P-955
AM/FM/MPX RADIO WITH FOLD-DOWN
DETACHABLE FRONT PANEL,
COMP ACT DISC PLAYER, CD CHANGER CONTROLS,
WIRELESS REMOTE CONTROL
AND QUARTZ CLOCK
OO
WNER'SWNER'S
O
WNER'S
OO
WNER'SWNER'S
MAMA
MA
MAMA
NUALNUAL
NUAL
NUALNUAL
INDEX
Operating Instructions ................................................................ 3 - 9
Setting the Clock ..........................................................................10
CD Player Error Codes.................................................................10
CD Changer Controls...................................................................11
CD Changer Error Codes.............................................................12
Wireless Remote Control Operation.............................................13
Specifications ...............................................................................15
Care and Maintenance .................................................................16
Warranty.......................................................................................17
Page
OPERATING INSTRUCTIONS
1 ON-OFF POWER BUTTON ( )
Pre ss this button to turn the unit on or off. If the ignition switch is
“on”, the unit will also turn on automatically when a compact disc is
inserted, or if the BAND switch or Mode switch (MOD) is
pressed.
2 AUDIO (LEVEL) CONTROL
T o increase the volume level, turn the knob clockwise (UP). The
volume will increase and the level will be shown on the display
panel from a minimum of 00 to a maximum of VOL 39. To
decrease the volume level, turn the knob counter-clockwise (DN).
The display will automatically return to the normal indication 5
seconds after the last volume adjustment or when another function
is activated. This control is also used in conjunction with the Push
Select Control button 3 to adjust the bass, treble, balance and
fader levels as described in 4, 5, 6 and 7.
3 PUSH SELECT CONTROL BUTTON
This button, which is integral to the AUDIO CONTROL, is used to
select the audio function (volume, bass, treble, balance, or fade)
whose setting is adjusted using the AUDIO CONTROL 2.
Pressing the PUSH SELECT control button once will set the unit
for bass adjustment (BAS will appear on the display panel) and
an audible beep will occur. Pressing the button additional times
will select treble adjustment (TRE on the display), balance (BAL),
or fader (FAD), each accompanied by a beep tone. The display
will automatically return to the normal indication 5 seconds after
the last adjustment or when another function is activated.
4 BASS CONTROL
To adjust the bass level, first select the Bass mode by pressing
the Select button 3 so the BAS indication appears on the display
panel.
-3-
Within 5 seconds of choosing the Bass mode, turn the AUDIO
CONTROL 2 counter-clockwise to decrease the bass response
or clockwise to increase it as desired. The level will be shown on
the display panel from a minimum BAS -12 to a maximum of
BAS +12 (BAS 00 indicates flat response). The display will
automatically return to the normal indication 5 seconds after the
last adjustment or when another function is activated.
5 TREBLE CONTROL
T o adjust the treble level, first select the T reble mode by pressing
the Select button 3 so the TRE indication appears on the display
panel. Within 5 seconds of choosing the Treble mode, turn the
AUDIO CONTROL 2 counter-clockwise to decrease the treble
response or clockwise to increase it as desired. The level will be
shown on the display panel from a minimum TRE -12 to a
maximum of TRE +12 (TRE 00 indicates flat response). The
display will automatically return to the normal indication 5 seconds
after the last adjustment or when another function is activated.
6 LEFT/RIGHT BALANCE CONTROL
To adjust the left-right speaker balance, first select the Balance
mode by pressing the Select button 3 so the BAL indication
appears on the display panel. Within 5 seconds of choosing the
Balance mode, turn the AUDIO CONTROL 2 counter-clockwise
to adjust the stereo balance to the left channel speakers or
clockwise to adjust it to the right channel speakers. The balance
position will be shown on the display panel from BAL L16 (full left)
to BAL R16 (full right). When the volume level between the left
and right speakers is equal, BAL 00 will be shown on the display
panel. The display will automatically return to the normal
indication 5 seconds after the last adjustment or when another
function is activated.
7 FRONT/REAR F ADER CONTROL
To adjust the front-rear speaker balance, first select the Fader
mode by pressing the Select button 3 so the FAD indication
appears on the display panel. Within 5 seconds of choosing the
Fader mode, turn the AUDIO CONTROL 2 counter-clockwise to
adjust the front-rear speaker balance to the rear speakers or
clockwise to adjust it to the front speakers. The fader position will
be shown on the display panel from FAD R16 (full rear) to FAD F16
(full front). When the level between the front and rear speakers
is equal, FAD 00 will be shown on the display panel. The display
will automatically return to the normal indication 5 seconds after
the last adjustment or when another function is activated.
8 LOUDNESS CONTOUR (LOUD)
When listening to music at low volume levels, this feature will
boost the bass and treble ranges to compensate for the
characteristics of human hearing. Press the LOUD button
momentarily to activate this feature and the indication LOUD will
appear on the display panel. Pressing the button again
momentarily will deactivate the feature (the LOUD indication will
disappear from the display panel).
9 AUDIO MUTE SELECTOR (MUTE)
Press the MUTE button momentarily to mute the volume from the
system (MUTE will appear flashing on the display panel).
Pressing the button again or adjusting the AUDIO CONTROL 2,
or pressing the equalizer (EQ) button or LOUD button, will return
to the volume level setting in use before the Mute function was
activated.
bl AM/FM BAND SELECTOR (BAND)
Each time this button is pressed, the radio band is changed. The
indication AM1, AM2, FM1, FM2 or FM3 will appear on the display
-4-
panel according to your selection. During disc play , pressing this
button will stop play of the disc and switch to radio operation
without ejecting the disc. During this time, the IN indication
will remain on the display panel to show that a disc is still loaded
in the unit. Press the MOD button to return to disc play from the
beginning of the last track in play .
When AM1 or AM2 is selected, the stereo (ST ) indication will
disappear from the display .
bm MANUAL UP/DOWN TUNING ( + / -) /
AUTOMA TIC SEEK TUNING (SEEK)
To manually select a radio station, momematrily press the Up
Tuning (+ ) side of the button to advance the unit two digits
higher or the Down Tuning ( -) side of the button to tune two
digits lower.
Pressing either side of the button for longer than 0.5 seconds
and then releasing will activate the Automatic Seek Tuning function.
The radio will seek the next station in the selected direction and
stop at that frequency. The Seek function can be stopped by
pressing the button again or activating any other tuning function.
Pressing and holding either side of the button for longer than 0.5
seconds will cause the radio to continue tuning rapidly in the
selected direction until the next available station and stop there.
bn LOCAL/DISTANT SELECTOR (LOC)
This feature is used to select the strength of the signals at which
the radio will stop during Automatic Seek Tuning. Pressing the
button will select the Local setting (LOC will appear on the display
panel) and only strong (local) stations will be received. Pressing
the button again will select the Distant setting (LOC will disappear
from the display panel) and the radio will stop at a wider range of
signals, including weaker (more distant) stations.
bo SUB-WOOFER SELECTION (SUB.W.)
The radio is equipped with a monaural audio output (in addition
to the low-level stereo outputs) which can be connected to
a remote power amplifier and associated sub-woofer speaker.
When the SUB.W. button is pressed, the indication appears
on the display and the sub-woofer audio signal is activated
and applied to the remote power amplifier, thereby enabling
the sub-woofer output.
bp PRE-SET SCAN (PS) / AUTO-STORE TUNING (AS)
Press this button momentarily to scan the stations pre-set into
each AM band and each FM band. The unit will stop at each
pre-set station for 5 seconds before continuing to the next pre-set
station (the pre-set number on the display panel will flash during
Pre-Set Scan operation). Press the button again momentarily to
stop Pre-Set Scan operation and remain on the selected
frequency . If no buttons are pressed during the scan, the unit will
return to the original station before the scan.
Pressing and holding the button for longer than 2 seconds will
activate the Auto-Store Tuning feature which will automatically
scan and enter up to 6 sta ti ons into the pre-set memories on the
band in use. If you have already set the pre-set memories to your
favorite stations, activating the Auto-Store Tuning feature will erase
those stations and enter the new ones. This feature is most
useful when travelling in a new area where you are not familiar
with the local stations.
bq STA TION PRE-SET MEMORIES
To set any of the 6 pre-set memories in each band, use the
following procedure:
1. Turn the radio on and select the desired band.
2. Select the first station to be pre-set using the Manual Up/
Down or Automatic Seek Tuning Controls bm.
-5-
3. Press the pre-set button to be set and continue to hold it in
for approximately 2 seconds. The pre-set number will appear
on the display panel and two beeps will sound, indicating that
the station is now set into that pre-set memory position. The
station can now be recalled at any time by pressing that button.
4. Repeat the above procedure for the remaining 5 pre-sets on
that band and for the other 4 bands on the unit.
br LIQUID CRYSTAL DISPLAY P ANEL
The Liquid Crystal Display (LCD) panel displays the frequency,
time, and activated functions.
NOTE: It is a characteristic of LCD panels that, if subjected to
cold temperatures for an extended period of time, they
may take longer to illuminate than under normal conditions.
In addition, the visibility of the numbers on the LCD may
slightly decrease. The LCD read-out will return to normal
when the temperature increases to a normal range.
bs FUNCTION DISPLAY
The Function Display consits of five bar graphs which provide a
visual representation of the volume level and the left and right
channel balance levels. The volume level is represented by three
thin bar graphs. As the volume is increased, the number of
illuminated segments will increase. The left and right channels
are represented by the wider bar graphs. As the strength of the
signal applied to either the left or right channel increases, the
number of illuminated segments will increase.
bt MODE SELECTOR (MOD)
This button is used to select the radio or the playback mode for
the CD player/changer. Each press of the button will select a
different mode as indicated on the display panel.
During integral CD player operation, this button may be used to
change to radio without ejecting the disc. The IN indication
will remain on the display panel to show that the disc is still
loaded in the unit. During remote CD changer operation, the
DISC number indication will remain on the display panel together
with the TRACK number being played, to show that the CD
changer is operating. Press the button again to return to radio
or integral CD player mode to resume play of the disc from the
point at which it was stopped.
bu DISC SLOT
With the front panel in the fold-down position, gently insert the
disc into the slot (label surface facing up) until the soft-loading
mechanism engages and pulls the disc in. The LOAD indication
will momentarily appear on the display panel followed by the total
playing time of the disc. The ( ) indication illuminates and
becomes animated, the IN symbol lights, and the track
number and elapsed time will appear on the display panel.
CAUTION: This unit is designed for play of standard 5"
(12cm) compact discs ONLY. Do not attempt to u se
3" (8cm) CD-Singles in this unit, either with or without
an adapter, as damage to the player and/or disc can
occur. Such damage will not be covered by the
Warranty on this product.
cl TRACK SELECT ( + / - )
During disc play the Track Select functions are used to quickly
access the beginning of a particular track. Each time the Forward
Track Select ( + ) side of the button is pressed, the next
higher track number will be selected as shown on the display
panel. Similarly, each time the Backward Track Select ( - )
side of the button is pressed, the next lower track number will be
selected as shown on the display panel.
-6-
cm CUE/REVIEW FUNCTIONS (+ / -)
During disc play, high-speed audible search to any section of
the disc can be made by the Cue and Review functions. Press
and hold the Cue (+ ) side of the button to advance rapidly in
the forward direction (the advancing disc playing time will be
shown on the display panel), or the Review ( -) side of the
button to advance rapidly in the backward direction (the
decreasing disc playing time will be shown on the display panel).
During either function, the elapsed time within each track will
automatically be shown on the display panel.
cn TRACK ONE POSITION (TOP)
During disc play, press this button to quickly return to the begining
of the first track on the disc. The disc counter will return to zero,
and TRACK number 01 will appear on the display panel.
co TRACK SCAN SELECTOR (SCN)
During disc play, press this button to play the first 10 seconds of
each track on the disc (SCAN will appear on the display panel).
When a desired track is reached, press the Scan button again to
cancel the function (SCAN will disappear from the display panel)
and play of the selected track will continue. Scan mode will also
be canceled by activating the Repeat Play cp, or Random Play
cq functions. During CD changer operation, when the SCN
button is pressed twice the DISC and SCAN indications will
appear on the display panel and the first 10 seconds of the first
track on each disc in the magazine will be played. When a
desired disc is reached, press the SCN button again and play of
the selected disc will continue (DISC and SCAN will disappear
from the display panel). The Disc Scan mode will also be canceled
by activating any other disc function ( Repeat Play, Random
Play, etc.).
cp REPEAT PLAY SELECTOR (RPT)
During disc play , press this button to repeat the play of the selected
track (RPT will appear on the display panel). Play of the track will
continue to repeat until the button is pressed again and the RPT
indication disappears from the display panel. Repeat Play mode
will also be canceled by activating the Track Scan co or Random
Play cq functions. During CD changer operation, when the RPT
button is pressed twice the DISC and RPT indications will appear
on the display panel and play of the selected disc will be continually
repeated until the Disc Repeat mode is canceled by pressing the
RPT button again or by activating the Scan co or Random Play
cq functions.
cq RANDOM PLA Y SELECTOR (RND)
During disc play , press this button to play the tracks on the disc
in a random shuffled order (RND will appear on the display panel).
In Random Play mode, the Track Select function cl will also select
tracks in the random order instead of the normal progression.
The Random Play mode can be canceled by pressing the button
again (RND indication will disappear from the display panel) or
by activating theRepeat Play cp or Track Scan co functions.
During CD changer operation, when the RND button is pressed
twice, the DISC and RND indications will appear on the display
panel and the discs in the magazine will be played in a random,
shuffled order, as well as the tracks on each disc. After playing a
track selected at random from a disc in the magazine, the unit
will select another disc at random and play a randomly selected
track on it. This will continue until the Random Disc mode is
canceled by pressing the RND button again or by activating the
Scan co or Repeat Play cp functions.
-7-
cr DISC SELECT UP/DOWN (CD+/CD-)
During CD changer operation, these buttons are used to select the
desired disc for play. To advance to a higher number disc, press the
CD+ button, and to return to a lower number disc, press the CD- button.
The number of the disc in play will be shown on the display panel.
cs DISC EJECT ( )
During CD player operation, disc play is stopped and the disc is ejected
when the front panel is folded down and this button on the rear of the
panel is pressed. Radio or CD changer operation will automatically
resume depending on which mode was in operation prior to disc play .
If the disc is not removed from the unit within approximately 15 seconds
of being ejected, it will automatically be re-loaded into the unit to prevent
it from being accidentally damaged ( IN will appear on the display
panel to indicate that a disc is loaded in the player). Play of the disc can
be resumed by using the Mode Selector bt to choose CD player function.
ct TIME/FREQUENCY SELECTOR (T/F)
During radio operation, press this button to call the time display on the
incorporated quartz clock. The display will return to the radio frequency
indication after 5 seconds.
During integral CD player operation, the first press of the button will call
the track elapsed time on the display panel. A second press will call the
time display . During CD changer operation the first press of the button
will call the time display . A second press will call the disc slot number
and track number in play . In either case, the display will return to the
disc indication after 5 seconds.
cu EQUALIZER BUTTON (EQ)
The EQ button applies preset sound effects to the unit’s audio
output signal. The EQ button, when pressed, will activate one of
three operating modes (ROCK, CLAS, or POP). When the
Equalizer function is active the bass and treble levels cannot be
changed. When the Equalizer function is not active, the unit returns
to the user set bass and treble levels.
dl THEFT-DETERRENT LED
Located on the chassis behind the front panel, a Light Emitting
Diode (LED) will flash when the panel is removed. The flashing
light serves as a visual warning to the would-be thief that the unit
has been disabled by removal of the front panel.
dm RESET BUTTON
A RESET button is also accessible behind the front panel and can be
used to activate the reset circuitry . However, this feature should only be
activated under the following circumstances as it will erase the time and
pre-set memories:
1. Upon initial installation after all wiring i s co mpleted.
2. If there is a malfunction of any of the switches, on the unit,
pressing the RESET button may clear the system and return
to normal operation.
dn REMOTE SENSOR
The sensor to detect the infrared signal from the wireless remote
control is located behind this lens. For optimum operation of the
remote control, always aim the control at this sensor.
do FRONT PANEL RELEASE BUTT ON (OPEN)
This button is used to release the mechanism that holds the front
panel to the chassis. To detach the front panel, press the button
so that the panel drops to the lowered position. Grasp the panel at
the middle and slide it off of the front mounting plate. After removing
the panel, push the metal plate back up to the vertical position.
-8-
NOTES ON USE OF FRONT PANEL
1. Make sure the front panel is oriented correctly when sliding it into the front mounting plate, as it cannot be attached when upside down. Use moderate pressure to fully seat the panel into position.
2. To verify correct panel installation, swing the panel assembly up into position until it locks easily into place. If any resistance is encountered, re-check panel orientation in chassis mounting plate.
3. When taking the front panel with you, please use the supplied carrying case to protect the panel from dirt and damage. Make
sure there is no dust or dirt on the electrical terminals on the back of the panel as this could cause intermittent operation
or other malfunctions.
THEFT-DETERRENT
LED (30)
CD SLOT (19)
MOUNTING
PLA TE GUIDE
(2 PLACES)
PANEL MOUNTING
PLATE
CD EJECT
BUTTON
(27)
-9-
FRONT PANEL
RESET BUTTON (31)
CD PLAYER ERROR CODES
If a problem should develop while operating the CD player, an error code (ER-1, ER-2, ER-3, etc.) may appear on the display
panel. This can indicate a number of problems with the unit, including a mechanical error or an error in the microprocessor
control of the player. If an error code should appear , try ejecting and re-loading the disc into the player . While the disc is out
of the unit, make sure it is clean, undamaged, and loaded correctly (label surface up). Y ou may also try activating the
RESET button dm on the unit, but this will also erase the time and pre-set memories.
SETTING THE CLOCK
1. Switch the vehicle ignition and radio “on”.
2. Press the Time/Frequency button to access the time display .
3. While holding the Time/Frequency button in, press the Down Tuning ( -) button to adjust the hours and AM/PM
indication or the Up Tuning (+ ) button to adjust the minutes to the correct time.
4. Five seconds after the last hour or minute adjustment is made, the time will be set in the unit and the display will return to
the normal indication.
-10-
CD CHANGER CONTROLS
Built into this radio are controls to operate an optional CD changer.
Please check with your Prestige/Audiovox car stereo specialist
or call 1-800-645-4994 for recommendations of the models that
will work with this radio.
Adjustment of the audio functions (volume, tone, balance, and
fader) for the CD changer operate in the same manner as they do
for radio play . The following controls will operate the CD changer
when it is installed and connected to this radio. Refer to the
owner’s manual included with the CD changer for instructions on
the installation and correct loading and use of the CD magazine.
dp CD CHANGER MODE SELECTOR (MOD)
During radio or CD play, press this button to select operation of
the CD changer as shown by CDC on the display panel. Disc
play will begin and the disc and track number will be shown on the
display panel. If a new magazine has been loaded into the changer,
play will begin from the first track of the first disc in the magazine.
If a magazine was already in the changer, play will resume from
the track on the disc previously in play .
dq & dr DISC SELECT (CD+ & CD-)
These buttons are used to select the desired disc for play. To
advance to a higher number disc, press the CD+ button dq. To
return to a lower number disc, press the CD- button dr. The
number of the disc in play will be shown on the display panel.
ds TRACK SELECT (+ / -)
The Track Select functions are used to quickly access the beginning
of a particular track. Each time the Forward Track Select (+ )
side of the button is pressed, the next higher track number will be
selected as shown on the display panel. Similarly , each time the
Backward Track Select ( -) side of the button is pressed, the
next lower track number will be selected as shown on the display
panel.
dt CUE/REVIEW FUNCTIONS (+ / -)
High-speed audible search to any section of the disc can be made
by the Cue and Review functions. Press and hold the Cue (+ )
side of the button to advance rapidly in the forward direction (the
disc play symbol will rotate foward on the display panel) or the
Review ( -) side of the button to advance rapidly in the backward
direction (the disc symbol will rotate backwards on the display
panel).
du TRACK/DISC SCAN SELECTOR (SCN)
When the SCN button is pressed, the SCAN indication will appear
on the display panel, and the first 10 seconds of each track on the
disc will be played in order. When a desired track is reached,
press the SCN button again and play of the selected track
willcontinue (SCN) will disappear from the display panel). The
Track Scan mode will also be canceled by activating the Repeat
or Random Play functions.
When the SCN button is pressed twice the DISC and SCN
indications will appear on the display panel and the first 10 seconds
of the first track on each disc in the magazine will be played.
When a desired disc is reached, press the SCN button again and
play of the selected disc will continue (DISC and SCN will disappear
from the display panel). The Disc Scan mode will also be canceled
by activating the Repeat Play or Random Play functions.
el DISC/TRACK REPEA T PLA Y (RPT)
When the RPT button is pressed, the RPT indication will appear on
the display panel and play of the selected track will be continually
repeated until the Track Repeat mode is canceled by pressing the
-11-
RPT button again or by activating the Scan du or Random Play
em functions.
When the Repeat button is pressed twice the DISC and RPT
indications will appear on the display panel and play of the selected
disc will be continually repeated until the Disc Repeat mode is
canceled by pressing the RPT button again or by activating the
Scan du or Random Play em functions.
em DISC/TRACK RANDOM PLAY (RND)
When the RND button is pressed, the RND indication will appear
on the display panel and the tracks on the disc will be played in a
random, shuffled order. The T rack Select button ds will also select
tracks in the shuffled order instead of the normal progression.
The Random Track mode can be canceled by pressing the RND
button again or by activating the Scan du or Repeat Play el
functions. When the RND button is pressed twice, the DISC
and RND indications will appear on the display panel and the
discs in the magazine will be played in a random, shuffled order,
as well as the tracks on each disc. After playing a track selected
at random from a disc in the magazine, the unit will select another
disc at random and play a randomly selected track on it. This will
continue until the Random Disc mode is canceled by pressing
the RND button again or by activating the Scan du or Repeat
Play el functions.
CD CHANGER ERROR CODES
If a problem should develop while operating the CD changer, the following error codes may appear on the display panel.
ER-1: Indicates that there is no magazine loaded in the CD changer.
ER-2: Indicates a problem with the magazine eject function.
ER-3: Indicates an error in the disc loading function.
ER-4: Indicates an error in the disc un-loading function.
ER-5: Indicates an error in the magazine position.
ER-6: Indicates an error in the laser pick-up position.
ER-7: Indicates an error in the laser focus on the disc.
In any of these error situations, try ejecting the CD magazine from the changer and make sure the discs are clean, undamaged,
and loaded correctly(refer to the Owner’s Manual of the CD changer). Re-load the magazine and check for proper operation. Y ou
may also try activating the RESET button dm on the unit, but this will also erase the time and pre-set memories.
If the suggested measures do not solve the problem, contact an approved warranty station near you for further assistance.
-12-
WIRELESS REMOTE CONTROL
OPERATION
The wireless remote control supplied with this model is capable of
operating most of the features of the unit from a remote location.
Each button on the remote control functions in the same way as
the referenced button on the main unit. For optimal operation of
the remote control, always aim it toward the Remote Sensor dn
on the front panel of the main unit.
1 ON-OFF POWER - See Main Unit 1
2 VOLUME (LEVEL) CONTROL- See Main Unit 2, 3 4,
5, 6, and 7 except + press to increase level, and
press - to decrease level
3 SELECT BUTTON (S) - See Main Unit 3, 4, 5, 6, and 7
4 AUDIO MUTE (MUTE) – See Main Unit 9
5 AM/FM BAND SELECTOR (BND) – See Main Unit bl
6 MANUAL UP/DOWN TUNING – See M a i n Unit bm except
press + to increase frequency , press - to decrease
frequency .
AUTOMA TIC SEEK TUNING – See Main Unit bm except
press + to Seek upward, press - to Seek downward.
CD TRACK SELECT – See Main Unit cl and ds except
press + to select a higher track number , press - to
select a lower track number.
CD CUE/REVIEW – See Main Unit cm and dt except press
+ for Cue function, and press - for Review function.
7 RADIO PRE-SET MEMORY 1-6 - See Main Unit bq
8 DISC UP SELECT (CD+) - See Main Unit cr
9 DISC DOWN SELECT (CD-) - See Main Unit cr
bl TRACK/DISC REPEA T (RPT) - See Main Unit cp and el
bm TRACK/DISC RANDOM (RND) - See Main Unit cq and em
bn TRACK/DISC TRACK ONE POSITION (TOP) - See Main
Unit cn
bo TRACK/DISC SCAN (SCN) - See Main Unit co and du
bp MODE SELECTOR (MOD) - See Main Unit bt and dp
bq AUDIO EQUALIZA TION BUTTON (EQ) - See Main Unit cu
br INFRARED SENDER - Emits infrared signal to radio which
is detected by the sensor dn
bs BATTERY COMPARTMENT - Holds two AAA batteries for
remote wireless control operation.
-13-
-14-
SPECIFICATIONS
Size: 7" W x 2" H x 6" D
Operating Voltage: 12 Volts DC, Negative Ground
Output Power: 160 Watts Maximum (40 W atts x 4 Channels)
Output Wiring: Floating-Ground Type Designed for use
Output Impedance: Compatible with 4-8 Ohm Speakers
Tuning Range: AM: 540 - 1,710 kHz
Sensitivity: AM: 15 uV
FM Stereo Separation: 30 dB
178mm x 50mm x 150mm
with 4 Speakers(Front and Rear Channels Cannot be
Combined (Bridged) for use with 2 Speakers)
FM: 88 - 108 MHz
FM: 2.5uV
*Specifications are subject to change without notice.
-15-
CARE AND MAINTENANCE
The radio section of your new sound system does not require any
maintenance. We recommend you keep this manual for
reference on the many features found in this unit as well as how
to set the clock.
The compact disc player section also requires no routine
maintenance, but proper understanding of its use and handling will
help you obtain maximum enjoyment of its capabilities. The
following points should be observed:
l When cleaning the interior of the vehicle, do not get water or
cleaning fluids on the unit.
l The CD player is a precision instrument and will not operate
properly in extreme hot or cold. In case of such conditions, wait
until the interior temperature of the vehicle reaches a normal
temperature before using the player.
l If the temperature inside the player gets too hot, a protective
circuit will automatically stop play of the disc. In this case, allow
the unit to cool off before operating the player again.
l Never insert anything other than a 5" (12 cm) compact disc into
the player as the mechanism can be damaged by foreign
objects.
l Do not attempt to use 3" (8 cm) CD-Single discs in this unit, either
with or without an adaptor, as damage to the player and/or disc
may occur. Such damage will not be covered by the Warranty
on this product.
l When not using the disc player, always remove the compact
disc.
l Do not attempt to open the unit chassis. There are no user
serviceable parts or adjustments inside.
l When the vehicle warms up during cold weather or under damp
conditions, moisture may condense on the lens of the disc player.
Should this occur, the player will not operate properly until the
moisture has evaporated.
l The unit is designed with a vibration dampening CD mechanism to
minimize interruption of disc play due to normal vibration in a
moving vehicle. When driving on very rough roads, however,
occasional sound skips may occur. This will not scratch or
damage the disc and normal play will resume when the rough
conditions cease.
HANDLING COMPACT DISCS
Dirt, dust, scratches, and warpage can cause skips in the playback
and deterioration of sound quality. Please follow these guidelines
to take care of your compact discs:
l Use only compact discs with the mark .
l Fingerprints, dust, and dirt should be carefully wiped off the
disc’s playing surface (shiny side) with a soft cloth. Wipe in a
straight motion from the inside to the outside of the disc.
l Never use chemicals such as record sprays, household cleaners
or thinner to clean compact discs. Such chemicals can
irreparably damage the disc’s surface.
l Discs should be kept in their storage cases when not in use.
l Do not expose discs to direct sunlight, high temperatures or high
humidity for extended periods.
l Do not stick paper, tape, or labels on the disc surfaces nor write
on them with any type of marker.
-16-
12 / 24 MONTH LIMITED W ARRANTY
Applies to automotive radios, radio/tape players, radio/CD players,
CD changers, power amplifiers, equalizers and accessories.
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under
normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will
be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty coverage (e.g. dated bill of
sale), specification of defect(s), transportation prepaid, to an approved warranty station or the Company at the address shown below.
The warranty period will be extended to 24 months from the date of original purchase if the product is installed by an authorized Prestige Audio dealer.
To claim warranty service during this extended period, the bill of sale must specify that the product was installed by an authorized Prestige Audio
dealer.
This Warranty does not extend to the elimination of externally generated static or noise, to correction of antenna problems, to costs incurred for
installation, removal or reinstallation of the product, or to damage to tapes, compact discs, speakers, accessories, or vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or been damaged through alteration,
improper installation, mishandling, misuse, neglect, accident, or by removal or defacement of the factory serial number/bar code label(s). THE
EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND,
IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY
WARRANTY HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30
MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. No person or
representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so
the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights and you may also have other rights which
vary from state to state.
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 l 1-800-645-4994
CANADA : CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA
-17-
128-5543
© 2000 Audiovox Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788 Printed in China
128-5799A
Loading...
