AU OPTRONICS A190EN02-V0 SPECIFICATION

Product Specification
() Preliminary Specification
AU OPTRONICS CORPORATION
(V) Final Specification
Module 19.0” SXGA Color TFT-LCD
Model Name A190EN02 V0
A190EN02 V0
Customer Date
www.jxlcd.com
www.jxlcd.com
Approved by
Checked &
Approved by
FY Gan
Prepared by
Joyce Kuo
Date
07. 16, 2008
07. 16, 2008
Note: This Specification is subject to change without
notice.
document version 0.6 1/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Audio Video Business Group /
AU Optronics corporation
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
Contents
1. Handling Precautions ..................................................................................................................5
2. General Description.....................................................................................................................6
2.1 Display Characteristics ........................................................................................................................ 7
3. Functional Block Diagram.........................................................................................................12
4. Absolute Maximum Ratings......................................................................................................13
4.1 Absolute Ratings of TFT LCD Module ............................................................................................. 13
4.2 Absolute Ratings of Backlight Unit ................................................................................................... 13
5. Electrical characteristics ..........................................................................................................14
5.1 TFT LCD Module .............................................................................................................................14
5.2 Backlight Unit.................................................................................................................................... 15
6. Signal Characteristic .................................................................................................................16
6.1 Pixel Format Image ........................................................................................................................... 16
6.2 The Input Data Format ...................................................................................................................... 17
6.4 Interface Timing................................................................................................................................. 19
6.5 Power ON/OFF Sequence................................................................................................................. 21
7. Connector & Pin Assignment ...................................................................................................22
7.1 TFT LCD Module .............................................................................................................................22
7.2 Backlight Unit.................................................................................................................................... 23
8. Reliability Test............................................................................................................................24
9. Shipping Label............................................................................................................................25
10. Outline Drawing........................................................................................................................26
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 2/28
Product Specification
26~28
Outline drawing
Updated
25~27
Outline Drawing
Updated
AU OPTRONICS CORPORATION
A190EN02 V0
Record of Revision
Version & Date Page
0.0 2008/01/31 All First Edition for Customer
0.1 2008/02/20
0.2 2008/04/20
www.jxlcd.com
www.jxlcd.com
10
20
21
6
7
8
9
14
21
22
---
TFT-LCD connector information
BLU connector information
Temperature Range
Luminance Uniformity:--
Min. of Brightness:--
---
---
---
Pin 26: NC
CCFL Life Time: 40,000
---
Pin 26: NC
---
Old Description New Description
Update drawing of function block
TBD
TBD
Temperature Range (Ta)
Luminance Uniformity 13 point: 75%, 80%
Min. of Brightness: 270
Add drawing of note 2
Add the definition of note 3
Update the drawing in note 4
Pin 26: VSS, power ground
CCFL Life Time: 30,000, add note 2
Add information of TFT connector
Pin 26: VSS
Add information of BLU connector
0.3 2008/06/17
0.4 2008/06/24
0.5 2008/06//30
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
24
25~27
5
22
24
25
22
25
21,22
21
25~27
---
Mechanical drawing
---
Connector type part number:
2 PIN BHSR-02VS-1
Shipping label
Packing Form
Mating Type Part Number
2 PIN BHSR-02VS-1 (N)
7.2 title
Packing Form
Mating Housing Part Number
MDF76TW-30S-1H (58)
Outline Drawing
Add Packing Form
Updated
Update General Description
Connector type part number:
2 PIN BHSR-02VS-1 (N)
Added
Updated
Mating Housing Part Number
BHSR-02VS-1 (N)
Updated
Removed
Mating Type Part Number
MDF76TW-30S-1H
Updated
document version 0.6 3/28
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
0.6 2008/07/16
25
26, 28
Shipping Label
Outline Drawing
Update Drawing
Updated
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 4/28
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the Cold Cathode Fluorescent Lamp (CCFL) reflector
edge. Instead, press at the far ends of the CCFL reflector edge softly. Otherwise the TFT Module
may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Cold Cathode Fluorescent Lamp (CCFL) in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit (IEC60950 or
UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 5/28
Product Specification
AU OPTRONICS CORPORATION
2. General Description
A190EN0X V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a driver circuit,
and a backlight system. The screen format is intended to support the SXGA (1280(H) x 1024(V)) screen and
16.7M colors (RGB 6-bits + HiFRC data). All input signals are LVDS interface compatible. Inverter card of
backlight is not included.
A190EN02 V0
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 6/28
Product Specification
AU OPTRONICS CORPORATION
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
A190EN02 V0
Screen Diagonal [mm]
Active Area [mm]
Pixels H x V
Pixel Pitch [mm]
Pixel Arrangement
Display Mode
White Luminance [cd/m2] 350 (Typ.)
Contrast Ratio
Optical ResponseTime [msec]
Nominal Input Voltage VDD [Volt]
Power Consumption [Watt]
Weight [Grams]
Physical Size (H x V x D) [mm]
Electrical Interface
Surface Treatment Hard-coating (3H), Glare treatment
Support Color
Temperature Range (Ta)
Operating Storage (Non-Operating)
RoHS Compliance
www.jxlcd.com
www.jxlcd.com
[oC] [oC]
482.6 (19.0" )
376.32 (H) x 301.06 (V)
1280(x3) x 1024
0.294 (per one triad) x 0.294
R.G.B. Vertical Stripe
Normally White
1000 : 1 (Typ)
5 ms (Typ, on/off)
+5.0 V
24.71W (Typ)
(PDD=5.11W, PCFL=19.6 W @Lamp=7.5mA)
2000 (Typ)
396 (H) x 324 (V) x 16.3 (D) (Typ)
Dual channel LVDS
16.7M colors (RGB 6-bit data + HiFRC data)
0 to +60
-20 to +60
RoHS Compliance
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 7/28
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) CR = 10 (Left)
Viewing Angle [degree]
Vertical (Up) CR = 10 (Down)
Luminance Uniformity [%] 13 Points 75 80 - 2, 3
Rising - 3.6 5.7
Optical Response Time [msec]
Color / Chromaticity Coordinates (CIE 1931)
www.jxlcd.com
www.jxlcd.com
Falling - 1.4 2.3
Rising + Falling - 5 8
Red x 0.617 0.647 0.677
Red y 0.310 0.340 0.370
Green x 0.258 0.288 0.318
Green y 0.575 0.605 0.635
Blue x 0.115 0.145 0.175
Blue y 0.041 0.071 0.101
70 70
70 70
80 80
80 80
-
1
-
4, 5
4
White x 0.283 0.313 0.343
White y 0.299
White Luminance (At CCFL= 7.5mA)
Contrast Ratio 600 1000 - 4
Optical Equipment: BM-5A, BM-7, PR880, or equivalent
[cd/m
2
270 350 - 4
]
0.329 0.359
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 8/28
Product Specification
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle Viewing angle is the measurement of contrast ratio10, or 5, at the screen center, over a 180° horizontal
and 180° vertical range (off-normal viewing angles). The 180° viewing angle range is broken down as follows; 90° (θ) horizontal left and right and 90° (Φ) vertical, high (up) and low (down). The measurement
direction is typically perpendicular to the display surface with the screen rotated about its center to develop
the desired measurement viewing angle.
A190EN02 V0
Note 2: 13 points position
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 9/28
Product Specification
TFT-LCD Module
LCD Panel
AU OPTRONICS CORPORATION
Note 3:
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature
change during measuring. In order to stabilize the luminance, the measurement should be executed after
lighting Backlight for 30 minutes in a stable, windless and dark room.
A190EN02 V0
Photo detector
www.jxlcd.com
www.jxlcd.com
Field=1°
50 cm
Center of the screen
document version 0.6 10/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Product Specification
AU OPTRONICS CORPORATION
Note 5: Definition of response time:
The output signals of photo detector are measured when the input signals are changed from “Full Black” to
“Full White” (rising time), and from “Full White” to “Full Black” (falling time), respectively. The response time
is interval between the 10% and 90% of amplitudes. Please refer to the figure as below.
A190EN02 V0
Optical
Optical
response
response
100
100
90
90
10
10
%
%
White
White
0
0
Tr
Tr
Tr
F
F
Black
Black
Tr
R
R
White
White
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 11/28
Product Specification
Connector
D1
LVDS
+ 5V
A190EN0X V0
AU OPTRONICS CORPORATION
A190EN02 V0
3. Functional Block Diagram
The following diagram shows the functional block of the 19.0 inches Color TFT-LCD Module:
DC/DC
Converter
www.jxlcd.com
www.jxlcd.com
LVDS
AU ASIC
Gamma
Correction
Timing
Controller
RSDS
DC POWER
G1
TFT-LCD
1280*(3)*1024
Pixels
G1024
D3840
Inverte
4 CCFL
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 12/28
Product Specification
Voltage
AU OPTRONICS CORPORATION
4. Absolute Maximum Ratings
Absolute maximum ratings of the module are as following:
4.1 Absolute Ratings of TFT LCD Module
Item Symbol Min. Max. Unit Conditions
A190EN02 V0
Logic/LCD Drive
VDD -0.3 +6 [Volt] Note 1, 2
4.2 Absolute Ratings of Backlight Unit
Item Symbol Min. Max. Unit Conditions
CCFL Current ICFL - 8 [mA] rms Note 1, 2
Note 1: With in Ta= 25
Note 2: Permanent damage to the device may occur if exceed maximum values
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 13/28
Product Specification
Vin rising time
0V
5.0V
470 us
AU OPTRONICS CORPORATION
5. Electrical characteristics
5.1 TFT LCD Module
5.1.1 Power Specification
Input power specifications are as follows:
A190EN02 V0
Symble Parameter Min. Typ. Max.
VDD
Logic/LCD Drive
Voltage
4.5 5.0 5.5 [Volt]
Unit Condition
IDD Input Current - 1.02 1.34 [A]
PDD VDD Power - 5.11 6.71 [Watt]
IRush Inrush Current - - 2.5 [A] Note 2
VDDrp
Allowable
Logic/LCD Drive
Ripple Voltage
- - 100
[mV]
p-p
Note 1: The variance of VDD power consumption is ±30%.
Note 2: Measurement conditions:
www.jxlcd.com
(High to Low) Control Signal
+5.0V
www.jxlcd.com
R1 47K
R2
Q3
AO6402
D6 D5 D2 S D1
G
D2SD1D5
D6
G
Q3
AO6402
F1
C1 1uF/16V
±10%
VDD= 5.0V, All Black Pattern At 75Hz, +30%
VDD= 5.0V, All Black Pattern At 75Hz , Note 1
VDD= 5.0V, All Black Pattern At 75Hz
VCC
(LCD Module Input)
1K
C3
0.01uF/25V
SW1
SW MAG-SPST
1 2
+12.0V
C2 1uF/25V
VR1
47K
document version 0.6 14/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
5.2 Backlight Unit
Parameter guideline for CCFL Inverter is under stable conditions at 25 (Room Temper ature):
Parameter Min. Typ. Max. Unit Condition
CCFL Standard Current(ISCFL) 7.0 7.5 8.0 [mA] rms Note 2
CCFL Operation Current(IRCFL) 3.0 7.5 8.0 [mA] rms Note 2
CCFL Frequency(FCFL) 40 60 80 [KHz] Note 3,4
CCFL Ignition Voltage(ViCFL, Ta= 0 )
CCFL Ignition Voltage(ViCF, Ta= 25 )
CCFL Operation Voltage (VCFL)
CCFL Power Consumption(PCFL) - 19.6 21.56 [Watt] Note 6
CCFL Life Time(LTCFL) 30,000 - - [Hour] Note 2,7
Note 1: Typ. are AUO recommended design points.
*1 All of characteristics listed are measured under the condition using the AUO test inverter.
*2 In case of using an inverter other than listed, it is recommended to check the inverter carefully.
www.jxlcd.com
Sometimes, interfering noise stripes appear on the screen, and substandard luminance or flicker at low power may happen.
*3 In designing an inverter, it is suggested to check safety circuit very carefully. Impedance of CCFL,
for instance, becomes more than 1 [M ohm] when CCFL is damaged.
*4 Generally, CCFL has some amount of delay time after applying kick-off voltage. It is
recommended to keep on applying kick-off voltage for 1 [Sec] until discharge.
*5 Reducing CCFL current increases CCFL discharge voltage and generally increases CCFL
discharge frequency. So all the parameters of an inverter should be carefully designed so as not to produce too much leakage current from high-voltage output of the inverter.
www.jxlcd.com
1690 - - [Volt] rms
1300 - - [Volt] rms
544
(@ 7.5mA)
653
(@ 7.5mA)
783
(@ 7.5mA)
[Volt] rms Note 6
Note 5
Note 2: CCFL standard current is measured at 25±2.
Note 3: CCFL discharge frequency should be carefully determined to avoid interference between inverter and
TFT LCD.
Note 4: The frequency range will not affect to lamp life and reliability characteristics.
Note 5: CCFL inverter should be able to give out a power that has a generating capacity of over 1,690
voltage. Lamp units need 1,690 voltage minimum for ignition.
Note 6: The variance of CCFL power consumption is ±10%. Calculator value for reference (ISCFL × VCFL ×
4 = PCFL)
Note 7: Definition of life: brightness becomes 50%. The typical life time of CCFL is on the condition at 7.5 mA
lamp current.
document version 0.6 15/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Product Specification
1
AU OPTRONICS CORPORATION
6. Signal Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
0
A190EN02 V0
1279 1280
1st Line
1024th Line
www.jxlcd.com
www.jxlcd.com
R G B R G B
R G B R G B
R G B R G B
R G B R G B
document version 0.6 16/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
6.2 The Input Data Format
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
Note1: Normally, DE, VS, HS on EVEN channel are not used. Note2: Please follow PSWG. Note3: 8-bit in
www.jxlcd.com
www.jxlcd.com
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 17/28
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
6.3 Signal Description
The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels.
PIN # SIGNAL NAME DESCRIPTION
1 RxOIN0- Negative LVDS differential data input (Odd data)
2 RxOIN0+ Positive LVDS differential data input (Odd data)
3 RxOIN1- Negative LVDS differential data input (Odd data)
4 RxOIN1+ Positive LVDS differential data input (Odd data)
5 RxOIN2- Negative LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG)
6 RxOIN2+ Positive LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG)
7 VSS Power Ground
8 RxOCLKIN- Negative LVDS differential clock input (Odd clock)
9 RxOCLKIN+
10 RxOIN3- Negative LVDS differential data input (Odd data)
11 RxOIN3+ Positive LVDS differential data input (Odd data)
12 RxEIN0- Negative LVDS differential data input (Even data)
13 RxEIN0+ Positive LVDS differential data input (Even data)
14 VSS Power Ground
15 RxEIN1- Negative LVDS differential data input (Even data)
16 RxEIN1+ Positive LVDS differential data input (Even data)
17 VSS Power Ground
18 RxEIN2- Negative LVDS differential data input (Even data)
19 RxEIN2+ Positive LVDS differential data input (Even data)
20 RxECLKIN- Negative LVDS differential clock input (Even clock)
21 RxECLKIN+ Positive LVDS differential clock input (Even clock)
22 RxEIN3- Negative LVDS differential data input (Even data)
23 RxEIN3+ Positive LVDS differential data input (Even data)
www.jxlcd.com
www.jxlcd.com
Positive LVDS differential clock input (Odd clock)
24 VSS Power Ground
25 VSS Power Ground
26 VSS Power Ground
27 VSS Power Ground
28 VCC +5.0V Power Supply
29 VCC +5.0V Power Supply
30 VCC +5.0V Power Supply
document version 0.6 18/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Connector
RxO IN
0
-
VCC
Note1: Start from left side
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
Note2: Input signals of odd and even clock shall be the same timing.
Note3: Please follow PSWG.
www.jxlcd.com
www.jxlcd.com
30
6.4 Interface Timing
6.4.1 Timing Characteristics
Item Symbol Min Typ Max Unit
Data CLK Tclk 40 54 67.5 MHz
H-section
V-section
Frame Rate F 50 60 75 Hz
Note : DE mode only
Period Th 680 844 1024 Tclk
Display Area Tdisp(h) 640 640 640 Tclk
Period Tv 1028 1066 2048 Th
Display Area Tdisp(v) 1024 1024 1024 Th
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 19/28
6.4.2 Timing Diagram
RGB Data
(Odd)
RGB Data
(Even)
Product Specification
A190EN02 V0
AU OPTRONICS CORPORATION
Hsync
DE
CLK
RGB Data
DE
Line Line Line Line Line Line
N
Hsync
Vsync
PWhs
Invalid Data
Invalid Data
Tbp(h)
Pixel
Pixel
2
1
Pixel Pixel
Pixel
3 9 M-1
4
Pixel
6
5 M-3
Pixel Pixel Pixel Pixel Pixel Pixel
7
8
www.jxlcd.com
www.jxlcd.com
10
12
11
Tdisp(h)
Tclk
Invalid Data
2
43
Tfp(v)
PWvs
Tbp(v)
Tdisp(v)
Tv
PixelPixelPixelPixel
M-5
M-4
M-2
M
PixelPixel
Tfp(h)
Invalid Data
Invalid Data
N1
Th
Invalid Data
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 20/28
Product Specification
T5
T2
T1
T6
AU OPTRONICS CORPORATION
A190EN02 V0
6.5 Power ON/OFF Sequence
VDD power and lamp on/off sequence is as follows. Interface signals are also shown in the chart. Signals
from any system shall be Hi-Z state or low level when VDD is off.
VALID DATA
90%
10%
T7
T4
Power Supply VDD
LVDS Signal
Backlight On
90%
10%
T3
www.jxlcd.com
www.jxlcd.com
Power Sequence Timing
Parameter
Unit
Min. Typ. Max.
Value
T1 0.5 - 10 [ms]
T2 0 - 50 [ms]
T3 300 - - [ms]
T4 300 - - [ms]
T5 0 16 50 [ms]
T6 - - 10 [ms]
T7 500 - - [ms]
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 21/28
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
7. Connector & Pin Assignment
Physical interface is described as for the connector on module.These connectors are capable of
accommodating the following signals and will be following components.
7.1 TFT LCD Module
7.1.1 Connector
Connector Name / Designation Interface Connector / Interface card
Manufacturer HRS
Type Part Number MDF76TW-30S-1H
Mating Type Part Number MDF76-30P-1C
7.1.2 Pin Assignment
Pin# Signal Name Pin# Signal Name
1 RxOIN0- 2 RxOIN0+
3 RxOIN1- 4 RxOIN1+
5 RxOIN2- 6 RxOIN2+
7 VSS 8 RxOCLKIN-
9 RxOCLKIN+ 10 RxOIN3-
11 RxOIN3+ 12 RxEIN0-
13 RxEIN0+ 14 VSS
15 RxEIN1- 16 RxEIN1+
17 VSS 18 RxEIN2-
19 RxEIN2+ 20 RxECLKIN-
21 RxECLKIN+ 22 RxEIN3-
23 RxEIN3+ 24 VSS
25 VSS 26 VSS
27 VSS 28 VCC
www.jxlcd.com
www.jxlcd.com
29 VCC 30 VCC
document version 0.6 22/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
7.2 Backlight Unit
Physical interface is described as for the connector on module. These connectors are capable of
accommodating the following signals and will be following components.
7.2.1 Connector
Connector Name / Designation Lamp Connector / Backlight lamp
Manufacturer JST
Type Part Number BHSR-02VS-1 (N)
Mating Type Part Number SM02B-BHSS-1-TB
7.2.2 Pin Assignment
Connector No.
CN1
Upper
CN2
www.jxlcd.com
www.jxlcd.com
Connector No.
CN3
Lower
CN4
Pin No. Input Color Function
1 Hot1 Red High Voltage
2 Cold1 White Low Voltage
1 Hot2 Blue High Voltage
2 Cold2 White Low Voltage
Pin No. Input Color Function
1 Hot1 Red High Voltage
2 Cold1 White Low Voltage
1 Hot2 Blue High Voltage
2 Cold2 White Low Voltage
document version 0.6 23/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
Product Specification
AU OPTRONICS CORPORATION
8. Reliability Test
Environment test conditions are listed as following table.
Items Required Condition
Temperature Humidity Bias (THB) Ta= 50 , ℃ 80%RH, 240hours
A190EN02 V0
Note
High Temperature Operation (HTO) Ta= 60, 240hours
Low Temperature Operation (LTO) Ta= 0, 240hours
High Temperature Storage (HTS) Ta= 60, 240hours
Low Temperature Storage (LTS) Ta= -20, 240hours
Acceleration: 1.5 G Vibration Test (Non-operation)
Shock Test (Non-operation)
Drop Test Height: 60 cm, package test
Thermal Shock Test (TST) -20/30min, 60/30min, 50 cycles
www.jxlcd.com
www.jxlcd.com
ESD (ElectroStatic Discharge)
Wave: Random
Frequency: 10 - 200 - 10 Hz
Sweep: 30 Minutes each Axis (X, Y, Z)
Acceleration: 50 G
Wave: Half-sine
Active Time: 20 ms
Direction: ±X, ±Y, ±Z (one time for each Axis)
Contact Discharge: ± 8KV, 150pF(330Ω ) 1sec,
8 points, 25 times/ point.
Air Discharge: ± 15KV, 150pF(330Ω ) 1sec
8 points, 25 times/ point.
1
2
Note 1: The TFT-LCD module will not sustain damage after being subjected to 100 cycles of rapid
temperature change. A cycle of rapid temperature change consists of varying the temperature from
-20℃ to 60℃, and back again. Power is not applied during the test. After temperature cycling, the unit is placed in normal room ambient for at least 4 hours before power on.
Note 2: According to EN61000-4-2, ESD class B: Some performance degradation allowed. No data lost.
Self-recoverable. No hardware failures.
document version 0.6 24/28
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
A190EN02 V
0
9. Shipping Label
Product Specification
AU OPTRONICS CORPORATION
A190EN02 V0
AAAA.... Manufa
Manufactured end of year
Manufa Manufa
Mark 08 09 10 11
Definition 2008 2009 2010 2011
Shipping No. has 18 digits: for example: VW7400100001-PM0100
VW7400100001-PM0100 => Lot number
VW74001 VW7400100001-
ctured end of year mark
ctured end of yearctured end of year
00001-PM0100 => Serial number
www.jxlcd.com
www.jxlcd.com
PM0100 => Factory number
mark BBBB.... Manufactured week mark
mark mark
Manufactured week mark
Manufactured week mark Manufactured week mark
Mark 01 02
Definition 1st Week 2nd Week
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 25/28
A190EN02 V0
www.jxlcd.com
www.jxlcd.com
AU OPTRONICS CORPORATION
Product Specification
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
10. Outline Drawing
document version 0.6 26/28
A190EN02 V0
www.jxlcd.com
www.jxlcd.com
AU OPTRONICS CORPORATION
Product Specification
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 27/28
A190EN02 V0
www.jxlcd.com
www.jxlcd.com
AU OPTRONICS CORPORATION
Product Specification
AUO Confidential For Eric Tseng Internal Use Only / 2009/8/17
document version 0.6 28/28
Loading...
