August CR150 User Manual

-3-

-1- -2-

-4-

User Manual

Thank you for purchasing this August
product, please follow the instructions
below to use the device.

Play/Pause

Previous/Vol-

Next/Vol+

To play MP3 music from a USB stick,
MMC or SD card, insert the card or
stick into the card reader or USB port.
(Please note the transmitter supports
up to 8GB memory cards or USB
sticks.)

Plug the device into your car's
cigarette lighter socket, the device
will automatically turn on and start to
play any MP3 music files stored on the
card or stick.

The device's transmission frequency
is shown on the LCD screen. Tune
your car's radio to the matching
frequency to start playback via the
stereo.

To alter the transmission frequency,
use the - / + buttons on the device or
CH- / CH+ on the remote control.
Changing frequency can help to
improve signal quality.

The PREV, NEXT buttons can be used
to skip forward and backwards
through stored tracks and the
PLAY/PAUSE button pauses and
resumes playback.

1.

2.

3.

4.

5.

To set the volume, press and hold
PREV or NEXT on the device or use the
volume buttons on the remote control.

To change EQ settings press the EQ
button on the remote to cycle through:
NORMAL, POP, ROCK, JAZZ,
CLASSIC and COUNTRY.

To select a specific song, type in the
number of the track you would like to
play. For example: pressing number
''2'' will start playback of the second
song.

Pressing and holding the PLAY/PAUSE
button switches the playback mode
between: Single (repeats the current
track continuously), Random (plays all
tracks in a random order) Folder
(repeats all tracks in the current folder)
and All.

6.

7.

8.

9.

10. Specifications

FM Frequencies Range

Input Ports

USB
SD/SDHC/MMC
Card Reader

Supported File Type

MP3

12 / 24 V

Power Input

87.5 – 108MHz

Please note the above instructions are
only intended for reference. August
International Ltd reserves rights to
revise product specifications, features
and design without notice.

For any further queries, please
telephone August International Ltd's
helpline [phone] or email
[e-mail]

LCD

SD MMC Card Reader/

USB Port

Negative Pole

Positive Pole

Card Reader

Support SD/MMC card
up to 8GB

Support USB memory
stick i n FAT format a nd
up to 8GB

USB Port

User Manual

Car MP3 Player & FM Transmitter with

Card Reader/USB

CR150
