Audix MB2450 Specifications

Carbon Fiber

MicroBoom

MicroBoom™

OVERVIEW

The MicroBoom™ integrated carbon fiber boom system is available in three lengths:

24”, 50” and 84” and is designed to be used with the award winning Micros™ Series of

miniaturized condensers. Lightweight and able to attach to any standard microphone

stand, the MicroBoom is a problem solver for portability and hard-to-reach miking

applications including choir, live theater and orchestra.

Boom Arms

The MicroBoom can be used with a choice of capsules in the Micros Series, offering

a broad choice of pick-up pattern and frequency response. A high quality shielded

cable is used internally to insure the cleanest audio signal path between the

microphone and the bottom of the boom, which terminates in a mini-XLR male

connector. The MCBOOM adaptor allows for total control over the angle, rotation and

position of the carbon fiber rod. The MicroBoom provides an ultra-clean, professional

and elegant appearance on stage while providing exceptional performance

and portability.

MODEL VARIATIONS

MICROBOOM24 - 24” carbon fiber boom arm with clutch assembly

MICROBOOM50 - 50” carbon fiber boom arm with clutch assembly

MICROBOOM84 - 84” carbon fiber boom arm with clutch assembly

MICROBOOM SYSTEMS

The MicroBoom System comes with a carbon fiber boom, clutch assembly,
microphone, cable and windscreen.

MB5050 - 50” carbon fiber boom, clutch assembly & M1250B cardioid mic

MB5050HC - same as above but with a M1250BHC hypercardioid mic

MB5055 - same as above but with a M1255B high output cardioid mic

MB5055HC - same as above but with a M1255BHC high output hypercardioid mic

MB8450 - 80” carbon fiber boom, clutch assembly & M1250B cardioid mic

MB8450HC - same as above but with a M1250BHC hypercardioid mic

MB8455 - same as above but with a M1255B high output cardioid mic

MB8455HC - same as above but with a M1255BHC hypercardioid mic

MicroBoom

TM

in 24”, 50”, & 84”

FEATURES

· Clean, elegant appearance

· Choice of capsules

· No external power needed

· Designed, assembled & tested in the USA

· 1 year warranty

APPLICATIONS

· Choir

· Ensemble vocal

· Theatre

· Orchestral zone miking

· Location recording

· Presentation

· Conference room

· Video production

SUPPLIED ACCESSORIES

MCBOOM - Mic stand adapter with thumbscrew

and wing nut adjustments

MCBOOM

CBL20

OPTIONAL ACCESSORIES

CBLM25 - 25’ shielded mic cable with

mini-XLRf - XLRm connectors

STANDMB - Pedestal mic stand adjustable

CBLDR25 WS1218

13-20 inches

WS1218 - Windscreen

SPECIFICATIONS

Rod material

Gooseneck

Length MicroBoom™24

Length MicroBoom™50

Length MicroBoom™84

Diameter

Connections

Weight MicroBoom™24

Weight MicroBoom™50

Weight MicroBoom™84

Finish

DIMENSIONS (mm)

Carbon Fiber

Flexible Steel

609 mm / 24 in

1270 mm / 50 in

2134 mm / 84 in

7.4 mm / .2 in

mini-XLRm (bottom)
mini-XLRf (top)

45 g / 1.6 oz

78 g / 2.5 oz

111 g / 4 oz

Black Finish

OPERATION

The MicroBoom™ is a modular system and simple to use. The microphone

attaches to the mini-XLR connector at the end of the gooseneck. To

release and remove the microphone from the connector, simply push

the black button on the side of the mini-XLR and pull the microphone off.

MicroBoom

2134

609

PRODUCT REGISTRATION: Please register your product online at www.audixusa.com/docs_12/about/product_registration.shtml.
SERVICE AND WARRANTY:

workmanship, Audix will repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes
any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions. No
Implied Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose are hereby excluded. The liability of Audix, if any,
for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages of
any kind. Should your microphone fail in any way, please contact the Audix Service department at 503.682.6933. A Return Authorization is required before returning any product. OTHER THAN
THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPEC T TO THE PRODUCTS, THE USE OF THE PRODUC TS, THE PERFORMANCE OF THE PRODUCTS. AUDIX SHALL
NOT BE LIABLE FOR SPECIAL INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THE SALE, USE, STORAGE OR DISPOSAL OF THE PRODUC TS, AUDIX’S
SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT. NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILIT Y OF SUCH DAMAGES.

This product is under warranty for a period of 1 year to be free of defects in material and workmanship. In the event of a product failure due to materials or

ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

www.audixusa.com

Audix Corporation 9400 SW Barber St. Wilsonville, OR 97070

503.682.6933 Fax: [phone]

ver 3.2 12-15
