Product Specification
() Preliminary Specification
AU OPTRONICS CORPORATION
(V) Final Specification
Module 15” XGA TFT-LCD Semi-Module
Model Name A150XN01 V1- W02300508
A150XN01 V1
Customer Date
www.jxlcd.com
www.jxlcd.com
Approved by
Checked &
Approved by
JC Fan
Prepared by Date
Joyce Kuo
Date
08/17/2009
08/17/2009
Note: This Specification is subject to change without
notice.
document version 0.6 1/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Audio-Video Display Business Unit /
AU Optronics corporation
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
Contents
1. Handling Precautions ..................................................................................................................5
2. General Description.....................................................................................................................6
2.1 Display Characteristics ........................................................................................................................ 6
3. Functional Block Diagram...........................................................................................................9
4. Absolute Maximum Ratings......................................................................................................10
4.1 Absolute Ratings of TFT LCD Module ............................................................................................. 10
4.2 Absolute Ratings of Environment ......................................................................................................10
5. Electrical characteristics ..........................................................................................................11
5.1 TFT LCD Module ............................................................................................................................. 11
6. Signal Characteristic .................................................................................................................13
6.1 Pixel Format Image ........................................................................................................................... 13
6.2 The Input Data Format ...................................................................................................................... 13
6.4 Interface Timing................................................................................................................................. 16
6.5 Color Input Data Reference ............................................................................................................... 18
6.6 Power ON/OFF Sequence................................................................................................................. 19
7. Connector & Pin Assignment ...................................................................................................20
7.1 TFT LCD Module .............................................................................................................................20
8. Reliability Test............................................................................................................................21
9. Outline Drawing..........................................................................................................................22
10. Packing Form............................................................................................................................23
11. Shipping Label..........................................................................................................................24
11.1. Lot Definition of Product (Product Label)...................................................................................... 24
12. Carton Label .............................................................................................................................25
Appendix .........................................................................................................................................26
www.jxlcd.com
www.jxlcd.com
document version 0.6 2/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
A150XN01 V1
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page
0.0 2008/03/01 All First Draft All
5
Power consumption, PDD: 2.5
11
0.1 2008/08/22
0.1 2008/09/12
20
Connector: DF14A-20P-1.25H(56)
22
Outline Drawing
1
A150XN01 V1
5
Power consumption, PDD: 2.5
6
Optical Equipment
9
4.2, 4.3
10
Power SPEC
14
Signal Description
17
---
19
Connector: DF14A-20P-1.25H(56)
20
ESD remark
Old description New Description Remark
Power consumption, PDD: 1.98
Connector: DF19G-20P-1H(56)
Updated
A150XN01 V1：W02300508
Power consumption, PDD: 1.98
Optical Equipment: BM-5A.
Removed
Updated
Add suggest LVDS transmitter and
update connector
Add note for grey-lavel
Connector: DF19G-20P-1H(56)
Add Note 3
0.2 2008/12/15
0.3 2009/03/06
0.4 2009/07/01
21
Outline Drawing
22
Shipping Label
www.jxlcd.com
www.jxlcd.com
9
4.2 Absolute Ratings of Environment
23
Shipping label
6
2.2 Optical Characteristics
9
4.2 Absolute Ratings of Environment
10
Measuring condition diagram update.
--
Vin -> VDD
11
VICM=1.2V
11
VCM -> VICM
14
Pin 18 description update
24
12. Carton label
6
Tolerance of the white chromaticity
Temp.-humidity curve
10
IDD unit
20
Note 3
21
Outline Drawing
Updated
Added
Addad
Add year/month discription
Add Min. an Max. value
Updated
Updated
Updated
VICM=1.25V
Typing error updated.
Updated
Added
Decreased
Updated
[mA]
Added
Updated
24
Carton label
20
0.5 2009/07/31
document version 0.6 3/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
25
Note 3
Appendix
Updated
Remove the description of metal frame
Added
Product Specification
AU OPTRONICS CORPORATION
0.6 2009/0817 22 Outline Drawing Updated
A150XN01 V1
www.jxlcd.com
www.jxlcd.com
document version 0.6 4/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
9) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no bending/twisting
forces are applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
www.jxlcd.com
www.jxlcd.com
document version 0.6 5/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
RoHS Compliance
AU OPTRONICS CORPORATION
A150XN01 V1
2. General Description
This specification applies to the 15 inch Color TFT-LCD Semi-Module A150XN01 V1
The display supports the XGA (1024(H) x 768(V)) screen format and 16.2M colors. All input signals are 1 Channel LVDS
interface compatible.
This module does not contain the backlight.
.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 ℃ condition:
Items Unit Specifications
Active Area [mm]
Pixels H x V
Pixel Pitch [mm]
Pixel Arrangement
Display Mode
Cell Transmittance [%] (8.8)
Optical ResponseTime [msec] 12 (Typ, on/off)
Nominal Input Voltage VDD [Volt] +3.3 (Typ)
Power Consumption(Black Pattern) [Watt] 1.98 (Typ)
Weight [Grams] 285.5 (Typ)
Physical Size (H x V x D) [mm] 316.23(W) x 242.55(H) x 1.69(D) (Typ)
Electrical Interface one Channel LVDS
www.jxlcd.com
www.jxlcd.com
304.128 (H) x 228.096
1024(x3) x 768
0.297 (per one triad) x 0.297
R.G.B. Vertical Stripe
TN mode, Normally White
Surface Treatment Without upper pol.
Support Colors 16.2M colors (RGB 6-bits+FRC)
RoHS Compliance
document version 0.6 6/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25℃ (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Optical Response Time [msec] Rising + Falling
Color / Chromaticity
Coordinates
(CIE 1931)
Cell Transmittance
(At CCFL= mA)
Optical Equipment: BM-5A.
Note 1: Definition of viewing angle
Viewing angle is the measurement of contrast ratio ≧10, at the screen center, over a 180° horizontal and 180°
vertical range (off-normal viewing angles). The 180° viewing angle range is broken down as follows; 90° (θ)
horizontal left and right and 90° (Φ) vertical, high (up) and low (down). The measurement direction is typically
perpendicular to the display surface with the screen rotated about its center to develop the desired measurement
viewing angle.
[% ] 8.7 9.7 - 2
White x
White y
12 17
0.28 0.310 0.34
0.30 0.330 0.36
3
2
www.jxlcd.com
www.jxlcd.com
Note 2: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting
Backlight for 30 minutes in a stable, windless and dark room. Based on backlight chromaticity (Wx:0.30,
Wy:0.31), backlight luminance 3600nit.
document version 0.6 7/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
TFT-LCD Module
LCD P
anel
AU OPTRONICS CORPORATION
A150XN01 V1
Note 3: Definition of response time:
Photo detector
Field=2°
50 cm
Center of the screen
The output signals of photo detector are measured when the input signals are changed from “Full Black” to “Full
White” (rising time), and from “Full White” to “Full Black ”(falling time), respectively. The response time is
interval between the 10% and 90% of amplitudes. Please refer to the figure as below.
www.jxlcd.com
www.jxlcd.com
document version 0.6 8/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
Connector
LVDS
I/F + X
-
PCB
Y
-
Driver IC
AU OPTRONICS CORPORATION
A150XN01 V1
3. Functional Block Diagram
The following diagram shows the functional block of the 15.0 inches wide Color TFT-LCD Module:
+3.3V
DC/DC
Converter
www.jxlcd.com
www.jxlcd.com
AUO ASIC
LVDS
Receiver
Timing
Controller
Gamma
Correction
G1
TFT-LCD
1024(x3) x 768
Pixels
G768
D1 D3072
document version 0.6 9/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
A150XN01 V1
AU OPTRONICS CORPORATION
4. Absolute Maximum Ratings
Absolute maximum ratings of the module are as follows:
4.1 Absolute Ratings of TFT LCD Module
Item Symbol Min. Max. Unit Conditions
Logic/LCD Drive Voltage VDD -0.3 +4.0 [Volt] Note 1,2
N
1
Wi
hi
T
t
o
e
t
:
Note 2: Permanent damage to the device may occur if exceed maximum values
25
n
a
=
4.2 Absolute Ratings of Environment
Item Symbol Min. Max. Unit Conditions
Operating Temperature TOP 0 +65 [oC]
Operating Humidity HOP 8 90 [%RH]
Storage Temperature TST -20 +80 [oC]
Storage Humidity HST 8 90 [%RH]
Note 1: With in Ta= 25℃
Note 2: Permanent damage to the device may occur if exceed maximum values
www.jxlcd.com
www.jxlcd.com
Note 3: For quality performance, please refer to AUO IIS (Incoming Inspection Standard).
Note 3
document version 0.6 10/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
90%
10%
Vin rising time
0V
3.3V
470 us
+3.3V
A150XN01 V1
AU OPTRONICS CORPORATION
5. Electrical characteristics
5.1 TFT LCD Module
5.1.1 Power Specification
Input power specifications are as follows:
Symble Parameter Min. Typ. Max. Unit Condition
VDD
Logic/LCD Drive
Voltage
IDD VDD current - 600 630 [mA]
IDD VDD current 500 525 [mA]
3.0 3.3 3.6 [Volt] ±10%
VDD =3.3V , Black Pattern,
at 60Hz
VDD =3.3V , Gray-scale Pattern,
at 60Hz
Irush LCD Inrush Current - 930 1500 [mA] Vin rising time = 470us
PDD VDD Power
PDD VDD Power
1.98 2.27 [Watt]
1.65 1.89 [Watt]
VDD =3.3V , Black Pattern,
at 60Hz
VDD =3.3V , Gray-scale Pattern,
at 60Hz
Note: Measurement conditions:
www.jxlcd.com
+5.0V
www.jxlcd.com
R1
47K
Q3
AO6402
D6
D5
D2 S
D1
G
F1
VCC
VDD
(LCD Module Input)
C1
1uF/16V
D2SD1D5
(High to Low)
Control Signal
SW
+12.0V
C2
1uF/25V
R2
1K
VR1
47K
G
C3
0.01uF/25V
D6
Q3
AO6402
document version 0.6 11/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
5.1.2 Signal Electrical Characteristics
Input signals shall be low or Hi-Z state when Vin is off
It is recommended to refer the specifications of SN75LVDS82DGG (Texas Instruments) in detail.
A150XN01 V1
Each signal characteristics are as follows;
Symbol Parameter Min Typ Max
Differential Input High
VTH
Threshold
Differential Input Low
VTL
Threshold
│VID│ Input Differential Voltage 250 350 450 [mV] Note1
Differential Input
VICM
Common Mode Voltage
tsu Data setup time 400 -- -- ps
thd Data hold time 400 -- -- ps
Tcj1 Cycle Jitter -- -- 250 ps
Units Condition
VICM = 1.25V
- - 100 [mV]
Note1
VICM = 1.25V
-100 - - [mV]
Note1
VTH/VTL = ± 100mV
1.0 1.25 2 [V]
Note1
VDD=3.3±0.3V , TOP=-10~85 oC
Tclk =15ns , VICM =1.25V
Note2
VDD=3.3±0.3V , TOP=-10~85 oC
Tclk =15ns , VICM =1.25V
Note2
Tcj2
Note1: LVDS Signal Waveform
VTH
VTL
Clock Cycle Rate of
www.jxlcd.com
www.jxlcd.com
Change
VSS
-- -- 20 ps/cycle
｜｜｜｜VID ︱︱︱︱
VICM
Note2: LVDS Input Signal For Timing Specification
document version 0.6 12/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
6. Signal Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
A150XN01 V1
www.jxlcd.com
www.jxlcd.com
6.2 The Input Data Format
document version 0.6 13/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
CLKIN+
CLKIN-
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
RIN0 +/-
RIN1 +/-
RIN2 +/-
RIN3 +/-
OG0 OR5 OR4 OR3 OR2 OR1 OR0
DE VS HS
Rsvd
Note1: Please follow PSWG.
Note2: 8-bit in
Note3:
R/G/B data 7:MSB, R/G/B data 0:LSB
www.jxlcd.com
www.jxlcd.com
OB0 OG3OG4 OG1OG2OB1 OG5
OB5 OB3OB4 OB2
Current Cycle
OR7OB7 OR6OB6 OG7 OG6
document version 0.6 14/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
6.3 Signal Description
The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a differential signal
technology for LCD interface and high speed data transfer device. Transmitter shall be SN75LVDS83(negative edge
sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits
even pixels.
Suggest LVDS transmitter : THC63LVDM83A-G（THINE）
DF19G-20P-1H(56)
Pin No. Symbol Description
1 VDD Power Supply, 3.3V (typical)
2 VDD Power Supply, 3.3V (typical)
3 VSS Ground
4 VSS Ground
5 Rin0- - LVDS differential data input (R0-R5, G0)
6 Rin0+ + LVDS differential data input (R0-R5, G0)
7 VSS Ground
8 Rin1- - LVDS differential data input (G1-G5, B0-B1)
9 Rin1+ + LVDS differential data input (G1-G5, B0-B1)
10 VSS Ground
11 Rin2- - LVDS differential data input (B2-B5, HS, VS, DE)
12 Rin2+ + LVDS differential data input (B2-B5, HS, VS, DE)
13 VSS Ground
14 ClkIN- - LVDS differential clock input
15 ClkIN+ + LVDS differential clock input
16 VSS Ground
17 Rin3- - LVDS differential data input (R6-R7, G6-G7,B6-B7)
18 Rin3+ + LVDS differential data input (R6-R7, G6-G7,B6-B7)
19 VSS Ground
20 VSS Ground
www.jxlcd.com
www.jxlcd.com
document version 0.6 15/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
6.4 Interface Timing
6.4.1 Timing Characteristics
Signal Item Symbol Min Typ Max Unit
Clock Timing
Hsync Timing
Vsync Timing
Note: DE mode only
Note: Typical value refer to VESA STANDARD
Clock frequency Tclk 50 65 81 MHz
Horizontal active Tdisp(h) 1024 1024 1024 Tclk
Horizontal blanking Tblk(h) 30 320 1024 Tclk
Horizontal period Th 1054 1344 2048 Tck
Vertical active Tdisp(v) 768 768 768 Th
Vertical blanking Tblk(v) 8 38 256 Th
Vertical period Tv 776 806 1024 Th
www.jxlcd.com
www.jxlcd.com
A150XN01 V1
document version 0.6 16/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
6.4.2 Timing Diagram
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
www.jxlcd.com
www.jxlcd.com
document version 0.6 17/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
6.5 Color Input Data Reference
A150XN01 V1
Color Data Reference
www.jxlcd.com
www.jxlcd.com
Note: grey-level 252~255 are the same
document version 0.6 18/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
T5
T2
T1
T6
AU OPTRONICS CORPORATION
A150XN01 V1
6.6 Power ON/OFF Sequence
Vin power and lamp on/off sequence is as follows. Interface signals are also shown in the chart. Signals from any
system shall be Hi-Z state or low level when Vin is off.
VALID
DATA
90%
10%
T7
T4
Power Supply VDD
LVDS Signal
Backlight On
90%
10%
T3
www.jxlcd.com
www.jxlcd.com
Power Sequence Timing
Parameter
Unit
Min. Typ. Max.
T1 0.5 - 10 [ms]
T2 30 40 50 [ms]
T3 200 - - [ms]
T4 100 - - [ms]
T5 0 16 50 [ms]
T6 - - 10 [ms]
T7 1000 - - [ms]
Value
document version 0.6 19/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
7. Connector & Pin Assignment
Physical interface is described as for the connector on module.These connectors are capable of accommodating
the following signals and will be following components.
7.1 TFT LCD Module
7.1.1 Connector
Connector Name / Designation Interface Connector / Interface card
Manufacturer HIROSE
Type Part Number HRS DF19G-20P-1H(56)
7.1.2 Pin Assignment
Pin# Signal Name Pin# Signal Name
1
3
5
7
9
11
13
15
17
19
document version 0.6 20/26
VDD
VSS
Rin0-
VSS
Rin1+
Rin2-
www.jxlcd.com
www.jxlcd.com
VSS
ClkIN+
Rin3-
VSS
AUO Confidential For Eric Internal Use Only / 2009/9/10
2 VDD
4 VSS
6
8 Rin1-
10 VSS
12 Rin2+
14
16 VSS
18 Rin3+
20 VSS
Rin0+
ClkIN-
Product Specification
AU OPTRONICS CORPORATION
8. Reliability Test
Environment test conditions are listed as following table.
Items Required Condition
Temperature Humidity Bias (THB) Ta= 5
High Temperature Operation (HTO) Ta= 65
Low Temperature Operation (LTO) Ta=
High Temperature Storage (HTS) Ta= 8
Low Temperature Storage (LTS) Ta= -1
,
0
80%RH, 240hours
, 240hours
, 240hours
0
, 240hours
0
, 240hours
0
A150XN01 V1
Note
Drop Test Height: 60 cm, package test
Thermal Shock Test (TST) -1
/
0
30min, 8
/
0
30min, 100 cycles
1
Contact Discharge: ± 8KV, 150pF(330Ω ) 1sec,
8 points, 25 times/ point.
ESD (Electro Static Discharge)
2,3
Air Discharge: ± 15KV, 150pF(330Ω ) 1sec
8 points, 25 times/ point.
Note 1: The TFT-LCD module will not sustain damage after being subjected to 100 cycles of rapid temperature
change. A cycle of rapid temperature change consists of varying the temperature from -10℃ to 80℃,
and back again. Power is not applied during the test. After temperature cycling, the unit is placed in
normal room ambient for at least 4 hours before power on.
www.jxlcd.com
Note 2: According to EN61000-4-2 , ESD class B: Some performance degradation allowed. No data lost.
www.jxlcd.com
Self-recoverable. No hardware failures.
Note 3:
5 6 7
4
8
1 2 3
document version 0.6 21/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
9. Outline Drawing
Product Specification
AU OPTRONICS CORPORATION
X4X3X2X1 X5
A150XN01 V1
Detail F
www.jxlcd.com
www.jxlcd.com
.
document version 0.6 22/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
10. Packing Form
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
www.jxlcd.com
www.jxlcd.com
document version 0.6 23/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Product Specification
AU OPTRONICS CORPORATION
11. Shipping Label
11.1. Lot Definition of Product (Product Label)
A150XN01 V1
Shipping No. has 18 digits
AAAA.... Manufactured end of year
Manufactured end of year mark
Manufactured end of year Manufactured end of year
Mark 08 09 10 11 …
Definition 2008 2009 2010 2011 …
Shipping No. has 18 digits: for example: VW7400100001-PM0100
VW7400100001-PM0100 => Lot number
Production Date Related:
VW7400100001-PM0100 => Module production year (2007)
VW7400100001-PM0100 => Module production month (Jan~Sep:1~9. Oct: A, Nov: B, Dec: C)
VW7400100001-PM0100 => Serial number
VW7400100001-PM0100 => Factory number
www.jxlcd.com
mark BBBB.... Manufactured week mark
mark mark
www.jxlcd.com
Manufactured week mark
Manufactured week mark Manufactured week mark
Mark 01 02 …
Definition 1st Week 2nd Week …
document version 0.6 24/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
12. Carton Label
Product Specification
AU OPTRONICS CORPORATION
A150XN01 V1
www.jxlcd.com
www.jxlcd.com
document version 0.6 25/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Appendix
CF Chromaticity SPEC:
Items
R
Product Specification
AU OPTRONICS CORPORATION
Typical (C light)
x y
0.491±0.02 0.344±0.02
A150XN01 V1
NTSC target
G
B
W
0.312±0.02 0.528±0.020
0.141±0.02 0.173±0.02
0.307±0.02 0.346±0.02
31.5(參考值)
www.jxlcd.com
www.jxlcd.com
document version 0.6 26/26
AUO Confidential For Eric Internal Use Only / 2009/9/10
Loading...
