EW01 V3

(u) Preliminary Specification

( ) Final Specification

M201EW01 V3

Note: This Specification is subject to change without notice.

AU OPTRONICS CORPORATION

Product Specification

20.1”Wide SXGA+ Color TFT-LCD Module

Model Name: M201EW01 V.3

Approved by Prepared by

CCChiu

DDBU Marketing Division / AU Optronics corporation

Customer Checked & Approved by

Chris Peng

M201EW01 V3

Contents

1.0 Handling Precautions.............................................................6

2.0 General Description...............................................................7

2.1 Display Characteristics..............................................................................................................7

2.2 Optical Characteristics...............................................................................................................8

3.0 Functional Block Diagram....................................................12

4.0 Absolute Maximum Ratings.................................................13

4.1 TFT LCD Module......................................................................................................................13

4.2 Backlight Unit............................................................................................................................13

4.3 Absolute Ratings of Environment............................................................................................13

5.0 Electrical characteristics......................................................14

5.1 TFT LCD Module......................................................................................................................14

5.1.1 Power Specification...............................................................................................14

5.1.2 Signal Electrical Characteristics..............................................................................15

5.2 Backlight Unit............................................................................................................................16

6.0 Signal Characteristic............................................................17

6.1 Pixel Format Image...................................................................................................................17

6.2 The input data format...............................................................................................................17

6.3 Signal Description ....................................................................................................................18

6.4 Timing Characteristics..............................................................................................................19

6.4.1 Timing diagram....................................................................................................20

6.5 Power ON/OFF Sequence.......................................................................................................21

7.0 Connector & Pin Assignment...............................................22

7.1 TFT LCD Module......................................................................................................................22

7.2 Backlight Unit............................................................................................................................23

7.3 Signal for Lamp connector.......................................................................................................23

8.0 Reliability............................................................................25

9.0 Environment........................................................................26

9.1 Temperature and Humidity.......................................................................................................26

9.1.1 Operating Conditions............................................................................................26

9.1.2 Shipping Conditions..............................................................................................26

9.2 Atmospheric Pressure..............................................................................................................26

10.0 Safety................................................................................27

10.1 Sharp Edge Requirements....................................................................................................27

10.2 Materials..................................................................................................................................27

10.2.1 Toxicity.............................................................................................................27

10.2.2 Flammability......................................................................................................27

M201EW01 V3

10.3 Capacitors...............................................................................................................................27

11.0 Other requirement.............................................................28

11.1 National Test Lab Requirement.............................................................................................28

11.2 Label ........................................................................................................................................28

12.0 Mechanical Characteristics................................................29

M201EW01 V3

Record of Revision

Version and

Date

0.1

Page

Old description New Description Remark

All First Edition for Customer All

2006/01/18

0.2 2006/02/06

16 FCFL Typ: 50; Max: 60 [KHz] FCFL Typ. 55; Max. 80 [KHz]

ViCFL (0oC) Min:1950 [Volt] ViCFL (0oC) Min: 2120 [Volt] ViCF (25oC) Min:1495 [Volt] ViCF (25oC) Min: 1625 [Volt]

VCFL Min 740@8mA

Typ 760@7mA Max 860@3mA

PCFL Typ: 32[Watt] PCFL Typ: 32.9[Watt]

13

14

12

22

4.1 TFT LCD Module Logic/LCD Drive Voltage Max: 6 [Volt]

5.1.1 Power specification IDD Typ 500 Max 550 [mA]

5.1.1 Power specification Irush Max:7 [A]

5.1.1 Power specification PDD Typ:6; Max:7 [Watt] Mating type: HRS: MDF76TW-30S-1H(58) Mating house part number: HRS: MDF76TW-30S-1H(58)

VCFL Min 750@8mA;

Typ 783@7mA; Max 936@3mA

4.1 TFT LCD Module Logic/LCD Drive Voltage Max: 14 [Volt]

5.1.1 Power specification IDD Typ 550 Max 650 [mA]

5.1.1 Power specification Irush Max: 2.5 [A]

5.1.1 Power specification PDD Typ:6.6; Max:8 [Watt] Mating type: F I-X30S-H Mating house part number: FI-X30S-H

M201EW01 V3

1.0 Handling Precautions

1) Since front polarizer is easily damaged, pay attention not to scratch it.

2) Be sure to turn off power supply when inserting or disconnecting from input connector.

3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.

4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.

5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.

6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when handling.

7) Do not open nor modify the Module Assembly.

8) Do not press or pat the panel surface by fingers,hand or tooling

9) Do not press the reflector sheet at the back of the module to any directions.

10) In case if a module has to be put back into the packing container slot after once it was taken out from the container, do not press the center of the CCFL reflector edge. Instead, press at the far ends of the CCFL reflector edge softly. Otherwise the TFT module may be damaged.

11) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface Connector of the TFT module.

12) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for example), do not twist nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise the TFT module may be damaged.

M201EW01 V3

2.0 General Description

This specification applies to the 20.1 inch-wide Color TFT-LCD Module M201EW01. The display supports the WSXGA+ (1680(H) x 1050(V)) screen format and 16.7M colors (RGB 8-bits data). All input signals are 2 Channel LVDS interface compatible. This module does not contain an inverter card for backlight.

2.1 Display Characteristics

The following items are characteristics summary on the table under 25 ℃ condition:

ITEMS Unit SPECIFICATIONS

Screen Diagonal [mm] 511.13 (20.1"Wide) Active Area [mm] 433.44 (H) x 270.90(V) Pixels H x V 1680(x3) x 1050 Pixel Pitch [mm] 0.258 (per one triad) x 0.258 Pixel Arrangement R.G.B. Vertical Stripe Display Mode Normally Black by AUO AMVA White Luminance ( Center ) [cd/m2]

Contrast Ratio 1000 : 1 (Typ) Optical Response Time [msec] 16ms (Typ, on/off) ; 8ms (Average, grey to grey) Color Saturation 72% NTSC Nominal Input Voltage VDD [Volt] +12 V Power Consumption (VDD line + CCFL line) Weight [Grams] 2950 (Typ) Physical Size [mm] 459.4(W) x 296.4(H) x 22.8(D) (Typ) Electrical Interface Even/Odd R/G/B data, 3 sync signal,

Support Color 16.7M colors (RGB 8-bit data ) Temperature Range Operating Storage (Shipping) Surface Treatment Hard-coating (3H), Anti-Glare treatment

[Watt] 30W(Typ) (w/o Inverter, All white pattern)

[oC] [oC]

300 cd/m

Clock

0 to +50

-20 to +60

2 @7mA

(Typ)

M201EW01 V3

2.2 Optical Characteristics

The optical characteristics are measured under stable conditions at 25 ℃:

Item Unit Conditions Min. Typ. Max. Note

Viewing Angle

[degree] [degree]

Contrast ratio Normal Direction Response Time

[msec] Rising Time [msec] Falling Time [msec] Rising + Falling [msec] Grey to Grey

Color / Chromaticity Coordinates (CIE)

Color Coordinates (CIE) White

White Luminance at CCFL 7.0mA (central point)

Luminance Uniformity Crosstalk (in75Hz)

Flicker

[cd/m2]

[%] 75 80 [%] 1.5 DB -20

Horizontal (Right) CR = 10 (Left)

Vertical (Up)

CR = 10 (Down)

(average)

Red x

Red y Green x Green y

Blue x

Blue y White x White y

0.610 0.641 0.670

0.322 0.353 0.382

0.258 0.289 0.318

0.598 0.626 0.658

0.114 0.142 0.174

0.046 0.078 0.106

0.283

0.299

75 75

89 89

750 1000

- 11 25

- 5 15

- 16 40

- 8 -

0.313

0.329

0.343

0.359

240 300 -

-

Note 1 Note 1 Note 1 Note 2

Note 3 Note 4 Note 5

Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (PR 880, BM-5A ,

BM 7 ,CS-1000, & EZContrast* )

Aperture : 1

∘

with 100cm viewing distance (VD) or 2∘with 50cm viewing distance (VD) Test Point: Center (VESA point 9) Environment: < 1 lux

LCD Module

PR-880 /

BM5A /

BM7

/CS-1000

measuring distance

Module Driving Equipment

M201EW01 V3

Time

*’ EZ Contrast is different measurement tool with very close viewing distance.

Note 1: Definition of Response time

The output signals of photodetector are measured when the input signals are changed from “Black” to “White” (rising time), and from “White” to “Black ”(falling time), respectively. The response time is interval between the 10% and 90% of amplitudes.

Note 2: Over-Drive and Response time:

B

A

100%

90%

10%

0%

Optical Response Driving Signal

Algorithm:

16 B Level - A Level ≥ then average Tr≦8ms & average Tf ≦8ms

Time

TrTf

M201EW01 V3

90 %

1/2

1/6 1/6

A B

1/2

1/6

2/3 1/3

1/3 2/3 A’ B’

Note 3: Brightness uniformity of these 9 points is defined as below

90 %

50 %

10 %

Uniformity =

Note 4: Crosstalk is defined as below :

9)-(1 points 9in Luminance Minimum

x 100%

9)-(1 Points 9in Luminance Maximum

10 %

50 %

l LA-LA’ l / LA x 100%= 1.5% max., LA and LB are brightness at location A and B l LB-LB’ l / LB x 100%= 1.5% max., LA’ and LB’ are brightness at location A’ and B’

184 gray level 184 gray level

Unit: percentage of dimension of display area

0 gray level

M201EW01 V3

R G B R G B R G B R G B

Level

DC

Note5: Test Paterm: Subchecker Pattern

R G B R G B

Method: Record dBV & DC value with (WESTAR)TRD-100

Amplitude

Gray Level = L127

Gray Level = L0

DC

Hz) 30Level(at AC

log20(dB)Flicker =

AC

Time

3.0 Functional Block Diagram

The following diagram shows the functional block of the 20.1 inches wide Color TFT/LCD Module:

M201EW01 V3

X-Driver IC

Y

-

Driver IC

DC POWER

AUO ASIC

LVDS

+12V

Connector

LVDS

Receiver

Over-Driver

DC/DC

Converter

Timing

Controller

Gamma

Correction

TFT-LCD

1680*(3)*1050

Pixels

G1050

D1 D5040

Inverter

JAE: FI-XB30SSL-HF15 JST: BHSR-02VS-1 (2 pin)

BHSR-05VS-1 (5 pin) Mating Type: Mating Type:

JAE: FI-X30S-H SM02B-BHSS-1-TB (2 pin) SM04(9-E2)B-BHS-1-TB (5 pin)

4.0 Absolute Maximum Ratings

6 CCFL

Absolute maximum ratings of the module is as following:

4.1 TFT LCD Module

M201EW01 V3

Relative Humidity %

Temperature

℃

-20 0 60 50 90

5

100

0

Operat

ion range

Storage

80

60 40

20

T=40

,H=9

0%

T=60

℃

,H=39%

T=50

℃

,H=55%

Item Symbol Min Max Unit Conditions

Logic/LCD Drive

VIN -0.3 14 [Volt] Note 1,2

4.2 Backlight Unit

Item Symbol Min Max Unit Conditions

CCFL Current ICFL - 8 [mA] rms Note 1,2

4.3 Absolute Ratings of Environment

Item Symbol Min Max Unit Conditions

Operating Humidity HOP 5 90 [%RH] Note

Storage Temperature TST -20 +60 [

Storage Humidity HST 5 90 [%RH] Note

Note 1: With in Ta (25℃ )

o

C] Note

Note 2: Permanent damage to the device may occur if exceed maximum values

range

Twb=39℃

℃

range

5.0 Electrical characteristics

T=65℃,H=29%

5.1 TFT LCD Module

5.1.1 Power Specification

Input power specifications are as follows;

M201EW01 V3

90%

Vin rising time

0V 5.0V

470 us

Symbol Parameter Min Typ Max Units

Condition

VDD

Logic/LCD Drive Voltage

10.8 12 13.2 [Volt] ±10%

IDD VDD current - 550 650 [mA]

Irush LCD Inrush Current - - 2.5 [A] Note

PDD VDD Power - 6.6 8 [Watt]

VDDrp

Allowable Logic/LCD Drive Ripple Voltage

100

[mV]

p-p

Note: Measurement conditions:

(High to Low) Control Signal

SW

+12.0V

+5.0V

R1 47K

R2

1K

D6 D5 D2 S D1

G

C3

Q3 AO6402

D2SD1D5

G

D6

Q3

AO6402

F1

Vin=12V , All White Pattern, at 60Hz

VCC

(LCD Module Input)

C1 1uF/16V

C2 1uF/25V

VR1

47K

0.01uF/25V

5.1.2 Signal Electrical Characteristics

Input signals shall be low or Hi-Z state when Vin is off It is recommended to refer the specifications of SN75LVDS82DGG (Texas Instruments) in detail.

Each signal characteristics are as follows;

Symbol Parameter Min Typ Max Units

Condition

M201EW01 V3

│

VID│

VSS

VTH

VTL

│VID│ Input Differential Voltage 100 400 600 [mV] Note

VICM

Note: LVDS Signal Waveform

VTH

VTL

Differential Input High Threshold Differential Input Low Threshold

Differential Input Common Mode Voltage

VICM

- - +100 [mV]

-100 - - [mV]

+1.0 +1.2 +1.5 [V]

VICM = 1.2V Note VICM = 1.2V Note

VTH/VTL = ±100MV Note

5.2 Backlight Unit

Parameter guideline for CCFL Inverter

Symbol

ISCFL CCFL standard current 6.5 7.0 7.5

Parameter Min. Typ. Max. Unit Condition

[mA]

rms

(Ta=25oC) Note 1

M201EW01 V3

IRCFL CCFL operation range FCFL CCFL Frequency 40 55 80 [KHz] (Ta=25oC) Note 2 ViCFL

(0oC)

ViCF (25oC)

VCFL

PCFL

CCFL Ignition Voltage (End of the lamp wire connector) CCFL Ignition Voltage (End of the lamp wire connector) CCFL Operation Voltage

CCFL Power consumption (for reference)

LTCFL CCFL life Time 40,000 50,000 - [Hour] (Ta=25oC) Note 6

Note 1: CCFL standard current is measured at 25±2℃. Note 2: CCFL Frequency should be carefully determined to avoid interference between inverter and TFT LCD

Note 3: ViCFL means Ignition Voltage for both ends of the lamp, and CCFL inverter should be able to give out a

power that has a generating capacity of over ViCFL for ignition

Note 4: CCFL operation voltage is measured at 25±2℃.

3.0 7.0 8.0

2120 -

1625 -

750

@8mA

783

@7mA

936

@3mA

[mA]

rms

[Volt]

rms

[Volt]

rms

[Volt]

rms

(Ta=25oC)

(Ta=0oC) Note 3

(Ta=25oC) Note 3

(Ta=25oC) Note 4

- 32.9 - [Watt] (Ta=25oC) Note 5

Note 5: The variance of CCFL power consumption is ±10%. Power is calculated for reference

(ICFL×VCFL×6=PCFL).

Note 6: Definition of life: brightness becomes 50% or less than the minimum luminance value of CCFL..The

typical life time of CCFL is on the condition at 6.0 mA lamp current.

6.0 Signal Characteristic

6.1 Pixel Format Image

Following figure shows the relationship of the input signals and LCD pixel format.

M201EW01 V3

R G B R G B R G B R G B R G B R G B R G B R G B 1 2 1679 1680

1st Line

1050

Line

6.2 The input data format

Note 1: R/G/B data 7:MSB, R/G/B data 0:LSB

O = “First Pixel Data”

E = “Second Pixel Data”

6.3 Signal Description

The module using one LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be

M201EW01 V3

PIN #

SIGNAL NAME

DESCRIPTION

1 RxO0-

Negative LVDS differential data input (Odd data)

2 RxO0+

Positive LVDS differential data input (Odd data)

3 RxO1

- Negative LVDS differential data input (Odd data)

4

RxO1+

Positive LVDS differential data input (Odd data)

5

RxO2

- Negative LVDS differ

ential data input (Odd data, H

-

Sync,V

-

Sync,DSPTMG)

6

RxO2+

Positive LVDS differential data input (Odd data, H

-

Sync,V

-

Sync,DSPTMG)

7

GND

Power Ground

8

RxOC

- Negative LVDS differential clock input (Odd clock)

9 RxOC+

Positive LVDS differential clock inp

ut (Odd clock)

10 RxO3

- Negative LVDS differential data input (Odd data)

11

RxO3+

Positive LVDS differential data input (Odd data)

12

RxE0

- Negative LVDS differential data input (Even clock)

13 RxE0+

Positive LVDS differential data input (Even data)

14

GND

Power Ground

15

RxE1

- Positive LVDS differential data input (Even data)

16

RxE1+

Negative LVDS differential data input (Even data)

17 GND

Power Ground

18 RxE2

- Negative LVDS differential data input (Even data)

19

RxE2+

Positive LVDS differential

data input (Even data)

20

RxEC

- Negative LVDS differential clock input (Even clock)

21 RxEC+

Positive LVDS differential clock input (Even clock)

22 RxE3

- Negative LVDS differential data input (Even data)

23

RxE3+

Positive LVDS differential data input

(Even data)

24

GND

Power Ground

25 NC No contact (For AUO test only)

26 NC No contact (For AUO test only)

27 NC

No contact (For AUO test only)

28

POWER

Power

29

POWER

Power

30

POWER

Power

SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels.

Note1: Start from left side

M201EW01 V3

Tfp(v) PWhs

Connector

RxO IN

0

-

VCC

30

Note2: Input signals of odd and even clock shall be the same timing.

6.4 Timing Characteristics

Basically, interface timings described here is not actual input timing of LCD module but output timing of SN75LVDS82DGG (Texas Instruments) or equivalent.

Signal Item Symbol Min Typ Max Unit

Period Tv

1061 1087 1600 Th

Vertical Section

Active Tdisp(v) 1050 1050 1050 Th

Blanking Tbp(v)+Tfp(v)+PWvs 11 37 550 Th

Period Th 920 1128 1400 Tclk

Horizontal

Active Tdisp(h) 840 840 840 Tclk

Section

Blanking Tbp(h)+Tfp(h)+PWhs 80 288 560 Tclk

Period Tclk 12.3 13.6 16.67 ns

Clock

Frequency Freq 60 73.5 81 MHz

Frame rate Frame rate F 55 60 75 Hz

Note : DE mode only

6.4.1 Timing diagram

RGB Data

(Even)

RGB Data

(Odd)

DE

HsyncD

CLK

RGB Data

E

Line

N

Hsync

Vsync

M201EW01 V3

6.5 Power ON/OFF Sequence

M201EW01 V3

Vin power and lamp on/off sequence is as follows. Interface signals are also shown in the chart. Signals from any system shall be Hi-Z state or low level when Vin is off.

Vin10%

Signal

Lamp

90%90%

10%

0V

T2T5T6T7

T1

0V

T4

T3

0V

Symbol

Min Typ Max

T1 0.5 - 10 [ms] T2 0.5 40 50 [ms] T3 200 - - [ms] T4 200 - - [ms] T5 0.5 16 50 [ms] T6 - - 10 [ms] T7 1000 - - [ms]

Values

T4

10%

Unit

7.0 Connector & Pin Assignment

Physical interface is described as for the connector on module. These connectors are capable of accommodating the following signals and will be following components.

M201EW01 V3

7.1 TFT LCD Module

Connector Name / Designation Interface Connector / Interface card Manufacturer JAE or compatible Type Part Number FI-XB30SSL-HF15

Mating Housing Part Number JAE: FI-X30S-H

Pin# Signal Name Pin# Signal Name

1 RxO0- 2 RxO0+

3 RxO1- 4 RxO1+ 5 RxO2- 6 RxO2+ 7 GND 8 RxOC9 RxOC+ 10 RxO3-

11 RxO3+ 12 RxE013 RxE0+ 14 GND 15 RxE1- 16 RxE1+ 17 GND 18 RxE219 RxE2+ 20 RxEC21 RxEC+ 22 RxE323 RxE3+ 24 GND 25 NC 26 NC 27 NC 28 Power 29 Power 30 Power

7.2 Backlight Unit

Connector Name / Designation Lamp Connector / Backlight lamp

M201EW01 V3

Lamp 1

Manufacturer JST

Type Part Number

Mating Type Part Number

7.3 Signal for Lamp connector

Connector No.

CN2

Upper

CN3

CN4

Lower

CN5

Pin No. Color Function

1 Pink High Voltage (Lamp 1) 2 Sky Blue High Voltage (Lamp 2) 3 NC NC 4 Black Low Voltage (Lamp 1) 5 Dark Blue Low Voltage (Lamp 2) 1 White High Voltage (Lamp 3) 2 White Low Voltage (Lamp 3) 1 White High Voltage (Lamp 4) 2 White Low Voltage (Lamp 4) 1 Pink High Voltage (Lamp 6) 2 Sky Blue High Voltage (Lamp 5) 3 NC NC 4 Black Low Voltage (Lamp 6) 5 Dark Blue Low Voltage (Lamp 5)

BHSR-02VS-1 (CN3/CN4) BHSR-05VS-1 (CN2/CN5)

SM02B-BHSS-1-TB (2pin) SM04 (9-E2) B-BHS-1-TB (5pin)

Upper

M201EW01 V3

8.0 Reliability

Reliability test condition

No Test Item Test Condition

M201EW01 V3

1 Temperature Humidity Bias (THB) 2 High Temperature Operation (HTO) 3 Low Temperature Operation (LTO) 4 High Temperature Storage (HTS) 5 Low Temperature Storage (LTS) 6 Thermal Shock Test (TST) 7 On/Off Test On/10sec, Off/10sec, 30,000 cycles 8 Shock Test (Non-Operating) 50G, 20ms, Half-sine wave (+ X, +Y, +Z) 9 Vibration Test (Non-Operating) 1.5G(10~200Hz P- P), 30 Minutes each Axis (X, Y, Z) 10 Drop test 11 ESD (ElectroStatic Discharge) Contact Discharge: ± 8KV, 150pF(330Ω ) 1sec, 8 points, 25 times/ point

12 Altitude Test Operation:10,000 ft

50℃, 80%, 300hours 50℃, 300hours 0℃, 300hours 60℃, 300hours

-20℃, 300hours

-20℃/30min, 60℃/30min, 100 cycles

Package test: The drop height is 60cm.

Air Discharge: ± 15KV, 150pF(330Ω ) 1sec, 8 points, 25 times/ point

Non-Operation:30,000 ft

9.0 Environment

The display module will meet the provision of this specification during operating condition or after storage

M201EW01 V3

or shipment condition specified below. Operation at 10% beyond the specified range will not cause physical damage to the unit.

9.1 Temperature and Humidity

9.1.1 Operating Conditions

The display module operates error free, when operated under the following conditions; Temperature 0 0C to 50 0C Relative Humidity 5% to 90% Wet Bulb Temperature 39.0 0C

9.1.2 Shipping Conditions

The display module operates error free, after the following conditions; Temperature -20 0C to 60 0C Relative Humidity 5% to 90% Wet Bulb Temperature 39.0 0C

9.2 Atmospheric Pressure

The display assembly is capable of being operated without affecting its operations over the pressure

range as following specified;

Pressure Note

Maximum Pressure 1040hPa 0m = sea level

Minimum Pressure 674hPa 3048m = 10.000 feet

Note : Non-operation attitude limit of this display module = 30,000 feet. = 9145 m.

10.0 Safety

10.1 Sharp Edge Requirements

M201EW01 V3

There will be no sharp edges or comers on the display assembly that could cause injury.

10.2 Materials

10.2.1 Toxicity

There will be no carcinogenic materials used anywhere in the display module. If toxic materials are used, they will be reviewed and approved by the responsible ADT Toxicologist.

10.2.2 Flammability

All components including electrical components that do not meet the flammability grade UL94-V1 in the module will complete the flammability rating exception approval process.

The printed circuit board will be made from material rated 94-V1 or better. The actual UL flammability rating will be printed on the printed circuit board.

10.3 Capacitors

If any polarized capacitors are used in the display assembly, provisions will be made to keep them from being inserted backwards.

11.0 Other requirement

11.1 National Test Lab Requirement

M201EW01 V3

M201EW01 V.3

The display module will satisfy all requirements for compliance to

UL 1950, First Edition U.S.A. Information Technology Equipment CSA C22.2 No.950-M89 Canada, Information Technology Equipment EEC 950 International, Information Technology Equipment EN 60 950 International, Information Processing Equipment

(European Norm for IEC950)

11.2 Label

The label is on the panel as shown below:

12.0 Mechanical Characteristics

Ver0.2 29/32

Ver0.2 30/32

AU OPTRONICS M201EW01 SPECIFICATION

Specifications and Main Features

Frequently Asked Questions

User Manual
