Audiovox Thera PDA2032 User Guide

INTRODUCTION

It is important you read this manual (USER’S GUIDE) before using your device ( Pocket PC) to ensure its proper operation.

It is recommended that important data stored in your device should be saved to a memory card (sold separately) or your personal computer (data transfer with ActiveSync®) on a regular basis. Before returning your unit for service, be sure to back up your data and remove any confidential, proprietary or personal information. Audiovox Communications Corp. is not responsible for damage to or loss of any programs, data or removable storage media.

The purpose of the Safety Instructions in this manual is to provide you with warnings and safety instructions that will assist in preventing the misuse of your device.

All of the Safety Instructions that are contained in this manual must be read carefully and must

be fully understood before you attempt to use your device in order to avoid potential hazards that could cause bodily injury or property damage, or could result in damage to your device or loss of data.

Always keep this manual in a convenient place for future reference.

Trademark Information

• Microsoft, ActiveSync, Outlook, Pocket Outlook, Windows, Windows NT, and the Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary of Microsoft Corporation.

• Sierra Wireless, the Sierra Wireless logo, red wave design and, Watcher are trademarks of Sierra Wireless, Inc. Heart of the Wireless Machine is a registered trademark of Sierra Wireless, Inc. © 2001 Sierra Wireless, inc.

• Other product names mentioned in this manual are trademarks or registered trademarks of the respective companies.

Please note that coping and modifying, changing or editing any material on the Internet, except using it privately for non-commercial purpose, may infringe the author's copyright protected by the Copyright Act.

Product Name: Model Number(s): CET0200A (PDA2032)

FCC Notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: Only peripherals complying with the FCC class B limits may be attached to this

equipment. Operation with non-compliant peripherals or peripherals not recommended by us is

likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the cradle connecting port.

Changes or modifications made to this equipment, not expressly approved by us or parties authorized by us could void the user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

Product Name: USB Cradle Model Number(s): CEX0208B (CRU2032B)

FCC Notice “Declaration of Conformity Information”

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

SAFETY INSTRUCTIONS

• There are two categories of Safety Instructions included in this manual:

✓ Product Warnings, (i.e., what must never be done to assure avoiding those hazards that could

cause bodily injury or property damage); and

✓ User Directions (i.e., what must always be done to assure the safe use of your device).

• The Safety Instructions contained in this manual have been categorized in accordance with the seriousness of the potential hazards through the use of Signal Words.

Those Signal Words, and their intended meanings, are as follows: DANGER: Indicates that a failure to observe the Safety Instructions could result in death or

catastrophic bodily injury.

WARNING: Indicates that a failure to observe the Safety Instructions could result in serious

bodily injury.

CAUTION: Indicates that a failure to observe the Safety Instructions could result in minor

bodily injury or property damage.

NOTE: Designates important information that relates to activities and/or conditions that

might result in loss of data and/or damage to your device.

Safe Use And Operation of Your Device

All portable computers produce low levels of RF energy due to the generation of digital timing pulses by its clock oscillator circuits. Your device has been equipped with internal shielding to minimize stray emissions of RF energy. Airlines may nevertheless prohibit the on-board use of portable PCs (and all other portable electronic devices that could potentially emit stray RF energy), particularly during take-offs and landings, to prevent any possible interference with the reception of signals by airborne electronic navigational devices. Other locations, such as hospitals, may also restrict the use of Pocket PC’s and other devices that emit low-level RF energy.

WARNING

■ Always request and obtain prior consent and approval of an authorized airline representative before using your device aboard an aircraft.

■ Always follow the instructions of the airline representative whenever using your device aboard an aircraft, to prevent any possible interference with airborne electronic equipment.

WARNING

■ Always comply with posted prohibitions of the use of RF-emitting devices, such as in hospitals. Failure to follow such directives could result in the interference with medical equipment and/or devices.

■ Never come closer than 6 inches to a person with a heart pacemaker implant when using this device. Failure to do so could result in interference with the function of the pacemaker.

SAFETY INSTRUCTIONS

WARNING

■ Never use your device while driving an automobile or any other moving vehicle. Always pull out of traffic and come to a stop in a legally permissible and safe location before using your device. Failure to do so could result in serious bodily injury in a traffic accident.

■ Never use your device while walking. Usage while walking could result in bodily injury caused by inattention to automobile traffic or other pedestrian hazards.

WARNING

■ Never allow metallic objects, such as staples and paper clips, to enter inside your device. Metallic objects, such as staples and paper clips, if allowed to enter your device, could cause the generation of excess heat or fire.

■ Never connect terminals (metal parts) to metallic objects (such as wires). Connecting terminals to metal objects could cause excessive heat or fire.

■ Always immediately disconnect the AC Adapter from the power outlet and turn the battery switch to the “Stop” position in the event the device emits an unusual odor or sound or generates smoke.

WARNING

■ Never use or store your device in the following locations:

• Anywhere it may be exposed to water, such as a bathroom or sauna;

• In conditions of high humidity, such as in the rain or fog;

• Where your device will be exposed to high temperatures, such as near a fire or equipment

that emits high temperatures;

• In direct sunlight; or

• In a sealed automobile left in the sun and subject to high temperatures.

• Never store or transport flammable liquids, gases or explosive materials in the same

compartment of your automobile as the device or any of its accessories, as possible sparking in the PC could cause ignition or explosion.

• When driving, always secure your device in its softcase, when it is not in use. Never place

your device on the passenger seat or any place else in the car where it can become a projectile during a collision or stop.

■ Never drop your device or subject it to severe shock. Dropping your device or subjecting it to severe shock could cause the built-in battery to leak, ignite and/or rupture.

■ Always immediately remove your device and its battery from the vicinity of any source of heat, such as an open flame, in the event the built-in battery leaks liquid or emits an unusual odor. Continued use of your device under either of these conditions could cause ignition (i.e., fire) of the leaked battery liquid, or rupture.

■ Never touch any fluid that might leak from the built-in battery. Such liquid when in contact with

SAFETY INSTRUCTIONS

the eyes or skin, could cause injury to the skin or eyes.

with the eyes, irrigate the eyes thoroughly with clean water and immediately seek medical attention.

immediately with clean water.

Failure to follow the above directions concerning use and storage could result in bodily injury and/ or property damage due to battery liquid leakage, fire or rupture. Failure to follow the above directions concerning use and storage could also result in damage to your device.

In the event the liquid comes into contact with the skin or clothing, wash it away

Should the liquid come into contact

WARNING

■ Always use authorized Audiovox accessories and optional devices when operating this device, as the use of incompatible auxiliary equipment could result in fire, electric shock or other bodily injury. The use of unauthorized accessories will also void your Warranty.

WARNING

■ Never attempt to disassemble, repair or make any modification to your device. Disassembly, modification or any attempt at repair could cause bodily injury or property damage, as well as damage to the device itself.

WARNING

■ Your device is not a toy. Never allow children to play with your device. Misuse, rough or improper handling of your device by children could result in serious bodily injury for any of the enumerated safety warnings in this manual. In addition, always keep all accessories and components out of the reach of small children as small parts might present a choking hazard.

Seek immediate medical attention if choking occurs or if any small part has been swallowed.

CAUTION

■ Never raise the sound volume level too high when using your device with earphones. An excessive sound volume level could cause damage to your hearing.

■ Never touch the liquid that might leak from a broken liquid crystal display. Contact with this liquid could cause a skin rash. If the crystal display liquid should come into contact with the skin or clothing, wash it immediately with clean water.

NOTE

■ Under certain conditions, data may be lost, including: ✓ Failure to follow all instructions for use and warnings in this manual. ✓ Misuse of your device; ✓ Subjecting the main unit of your device to static electricity and/or noise; ✓ Total loss of electric charge in the built-in battery; and ✓ Servicing of your device.

SAFETY INSTRUCTIONS

■ Use of your device in locations where the following ambient environmental conditions are exceeded:

✓ Under normal operational use ambient temperatures not less than 32°F and not in excess of

104°F (0°C and 40°C);

✓ With humidity of not less than 30% or in excess of 80%; and ✓ When charging the battery ambient temperatures not less than 41°F and not to exceed 95°F

(5°C and 35°C).

■ Do not store or use your device in the following locations: ✓ Those subject to extremely high or low temperatures; ✓ Dusty locations; and ✓ Locations or sites subject to strong vibration.

Use or storage in these location, sites or areas can result in product failure, malfunction or loss of data.

■ Avoid connecting your device to an external device such as a computer in an environment likely to be affected by static electricity. For example, during low-humidity weather, shuffling your shoes upon a rug can produce static electricity. Before you handle your computer, you should touch a grounded object to discharge any static electricity from your body.

■ Do not subject your device to sudden and severe temperature changes. This could result in moisture condensation in the device that could cause damage to your device, computer function loss, and/or the loss of data. In the event of moisture condensation, allow your device to dry out completely.

■ It is normal for the AC Adapter to become warm when charging.

■ Disconnect the power plug from the outlet when not in use.

■ Take care not to sit on device when it is located in the back pocket of trousers, etc. This could

cause damage to your device or malfunction of the device functions.

■ Do not place objects on top of your device or drop them on top of your device. This could cause damage to your device and/or malfunction.

■ Never paint or apply any foreign substance to this device as this can clog and damage moving parts.

■ Clean terminals (metallic parts) on a regular basis with a dry cotton swab. Dirty terminals could affect battery charging.

■ Never use organic solvents such as benzene or paint thinner to clean your device. Use of these solvents can cause deformation or discoloration. Wipe dirty parts with a soft dry cloth.

■ Do not wipe the display with a damp or wet cloth or touch the display with damp or wet hands. Wiping or touching the display under this condition can cause product failure or malfunction. Always use a soft dry cloth to wipe the display.

■ When using the optional “SD memory card”, be sure to read the relevant instruction manual and ensure that you know the proper procedures for their use and compatibility with your device.

✓ Never subject the card to any severe shock while connected to your device. Such a shock can

cause damage to the card and a malfunction.

✓ Do not carry your device with the card connected to it. This can result in the damage or loss of

the card.

SAFETY INSTRUCTIONS

■ When the device is operating, do not insert or remove the “SD memory card” into or out of the SD card slot or connect or disconnect the device from the cradle as this may cause loss of stored data, or product failure/malfunction.

■ Never connect cradle terminals with metallic objects, such as wires. Connecting these terminals with metallic objects may cause the production of excess heat, burns and damage to the charger and/or your device.

■ To avoid eye strain, take frequent visual breaks, focusing on objects located at a distance greater than 15 feet.

CAUTION

■ A lithium ion battery is used in this device. When a replacement is needed, please request the dealer from whom your device was purchased to assist you.

■ Lithium ion batteries are recyclable. When you replace your built-in battery, please request the repair center to recycle the battery in accordance with RBRC standards. When disposing of the battery by yourself, please call RBRC at (800) 822-8837 for tips on the proper disposal of the lithium ion battery. Never dispose of the battery with ordinary waste.

SAFETY INSTRUCTIONS

Safe Use of AC Adapter

DANGER

■ Never attempt to disassemble or repair an AC Adapter, and never alter the power cords or plugs as exposure to electric shock hazards may result.

Always contact an authorized Audiovox service center, if repair or replacement is required.

■ If the plug will not fit into the available outlet, have a proper outlet installed by a qualified electrician. Improper connection can result in the risk of electric shock. Never attempt to modify or alter the AC cord or plug of the AC Adapter.

WARNING

■ Never allow the AC Adapter to come into contact with water or any other liquid. Water or any other liquid in contact with the AC Adapter can create a risk of fire or electric shock.

■ Always use the authorized Audiovox AC Adapter to avoid any risk of fire or damage to your device or battery. Bodily injury or property damage may occur as a result of the use of an unauthorized and incompatible AC Adapter.

■ Never use an AC Adapter if it has a damaged or worn power cord or plug. The use of damaged or worn power cords or plugs could result in electric shock, burns or fire. Contact an authorized Audiovox service center immediately to obtain a suitable replacement.

■ Never connect or disconnect the AC Adapter with wet hands. Connecting or disconnecting the AC Adapter to a power source with wet hands could cause electric shock.

■ Never attempt to connect or disconnect the power plug with damp or wet hands. Connecting or disconnecting the power plug with damp or wet hands could result in an electric shock.

■ Always unplug the AC Adapter from the power source before attempting any cleaning in order to avoid the risk of electric shock. Always use a soft dry cloth to clean the equipment, after it has been unplugged.

■ Never attempt to use an unauthorized AC Adapter with your device in order to avoid any risk of bodily injury or property damage. Since unauthorized accessories have different specifications, they may be incompatible with your device.

SAFETY INSTRUCTIONS

CAUTION

■ Never place an AC Adapter on a wooden surface (or any other surface that could be marred by exposure to heat) while it is in use. Since its surface temperature of the AC adapter increases during normal use, always rest it on a suitable heat-insulating material.

■ Never cover the AC Adapter with any object while it is in use, and never place it adjacent to a heat source. An excessive temperature increase could detrimentally affect its performance.

■ Never place a Power Supply Cable near a heat source, as damage to the cord or to its insulation could result.

■ Always use a surge protector when utilizing the AC Adapter during an electrical storm. Otherwise, a power surge could result in the loss of stored data.

■ Always use a surge protector when utilizing the AC Adapter near an electrical noise source such as high voltage line or power source. Otherwise, a power surge could result in loss of stored data.

■ In order to avoid any possibility of a fire, always insert the power plug into household electric outlet supplying 120V AC.

■ When traveling abroad, never plug the AC Adapter into a power source that does not correspond to both the voltage and the frequency specified on the rating plate of the AC Adapter, as equipment damage and fire will result. When you connect to a power supply of more than 125V AC, change the Power Supply Cable with one that corresponds to the power supply specification. Failure to do so could cause a fire.

CAUTION

■ Never drop the AC adapter or subject it to severe shock. This may cause ignition or electric shock, as well as damage to the adapter.

■ Always locate an accessory Power Supply Cable so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.

■ Never place heavy objects on a Power Supply Cable, as this could result in damage to the cord.

■ Never bend or twist a Power Supply Cable, and never pull on a Power Supply Cable in an

attempt to remove an AC Adapter or accessory plug from a socket. Always grasp the AC Adapter or the accessory plug directly when unplugging the Power Supply Cable in order to avoid damaging the cable.

■ Always ensure the power plug pins are clean and free of dust or other foreign material by wiping the pins with a clean dry cloth. Dust or other foreign material accumulation on the power plug pins could cause fire.

■ Be certain to insert the power plug deeply into a socket. Failure to do so could cause a fire and an electric shock.

■ Always disconnect the AC Adapter from the power source when it is not in use.

SAFETY INSTRUCTIONS

SAFE USE AND OPERATION OF DEVICE (WIRELESS HANDHELD PHONE)

Read this information before using your device. Your device is a low power radio transmitter and receiver. When it is ON, it receives and also

sends out radiofrequency (RF) signals.

FCC RF EXPOSURE INFORMATION

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to radiofrequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this device complies with the FCC guidelines and these international standards.

Use only the supplied or an approved antenna. Unauthorized antennas, damaged antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Please contact your local dealer for replacement antenna.

Body-worn Operation

This device was tested with the BC-2032 belt clip and LB-2032 softcase, offered by Audiovox, as an accessory to this device and was found to comply with the FCC exposure requirements. Other third-party belt clip and softcase or holsters have not been tested with this device and therefore their compliance with the FCC RF exposure limits cannot be confirmed.

When operating this device, a minimum separation distance of 1 inch (2.5 cm) must be maintained between the user’s body and the device, including its antenna, to comply with the FCC exposure limits.

This particular device has not been designed for held-to-ear use and should never be used against the ear. It is designed to be used in a belt clip with an earphone microphone or as a speakerphone.

For more information about RF exposure, please visit the FCC website at www.fcc.gov .

PHONE OPERATION

When speaking into the Microphone or the Earphone Microphone, a minimum separation distance of 1 inch (2.5 cm) must be maintained between the user's face and the device, including its antenna, to comply with the FCC exposure limits.

This particular device has not been designed for held-to-ear use and should never be used against the ear.

In front of your face, hold the device keeping distance from your body. or, In front of your face, hold the device wearing the earpiece keeping distance from your body.

SAFETY INSTRUCTIONS

Tips on Efficient Operation:

For your phone to operate most efficiently:

• Do not touch the antenna unnecessarily and keep the antenna from metal when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

WARNING

DRIVING

Never use a device and/or cell phone while driving an automobile or any other moving vehicle. Always pull out of traffic and come to a stop in a legally permissible and safe location before using your device. Failure to do so could result in serious bodily injury in a traffic accident.

WARNING

ELECTRONIC DEVICES

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your device.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six (6") inches must be maintained between your device and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research and recommendations of Wireless Technology Research.

Persons with pacemakers:

• Should ALWAYS keep the device more than six (6”) inches from their pacemaker when the device is turned ON.

• Should not carry the device in a breast pocket.

• If you have any reason to suspect that interference is taking place, turn your device OFF

immediately.

WARNING

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

SAFETY INSTRUCTIONS

Posted Facilities

Turn your device OFF in any facility where posted notices require so.

AIRCRAFT

FCC regulations prohibit using your device while in the air. Turn your device OFF before boarding an aircraft.

BLASTING AREAS

To avoid interfering with blasting operations, turn your device OFF when in a “Blasting area” or in areas posted “Turn off two-way radio”. Obey all signs and instructions.

POTENTIALLY EXPLOSIVE ATMOSPHERES

Turn your device OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations); below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

CAUTION

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider [or call the customer service line to discuss alternatives].

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn your device OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

“device OFF” means to turn the Radio Standby Switch “OFF”, then turn the power off using the Power button.

SAR Information

Specific Absorption Rate

THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WA VES.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., worn on the body) as required by the FCC for each model. The highest SAR value for this model phone tested when being worn on the body, as described in this user guide, is 0.56W/kg. (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http:// www.fcc.gov/oet/fccid after searching on FCC ID CJ6CET0200MT.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) web-site at http://www.phonefacts.net.

In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6

watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

Table of Contents

SAFETY INSTRUCTIONS ............................................................................................................ 5

SAFE USE AND OPERATION OF DEVICE

(WIRELESS HANDHELD PHONE) .......................................................................... 12

SAR Information........................................................................................................................ 15

Chapter 1: Getting Started ................................................................................................. 18

Welcome...................................................................................................................19

Where to Find Information ........................................................................................ 19

Chapter 2: Basic Skills........................................................................................................ 20

Parts Names and Function ....................................................................................... 21

Battery Charging.......................................................................................................27

Initial Setup............................................................................................................... 29

Setup Options........................................................................................................... 30

Connecting to a Computer........................................................................................31

Today Screen............................................................................................................32

Programs .................................................................................................................. 34

Navigation Bar and Command Bar........................................................................... 35

Pop-up Menus .......................................................................................................... 36

Notifications .............................................................................................................. 36

Entering Information ................................................................................................. 37

Entering Text Using the Input Panel ......................................................................... 37

Finding and Organizing Information.......................................................................... 46

Customizing Y our Device.......................................................................................... 47

Chapter 3: Phone Functions .............................................................................................. 55

Using Phone Function .............................................................................................. 56

Placing Calls............................................................................................................. 62

Receiving a Call........................................................................................................64

Call Waiting............................................................................................................... 66

Call Forwarding......................................................................................................... 66

Three-Way Calling.................................................................................................... 66

Voice Mail ................................................................................................................. 66

Digital Numeric Page................................................................................................ 66

Missed Call ............................................................................................................... 67

Link Dialing ............................................................................................................... 67

Emergency Dialing.................................................................................................... 68

Phone Book .............................................................................................................. 68

KeyGuard Lock......................................................................................................... 69

Scratch Pad .............................................................................................................. 69

Speed Dial ................................................................................................................ 70

Call Log..................................................................................................................... 71

Options (Preferences)............................................................................................... 72

SMS (Messaging) ..................................................................................................... 78

Accessing the Internet .............................................................................................. 83

Chapter 4: Microsoft® ActiveSync Chapter 5: Microsoft® Pocket Outlook

.................................................................................................................................................

.....................................................................................................................................

86 89

Calendar: Scheduling Appointments and Meetings..................................................90

Contacts: Tracking Friends and Colleagues.............................................................93

Tasks: Keeping a To Do List ..................................................................................... 96

Notes: Capturing Thoughts and Ideas...................................................................... 99

Inbox: Sending and Receiving E-mail Messages ................................................... 101

Chapter 6: Companion Programs .................................................................................... 106

Pocket Word ........................................................................................................... 107

Pocket Excel ............................................................................................................111

Messenger ................................................................................................... 113

MSN

Windows Media™ Player for Pocket PC ................................................................ 117

Microsoft

Reader................................................................................................... 118

Chapter 7: Pocket Internet Explorer ................................................................................ 122

The Mobile Favorites Folder................................................................................... 123

Mobile Favorites ..................................................................................................... 123

Using AvantGo Channels........................................................................................125

Using Pocket Internet Explorer............................................................................... 126

Chapter 8: Getting Connected ......................................................................................... 128

Transferring Items Using Infrared........................................................................... 129

Connecting to the Internet ...................................................................................... 130

Connecting to Work ................................................................................................ 131

Ending a Connection .............................................................................................. 132

Connecting Directly to an E-mail Server.................................................................132

Get Help on Connecting ......................................................................................... 132

Chapter 9: Optional Functions......................................................................................... 133

Home ...................................................................................................................... 134

Backing Up ............................................................................................................. 141

Chapter 10: Additional Information ................................................................................... 145

Resetting................................................................................................................. 146

Clearing Memory (Initialization) .............................................................................. 147

Specifications.......................................................................................................... 148

Chapter 1: Getting Started

Chapter 1

Getting Started

Chapter 1: Getting Started

Welcome

Congratulations on the purchase of your Pocket PC. You can keep your most important business and personal information up to date and close at hand. And with the power of Microsoft ActiveSync® you can synchronize and download information on your desktop or laptop computer with your handheld device.

With your

Pocket PC you can:

• Make and receive phone calls.

• Instantly view the day’s appointments with the touch of a button.

• Send and receive e-mails.

• Download web pages.

• Make handwritten notes

Where to Find Information

This manual describes your device hardware, an overview of its programs and explains how to connect to a computer, network, or the Internet. See the Quick Start Card for instructions on setting

up the device and installing ActiveSync

For information on: See this source:

Programs on your device

This manual and device Help. To view Help, tap then Help.

Additional programs that can be installed on the device Connecting to and synchronizing with a computer Last-minute updates and detailed technical information Up-to-date information on Pocket PC Product & technical support information about and other Audiovox Pocket PC devices.

The Companion CD.

The Quick Start Card or ActiveSync® Help on your computer. To view Help, click Help then Microsoft ActiveSync Help. The Read Me files, located in the Microsoft ActiveSync folder on the computer and on the Companion CD. http://www.microsoft.com/mobile/pocketpc http://www.audiovox.com/pda

Chapter 2

Basic Skills

Chapter 2: Basic Skills

Touch Screen

Program Button 1, 2, 3 & 4 (From the Left)

Record Button (Program Button 5)

Incoming Call / System Notification LED

Fixed Antenna

Radio Standby Switch

Charging LED

Microphone

SEND Button

END Button

Cursor Button / Navigation Button

Power Button / Front Light Button

Speaker

AC Adapter Jack

Cradle Connection Port

USB Cradle

Parts Names and Function

Main Unit (front view)

The Cradle

Initial Setting of Program Buttons

Program button 1 ........Calendar

Program button 2 ........Tasks

Program button 3 ........Home

Program button 4 ........Contacts

Program button 5 ........Voice Recorder

Chapter 2: Basic Skills

Main Unit (back view)

Stylus

Infrared Port

Color Panel

Stylus Holder

Headphone Jack

SD Card Slot

Hand Strap Attachment

Reset Switch

Chapter 2: Basic Skills

Power Button / Front Light Button

Press this to turn the device and the front light on/off.

Power button When the power is off When the power is on

Press and hold. The power turns on. The front light alternately turns on/off. Press it quickly. The power turns on. The power turns off.

Even if the power is turned off, pressing the program button turns the power on and the program screen is displayed. (However, you can change the setting. See “Setting Power” in “Customizing Your Device” later in this chapter.)

When using the device under high ambient temperatures and the temperature inside of the device goes up (to about 144°F or more), the power is forcibly turned off. In this case, after the temperature inside of the device cooled down, turn the power on and use the device under appropriate ambient temperatures. (144°F=62°C)

Battery Switch

The Battery Switch supplies/cuts the battery power to the device. When shipped, the setting is “Stop.” Before using your device for the first time:

1. Detach the Color Panel (see illustration) to expose the Battery Switch.

2. Confirm that the Radio Standby Switch is set to “OFF,” then slide the Battery Switch to “Supply”

(lower side).

Battery Switch Lock

Battery Switch

Chapter 2: Basic Skills

3. Reattach the Color Panel.

Note

Returning the switch to the “Stop” (the upper side) resets the device back to its factory settings - initial setup will need to be repeated. To move to the “Stop” side, slide the switch while inserting the stylus into the Battery Switch Lock.

Charging LED

• Steady orange ..............Built-in battery charging

• Flashing yellow............. Charging has stopped due to extreme temperatures. Charge at a

temperature of approximately 41°F - 95°F (5°C and 35°C).

• Steady green ................Built-in battery fully charged.

• Steady yellow ...............Built-in battery charging but level is not strong enough to power.

Incoming Call / System Notification LED

• Fast flashing orange.....Incoming call

(Approx. 2Hz)

• Slow flashing orange ....Indicates alarm as set through Calendar or Tasks.

(Approx. 1Hz)

Radio Standby Switch

Determines functionality of device. To turn ON, slide Radio Standby Switch to the upper side.

• ON .......Can be used as phone to make and receive calls

• OFF .....Cannot function as a phone

Using the Stylus

Use only on touch-screen for menu selection or data input.

• Tap: Touch the screen once with the stylus to open items and select options.

• Drag: Hold the stylus on the screen and drag it across to select text and images. Drag in a list

to select multiple items.

• Tap and hold: Tap and hold the stylus on an item to see a list of actions available for that

item. On the pop-up menu that appears, tap the action you want to perform.

Note

Only use the supplied stylus on the touch screen. If the stylus tip becomes damage, replace with a new one. Using a ballpoint pen or damaged stylus may damage the screen.

Chapter 2: Basic Skills

About Cursor Button

Navigate the cursor on screen by pressing the upper, lower, right or left part of the cursor button. Press the center of the button to select an option or program.

Note

The cursor movement depends on the screen. When the cursor is at the right or the left side of the screen, it may not move.

Earphone Microphone

The supplied Earphone Microphone can be used to receive phone calls. When the Earphone Microphone is inserted into the device, the microphone and speaker on the main unit will become inactive.

Also, this microphone can be used as a recorder.

Microphone

Clip

You can attach the Earphone Microphone to your pocket, etc., by using this clip.

To Headphone Jack

This device’s phone component can be used with the Earphone Microphone or as a speakerphone. Unlike conventional cell phones, it is not designed to be held against the head in conversation. Such unauthorized use of the phone, without an Earphone Microphone or other than as a speakerphone, is contrary to the design of this product and is not recommended. For instructions on how to use the phone with Earphone Microphone or as a speakerphone, please refer to page 61 of this manual.

Note

Do not use the Earphone Microphone when turning on and off the device or when connecting or disconnecting the Earphone Microphone to/from the device because a loud noise may be otherwise emitted during connection and disconnection.

Chapter 2: Basic Skills

Audio Remote Controller with Microphone

The supplied Audio Remote Controller with Microphone can be used to listen to audio playback. Combined with the headphone (sold separately), it can be used to receive phone calls. When the Audio Remote plug is inserted into the device, the microphone and speaker on the main unit will become inactive.

Also, this microphone can be used as a recorder.

Headphone

(sold separately)

SEND / END button

Play / Pause, FF, REW Switch

Play a previous song

Play / Pause

Skip to the next song

To Headphone Jack

Hold Switch

All other remote keys become inactive when “HOLD” is set. The SEND/END button is active.

Microphone

Audio Remote Controller with Microphone

Clip

Volume button

Adjust Volume

–

You can attach the Audio Remote Controller with Microphone to your pocket, etc., by using this clip.

Stop button

Stereo headphone jack

During a call, it is not possible to adjust the volume with the Volume button. Use ø 3.5mm mini-plug type headphone to connect to the Audio Remote Controller with

Microphone. This device’s phone component can be used with the Audio Remote Controller with Microphone or

as a speakerphone. Unlike conventional cell phones, it is not designed to be held against the head in conversation. Such unauthorized use of the phone, without an Audio Remote Controller with Microphone or other than as a speakerphone, is contrary to the design of this product and is not recommended. For instructions on how to use the phone with Audio Remote Controller with Microphone or as a speakerphone, please refer to page 61 of this manual.

Chapter 2: Basic Skills

Battery Charging

When using the device for the first time, set the Battery Switch to the supply side (see page 23), then fully charge the battery.

Charging the Battery

You can use two charging methods. When you connect the AC Adapter to the device, turn the power off.

• Connect the supplied AC Adapter to the cradle as shown in the figure below, and then insert the device into the cradle.

• Connect the supplied AC Adapter to the device as shown in the figure below.

Note

Charge the battery in an environment between 41°F - 95°F (5°C and 35°C). Temperatures outside this range may pause the charging process. Refer to page 24 for additional information on charging.

When charging the battery for the first time, or immediately after setting the battery switch to the supply side, fully charge the battery. If the battery is not fully charged, the remaining battery power will not be accurately displayed.

Chapter 2: Basic Skills

Maximizing the Battery Operating Time

Whenever possible, use the device with the AC Adapter – especially when it is connected to

•

your computer. Select the short powered-off time in the setting menu. This will shorten the time the unit will

•

remain on if not used. See “Customizing Your Device” later in this chapter for more information. Turn off the front light.

•

Set the screen brightness to power savings mode (front light off) or shorten the front light

•

turn-off time. See “Customizing Your Device” later in this chapter for more information. For optimal performance use in an environment between 59°F - 77°F (15°C and 25°C).

•

Anything outside this temperature range may decrease the operating time.

Battery Life

The built-in battery has a limited life that will gradually decrease after repeated charging. Replace the battery when you notice a dramatic decrease in battery performance.

Battery Charge Level and Stored Data Protection

If the battery charge level becomes extremely low or completely discharged, stored memory data will be deleted. As soon as the low battery status icon or the alarm message appears, immediately connect the AC Adapter to the device so it can charge.

• The battery gradually discharges even when not in use. If not used for a long time, it may completely discharge.

• It is strongly recommended that you save the device’s memory data to your computer or a storage card. The manufacturer is not responsible for data changed or lost due to battery discharge. For back up, see “Backing Up” in Chapter 9.

Chapter 2: Basic Skills

Initial Setup

When using your device for the first time, completely charge the battery then follow the initial setup procedures below:

1. Press the Power button and when the welcome screen appears, tap the screen with the stylus to start the setup process.

2. When the align screen appears, follow the directions for adjusting the touch screen until the stylus screen appears.

• If a finger or any other object touches the screen during a correction, it will be cancelled.

Repeat the correction procedure.

Note

3. Read and understand how to use the stylus, then tap Next.

Note

4. Read and understand pop-up menu operation, then tap Next.

5. Follow the directions for setting the location, then tap Next.

6. When the complete screen appears, initial setup is finished. After tapping the screen, the Today

To display the align screen after the initial setup process, press the Record button while pressing the center of the navigation button, or by tapping then Screen.

See “Using the Stylus” on page 24 for more information.

• Read the on-screen explanation and then operate the screen.

Display the pop-up menus, and cut and paste the data according to the screen instructions. When this stage is complete, tap Next.

screen will appear and the device will be ready to use. See “Today Screen,” later in this chapter for more information.

, Settings, System, and

Chapter 2: Basic Skills

Setup Options

Method of Setting Card into SD Card Slot

Inserting a card:

1. Turn off the power.

2. Insert the card with its contact surface (metal contact surface) facing backward into the

device.

Contact surface

Note

An SD dummy card is loaded in the SD card slot at purchase. Remove the SD dummy card before inserting the card.

Removing a card:

1. Make sure that no application is accessing the SD card.

2. Turn off the power.

3. Lightly press down on the card until a clicking sound is heard. The card will pop out slightly

from the slot.

4. Pull the card straight up to remove.

Chapter 2: Basic Skills

Connecting to a Computer

Before connecting your device to a computer, check the following.

• ActiveSync

Card.)

• The device is turned off.

• The computer you’re connecting has an available USB port for the cradle.

To connect using the supplied USB cradle:

1. Connect the USB cradle to your computer as shown in the illustration below.

is on your computer. (For installation procedures of ActiveSync®, see Quick Start

USB port

2. Insert the device into the USB cradle.

Make sure that the connector on the cradle is inserted into the port on the bottom of the device. Data can not be transferred if the connection is not made.

When your device is properly inserted into the cradle, your device will turn on automatically and

ActiveSync

Note

will automatically open on your computer.

Avoid using your device in environments that are likely to be affected by static electricity or are prone to high electrical noise. If you connect your device to a computer via the docking cradle for data transfer or data restoration purposes, Audiovox Communications Corp. will not be responsible for any device or computer malfunction, problems with data transfer or (strikethrough: restoration creation or data communication), or data modification/loss that may occur in these environments.

Chapter 2: Basic Skills

Today Screen

The Today screen appears when you turn on your device after 4 hours of inactivity. It can be accessed by tapping

Tap to switch to a program.

and then Today.

Tap to change date and time.

Tap to open information setting.

Your day at a glance.

Tap to create a new item.

Tap to view connection status.

Chapter 2: Basic Skills

Following are some of the status icons you may see.

Status Icon Meaning

Turns all sounds on and off and changes the volume level Battery charging Battery is low Battery is very low Battery is full Active connection Synchronization is beginning or ending Synchronization in process Notification that a new program or system update is available Instant message received E-mail message received

Note

If more notification icons need to be displayed than there is room for on the screen, the

will display. Tap the icon to view all the notifications.

Watcher™ Status Icons:

When Watcher™ is activated, the following icons may be displayed on the command bar of the Today screen.

Status Icon Meaning

Not connected to the network Connected to the network There is a missed call

There is an unread SMS message There is a voice mail message

Chapter 2: Basic Skills

Programs

Switch from one program to another by using the menu. To access programs not listed on the drop down menu, tap

You can also switch to another program by pressing any of the five program buttons located on the front and side of the device. The icons above the buttons identify the factory set programs (from left to right) – Calendar, Tasks, Home and Contacts. The Record button on the side is for voice recording. To reprogram these buttons to activate other programs, see page 47, “Adjusting Settings.”

The following table is a partial list of programs on your device.

Icon Program Description

ActiveSync

Calendar Keep track of your appointments and create meeting requests.

, Programs, then the desired program.

Synchronize information between your device and your computer.

Contacts Keep track of your friends and colleagues. Inbox Send and receive e-mail messages. Pocket Internet Explorer Browse Web and WAP sites, and download new programs and

files from the Internet. Notes Create handwritten or typed notes, drawings, and recordings. Tasks Keep track of your tasks. Pocket Excel Create Excel spreadsheets or view and edit Excel

spreadsheets created on your computer. MSN® Messenger Send and receive instant messages with your MSN

Messenger contacts. Pocket Word Create new documents or view and edit Word documents

created on your computer.

In addition to the programs listed above, Windows Media™ Player, Backup, Calculator, File Explorer, Home, Infrared Receive, Microsoft Reader, Terminal Services Client, Watcher, Solitaire are pre- installed.

Note

The program can be launched by using Home. See “Home” in Chapter 9.

Chapter 2: Basic Skills

Navigation Bar and Command Bar

The navigation bar, located at the top of the screen, displays the active program and time, and allows you to switch programs and close screens.

The command bar at the bottom of the screen performs tasks in the open program, and includes menu names, buttons and the Input Panel button. Tap New to create a new item in the program.

Tap to view notification messages.

Tap to change volume or mute the device.

Tap to display the current date and the next schedule.

Navigation bar.

Tap to quickly select a program you have recently used. The program launched from Home is not stored here.

Tap to select a program.

New button.

Note

If you tap on the right of the navigation bar, you can close that program screen. Also, if you tap

To end the program, tap select the program you wish to end, then tap Stop.

You can also end the program with Home.

Menu names.

Tap to see additional programs. Tap to customize the device.

Input Panel button.

Command bar.

Buttons.

on the navigation bar, you can close that screen.

, Settings, System, Memory and Running Programs, and

Chapter 2: Basic Skills

Pop-up Menus

Pop-up menus provide quick access to select an action for an item, and vary with each program. To access a pop-up menu, tap and hold the stylus on the item you want to perform the action on. When the menu appears, lift the stylus and tap the desired action. Tap anywhere outside the menu to close it.

Tap and hold to display the pop-up menu.

Lift the stylus and tap the action you want.

Tap outside the menu to close it without performing an action.

Notifications

Your device can remind you when you have an appointment or task scheduled, or serve as an alarm clock. Notification options include:

• A message box on the screen

• A sound (which you select)

• A flashing light

To select reminder types and sounds, tap & Notifications. The selected options will apply for the entire device.

and then Settings. In the Personal tab, tap Sounds

Chapter 2: Basic Skills

Entering Information

Options for entering new information include:

• Using the input panel to enter typed text.

• Writing or drawing pictures directly on the screen.

• Recording a message by speaking into the microphone.

• Using Microsoft

your device.

ActiveSync® to synchronize or copy information from your computer to the

Entering Text Using the Input Panel

Use the input panel to enter information in any program by either typing using the soft keyboard, or by writing using the Letter Recognizer, Block Recognizer or Transcriber. With either option the characters will appear as typed text on the screen.

To view/hide the input panel, tap the Input Panel button. Tap the arrow next to it to see your options.

Select an input method.

Tap to see your choices.

Input Panel button.

Chapter 2: Basic Skills

When you use the input panel, your device anticipates the word you are typing or writing and displays it above the input panel. When you tap the displayed word, it is inserted into your text at the insertion point. The more you use your device, the more words it learns to anticipate.

Tap here if this is the right word.

Note

To change word suggestion options, such as the number of words suggested at one time, tap

, Settings, Personal tab, Input, and then the Word Completion tab.

Typing with the soft keyboard:

1. Tap the arrow next to the Input Panel button and then Keyboard.

2. Use the stylus to tap the keys on the soft keyboard.

Using Letter Recognizer:

With Letter Recognizer you can write letters using the stylus just as you would on paper.

1. Tap the arrow next to the Input Panel button and then Letter Recognizer.

2. Write a letter in the box – it will automatically be converted to typed text on the screen.

For specific instructions, open Letter Recognizer and tap the question mark icon next to the writing area.

Chapter 2: Basic Skills

Using Block Recognizer:

With Block Recognizer you can use the stylus to input character strokes similar to those used on other devices.

1. Tap the arrow next to the Input Panel button and then Block Recognizer.

2. Write a letter in the box — it will automatically be converted to typed text on the screen.

For specific instructions, open Block Recognizer and tap the question mark icon next to the writing area.

Using T ranscriber:

With Transcriber you can write anywhere on the screen using the stylus just as you would on paper. Unlike Letter Recognizer and Block Recognizer, you can write a sentence or more of information. Then, pause and let Transcriber change the written characters to typed characters.

1. Tap the arrow next to the Input Panel button and then Transcriber.

2. Tap OK to close the explanation screen of Transcriber.

3. Write anywhere on the screen.

For specific instructions, open Transcriber and tap the question mark icon next to the writing area.

Selecting typed text:

1. Drag the stylus across the text you want to select.

2. Format or edit text by tapping the command on the Edit menu or by tapping and holding the

selected words until the pop-up menu appears.

Chapter 2: Basic Skills

Writing on the Screen

To write on the screen, write the same way do on paper. The text can be edited, formatted or converted at a later time.

Writing on the screen:

• To switch to the writing mode, tap the Pen button. Lines will appear on the screen to help you write.

Tap the Pen button and use your stylus like a pen.

Note

Not all programs that accept writing feature the Pen button. Refer to that program’s documentation to find out how to switch to writing.

If you accidentally write on the screen, tap Edit, then Undo and try again.

To select writing:

If you want to edit or format writing, you must select it first.

1. Tap the Pen button to cancel the writing mode.

2. Drag the stylus across the text you want to select.

You can cut, copy, and paste written text in the same way you work with typed text: tap and hold the selected words and then tap an editing command on the pop-up menu, or tap the command on the Edit menu.

Chapter 2: Basic Skills

Converting writing to text:

• Tap Tools and then Recognize.

If you want to convert only certain words, select them before tapping Recognize on the Tools menu (or tap and hold the selected words and then tap Recognize on the pop-up menu). If a word is not recognized, it is left as writing.

Select the text you want to convert and tap Recognize on the pop-up menu.

The writing is turned into text.

Chapter 2: Basic Skills

If the word conversion is incorrect, you can select an alternative word by tapping and holding down on the wrong word. On the pop-up menu tap Alternates and browse the list. Either tap the word you want to use, or tap the writing at the top of the menu to return to the original writing.

Tap to return to your original writing.

Or, tap the word you want to use.

For best recognition:

• Write neatly within the lines and draw descenders below the line. Write the cross of the “t” and apostrophes below the top line so they aren’t confused with the word above. Write periods and commas above the line.

• Using the T ools menu, increase the zoom level to 300%.

• Write the letters of words close together and leave big gaps between words.

• Any changes made to a word after you attempt to recognize it (such as changing a “3” to an “8”) will not be included if you attempt to recognize it again.

Note

Hyphenated words, foreign words that use special characters such as accents, and some punctuation cannot be converted.

Chapter 2: Basic Skills

Drawing on the Screen

Draw on the screen in the same way that you write on it. The only difference is how the items are selected and edited. For example, drawings can be resized - writing cannot.

Creating a drawing:

• A drawing box will appear when you cross any three ruled lines on your first stroke. Subsequent strokes in or touching the box become part of the drawing. Drawings that do not cross three lines will be considered writing.

The drawing box indicates the boundaries of the drawing.

Pen button.

Note

You may want to change the zoom level so that you can more easily work on or view your drawing. Tap Tools and then a zoom level.

Selecting a drawing:

If you want to edit or format a drawing, you must select it first.

• Tap and hold the stylus on the drawing until the selection handle appears. To select multiple drawings, deselect the Pen button and then drag to select the drawings you want.

You can cut, copy, and paste selected drawings by tapping and holding the selected drawing and then tapping an editing command on the pop-up menu, or by tapping the command on the Edit menu. To resize a drawing, make sure the Pen button is not selected, and drag a selection handle.

Chapter 2: Basic Skills

Recording a Message

A message can also be recorded on any program where you can write or draw on screen. In Calendar, tasks and Contacts, you can include a recording in the Notes tab. In the Notes program, you can either create a stand-alone recording or include a recording with a written note. With the Inbox program a recording can be added to an e-mail.

When recording or playing a message during data communication, hold the device keeping distance from your body as shown on page 61.

Creating a recording:

1. Hold the device’s microphone near your mouth or sound source.

2. Press and hold the Record button (on the left side) until it beeps.

3. While holding down the button make the recording.

4. Release the button to stop recording and two beeps will sound. The new recording appears in

the note list or as an embedded icon.

Note

To play a recording, tap it in the list or tap its icon in the note.

Tapping the Record button on the Recording toolbar can also make a recording. To end recording, press the Stop

button.

Indicates an embedded recording.

Tap to show or hide the Recordin

Tap to begin recording.

toolbar.

Chapter 2: Basic Skills

Using My Text

My Text quickly inserts preset and frequently used messages into the text entry areas of Inbox or

Messenger. To insert a message, tap My T ext and select a message.

MSN

Tap to select a prewritten

Note

message.

You can add text after inserting a My Text message.

To edit a My Text Message, tap Edit My Text Messages in the Tools menu. Select the message you wish to edit and make the changes. Tap OK in the upper right corner to complete the change.

Chapter 2: Basic Skills

Finding and Organizing Information

To quickly locate information using the Find feature, tap Find in the menu.

Note

To quickly find information that is taking up storage space on your device, select Larger than 64 KB in T ype .

File Explorer can also find files on your device and organize them into folders. To access from the

menu, tap Programs, then File Explorer.

Tap to change folders.

Select the sort order for the list.

Tap the folder name to open it.

Note

Tap and hold to create a new folder.

Tap to display the path entry screen for opening the shared file of the network.

Tap to display the contents of the Storage Card.

Tap to display the contents of the My Device.

To move files in File Explorer, tap and hold the item you want to move then tap Cut or Copy. Go to the file where you want to move the document and tap Paste on the pop-up menu.

Chapter 2: Basic Skills

Customizing Y our Device

Customize your device by adjusting the settings and installing additional software.

Adjusting Settings

Settings can be adjusted by tapping , Settings, and then the Personal or System tab located at the bottom of the screen. The following settings can be adjusted:

• Clock: To change the time or to set alarms.

• Menus: To customize what appears on the menu, and to enable a pop-up

menu from the New button.

• Owner Information: To enter your contact information.

• Today: To customize the look and the information that is displayed on the

Today screen.

• Buttons: To assign your favorite program to the program button.

• Remove Programs: See the following pages.

• Password: To limit access to your device. See the following pages.

• Front Light: See the following pages.

• Power: To maximize battery life. See the following pages.

• Memory: See the following pages.

Chapter 2: Basic Skills

Adding or Removing Programs

Programs installed on your device at the factory are stored on ROM (read-only memory) and cannot be removed or accidentally lost. ROM programs can be updated using special installation programs with a *.xip extension. Any programs and files added after factory installation are stored in RAM (random access memory). As long as you have enough memory, you can install any program created for your device. To find software for your device, visit the Pocket PC website at http://www.microsoft.com/mobile/pocketpc.

Note

If you update ROM programs using special installation programs with a *.xip extension, do not use the backup data which you made before updating ROM programs.

Adding programs using ActiveSync®:

Before installing a program on your device, the appropriate software will need to be installed on the computer.

1. Determine which version of the software to install by tapping System tab, tap About. In the Version tab, make a note of the information in Processor.

2. Download the program to your computer (Or insert the CD or disk that contains the program

into your computer). You may see a single *.xip, *.exe, or *.zip file, a Setup.exe file, or several versions of files for different Pocket PC types and processors. Be sure to select the program designed for the Pocket PC and your device processor type.

3. Read any installation instructions, Read Me files, or documentation that comes with the program. Many programs provide special installation instructions.

4. Connect your device and your computer.

5. Double-click the *.exe file.

• If the file is an installer, the installation wizard will begin. Follow the directions on the screen.

Once the software has been installed on your computer, the installer will automatically transfer the software to your device.

, then Settings. On the

• If the file is not an installer, an error message will appear stating that the program is valid but

designed for a different computer. You will need to move this file to your device. If you cannot find any installation instructions for the program in the Read Me file or documentation, use

ActiveSync

Explore to copy the program file to the Program Files folder on your device. For

more information on copying files using ActiveSync

Once installation is complete, tap

, see ActiveSync® Help.

, Programs, and then the program icon.

Chapter 2: Basic Skills

Adding a program directly from the Internet:

1. Determine which version of the software to install by tapping , then Settings. On the System tab, tap About. In the Version tab, make a note of the information in Processor.

2. Download the program to your device straight from the Internet using Pocket Internet Explorer.

You may see a single *.xip, *.exe or *.zip file, a Setup.exe file, or several versions of files for different device types and processors. Be sure to select the program designed for the Pocket PC and your device processor type.

3. Read any installation instructions, Read Me files, or documentation that comes with the program. Many programs provide special installation instructions.

4. Tap the file, such as a *.xip or *.exe file. The installation wizard will begin. Follow the directions on the screen.

Adding a program to the Start menu:

Tap , Settings, Menus, the Start Menu tab, then the check box for the program. If you do not see the program listed, you can either use File Explorer on the device to create a shortcut the

program to the Start Menu folder or use ActiveSync program and place the shortcut in the Start Menu folder.

on your computer to create a shortcut to the

• Using File Explorer on the device: Tap

, Programs, File Explorer, and locate the program (tap the folder list, labeled My Documents by default, then My Device to see a list of all folders on the device). Tap and hold the program and tap Copy on the pop-up menu. Open the Start Menu folder located in the Windows folder, tap and hold a blank area of the screen, and tap Paste Shortcut on the pop-up menu.

The program will now appear on the

menu. For more information on using File Explorer,

see “Finding and Organizing Information,” on page 46.

• Using ActiveSync

on your computer: Use the Explorer in ActiveSync® to explore your

device files and locate the program. Right-click the program, then click Create Shortcut. Move the shortcut to the Start Menu folder in the Windows folder. The shortcut now appears on the

menu. For more information, see ActiveSync® Help.

Removing programs:

• Tap , then Settings. On the System tab, tap Remove Programs.

If the program does not appear in the list of installed programs, use File Explorer on your device to locate the program, tap and hold the program, and then tap Delete on the pop-up menu.

Chapter 2: Basic Skills

Setting Password

Protect data and settings by choosing a password that will be requested every time the power is turned on.

1. Tap , then Settings. On the Personal tab, tap Password.

2. Select the type of password you would like to use.

Your password must be four numerals. Your password must be at least seven

characters long and contain a combination of uppercase letters, lowercase letters, numerals or punctuation.

Select how long your device must be turned off before the password is required to use your device.

Enter the password.

3. Enter a password and tap OK.

4. Tap YES on the confirmation screen. The password is saved and the screen returns to the

Personal tab screen.

Note

Record your password in a safe place. If you wish to change your password, you will have to know the existing one to access the Password setting screen. If you forget your password, you will have to initialize the device, which deletes all stored data and settings.

If the power is off, you will not be able to answer or make a phone call without entering your password.

You can automatically receive a call when the Auto-Answer is activated. However, you cannot disconnect without entering the password.

Chapter 2: Basic Skills

Setting the Front Light

1. Tap , then Settings. On the System tab, tap Front Light.

2. Set the Front Light.

Check and select when you want front light to automatically turn off.

Sets the time that elapses until the front light automatically turns off.

3. When finished, tap OK.

Note

If the remaining battery power decreases, the brightness level may be lower than the selected setting.

Automatically turns the front light off when the AC Adapter (external power) is in use.

Tap to select brightness level. If Power Save is activated, the front light turns off.

Chapter 2: Basic Skills

Setting Power

To confirm and control power usage:

1. Tap

, then Settings. On the System tab, tap Power.

2. Set Power Options.

Displays remaining battery power. When the AC Adapter is used, the battery charging mode is displayed, but the remaining battery power is not displayed.

When checked, automatically turns off when the device hasn't been used for a user-set amount of time.

Sets the time that elapses until the power automatically turns off.

Automatically turns the power off when the AC Adapter (external power) is in use.

Check to turn the power on if you press the program buttons or the SEND button when the device is off. To prevent the device from being turned on when the button is pressed accidentally, clear the checkbox.

3. When finished, tap OK.

Chapter 2: Basic Skills

Setting Memory

Memory for the device is automatically managed. You can adjust data storage memory and program running memory, and confirm the amount of free space on a storage card.

Changing memory allocation:

1. Tap , then Settings. On the System tab, tap Memory to display the Memory setting screen.

Slider.

Free space of the Program memory.

Free space of the Storage memory.

2. Drag the slider widthwise to adjust the memory allocation between Storage and Program.

3. When finished, tap OK.

Chapter 2: Basic Skills

To confirm usage status of a storage card:

1. Tap , then Settings. On the System tab, tap Memory, then the Storage Card tab on the

bottom.

Capacity of a storage card being inserted.

Free space.

Capacity in use.

2. When finished, tap OK.

Releasing memory:

If memory is approaching full capacity, you can free up space by:

• Transferring data to a storage card or to your computer then delete it from your device.

• Deleting unnecessary files and programs.

• Quitting the program currently in use.

Note

For more detailed information on operation method or the releasing memory, tap then

Help.

Chapter 3

Phone Functions

Chapter 3: Phone Functions

Using Phone Function

Launching W atcher

The “Watcher” program is used for the phone functions of your device. When the Radio Standby Switch is ON and Watcher is launched, the Watcher screen automatically is displayed when a call is received, even if you are currently using another program.

1. Turn the Radio Standby Switch (located on the left side) ON. Watcher will automatically launch and the phone can be used when the main screen appears.

Note

When launched, a watcher status icon is displayed on the right part of the Today screen command bar.

As long as the Radio Standby Switch is ON, the Watcher screen will automatically appear when a call is received, even if the main unit is off.

is operated by the Pocket PC operating system and the application programs on the device, pre-loaded and post-loaded. If the system get in such unusual case as when a button or tapping the screen does not respond, the phone functions are also unavailable, voice or data, outgoing or incoming. In such a case, please reset your device. See Chapter 10 (Resetting).

Ending Watc her

1. Turn the Radio Standby Switch OFF. Watcher will turn off and the screen will disappear.

Do not quit Watcher during a call or communication.

Note

When Watcher is OFF, the phone functions will not work even if the device is on. If you turn the switch OFF while the device is OFF, the device will turn on automatically,

and then the Watcher will turn off.

Chapter 3: Phone Functions

Main Screen

DATA tab

In Use Indicator. Receiving Signal Strength Indicator.

Coverage Indicator Icons. Receiving Signal Strength/No Service Indicator.

Status box displays information about the current call and any status messages.

Indicator icons.

Connection Drop-List. Phone number of the connection destination.

VOICE tab

Shortcut to Dial-up Manager.

Data/Voice Controls Tab Selection.

Call progress indicator. Incoming or Outgoing number and cross-referenced Phone Book name.

Phone Book.

Volume up and down, and Microphone Mute.

Scratch Pad. SEND button.

END button. CLR button.

Dial pad.

Chapter 3: Phone Functions

Icons

Icons of the display indication

Icon

Icons of the modem

Meaning

Auto-Answer incoming Voice Calls Unread message waiting - flashes when message is set to high priority. One or more voice mail messages One or more missed calls Earphone connected to the device When receiving a call, the ringer tone sounds and the vibrating alert

vibrates simultaneously. When receiving a call, the ringer tone does not sound but the vibrating

alert vibrates. When receiving a call, the ringer tone does not sound and the vibrating

alert does not vibrate. Mutes during a call. Enhanced Voice Privacy is available during a call. 1X Service can be used Roaming

Icon Meaning

Modem is currently unusable. Data transfer High speed data transfer Voice call

Chapter 3: Phone Functions

Keypad Operation List

Regardless of the program in use, pressing the SEND button or the END button while Watcher is open displays the VOICE tab of the Watcher screen.

Even if the power is turned off, pressing the SEND button turns the power on and displays the VOICE tab screen. (However, the setting can be changed not to turn the power on.)

When the Watcher screen is displayed, the SEND/END buttons on the device perform the same functions as the SEND/END buttons on the screen. Button functions include:

SEND

END

CLR

0-9,

, #

Idle

Calls phone number displayed on screen. If a phone number is not displayed, last number dialed is called.

Delete all entered numbers at once.

Delete entered numbers one by one or tap and hold CLR button to delete them all at one time.

Enter the number you wish to call. Tap and hold the Speed Dial location number for one-touch dialing of that number.

Incoming Call

Answer a call.

Reject the incoming call.

Mute the ringer tone.

If Any-key Answer is set, you can answer a call by tapping any of these keys.

During a Voice Call

Answers incoming call; switches to Three-Way calling.

End all calls including the three-way calling.

Delete messages or entered numbers one by one. button to delete them all at one time.

Number entered is displayed on screen.

Tap

and hold the

Navigation Button and Program

When in the Watcher screen, pressing the navigation button on the device opens the following programs:

Phone Book

Top : Phone Book Bottom : Messaging

CLR

Speed Dial

Messaging

Call Log

Right : Call Log Left : Speed Dial

Chapter 3: Phone Functions

Tools menu:

The following items can be selected from the Tools menu of the DATA and VOICE tabs:

Displays the Messaging screen.

Displays Phone Book.

Displays screen for storing numbers. Displays a list of incoming calls, outgoing calls,

missed calls. Displays the Connections setting screen.

Protects against accidental operation.

Displays Options for changing settings.

Admin menu:

The following items can be selected from the Admin menu of the DAT A and VOICE tabs:

Displays information about Watcher.

Use this when the phone functions of device are not activated.

Chapter 3: Phone Functions

Talking on the Phone

Here explains how to use your device when you talk on the phone. Keep the device from your face more than 1 inch (2.5 cm).

Using the Microphone and Speaker:

Using the Earphone Microphone:

To use the supplied Earphone Microphone, insert it into the headphone jack.

For the Earphone Microphone, see page 25 of Chapter 2.

Using the Audio Remote Controller with Microphone:

To use the Audio Remote Controller with Microphone, insert it into the headphone jack and insert the headphone (sold separately) into the stereo headphone jack of the Audio Remote Controller with Microphone.

For the Audio Remote Controller with Microphone, see page 26 of Chapter 2.

To use the SEND/END button of the controller, press and immediately release for SEND and press and hold for END.

Chapter 3: Phone Functions

Placing Calls

To place a call, Watcher must be launched.

Dialing

1. On the VOICE tab screen, use the dial pad to enter the phone number and tap SEND.

appears when the call is connected.

Call is connected.

Note

If a mistake is made while dialing, tap CLR to clear the last digit, or END to clear the entire number.

Ending a Call

1. Tap END to end a call. The call time will disappear from the screen.

Chapter 3: Phone Functions

Dialing from the Phone Book

1. To access Phone Book either tap on the VOICE tab screen or tap Phone Book on the Tools menu.

2. Select the phone number you wish to call, then tap Dial on the command bar. appears

when the call is connected.

Note

Dial can be found in the pop-up menu that appears when you tap and hold a phone book

entry. Double tapping the desired phone number also places the call.

Speed Dialing

1. On the VOICE tab screen, tap and hold the corresponding speed dial location number of the

number you wish to call for at least one second. The phone number stored at that location is dialed.

Note

Selecting the corresponding speed dial location on the keypad and then tapping SEND can also place Speed Dial calls.

For more details on this function see “Speed Dial” (page 70).

Dialing from the Call Log

1. Tap Call Log on the Tools menu.

2. Tap the number you want to dial and select Dial from the File menu, or press the center of the

navigation button.

Note

You can also place calls by tapping and holding the number you want to dial and selecting Dial from the pop-up menu. For details on the Call Log screen, see “Call Log” (page 71).

Redialing

1. Tap SEND on the VOICE tab screen to call the last number dialed.

Note

The redial function does not work when there has been a missed call.

Chapter 3: Phone Functions

Receiving a Call

Depending on the settings, an incoming call is alerted with an audible sound, a flashing indicator, or a vibrating alert.

1. To answer a call, tap the SEND button on the device or the screen. Tapping CLR or the Volume button can mute the ringer tone.

About Any-key Answer:

• When activated, Any-key Answer enables calls to be answered by tapping any button, other than the END, CLR or Volume buttons. This also includes the four program buttons on the front of the device.

• To set, in the VOICE tab screen, tap Tools, Options, and then scroll over to Voice at the bottom of the screen. For more information, see page 77.

About Caller ID: If a call is received from a number stored in the Pocket Outlook

number will be displayed. “Unknown” will be displayed if the caller is not on the Contacts list.

Contacts list, the name and

Note

When END is tapped during an incoming call, it is rejected and the missed call icon appears.

Chapter 3: Phone Functions

Volume Control

Adjust the ringer volume by using the Speaker Icon on the navigation bar and the call volume (the speakerphone volume) by using the Volume buttons.

Tap to adjust the ringer volume.

Appears when Volume buttons are used.

Speaker Icon button.

Volume buttons.

Speaker Icon button:

The ringer type changes each time you tap the Speaker Icon button. The setting options in standby mode are “Ringer Only,” “Ring and Vibe,” “Vibrate Only,” and “Silent

Mode” (Ring and Vibe Off). During a call, the setting switches between “Sound on” and “Mute”.

Volume buttons:

When you tap the Volume buttons, a volume bar appears on the screen to indicate the call volume level (6 levels excluding Mute).

The call volume (the speakerphone volume) can be adjusted by tapping Tools on the VOICE tab screen, then Options, then Sounds at the bottom of the screen.

Chapter 3: Phone Functions

Call W aiting

When you’re on the phone and another call is received, you hear a call waiting tone and “Call Alert From” appears on the display.

1. Tap SEND to put the original party on hold and switch to the new caller. When speaking to the new caller, the information for the first caller will not be displayed.

2. Tap SEND to switch to the original caller.

Call Forwarding

Call Forwarding transfers incoming calls to another phone number. Please contact your service provider about this feature.

Three-Way Calling

Three-Way Calling allows you to simultaneously talk to two callers at different phone numbers. Please contact your service provider about the availability of this feature.

1. When connected to one party, tap SEND and enter the second party’s number, then tap SEND again.

2. When the second call is connected, tap SEND to talk to both callers.

3. Tap END to disconnect both parties.

Voice Mail

appears on the display when you have new voice mail.

1. Tap

2. On the confirmation dialog screen, tap Yes. The phone connects to your voice mailbox.

The voice mailbox phone number can be set at the Voice tab in Options. For details, see page

77.

Digital Numeric Page

When Digital numeric page is received, “Numeric Page: XXX-XXXX” appears on the screen. XXX-XXXX is numerical.

The received “Digital numeric page” is saved as SMS in Inbox. To call the number, tap Messaging on the Tools menu, then select the Digital numeric page, then

tap Call back Sender on the File menu.

Chapter 3: Phone Functions

Missed Call

appears if you do not answer a call.

Tap END to turn off the missed call message.

Returning Missed Calls

To return the last missed call, tap SEND. When is tapped, the Call Log appears. This can be used to select a contact to call back. For details on the Call Log function, see page 71.

Note

If the caller’s number is not identified, you cannot call back.

Link Dialing

With Link Dialing you can place calls require multiple inputs in a sequence of continuous operations. It is set when storing phone numbers in the Contacts of Pocket Outlook®.

Link Dialing Storing

1. From the Today screen tap New then Contact.

2. Enter the phone number.

3. After the phone number, enter uppercase “L” or lowercase “l”, then the next number.

4. To enter more numbers repeat step 3.

5. Once all the numbers are entered, tap OK then start Phone Book in Watcher.

6. Tap Refresh on the command bar. The set number is read into Phone Book, and calls can now

be placed from there using Link Dialing.

Example: 604-323-

****

L 9837

***

l 9832

Chapter 3: Phone Functions

Emergency Dialing

Emergency calls can be placed - even if the phone is not registered or activated, or KeyGuard is activated -- as long as the power is on and there is a signal.

1. Enter “911” from the dial pad and tap SEND.

2. Tap END to end the call.

Note

If an emergency number is stored in Speed Dial you will be able to dial it by pressing a single key. However, speed dial will not work if KeyGuard is enabled.

The emergency call number varies from region to region.

Phone Book

The Phone Book screen, which displays the names and numbers stored in Contacts, can be used to place calls. Numbers added to Contacts can easily be transferred to the Phone Book.

To display the Phone Book, go to the VOICE tab screen, and tap Tools menu. To dial, tap the contact you wish to call, and tap Dial.

Tap the first letter of the name you want displayed.

, or tap Phone Book on the

Note

Tap to dial the selected phone number.

Names and phone numbers cannot be added directly to the Phone Book screen. They must be entered in Contacts first.

Tap to read in the data from Contacts and refresh the Phone Book.

Chapter 3: Phone Functions

KeyGuard Lock

This function guards against accidentally inputting numbers or pressing unwanted keys. To enable from the VOICE tab screen:

1. Tap Tools, then KeyGuard. “KeyGuard enabled” appears on the screen.

2. Repeat the same process to turn KeyGuard off.

Note

When KeyGuard is enabled, the only functions that can be performed are selecting the

Tools/Admin menus, placing emergency calls, receiving incoming calls (by tapping SEND), and turning the KeyGuard mode off.

Scratch Pad

The Scratch Pad allows you to take notes while on the phone. To access, tap .

Tap to close Scratch pad. Contents will remain even when device is shut down.

Tap to delete all notes.

Chapter 3: Phone Functions

Speed Dial

Using speed dial simplifies calling.

Storing

1. To access speed dial list, tap Speed Dial on the Tools menu or press left on the navigation

button.

2. Tap the area next to the dial pad number where you want to store a phone number, and the Phone Book screen appears.

3. Select the contact you want to store, then tap Add on the command bar.

4. Tap OK.

Tap to call to the phone number in the right section.

Clearing

1. Tap Speed Dial on the Tools menu or press left on the navigation button. The phone number

section storing dial pad number appears.

2. Tap and hold the entry you want cleared.

3. When the pop-up menu appears, tap Clear Speed Dial Entry.

“<Unassigned>” appears in the location.

4. Tap OK.

Chapter 3: Phone Functions

Call Log

Call Log screen displays a list of incoming, outgoing and missed calls, including caller information and call time. To display, tap Call Log on the Tools menu or press right on the navigation button.

When you tap and hold a log entry a pop-up menu displaying Delete, Copy Phone Number and

Dial.

Adding Telephone Numbers From the Log

1. Tap and hold the contact name, when pop-up menu appears tap Copy Phone Number.

2. Tap

3. Using the Edit menu at the bottom of screen and paste the copied number into the phone

number section.

Note

, Contacts and New.

Numbers marked “Unknown” in the call log cannot be called or stored in Contacts.

Storing Call Log As a Text File

1. Tap Save As on the File menu.

2. Name the text file on the Save As screen.

3. Tap OK.

Chapter 3: Phone Functions

Options (Preferences)

Tap Options on the Tools menu to display the Options setting screen. A number of settings (Security, Sounds, etc.) can be made at this screen.

General

Sets number of minutes a line is disconnected after data communication ends. (Display tab of Options can be set to display warning before line is disconnected.)

Select the mode for answering incoming calls.

Select the number of calls to be retained in the Call Log. Calls exceeding this number are automatically deleted.

When contracting with two NAMs (Number Assignment Modules), you can select to use either of the NAMs.

System selection is possible in an area that permits roaming. Automatic A: Automatic B: Home Only: Permits only home service. Automatic: Permits roaming if the home service is not found.

When checked, CDMA network updates the time when Watcher is launched.

Check when connecting teletypewriter, etc. to the headphone jack.

Tap to save the new settings.

Tap to restore all the settings to the defaults.

Tap to return to the previous screen without storing the settings.

Scans the Priority system, if not found, scans the A-system. Scans the Priority system, if not found, scans the B-system.

The operations for Cancel, Restore and Save are common for each tab screen.

Chapter 3: Phone Functions

Display

Check to display the Warning Message while meeting the conditions on the right part.

Chapter 3: Phone Functions

Messaging

Sets options for short message services.

Sets messages expiration dates.

Check here then tap Change to display the Callback entry screen. Enter the phone number you want displayed as a callback number when a message is sent.

Sets Outbox storage preference.

Chapter 3: Phone Functions

Security

Use Security tab to lock the modem or change the password. When the modem is locked, most menu functions (Options, Messaging, Call Log etc.) cannot be

used. (The Unlock Modem menu can be selected.) Also, no calls other than emergency calls can be placed, and when a call is received, the caller’s

phone number is displayed “ The default of the lock code is the last four digits of the device’s phone number, if the phone is

activated.

***

”.

Select never or on power up.

Tap to change the lock code. To change the lock code, first enter the old lock code, then enter the new one.

Tap to immediately lock the modem.

Chapter 3: Phone Functions

Sounds

Use to select the sounds for incoming calls, voice mail and SMS messages.

When a box is checked that alert will sound.

Tap “>” to play selected sound. Tap “...” to select a sound file.

Select a receiving type from “Ringer Only”, “Ring and Vibe”, “Vibrate Only” and “Ring and Vibe Off” in the “Incoming Call” section. You can also select a receiving type with the Speaker Icon button on the VOICE tab screen.

Adjust the volume of the conversation. The volume can also be changed at the VOICE tab.

Chapter 3: Phone Functions

Voice

Determines when auto-answer function answers phone. Ideal to use while driving.

Determines when to retry a call that did not connect.

When checked, automatically adds hyphenation when phone numbers are entered on dial pad.

When this is checked, incoming calls can be answered by pressing any key other than END, CLR and the Volume button. This function does not work in the KeyGuard mode.

Sets the dial pad tone length.

When checked, tone is not sounded.

When checked, tone sounds every minute during phone calls.

When this is checked, a tone is sounded when calls are interrupted, when the service area switches from home to roaming, etc.

Enter the phone number, then tap Change to set the number for checking your voice mail.

Chapter 3: Phone Functions

SMS (Messaging)

Contact your service provider before using this function. Tap Messaging on the Tools menu to display the SMS message screen.

appears on the display when you receive a message, flashing if it is high priority.

Tap this indicator to open the SMS screen.

The following is a list of the icons displayed with the SMS function.

Icon Meaning

High priority message. Saved, unsent message in the Outbox. Error occurred during transmission and message not sent. Transmission to network is complete. Mail recipient received message.

Messages marked with this check will be deleted when Delete is selected from the Edit menu.

Chapter 3: Phone Functions

Inbox

Received messages are stored in the Inbox.

List of received messages. Unread messages displayed in bold.

Time message was received.

Sender’s phone number.

Displays Callback number when the sender specified it.

Message priority.

Number of messages stored in the Inbox.

Tap to compose a new message.

The following options can be selected through the File menu:

New Message: Create a new message Forward Message: Forwards message to another party Reply to Sender: Reply to sender with the sending number already entered. Call back Sender: Calls the sender back.

The following options can be selected through the Edit menu. Delete: Deletes checked messages Delete All: Deletes all messages in box, regardless of whether or not they are checked.

Chapter 3: Phone Functions

Outbox

Sent and unsent messages are stored in the Outbox.

List of sent or saved messages.

Icon displayed depends on message status - see page 78.

Message status.

Destination address.

Set Callback number.

Number of messages stored in Outbox.

The following options can be selected from the File menu.

Edit Message: Edits stored messages - overwriting previous message. New Message: Create a new message

The following options can be selected through the Edit menu. Delete: Deletes checked messages Delete All: Deletes all messages in box, regardless of whether or not they are checked.

Chapter 3: Phone Functions

Composing New Messages

1. At the Messaging screen, tap on the command bar.

2. Enter the recipient’s phone number or address with the input panel or by accessing the Phone Book by tapping To. (See the following page.)

3. Select Normal or Urgent for Priority.

4. Enter the message and press Send. If the message is successfully transmitted, the screen

automatically closes.

Note

Selecting Send from the File menu also sends messages. To store sent messages in the Outbox see the SMS tab in Options. This function must

be set if you want to check whether or not the recipient received the message.

Tap to view stored contacts.

Keeps track of characters entered. Message limit is 160.

Select Normal or Urgent (for urgent messages).

The following options can be selected from the File menu.

Send: Sends message. Save: Saves message to Outbox without sending it. To send the message, select it in the Outbox,

tap Edit Message from the File menu, then tap Send. Tap OK to stop operations. Select Yes when the save message appears to store the message, and

No not to save it.

Chapter 3: Phone Functions

Selecting recipients:

1. On the message screen, tap To.

2. Select the recipient from the list, then tap Add. Recipients can also be selected by continually

double tapping the phone number or address.

3. After selecting recipients, tap OK.

Enter contact not listed in Phone Book, then tap Add to include in Recipients.

To remove a recipient, select the recipient and tap Remove.

Displays recipients.

Tap to return to previous screen.

Sending messages to multiple recipients:

Add multiple recipients by repeating steps outlined above. If not using names from the Phone Book list, enter a “,” or “;” after each number.

For example: 98701****; 98712****;

Chapter 3: Phone Functions

Accessing the Internet

Access the Internet by selecting Circuit Switch Data or High Speed Data from the DA TA tab or by using an ISP.

High-speed packet service. Connection service allowing smooth connection

to the Internet.

1. Tap the pull-down list and select the desired connection name.

2. Tap Connect to access the Internet.

Chapter 3: Phone Functions

Enter the connection name. (Example: ISP name)

Enter the connection user name specified by the ISP.

Enter the connection number.

Enter the connection password.

Using Subscribed Internet Service Provider (ISP):

1. Tap Dial-Up Manager on the Tools menu. The Connections setting screen appears.

2. Tap Add.

3. Enter the required information.

Chapter 3: Phone Functions

4. Tap Save. The settings are now stored and can be accessed.

Note

After establishing the dial-up setting using the Sierra Wireless SB555 Modem by setting Connection of Settings, if you restart Watcher with Radio Standby Switch, you can also use the connection setting from the DATA tab screen. For more information on setting Connection of Settings, see “Connecting to the Internet” in Chapter 8.

After the setting is entered, you can access your subscribed ISP. Tap Connect from the DATA tab screen to connect to the Internet, once connected, you can:

• Send and receive e-mail messages by using Inbox. Before you can use Inbox, you need to

provide the information it needs to communicate with the e-mail server. For specific instructions, see “Connecting Directly to an E-mail Server,” in Chapter 8.

• Visit Web and WAP pages by using Pocket Internet Explorer. For more information, see

Chapter 7.

• Send and receive instant messages with MSN

Messenger. For more information, see “MSN

Messenger,” in Chapter 6.

Chapter 4: Microsoft® ActiveSync

Chapter 4

Microsoft

ActiveSync

Chapter 4: Microsoft® ActiveSync

Microsoft® ActiveSync® synchronizes the information on your computer with the information on your device. Synchronization compares data between the two and updates both with the most recent information. For example:

• Keep Pocket Outlook® data up-to-date by synchronizing your device with your computer’s

Microsoft

• Synchronize Microsoft

Outlook®.

Word and Microsoft® Excel files between the two. Files will be

automatically converted to the correct format.

Note

With ActiveSync

Use ActiveSync® options to select which types of information to be synchronized.

, you can also:

• Back up and restore your device data.

• Copy (rather than synchronize) files between your device and computer.

• Control when synchronization occurs by selecting a synchronization mode. For example, you

can synchronize continually while connected to your computer or only when you choose the synchronize command.

• Select which information types are synchronized and control how much data is synchronized.

For example, you can choose how many weeks of past appointments you want synchronized.

Before you begin synchronization, install ActiveSync

on your computer from the Companion CD. For more information on installing ActiveSync®, see your Quick Start Card. ActiveSync® is already installed on your device.

Chapter 4: Microsoft® ActiveSync

After installation is complete, the ActiveSync® Setup Wizard will:

1.Help connect your device to your computer.

2.Set up a partnership to synchronize information between the two devices.

3.Customize the synchronization settings.

Synchronization automatically begins when you finish using the Wizard. After this initial synchronization, view your device’s Calendar, Contacts and Tasks. Everything stored in Microsoft Outlook® on your computer should now be on your device. Disconnect the device from your computer and you’re ready to go.

To initiate ActiveSync

on your device, tap , and then tap ActiveSync.

For information about using ActiveSync® on your computer, see ActiveSync® Help in the ActiveSync program.

View connection status. Tap to connect and synchronize.

Tap to stop synchronization.

View synchronization status.

Tap to synchronize via IR or chan

e synchronization settings.

For more information about ActiveSync® on your device, switch to ActiveSync®, tap , then tap

Help.

Chapter 5

Microsoft

Pocket Outlook

Chapter 5: Microsoft® Pocket Outlook

Microsoft® Pocket Outlook® includes Calendars, Contacts, Tasks, Inbox and Notes which can be used individually or together. For example, e-mail addresses stored in Contacts can be used to address e-mail messages in Inbox.

ActiveSync® synchronizes information in Microsoft® Outlook® or Microsoft® Exchange on your computer with your device, comparing changes made on both and updating each of them with the

latest information. For information on using ActiveSync

, see ActiveSync® Help on the computer.

Calendar: Scheduling Appointments and Meetings

Use Calendar to schedule appointments, including meetings and other events. You can check your appointments in one of several views (Agenda, Day, Week, Month, and Year) and easily switch views by tapping one of the 5 view icons at the bottom of the screen or by pressing the Calendar Program (button#1 on front of your device).

To access the Calendar, tap front of the device.

, then Calendar. Or, press the Calendar Program button on the

Tap to go to today.

Tap to display or edit the appointment details.

Tap to switch between the 5 views (Agenda, Day, Week, Month and Year).

Tap to create a new appointment.

Note

Tap Options on the Tools menu to customize the Calendar display.

Chapter 5: Microsoft® Pocket Outlook

Creating an appointment:

If you are in Day or Week view, tap the desired date and time for the appointment.

1. Tap New.

Tap to return to the calendar (the appointment is saved automatically).

Tap to choose from predefined text.

Tap to choose from previously entered locations.

Tap to select a time. Tap to select a date.

Notes is a good place for maps and directions.

2. Enter a description and location.

3. Adjust date and time as needed.

4. Enter other desired information. Hide the input panel to view all available fields.

5. Tap the Notes tab to add notes or a drawing, or to create a recording. For more information see

“Notes: Capturing Thoughts and Ideas” later in this chapter.

6. Tap OK when finished.

Note

If you select Remind me in an appointment, your device will remind you according to the options set in the

menu, Settings, Personal tab, Sounds & Notifications.

Chapter 5: Microsoft® Pocket Outlook

Using the Summary Screen

Tap an appointment to display the summary screen. To make changes, tap Edit.

View appointment details.

Display notes.

Tap to change appointment.

Creating Meeting Requests

Calendar can set up meetings with Outlook® or Pocket Outlook® users. The meeting request will be created automatically and sent either when you synchronize Inbox or when you connect to your e-mail server. Indicate how you want meeting requests sent by tapping Tools then Options. If you

send and receive e-mail messages through ActiveSync

To schedule a meeting:

1. Create an appointment.

2. In the appointment details, hide the input panel, then tap Attendees.

3. Select the meeting attendees from your Contacts list. Tap OK.

The meeting notice is created automatically and placed in the Outbox folder. For more information on sending and receiving meeting requests, see Calendar Help and

Inbox Help on the device.

, select ActiveSync.

Chapter 5: Microsoft® Pocket Outlook

Contacts: Tracking Friends and Colleagues

Contacts maintains an easily accessible list of friends and colleagues (See note below). The device’s infrared (IR) port allows you to quickly share Contacts information with other device users. To access Contacts, tap the device.

Select the category of contacts you want displayed in the list.

, then Contacts. Or, press the Contacts Program button on the front of

Tap and enter part of a name to quickly find it in the list.

Tap to see additional phone numbers and e-mail addresses.

Tap to display or edit the contact details.

Tap and hold to display a pop-up menu of actions.

Tap to create a new contact.

Note

Tap Tools then Options to change the way information is displayed. All phone numbers stored in Contacts can be accessed from the Phone Book to place a

call. When transferring the contact to another device by using infrared (IR), tap and hold that

contact, then tap the Beam Contact from the displayed pop-up menu. For more information, See “Transferring Items Using Infrared” in chapter 8.

Chapter 5: Microsoft® Pocket Outlook

Creating a contact:

1. Tap New.

ap to return to the contact list (the contact is saved automatically).

Scroll to see more fields.

Notes is a good place for maps and directions.

2. Enter name and contact information. Scroll down to see all available fields.

3. Tap Categories to assign the contact to a category. In the list, Contacts can be displayed by

category.

4. Tap the Notes tab to add notes or a drawing, or to create a recording. For more information, see “Notes: Capturing Thoughts and Ideas” later in this chapter.

5. Tap OK when finished.

Finding a contact

There are four ways to find a contact from the contact list:

• Enter a name in the box under the navigation bar. To view all contacts, clear text from the box

or tap the button to the right of the box.

• Tap the category list (labeled All Contacts by default) and select the type of contact you want

displayed. To view unassigned contacts, select No Categories. Select All Contacts to view the entire contacts list.

• To view contacts by their company names, tap View, then By Company. The number of

contacts working for that company will be displayed to the right of the company name.

• Tap

, Find, enter the contact name, select Contacts for the type, then tap Go.

Chapter 5: Microsoft® Pocket Outlook

Using the Summary Screen

Tap a contact to display the summary screen. To make changes, tap Edit.

View contact details.

Tap to change contact information.

Tap to view or add notes.

Chapter 5: Microsoft® Pocket Outlook

Tasks: Keeping a To Do List

Tasks keeps track of what has to be done. To access, tap , then Tasks. Or, press the Tasks Program button on the front of the device.

Select the category of tasks you want displayed in the list.

Select the sort order of the list.

Indicates high priority.

Tap to display or edit the task details.

Tap and hold to display a pop-up menu of actions.

Tap to create a new task.

Note

Tap Tools then Options to change the way information is displayed.

Chapter 5: Microsoft® Pocket Outlook

Creating a task:

1. Tap New.

Tap to return to the task list (the task is saved automatically).

Tap to choose from predefined subjects.

Notes is a good place for maps and drawings.

2. Enter a description.

3. Enter a start and due date or other information by tapping the field. To see all available fields,

hide the input panel.

4. Tap Categories to assign the task a category. In the list, Tasks can be displayed by category.

5. Tap the Notes tab to add notes or a drawing, or to create a recording. For more information,

see “Notes: Capturing Thoughts and Ideas” later in this chapter.

6. Tap OK when finished.

Note

To quickly create a task with only a subject, tap Entry Bar on the Tools menu. Then, tap Tap here to add a new task and enter your task information.

Chapter 5: Microsoft® Pocket Outlook

Using the Summary Screen

Tap a task to display the summary screen. To make changes, tap Edit.

View task details.

Tap to show and hide additional summary information.

View notes.

Tap to change task.

Chapter 5: Microsoft® Pocket Outlook

Notes: Capturing Thoughts and Ideas

Notes quickly captures thoughts, reminders, ideas and phone numbers. You can also create a recording to include with the entry.

Tap to change the sort order of the list.

Tap to open a note or play a recording.

Tap and hold to display a pop-up menu of actions.

Tap to create a new item.

Tap to record.

Tap to show or hide the Recording toolbar.

Chapter 5: Microsoft® Pocket Outlook

Creating a note:

1. Tap New.

2. Create your note by writing, drawing, typing, and recording. For more information about using

the input panel, writing and drawing on the screen, and creating recordings, see “Entering Text Using the Input Panel” in Chapter 2.

Tap to return to the note list (the note is saved automatically).

100

Tap to show or hide the input panel.

Tap to write on the screen.

Tap to add a recording to the note.

Audiovox Thera PDA2032 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
