Audiovox FP1210 User Manual

FP1210 User Manual

1286475

TABLE OF CONTENTS

General Information ………………………………………………...2

Important Safety Instructions …………………………………..2

Federal Communication Commission Information (FCC) ……….6

Getting Started

Package Contents ...........................................................................7

Connection .......................................................................................8

Operation

Front Control Panel ...........................................................................11

Remote Control …………………………………………………..….12

Power Management System ……………………………………...14

Technical Information

Specifications ……………………………………………………….15

Troubleshooting ……………………………………………………..16

General Information

Thank you for purchasing this 12.1" flat-screen TFT LCD monitor. It is designed to meet the screen performance requirements of today's demanding business applications. It delivers a larger display area, higher resolutions and greater color accuracy.

The On Screen Display (OSD) microprocessor user control system enhances and expands your ability to control your display. The microprocessor-based memory stores your preferred screen settings. Digital controls positioned on the front of the screen are easier to reach and use and greatly improve your capabilities to adjust the screen settings.

The tilt base allows you to adjust the monitor to your preferred angle of vision.

Important Safety Instructions

Ø Read Instructions -- All the safety and operating instructions should be

read before the product is operated.

Ø Retain Instructions – The safety and operating instructions should be

retained for future references.

Ø Heed Warnings – All Warnings on the product and in the operation

instructions should be adhered to.

Ø Follow Instructions – All Operating and user instructions should be

followed.

Ø Cleaning – Unplug this product from the wall outlet before cleaning. DO

NOT use liquid cleaners or aerosol cleaners. Use damp Cloth for cleaning.

Ø Attachments – DO NOT use attachments not recommended by the

product manufacturer they may cause hazards.

Ø Mounting – DO NOT place this product on an unstable cart, stand, tripod,

bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product. Any mounting of this product should follow the manufacture’s instructions, and should use a mounting accessory recommended by the manufacturer.

Ø Heat – The Product should be situated away from heat source such as

radiators, heat registers, stoves or other products (including amplifiers) that produce heat.

Important Safety Instructions (continued)

Ø Water – DO NOT use this product near water. For example: Avoid placing

it near bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, ETC…

Ø Cabinet Slots – NEVER push objects or any kind into the unit through the

cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. NEVER spill liquid of any kind on the product.

Ø Ventilation – DO NOT block any ventilation openings. Install in

accordance with manufacture’s instructions. Slots and openings in the cabinet and the back and bottom are provided for ventilation, and to ensure reliable operation of the product and to protect it from Overheating. These openings must NOT be blocked or covered. There should be at least 10cm of space from these openings. The openings should never be blocked by placing the unit on a bed, rug o r other similar surface. This product should NOT be placed in a built-in installation such as a bookcase unless proper ventilation is provided.

Ø Grounding or Polarization – This product may be equipped with a

polarized alternating current line plug (a plug having one blade wider then the other). This plug will fit the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. DO NOT defeat the safety purpose of the polarized plug.

Ø Power – Cord Protection – Power supply cords should be routed so that

they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

Ø Power Sources – This product should be operated only from the type of

power source indicated on the rear panel. If you are not sure of the type of power supply to your home consult your product dealer or local power company.

Ø Lightning – For added protection for this product during a lightning storm,

or when it is left unattended and unused for a long period of time, unplug it from the outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

Ø Power Lines – An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Ø Overload – DO NOT overload wall outlets, extension cords or integral

convenience receptacles as this can result in a risk of fire or electric shock.

Important Safety Instructions (continued)

Ø Damages Requiring Service – Unplug this product from the wall outlet

and refer servicing to qualified service personnel under the following conditions.

Ø When the power-supply cord or plug is damaged. Ø If liquid has been spilled, or objects have fallen into the product. Ø If the product has been exposed to rain or water. Ø If the product does not operate normally after following the operating

instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

Ø If the product has been dropped or damaged in any way. Ø When the product exhibits a distinct change in performance – this

Ø Replacement parts – When replacement parts are required, be sure the

Ø Safety Check – Upon completion of any service or repair to this product,

Ø Important Information Regarding Use of Video Games, Computer,

Ø Recycling – This product utilizes tin-lead solder, and has a

indicates a need for service.

service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. UNAUTHORIZED substitution may result in fire, electric shock or other hazards.

ask the service technician to perform safety checks to determine that the product is in proper operating condition.

Captions or other Fixed Image Displays. Ø The Extended use of a fixed image program material can cause

permanent “Shadow Image” on the LCD Panel. The Background image is viewable on normal programs in the form of stationary fixed image. This type of irreversible LCD panel deterioration can be limited by observing the following steps: Ø Reduce the brightness/contrast setting to a minimum viewing

level.

Ø DO NOT display the fixed image for extended periods of time. Ø Turn the power off when not in actual use.

fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information please contact you local authorities, or the Electronics Industries Alliance: http://www.eiae.org/

Important Safety Instructions (continued)

The Lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “DANGEROUS VOLTAGE” within the product’s enclosure that may be of sufficient magnitude to constitute a risk or electric shock to persons.

The Exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing instructions in the literature accompanying the product).
