Audix OM3S Datasheet

OM3

OM3

OVERVIEW

Designed, assembled and tested by Audix in the USA, the OM3 is a dynamic vocal

microphone used for a wide variety of live, studio, and broadcast applications. The

OM3 provides clear and accurate sound reproduction, resistance to feedback and the

ability to handle very high SPL (Sound Pressure Levels) without distortion.

The OM3 is designed with a tight and uniformly controlled hypercardioid polar

pattern which helps to isolate the vocals from the rest of the instruments on stage.

With a wide frequency range of 50 Hz - 18 kHz, the OM3 employs a VLM™(Very Low

Mass) diaphragm for natural sound with exceptional transient response.

The OM3 is naturally attenuated in the lower mid-bass frequencies in order to reduce

boominess and handling noise. This, in conjuction with an extremely articulate mid-

range, makes the OM3 an excellent choice for PA systems of all sizes. The OM3 is well

balanced, comfortable to hold, durable, and designed with high standards and tight

tolerances.

The OM3 is manufactured with a precision die cast zinc alloy body, durable black

E-coat finish, dent resistant steel mesh grill and gold plated XLR connector.

MODEL VARIATIONS

OM3S - Same as OM3 with On-Off switch

SUPPLIED ACCESSORIES

MC1 - Heavy-duty nylon molded clip with brass insert

P1 - Carrying pouch

OPTIONAL ACCESSORIES

Dynamic Vocal Microphone

FEATURES

· Multi-purpose vocal and instrument mic for live

sound, home studio

· Clear, natural, accurate sound for mid-size to large

PA systems

· Excellent off-axis rejection on stage for increased

feedback rejection. Isolates the vocal from other
instruments on stage

· Handles high SPLs without distortion

· VLM Capsule

WS357 - Optional high quality external foam windscreen for reducing wind, sibilance,

and pop noise.

CBL20 - 20’ premium XLR-XLR balanced mic cable. Quad conductor, twisted pair with

braided shield for maximum conductivity. 6mm PVC jacketed.

CBLDR25 - 25’ premium right angle XLR-XLR balanced mic cable. Quad conductor,

twisted pair with braided shield for maximum conductivity. 6mm PVC jacketed.

T50K - Professional impedance matching transformer that allows a low impedance

mic to be connected to a high impedance input.

TRIPOD - Metal tripod desktop stand for use with any 5/8” threaded mic clip.

MC1 P1 WS357 CBL20 CBLDR25 T50K TRIPOD

· Designed, assembled & tested in the USA

· 5 year warranty

APPLICATIONS

· Lead or backing vocals

· Live recording

· Broadcast

· Home studio - vocal and instrument

· Sax, brass, guitar, dobro, flute, percussion, drums

SPECIFICATIONS

Transducer Type

Frequency Response

Polar Pattern

Output Impedance

Sensitivity

Capsule Technology VLM Type B

Off-Axis Rejection

Maximum SPL

Power Requirements

Connector

Polarity Positive pressure on diaphragm

Materials / Finish

Weight 307 g / 10.8 oz

Length

Dynamic

50 Hz - 18 kHz

Hypercardioid

290 ohms

1.6 mV / Pa @ 1k

>25 dB

≥144 dB

None

3-pin XLRm

produces positive voltage on pin
2 relative to pin 3 of output XLR
connector

Zinc Alloy / Black Finish

176 mm / 6.9 in

ARCHITECT AND ENGINEER SPECIFICATIONS

The microphone shall be of the dynamic type and the polar pattern of the

microphone shall be hypercardioid. The nominal output impedance shall be

equal to 290 ohms at 1 kHz. The microphone shall have a sensitivity of 1.6 mV /

Pa at 1 kHz and a sound pressure level ≥144 dB. The microphone body shall be

of zinc alloy and the grill cap shall be steel wire mesh. The overall dimensions

shall be 23 mm in diameter at the base, 53 mm in diameter at the widest point

on the grill and 176 mm in length.

OPERATION AND MAINTENANCE

The OM3 is a low impedance microphone and should be plugged into the

“mic level” input of your console, mixer or recording device. Please note that

your microphone does not require phantom power and will not be affected

in any way by phantom power should it be running simultaneously while the

microphone is in operation. Avoid plugging or unplugging the microphone

from the PA system unless the channel is muted or the volume of the system

turned down. Failure to do so may result in a loud “popping” noise which could

seriously damage the speakers in the PA system.

OM3

DIMENSIONS (mm)

FREQUENCY RESPONSE

POLAR PATTERNS

Lo

The OM3 is manufactured to exacting specs with roadworthy construction.

However, the capsule is highly sensitive and should be handled with care. Avoid

extreme temperatures and be sure to store your microphone in the pouch

provided when not in use. Moisture of any kind can adversely effect the sound

and performance of your microphone.

USER TIPS

The OM3 has a very tight pick-up pattern in order to help eliminate sound from

other instruments on stage from “bleeding” into the microphone. For best results,

it is important to sing directly into the mic at close proximity (within 2 inches).

When using floor monitors, position the microphone so that it is parallel to

the floor.

Further miking techniques may be found at www.audixusa.com.

Hi

PRODUCT REGISTRATION: Please register your product online at www.audixusa.com/docs_12/about/product_registration.shtml.
SERVICE AND WARRANTY:

workmanship, Audix will repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes
any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions. No
Implied Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose are hereby excluded. The liability of Audix, if any,
for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages of
any kind. Should your microphone fail in any way, please contact the Audix Service department at 503.682.6933. A Return Authorization is required before returning any product. OTHER THAN
THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS, THE USE OF THE PRODUCTS, THE PERFORMANCE OF THE PRODUCTS. AUDIX SHALL
NOT BE LIABLE FOR SPECIAL INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THE SALE, USE, STORAGE OR DISPOSAL OF THE PRODUCTS, AUDIX’S
SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT. NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

This microphone is under warranty for a period of 5 years to be free of defects in material and workmanship. In the event of a product failure due to materials or

www.audixusa.com

Audix Corporation 9400 SW Barber St. Wilsonville, OR 97070

503.682.6933 Fax: [phone]

ver 3.0 05-16
