Audiovox CMD-8500 User Manual

AUDIOVOX

CDM-8500

Tri Mode Digital CDMA2000 1X

Handheld Portable Telephone

In today’s fast paced world, it has become a necessity to have access to real time information. Y our communications tools must provide you with this access from anywhere at anytime. With that in mind, Audiovox developed the CDM-8500, a tri mode clamshell style handset with dual LCD displays.

This 1X digital handset enables carriers supporting 1X technology to provide consumers with access to high speed connectivity for web browsing, email and mobile e-commerce. Operating on the 800 MHz Amps/CDMA and 1900 MHz PCS frequencies, the CDM-8500 allows for seamless nationwide coverage as well as offering state-of-the-art,

user-friendly features. Voice activated

dialing and 2-way

speakerphone are great for enhancing hands-free use of this phone. T9TMText Input, vibrating alert and a 7-line LCD display make the CDM-8500 easier to use.

Seven different LCD colors let you set the backlight to match your mood. Red, yellow, deep green, green, blue, purple and white. You can also set the backlight to change color everytime you open your phone. The keypad is always backlight blue.

Your new CDM-8500 provides you with something only an Audiovox phone can: the proven reliability that has made us a leading wireless handset provider. Please take a few moments to read the following pages of the owner’s manual. It will help you make the most efficient use of this valuable communications tool.

Preface

TABLE OF CONTENTS

CHAPTER 1 BEFORE USING YOUR PHONE..........7

Package Contents...................................................8

Handset Description...............................................9

Function Keys.......................................................10

Display Indicators.................................................11

Using the Battery..................................................13

Installing the Battery............................................13

Removing the Battery..........................................13

Charging the Battery ............................................14

Power Connection...............................................14

Charging the Battery............................................14

Battery Charging Time.........................................15

Battery Talk & Standby Times .............................15

Battery Information...............................................16

CHAPTER 2 BASIC OPERATION ...........................17

Using the Phone ...................................................18

Turning the Phone On.........................................18

Turning the Phone Off.........................................18

Using the Menu.....................................................19

Menu Summary.....................................................20

Basic Functions....................................................23

Making a Call.......................................................23

Pause Feature.....................................................24

Speaker phone....................................................25

Answering Calls...................................................25

Caller ID...............................................................25

Call Waiting..........................................................26

Answering Machine Display.................................26

Adjusting the Volume...........................................27

Lock.....................................................................27

Vibrate .................................................................28

Etiquette Mode ....................................................28

Functions During a Call .......................................29

Mute.....................................................................29

Silent....................................................................29

Send My Phone#.................................................29

Table of Contents - Page 1

TABLE OF CONTENTS TABLE OF CONTENTS

Force Analog .......................................................50

NAM Setting ........................................................51

PRL ID.................................................................52

Setting....................................................................53

Sounds.................................................................53

Display.................................................................58

Others..................................................................63

UP Proxy IP.........................................................67

VR Mode ................................................................68

Name...................................................................68

Dial.......................................................................69

Redial...................................................................69

Voice Memo.........................................................70

Phonebook...........................................................70

Cancel..................................................................71

VS Menu.................................................................72

Voice Memo.........................................................72

Call Answer..........................................................73

Voice Command..................................................74

Voice Dial.............................................................78

Voice Alert............................................................80

Voice Setting........................................................81

CHAPTER 5 SECURITY FEATURES.......................85

Security Features..................................................86

Security................................................................86

CHAPTER 6 SUPPLEMENTARY FUNCTIONS.......93

Schedule ................................................................94

Event....................................................................94

Alarm....................................................................95

Calculator ..............................................................96

Calculator.............................................................96

World Clock...........................................................97

World Clock.........................................................97

Stopwatch..............................................................98

Stopwatch............................................................98

My Profile.............................................................30

Voice Privacy .......................................................30

Location...............................................................30

CHAPTER 3 MEMORY FUNCTION ........................31

Storing Phone Numbers.......................................32

Text Input Methods...............................................33

Entering Characters.............................................33

Alpha Mode [ABC]...............................................33

T9TMPredictive Text Mode [T9TMABC]..................34

Numeric Mode [123]............................................36

Symbol Mode [SYM]............................................36

Speed Dialing ........................................................37

One-Touch/Two-Touch Dialing.............................37

Call Logs................................................................38

Outgoing Calls.....................................................38

Incoming Calls.....................................................39

Missed Calls........................................................40

Call Times ..............................................................41

Last Call...............................................................41

All Calls ................................................................41

Home Calls..........................................................41

Roam Calls..........................................................41

Accumulate Calls.................................................41

Using Your Phonebook.........................................42

Recalling by Group..............................................42

Recalling by Name ..............................................42

Recalling by Phone Number................................43

Editing Your Phonebook......................................43

Edit Group ...........................................................44

Speed Dial...........................................................46

My Profile.............................................................47

CHAPTER 4 SETTINGS...........................................49

Roaming.................................................................50

Set Mode.............................................................50

Page 2 - Table of Contents Table of Contents - Page 3

TABLE OF CONTENTSTABLE OF CONTENTS

Offline Services..................................................119

Outbox ...............................................................119

Restart Up.Browser ...........................................119

Encryption..........................................................119

CHAPTER 10 DATA SERVICE ...............................121

Data SVC..............................................................122

Connection.........................................................122

Data Speed........................................................123

Location ...............................................................124

Setting................................................................124

CHAPTER 11 SAFETY INFORMATION .................125

Safety Information for Wireless Handheld Phones

..126

Safety Information for FCC RF Exposure.........133

SAR Information..................................................134

FDA Consumer Update ......................................136

CHAPTER 12 WARRANTY...................................145

Protect Your Warranty........................................146

12 Month Limited Warranty ...............................147

Page 4 - Table of Contents

CHAPTER 7 VOICE MAIL AND TEXT MESSAGES.99

Two-Way SMS .....................................................100

Message Indicators ...........................................100

Received Message Notification.........................100

Checking Messages ...........................................101

Checking Received Voice Mail Message..........101

Checking Received Text Message ....................101

Sending Text Messages .....................................102

Sending New Text Messages ............................102

Inbox ....................................................................104

Inbox Menu ........................................................104

Outbox .................................................................106

Outbox Menu.....................................................106

Filed......................................................................108

Erase All...............................................................119

Settings................................................................110

Settings Menu....................................................110

CHAPTER 8 MAKING AN EMERGENCY CALL...113

Emergency Calling..............................................114

E911 Calling.......................................................114

CHAPTER 9 INTERNET BROWSER .....................115

Start Internet Browser........................................116

Wireless Internet................................................116

Browser Menu.....................................................117

Reload................................................................117

Home .................................................................117

Bookmarks.........................................................117

Mark Site............................................................117

About Openwave ...............................................118

Advanced...........................................................118

Show URL..........................................................118

Homepage .........................................................118

Set WAP PROXY...............................................118

Table of Contents - Page 5

Please read and fully understand this manual before using your phone.

This chapter addresses your phone, its keys, display icons, and the charging and proper use of the battery.

Once you have read this chapter, you can move on to the basic and advanced features of your phone.

Package Contents Handset Description Function Keys Display Indicators Using the Battery Charging the Battery Battery Information

Chapter 1

BEFORE USING

YOUR PHONE

Chapter 1 - Page 7Page 6

HANDSET DESCRIPTION

Volume

Button

Adjusts the earpiece and ringer volume.

Earpiece

Function Keys

Keypad

Microphone

This phone is a tri mode CDMA2000 1X digital phone with data and web browsing capabilities. The CDM-8500 weighs 3.1 oz. and the dimensions are 3.3” x 1.6” x 9”.

Chapter 1 - Page 9

PPACKAGE CONTENTS

ACKAGE CONTENTS

Thank you for purchasing the CDM-8500 wireless handset. The phone’s giftbox contains all of the items listed below.

NOTE: Immediately report any product defects or

missing items to the place of purchase.

User Manual

Hand strap

Handset

Page 8 - Chapter 1

Antenna

For best call quality, fully extend the antenna during the call.

LCD Display

Desktop Charger

Standard Battery

Belt Clip

DISPLA

Y INDICA

TORS

Chapter 1 - Page 11

FUNCTION KEYS

END KEY: Press to turn the handset on or off. Terminates a call or exits the current menu.

SEND KEY: Press to make or receive a call.

NAVIGATION KEY: Press the arrow keys to scroll through the menu. Press OK to select an item in the menu.

SOFT KEYS: Press to perform the functions displayed above them on the LCD Display.

WEB KEY: Press to access the web. CLEAR KEY: Press to clear characters

or enable the speakerphone mode. LOCK KEY: Press and hold to enter the

Lock mode. ETIQUETTE MODE KEY: This mode

disables the keypad tone and enables vibrating alert.

Page 10 - Chapter 1

Signal Strength

Indicates current signal strength. The more lines, the stronger the signal.

Roaming

Phone is outside of its home area.

Service Indicator

When a call is in progress, is displayed. When is displayed, the phone is in idle mode. When is displayed, the phone is not receiving a signal from the system.

Message

Text or voice mail message is waiting.

Digital Mode

Phone is operating in digital mode.

Battery

Charge level status. The more black lines, the greater the charge.

Mute

Phone is mute during a call.

Phone is in the 1x service area.

Dormant

Indicates the phone is in disconnection condition while on " Server Connection ".

Text Message

Voice Message

Voice & Text Message

USING THE BA

TTER

TTERYY

Chapter 1 - Page 13

DISPLA

Y INDICA

TORS

INSTALLING THE BATTERY

1. Insert the bottom of battery into groove at bottom of the handset.

2. Press in the top of the battery until it clicks.

REMOVING THE BATTERY

Push the tab with one hand and lift the top of the battery

to separate.

NOTE: If the battery is not correctly placed in the battery

compartment, the handset will not turn on and/or the battery may detach during use.

Page 12 - Chapter 1

Phone receive an "UPAlert". Phone receive an "UPAlert" and have a text

massage whice it isn’t checked.

Silent

Mutes key tone during a call.

Emergency call

Blinks when an emergency call is in progress.

Answering machine memo

New voice memos.

Answering machine

Phone is answering machine mode.

Etiquette

Phone is in etiquette mode (vibration alert).

Schedule

Event or an alarm is set.

Ring Mode

Appears when Silent is selected as the ring mode.

Phone is in the progress of UP Browser.

GPS Icon

911 Only Location On

Ringer Silent VibrateRinger after

vibrate

CHARGING THE BA

TTER

TTERYY

NOTE: Charging time applies only when your phone is

turned off. Charging time may vary if your phone is turned on.

NOTE: These times are for a new battery. Talk and

standby time may decrease over time.

BATTERY TALK & STANDBY TIMES

BATTERY CHARGING TIME

Chapter 1 - Page 15

CHARGING THE BA

TTER

TTERYY

NOTE: 1. It is more efficient to charge the battery with

the handset off.

2. The battery must be connected to the phone in order to charge it.

3. If the LED flickers while charging, the battery contacts may need cleaning.

Once fully charged, the LED may change from red to green. This does not indicate a problem with the battery.

Battery operating time gradually decreases over time.

6. If the battery fails to perform normally, you may

need to replace the battery.

Page 14 - Chapter 1

POWER CONNECTION

Connect the charger to a standard 110V AC outlet. The battery can be charged alone, or when attached to the phone.

NOTE: 1.

The battery is not charged at the time of

purchase.

2. Fully charge the battery before use.

● Red indicates charging is in progress.

● Green indicates charging is complete.

CHARGING THE BATTERY

Battery Type

BTR - 8500

200 minutes

Charging Time

Standard Battery

(900mAh)

190

150

Talk Time (min)

Digital

Analog

Digital

Analog

Standby Time (hrs)

This chapter addresses the phone’s basic functions including menus, volume levels, and call features.

Using the Phone Using the Menu Menu Summary Basic Functions Functions During a Call

Chapter 2

BASIC OPERATION

Chapter 2 - Page 17

Use only manufacturer approved batteries. Never use a damaged or worn out battery. Use the battery only for its intended purpose. Never expose the battery terminals to any other metal

object. This can short circuit the battery. Avoid exposure to temperature extremes. A phone with

a hot or cold battery may temporarily not work (or charge), even if the battery is fully charged. Always allow it to cool down or warm up first and keep the battery between 41oF and 95oF (5oC and 35oC).

When not in use, store the battery uncharged in a cool, dark, dry place.

The battery is a self-contained unit. Do not attempt to open its case.

Battery operating time gradually decreases. You may need to buy a new battery.

Never dispose of a battery in a fire! Dispose of used batteries in accordance with local

regulations. Recycle!

TTER

Y INFORMA

TION

Page 16 - Chapter 1

USING THE MENU

To enter the main menu from the standby screen, press .

2. Use the navigation key to view menu selections.

3. To go back to previous screen, press .

4. To exit the menu, press .

5. To go into a submenu, press the corresponding number or select the desired item by pressing on the navigation key.

Chapter 2 - Page 19

USING THE PHONE

TURNING THE PHONE ON

1. Press .

NOTE: 1.

If "LOW BATTERY WARNING POWER OFF" appears and the power goes off, there is a possibility of damaging your phone's memory. It is recommended that you change or charge the battery.

If the battery is removed while the phone is on,

information about the last call may be

erased.

NOTE: The default password is the last 4 digits of your

phone number.

● If “PASSWORD” appears, the phone is locked. To

unlock, enter your 4-digit password.

● can be used for scrolling through the menu.

TURNING THE PHONE OFF

1. Press and hold until “Powering Off Good Bye” appears.

Page 18 - Chapter 2

SETTING

MENU SUMMAR

MENU SUMMARYY

TOOLS

1 : Set Mode 2 : Force Analog 3 : NAM Setting

4 : PRL ID 1 : Sounds

2 : Display

3 : Security

4 : Others

5 : UP Proxy IP 1 : Calculator

2 : World Clock 3 : Stopwatch

1 : Auto NAM 2 : Change NAM

1 : Ringer Type 2 : Ringer Mode 3 : Volume 4 : Alert 5 : Roam Ringer 6 : Tone Length 1 : Animation Setting 2 : Main Display Setting 3 : LCD Setting 4 : Sub LCD Setting 1 : Restrict 2 : Special #’s 3 : Clear Phonebook 4 : Reset Phone 5 : Change Password 1 : Answer Mode 2 : Active Flip 3 : Auto Retry 4 : Auto Answer 5 : Voice Privacy 6 : Language 7 : Web Idle Time 8 : S/W Version

Chapter 2 - Page 21

MENU SUMMAR

MENU SUMMARYY

CALL HISTORY

PHONE BOOK

SCHEDULE

1 : Last Call 2 : All Calls 3 : Home Calls 4 : Roam Calls 5 : Accumulate Calls

1 : By Group 2 : By Name 3 : By Number 1 : Add New Entry 2 : Edit Existing Entry 1 : Add New Group 2 : Change Group Name 3 : Change Group Bell 4 : Change Group Color 5 : Clear Group

●

Name

●

My Phone Number

●

Birthday

●

Blood Type

●

Address

●

Home Number

●

E-mail

●

Work Phone Number

●

Memo

●

Set Secret

1 : New Event 2 : View Event List

1 : Outgoing Calls 2 : Incoming Calls 3 : Missed Calls 4 : Call Times

1 : Find

2 : Edit Phonebook 3 : Edit Group

4 : Speed Dial 5 : My Profile

1 : Event 2 : Alarm

Page 20 - Chapter 2

ROAMING

Chapter 2 - Page 23

BASIC FUNCTIONS

MAKING A CALL

1. Enter the phone number.

2. To place a call, press .

3. To end a call,

press .

Page 22 - Chapter 2

MENU SUMMAR

MENU SUMMARYY

VOICE SVC

1 : On/Off 2 : Inbox 3 : Call Speaker 4 : Wait Time 1 : Yes/No 2 : Wake-Up 3 : Top Level 4 : Digit Dial 1 : List 2 : Add 3 : Clear All 1 : On/Off 2 : Record 3 : Play 4 : Clear 1 : Untrain All 2 : Prompt Mode 3 : Digit Mode 4 : HFK Mode 5 : Set Active

1 : Connection 2 : Data Speed

1 : Setting

1: Voice Memo 2: Call Answer

3: Voice Command

4: Voice Dial

5: Voice Alert

6: Voice Setting

● If the line is busy, press .

● To erase the last entered number, press .

● To erase all numbers and start again, press and hold .

● “CALL FAILED” will display if the call did not connect.

● If the line is busy, press .

● Selecting Auto Retry will automatically redial the number

for the time you have selected. (Refer to page 64)

LOCATION

DATA SVC.

The phone resets to Speakerphone Off when it turns off and back on.

Chapter 2 - Page 25

BASIC FUNCTIONS

SPEAKER PHONE

1. To activate speakerphone in idle, answering and calling modes, press and hold .

2. After a call the phone returns to normal (Speakerphone off).

Page 24 - Chapter 2

ANSWERING CALLS

1. To answer a call, press any key except .

NOTE: Calls can be automatically answered by activating

the AUTO ANSWER function. (Refer to page 65)

NOTE: The Caller ID numbers are saved in the call log.

Caller ID is a system dependent feature. Please contact your service provider for details.

Stanby menu that appears when entering a number.

CALLER ID

Identifies caller by displaying that person’s phone number. If the caller’s name and number are stored in your phonebook, the name and number from the memory location are displayed.

BASIC FUNCTIONS

STANDBY MENU

PAUSE INPUT: 1 : HARD PAUSE 2 : TIMED PAUSE

PAUSE FEATURE

Pauses are used for automated systems (i.e., voice mail and calling cards). Insert a pause

after a phone number,

then enter another group of numbers

. The second set of numbers is dialed automatically after the pause. This feature is useful for dialing into systems that require a code.

1. Enter the phone number, then press [PSE].

2. Select the desired pause (Hard Pause or Timed

Pause). A“P” will appear after the number

represent the pause.

4. To dial, press . To store, press .

HARD PAUSE: If you enter the pause character (P), the

number entered after the pause character will be sent after the dialed number.

3. Then enter the second set of numbers.

STO FIND PSE

ADJUSTING THE VOLUME

Y ou can adjust the volume in two ways: by using the volume control keys on the side of the handset.

Pressing volume control keys:

●

During a call : Adjusts earpiece volume.

●

In Standby Status : Adjusts ringer volume.

●

When the phone rings : Adjusts ringer volume.

See page 54 for more detailed instructions.

LOCK

Locks your phone and prevents unauthorized use. Phone can only be used after inputting the password.

1. To lock the phone, press and hold .

2. To unlock the phone, press then input the password.

Chapter 2 - Page 27

BASIC FUNCTIONS

Page 26 - Chapter 2

BASIC FUNCTIONS

CALL WAITING

If you have call waiting this function notifies you of an incoming call when you are on another call by sounding a beep tone.

1. When you hear the beep, press to answer the call.

2. To switch back to the first caller, press again.

NOTE:

Call Waiting is a system dependent feature. Please

contact your service provider for details.

ANSWERING MACHINE DISPLAY

Notifies you of unchecked recorded memos in the answering machine and displays the number of stored memos that are recorded in the answering machine.

See page 73 for more information about the answering machine.

To play the recorded voice memos, press .

NOTE: The default password is the last 4 digits of your

phone number.

Chapter 2 - Page 29

NOTE: To turn mute off, press , then “Unmute” again.

FUNCTIONS DURING A CALL

SEND MY PHONE#

Enables your phone number to be automatically transmitted to a pager. (Dependent on pager service.)

After calling a pager, when you are asked to enter your number, press “SENDMY PHONE #”.

MUTE

Mutes the microphone while you are on a call so the other party cannot hear you if you speak.

1. Press “MUTE”.

These menu items are available while you are on a call.

Page 28 - Chapter 2

SILENT

Prevents the person you’re talking to from hearing DTMF tones when any key is pressed during a call.

1. To activate, press “SILENT”.

2. To deactivate, press .

BASIC FUNCTIONS

VIBRATE

Disables the ringer and vibrates when an incoming call is received. To enable this function:

1. Press .

2. Select “SOUNDS”, then press .

3. Select “VIBRATE”.

ETIQUETTE MODE

Silences all phone sounds while attending a meeting, a movie, or any other time you do not want your phone to be heard. All phone sounds include the ringer, key beeps and notifications. Your phone will vibrate to notify you of an incoming call. To enable this function, press and hold “Etiquette mode”.

This chapter addresses numerous functions including saving phone numbers to the internal phonebook, entering text and accessing call logs.

Storing Phone Numbers Text Input Methods Speed Dialing Call Logs Call Times Using Your Phonebook

Chapter 3

MEMORY

FUNCTION

Chapter 3 - Page 31Page 30 - Chapter 2

FUNCTIONS DURING A CALL

MY PROFILE

Enables you to review and edit your profile, entered through the phonebook entry . Please refer to page 47 for more details.

1. Press “MY PROFILE”.

VOICE PRIVACY

Enhances voice privacy during a call.

1. Press “VOICE PRIVACY”.

2. Select “STANDARD” or “ENHANCED” with the navigation key.

LOCATION

Enables your network to locate your current location through Global Positioning System (GPS). Refer to page 124 for more details.

1. Press “LOCATION”.

NOTE: This feature may not be available on all networks.

Please check with your service provider for availability.

NOTE: This feature may not be available on all networks.

Please check with your service provider for availability.

TEXT INPUT METHODS

Key Pad

2ABC 3DEF

4GHI

9WXYZ

1 Repetition

A D

2 Repetitions

B E H

3 Repetitions

C F

4 Repetitions

2 3 4

5 Repetitions

’

... ... ...

ENTERING CHARACTERS

For convenient entry of memory location names and text messages, your phone offers several text input methods:

Alpha mode : Enters words by repeatedly tapping the

corresponding key until the desired character is displayed.

T9TMmode : T ap each corresponding key only once and the phone

predicts the word you are entering.

Numeric mode : Only enters numbers. Symbol mode : Enters symbols like @, #, %.

●

The cursor automatically moves to the next

space in two seconds after character input.

●

To erase one letter, press .

●

To erase the entire entry, press and hold .

●

To switch between lowercase to uppercase

letters,

press .

ALPHA MODE [ABC]

To choose Alpha mode, press [MODE] then choose [ABC]. The chart below outlines the key presses needed to display each letter or number in this mode.

Chapter 3 - Page 33

STORING PHONE NUMBERS

Page 32 - Chapter 3

The CDM-8500 internal phonebook stores up to 300 frequently dialed numbers.

2. To select add new entry and press .

3. To select phone number type by using the navigation

key (Home, Mobile, Office, Pager, Fax) and press .

4. Press [EDIT] then enter the person’s name and

press .

5.1 To make a voice dial, select the catalog by using

the navigation key (Home, Mobile, Office). Press and press .

5.2 Press “Enter Voice Tag?”.

5.3 Press .

6. To confirm the entry & save to your phonebook press .

1. Enter the phone number, including area code, and press .

NOTE: “New entry saved” will appear.

1. Press each key once for each letter of the word you are writing.

●

To write John with the English dictionary selected:

1. Press 5 once - (for - k)

2. Press 6 once - (for - km)

3. Press 4 once - (for - log)

4. Press 6 once - (for - john)

2. Press until the correct word is displayed.

3. To select the correct word and press .

TEXT INPUT METHODS

NOTE:

The display shows for each key

pressed.

Chapter 3 - Page 35

TEXT INPUT METHODS

Mode

[0]

[#]

Space

Clear

Left, Right

Switch

Press to change text input mode: [T9TMAbc][123][Sym]. Select [T9TMAbc] for predictive text input.

Press to view the next matching word if the underlined word is not the word you intended.

Press once to accept a word and add a space.

Press once to delete the character to the left of the cursor.

To move cursor.

To switch between lowercase to uppercase letters:

[ABC][Abc]

[abc][T9TMABC][T9TMAbc][T9TMabc].

KEY FUNCTION

T9TMPREDICTIVE TEXT MODE [T9TMABC]

To choose T9TMmode, press [MODE] then choose [T9TMABC]. This mode predicts the words you are entering using a built-in dictionary. With T9TMpredictive text input, you press

each key only once for each letter. The chart below

outlines

how to use T9TMtext input.

Page 34 - Chapter 3

SPEED DIALING

ONE-TOUCH/TWO-TOUCH DIALING

Ideal for frequently dialed numbers, this feature allows phonebook entries to be dialed via the keypad with only one or two key presses.

ONE-TOUCH DIALING:

1-9 : Press the corresponding memory number and hold

for more than 1 second.

TWO-TOUCH DIALING:

10-20 : Press the first digit and second digits of the

memory number short and long respectively.

●

If no phone number is stored in the location

entered, “There is no number” will appear on the screen.

●

If a phone number is stored in secret, you must enter

the password to make a call.

NOTE:

See page 46 for information about saving a phone

number in a speed dial location.

Chapter 3 - Page 37

NUMERIC MODE [123]

Numeric mode allows you to add a number to your entry/message. To select numeric mode, press [MODE] then select [123].

TEXT INPUT METHODS

SYMBOL MODE [SYM]

Select symbol mode allows you to add various symbols to your entry . Whether you are adding an e-mail address to your phonebook or sending an expressive message, symbols make these entries easier. To select symbol mode, press [MODE] then choose [SYM]. The symbols will appear on the display. The corresponding key number for that symbol will appear as well. You can press the key to select the symbol or use the navigation key to highlight the symbol, then press . To move to the next screen of symbols press .

Page 36 - Chapter 3

INCOMING CALLS

1. To view the 10 most recently answered calls, press .

The most recent call will be listed first.

2. Use the navigation key to scroll through the list of answered calls, then select the desired number. To view call details, press .

●

Detail information includes the phone number, its log number, time and date of the call.

3. To dial the number, press .

To delete the number, press . To save the number, press .

You can add a prefix or simply store the number as is.

CALL LOGS

OUTGOING CALLS

1. To view the 10 most recently dialed numbers, press . The most recent call will be listed first.

2. Use the navigation key to scroll through the list of dialed calls, then select the desired number. To view call details, press .

●

Detail information includes the phone number, its log number, time and date of the call.

3. To dial the number, press .

To delete the number, press . To save the number, press .

You can add a prefix or simply store the number as is.

Chapter 3 - Page 39

CALL LOGS

The CDM-8500 keeps a log of the 10 most recently missed, answered (incoming) and dialed (outgoing) calls. Log information includes the phone number and the date and time of the call.

Page 38 - Chapter 3

Chapter 3 - Page 41Page 40 - Chapter 3

CALL LOGS

MISSED CALLS

1. To view the 10 most recently missed calls, press . The most recent call will be listed first.

2. Use the navigation key to scroll through the list of

missed calls, then select the desired number. To view call details, press .

●

Detail information includes the phone number, its log number, time and date of the call.

3. To dial the number, press .

To delete the number, press . To save the number, press .

You can add a prefix or simply store the number as is.

CALL TIMES

LAST CALL

To display the total time of your last call:

1. Press .

ALL CALLS

To display the total time of all your calls:

1. Press .

HOME CALLS

To display the total time for calls placed within your home area:

1. Press .

ROAM CALLS

To display the total time for calls placed outside your home area:

1. Press .

ACCUMULATE CALLS

To display talk time of accumulated calls:

1. Press .

Chapter 3 - Page 43Page 42 - Chapter 3

USING YOUR PHONEBOOK

EDITING YOUR PHONEBOOK

You can add, edit, or erase phone numbers in the phonebook.

RECALLING BY PHONE NUMBER

Recall saved phone numbers by searching for the location number. Search results include the name and phone number saved to that location.

1. Press .

2. Enter the phone number or partial phone number & press .

All numbers matching the entered numbers will

appear. Use the navigation key to select the desired numbers and press .

3. To dial the selected number, scroll to that number in the entry and press .

ADD NEW ENTRY

1. To add a new entry to the phonebook, press .

2. Use the navigation key to move to a phonebook

field entry and enter the required information.

3. To save it press . To return to the previous page,

press .

See page 32 for complete add new entry instructions.

RECALLING BY GROUP

1. Press .

2. Select one of the options (Family, Friends, Work, Etc, All) with the navigation key then press .

3. All the entries under the group will appear. You can delete the entry by pressing or view the entry by pressing ok icon when it is selected.

4. To call the selected number, press icon,

select which number for the entry you want to call & press .

RECALLING BY NAME

1. Press .

2. Enter a name or partial name then press to

display names in the phonebook using that name or characters in alphabetical order, regardless of letter case. (Please refer to page 33 about the usage of

Alpha Editor)

3. All matched entries appear. Delete an entry by pressing or view an

entry by pressing .

4. To call one of the numbers for the selected entry, select the number to dial and press .

USING YOUR PHONEBOOK

Chapter 3 - Page 45Page 44 - Chapter 3

USING YOUR PHONEBOOK

CHANGE GROUP BELL

1. To change a group bell, press .

2. Select the group whose bell is to be changed & press .

Use the navigation key to select one of the bell options.

4. To save it, press .

CHANGE GROUP COLOR

1. To change a group color, press .

2. Select the group whose color is to be changed & press .

Use the navigation key to select one of the group colors.

4. To save it, press .

CHANGE GROUP NAME

1. To change a group name, press .

Use the navigation key to select an existing group name &

press .

3. Input a new name.

4. To save it, press .

EDIT GROUP

Adds, changes and deletes a group.

USING YOUR PHONEBOOK

ADD NEW GROUP

1. To add a new group, press . A maximum of 7 groups is allowed.

2. Input a new group name.

3. To save, press .

EDIT EXISTING ENTRY

1. To edit an existing entry, press .

The 5 entry groups appear – Family, Friends, Work, Etc., All.

2. Use the navigation key to select one of the groups

& press .

3. Select an entry under the group. To view or edit the

entry, press . To delete the entry, press .

Chapter 3 - Page 47Page 46 - Chapter 3

SPEED DIAL

Links a phone number of phonebook entry to a location number and enables you to make a call simply by pressing its location number in the idle mode.

1. Press .

2. To link a phone number to the location, select the

location then press . If a phone number already exists in the location, press then the navigation key to delete it.

3. Select the group where the phone number is saved,

then press .

4. Select the entry, then press .

5. Select the phone number, then press .

USING YOUR PHONEBOOK

CLEAR GROUP

1. To delete an existing group, press .

2. Use the navigation key to select the group to be

deleted & press .

3. If a phone number already exists in the location,

press , then to delete it.

4. To reconfirm, press .

MY PROFILE

Saves and edits your personal information.

1. To review and edit your personal information (Name, My phone number, Birthday, Blood Type, Address,

Home Number, E-Mail, Work Phone Number, Memo,

Set Secret), press .

2. To edit a selected item, press .

3. To confirm and save, press .

To Select the “Blood type”(A/B/AB/O) with the navigation key.

This chapter addresses customizing your phone by adjusting backlighting, volume, ring tones and other user-friendly features.

Roaming Setting VR Mode VS Menu

Chapter 4

SETTINGS

Chapter 4 - Page 49Page 48 - Chapter 3

MEMO

Chapter 4 - Page 51Page 50 - Chapter 4

Scans the channels to stay connected to any available system.

SET MODE

Selects the Preferred System.

1. Press .

2. Select one of the following options (Automatic A/ Automatic B / Home Only) with the navigation key, then press .

FORCE ANALOG

Temporarily forces phone to use Analog mode – mode automatically ends in 10 minutes.

1. Press .

2. Select “Yes” or “No” with the navigation key, then press to activate it.

ROAMING

NAM SETTING

Enables Auto NAM (Number Assignment Modules) or manually changes a NAM.

ROAMING

AUTO NAM

To automatically switch phone to the proper NAM when you have multiple NAM registrations:

1. Press .

2. Select “Yes” or “No”, then press to save it.

CHANGE NAM

To change the NAM used by the phone when you have multiple registrations:

1. Press .

2. Select a NAM (NAM1,NAM2) with the navigation key, then press to save it.

● Automatic : Scans the radio channels based on the

Automatic setting. – read description for

Auto A & Auto B.

● Home Only :

Force phone to use the only home system.

Page 52 - Chapter 4 Chapter 4 - Page 53

ROAMING

PRL ID

To display the phone’s PRL (Preferred Roaming List):

1. Press .

SETTING

SOUNDS

You can choose different Ringer Type, Ringer Mode, Volume, Alert, Roam Ringer and Tone length.

RINGER TYPE

Selects a ringer type to alert you of an incoming call.

1. Press .

2. Select a ringer type from the 30 melodies and

10 Ringtones.

3. To confirm, press .

RINGER MODE

Alerts you to incoming calls in the following modes:

1. Press .

2. Select one of the following options with the navigation key .

●

Ringer

●

Vibrate

●

Ringer after Vibrate – The ringer sounds after

vibration.

●

Silent – Mutes the ringer

3. To confirm, press .

PRL ID

XXXX

OK CNCL

SETTING

VOLUME

Controls the volume of the following items. The volume can be adjusted to 5 levels.

RINGER

Controls the Ringer volume.

1. Press .

2. Adjust the ringer volume with the navigation key.

3. To save, press .

KEY

Controls the keypad tone.

1. Press .

2. Adjust the keypad tone with the navigation key.

3. To save, press .

VOICE CALL

Controls the earpiece volume

1. Press .

Adjust the earpiece volume with the navigation key.

3. To save, press .

Chapter 4 - Page 55Page 54 - Chapter 4

SETTING

ALERT

Sounds an alert to any change occurring on the phone.

MINUTE ALERT

Sounds an alert every minute of a phone call.

1. Press .

2. Select “OFF” or “ON” with the navigation key, then

press to save it.

ROAM ALERT

Sounds an alert when leaving a service area and entering a roaming service area.

1. Press .

2. Select “OFF” or “ON” with the navigation key, then

press to save it.

CONNECT ALERT

Notifies you that a call has been successfully placed.

1. Press .

2. Select “OFF” or “ON” with the navigation key, then

press to save it.

SETTING

FADE ALERT

Sounds an alert when entering an area where calls cannot be made due to weak signal strength. The alert sounds is made when the call is disconnected.

1. Press .

2. Select “OFF” or “ON” with the navigation key, then press to save it.

LOW SIGNAL ALERT

Sounds an alert when you encounter low signal strength during a call and in standby mode.

1. Press .

2. Select “OFF” or “ON” with the navigation key, then press to save it.

Chapter 4 - Page 57Page 56 - Chapter 4

SETTING

ROAM RINGER

Reminds you that you are in a roaming service area, by sounding a different ringer from what you set as voice call in Ringer type.

1. Press .

2. Select “Distinctive” or “Normal” with the navigation key, then pr es s to sa ve it .

TONE LENGTH

Adjusts the tone length.

1. Press .

2. Select “Normal” or “Long” with the navigation key, then p re s s t o s av e i t.

● Distinctive : Sounds a different ringer type.

● Normal : Sounds the same ringer type as used in Home

area.

DISPLAY

Customizes and personalizes the display.

ANIMATION SETTING

Selects your favorite LCD display in the following modes:

IDLE DISPLAY

1. Press .

2. Select one from the Animation List to use in the idle mode by using the navigation key.

3. To save, press .

POWER ON

1. Press .

2. Select one from the Animation List to use in the power on mode by using the navigation key.

3. To save, press .

SETTING

Chapter 4 - Page 59Page 58 - Chapter 4

SETTING

POWER OFF

1. Press .

2. Select one from the Animation List to display when you turn off the handset by using the navigation key.

3. To save, press .

MAIN DISPLAY SETTING

Selects your favorite LCD display in the following modes

GREETING INPUT

To edit the greeting press the navigation key.

1. Press .

2. To edit the greeting press .

3. Input your personal greeting, using the Alpha Editor.

4. To save, press .

SETTING

IDLE CLOCK

To select an LCD clock display:

1. Press .

2. Select one of the following options:

●

Digital Clock

●

Analog Clock

●

Greeting Clcok

●

Animation+Clock

3. To save, press .

LCD SETTING

Controls backlight and LCD contrast for better view and more efficient use.

BACKLIGHTING

Backlights the display and keypad for easy viewing in dark places.

1. Press .

2. Select one of the following options: 5 secs, 10 secs, 20 secs, Off.

3. To save, press .

Chapter 4 - Page 61Page 60 - Chapter 4

SETTING

CONTRAST

The LCD display contrast can be adjusted to 5 levels.

1. Press .

2. Adjust the LCD contrast for better view.

3. To save, press .

LCD COLOR

To select an LCD display backlight color.

1. Press .

2. Select one of the following options: Automatic, Red, Green, Yellow, Blue, Deep Green, Purple, White.

3. To save, press .

● Off: Turns the backlight off

● 5 secs, 10 secs, 20 secs : Backlight remains on for 5, 10,

or 20 seconds after touching the keypad.

When Automatic is selected, the LCD backlight color will change to a different color (one of the seven colors) everytime you open and close the phone.

NOTE:

They keypad backlight color does not change.

It is always blue.

SETTING

Chapter 4 - Page 63Page 62 - Chapter 4

SETTING

SUB LCD SETTING

Controls backlight and Sub LCD contrast for better view and more efficient use.

SUB LCD CLOCK

To select a Sub LCD clock display:

1. Press .

2. Select one of the following options: Analog Clock, Digital Clock.

3. To save, press .

SUB LCD CONTRAST

The Sub LCD display contrast can be controlled in 5 levels.

1. Press .

2. Adjust the Sub LCD contrast for better view.

3. To save, press .

OTHERS

ANSWER MODE

Selects an Answer mode.

1. Press .

2. Select “Any Key” or “Send Key” with the navigation key.

3. To save, press .

ACTIVE FLIP

Selects an Active Flip Answer mode as follows.

1. Press .

2. Select “On” or “Off” with the navigation key

3. To save, press .

● Any Key : Press any key to answer an incoming call

except , , and .

● Send Key : Press only to answer a call.

NOTE:

When Active Flip on is selected, an incoming phone call can be answered simply by opening the phone. When Active flip off is selected, you will need to open the phone & follow the Answer Mode you have selected.

Chapter 4 - Page 65Page 64 - Chapter 4

SETTING

AUTO RETRY

Automatically retries a call up to 5 times after a set time interval.

RETRY TIME

1. Press .

2. Select a time interval option (Off, 3, 5, 7, 10 seconds) with the navigation key.

3. To save, press .

REPEAT

1. Press .

2. Select one of the options (1 time, 3 times, 5 times)

with the navigation key.

3. To save, press .

AUTO ANSWER

Automatically answers a call after a preset number of rings. An ideal setting for the hands-free car kit.

1. Press .

2. Select one from the following items (off, 5, 10, 18 seconds) with the navigation key.

3. To save, press .

VOICE PRIVACY

Enhances voice privacy and avoids tapping during a call.

1. Press .

2. Select “Standard” or “Enhanced”, if available.

3. To save, press .

This feature is system dependent. Please contact your service

provider for availability.

NOTE: This function will not be activated when you

select Vibrate, Silent, or Ringer after vib as a ringer mode.

● Enhanced : Makes it more difficult to wire tap.

Chapter 4 - Page 67Page 66 - Chapter 4

SETTING

LANGUAGE

Selects the language in which letters are displayed on screen.

1. Press .

2. Select “English” or “Spanish”.

3. To save, press .

WEB IDLE TIME

This function disconnects your phone from a network when there is no key input for a certain time period.

1. Press and set the web idle timer.

2. Use the navigation key to set the web idle timer or press digit keys to enter the time on your own.

S/W VERSION

Displays the version of your phone.

1. Press .

2. The version of the software and hardware appears.

UP PROXY IP

To access your service provider’s website the phone can have up to 3 sets of the server IP (Internet Protocol) addresses and Port numbers. These may already be preset or be separately programmed by your service provider. Please note that any change to these settings may disable the Web access capability.

1. Press .

Chapter 4 - Page 69Page 68 - Chapter 4

VR MODE

Voice Recognition (VR) enables you to place calls and record voice memos using your voice.

1. Press and hold until your phone turns to VR mode.

2. When the phone turns to VR mode, the screen on the right appears.

NAME

1. Press and hold and wait until your phone turns to VR mode.

2. In VR mode, say a recorded name or tag stored in the

phonebook, and the name and number will appear on

the display and you will hear “Calling <name>.”

See page 78 for additional details.

NOTE: Depending on the prompt mode – expert or beginner

-- you will hear a different set of prompts as listed below. The second prompt will automatically play if nothing is said.

Beginner Mode

- 1

: “Main Menu”

- 2nd: “Speak a name to call, or say dial, redial, voice memo, phonebook or cancel”.

Expert Mode

- 1st: “beep”

- 2nd: “Main Menu”

Once you say one of the following options. You will go through each of the procedures (name, dial, redial, voice memo, phonebook, cancel).

Say a name

or a command

VR Mode

DIAL

1. Press and hold until your phone turns to VR mode.

2. Say “Dial” and the display on the

right will appear.

3. Press or say the digits of the phone number.

4. After entering the entire number, say “Call”.

REDIAL

1. Press and hold until your phone turns to VR

mode.

2. To call the last dialed number, say “Redial”.

NOTE: Beginner mode

- 1stprompt :“Digit menu”

- 2ndprompt :“Say digits or verify, cancel, clear, or call”.

Expert mode

- 1stprompt :“doo-doo” (a sequence of high and low tones).

- 2ndprompt :“Digit menu”

Depending on the prompt mode, expert or beginner,you will hear a different set of prompts that follows. You can hear the second prompt when nothing is said.

Say digits one at

a time, or command

Digit Dial

Chapter 4 - Page 71Page 70 - Chapter 4

VR MODE

CANCEL

1. Press and hold until your phone turns to VR mode.

To exit VR mode or return to the standby mode, say “Cancel.”

VOICE MEMO

This feature is the same as on page 72, except you must use the phone to access the menu not your voice.

1. Press and hold until your phone turns to VR mode.

2. Say “Voice Memo” instructions will appear and you

will hear “Please record it at the tone”.

3. To stop recording, press .

4. After recording a voice memo you can REVIEW, RE-RECORD or SAVE.

PHONEBOOK

1. Press and hold until your phone turns to VR mode.

2. Say “Phonebook”.

NOTE: Press to pause, then press to resume.

Phonebook entries with voice tags will appear and each voice tag will play.

NOTE: To call a phone number with an attached voice

tag, say “Yes” while the voice tag plays.

Chapter 4 - Page 73Page 72 - Chapter 4

VS MENU

CALL ANSWER

Sets and operates the answering machine.

1. Press .

2. Press .

3. Select one of the following options with the navigation key, then press .

ON/OFF : Turns the Auto Answering machine on/off. INBOX : Play or erase a recorded memo. CALL SPEAKER ON (OFF) : You can(not) hear the caller’s

voice being recorded in the answering machine.

WAIT TIME : No Ringer, 5s, 10s, 18s. The answering

machine will be operated in a specific time.

ICONS IN THE STORED MEMO LIST

: Unchecked recorded memo in Answering machine.

: A recorded memo in Answering machine that you have

already checked.

✓

NOTE: RECORDING LIMITATION : You have a limit of 10 voice memos including those in Answering Machine. Each voice memo has the time limit of 60 seconds.

Answering Machine plays preprogrammed greeting. This cannot be changed.

1. To start VS menu, press .

2. To enter the voice memo menu, press .

3. When you press to record a voice memo, instructions will appear and you will hear “Please record it at the tone”.

4. To stop recording a memo, press .

5. After recording a voice memo you can REVIEW,

RE-RECORD or SAVE.

VOICE MEMO

1. To start VS menu, press .

2. To enter the voice memo menu, press .

3. To play the voice memo menu, press , select the desired voice memo, press .

RECORD VOICE MEMO

PLAY VOICE MEMO

NOTE: Press to pause, then press to resume.

NOTE: Edit Key - To edit the voice memo title.

CLR Key - To delete the selected voice memo.

1. To start VS menu, press .

2. To enter the voice memo menu, press .

3. To delete a voice memo, press .

CLEAR ALL

Chapter 4 - Page 75Page 74 - Chapter 4

VS MENU

VOICE COMMAND

Trains the VR with the following categories of control words:

YES/NO

1. Press .

2. Press .

3. Select one of the following options with the navigation key, then press .

LIST WORDS : Displays the list of control words in the

Yes/No set. Select a control word from the list then press . Either train, untrain or view its status. To train a word, press

and follow the voice prompts. TRAIN ALL : Train Yes/No set to recognize your voice. UNTRAIN ALL : Untrain Yes/No set not to recognize trained

control words.

WAKE UP

Use the Wake-Up to train or untrain the VR with the control word, wake up.

1. Press .

2. Press .

3. Select one of the following options with the navigation key, then press .

LIST WORDS : Displays the list of control words in the wake

up set. Select a control word from the list then press . Either train, untrain or view its status. To train a word, press and

follow the voice prompts. TRAIN ALL : Train Wake-up set to recognize your voice. UNTRAIN ALL : Untrain Wake-up set not to recognize

trained control words.

Chapter 4 - Page 77Page 76 - Chapter 4

VS MENU

TOP LEVEL

Use the Top Level to train or untrain the VR with your control words. (Dial, Redial, Voice Memo, Phonebook, Cancel).

1. Press .

2. Press .

3. Select one of the following options with the navigation key, then press .

LIST WORDS : Displays the list of control words in the top

level set. Select a control word from the list then press . Either train, untrain or view its status. To train a word, press

and follow the voice prompts. TRAIN ALL : Train Top level set to recognize your voice. UNTRAIN ALL : Untrain Top level set not to recognize

trained control words.

DIGIT DIAL

Use the Digit dial to train or untrain the VR with the control words (1 to 9, Zero, Oh, Verify, Clear, Call).

1. Press .

2. Press .

3. Select one of the following options with the navigation key, then press .

LIST WORDS 1, 2 : Displays the list of control words in the

digit dial set. Select a control word from the list then press . Either train, untrain or view its status. To train a word, press and follow the

voice prompts. TRAIN ALL : Train Digit dial set to recognize your voice. UNTRAIN ALL : Untrain Digit dial set not to recognize

trained control words.

Chapter 4 - Page 79Page 78 - Chapter 4

VS MENU

VOICE DIAL

Lists, adds and erases voice tags for phonebook entry

LIST

1. Press .

2. To list phonebook entries with attached voice tags, press .

3. Select one with the navigation key, then press .

4. Press to play a voice tag or to edit an existing voice tag.

5. Select one of the following options, then press .

EDIT : Retrain / Voice Setting / Clear PLAY : Play voice tag.

1) Retrain: “Retrain Voice Name?” appears. Press , then say a name.

2) Voice Setting: “Change?” appears. Press , select a

phone number, then press again.

3) Clear: “Removing Voice Names Proceed?” appears.

Press .

ADD

1. Press .

2. To add a voice tag to phonebook entry, press .

Select one group with the navigation key , then press .

4. Select a phone number with the navigation key, then

press .

5. To add a voice tag to the number, say the name.

CLEAR ALL

1. Press .

2. To erase all voice tags in the list, press .

3. “Removing all voice tags proceed?” appears.

4. Press and you will see a message.

5. To clear all voice tags, press .

OK : Proceed to erase all the voice tags. CNCL : Return to the previous page.

Chapter 4 - Page 81Page 80 - Chapter 4

VS MENU

VOICE ALERT

Sets the voice alert service.

ON/OFF

1. Press .

2. Press .

Select “On” or “Off” with the navigation key, then press .

RECORD

1. Press .

2. Press .

3. Record voice alert.

PLAY

1. Press .

2. Press .

3. Confirm voice alert.

CLEAR

1. Press .

2. Press .

Select “Yes” or “No” with the navigation key, then press .

VOICE SETTING

Customizes the voice service menu.

UNTRAIN ALL

1. Press .

2. Press .

Select “Yes” or “No” with the navigation key, then press .

PROMPT MODE

Use the prompt mode to select either beginner or expert mode. The expert mode consists of shorter texts and just beeps as opposed to the beginner mode that gives full instructions.

1. Press .

2. Press .

3. Select Beginner/Expert with the navigation key.

Press .

<Beginner mode> 1stprompt : “Main menu” followed by a short beep. 2ndprompt : “Speak a name to call, or say dial, redial, voice

memo, phonebook, or cancel”, followed by a short beep.

<Expert mode> 1stprompt : A sequence of high and low tones. 2ndprompt : “Main menu”.

NOTE: The VR times out and the phone returns to the standby mode after the 1st and 2nd prompts are heard and nothing is said.

VS MENU

Chapter 4 - Page 83Page 82 - Chapter 4

DIGIT MODE

Use the digit mode to select one of the following options ; ECHO, BEEP, ECHO+BEEP.

1. Press .

2. Press .

3. Select one option with the navigation key, then press .

HFK MODE

HFK stands for Hands-Free Car Kit. With this function, you can activate and utilize the VR feature when the phone is in hands-free car kit.

1. Press .

2. Press .

3. Select “Off” or “On” with the navigation key, then press .

ECHO: Digit echoes back when entered. BEEP: Digit beeps when entered. ECHO + BEEP: Digit echoes and beeps when entered.

NOTE: Once you say “Wake Up” and the phone

recognizes your voice, you will hear a beep. The second time you say “Wake Up”, your phone turns to VR mode.

VS MENU

SET ACTIVE

1. Press .

2. Press .

3. Select “Send Key” or “Active Flip” with the navigation key, then press .

This chapter addresses security features including locking and unlocking the phone, restricting calls and clearing the phonebook.

Chapter 5

SECURITY

FEATURES

Chapter 5 - Page 85Page 84 - Chapter 4

MEMO

SECURITY FEA

TURES

Chapter 5 - Page 87

SECURITY FEA

TURES

Page 86 - Chapter 5

INCOMING CALL

Blocks all incoming calls but allows outgoing calls to be placed.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict”

with the navigation key.

3. To save, press .

OUTGOING CALL

Blocks all outgoing calls except emergency calls from being placed, but allows incoming calls to be answered.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict”

with the navigation key.

3. To save, press .

SECURITY

Prevents others from using the phone without permission and allows access to security features only after inputting your password.

RESTRICT

Enables you to restrict certain features with the password. You are to unlock the phone to use the features.

AUTOMATIC LOCK

Prevents others from using your phone without permission. When locked, the menu cannot be accessed without password.

1. Press then enter “PASSWORD.”

2. Press then select “Off”, “Lock Now” or “Lock On Power Up”.

3. To save, press .

● Off : Do not lock the phone.

● Lock Now : Lock the phone now.

● Lock On Power Up : Lock the phone whenever it is

turned on.

● Restrict : Restrict an incoming call.

● Allow : Allow an incoming call

● Restrict : Restrict an outgoing call.

● Allow : Allow an outgoing call.

SECURITY FEA

TURES

Chapter 5 - Page 89

SECURITY FEA

TURES

Page 88 - Chapter 5

PHONEBOOK

Blocks access to, and protects data in your phonebook.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

DATA CALL

Restricts data calls from being placed.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

INCOMING CALL HISTORY

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

OUTGOING CALL HISTORY

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

Blocks access to the menu to prevent any changes.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

● Restrict : Restrict access to incoming call history.

● Allow : Allow access to incoming call history.

● Restrict : Restrict access to the phonebook.

● Allow : Allow access to the phonebook.

● Restrict : Restrict a data call.

● Allow : Allow a data call.

● Restrict : Restrict access to the outgoing call history.

● Allow : Allow access to the outgoing call history.

● Restrict : Restrict access to the menu.

● Allow : Allow access to the menu.

SECURITY FEA

TURES

Chapter 5 - Page 91

SECURITY FEA

TURES

Page 90 - Chapter 5

SPECIAL #’s

Stores 3 phone numbers to allow to be dialed even in rock mode.

1. Press then enter “PASSWORD.”

2. Press then select one from three blanks with the navigation key

3. Press and input a phone number

4. Press again to save it.

CLEAR PHONEBOOK

Clears all phonebook entries.

1. Press then enter “PASSWORD.”

2. Press .

3. Select “Yes” or “No” with the navigation key.

Press .

900#S

Restricts calling 900 dial service numbers.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

LONG DISTANCE

Restricts calling long distance numbers – the phone is limited to calling numbers within the area.

1. Press then enter “PASSWORD.”

2. Press then select “Allow” or “Restrict” with the navigation key.

3. To save, press .

NOTE: “This phone is restricted” appears on the display

when you attempt to make a restricted call.

NOTE: The default password is the last 4 digits of your

phone number.

NOTE: A phone number over 8 digits is restricted.

● Restrict : Restrict a 900-dial service.

● Allow : Allow a 900-dial service.

● Restrict : Restrict a long distance call.

● Allow : Allow a long distance call.

This chapter addresses supplemental functions including the schedule, calculator, clock and stopwatch features.

Schedule Calculator World Clock Stopwatch

Chapter 6

SUPPLEMENTARY

FUNCTIONS

SECURITY FEA

TURES

Page 92 - Chapter 5

RESET PHONE

Resets phone to default settings.

1. Press then enter “PASSWORD.”

2. Press .

3. Select “Yes” or “No” with the navigation key.

Press .

CHANGE PASSWORD

Changes password.

1. Press then enter “PASSWORD.”

2. Press .

3. Enter a new password, then press .

4. Enter the new password again, then press .

NOTE: The default password is the last 4 digits of your

phone number.

Chapter 6 - Page 93

● When you select “Yes”, “Powering off Good bye!”

appears and the phone will automatically reboot.

Chapter 6 - Page 95Page 94 - Chapter 6

Reminds you of a previously scheduled event or anniversary with an alarm.

EVENT

1. To display a calendar, press .

2. Use the navigation key to choose a date in the

calendar, then press .

3.1. To set a time for an event, press .

3.2. To set a melody for the event, press .

3.3. To set a message for the event, press .

4. Press to save it or to return to the calendar.

5. “Save complete” appears. When you return to the

calendar the day will be highlighted.

SCHEDULE

ALARM

1. To display three alarm entries, press .

2. Select one of the entries with the Navigation key.

3. To edit the existing alarm or set a new alarm, press . To delete the existing one, press .

4.1. To set a time, press .

4.2. To set a melody, press .

Select one, then press .

4.3. To set a message, press .

4.4. To set a snooze, press .

Select one, then press .

SCHEDULE

● Day to Day movement: Press the navigation key left and

right.

● Week to Week movement: Press the navigation key

down and up.

● Choose an alarm frequency. (Once, Daily, Weekly,

Monthly, Yearly) with the Navigation key . To save, press .

● Choose one of the following in the first line (On time, 10

Min before, 30 Min before, 1 Hour before, No alarm)

● To change the date and time in the second line by moving

to year, month, day, time input with the navigation key.

WORLD CLOCK

Displays the time in a pre-programmed specific city.

1. Press then for WORLD CLOCK.

2. Select a city with the navigation key.

3. The world map appears with the city, its date and

time. Select another city using the navigation key.

4. Press to return to the Tools Menu.

Chapter 6 - Page 97Page 96 - Chapter 6

CALCULA

TOR

CALCULATOR

Allows you to use the CDM-8500 as a calculator to perform basic mathematic functions (addition, subtraction, multiplication, division).

1. Press then for CALCULATOR.

2. Use the keypad to enter the numbers to be calculated.

3. Follow the instructions below to calculate (8*6)/4-2.5

●

Input 8 Move the navigation key left Input 6 and press the navigation key Move it right Input 4 and press the navigation key Move it down Input 2 and press to input(.) Press 5, then .

4. To reset, press .

NOTE: 1. Up to 10 integer digits and up to 2 decimals

can be displayed. If the calculated result has more than 10 digits, the result is displayed in 10 digit logarithm.

2. There is no (-) sign. To express a negative number, use ‘0-value’.

This chapter addresses checking voice mail messages, as well as sending and receiving text messages.

Two-Way SMS Checking Messages Sending Text Messages Inbox Outbox Filed Erase All Settings

Chapter 7

VOICE MAIL AND

TEXT MESSAGES

Page 98 - Chapter 6 Chapter 7 - Page 99

STOPW

STOPWAA

TCH

STOPWATCH

Allows you to use your phone as a stopwatch. The stopwatch displays time in hours, minutes, seconds, and 1/100 of a second.

1. Press then for STOPWATCH.

2. To measure a time period.

●

To start the stopwatch, press .

●

To pause it, press .

●

To reset it, press .

●

Press to resume it or to return to the previous page.

3. To measure more than one timed event:

● To start, press .

● To stop a time period and continue measuring another

one, press .

● To stop the second and continue measuring a third one,

press .

● And keep repeating the above to measure up to 6 time

periods.

● Press to stop it and to view the results.

● Press or to return to the stopwatch.

● To reset it, press .

CHECKING MESSAGES

CHECKING RECEIVED VOICE MAIL MESSAGE

1. Press , then press for Voice Mail.

2. The number of voice mail messages currently waiting in your mailbox appears. To access your voice mailbox, press .

CHECKING RECEIVED TEXT MESSAGE

1. Press , then press “Inbox”.

2. Highlight the message you want to view and press

. The text message is displayed.

3. To view the inbox message menu, press then you

can reply, erase, forward, save, save address, lock &

unlock the message.

Chapter 7 - Page 101

RECEIVED MESSAGE NOTIFICATION

When your phone receives a message, the screen displays the number of new text messages and voice mail messages.

1. T o display the received message, press the key under .

TWO-W

TWO-WAA

Y SMS

Your CDM-8500 features Two-Way Short Message Service (SMS). This feature sends and receives text messages through your phone. Voice mail notification is also supported.

: Text Message : Voice + Text Mail Message : Voice Mail Message

MESSAGE INDICATORS

The following symbols indicate the status of message received by your phone. These symbols appear for voice mail and text messages.

Page 100 - Chapter 7

EDIT MESSAGE

1. To change the text message, press

“EDIT MESSAGE”.

2. Input text message, then press .

PRIORITY

1. To send an urgent message, press “PRIORITY”.

2. Select the priority (NORMAL/URGENT) by using the navigation key, then press .

CALL BACK

1. To change the call back number, press “CALL BACK”.

2. Input call back number, then press .

SAVE

1. To save the text message, press “SAVE”.

SENDING TEXT MESSAGES

Chapter 7 - Page 103

SENDING TEXT MESSAGES

SENDING NEW TEXT MESSAGES

1. Press then press “SEND NEW”.

2. Input phone number, then press .

3. Input the text message, then press to display the send new menu.

NOTE:

If the message failed to reach the other party, the display will read “Delivery Failed. Retry

in 3 mins?”. Press YES to have the phone

automatically send the message again.

SEND

1. To send the text message, press or “SEND”.

EDIT RECIPIENT

1. To change the recipient, press “EDIT RECIPIENT”.

2. Input the phone number, then press .

Page 102 - Chapter 7

REQUEST DELIV. ACK

1. To be notified that the recipient received your message, press “REQUEST DELIVERY ACK”.

LOCK & UNLOCK

1. To lock or unlock the text message, press

“LOCK/UNLOCK”.

2. Select LOCK to lock the message or UNLOCK to unlock the message, then press .

SAVE ADDRESS

1. To save the Callback number from the text message, press “SAVE ADDRESS”.

2. To save the call back number into a memory location, follow the procedures for STORING PHONE NUMBERS on page 32.

INBOX

Chapter 7 - Page 105

ERASE

1. To erase the text message, press “ERASE”.

2. To erase the message from your Inbox, press .

SAVE

1. To save the text message in your phone, press “SAVE”.

INBOX MENU

To enter the INBOX menu, follow the procedures for CHECKING RECEIVED TEXT MESSAGES on page 101.

1. To reply to the text message, press “REPLY”.

2. Enter your message, then press .

INBOX

FORWARD

1. To forward the text message, press “FORWARD”.

2. Input the phone number of the person you will send the message, then press .

3. Input any text message to go along with the forwarded message, then press .

Page 104 - Chapter 7

OUTBOX

SAVE

1. To save the message, press “SAVE”.

2. Press .

STATE

1. To display the state of the sent message, press .

Chapter 7 - Page 107

OUTBOX

RESEND

1. To send the message again, press “RESEND”.

ERASE

1. To erase the message, press “ERASE”.

2. Select “Yes” or “No” with or .

OUTBOX MENU

1. To enter the OUTBOX menu, press then “OUTBOX”.

2. Select the stored message then press . The text message will be displayed then .

3. To enter the OUTBOX menu, press then you can resend, erase, send to, save, and display the message state.

Page 106 - Chapter 7

SEND TO

1. To send the message to the other person, press “SEND TO”.

2. Input the phone number, then press .

3. Modify the message, then press to display the "Send New Message" menu.

Chapter 7 - Page 109

Page 108 - Chapter 7

FILED

When there is the saved message from the Inbox/Outbox.

1. Press and . Select a text message with the

navigation

key.

Press .

2. The text message appears. Press to display OPTS.

3. If the text message is saved from “Inbox” menu, this screen will be displayed.

If the text message is saved from “Outbox ” menu, this screen will be displayed.

4. Select one by pressing .

1: Reply 2: Erase 3: Forward 4: Save Address

Filed Option

OK CNCL

1: Resend 2: Erase 3: Send to 4: State

Filed Option

FILED

ERASE ALL

ERASE MESSAGES

1. Press and .

2.1. To erase messages in the Inbox, press .

2.2. To erase messages in the Outbox, press .

2.3. To erase messages in the Filed, press .

3. Select “Yes” by pressing . Select “No” by pressing .

NOTE:

Select “Entire Inbox” or “Old Inbox”.

Chapter 7 - Page 111

Page 110 - Chapter 7

SETTINGS MENU

1. To enter the SETTINGS menu, press then “SETTINGS”.

SAVE SENT MESSAGE

1. Press “SAVE SENT MSG?”.

2. Select (NO/YES/PROMPT) using the navigation key, then press .

DEFAULT CALLBACK

1. Press “DEFAULT CALLBACK”.

2. Input the Callback number, then press .

ALERT

1. Press “ALERT”.

2. Select the alert type (RINGER/VIBRATE/SILENT/

RINGER & REMIND/VIBRATE & REMIND) using the

navigation key, then press .

SETTINGS

AUTO ERASE

1. Press “AUTO ERASE”.

AUTO ERASE INBOX

1. Press .

2. Select (DISABLE/OLD INBOX) using the navigation key, then press .

AUTO ERASE OUTBOX

1. Press .

2. Select (DISABLE/OLD OUTBOX) using the navigation key, then press .

ENTRY MODE

1. Press “ENTRY MODE”.

2. Select (ALPHA MODE/T9 MODE) using the navigation key, then press .

DISPLAY DELIV.ACK

1. Press “DISPLAY DELIVERY ACK”.

2. Select (NO/YES) using the navigation key, then press .

Chapter 8

MAKING AN

EMERGENCY CALL

Chapter 8 - Page 113Page 112 - Chapter 7

MEMO

This chapter addresses using your handset to access the Wireless Internet.

Start Internet Browser Browser Menu

Chapter 9

INTERNET

BROWSER

Chapter 9 - Page 115

E911 CALLING

Allows you to place emergency calls, even when the phone is locked. Emergency calls are placed on any available system.

1. Enter 911 and press .

2. The call will connect.

EMERGENCY CALLING

Page 114 - Chapter 8

● When an emergency call ends, the phone goes to the

Emergency Mode for 5 minutes.

BROWSER MENU

1. To enter the browser menu, press and hold .

RELOAD

Reloads current page.

1. To select Reload, press .

HOME

Displays Home Page.

1. To select Home, press .

BOOKMARKS

Displays Bookmark list.

1. To select Bookmarks, press .

MARK SITE

Adds a web page to bookmark list.

1. To select Mark Site, press .

Chapter 9 - Page 117

WIRELESS INTERNET

Your CDM-8500 allows you to browse various Internet websites directly from your phone. This provides access to up-to-date information such as news, sports, weather and stock quotes when you subscribe to Internet service with your service provider. Please contact your service provider for a list of available websites and service details.

1. To access the Wireless Internet Network, press .

2. The Internet browser will launch.

3. Scroll the page using .

To select the softkey at the bottom

of the display,

press or

5. To return to the previous page, press .

6. To exit the Internet, press .

T INTERNET BROWSER

Page 116 - Chapter 9

● You can access the Internet through your phone when it

is in digital mode, as indicated by the or symbol on your phone’s display.

BROWSER MENU

●

OFFLINE SERVICES

1. To navigate through the list of installed channel applications and guide you to the entry point of the applications, press .

●

OUTBOX

1. To display the number of items that are delivery-pending and how long they have been there, Press .

●

RESTART BROWSER

Causes the deck history and deck cache to be cleared and starts a new session with the UP. Link.

1. To select Restart Browser, press .

●

ENCRYPTION

Displays a list of security-related items.

1. To select Encryption, press .

Chapter 9 - Page 119

ABOUT OPENWAVE

When you select the About Openwave of the Browser Menu, the browser version and copyright information is displayed. The device layer version is also displayed.

1. To select About Openwave, press .

ADVANCED

Displays Advanced Menu options.

1. To select Advanced, press .

●

SHOW URL

Displays the URL(Uniform Resource Locator) of the current page.

1. To select Show URL, press .

●

HOMEPAGE

Enables you to change the homepage.

1. To select Homepage, press .

●

SET WAP PROXY

Enables you to select another WAP PROXY.

1. To select Set UP.Link, press .

BROWSER MENU

Page 118 - Chapter 9

Selecting the encryption item of browser menu displays a list of security-related items.

Your phone works as wireless modem when connected to a PC and a Laptop computer with data interface cable. This chapter shows you how to choose the correct settings for this to properly function.

Data SVC Location

Chapter 10

DATA SERVICE

Chapter 10 - Page 121Page 120 - Chapter 9

MEMO

DATT

A SVC

DATA SPEED

Select a connection speed based on the handset usage.

1. Press .

2. Select one of the following connection modes with the

navigation key.

3. To save, press .

Chapter 10 - Page 123

DATT

A SVC

Page 122 - Chapter 10

CONNECTION

Select a connection mode based on the handset usage.

1. Press .

2. Select one of the following connection modes with the navigation key.

3. To save, press .

NOTE:

This function is available only when the phone is connected to data cable.

● Voice Call : To receive a voice call.

● Data Only : To receive data when connected to PC.

● Fax Only : To function as a fax when connected to PC.

● 19200 BPS

● 115200 BPS

● 230400 BPS

Safety Information for Wireless Handheld Phones Safety Information for FCC RF Exposure SAR Information FDA Consumer Update

Chapter 11

SAFETY

INFORMATION

Chapter 11 - Page 125

LOCA

TION

SETTING

To select whether or not you allow the network system to detect your position.

1. Press .

2. Select “Location On” or “911 Only” with the navigation key.

Page 124 - Chapter 10

● 911 Only : Your location will be hidden from network

& application except 911.

● Location On : Your location is now available to the

network.

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

ANTENNA CARE

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

PHONE OPERATION

Normal Position: Hold the phone as you would any other telephone

with the antenna pointed up and over your shoul-

der.

Tips on efficient operation:

- Extend your antenna fully.

- Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may

cause the phone to operate at a higher power level

than otherwise

needed.

DRIVING SAFETY

Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes first. Check the laws and regulations on the use of phones in the areas where you drive. Always obey them.

Also, if using your phone while driving please:

- Give full attention to driving. Driving safely is your first

responsibility .

- Use hands-free operation, if available.

- Pull off the road and park before making or answering a

call, if driving conditions require.

Chapter 11 - Page 127

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

EXPOSURE TO RADIO FREQUENCY SIGNALS

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it

receives and

also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commissions

(FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards

previously

set by both U.S. and inter-

national

standards bodies:

ANSI C95.1 (1992) * NCRP Report 88 (1986) * ICNIRP (1996) *

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature.

For

example, over 120 scientists, engineers, and physicians

from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C951).

The design of your phone complies with the FCC guidelines (and those standards).

; American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission on Nonionizing Radiation Protection.

Read This Information Before Using Your Handheld

Portable Cellular Telephone

Page 126 - Chapter 11

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

ELECTRONIC DEVICES

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy Your physician may be able to assist you in obtaining this information.

Turn your phone OFF in healthcare facilities when any regulations posted in these areas instruct you to do so. Hospitals or healthcare facilities may be using equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

An airbag inflates with great force. DO NOT place objects, including both installed or portable wireless equipment, in the area over the airbag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Posted Facilities

Turn your phone OFF where posted notices so require.

Chapter 11 - Page 129

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

ELECTRONIC DEVICES

Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

If you have a pacemaker:

l ALWAYS keep the phone more than six inches from

your pacemaker when the phone is turned on.

l Do not carry the phone in a breast pocket. l Use the ear opposite the pacemaker to minimize

the potential for interference.

l If you have any reason to suspect that interference

is taking place, turn your phone OFF immediately.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the custome

r serv-

ice line to discuss alternatives).

Page 128 - Chapter 11

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

PRECAUTIONS AND WARNINGS

Please read and understand all of the Precautions and Warnings contained in this manual before attempting to operate your phone.

1. DO NOTuse this equipment in an extreme environment where high temperature or high humidity exists, such as near a heater or in a closed car parked in the sun.

2. DO NOTabuse the equipment. Avoid striking, shaking or shocking. When not using the unit, lay down the unit to avoid possible damage due to instability.

DO NOT expose this equipment to liquids such as rain or spilled beverages.

DO NOTuse unauthorized accessories. Use of unauthorized accessories may result in fire, electric shock or other bodily injury.

5. DO NOT disassemble the phone or its accessories. If service or repair is required, return the unit to an authorized Audiovox service center. If unit is disassembled, the risk of electric shock or fire may result.

6. DO NOT short-circuit the battery terminals with metal items etc.

7. DO NOT use harsh chemicals, cleaning solvents or strong detergents to clean this phone. Always clean it with a soft, damp cloth.

8. DO NOT paint this phone. This can clog moving parts.

Chapter 11 - Page 131

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

OTHER SAFETY GUIDELINES

Aircraft

FCC Regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

Blasting Areas

T o avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way

radio.” Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle’s engine.

Page 130 - Chapter 11

CAUTION

In August 1996, the Federal Communications Commission (FCC)

of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted

by FCC regulated trans-

mitters. Those guidelines are consistent

with the safety standard

previously set by both U.S. and international

standards bodies.

The design of this phone complies

with the FCC guidelines and

these international standards. Use only the supplied or an approved antenna. Unauthorized

antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations.

Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may

result.

Please contact your local dealer for replacement antenna.

Body-worn Operation (Holster Part Number : 2H020665002)

This device was tested with holster (Part No:2H020665002) for body-worn operation with the back of the phone kept 0.59 inchs (15mm) from the body . To comply with FCC RF exposure requirements, a minimum separation distance of 0.59 inchs (15mm) must be maintained between the user's body and the back of the phone, including the antenna, whether extended or retracted. All belt-clips, holsters and similar accessories used by this device must not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with FCC RF exposure limits and should be avoided.

Note: For more information about RF exposure, please visit the FCC website at www

.fcc.gov.

SAFETY INFORMATION FOR

FCC RF EXPOSURE

WARNING! Read this information before using

your phone

Chapter 11 - Page 133

SAFETY INFORMATION FOR

WIRELESS HANDHELD PHONES

OPERATING PROCEDURES

Never violate any of the following Rules and Regulations of the FCC when using your phone. The following offenses are punishable by fine, imprisonment, or both:

- Using obscene, indecent, or profane language.

- Using the unit to give off false distress calls.

- Wiretapping or otherwise intercepting a telephone call, unless that person has first obtained the consent of the parties participating in the call.

- Making anonymous calls to annoy, harass, or molest other people.

- Charging to an account without authorization to avoid payment for service.

- Refusing to yield a party line when informed that it is needed for an emergency call (It is also unlawful to take over a party line by stating falsely that it is needed for an emergency).

Page 132 - Chapter 11

SAR INFORMATION

as described in this user guide, is 0.633 W/kg. (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.

The FCC has granted an Equipment Authorization for this

model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information

on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID PP4TX-50C.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) web-site at http://phonefacts.net.

* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged

over one gram

of tissue. The standard incorporates a substantial

margin of safety to give additional protection for the public and to account for any variations in measurements.

Chapter 11 - Page 135

THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.15 W/kg and when worn on the body,

SAR INFORMATION

Page 134 - Chapter 11

• Design wireless phones in a way that minimizes any RF expo sure to the user that is not necessary for device function; and

• Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health. FDAbelongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:

• National Institute for Occupational Safety and Health

• Environmental Protection Agency

• Federal Communications Commission

• Occupational Safety and Health Administration

• National Telecommunications and Information Administration The National Institutes of Health participates in some interagency working group activities, as well. FDAshares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. FCC relies on FDA and other health agencies for safety questions about wireless phones. FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.

3. What kinds of phones are the subject of this update?

The term “wireless phone” refers here to hand-held wireless phones with built-in antennas, often called “cell,” “mobile,” or “PCS” phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short distance between the phone and the user’s head.

These RF expo-

sures are limited by Federal Communications

Commission safety

Chapter 11 - Page 137

U.S. Food and Drug Administration Center for Devices and Radiological

Health

Consumer Update on Mobile Phones

1. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the stand-by mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

2. What is FDA’s role concerning the safety of wireless phones?

Under the law, FDAdoes not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, FDAcould require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists. Although the existing scientific data do not justify FDA regulatory actions, FDAhas urged the wireless phone industry to take a number of steps, including the following:

• Support needed research into possible biological effects of RF

of the type emitted by wireless phones;

Page 136 - Chapter 11

5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?

A combination of laboratory studies and epidemiological studies

of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However, very large numbers of animals would be needed to provide reliable proof of a cancer promoting effect if one exists. Epidemiological studies can provide data that is directly applicable to human populations, but 10 or more years’follow-up may be needed to provide answers about some health effects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop - if they do - may be many , many years. The interpretation of epidemiological studies is hampered by difficulties in measuring actual RF exposure during day-to-day use of wireless phones. Many factors affect this measurement, such as the angle at which the phone is held, or which model of phone is used.

6. What is FDA doing to find out more about the possible

health effects of wireless phone RF?

FDAis working with the U.S. National T oxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to radiofrequency energy (RF). FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The Project has also helped develop a series of public information documents on EMF issues. FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts to independent investigators.

Chapter 11 - Page 139

guidelines that were developed with the advice of FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person’s RF exposure decreases rapidly with increasing distance from the source. The so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures far below the FCC safety limits.

4. What are the results of the research done already?

The research done thus far has produced conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of radiofrequency energy (RF) exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer-causing chemicals so as to be pre-disposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours per day . These conditions are not similar to the conditions under which people use wireless phones, so we don’t know with certainty what the results of such studies mean for human health. Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any possible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the average period of phone use in these studies was around three years.

Page 138 - Chapter 11

methodology for measuring the rate at which RF is deposited

in the heads of wireless phone users. The test method uses a tissuesimulating model of the human head. Standardized

SAR test

methodology is expected to greatly improve the consistency

of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body . It is measured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.

9. What steps can I take to reduce my exposure to

radiofrequency energy from my wireless phone?

If there is a risk from these products—and at this point we do not know that there is—it is probably very small. But if you are concerned about avoiding even potential risks, you can take a few simple steps to minimize your exposure to radiofrequency energy (RF). Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure.

• If you must conduct extended conversations by wireless phone every day , you could place more distance between your body and the source of the RF, since the exposure level drops off dramatically with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientific data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.

10. What about children using wireless phones?

The scientific evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radiofrequency energy (RF), the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and

Chapter 11 - Page 141

The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.

7. How can I find out how much radiofrequency energy exposure I can get by using my wireless phone?

All phones sold in the United States must comply with Federal Communications Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC established these guidelines in consultation with FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless telephones is set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have effects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website (http://www.fcc.gov/oet/rfsafety) gives directions for locating the FCC identification number on your phone so you can find your phone’s RF exposure level in the online listing.

8. What has FDA done to measure the radiofrequency energy coming from wireless phones ?

The Institute of Electrical and Electronic Engineers (IEEE) is

devel-

oping a technical standard for measuring the radiofrequency

energy (RF) exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers. The standard, “Recommended Practice for Determining the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques,” sets forth the first consistent test

Page 140 - Chapter 11

12. Where can I find additional information?

For additional information, please refer to the following resources:

- FDA web page on wireless phones: (http://www.fda.gov/cdrh/phones/index.html)

- Federal Communications Commission (FCC) RF Safety Program: (http://www.fcc.gov/oet/rfsafety)

International Commission on Non-Ionizing Radiation Protection: (http://www.icnirp.de)

- World Health Organization (WHO) International EMF Project: (http://www.who.int/emf)

- National Radiological Protection Board (UK): (http://www.nrpb.org.uk/)

Chapter 11 - Page 143

increasing the distance between the user and the RF source will reduce RF exposure. Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United

Kingdom distributed leaflets containing such a recommen-

dation

in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children

was

strictly precautionary; it was not based on scientific evidence

that any

health hazard exists.

11. What about wireless phone interference with medical

equipment?

Radiofrequency energy (RF) from wireless phones can interact with some electronic devices. For this reason, FDA helped develop a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless

telephones. This test method is now part of a standard

Audiovox CMD-8500 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
