Audiovox PCD-5R User Manual
SEL
PWR
LOUD
CDC/
LUM
O
E
V
5
BAND
DISC
DISC
SEL
PCD-5
AUX
SCN
1
2
RPT
RPT
A-B
RDM
43
4x40 WATTS
PGM
5
1
5
PCD-5R
AM/FM/MPX RADIO
WITH
FOLD-DOWN DETACHABLE FRONT PANEL,
5-DISC COMPACT DISC PLAYER
AND QUARTZ CLOCK
REL
2
TUNE
3
AS/PS
TRK
4
MEM
6
T/F
CLR
OO
WNER'SWNER'S
O
WNER'S
OO
WNER'SWNER'S
Released: 10-15-01
Revision A: 4-20-02 --- Added Remote Control description and incorporated other minor changes
MAMA
MA
MAMA
NUALNUAL
NUAL
NUALNUAL
INDEX
Operating Instructions............................................................... 3 - 8
Notes On Use of Front Panel....................................................... 8
Setting the Clock ..........................................................................9
CD Player Error Codes .................................................................9
Specifications ..............................................................................10
Remote Control Unit ....................................................................10
Care and Maintenance ...............................................................11
Handling Compact Discs ............................................................11
CD-R Playback Capability...........................................................11
Warranty ......................................................................................12
Page
-2-
OPERA TING INSTRUCTIONS
3,4,5,6,7,8
17
34
31
13,14,15
1
SEL
PWR
LOUD
CDC/
LUM
O
E
DISC
V
5
DISC
SEL
PCD-5
BAND
2
9
26
AUX
27
1 POWER (PWR) BUTTON
Press this button to turn the unit on and off. When the ignition switch is
on, the radio will turn on automatically when the CDC, BAND or AUX
button is pressed.
2 VOLUME CONTROL
To increase the volume level, rotate the VOLUME control in the clockwise direction. The volume will increase and the level will be shown
on the display panel from a minimum of V -0 to a maximum of V -46
To decrease the volume level, rotate the control in the counterclockwise direction. The display will automatically return t o the normal indication 5 seconds after the last volume adjustment or when another
function is activated. This control is also used in conjunction with
the SEL/LOUD button to adjust the bass, treble, balance and fader
levels as described i n
4, 5, 6 and 7 .
3 SELECT (SEL)/LOUD BUTTON
This button is used to select the audio function (volume, bass, treble,
balance or fade) to be adjusted using the VOLUME control.
16,32 28,29
SCN
RPT
1
2
RPT
RDM
43
A-B
4x40 WATTS
PGM
5
10,18,19
1
2
TUNE
3
5
TRK
4
MEM
6
CLR
33
REL
AS/PS
T/F
11
30
20 21 22 232425
12
Pressing the Select button once will set the unit for volume a djustment (VOL will momentarily appear on the display panel, followed a
few seconds later by V -- and the setting number). Pressing the button
additional tim es will select bass adjustment (BAS o n display panel),
treble adjustment (TRE), balance (BAL), fader (FAD), and volume (VOL)
again. The display will return to the normal indication 5 seconds
after the last adjustment or when another function is activated. Refer to
paragraph
8 for the LOUD function of this button.
4 BASS CONTROL
To adjust the bass level, first select the Bass mode by pressing the
SEL/LOUD button until the BAS indication appears on the display panel.
Within 5 seconds of choosing the Bass mode, rotate the VOLUME
Control to adjust the bass response as desired. The bass level will be
shown on the display panel from a minimum of B -6 to a maximum
of B +6 (B 0 represents flat response). The display will automatically
return to the normal indication 5 seconds after the last adjustment
or when another function is activated.
-3-
5 TREBLE CONTROL
To adjust the treble level, first select the Treble mode by pressing the
SEL/LOUD button until the TRE indication appears on the display
panel. Within 5 seconds of choosing the Treble mode, rotate
the VOLUME control to adjust the treble response as desired. The
treble level will be shown on the display panel from a minimum of
T -6 to a maximum of T +6 (T 0 represents flat response). The display
will automatically return to the normal indication 5 seconds after
the last adjustment or when another function is activated.
6 LEFT/RIGHT BALANCE CONTROL
To adjust the left-right speaker balance, first select the Balance mode by
pressing the SEL/LOUD button until the BAL indication appears on the
display panel. Within 5 seconds of choosing the Balance mode, rotate
the VOLUME control clockwise to adjust it to the right channel speakers,
or counterclockwise to adjust it to the left channel speakers. The balance
position will be shown on the display panel from L 12 (full left) to R 12 (full
right). When the volume level between the left and right speakers is
equal, C 00 will be shown on the display panel. The display will automatically return to the normal indication 5 seconds after the last adjustment or when another function is activated.
7 FRONT/REAR F ADER CONTROL
To adjust the front-rear speaker balance, first select the Fader mode
by pressing the SEL/LOUD button until the FAD indication appears
on the display panel. Within 5 seconds of choosing the Fader mode,
rotate the VOLUME control clockwise or counterclockwise to adjust the
front-rear speaker levels as desired. The fader position will be shown
on the display panel from F 12 (full front) to R 12 (full rear). When the
volume level between the front and rear speakers is equal, C 00 will
appear on the display panel. The display will automatically return to the
normal indication 5 seconds after the last adjustment or when
another function is activated.
8 LOUDNESS CONTOUR (LOUD)
When listening to music at low volume levels, this feature will boost the
bass and treble ranges to compensate for the characteristics of
human hearing. Press and hold the SEL/LOUD button for at least 2
seconds to activate this f e atu r e as indica t ed b y LOUD on the display
panel. Pressing the button again for 2 seconds will de-ac tiv ate the
function and LOUD will disappear from the display.
9 AM/FM BAND SELECTOR
During radio play, each time the button is pressed, the radio band
changes. The indications AM
on the display panel according to your selection.
During CD play, pressing this button will change to radio operation
without ejecting the disc.
1, AM11, FM1, FM11, or FM111 will appear
bl UP/DOWN TUNING ( / )/CD TRACK (TRK) SELECTION
During radio operation, each time the Up TUNE button ( ) is
pressed, the radio will tune two frequency steps higher. Similarly, each
press of the Down TUNE button ( ) will tune two frequency steps
lower. Pressing either button for longer than 1 second and then releasing will activate the automatic seek tuning function, whereby the radio
will seek the next station in the selected direction and stop and remain
at that frequency.
Pressing and holding either button for longer than 1 second will cause
the radio to continue tuning rapidly in the selected direction until
the next available station and momentarily stop there. Tuning will continue unless the button is released at the desired station.
During CD player operation, these buttons are used to select a desired
track on the disc. (Refer to Track Select.)
bmAUTO-STORE TUNING (AS)
PRE-SET SCAN TUNING (PS)
Press this button momentarily to scan the 6 stations in the preset memories of the band in use. The unit will stop at each pre-set
station for 10 seconds before continuing to the next pre-set station (the
frequency on the display panel will flash during Pre-Set Scan operation). Press the button again momentarily to stop Pre-Set Scan operation and remain on the selected frequency.
Pressing the button for longer than 2 seconds will activate the Auto-Store
Tuning feature. The radio will automatically scan the band in use and enter
strong local stations into the pre-set memory positions for that band.
-4-
