August DVB415 User Manual

August International Ltd

United Kingdom

Telephone:[phone]

www.augustint.com

Freeview HD Receiver and Media Player

DVB-T2 Empfänger und Media Player
DVB-T2 Ricevitore T V e Media Player
Receptor de TV DVB-T2 y Lector Media

Récepteur de TV DVB-T2 et Lecteur M edia

DVB415

User Manual

Quick Start Guide

DVB415

It is suggested that you use a roof top aerial when searching for TV channels for the

first time.

Connect the device with a monitor via HDMI or SCART. Connect the device to the

mains power, press the Power button on the remote to switch on the device.

When turning on the device for the first time, “Installation Guide” will show. Follow

the instructions to select the desired OSD Language and Country, then press <OK>.

The auto search will then start. Once the search has finished, press to

select channels. Press <TV/RADIO> to switch between Freeview TV and Radio

channels.

If you have done the first time installation before, and would like to search for Digital

Freeview channels again, or if you have moved to a different region and need to search

channels again, press <MENU>, move to the “Installation” menu, select Auto Search

and press <OK> to start the search. Once the search has finished, press

to select channels. Press <TV/RADIO> to switch between Freeview TV and Radio

channels.

To play music, photos, movies or PVR from a USB memory stick, insert the memory

stick into the USB port, press <MENU>, move to Media Player menu, select “Music”,

“Image”, “Video” or “PVR”, press <OK> to view the file list. Select a file and press

<OK> to Play.

Please note that the signal strength in some areas may not be sufficient to support TV

reception using a portable aerial. The distance from the closest transmitter and other

factors such as surrounding buildings, the walls of your house, weather and electro-

magnetic interference caused by power and telecommunication infrastructure may

affect signal strength. Changing location may improve signal reception and a rooftop

aerial designed for digital TV can be used to achieve the best possible reception.

For any further queries, please telephone August International Ltd helpline
[phone] or email [e-mail]

<▲> or <▼>

<▲> or <▼>

1.

2.

3.

4.

5.

7.

Thank you for purchasing this August Receiver. You may already be

familiar with using similar products but please take the time to read these

instructions carefully. They are designed to familiarise you with the

product’s many features and to ensure that you get the very best from

your purchase.

Safety

Please read the Safety Instructions before using this product to ensure

your safety and the safety of others.

Disposal

Please ensure the product and its accessories are disposed in compliance

with WEEE (Waste Electrical and Electronic Equipment) Directive and

any other applicable regulations. Please check with your local authority

for current disposal regulations.

Customer Service

If you need help, please contact our Customer Service:

Telephone: [phone]

Email: [e-mail]

6.

English

Contents

1. Safety Instructions

Maint ena nce

Please unplug all connection wires before cleani ng this machine.

Stora ge an d Use

Never expose
the Receiver to
moisture,dust
oil or smoke.

Never put this
machine in
containers that
are unstable as
this may cause
damage.

Never extrude
or chafe this
machine with
sharp objects.

Keep this
machine away
from hot or
cold places.
Working
temperature of
this device is
0ﾟC ~ 50ﾟC,
storage
temperature is

Keep the

away
from water or
damp
environment.

Receiver

Avoid
dropping or
exposing to
impacts.

Please wipe this
machine
and buttons with
a softcloth. Only
clean the screen
with professional
LCD TV screen
cleanser.

Never wipe this
machine with an
abrasive cloth,
detergent
powder, alcohol
and benzene etc.
various
propellants or
chemical
cleaning products.

-1-

-10ﾟC ~ 60ﾟC.

1. Safety Instru ction s

2. Acces sories

3. Part Names and Fu nctio ns

4. Connection

5. Unit Operatio n

6.

7. Troubl eshoo ting

8. Warranty

Specificatio ns

1

2

3

7

8

24

25

26

Alcohol

English

-2-

-3-

2. Accessories

Remote control

User manual

3.1 Front

1 2 3 4

1. Display

2. Power Indicator

3. IR receiver window

4. USB Port

3.2 Rear

1. SCART

2. HDMI Port

3. Coaxial

4. RF Out

5. RF In

For the sake of safety, when you do not intend to use the Receiver, please switch off the
power button.

Special Notice

Never try to repair this machine by yourself. In case of any fault or failure, please turn

off the Receiver at once, and notify our company or the corresponding dealer. The

Receiver is made up of many precision electronic components. Any disassembly or

modification may lead to further damage.

Operation Precautions

1

2

35

English

3. Part Names and Functions

4

DVB4

15

-4-

3.3 Remote Control

3.3.1 Remote Button Functions

1

2

9

6

5

4

7

8

10

11

12

13

14

15

16

17

18

20

19

21

22

23

24

28

27

29
31

30

32

33

36

34 35

37

38

39

40

-5-

1.

2.

Numbers

8.

37. Zoom in

38. A spe ct ra tio

39. Resolution

40. Schedule

Mute/unmute the sound
Power

3. Favourite channel list

4. Subtitle

5. Information

6. Teletext (n ot av ail abl e in UK )

7.
Change back to the previous channel

9. Channel List

10. Enter the main menu

11. Exit

12. Up

13. Down

14. Left

15. Right

16. Confirm

17. Electronic Program Guide

18. SWAP

19. Page down

20. Page up

21. Channel up

22. Channel down

23. Volume up

24. Volume down

25. Rewind

26. Forward

27. Previous track

28. Next track

29. Play

30. Stop

31. Pause/Time shi ft

32. A udi o lan guage

33. Record

34. USB

35. TV and R adi o swi tch

36. Repeat mode

English

3

25

26
