August CR220 User Manual

August International Ltd

United Kingdom

Tel: [phone]

www.a ug us ti nt .c om

CR2

20

FM Transmitter for Bluetooth Devices
Transmetteur FM pour Appareils Bluetooth
FM Transmitter für Bluetooth Geräte
Trasmettitore FM per Dispositivi Bluetooth
Transmisor FM para Dispositivos Bluetooth

EN

FR

DE

IT

ES

User Manual

Storage and Use

Do not expose
this device to
dust, oil or
smoke.

When transporting
this device store
securely to avoid
impact damage.

Do not scratch
this device with
sharp objects.

Do not store or
use this device
in extreme
temperatures.

Do not store or
use this device
in wet or damp
environments.

Do not drop
or strike this
device.

Maintenance

Please unplug all leads before cleaning this device.

Wipe the
devic e and
butto ns with
a soft cloth.

Never wipe this
device with an
abrasive cloth
or apply
detergent,
alcohol or
chemical based
cleaning
products.

Alcoh ol

1. Safety Instructions

-2-

-1-

English Français Deutsch Español

Thank you for purchasing the August Bluetooth FM Transmitter
CR220. This user manual is designed to familiarize you with all
the features of this device. Please take the time to read this
user manual carefully, even if you are already familiar with a
similar product.

Safety

To ensure the safety of you and others, please read the Safety
Instructions before using this device. Please do not
disassemble the CR220, it can be unsafe and will invalidate the
manufacturer's warranty.

Disposal

Please ensure the product and accessories are disposed of in
compliance with the WEEE (Was te E le ct ri ca l an d El ec tr on ic
Equipment) Directive and any other regulations applicable to
your country. Always check with the environment agency and
any other relevant authorities for current disposal regulations.

Customer Service

You ca n co nt ac t us b y ph on e on : [phone] or b y
email at: [e-mail] should you require further
technical support or customer service.

4. Part Names and Functions

-4-

-3-

3. Box Contents

1 2

3

Bluetooth FM Tra nsm itter

English

2. Main Features

Wirelessly connect your mobile phone to your car stereo

Take calls hands free through the integrated microphone
Powered USB sockets for charging your portable electronics
Powered by 12V-24V cigarette lighter socket

User Manual3.5mm Audio Cabl e

1. Multif un ction D ia l

2. Status L ED

3. Displa y Sc reen

4. Microp ho ne

5. Freque nc y Up

6. Freque nc y Down

7. Next Trac k

8. Previo us Tr ack

9. Audio-I n So cket

10. USB Out pu t: 1.0A

11. USB Ou tput: 2.4 A

1
2
3

5

6

7

9

8

11

104

5. Operation

5.1 Power

Insert the CR220 into a 12/24V car cigarette socket, the
CR220 will switch on automatically. Press and hold the
multifunction dial to turn the device off or on.

Note: The CR220 will automatically switch off a ft er 1 0 mi nu te s
if it is not connected to a Bluetooth source device.

5.2 Bluetooth connection

1. Once switched on, the CR220 will enter pairing mode
automatically. In pairing mode the status LED will flash blue.

2. Enable Bluetooth on the source device.

3. Scan for Bluetooth devices on your source device and
select CR220 to connect to it. Once successfully paired, the
status LED will light blue constantly.

Note: When switched on, the CR220 will reconnect to any
previous known device automatically. To pa ir t o a ne w de vi ce ,
disconnect the existing connection and repeat steps 2-3

5.3 FM Transmission

The display screen shows the current FM transmission’s
frequency. Match your FM radio to this frequency to begin
playback through your car stereo.

To reduce interference, find an empty station on your FM radio
then use CH+ and CH- to match this frequency on the CR220.

5.4 Music Control

Tur n th e mu lt if un ct io n di al t o ad ju st t he v ol um e.
Press the multifunction dial to play / pause the track.
Press NEXT to go to the next track.
Press PREV to go to the previous track.

CR220

FM Transmitter for Bluetooth Devices

Transmetteur FM pour

Appareils Bluetooth

FM Transmitter für Bluetooth Geräte

Trasmettitore FM per Dispositivi Bluetooth

Transmisor FM para Dispositivos Bluetooth

E

N
F
R

DE

I

T
E
S

-6-

-5-

5.5 Hands-free Calling

Whilst connected to your mobile phone, the CR220 will act as
a hands-free system for phone calls.
Press the multifunction dial to receive or hang up a call
Press NEXT or PREV or double press the multifunction dial to
reject a call.

5.6 USB Output

Whilst the CR220 is connected to a 12V-24V car cigarette
socket, the USB ports on the CR220 can be used to charge
portable devices.

5.7 Aud io -i n

Plug the 3.5mm audio cable provided into the audio-in socket
of the CR220 and to your source device’s headphone socket.
The CR220 will enter Line-in mode automatically and play any
music from the connected source device.

Removing the audio cable will return the CR220 in Bluetooth
mode automatically

6. Specification

V4.0+EDR

HSP, HFP A2D P and AVRCP

20Hz-16KHz

10m

88.1~107.9MHz

5m

DC 12-24V 30-50mA

USB1: 5V/2.4A(Max)
USB2: 5V/1A

165x130x40mm

88g

Bluetooth Version

Bluetooth Profile

Frequency Response

Working Distance(Bluetooth)

FM Frequency

Working Distance(FM)

Power Input

USB Output Voltage

Dimensions

Net weight

English

-7-

English

7. Specification

Solution

Problem

The device will
not turn on

The microphone
volume is too low

No sound is heard

• Check that the CR220 is securely
plugged into the 12V-24V power
source

• Check that 12V-24V power source is
working

• Check that the fuse located at the tip
of the cylinder of the device is in
working conditions

• Check that the volume level on your
Bluetooth device CR220 and FM
Radio is not at minimum

• Check that the FM frequency of
CR220 and FM radio matches.

The sound quality
is intermittent

• Check that the FM frequency of
CR220 and FM radio matches

• Check that the FM frequency is clear
of any FM radio broadcasting

• Turn the microphone on the CR220
towards you

• Move the CR220 closer to you

English

8. Warranty

This product is guaranteed for twelve months from the date of the
original purchase. In the unlikely event of any defect arising due to
faulty materials or workmanship, the unit will be either replaced or
repaired free of charge (where possible) during this period. An
alternative product will be offered in case the product is no longer
available or repairable.

This warranty is subject to the following conditions:
The warranty is only valid within the country where the product is
purchased.
The product must be correctly installed and operated in
accordance to the instructions given in this user manual.
The product must be used solely for domestic purposes.
The warranty only covers the main unit, and does not cover the
accessories.
The warranty does not cover the damage caused by misuse,
negligence, accident and natural disaster.
The warranty will be rendered invalid if the product is resold or
has been damaged by inexpert repairs. The manufactures
disclaim any liability for incidental or consequential damages.
Please consult our customer adviser before returning any
product; we are not responsible for any unexpected product
returns.
Any faulty product must be kept and returned in the original
packaging with all the accessories and the original copy of
the purchase receipt.

The warranty is in addition to, and does not diminish, your statutory
or legal rights.

Customer Service:

Telephone: [phone]
Email: [e-mail]

-8-

This product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. The declaration of
conformity may be consulted at August International Ltd, Rawmec
Business Park, Plumpton Road, Hoddesdon, EN11 0EE,
United Kingdom.
