Audiovox PMC-50 User Manual
PMC-50
FM MODULATOR / WIRED COMMANDER
FOR CD CHANGER SYSTEMS
P-14R
WIRELESS REMOTE CONTROL (Optional)
OWNER'SOWNER'S
OWNER'S
OWNER'SOWNER'S
by AUDIOVOX
MANUALMANUAL
MANUAL
MANUALMANUAL
INDEX
OPERATING INSTRUCTIONS.............................................................................2
WIRED COMMANDER OPERATION ...............................................................3-4
DISC ID FEATURE ...........................................................................................5-6
CD CHANGER ERROR CODES .........................................................................6
WIRELESS REMOTE CONTROL ....................................................................7-8
SETTING THE FM MODULATOR OUTPUT FREQUENCY ................................9
SYSTEM RESET ................................................................................................9
TROUBLESHOOTING ......................................................................................10
WARRANTY ..................................................................................BACK COVER
1
OPERATING INSTRUCTIONS
The PMC-50 FM Modulator/Wired Commander is designed to
permit operation of compatible Prestige CD changers through the
FM section of any car stereo system. Please check with your
Prestige car stereo specialist for recommendations of the CD
changer models that will work with the PMC-50. The specific
details on the handling of discs and the use of the CD magazine
(loading, removal, etc.) will be found within the Owner’s Manual of
the compatible changer.
Since the PMC-50/CD changer system will operate through the FM
stereo section of your existing sound system, adjustment of the
audio functions (volume, tone, balance etc.) is made by using the
controls on the car stereo. Control of disc play is by the wired
commander of the PMC-50 which can be conveniently mounted to
the dashboard, as well as by the optional P-14R wireless remote
control. The output from the FM modulator of the PMC-50 is at
88.3, 88.7, 89.7, or 89.9 MHz. (which can be set by the user) on the
FM band. To simplify operation of the system, it is recommended
that a pre-set memory pushbutton on the radio be set to the
selected output frequency of the modulator. Consult the operating
instructions of the car stereo for directions on setting the memory
pushbuttons.
SETTING UP FOR OPERATION
Following the instructions in the owner’s manual of the compatible
CD changer, load the desired number of discs into the CD
magazine and insert the magazine into the changer.
Turn on the car stereo and select FM band operation. Tune the
radio to the frequency to which the PMC-50 has been set (see
“SETTING THE FM MODULATOR OUTPUT FREQUENCY” section of this manual) or push the pre-set memory pushbutton that
has been set as per the above description.
Turn on the changer system by pressing the Play/Pause button 2
on the commander. The display panel on the commander will
illuminate and play of the first disc in the magazine will begin.
Adjust the volume, tone, and balance to your taste by using the
controls on the car stereo.
When the last track on a disc has played, the unit will automatically
advance to and begin play of the next disc in the magazine. When
the last track on the last disc in the magazine has been played, the
unit will automatically return to the first disc and begin play again.
2
WIRED COMMANDER OPERATION
1 LIQUID CRYSTAL DISPLAY PANEL
The Liquid Crystal Display (LCD) panel will illuminate when the CD
changer is operating. The disc number, track number and elapsed time
or Disc ID name (if programmed) will appear as well as the function in use
as explained in the applicable function description in this section.
2 PLAY/PAUSE SELECTOR ( / )
Pressing this button turns on the CD changer, illuminates the display
panel and begins play of the first disc if a new magazine has been loaded
into the changer. If a magazine was already in the changer, play will
resume from the point on the track of the disc previously in play.
Pressing the button again will temporarily stop play of the disc and the
“PAUSE” indication will appear on the display panel. Press the button
again to resume play of the disc from the point at which it was stopped.
3 POWER OFF SWITCH (OFF)
Press this button to turn the CD changer off and return to normal FM radio
reception.
4 DISC SELECT(-DISC+)
This button is used to select the desired disc for play. To advance to a
higher number disc, press the “+” side of the button. To return to a lower
number disc, press the “-” side of the button. The number of the disc in
play will be shown on the display panel.
5 TRACK SELECT ( TRACK )
This button is used to quickly select the beginning of a particular track.
With each momentary tap of the Forward Track Select side of the button
( ), the next higher track number will be selected as shown on the
display panel. Similarly, with each momentary tap of the Backward Track
Select side of the button ( ), the next lower track number will be
selected.
6 CUE/REVIEW FUNCTIONS
High-speed audible search to any section of the disc can be made by the
Cue and Review functions. Press and hold the Cue side of the button
( ) to advance rapidly in the forward direction or the Review side of
the button ( ) to advance rapidly in the backward direction. During
either function, the elapsed time within each track will automatically be
shown on the display panel.
7 TRACK/DISC REPEAT (RPT)
When the Repeat button is pressed, the “RPT” indication will appear on
the display panel and play of the selected track will be continually
repeated until the Track Repeat mode is cancelled by pressing the
Repeat button again (“RPT” will disappear from the display panel).
When the Repeat button is pressed and held longer than 2 seconds, the
DISC and “RPT” indications will appear on the display panel and play of
the selected disc will be continually repeated. The Disc Repeat mode can
be cancelled by pressing the Repeat button again ( DISC and “RPT” will
disappear from the display panel).
When the Shuffle button
3
8 is pressed during Disc Repeat mode, the
