Page 1
EP61
6
Sports Bluetooth Earphones
Écouteurs Bluetooth pour le Sport
Bluetooth Sport Kopfhörer
Auricolari Bluetooth per Sportivi
Auriculares Bluetooth Deportivos
EN
FR
DE
IT
ES
August International Ltd
United Kingdom
Tel: +44 (0) 845 250 0586
www.augustint.com
Page 2
User Manual
Français Deutsch Español
English
Thank you for purchasing the EP616
Earphones. This user manual is designed to familiarize
you with all the features of this device. Please take the
time to read this user manual carefully, even if you are
already familiar with a similar product.
Safety
To ensure the safety of yourself and others, please read
the Safety Instructions before using this device. Please
do not disassemble the EP616 as it can be unsafe and will
invalidate the manufacturer's warranty.
Disposal
Please ensure the product and accessories are disposed
of in compliance with the WEEE (Waste Electrical and
Electronic Equipment) Directive and any other
regulations applicable to your country. Always check with
the environment agency and any other relevant
authorities for current disposal regulations.
Customer Service
Sports Bluetooth
Declaration of Conformity
The Declaration of Conformity can be found on our
website at http://augustint.com/en/declaration/
You can contact: +44 (0) 845 250 0586 or email
service@augustint.com should you require technical
support and customer service.
Page 3
- 2 -
Storage and Use
Do not expose
this device to
dust, oil or
smoke.
When
transporting
this device, store
securely to avoid
impact damage.
Do not scratch
this device with
sharp objects.
Do not store
or use this
device in
extreme
temperatures.
Do not store
or use this
device in wet
or damp
environments.
Do not drop
or strike this
device.
Maintenance
Please unplug all leads before cleaning this device.
Wipe the
device and
buttons with
a soft cloth.
Never wipe this
device with an
abrasive cloth
or apply
detergent,
alcohol or
chemical based
cleaning
products.
Alcoh ol
1. Safety Instructions
- 1 -
Warning:
1. Listening to headphones or earphones at high volume for
prolonged periods can cause damage to your hearing.
2. Please be considerate to others and listen at a low volume
while in public.
3. If you are experiencing tinnitus, stop using headphones or
listen only at a very low volume.
Wireless Earphones for Bluetooth Devices
Integrated Microphone for Hands-Free Calls
Bluetooth v4.1 and aptX for Enhanced Sound Quality
Built-in Rechargeable Battery
2. Main Features
3. Box Contents
EP616 Power Cable
Ear Buds
User Manual
English
Carry Bag
EP616
Sports Bluetooth Earphones
Écouteurs Bluetooth pour le Sport
Bluetooth Sport Kopfhörer
Auricolari Bluetooth per Sportivi
Auriculares Bluetooth Deportivos
EN
FR
DE
IT
ES
Page 4
4. Part Names and Functions
4.1 Device Layout
1. Power / Play / Pause / Answer
2. Status LED / Microphone
3. Next Track / Volume Up
4. Previous Track / Volume Down
5. Charging Socket
1
5
4
3
4.2 Remote Control
Button Operation
Press
Press and hold
Press
Press and hold
Function
Previous Track
Volume Up
Next Track
Volume Down
Power
Power
Press
Press and hold
Play / Pause;
Pick up / Hang up a call
Power on / Power off;
Reject an incoming call
4.3 Status LED Meaning
Indication LED Status
Flashing Red and Blue
Blue
Flashing Red
Red
Blue
Pairing
PairedFlashing
Low Battery
Charging
Fully Charged
5. Operation
5.1 Power
Please fully charge the EP616 before the first use or if left
unused for a long period of time. To charge, use the power
cable to connect the earphones to a powered USB port.
The status LED will light red while charging and will turn to
blue once fully charged. Ensure that the output voltage from
the USB port or the charger is 5V.
- 4 -
- 3 -
2
English
Page 5
- 6 -
- 5 -
English
- For mobile phones and tablets
1. Scan for available Bluetooth devices on your mobile phone
or tablet.
(Please consult the device’s user manual for further
instructions if necessary.)
2. Select ‘EP616’ from the available devices and confirm the
connection. Some devices require a pin code. If this is the
case, please enter the code ‘0000’.
3. Once successfully connected, the status LED will flash blue.
- For computers
1. Enable the Bluetooth function on your computer.
2. Select ‘Device and Printers’ from the Control Panel and click
‘Add a Device’.
3. Select ‘EP616’ from the available devices. The computer will
automatically install the driver. If a pin code is requested,
please enter the code ‘0000’.
4. Once successfully connected, the status LED will flash blue.
5.4 Multipoint
Multipoint allows you to connect your EP616 headphones to
two source devices at the same time.
- To create a multipoint connection:
1. Turn off the EP616 and all source devices.
2. Press and hold the Power button for 5 seconds to turn on
the EP616 and put it into pairing mode. In pairing mode the
status LED will flash red and blue.
3. Press the power button to enable multipoint.
4. Pair the EP616 to the first source device.
5. Turn off the Bluetooth on the first source device.
6. Pair the EP616 to the second source device.
7. Turn on the Bluetooth on the first source device. The EP616
will automatically reconnect to the first source device.
5.2 Turn On / Off
Press and hold the Power button for 3 seconds to switch on
the EP616. The EP616 will enter reconnection mode and the
status LED will flash red.
Press and hold the Power button for 3 seconds to switch off
the EP616.
If there is no Bluetooth connection, the EP616 will turn off
automatically after 10 minutes.
5.3 Bluetooth Connection
When the EP616 is switched on, it will enter reconnection
mode and connect automatically to any previously known
device. If no previously connected devices are found, the
EP616 will enter pairing mode after 3 seconds.
To connect to a different device, turn off the EP616 first, then
press and hold the Power button for 5 seconds to enter pairing
mode.
In pairing mode, the status LED will flash red and blue.
To forget all previously paired devices, while the EP616 is in
pairing mode, press and hold and together for 6
seconds.
Page 6
- To disable the Multipoint function on the EP616:
1. Turn off the EP616 and all source devices.
2. Press and hold the Power button for 5 seconds to turn on
the EP616 and put it into pairing mode. In pairing mode the
status LED will flash red and blue.
3. Double press the power button to disable the multipoint.
6 Charging.
Connect the EP616 to a powered USB port using the provided
USB charging cable. While charging, the status LED will light
red. It will turn blue once the battery is fully charged.
A full charge takes approximatively 1.5 hours depending on
power input.
Note:
1) Ensure that the output voltage from the USB port or the
charger is 5V. Charging voltage greater than 5V may
damage the headphones.
2) Please fully charge the EP616 before first use or if left
unused for a long period of time.
If you are using a smart USB charger, use the common USB
port and ensure that the output voltage is 5V.
7. Specification
Bluetooth Vers ion v4.1 with aptX
Bluetooth Dis tance 10m
Transmissi on Frequency 2.40GHz- 2.48GHz
Support Profi le HSP/HFP/A2D P/AVRCP
Speaker Diame ter Ø6mm
Impedance 16Ω
Sensitivity 86+/- 3dB
Speaker Outpu t 3mW x 2
Frequency Res ponse 120Hz-20KHz
Signal and Nois e Ratio(SNR) ≥80dB
Distortion ≤3%
Battery Type 3.7V/110mAh Built-in Li-Polyme Battery
Charging Time 1.5Hours
Continuous wo rking time 7 hours
Standby Time 18days
Dimensions 550 × 26× 12mm
Net Weight 10g
- 8 -
- 7 -
English
Page 7
8. Troubleshooting
•
your computer.
Update the driver of the Bluetooth module on
Problem
Won't turn on.
Can’t find the EP616.
Can’t install the
driver for EP616
on a computer.
Solution
• Please ensure that the EP616 is charged.
•
within 10 meters of the device.
Confirm that the EP616 is in pairing mode and
The sound quality is
intermittent in
Bluetooth mode.
• Disable the Wi-Fi on your source device.
No sound.
• Check the volume on both the source device
and the EP616.
9. Warranty
The product must be used solely for domestic purposes.
The warranty only covers the main units, and does not
cover the accessories.
The warranty does not cover the damage caused by
misuse, negligence, accident and natural disaster.
The warranty will be rendered invalid if the product is resold
or has been damaged by inexpert repairs. The manufactures
disclaim any liability for incidental or consequential damages.
Please consult our customer adviser before returning any
product; we are not responsible for any unexpected product
returns.
Any faulty product must be kept and returned in the original
packaging with all the accessories and the original copy of
the purchase receipt.
The warranty is in addition to, and does not diminish, your
statutory or legal rights.
Customer Service:
Telephone: +44 (0) 845 250 0586
Email: service@augustint.com
- 10 -
This product is guaranteed for twelve months from the date of
the original purchase. In the unlikely event of any defect
arising due to faulty materials or workmanship, the unit will be
either replaced or repaired free of charge (where possible)
during this period. An alternative product will be offered in case
the product is no longer available or repairable.
This warranty is subject to the following conditions:
The warranty is only valid within the country where the
product is purchased.
The product must be correctly installed and operated in
accordance to the instructions given in this user manual.
This product is in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU. The
Declaration of conformity may be consulted online at
http://www.augustint.com/en/declaration.
- 9 -
English
