2 DPF710K
Important Safety Instructions
Please read all safety and operating instructions carefully before installation, and keep these instructions handy for future reference. Take special note of all warnings listed in these instructions and on the unit.
1. Water and Moisture: The unit should not be used near water. For example: near a bathtub, swimming pool, etc.
2. Ventilation: The unit should be situated so that its location or position does not interfere with its proper ventila-
tion.
3. Heat: The unit should be situated away from heat sources such as radiators, heat registers, stoves, or other
appliances (including amplifiers) that produce heat.
4. Power Source: The unit should be connected to a power supply only of the type described in the operating
instructions or as marked on the appliance.
5. Power Cord Protection: Power cords should be routed so that they are not likely to be walked on or pinched by
items placed up or against them. It always best to have a clear area from where the cord exits the unit to where it is plugged into an AC outlet.
6. Cleaning: The unit should be cleaned as needed with a soft, non-abrasive cloth.
7. Object and Liquid Entry: Care should be taken so that objects do not fall and liquids are not spilled into any
openings or vents located on the product.
8. Attachments: Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection: Disconnect the unit from AC power during any electrical storm in the
immediate vacinity. This will prevent damage to the product due to lightning and power-line surges.
10. Overloading: Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
resulting in a risk of fire or electric shock.
11. Damage Requiring Service: This unit should be serviced by qualified service personnel when:
a. The power supply cord or plug has been damaged. b. Objects have fallen into or liquid has been spilled in the product enclosure. c. The unit has been exposed to rain. d. The unit has been dropped or the enclosure damaged. e. The unit exhibits a marked change in performance or does not operate normally.
12. Servicing: The user should not attempt to service the unit beyond those methods described in the User's
Manual. Service methods not covered in the operating instructions should be referred to qualified service personnel.
DPF710K 3
Your homebase allows you to:
Display your digital photos from its internal memory, a memory card, or USB memory devices
Record and retrieve audio messages
Use the calendar to set audio and/or event reminders
Display time and date
Use a timer, set an alarm
Leave a written message on the front of the unit or the Post-it®pad.
Introduction
4 DPF710K
Overall Description :
• 7-inch color LCD displays photos, calendar and clock
• 512 MB of memory-enough for more than 100 pictures depending on image size
• Internal microphone for recording digital voice messages
• Internal speakers with volume control
• Magnetic border for posting notes, coupons, etc.
• LED indicator lights when there's a message
• Erasable white board and dry erase marker for quick notes and messages
Product Features
• Post-it
®
notes for lists and reminders
• 3-key navigation for simple operation
• Multiple mounting options: refrigerator, wall and countertop.
• Supports SD/MMC, MS, xD, and CF memory cards and USB flash drives
• Interactive Calendar and Digital Clock
• Digital clock with alarm
• Countdown timer
DPF710K 5
What’s in the Box?
homebase
AC to DC Power Adapter (1)
Dry Erase Marker (1)
Wall Mount Bracket (1)
Adhesive Foam Pad (2)
Plastic Wall Anchor (2)
Angle Mount Bracket (2)
Post-It®Note Pad (1)
Button Magnet (2)
Wire Management System (3)
(Black, White, Clear)
Flat-Head Self-Tapping
Screw (2)
Double-Sided Tape (1)
Mounting Hole Template (1)
6 DPF710K
Installation
Wire Post(s)
Power Adapter
Wire Notch
Adhesive Foam Pads
homebase Bracket Mounting Holes
DC Input Connector
Power Adapter
Wire Notches
Wall Mount Bracket
Refrigerator Door Front Surface
DC Power Wire
homebase
Wire Cover
Refrigerator Door Seal
1inch
Wire Cover
See Step 9 Caution
Below
homebase Refrigerator Installation
1. Remove the protective backing from one side only of the two adhesive pads and position them on the back of the wall mount bracket as shown.
2. Clean the homebase mounting area on the refrigerator with isopropyl alcohol; do not use a glass cleaner.
3. Place the wall mount bracket in the desired area and level the top of the bracket. Note: Before removing the remaining protective backing from the two adhesive pads, be sure of the homebase
4. Remove the protective backing from the two adhesive pads, line up the top of the bracket, and firmly press and hold the bracket in place on the refrigerator surface to ensure the pads adhere securely. Note: 3M™ recommends waiting 24 hours for maximum adhesion prior to mounting your homebase to the mounting
5. Connect the power adapter plug to the DC input connector at the rear of the homebase.
6. Choose the direction of the adapter wire in reference to the AC wall outlet. Place the DC wire in the corresponding wire notch.
7. Check the amount of wire required to reach the AC outlet. Spool excess wire on the four posts inside the rear cavity of the homebase.
8. Attach the homebase to the bracket by lining up the homebase bracket mounting holes with the wall bracket mounting tabs, and slide the homebase down until the mounting tabs engage the mounting hole slots.
9. Cover the power adapter wire with the clear, black or white wire cover; seal the cover using the double-sided tape and dress the wire, adhering it to the refrigerator surface. Caution: The power adapter wire routing follows the right angle contour of the refrigerator door. Do NOT cover the DC power
mounting location as the adhesive pads are not designed to be removed and repositioned once they are applied to the refrigerator surface.
bracket.
adapter wire using the double-sided tape after the 90 degree transition from the front refrigerator surface to the side surface and for at least one inch rearward of the refrigerator seal. This will allow movement of the power adapter wire as the refrigerator door opens and closes.
DPF710K 7
homebase
Unit
Installation (Cont)
Angle Bracket Mounting Holes
DC Input Connector
Wire Post(s)
Power Adapter
Wire Notches
Angle Mount Brackets
Bracket Upper
Mounting Tabs
Bracket Lower
Mounting Tabs
homebase Countertop Installation
1. Find a suitable location on the countertop adjacent to an AC wall outlet.
2. Connect the power adapter plug to the DC input connector at the rear of the homebase.
3. Choose the direction of the adapter wire in reference to the AC wall outlet. Place the DC wire in the correspond­ing wire notch.
4. Check the amount of wire required to reach the AC outlet. Spool excess wire on the four posts inside the rear cavity of the homebase.
5. Attach each angle mount bracket to the homebase by lining up the individual angle mount bracket upper mounting tab with the associated homebase mounting hole.
6. Push each angle mount bracket towards the top of the homebase until the upper mounting tab engages the mounting hole slot; when the bottom of the angle bracket contacts the homebase, the tab on the bottom of the angle bracket snaps into place.
7. Place the homebase in the desired location.
8 DPF710K
Installation (Cont)
Flat-Head Self-Tapping
Screw (2)
Wall Bracket
Mounting Tabs
Wall Surface
Wall Mount
Bracket
Drill 1/4" Hole
(2 Places)
Mounting Hole
Template
Plastic Wall
Anchor (2) if
Needed
homebase Wall Mount Installation Using the Wall Mount Bracket
Note: If the wall bracket is to be mounted using the foam adhesive pads, the procedure will be the same as that
for the refrigerator mount as described on page 7.
If the wall bracket is to be mounted using screws, proceed as follows:
1. Position the mounting hole template at the desired place on the wall; level the template and mark the
position of the two upper holes.
2. Drill two holes using a 1/4" (6mm) drill bit. If a wall stud is not present, insert the plastic anchors into the holes
until flush with the wall surface .
Caution: Do not over tighten the screws; otherwise, the wall bracket could be damaged
3. Align the wall bracket with the two holes and/or wall anchors; insert two flat-head screws and secure the wall
bracket to the wall.
4. Connect the power adapter plug to the DC input connector at the rear of the homebase.
5. Choose the direction of the adapter wire in reference to the AC wall outlet. Place the DC wire in the correspond-
ing wire notch.
6. Check the amount of wire required to reach the AC outlet. Spool excess wire on the four posts inside the rear
cavity of the homebase.
7. Attach the homebase to the bracket by lining up the homebase bracket mounting holes with the wall bracket
mounting tabs, and slide the homebase down until the mounting tabs engage the mounting hole slots.
8. Cover the power adapter wire with the clear, black or white wire cover; seal the cover using the double-sided
tape and dress the wire, adhering it to the wall surface.
DPF710K 9
Installation (Cont)
Angle Mount Bracket
Mounting Tabs
Flat-Head Self-Tapping
Screw (2)
Plastic Wall Anchor (2)
if Needed
Angle Mount
Bracket (2)
Drill 1/4” Hole
(2 Places)
Wall Surface
Mounting Hole
Template
homebase Wall Mount Installation Using the Angle Mount Brackets
Note: Foam adhesive pads are not recommended when mounting the angle mount brackets to a wall surface.
Mount the brackets to the wall surface as follows:
1. Position the mounting hole template at the desired place on the wall; level the template and mark the
position of the two lower holes.
2. Drill two holes using a 1/4” (6mm) drill bit. If a wall stud is not present, insert the plastic anchors into the holes
until flush with the wall surface .
Caution: Do not over tighten the screws; otherwise, the angle mount bracket could be damaged.
3. Align each angle mount bracket with the respective hole and/or wall anchors; insert a flathead screw through
each bracket and secure the bracket to the wall.
4. Connect the power adapter plug to the DC input connector at the rear of the homebase.
5. Choose the direction of the adapter wire in reference to the AC wall outlet. Place the DC wire in the correspond-
ing wire notch.
6. Check the amount of wire required to reach the AC outlet. Spool excess wire on the four posts inside the rear
cavity of the homebase.
7. Attach the homebase to each bracket by lining up the homebase bracket mounting hole with the associated
bracket mounting tabs, and slide the homebase down until each mounting tab engages the mounting hole slot.
8. Cover the power adapter wire with the clear, black or white wire cover; seal the cover using the double-sided
tape and dress the wire, adhering it to the wall surface.
10 DPF710K
