Audiovox FPE1087 User Manual

Operating Instructions

Model FPE1087

8” LCD TV/DVD Player

For assistance, please call: 1-800-645-4994
Or Visit us at

http://www.audiovox.com

128-7934

Thank you. . .

. . . for choosing this tablet DVD player. For your own safety and in order
to learn all about the functions available, please read this manual and
keep it for future reference.

Note:

An LCD panel and/or video monitor may be installed in a motor vehicle
and visible to the driver if the LCD panel or video monitor is used for
vehicle information, system control, rear or side observation or
navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play, the LCD panel or video monitor must be
installed so that these features will only function when the vehicle is in
“park” or when the vehicle’s parking brake is applied.

An LCD panel or video monitor used for television reception, video or
DVD play that operates when the vehicle is in gear or when the
parking brake is not applied must be installed to the rear of the driver’s
seat where it will not be visible, directly or indirectly, to the operator of
the motor vehicle.

Note:

This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorized by Macrovision Corporation
, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.

2

Table of Contents

A. Cautions and Warnings...........................................................................04

B.About This Manual............................................................................06

C.Desktop Base Installation............................................................................08

D. Mount the unit on the wall..........................................................................09

E.Prior to Operation.......................................................................10

F.Remote Control..........................................................................12

G.DVD Player...............................................................................13

H.Power Supplies ............... ..................................................................14

I.Connections.......................................................................................15

J.Receiving TV Programs.....................................................................16

K. Reading SD (Secure Digital) and MMC (Multimedia) Card ..... .16

L. Playing DVDs ................................. .17

M. DVD Menu ................................... .18

N. DVD Display .................................. .18

O.Playing Audio CDS.................................................................20

P.Playing MP3 Disc.......................................................................22

Q.Setup DVD...........................................................................................24

R.Setup TV...........................................................................................27

S.Specifications...........................................................................................33

3

A. Cautions and Warnings

All operation and maintenance instructions must be followed and warnings adhered
to.

• Do not expose the unit to excessive moisture.

• Do not place objects filled with liquids, such as vases, on the unit.

• Do not use the unit where there are temperature extremes (below 41°F, 5°C or
exceeding 95°F, 35°C).

• Adjust the volume to prevent damage to speakers.

• Sudden changes in the ambient temperature may cause condensation to form on
the optical lens inside the unit. If this happens, remove the disc, and allow about
2 hours to pass and then proceed with normal operation.

• To ensure proper ventilation and proper operation, never cover or block the
slots and openings with a cloth or other material.

• Keep the unit away from strong magnets, heating sources, sunlight, and
excessive dust.

• Never allow objects of any kind or liquids to be pushed/spilled into the unit
openings as they may come into contact with dangerous voltages.

• Unplug the unit from the wall outlet before cleaning. Do not use liquid or
aerosol cleaners.

• Do not use accessories not recommended in this manual as they may be
hazardous.

• Power cords should be routed so that they are not likely to be walked on or

pinched by items placed upon or against them. Pay particular attention to plugs
and the point from which the cord exits the unit.

• Do not attempt to service this product yourself as opening or removing

covers may expose you to dangerous voltage points or other hazards. Refer all
servicing to qualified service personnel.

4

• When replacement parts are required, be sure the service technician has used

replacement parts that are specified. Unauthorised substitutions may result in
fire, electric shock or other hazards.

• Upon completion of any service or repairs to the unit, ask the service techni-

cian to perform operational checks to determine that the product is operating
correctly.

Handling the LCD panel

Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break
and injury may occur.
If the LCD panel is broken, do not touch liquid in the panel.
Also, if the liquid gets in your eyes or touches your skin, consult with your doctor
after rinsing for at least 15 minutes or longer with clean water.

Contents

1. 1 x 8” LCD Monitor & DVD Player

2. 1 x RCA AV Cable

3. 1 x AC To DC Adapter

4. 1 x Vehicle DC Power Adapter

5. 1 x Remote Control

6. 1 x Base

5

B. About This Manual

The operations described mainly refers to the use of the remote control.

Buttons with same or similar marking on the main unit have the same function as
those on the remote control.
If the symbol

not supported by the media type inserted in the DVD player. The unit will play
the following:

Many Disc Formats are supported

occurs on the screen during operation, the function requested is

DVD-Video

CD-R DVD+R

CD-RW

CD Audio MP3

Photo CD DVD-RAM

DVD-RW CD-G

DVD-R HDCD

= YES = NO

Important Information

DVD+RW

DVD-ROM

Note: Usually the unit plays CD-R, CD-RW and MP3 discs. But due to the variety
of disc types, recording computers, operating systems and software for burning we
cannot guarantee that every CD-R, CD-RW or DVD is playable within this unit.

Please be aware of the following:

• This instruction manual explains the basic instruction of this unit.

• Some DVD discs have different functions that may not be explained in this
instruction manual. You may need extra instructions. In this case, please follow
the instructions

• The disc information takes priority in various settings.

displayed on the screen or jacket or case of the disc.

6

• In this manual, the language in the on-screen display is English. If you
change the language, please follow the selected language in the on-screen display.

• The screen shown as an example in this manual may be different from the
actual screen.

• On-screen displays subject to change without notice.

Note: The types of functions and operations that can be used for a particular
disc vary depending on the features of that disc. In some cases, these functions
and operations may differ from the descriptions given in this Owner’s Manual.
In this event, follow the instructions given on the screen and on the sleeve of the
disc.

Region Management Information

This DVD player is designed and manufactured to respond to
the region management information that is recorded on a DVD
disc. If the region number described on the DVD disc does not
correspond to the Region number of this DVD player, this
DVD player cannot play this disc. The region number for this
DVD player is ‘1’.

1

Please note that the program of a DVD may be divided into several ‘titles’ (e.g.
main movie, bonus material, interviews etc.). Each of these titles can be divided
into ‘chapters’. The program of audio CD’s is divided into “tracks”.

3

16: 9

2

3

CC

Multiple languages

Multi-aspect

LB

Multi-language subtitles

Multi-angle

Closed caption

7

C. Desktop Base Installation

Screw Hole

Unit Base

1. Place the tablet DVD player base on flat surface.

2. Align the thumb screw with the hole on the back of the DVD player.

3. Thread the thumb screw into the hole on the back of the DVD player and turn
the thumb screw clockwise to tighten the base to the DVD player.

4. While holding the DVD player and the base, adjust the unit’s swivel angle for a
comfortable viewing position.

8

D. Mount the unit on the wall

The unit can be easily be mounted on the wall. You will need an optional VESA75
Wall Mount Bracket. The VESA75 Wall Mount Bracket can be purchased at
most local electronic retailers. The rear of the unit contains four screw holes
(Refer to figure below). The VESA75 Wall Mount Bracket is attached to the back
of the unit with four screws (M4x6 or M4x8). Follow the instructions supplied
with the VESA75 Wall Mount Bracket to complete the installation.

Screw Holes

Screw Holes

9

E. Prior to Operation

Place in Position

For setting up the unit please choose a location with sufficient air circulation

to prevent overheating.

The product must be positioned horizontally only.
Do not place heavy objects on its housing.
To protect the laser unit avoid dusty surroundings. If necessary, please use a

cleaning disc carefully following its operating instructions.

Moisture Condensation

In some cases water may condense on the laser lens causing a
malfunction:

The unit was suddenly brought from a cold to a warm surrounding.

=> Please take out the disc and wait for about an hour,
until the unit has warmed up.

The unit was operated in a very humid surrounding.

=> Please choose a location with lower humidity.

Handling Disc’s

In order to keep the disc clean, never touch the shiny surface.
Never place a sticker or adhesive label on the disc.

Don’t expose discs to direct sunlight or other heat sources.
Please store the discs only in their sleeves.

7

10

Cleaning a Disc

To clean a disc use a soft cloth without any cleaning agents.
Only wipe from the center hole towards

never

the outer edge,

Using the Remote Control Handset

1. The remote control uses a pre-installed Li-ion type
battery. To prevent the battery from discharging, we’ve
inserted an insulating strip. Please pull it
out prior to first use.
If the remote control should begin to operate
unreliably replace the battery with a new battery of
the same type. To replace the battery open the battery
compartment. Push the retention clip in the direction of
arrow and pull out the battery mounting.

2. Before you remove the battery, remember the battery
position. The ‘+’ marking must face upwards, otherwise
the remote control will not work and may be damaged.
Replace the cover.

in toward the center.

3. Please point the remote control towards the main unit when operating the but­tons. Obstacles between the remote control and infrared sensor will adversely
affect operation of the remote control.

Batteries should disposed in an environmentally correct manner. Never

throw batteries into fire.

If the remote control is not to be used for an extended period of time, please

remove the battery from the compartment to prevent damage by battery
leakage.

When replacing the battery, please observe the polarity. The ‘+’ must face

upwards.

11

F. The Remote Control

1

POWER

2

AUDIO

3

REPEAT

4

SUBTITLE

5
6

REW

7

8

9

10

11

VOL

12
13

EPG

14

15

16

17

DVD TV AV

//

DISPLAY

-

CATV

EJECT

MENU

FF

SETUP

ENTER

VOL

+

AUTO

ATV DTV

--

/

CH

SKIP

18

19

20

21

22

23

24

25

26

27

1. DISPLAY

2.POWER

3.AUDIO

4.REPEAT

5.SUBTITLE

6.NEXT

7.PREVIOUS

8.PLAY/PAUSE

9.STOP

10.PICTURE

11.VOL+

12.VOL-

13.SKIP

14.EPG

15.CATV

16.DVD/SD-USB

17.DVD/TV/AV

18.EJECT

19.0-9

20.MENU

21.SETUP

22.ENTER

Provides the elapsed playing time, subtitle, audio
Turns the unit on or off
Toggles DVD audio language
Activates repeat mode
Toggles the subtitle languages available
Go to the next chapter, track or scene during play back
Go back to the previous chapter, track or scene during play back
Starts play or pauses the playback
Stops DVD playback
Slects the picture adjust setting
The Volume up
The Volume down
Skips channels that the user wishes not to view
The electronic programming guide displays the list of available channels
and the corresponding channel information (start time, end time, program
title, program description) in the digital mode.
Switch between the ATV AIR and ATV CABLE-STD/SRC/IRC
Selects signal from DVD or SD-USB
Selects signal from DVD,TV,AV.
Ejects the disc
Numeric Buttons
Brings up the DVD player¡¯s menu
Accesses the menus for basic setup
Navigation keys to operate the menu.Speeds up playback forwards or
backword by 2x,4x,8x,16x up to 32 times normal speed (DVD), Enter
confirms the selection

12

23. --

In the analog mode, Press -- Button to select the (-/--/---)mode,
then press number button to select the channel you liked. In the
digital mode, If you want to select 5-2 channel, you can
press 5,--,2 buttons in order.

24. AUTO

25. CH+

26. CH-

27. A TV/DTV

Search for channels automatically.
Selects next channel while in TV mode
Selects previous channel while in TV mode
Switch between the DTV and ATV.

G. DVD Player

22
21

20
19

USB

18

17

16

+

PROG

123 4567

14

15

8 9 10 11

12

13

1. Power Button

2. Program Button

3. Channel +/- Button

4. Volume +/- Button

5. Picture Button

6. TV/AV/DVD Button

7. DTV/ATV Button

8.Previous Button

9. Play/Pause Button

10. Next Button

11. Stop Button

12. Eject Button

13. Disk Slot

14. Power Indicated LED

15. IR Remote Sensor

16. SD Slot

17. Cable Antenna Connector

18. USB Jack

19. DC 12V Input Jack

20. AV In/Out Switch
21 Audio Right Jack

22. Audio Left Jack

23. Video Jack

24. Headphone Jack

13

H. Power Supplies

a. Using AC adaptor
Connect the supplied AC adaptor.

INPUT: AC 100 ~ 240V, 50/60Hz, 0.4A
OUTPUT: DC 12V, 1.7A

b

• Use this unit only the supplied AC adaptor.
Use with other AC adaptors may damage the unit.

• Do not touch the AC adaptor with wet hands. Doing so is dangerous, as this
could result in an electric shock.

• Do not use with a voltage other than the voltage displayed. Improper voltage
could cause fire, electrical shock, or damage.

b. Using cigarette lighter adaptor
Connect the supplied DC power
adaptor to vehicle power outlet.

Caution on the cigarette lighter adaptor:

• Use only the supplied DC power adaptor. Using other DC power adaptors
could damage the unit.

• After use, disconnect the cigarette lighter adaptor plugs from both this unit and
the vehicle power socket.

• The DC power adaptor may cause interference with reception from the car
radio or another radio inside the vehicle. If this is the case, disconnect the
DC power adaptor from the vehicle power socket, or use the radio located at a
further distance from the vehicle power socket.

Traffic safety:

• Do not use while operating a motorized vehicle. It may create a traffic hazard
and is illegal in many areas.

Vehicle DC Power Adapter

INPUT: DC 12-14V
OUTPUT: DC 12-14V

a

14

After connecting the unit to power,

picture will appear on the screen and the LED power indicator located on lower
left front of the unit will be light.

press “POWER” button, and the logo

I. Connections

Although this unit has its own screen, you can connect it to an external
television set as well.

1. Playing a Video Game

1) Slide the AV in/out switch
to the “In” position.

2) Plug the AV output from your
game system into the Audio L+ R
and video input jack on the left side of
the unit with corresponding color:
(Audio Left= White, Audio Right= Red,Video=yellow).

3)Press “DVD/TV/AV” until the word “AV”
appears on the top right; Adjust the volume
control and the brightness control on the top
of the unit to your individual preference.

2. Connecting to a TV or another monitor

You can also connect the DVD
player to a TV or monitor to
enjoy high quality stereo.

AV

• Slide the AV in/out switch to the”Out” position

• Insert each cable firmly into its designated jack.

• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep

the twin lead cables away from audio/video cables.

15

1) Connect the supplied AV (RCA) cables into the Audio L+ R
and video jack on the left side of the unit following the corresponding colors:
(AudioLeft= White, Audio Right= Red, Video=yellow).

2) Connect the supplied AV cables on the other end to your TV. Match the cable
by color code.

J. Receiving TV Programs

1. Connect the Exteral antenna to the Cable Antenna
Connector on the left side of the unit.

2.Press “TV/AV/DVD” until the word “TV”
appears on the top right.

2. Press “AUTO”, the unit will search TV channels
automatically.

3. Press DTV/ATV button to select the mode what you want.

4. Press “AUTO”in remote control or “Program” on the unit,the unit will search TV
channels automatically.

5. After the channels are searched, you can use CH
to choose the channel you like.
Note:
a. The picture and audio are not visible when searching channels.
b. If you don’t like a channel, press “SKIP SEARCH”. The channel will not appear
when you press “CH

or ”.

or

K. Reading SD (Secure Digital) and MMC
(Multimedia) Card/MS

You can enjoy high-quality pictures , music and cinema stored in an SD card.
Note:
The maximum card size is 2GB.

1. Press “TV/AV/DVD” until the word “DVD” appears on the top right.

2. Insert the SD card (with the label side faced to you) into the SD slot on the left
side of the unit and the unit will read it automatically.

3. Press “DVD/SD-USB” button to switch between SD screen and DVD screen.

4. Press the

5. Then pull out the SD card for exit .

and button to switch between Music and Photo.

16

L. Playing DVDs

DVD Playback

1. Press “TV/AV/DVD” until the word “DVD” appears on the top right of the screen.;

2. Insert the disk in the right side of the unit with label

facing to you. Then the disk will be pulled into the unit
and play will begin automatically.

DVD discs will usually show a menu to choose from. Use the navigation buttons

on the remote control.

Highlight the desired menu item and press the ENTER button to activate it. This
starts the playback of the selected item.

//

DVD TV AV

DISPLAY

EJECT

To stop playback press the STOP button once. The
screen shows “Press Play key to continue”. The player will
recall the location where playback was stopped.
Press the PLAY button to resume playback there. But if
you press the STOP button again the unit will stop

NOTE

and not recall the last position of playback.
The “resume play” is not supported by all discs.

POWER

AUDIO

REPEAT

SUBTITLE

REW

MENU

FF

SETUP

ENTER

-

+

VOL

VOL

--

SKIP

EPG

AUTO

/

ATV DTV

CATV

CH

If this symbol appears on the screen during operation, the function

requested is not supported by the media type inserted.

//

DVD TV AV

DISPLAY

POWER

EJECT

NOTE

AUDIO

REPEAT

SUBTITLE

REW

MENU

FF

SETUP

ENTER

-

VOL

VOL

+

--

SKIP

EPG

AUTO

/

ATV DTV

CATV

CH

PICTURE ADJUSTMENT

Picture: Cycle through picture adjustments

Brightness, Contrast, Tint, Color, Sharpness

and Recall.
Vol - : Decrease picture adjustment
Vol + : Increase picture adjustment
NOTE: Button located on Remote and top of unit

17

M. Menu

A DVD is divided into sections called titles and chapters. When you play a
DVD, a root menu of the disc will appear on the screen of your TV or
Monitor. The contents of the menu vary from disc to disc. Press MENU
during playback to display the menu. Some DVDs only allow you to select
disc playback options using the DVD root menu.

N. Display

1. PLAYING TIME AND REMAINING TIME
During playback press the ‘DISPLAY’ button to display the

following:

Title, Chapter Number, and Time Screen Display

Title Elapsed: The elapsed time of the title
Title Remain: The remaining time of the title
Chapter Elapsed: The elapsed time of the chapter
Chapter Remain: The remaining time of the chapter
Display Off: The DVD’s time Information will not be displayed.

Title Elapsed

Display Off

Title Remain

Chapter Remain

18

Chapter Elapsed

2. SUBTITLE

During disc playback press ‘SUBTITLE’ to select the subtitle language you de­sire*, with the current Subtitle Language Number (1) and the total Number of
Subtitle Languages (2) displayed. If there are multiple languages press ‘SUB­TITLE’ again to select another subtitle language. To turn subtitles OFF, press the
‘SUBTITLE’ button until ‘Subtitle Off’ is displayed. The Subtitle display will
disappear automatically if the ‘SUBTITLE’ button is not pressed again within 3
seconds.

Subtitle Screen Display

* Some DVDs only allow access to this function through the DVD menu

3. AUDIO

During playback press ‘AUDIO’ to select the audio language you desire*, with the
current Audio Channel Number (1) and the total number of Audio Channels (2)
displayed. Press AUDIO again to select another audio language. The audio display
will disappear automatically if the ‘AUDIO’ button is not pressed within for 3
seconds.

Audio Language Screen Display

* Some DVDs only allow access to this function through the DVD menu.

19

4. REPEAT

DVD Repeat Mode

During playback each time ‘ REPEAT’ is pressed, the following modes will be­come available.

Chapter: Repeat the current chapter
Title: Repeat the current title
All: Repeat all chapters and titles
Off: Resume normal playback

The ‘Chapter’ repeat display shows below for example:

Chapter Repeat Screen Display

Chapter

Off

DVD Repeat Mode

Title

All

O. Playing Audio CDs

When playing an audio CD press the DISPLAY button repeatedly on the remote
to view time information. The options below appear on screen display circularly
to show you what information is available using this function.

Single Elapsed

Single Remain

Total Elapsed

CD Display Mode

Single Elapsed: The current track playing and playing time of that
track will display on the screen.
Single Remain: The current track playing and the amount of time
left.

Display Off

Total Remain

20

Total Elapsed: The current track playing and the total time that the
CD has been playing.
Total Remain: The current track playing and the amount of time
remaining on the CD.
Display Off: The CD time Information will not be displayed.

Take ‘Single Elapsed’ display as a example:

Single Elapsed Screen Display

USING THE REPEAT FEATURE

The default mode for the Repeat feature is OFF. Pressing 1/ALL REPEAT con­secutively changes the repeat options:

•

•

•
As you toggle through the options, the repeat option changes. The selected repeat
option loops repeatedly until you turn it off.

Track

- repeats the track that is playing.

All

- repeats the disc that is playing.

Off

21

P. Playing MP3 Discs

MP3 is a format for storing digital audio. An audio CD-quality song is compressed
into the MP3 format with very little loss of audio quality (192Kbps min) while
taking up much less disc space. CD-R /RW discs that have been encoded in MP3
format are compatible with this system.

MP3 MENU Screen Display

When an MP3 disc is inserted into the unit, the menu screen appears automatically.
You can use the menu screen to select your desired folders and songs or the system
plays the songs in the order they were burned onto the disc.

1. Press the or button to choose a folder from the folder list on the left side of
the screen.

2. Press ENTER to select the highlighted folder. The songs available under the
folder will be listed.

3. Use or button to choose a song from the list. Press ENTER to select and
begin playback of the highlighted song.

22

4. Use the ( NEXT ) button to move to the next song. Press the
(PREVIOUS) button to move to the beginning of the previous

song.

USING THE REPEAT FEATURE
The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively
changes the repeat options:

• Repeat One (repeat playback of a song)

• Repeat Folder (repeat playback of a specific folder)

• Repeat Off (normal playback)

As you toggle through the options, the repeat mode changes. The selected repeat
mode loops repeatedly until you turn it off.

NOTICE

“ ” icon in front of a file name indicates that this is a folder, not an

MP3 file.

“MP3” icon in front of a file name indicates that this is an MP3 file.

Note:

Due to the company’s policy of constant improvement and technical refinement,
the company reserves the right to change or alter software.

23

Q. Setup DVD

1. General Setup Page

1)With no disc inside the player, press ‘SETUP’ to display the Main screen of
the Setup Menu. The “General Setup Page” will also appear. At the same time,
“General Setup” is highlighted. Press ‘SETUP’ again to exit the Setup Menu.

2)Press the ENTER button, “TV Display” is highlighted.

3) Press the or button to select the other menus in general setup page.

4) Press  to enter the sub menu.

5) Press the or button to select the sub menu and press the ENTER to
confirm your selection.

6) Repeat steps 3-5 for other menus.
Note: Press  to return the previous menu.

a) TV Display

* Normal/PS: When the player outputs signal to a normal TV, a normal

picture is shown on the full screen.

* Normal/LB: When the player outputs signal to a normal TV, a normal

picture is shown on the screen with a black strip at both the top and
bottom of the screen.

* Wide: When the player outputs signal to a wide screen TV, a wide picture

is shown on the full screen.

b) Angle Mark

* On: The screen will show the angle mark icon. (*If an angle option is

available).

* Off: The screen will not display the Angle Mark
NOTE: Not all discs contain above features. The above features are disc

dependent.

24

c) Screen Saver

*On: Enables screen saver
*NOTE: The DVD player will enter the Screen Saver mode after approxi­mately five minutes if the same image remains on the screen.*Off: Disables
screen saver (off)

d) Last Memory

*On: The unit will return to the last position on the disc.
*Off: The unit will not return to the last position on the disc.

2. Password

In Setup menu, Press the  or button to select “Password Setup
Page” and
Press ENTER twice to enter the Password Change Page. Input the Old Pass-

word or the Default Password, the New Password, and Confirmed the New
Password. Press ENTER to confirm the change.
Note: The default password is 3308.

is highlighted. Press ENTER to enter the password page.

25

4. Preference Page

1) In Setup menu, Press the  or  button to select “Preference Page”and

is highlighted. Press ENTER to enter the preference page.

2) Press the ENTER button, “Audio” is highlighted.

3) Press the or

4) Press  to enter the sub menu.

5) Press the or button to select the sub menu and press the ENTER to
confirm your selection.

6) Repeat steps 3-5 for other menus.
Note: Press  to return the previous menu.

a) Audio
b) Subtitle
c) Disc Menu
Note: Language and subtitle selection is only available for discs that are recorded

in the above listed languages. If the selected language is not available, the player
will play and display on the screen the original recorded language contained in
the disc.

d) Parental

Select ‘Parental’ using the
Select the parental level you desire using
out function or multiple rating levels. These are listed from the lowest level (1 Kid
Safe) to the highest level (8 Adult). Press ENTER and input 4 digit password, then
press ENTER again to confirm the parental level setting.

NOTE: The level of 8 Adult is the factory default.
e) Default

Select ‘Default’ using the and button, then press to enter the submenu.
Press ENTER to make the setting return to the factoryset mode.

NOTE: The parental setting is not affected by the default reset function.
NOTE: The Default Password is

after you have selected your own password and changed it. To avoid the possi­bility of others using the default password to set the parental level and change the
password, you can record this default password in another area and delete it from
this manual. Some discs can be limited depending on the age of users while some
discs cannot.

button to select the other menus in preference page.

and button, then press to enter the submenu.

and the button for discs with lock-

3308

. This password is always effective even

26

R.Setup TV

Power on the TV and press the menu button to display the setup menu.
The menu will automatically disappear after being inactive for ten seconds. Press
menu button to exit setup menu.

Screen Format

Using Up/Down button to select the Screen Format item and press
Enter button to select Auto mode and 16:9 mode

Time

Using the Up/Down button to select the Time item and press Enter
to access Time menu.

MENU

Time zone: Press enter button select from Hawaii, Atlantic,
Eastern, Central, Mountain, Pacific, Alaska.
Sleep: Press enter button to choose the 10minutes, 20 minutes,
30minutes, 60 minutes, 120 minutes and off selction.
For example: When you select the 10 minutes, the TV will automatically

power off after 10 minutes.

Note: Press left button once to return to the setup menu, twice

to exit setup menu.

27

Closed Caption

Using the Up/Down button to select the Closed Caption item and press
Enter to access Closed Caption.

Caption: You can select the Caption ON/OFF/ON MUTE for the TV
Program.

Note: The Caption Function is helpful for those people with hearing difficulties.

Mode: Displays the menu in an analog or digital manner.

MENU

MENU

28

Options: Option inclulde (font size, font style, fore color, back

color, fore opacity, back opacity). Press the Up/Down

button to select the option, then press Enter button
to access the option.

MENU

.. .

Fore Color Red

.. .

Back Color Red

. ..

Back O pacity Translucent

Note: Press button once to return to the setup menu, twice

to exit setup menu.

V-Chip

Using the Up/Down button to select the V-Chip item and press Enter
to access V-Chip. Then input the 0000 password to Enter the V-Chip
lock Menu. (The default password is 0000).

MENU

- .. .

VChipLock On
Parent Guide
MPAA Rating

Change PIN

MENU

V-Chip Lock

You can press button to selcet the V-Chip Lock ON or OFF.

29

Parent Guide

Press the button to enter the Parent Guider Menu. You can lock
the TV Program in this menu. Press the Left/Right /Up/Down button to
select the rating that you want to lock or unlock and press Enter to
comfirm.

MENU

ALL FV D L S V

TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA

ALL
FV
D
L
S
V

All children
Directed to older children
General audience
Parental guidance suggested
Parents strongly cautioned
Mature audience only

All Content
Fantasy Violence
Sexually Suggestive Dialog
Adult Language
Sexual Situation
Violence

30

MPAA Rating

Press the button to enter the MPAA Rating Menu. You can lock the movie
Program in this menu. Press the Up/Down button to select the rating that you
want to lock or unlock and press Enter to comfirm.

MENU

G
PG
Pg13
R
Nc17
X
NR

G
PG
PG-13
R
NC17
X
NR

General audience
Parental guidance suggested
Parents strongly cautioned
Restricted
No one 17 and under admitted
Adult audience only
Not available

Canadian Ratings

You can use the button to select the Lock rating in
Canadian English as below:

C
C8+
G
PG
14+
18+
NA

Children
Children over 8 years
General
Parental Guidance
Over 14 year
Adults
Not Available

31

Canadian Ratings

You can use the button to select the Lock rating according to Canadian
standards as shown below:

G

General
8ANS+
13ANS+
16ANS+
18ANS+
NA

General but inadvisable for young children

Over 13 years

Over 16 years

Over 18 years

Not Available

Change PIN

Enter the old (or default) password, then enter the new password in the spaces
provided.The default password is 0000.

Note: Press left button once to return to the setup menu, twice to

exit setup menu.

Transparent

Using the Up/Down button to select the Transparent item and press
Enter button to select between on/off selection. The menu display will
change between the transparent and opaque.

32

P. Specifications:
TV Reception

TV System NTSC M/ATSC
Channel CATV - UHF/VHF 181 channels
Antenna Impedance 75ohm
Connector type F

Audio

Maximum Audio Output 1.5watt x 2
Total number of speakers 2

Video Connections Quantity

NTSC Analog TV Tuner 1
Composite Video Input 1 (Input/Output

switchable)
Composite Video Output 1 (Input/Output
Not Available for Internal DVD switchable)

Video Standards Supported

Composite Video input NTSC
RF NTSC

Audio Connections Quantity

RCA Input(Red, White) 1
Headphone:(Variable/Fixed) (3.5mm) 1 (Variable)

33

Playback Media Compatibility

Audio CD YES
CD-R YES
CD-RW YES
DVD-R YES
DVD-RW YES
DVD-Video YES
Picture CD YES
VCD N O
SVCD N O
SD/MMC/MS YES (2GB)

Playable Format (Codec)

MP3 (@ 32 - 320Kbps, 44kHz)
CD-DA YES
VCD 1.1 N O
VCD 2.0 N O
JPG NO

Features

Built-in DVD Player
Removable stand
12VDC input for car use
User friendly remote and On Screen Display (OSD)
Built-in Secure Digital (SD) and Multi-Media Card (MMC)/MS
MP3 playback on Disc and SD/MMC/MS
Photo Show on Disc and SD/MMC/MS
Receive the DTV/ATV

Accessories in the box

8" LCD/DVD unit
1x RCA AV Cable
1x AC/DC Adapter
1x 12V Car Adapter
1x Remote Control
1x Owner’s Manual

34

Power Requirements

Power Source 100-240 VAC 50/60Hz

Unit input power 12VDC 1.7A
Power ON consumption 12 W

Dimension (WxHxD)

Unit W/stand 10.63 x 8.31 x 6.38 (in)

Unit W/O stand 10.63 x 7.05 x 2.77(in)

Weight (N.W.)

Unit W/stand 3.88(lb)

Unit W/O Stand 3.31 (lb)

Warranty

Parts & Labor 90 day

Environment

Operating Temperature 41 - 95°F

Operating Humidity 30% - 80%

*Designs and specifications are subject to change without notice.

W aste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.

35

© 2007 Audiovox Electronics Corporation

128-7934
