Audiovox D1708PK User Manual

D1708PKD1708PK

D1708PK

D1708PKD1708PK

PORTABLE 7" LCD MONITOR AND DVD PLAYER

IN A BAG

Notice:

This Product incorporates copyright protection technology that is pro­tected by method claims of certain U.S. Patents and other intellectual
property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be autho­rized by Macrovision Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.

Notice:

An LCD panel and/or video monitor may be installed in a motor ve­hicle and visible to the driver if the LCD panel or video monitor is used
for vehicle information, system control, rear or side observation or
navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play , the LCD panel or video monitor must
be installed so that these features will only function when the vehicle
is in “park” or when the vehicle’s parking brake is applied.

An LCD panel or video monitor used for television reception, video or
DVD play that operates when the vehicle is in gear or when the park­ing brake is not applied must be installed to the rear of the driver’s
seat where it will not be visible, directly or indirectly , to the operator of
the motor vehicle.

2

A. Introduction

Thank you for selecting the D1708PK portable DVD player in a bag.
The main features include a 7" Screen (16:9 Aspect Ratio) Liquid
Crystal Display (LCD) monitor and a DVD player . The unit applies
the latest state of the art electronics and is designed for use in ho­tels, offices home or vehicle. The unit is constructed to provide years
of reliable, trouble-free service, and is compact so that you can take
it with you anywhere and is designed for quick and easy
installation.Please read the entire instruction manual supplied with
this product prior to operation. The documentation will assist you in
installing the system properly to obtain the best equipment perfor­mance. All manuals should be stored for later use.

B. Cautions and Warnings

1. Placement

T o prevent fire or electric shock, do not expose this appliance to
rain or moisture. Do not place the set on an unstable cart,
stand,tripod, bracket or table to prevent it from falling. Keep the
unit away from strong magnets, heat sources, direct sunlight, ex­cessive dust. If the unit is brought directly from a cold to a warm
location, moisture may condense inside the unit. When you move
it from a cold to a warm location, wait for about one hour before
operating the unit, or remove the disc and leave the unit turned on
until the moisture evaporates.

2. Installation

Ensure that the D1708PK is installed in accordance with the in­structions and illustrations provided in this manual.

3. Object and Liquid

Do not push objects of any kind into the unit through openings; do
not spill or spray liquid of any kind on or in the system (this may
result in a fire or electric shock). Do not place anything heavy on
the unit. T o ensure proper ventilation and proper operation, never
cover or block the slots and openings with a cloth or other mate­rial.

4. Disassembly

Do not attempt to disassemble the cabinet. There is a risk of elec­tric shock and/or exposure to Laser Radiation. Contact qualified
service personnel if your system is in need of repair.

3

5. Cleaning Unit

When cleaning, make sure the system is unplugged from the power
source. Do not use liquid cleaners or aerosol cleaners. Use a
cloth lightly dampened with water for cleaning the exterior of the
system only.

6. Disc

Do not use irregularly shaped discs such as heart or star-shaped
discs as they may cause the unit to malfunction. Do not stick pa­per, tape or glue on the disc. Do not expose the disc to direct sun­light or heat sources such as hot air ducts. Do not touch the sur­face of disc. Handle the disc by its edge. Clean the disc by wiping
the disc from the center out with a cleaning cloth. Remove the disc
from the unit and store it in its case after playing. Some playback
operations of discs may be intentionally fixed by software produc­ers. Since this unit plays discs according to the disc contents the
software producers designed, some playback features may not be
available. Also refer to the instructions supplied with the discs.

C. Contents

1. 1 x 7’’ LCD Monitor & DVD Player Combo

2. 1 x AC to DC Adapter

3. 1 x Remote Control w/Battery (CR2025)

4. 1 x Instruction Manual

5. 1 x Audio/Video Cable

6. 2 x Wired Headphones

7. 1 x DC Adapter

8. 1 x Mounting Bag w/S traps

9. 1 x Carrying Bag

10. 1 x Rechargeable Battery Pack

D. Powering and installation

1. Powering the system indoors (Refer to Figure 1)
Plug one end of the AC to DC adapter into the DC 9V jack on the
right side of the main unit, then plug the other end into the 120V AC
power receptacle.

4

2. Powering the system in a car

Plug one end of the cigarette lighter adapter into the DC 9V jack on
the unit, then plug the other end into the lighter socket.

Figure 1

3. Powering the system with rechargeable Battery

Please refer to L. * Rechargeable Battery Installation and Use
(Page 32 and 34).

E. Installation in Mounting Bag

Make sure that the unit is placed into the bag with the clear plastic
covering around DVD door, Load disc into the DVD comp artment and
then fasten the Velcro strap across the top portion of the unit. If
you are installing the bag onto the seatback you will need to attach the
supplied Seat Standoff to the back of the mounting bag with the
Velcro bands to obtain the proper viewing angle as shown in Figure.2

5

1.Installing the System onto the seat back in a car

(Refer to Figure 2)

Seat Standoff

Figure 2

1). Take one of the supplied straps from the carrier bag. Connect
the latch to one of the upper metal rings on the mounting bag.
Connect the “S” hook to the other upper metal ring and place the
loop over the headrest. Adjust the strap until the bag is firmly
secured.

2). T ake another strap from the carrier bag, and connect the latch to
the lower metal ring on the left side of the bag. Attach the “S”
hook to the same ring after looping the strap around the seat rail.
Repeat this process for the right side. In some vehicles, it may
be necessary to attach the “S” connector to the rail directly , as it
may not be long enough to reach back to the ring.

3). Adjust the straps tightly so that the bag is secured.

6

2. Installing the system between the driver/passenger seat

(Refer to Figure 3)

Figure 3

1). Take one strap and connect the latch to the upper metal ring on
the left side of the bag. Attach the “S” hook to the same ring
after looping the strap around the headrest of the driver’s seat.
Repeat this process for the right side (Passenger Seat).

2). T ake another strap and connect the latch to lower met al ring on
the left side of the bag. Attach the “S” hook to the same ring
after looping the strap around the driver’s seat rail. Repeat this
process for the right side. In some vehicles, it may be neces­sary to attach the “S” connector directly to the rail, as it may not
be long enough to reach back to the ring.

3). Adjust the straps tightly so that the bag is secured.

7

E. Controls, Indicators, and Connectors

1. Unit View (Refer to Figure 4)

Figure 4

1) Menu

2) UP Button

3) Left Button

4) Down Button

5) OK Button

6) Right Button

7) Open Button

8) Previous Button

9) Stop Button

10) Next Button
1 1) Play button

12) Pause

13) Screen Mode (WIDE) Button

14) Monitor Off Button

15) Remote Control Sensor

16) Power LED

17) DVD Video Output Jack

18) DVD Audio L+R Output Jack

19) Video Input Jack

20) Audio L+R Input Jack

21) Power On/Off Switch

22) Volume Up/Down control

23) Headphone Jack 1

24) Headphone Jack 2

25) DC 9V Input Jack

26) Brightness Up/Down control

8

2. Remote Control View (Refer to Figure 5)

1) Display Button

2) Angle Button

3) Subtitle Button

4) Audio Button

5) Zoom Button

6) UP/DOWN/LEFT/RIGHT/
ENTER Buttons

7) Return Button

8) A-B Button

9) Forward Button

10) Reverse Button
1 1) Slow Button

12) Stop Button

13) Numeric Keypad

14) Setup Button

15) Menu Button

16) Repeat Button

17) SKIP-

18) SKIP+

19) Play Button Figure 5

20) Pause Button

F. Loading and Playing a Disc

a. After connecting power to the unit, power on the “DVD player” with

the power switch. The power indicator will light.

b. Open the disc tray by pressing OPEN , and place a disc into the

tray with the label side facing up.

c. Close the tray by pressing the “PRESS” button.The unit will load

the disc and start playing.

d. Rotate the BRIGHTNESS and VOLUME controls to adjust the

LCD’s brightness and the DVD player’s volume.

e. To stop playing a disc, press STOP.

f. To turn off the DVD player, slide the POWER ON/OFF to OFF.

The DVD player’s POWER indicator turns off.

9

G. SETUP

Press ‘SETUP’ to display the Main screen of the SETUP Menu on the
screen. Press ‘SETUP’ again to exit the SETUP Menu and the unit
will resume it’s last playback mode.

Figure 6. Main SETUP Menu Screen

1) Press “Setup”, the ‘GENERAL SETUP PAGE’ will display on screen.

Figure 7. General SETUP Menu Screen

a).Select TV DISPLAY using the DOWN button, and then press

RIGHT to enter the submenu. Select the TV display mode on the
screen using UP/DOWN, and press ENTER to confirm the
setting. Press LEFT to return.

10

* NORMAL/PS: When the player is connected to a normal TV,

and a wide picture is shown on the full screen.

* NORMAL/LB: When the player is connected to a normal TV,

and a wide picture is shown on the screen with a black strip
at both the top and bottom of the screen.

* WIDE: When the player is connected to a wide screen TV, a

wide picture is shown on the full screen.

Figure 8. TV DISPLAY Screen Display

b).Select ‘ANGLE MARK’ using the DOWN buttton, and then press

the RIGHT button to enter the submenu. Choose Angle Mark on
or off using the UP/DOWN buttons and then press ENTER to
confirm the setting. Press the LEFT button to return.

Figure 9. ANGLE MARK Screen Display

* ON: The screen will show the angle mark icon. (*If an angle

option is available).

* OFF: The screen will not display the Angle Mark icon.

NOTE: Not all discs contain above features.

11

c). Select ‘SCREEN SAVER’ using the DOWN button.

Figure 10. SCREEN SAVER Display

*ON: enables screen saver
*OFF: disables screen saver (off)

*NOTE: The DVD player will enter the Screen Saver mode after
approximately five minutes if the same image remains on the
screen.

d). Select “ Last Memory” by using the DOWN button.

Figure 11. LAST MEMORY Screen Display

*ON: The unit will return to the last position on the disc.
*OFF: The unit will not return to the last position on the disc.

2) With no disc inside the player select “Video quality Setup”by using
the LEFT/RIGHT buttons, press “enter” to enter the video quality
set up page.

Figure 12. Main SETUP Menu VIDEO QUALITY

12
