Module 14.0” (13.98”) HD+ 16:9 Color TFT-LCD
with LED Backlight design
AU OPTRONICS CORPORATION
Model Name
Note ( )
Customer Date
Checked &
Approved by
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 (H/W:1A)
LED Backlight with driving circuit design
Date
Approved by Date
Ivy Lee
Prepared by Date
04/17/2009
Note: This Specification is subject to change
without notice.
B140RW01 V0 Document Version : 1.0
Yiwen Chen
NBBU Marketing Division
AU Optronics corporation
04/17/2009
1 of 34
Product Specification
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions ........................................................................... 4
2. General Description ............................................................................. 5
2.1 General Specification ..........................................................................................................................5
2.2 Optical Characteristics ........................................................................................................................6
3. Functional Block Diagram .................................................................. 11
4. Absolute Maximum Ratings................................................................ 12
4.1 Absolute Ratings of TFT LCD Module.............................................................................................12
4.2 Absolute Ratings of Environment .....................................................................................................12
5. Electrical Characteristics.................................................................... 13
5.1 TFT LCD Module..............................................................................................................................13
5.2 Backlight Unit ...................................................................................................................................15
6. Signal Interface Characteristic........................................................... 16
6.1 Pixel Format Image ...........................................................................................................................16
6.2 The Input Data Format ......................................................................................................................17
6.3 Integration Interface Requirement.....................................................................................................19
6.4 Interface Timing ................................................................................................................................21
7. Panel Reliability Test.......................................................................... 24
7.1 Vibration Test ....................................................................................................................................24
7.2 Shock Test .........................................................................................................................................24
www.jxlcd.com
7.3 Reliability Test...................................................................................................................................24
8. Mechanical Characteristics................................................................. 25
8.1 LCM Outline Dimension...................................................................................................................25
8.2 Screw Hole Depth and Center Position.............................................................................................27
9. Shipping and Package ........................................................................ 28
9.1 Shipping Label Format ..........................................................................28
9.2 Carton Package..................................................................................................................................29
9.3 Shipping Package of Palletizing Sequence........................................................................................29
10. Appendix: EDID Description ............................................................. 30
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
2 of 34
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page
1.0 2009/04/16 All First Final Spec. Edition for Customer
Old description New Description Remark
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
3 of 34
Product Specification
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input
connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration
or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate
AU OPTRONICS CORPORATION
nor tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock,
DO NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT
module that a LED light bar build in as a light source of back light unit. It can prevent
electrostic breakdown.
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
4 of 34
Product Specification
Thickne
2. General Description
B140RW01 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD
panel, a driver circuit, and LED backlight system. The screen format is intended to support
the 16:9 HD, 1600(H) x900(V) screen and 262k colors (RGB 6-bits data driver) with LED
backlight driving circuit. All input signals are LVDS interface compatible.
BXXXEWXX VX is designed for a display unit of notebook style personal computer and
industrial machine.
AU OPTRONICS CORPORATION
2.1 General Specification
The following items are characteristics summary on the table at 25 ℃ condition:
Items Unit Specifications
Screen Diagonal [mm] 354.95
Active Area [mm] 309.60 X 174.15
Pixels H x V 1600x3(RGB) x 900
Pixel Pitch [mm] 0.1935X0.1935
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
www.jxlcd.com
www.jxlcd.com
White Luminance (I
(Note: ILED is LED current)
Luminance Uniformity 1.25 max. (5 points)
Contrast Ratio 500 typ
LED
=20mA)
[cd/m2] 250 typ. (5 points average)
230 min. (5 points average)
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 5.5 max. (Include Logic and Blu power)
Weight [Grams] 375 max.
Physical Size
Include bracket
Electrical Interface 2 channel LVDS
Glass Thickness [mm] 0.5
Surface Treatment Glare, Hardness 3H,
Support Color 262K colors ( RGB 6-bit )
B140RW01 V0 Document Version : 1.0
[mm]
Min. Typ. Max.
Length 323.5 324
Width 192 192.5
ss - 5.4
5 of 34
Product Specification
RoHS Compliance
0.650
0.370
0.360
0.600
0.180
0.090
0.343
0.359
Temperature Range
Operating
Storage (Non-Operating)
RoHS Compliance
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25℃ (Room Temperature) :
AU OPTRONICS CORPORATION
[oC]
[oC]
0 to +50
-20 to +60
Item Symbol
White Luminance
I
LED
=20mA
Viewing Angle
Luminance
Uniformity
Luminance
Uniformity
Contrast Ratio CR
Cross talk %
www.jxlcd.com
www.jxlcd.com
Response Time
Red
Color /
Green
Chromaticity
Coodinates
Blue
White
Conditions Min. Typ. Max. Unit Note
5 points average
Horizontal (Right)
CR = 10 (Left)
Vertical (Upper)
CR = 10 (Lower)
5 Points
13 Points
θR
θL
ψH
ψL
δ5P
δ
13P
400 500 -
4
Tr Rising
Tf Falling
TRT Rising + Falling
Rx
Ry
Gx
Gy
Bx
CIE 1931
By
Wx
Wy
230 250 -
60
60
50
50
65
65
55
55
- - 1.25
- - 1.50
-
6
- 2 4.5
- 8 16
0.590 0.620
0.310 0.340
0.300 0.330
0.540 0.570
0.120 0.150
0.030 0.060
0.283 0.313
0.299 0.329
-
-
-
-
11.5
2
cd/m
degree
1, 4, 5.
4, 9
1, 3, 4
2, 3, 4
4, 6
4, 7
msec 4, 8
4
NTSC %
B140RW01 V0 Document Version : 1.0
- 60 -
6 of 34
Product Specification
=
Maximum Brightness of thirteen points
Minimum Brightness of thirteen points
Maximum Brightness of five
points
=
Minimum Brightness of five points
Note 1: 5 points position (Ref: Active area)
H /4
H /4
AU OPTRONICS CORPORATION
W / 4 W /4 W /4 W / 4
W
1 2
H
H /4
H /4
Note 2: 13 points position (Ref: Active area)
W /4
1 0
1 0
H /4
www.jxlcd.com
www.jxlcd.com
H /4
H
H /4
1
6
3
4
W
W /4
4 5
W /4
2
7
5
W /4
1 0
3
8
9
H /4
1 0
1 1
1 2
Note 3: The luminance uniformity of 5 or13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
δ
W5
1 0
1 3
δ
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting
B140RW01 V0 Document Version : 1.0
W13
7 of 34
Product Specification
Field
=2°
Contrast ratio (CR)=
Brightness on the “White” state
Brightness on the “Black” state
AU OPTRONICS CORPORATION
Backlight for 30 minutes in a stable, windless and dark room, and it should be measured in the center of screen.
Photo detector
Note 5： Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points，Y
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6： Definition of contrast ratio:
Note 7： Definition of Cross Talk (CT)
CT = | YB – YA | / YA × 100 (%)
Where
www.jxlcd.com
www.jxlcd.com
Contrast ratio is calculated with the following formula.
= [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L
YA = Luminance of measured location without gray level 0 pattern (cd/m2)
YB = Luminance of measured location with gray level 0 pattern (cd/m2)
B140RW01 V0 Document Version : 1.0
8 of 34
Product Specification
Note 8: Definition of response time:
The output signals of BM-7 or equivalent are measured when the input signals are changed from “Black” to
“White” (falling time) and from “White” to “Black” (rising time), respectively. The response time interval between
the 10% and 90% of amplitudes. Refer to figure as below.
AU OPTRONICS CORPORATION
"Black"
100%
S
i
90%
g
n
a
l
(
R
e
l
a
t
i
v
www.jxlcd.com
e
www.jxlcd.com
v
a
l
u
10%
e
)
0%
Tr
Tf
"White""White"
B140RW01 V0 Document Version : 1.0
9 of 34
Product Specification
Note 9. Definition of viewing angle
Viewing angle is the measurement of contrast ratio ≧10, at the screen center, over a 180° horizontal and
180° vertical range (off-normal viewing angles). The 180° viewing angle range is broken down as follows; 90°
(θ) horizontal left and right and 90° (Φ) vertical, high (up) and low (down). The measurement direction is
AU OPTRONICS CORPORATION
typically perpendicular to the display surface with the screen rotated about its center to develop the desired
measurement viewing angle.
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
10 of 34
Product Specification
3. Functional Block Diagram
The following diagram shows the functional block of the 14.0 inches wide Color TFT/LCD 40 Pin one
channel Module
AU OPTRONICS CORPORATION
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
11 of 34
Product Specification
4. Absolute Maximum Ratings
An absolute maximum rating of the module is as following:
4.1 Absolute Ratings of TFT LCD Module
Item Symbol Min Max Unit Conditions
AU OPTRONICS CORPORATION
Logic/LCD Drive Voltage
Vin -0.3 +4.0 [Volt] Note 1,2
4.2 Absolute Ratings of Environment
Item Symbol Min Max Unit Conditions
Operating Temperature
Operation Humidity HOP 5 95 [%RH] Note 4
Storage Temperature
Storage Humidity HST
Note 1: At Ta (25℃ )
Note 2: Permanent damage to the device may occur if exceed maximum values
Note 3: LED specification refer to section 5.2
Note 4: For quality performance, please refer to AUO IIS (Incoming Inspection Standard).
www.jxlcd.com
www.jxlcd.com
TOP 0 +50 [oC] Note 4
TST -20 +60 [oC] Note 4
5 95
Twb=39°C
[%RH]
Note 4
Operating Range
B140RW01 V0 Document Version : 1.0
Storage Range
12 of 34
Product Specification
Voltage
-
90%
10%
5. Electrical Characteristics
5.1 TFT LCD Module
5.1.1 Power Specification
Input power specifications are as follows;
The power specification are measured under 25℃ and frame frenquency under 60Hz
Symble Parameter Min Typ Max Units Note
VDD Logic/LCD Drive
AU OPTRONICS CORPORATION
3.0
3.3 3.6 [Volt]
PDD VDD Power
IDD IDD Current
I
Rush
Inrush Current
VDDrp Allowable
Logic/LCD Drive
Ripple Voltage
Note 1 : Maximum Measurement Condition：Black Pattern at 3.3V driving voltage. (P
Note 2：Measure Condition
www.jxlcd.com
www.jxlcd.com
- -
- -
- -
- 1.5 [Watt] Note 1
454
2000
100 [mV]
[mA] Note 1
[mA]
p-p
Note 2
max=V3.3
x I
black
)
0V
B140RW01 V0 Document Version : 1.0
0.5ms
Vin rising time
3.3V
13 of 34
Product Specification
5.1.2 Signal Electrical Characteristics
Input signals shall be low or High-impedance state when VDD is off.
Signal electrical characteristics are as follows;
AU OPTRONICS CORPORATION
Parameter
Vth
Vtl
VID
Vcm
Note: LVDS Signal Waveform
www.jxlcd.com
Differential Input High
Threshold (Vcm=+1.2V)
Differential Input Low
Threshold (Vcm=+1.2V)
Differential Input
Voltage
Differential Input
Common Mode Voltage
www.jxlcd.com
Condition Min Max Unit
-100
100
0.05
100
[mV]
-
-
1.9
[mV]
[mV]
[V]
B140RW01 V0 Document Version : 1.0
14 of 34
5.2 Backlight Unit
5.2.1 LED characteristics
Parameter
Product Specification
AU OPTRONICS CORPORATION
Symbol
Min Typ Max Units
Condition
Backlight Power
Consumption
LED Life-Time
Note 1: Calculator value for reference P
Note 2: The LED life-time define as the estimated time to 50% degradation of initial luminous.
5.2.2 Backlight input signal characteristics
Parameter
LED Power Supply VLED 6.0 12.0 21.0 [Volt]
LED Enable Input
High Level
LED Enable Input
Low Level
PWM Logic Input
High Level
PWM Logic Input
Low Level
www.jxlcd.com
www.jxlcd.com
PLED - - 3.67
N/A 15000 - -
= VF (Normal Distribution) * IF (Normal Distribution) / Efficiency
LED
Symbol
VLED_EN
VPWM_EN
Min Typ Max Units Remark
2.5 - 5.5 [Volt]
- - 0.8 [Volt]
2.5 - 5.5
- - 0.8
[Watt]
Hour
[Volt]
[Volt]
(Ta=25℃), Note 1
Vin =12V
(Ta=25℃), Note 2
IF=20 mA
Define as
Connector
Interface
(Ta=25℃)
PWM Input Frequency
PWM Duty Ratio
B140RW01 V0 Document Version : 1.0
FPWM 100 - 20K
Duty 5 -- 100
Hz
%
15 of 34
Product Specification
6. Signal Interface Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
1600 1
AU OPTRONICS CORPORATION
1st Line
900th Line
R G B R G B
R G B R G B
www.jxlcd.com
www.jxlcd.com
R G B R G B
R G B R G B
B140RW01 V0 Document Version : 1.0
16 of 34
Product Specification
Data Clock
6.2 The Input Data Format
AU OPTRONICS CORPORATION
Signal Name
R5
R4
R3
R2
R1
R0
G5
G4
G3
G2
G1
G0
B5
B4
B3
B2
B1
B0
RxCLKIN
Description
Red Data 5 (MSB)
Red Data 4
Red Data 3
www.jxlcd.com
www.jxlcd.com
Red Data 2
Red Data 1
Red Data 0 (LSB)
Red-pixel Data
Green Data 5 (MSB)
Green Data 4
Green Data 3
Green Data 2
Green Data 1
Green Data 0 (LSB)
Green-pixel Data
Blue Data 5 (MSB)
Blue Data 4
Blue Data 3
Blue Data 2
Blue Data 1
Blue Data 0 (LSB)
Blue-pixel Data
Red-pixel Data
Each red pixel's brightness data consists of
these 6 bits pixel data.
Green-pixel Data
Each green pixel's brightness data consists of
these 6 bits pixel data.
Blue-pixel Data
Each blue pixel's brightness data consists of
these 6 bits pixel data.
The signal is used to strobe the pixel data and
DE signals. All pixel data shall be valid at the
falling edge when the DE signal is high.
B140RW01 V0 Document Version : 1.0
17 of 34
Product Specification
DE Display Timing This signal is strobed at the falling edge of
VS Vertical Sync The signal is synchronized to RxCLKIN .
HS Horizontal Sync The signal is synchronized to RxCLKIN .
Note: Output signals from any system shall be low or High-impedance state when VDD is off.
AU OPTRONICS CORPORATION
RxCLKIN. When the signal is high, the pixel
data shall be valid to be displayed.
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
18 of 34
Product Specification
6.3 Integration Interface Requirement
6.3.1 Connector Description
Physical interface is described as for the connector on module.
These connectors are capable of accommodating the following signals and will be following
components.
Connector Name / Designation For Signal Connector
AU OPTRONICS CORPORATION
Manufacturer
Type / Part Number
Mating Housing/Part Number
IPEX 20455-040E-12A
IPEX 20453-040T-11
IPEX or Compatiable
or Compatiable
or Compatiable
6.3.2 Pin Assignment
LVDS is a differential signal technology for LCD interface and high speed data transfer device.
PIN NO Symbol Function
1 DIAG_LOOP Diag pin for Dell testing. Pin 1 & 34 must be connected together on the inverter board
2 VDD Power Supply, 3.3 V (typical)
3 VDD Power Supply, 3.3 V (typical)
4 V EEDID DDC 3.3V power
5 TEST Panel Self Test
6 Clk EEDID DDC Clock
7 DATA EEDID DDC Data
8 Odd_Rin0- - LVDS differential data input (R0-R5, G0) (odd pixels)
www.jxlcd.com
www.jxlcd.com
9 Odd_Rin0+ + LVDS differential data input (R0-R5, G0) (odd pixels)
10 VSS Ground – Shield
11 Odd_Rin1- - LVDS differential data input (G1-G5, B0-B1) (odd pixels)
12 Odd_Rin1+ + LVDS differential data input (G1-G5, B0-B1) (odd pixels)
13 VSS Ground – Shield
14 Odd_Rin2- - LVDS differential data input (B2-B5, HS, VS, DE) (odd pixels)
15 Odd_Rin2+ + LVDS differential data input (B2-B5, HS, VS, DE) (odd pixels)
16 VSS Ground – Shield
17 Odd_ClkIN- - LVDS differential clock input (odd pixels)
18 Odd_ClkIN+ + LVDS differential clock input (odd pixels)
19 VSS Ground – Shield
20 Even_Rin0- - LVDS differential data input (R0-R5, G0) (even pixels)
21 Even_Rin0+ + LVDS differential data input (R0-R5, G0) (even pixels)
22 VSS Ground – Shield
B140RW01 V0 Document Version : 1.0
19 of 34
Product Specification
23 Even_Rin1- - LVDS differential data input (G1-G5, B0-B1) (even pixels)
24 Even_Rin1+ + LVDS differential data input (G1-G5, B0-B1) (even pixels)
25 VSS Ground – Shield
26 Even_Rin2- - LVDS differential data input (B2-B5, HS, VS, DE) (even pixels)
27 Even_Rin2+ + LVDS differential data input (B2-B5, HS, VS, DE) (even pixels)
28 VSS Ground – Shield
29 Even_ClkIN- - LVDS differential clock input (even pixels)
30 Even_ClkIN+ + LVDS differential clock input (even pixels)
31 VSSLED Ground - LED
32 VSSLED Ground - LED
33 VSSLED Ground - LED
34 DIAG_LOOP Diag pin for Dell testing. Pin 1 & 34 must be connected together on the inverter board
35 PWM System PWM Signal Input (+3.3V Swing)
36 LED_EN LED enable pin (+3.3V Input)
AU OPTRONICS CORPORATION
37 NC NC
38 VDDLED 7.5V – 21V LED power
39 VDDLED 7.5V – 21V LED power
40 VDDLED 7.5V – 21V LED power
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
20 of 34
Product Specification
VLED
NC
Connector
AU OPTRONICS CORPORATION
Pin 40
Note1: Input signals shall be low or High-impedance state when VDD is off.
www.jxlcd.com
www.jxlcd.com
Pin 1
6.4 Interface Timing
6.4.1 Timing Characteristics
Basically, interface timings should match the 1600x900 /60Hz manufacturing guide line timing.
Parameter Symbol Min. Typ. Max. Unit
Frame Rate - - 60 - Hz
Clock frequency 1/ T
Period TV 908 912 2047
Vertical
Active TVD 900
Section
Blanking TVB 8 12 -
20 53 85 MHz
Clock
T
Line
Horizontal
Section
Period TH 830 965 1024
Active THD 800
Blanking THB 30 165 -
T
Clock
Note : DE mode only
6.4.2 Timing diagram
B140RW01 V0 Document Version : 1.0
21 of 34
DOTCLK
Input
Data
DE
DE
T
CLOCK
Invaild
Data
Product Specification
AU OPTRONICS CORPORATION
Input Timing Definition ( DE Mode)
Pixel
1
T
HB
T
VB
Pixel
2
T
Pixel
3
T
HD
H
T
V
Pixel
N-1
T
VD
Pixel
N
Invaild
Data
Pixel
1
www.jxlcd.com
www.jxlcd.com
B140RW01 V0 Document Version : 1.0
22 of 34
Product Specification
6.5 Power ON/OFF Sequence
Power on/off sequence is as follows. Interface signals and LED on/off sequence are also shown in
the chart. Signals from any system shall be Hi-Z state or low level when VDD is off
AU OPTRONICS CORPORATION
Note:If T3,T5,T6 couldn’t match above specifications, must request T3+T5+T6 > 200ms
www.jxlcd.com
www.jxlcd.com
Power Sequence Timing
Value
Parameter
T1
T2
T3
T4
T5
T6
T7
T8
T9
T10
T11
T12
T13
Min. Typ. Max.
0.5
5
0.5
400
200
200
0.5
10
10
10
10
0.5
5
-
-
-
-
-
-
-
-
-
-
-
-
-
10
50
50
-
-
-
10
---
---
---
---
10
50
Units
ms
at least
B140RW01 V0 Document Version : 1.0
23 of 34
7. Panel Reliability Test
7.1 Vibration Test
Test Spec:
Test method: Non-Operation
Acceleration: 1.5 G
Frequency: 10 - 500Hz Random
Sweep: 30 Minutes each Axis (X, Y, Z)
7.2 Shock Test
Test Spec:
Test method: Non-Operation
Acceleration: 220 G , Half sine wave
Product Specification
AU OPTRONICS CORPORATION
Active time: 2 ms
Pulse: X,Y,Z .one time for each side
7.3 Reliability Test
Items
www.jxlcd.com
www.jxlcd.com
Temperature
Humidity Bias
High Temperature
Operation
Low Temperature
Operation
High Temperature
Storage
Low Temperature
Storage
Thermal Shock
Test
Required Condition Note
Ta= 40℃℃℃℃, 90%RH, 300h
Ta= 50℃℃℃℃, Dry, 300h
Ta= 0℃℃℃℃, 300h
Ta= 60℃℃℃℃, 35%RH, 300h
Ta= -20℃℃℃℃, 50%RH, 250h
Ta=-20℃℃℃℃to 60℃℃℃℃, Duration at 30 min, 100 cycles
ESD
Note1: According to EN 61000-4-2 , ESD class B: Some performance degradation allowed. No data lost
. Self-recoverable. No hardware failures.
Remark: MTBF (Excluding the LED): 30,000 hours with a confidence level 90%
B140RW01 V0 Document Version : 1.0
Contact : ±8 KV
Air : ±15 KV
Note 1
24 of 34
8. Mechanical Characteristics
8.1 LCM Outline Dimension
www.jxlcd.com
www.jxlcd.com
25 of 34
B140RW01 V0 Document Version : 1.0
www.jxlcd.com
www.jxlcd.com
Note: Prevention IC damage, IC positions not allowed any overlap over these areas.
26 of 34
B140RW01 V0 Document Version : 1.0
8.2 Screw Hole Depth and Center Position
Maximum Screw penetration from side surface is 2.4 mm
The center of screw hole center location is 3.1 ± 0.2mm from front surface
Screw Torque: Maximum 2.5 kgf-cm
www.jxlcd.com
www.jxlcd.com
27 of 34
B140RW01 V0 Document Version : 1.0
MADE IN CHINA (S01)
Week code
Model name
H/W
9. Shipping and Package
9.1 Shipping Label Format
CN -0F133J-72090-
85C-01HE-A00
Made In China
DP/N 0F133J
Manufactured 08/39
Model No:
AU Optronics
B140RW01 V.0
H/W: 1A F/W:1
www.jxlcd.com
www.jxlcd.com
28 of 34
B140RW01 V0 Document Version : 1.0
9.2 Carton Package
The outside dimension of carton is 405(L)mm* 376(W)mm* 302(H)mm
9.3 Shipping Package of Palletizing Sequence
www.jxlcd.com
www.jxlcd.com
29 of 34
B140RW01 V0 Document Version : 1.0
10. Appendix: EDID Description
Byte Value Value Value
(hex)
0 Header 00 00000000 0
1 Header FF 11111111 255
2 Header FF 11111111 255
3 Header FF 11111111 255
Field Name and Comments
(hex) (binary) (DEC)
Header
Vendor / Product
4 Header FF 11111111 255
5 Header FF 11111111 255
6 Header FF 11111111 255
7 Header 00 00000000 0
8 EISA manufacture code = 3 Character ID 06 00000110 6
9 EISA manufacture code (Compressed ASCII) AF 10101111 175
0A Panel Supplier Reserved – Product Code 3E 00111110 62
0B Panel Supplier Reserved – Product Code 10 00010000 16
LCD module Serial No - Preferred but Optional (“0” if
0C
not used) 00 00000000 0
LCD module Serial No - Preferred but Optional (“0” if
0D
not used) 00 00000000 0
LCD module Serial No - Preferred but Optional (“0” if
EDID Version
0E
not used) 00 00000000 0
www.jxlcd.com
www.jxlcd.com
LCD module Serial No - Preferred but Optional (“0” if
0F
not used) 00 00000000 0
10 Week of manufacture 01 00000001 1
11 Year of manufacture 13 00010011 19
12 EDID structure version # = 1 01 00000001 1
13 EDID revision # = 3 03 00000011 3
Video I/P definition = Digital I/P (90 (6-bit) or A0
14
(8-Bit)) 90 10010000 144
15 Max H image size = 31 cm(Rounded to cm) 1F 00011111 31
16 Max V image size = 17 cm(Rounded to cm) 11 00010001 17
Display
Parameters
Panel Color
Coordinates
Display gamma = (gamma ×100)-100 = Example:
17
( 2.2×100 ) – 100 = 120 78 01111000 120
Feature support ( no DPMS, Active off, RGB, timing
18
BLK 1) ==> fix=0A 0A 00001010 10
19 Red/Green Low bit (RxRy/GxGy) C8 11001000 200
1A Blue/White Low bit (BxBy/WxWy) 95 10010101 149
1B Red X Rx = 0.620 9E 10011110 158
1C Red Y Ry = 0.340 57 01010111 87
1D Green X Rx = 0.330 54 01010100 84
30 of 34
B140RW01 V0 Document Version : 1.0
Pixel Clock/10,000 (LSB)
Pixel Clock/10,000 (MSB)
pixels (lower 8 bits)
Vertical Active : Vertical Blanking (Tvbp)
1E Green Y Ry = 0.570 92 10010010 146
1F Blue X Rx = 0.150 26 00100110 38
20 Blue Y Ry = 0.060 0F 00001111 15
21 White X Rx = 0.313 50 01010000 80
22 White Y Ry = 0.329 54 01010100 84
23 Established timings 1 (00h if not used) 00 00000000 0
24 Established timings 2 (00h if not used) 00 00000000 0
Timings
Established
25 Manufacturer’s timings (00h if not used) 00 00000000 0
26 Standard timing ID1 (01h if not used) 01 00000001 1
27 Standard timing ID1 (01h if not used) 01 00000001 1
28 Standard timing ID2 (01h if not used) 01 00000001 1
29 Standard timing ID2 (01h if not used) 01 00000001 1
2A Standard timing ID3 (01h if not used) 01 00000001 1
2B Standard timing ID3 (01h if not used) 01 00000001 1
2C Standard timing ID4 (01h if not used) 01 00000001 1
2D Standard timing ID4 (01h if not used) 01 00000001 1
2E Standard timing ID5 (01h if not used) 01 00000001 1
2F Standard timing ID5 (01h if not used) 01 00000001 1
Standard Timing ID
30 Standard timing ID6 (01h if not used) 01 00000001 1
www.jxlcd.com
31 Standard timing ID6 (01h if not used) 01 00000001 1
www.jxlcd.com
32 Standard timing ID7 (01h if not used) 01 00000001 1
33 Standard timing ID7 (01h if not used) 01 00000001 1
34 Standard timing ID8 (01h if not used) 01 00000001 1
35 Standard timing ID8 (01h if not used) 01 00000001 1
36
37
38 Horizontal Active = 1600
Horizontal Blanking (Thbp) = 330 pixels
39
(lower 8 bits) 4A 01001010 74
68 01101000 104
29 00101001 41
40 01000000 64
Horizontal Active/Horizontal blanking (Thbp)
3A
(upper4:4 bits) 61 01100001 97
3B Vertical Active = 900 lines 84 10000100 132
Vertical Blanking (Tvbp) = 12 lines (DE Blanking typ.
Timing Descripter #1
3C
for DE only panels) 0C 00001100 12
3D
(upper4:4 bits) 30 00110000 48
3E Horizontal Sync, Offset (Thfp) = 64 pixels 40 01000000 64
3F Horizontal Sync, Pulse Width = 42 pixels 2A 00101010 42
31 of 34
B140RW01 V0 Document Version : 1.0
Pixel Clock/10,000 (LSB)
Pixel Clock/10,000 (MSB)
Horizontal Active = xxxx pixels (lower 8 bits)
Horizontal Blanking (Thbp) = xxxx pixels
Vertical Active : Vertical Blanking (Tvbp)
Vertical Sync, Offset (Tvfp) = 3 lines Sync Width
40
= 3 lines 33 00110011 51
41 Horizontal Vertical Sync Offset/Width upper 2 bits 00 00000000 0
42 Horizontal Image Size =309.6 mm 35 00110101 53
43 Vertical image Size = 174.15 mm AE 10101110 174
44 Horizontal Image Size / Vertical image size 10 00010000 16
45 Horizontal Border = 0 (Zero for Notebook LCD) 00 00000000 0
46 Vertical Border = 0 (Zero for Notebook LCD) 00 00000000 0
Bit[7] 0: Non-interlace, 1: Interlace
Bit[6:5] 00: Normal display, no strero, see VESA
EDID Spec 1.3
Bit[4:3] 00: Analog composite, 01: Bipolar analog
composite, 10: Digital composite, 11: Digital separate
Bit[2:1] : The interpretation of bits 2 and 1 is
dependent on the decode of bits 4 and 3 - see VESA
EDID Spec 1.3 Bit[0] : See VESA EDID Spec 1.3==>
47
fix=1A 1A 00011010 26
48
49
4A
www.jxlcd.com
www.jxlcd.com
4B
(lower 8 bits) 4A 01001010 74
Horizontal Active/Horizontal blanking (Thbp)
4C
(upper4:4 bits) 61 01100001 97
4D Vertical Active = xxxx lines 84 10000100 132
Vertical Blanking (Tvbp) = xxxx lines (DE Blanking
4E
typ. for DE only panels) 0C 00001100 12
4F
(upper4:4 bits) 30 00110000 48
50 Horizontal Sync, Offset (Thfp) = xxxx pixels 40 01000000 64
Timing Descripter #2
(=Timing Descripter #1)
51 Horizontal Sync, Pulse Width = xxxx pixels 2A 00101010 42
68 01101000 104
29 00101001 41
40 01000000 64
Vertical Sync, Offset (Tvfp) = xx lines Sync
52
Width = xx lines 33 00110011 51
53 Horizontal Vertical Sync Offset/Width upper 2 bits 00 00000000 0
54 Horizontal Image Size =xxx mm 35 00110101 53
55 Vertical image Size = xxx mm AE 10101110 174
56 Horizontal Image Size / Vertical image size 10 00010000 16
57 Horizontal Border = 0 (Zero for Notebook LCD) 00 00000000 0
58 Vertical Border = 0 (Zero for Notebook LCD) 00 00000000 0
32 of 34
B140RW01 V0 Document Version : 1.0
see
Bit[7] 0: Non-interlace, 1: Interlace
Bit[6:5] 00: Normal display, no strero, see VESA
EDID Spec 1.3 Bit[4:3] 00: Analog composite, 01:
Bipolar analog composite, 10: Digital composite, 11:
Digital separate Bit[2:1] : The interpretation of bits 2
and 1 is dependent on the decode of bits 4 and 3 -
VESA EDID Spec 1.3 Bit[0] : See VESA EDID Spec
59
1.3 ==> fix=1A 1A 00011010 26
5A Flag 00 00000000 0
5B Flag 00 00000000 0
5C Flag 00 00000000 0
Data Type Tag: Alphanumeric Data String (ASCII)
5D
==> fix=FE FE 11111110 254
5E Flag 00 00000000 0
5F Dell P/N 1st Character 46 01000110 70
60 Dell P/N 2nd Character 31 00110001 49
61 Dell P/N 3rd Character 33 00110011 51
62 Dell P/N 4th Character 33 00110011 51
63 Dell P/N 5th Character 4A 01001010 74
EDID Revision
Timing Descripter #3
www.jxlcd.com
www.jxlcd.com
Dell specific information
Bit[6:0] See charts below
Bit[7] 0: X-rev, 1: A-rev
64
65 Manufacturer P/N 42 01000010 66
66 Manufacturer P/N 31 00110001 49
67 Manufacturer P/N 34 00110100 52
68 Manufacturer P/N 30 00110000 48
69 Manufacturer P/N 52 01010010 82
6A Manufacturer P/N 57 01010111 87
Manufacturer P/N (If <13 char, then terminate with
6B
ASCII code 0Ah, set remaining char = 20h) 31 00110001 49
6C Flag 00 00000000 0
80 10000000 128
6D Flag 00 00000000 0
6E Flag 00 00000000 0
Data Type Tag: Manufacturer Specified Data 00
6F
==>fix=00 00 00000000 0
70 Flag 00 00000000 0
71 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
Timing Descripter #4
72 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
73 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
74 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
33 of 34
B140RW01 V0 Document Version : 1.0
75 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
76 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
77 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
78 SMBUS Value = ?? Nits ==> fix=00(for M09) 00 00000000 0
Bit[1:0] 00: reserved, 01: single LVDS, 10: dual
LVDS, 11: reserved
Bit[2] 0: No RTC support, 1: RTC support
79
Bit[7:3] Reserved 02 00000010 2
Bit[0] 0: No BIST support, 1: BIST support
7A
Bit[7:1] Reserved 01 00000001 1
(If <13 char, then terminate with ASCII code 0Ah, set
7B
remaining char = 20h) 0A 00001010 10
(If <13 char, then terminate with ASCII code 0Ah, set
7C
remaining char = 20h) 20 00100000 32
(If <13 char, then terminate with ASCII code 0Ah, set
7D
remaining char = 20h) 20 00100000 32
Extension flag (# of optional 128 EDID extension
7E
blocks to follow, Typ = 0) 00 00000000 0
Checksum
www.jxlcd.com
www.jxlcd.com
Checksum (The 1-byte sum of all 128 bytes in this
7F
EDID block shall = 0) 19 00011001 25
34 of 34
B140RW01 V0 Document Version : 1.0
Loading...
