August EP620 User Manual

August International Ltd

United Kingdom

Telephone: [phone]

www.a ug us ti nt .c om

Oreillette B

luetooth

Auricolare Bluetooth

Bluetooth Headset

Auricular Bluetooth

Bluetooth Headset

EP

62 0

EN

FR

DE

IT

ES

User Manual

Thank you for purchasing the August EP620
Bluetooth Wireless Headset. This user manual is
designed to familiarize you with all the features
of this device. Please take the time to read this
user manual carefully, even if you are already
familiar with a similar product.

Safety

To ensure the safety of you and others, please read
the Safety Instructions before using this device.

Please do not disassemble the EP620, it can be
unsafe and will invalidate the manufacturer's
warranty.

Disposal

Please ensure the product and accessories are
disposed of in compliance with the WEEE (Waste
Electrical and Electronic Equipment) Directive
and any other regulations applicable to your
country.

Always check with the environment agency and
any other relevant authorities for current disposal
regulations.

Customer Service

You can contact us by phone on: [phone]
0586 or by email at: [e-mail]
should you require further technical support or
customer service.

English

Storage and Use

Never expose
the
to moisture,
dust, oil or
smoke.

device

When carrying
this device as
part of your
luggage please
ensure it is
securely stored
to avoid
impact damage.

Keep this
device away
from
extreme
temperatures.

1. Safety Instructions

Maintenance

Please unplug all leads before cleaning this device.

Wipe the
device and
buttons with
a soft cloth.

Never wipe this
device with an
abrasive cloth
or apply
detergent,
alcohol or
chemical based
cleaning
products.

-1 -

Alcoh ol

Never strike
or scratch this
device with
any sharp
object.

Keep the
device away
from wet or
damp
environment.

Avoid
dropping or
exposing to
impacts.

5. Operation

5.1 Switch On / Off

To switch the device on, press and hold the Enter
button until the device says “power on”. Whilst
on and unpaired, the status LED flashes blue.

To switch the device off, press and hold the Enter
button for 3 seconds, until the device says “power
off”. The status LED will flash red then turn off.

5.2 Bluetooth Connections

To pair to a device, turn the EP620 off, then press
and hold the Enter button for 6 seconds to enter
pairing mode. Whilst in pairing mode, the status
LED flashes red and blue.

For mobile phones

1) Scan for available Bluetooth devices on
your mobile phone (see your mobile phone
user manual for instructions if needed).

2) Select “EP620” from the available devices and
confirm connection.

3) The status LED double flashes once per second
whilst paired.

Note:

Accessing Bluetooth settings on mobile phones
varies for each phone, to find the information for
your phone, please refer to its user manual.

For computers

1) Enable the Bluetooth function on your
computer.

2) Select “Devices and Printers” from the Control
Panel and click “Add a Device”.

-2 -

-3 -

English

2. Main Features

Built-in Rechargeable Battery
Micro USB Charging Port
Range: up to 10m (Class II)
Bluetooth Version: 3.0+EDR

3. Accessories

1) USB charging cable

2) User manual

4. Part Names and Functions

Hands-Free Calls with Integrated Microphone

Wireless Headset for Bluetooth Devices

1
2

3
4

5

6

1) Status LED 4)

2) Enter 5) Power Socket

3) Volume Up 6) Microphone

Volume Down

-4 -

-5 -

English

3) Select “EP620” from the available devices, the
system will install the driver automatically.

For Windows 98, XP and Vista, a third-party
Bluetooth driver is needed (not included).

4) The status LED double flashes once per second
whilst paired.

5) If the EP620 is not automatically set as your
output device, select ”Sound” from the control
panel then highlight the EP620 and select “Set
Default”.

Note:

When switched on, the EP620 will
automatically reconnect to the last paired
Bluetooth device if it is in range.

5.3 Voice Control

Press the Enter button to activate your mobile
phone’s voice control.

5.4 Hands-free Calling

Whilst connected to your mobile phone, the
EP620 will act as a hands-free system for calls.

5.4.1 Answering / Ending a call

Press the Enter button to answer the incoming call
or end the current call.

5.4.2 Rejecting an incoming call

Press and hold the Enter button for 3 seconds to
reject the incoming call.

5.4.3 Handset Transfer

During a call, press and hold the Volume up

Note:

button for 3 seconds to transfer the In-Call audio
source between the phone and the headset.

5.4.4 Call waiting

If you receive a call whilst a call is in progress,
press the Enter button to end the current call and
answer the incoming call. Press and hold the
Enter button to answer the incoming call and
place the current call on hold.

5.4.5 Mute

During a call, press and hold the Volume down
button for 2 seconds to mute or un-mute the
headset. There is a reminder tone every 10
seconds while the headset is muted.

5.4.6 Re-dialing the last number

Double press the Enter button to redial the last
called number on your phone.

6. Charging

When the battery is low, the EP620 beeps every
20 seconds and the status LED flashes red to
indicate low power. To recharge the battery, use
the supplied micro USB cable to connect the
EP620 to a powered USB port.

The status LED constantly lights red whilst
charging and turns blue once the battery is fully
charged.

Note:

1) Only use certified USB chargers from branded
manufacturers.

2) Fully charge the headset before first use.

3) If unused for a long period of time, fully charge
the battery before use.

-6 -

-7 -

English

7. Specifications

Bluetooth Version 3.0 + EDR

Bluetooth Profile

Operating Range

Frequency Response

Speaker Output

Charging Port

Battery

Working Time

HSP, HFP, A2DP

Up to 10m

60Hz – 20KHz

30mW

Up to 6 hours

Charging Time

Weight

Dimensions 5.9 x 1.3 x 0.75cm

About 1.5 hours

7g

8. Troubleshooting

1) Recharge the EP620.repairable.

2) Press and hold the power button for 3 seconds.

The computer or mobile phone cannot find

the EP620.

Confirm the EP620 is in pairing status and within
10 meters of the device.

The EP620 will not turn on.

The computer cannot install the driver for

the EP620.

1) For Windows 98, XP and Vista computers, a
third-party Bluetooth driver is needed (not
included).

2) For Windows 7 and 8 computers, please update
the driver of the Bluetooth module on your
computer. For detailed information of your
Bluetooth module, please contact the
computer supplier.

The sound quality is intermittent in

Bluetooth mode.

1) Please ensure the headset is within 10 metres
of your source device.

2) Please disable the Wi-Fi on your source device.

There is no sound from the headset.

1) Check the volume on both the source device
and the EP620.

2) If the headset is connected to a computer,
please check that the headset is set as the
current audio out device.

The mobile phone asks for a PIN code.

The PIN code for the EP620 is 0000.

55mAh/3.7V
Li-ion Polymer battery

Micro USB

9. Warranty

This product is guaranteed for twelve months from
the date of the original purchase. In the unlikely
event of any defect arising due to faulty materials
or workmanship, the unit will be either replaced or
repaired free of charge (where possible) during this
period. An alternative product will be offered in
case the product is no longer available or
repairable.

This warranty is subject to the following
conditions:

where the product is purchased.

The product must be correctly installed and
operated in accordance to the instructions given
in this user manual.

The product must be used solely for domestic
purposes.

The warranty only covers the main unit, and
does not cover the accessories.

The warranty does not cover the damage caused
by misuse, negligence, accident and natural
disaster.

The warranty will be rendered invalid if the
product is resold or has been damaged by
inexpert repairs. The manufactures disclaim any
liability for incidental or consequential damages.

Please consult our customer adviser before
returning any product; we are not responsible for
any unexpected product returns.

The warranty is only valid within the country

in the original packaging with all the
accessories and the original copy of the
purchase receipt.

The warranty is in addition to, and does not
diminish, your statutory or legal rights.

Customer Service:

Telephone: [phone]
Email: [e-mail]

Any faulty product must be kept and returned

-8 -

-9 -

English
