Audiovox CE710CR User Manual

DOCKING DIGITAL MUSIC SYSTEM FOR iPod

ESTACIÓN DE SISTEMA DE MÚSICA DIGITAL PARA iPod® CONNEXION DU SYSTEME MUSICAL DIGITAL POUR iPod®

OWNER’S MANUAL

MANUAL DEL USUARIO/GUIDE DU PROPRIETAIRE

CE710CR

(iPod®Not Included/

PLEASE READ THIS OPERATING MANUAL COMPLETELY BEFORE OPERATING

THIS UNIT AND RETAIN THE BOOKLET FOR FUTURE REFERENCE

CE710CR IB 09/01/2009 VER 18.0 fold size: 148.5 x 210mm ( 15 pcs 297 x 210mm - 60PP) printing color: Black (black on white / BK+BK)

iPod® No Incluido/iPod®non inclus

)

Table of Contents

Dear Audiovox Customer ............................................................................................................................ 1

Important Safety Instructions....................................................................................................................... 2

Compliance With FCC Regulations ............................................................................................................. 4

Product Features ......................................................................................................................................... 4

Installation ................................................................................................................................................... 5

Location of Controls..................................................................................................................................... 6

iPod

Adaptors............................................................................................................................................ 8

Radio Operation .......................................................................................................................................... 9

iPod Docking ............................................................................................................................................. 10

Docking 1 Video Out from the iPod

and 2ndGeneration iPod Nanos............................................................................................. 11

.......................................................................................................................... 12

Auxiliary Input............................................................................................................................................ 13

Clock and Calendar Settings ..................................................................................................................... 13

Alarm Operations....................................................................................................................................... 14

Care and Maintenance .............................................................................................................................. 15

Troubleshooting Guide .............................................................................................................................. 16

Specifications ............................................................................................................................................ 17

Warranty.................................................................................................................................................... 18

iPod

, iPod®Mini, iPod®Nano, iPod®Shuffle, iPod®Classic and iPod®Touch are trademarks of Apple

Computer Inc., registered in the U.S. and other countries.

Tabla de Contenidos

Estimado Cliente de Audiovox................................................................................................................... 19

Instrucciones de Seguridad Importantes ................................................................................................... 20

Cumplimiento de las Regulaciones de la FCC .......................................................................................... 22

Características del Producto ..................................................................................................................... 22

Instalación ................................................................................................................................................. 23

Ubicación de Controles ............................................................................................................................. 24

Adaptadores de iPod

Operaciones del Radio .............................................................................................................................. 27

Estación de iPod

Conectando iPods nano de 1ra y 2da Generación.................................................................................... 29

Salida de Video Desde el iPod

............................................................................................................................... 26

..................................................................................................................................... 28

................................................................................................................ 30

Enrada Auxiliar .......................................................................................................................................... 31

Configuración del Reloj y del Calendario .................................................................................................. 31

Operaciones de Alarma............................................................................................................................. 32

Cuidados y Mantenimiento ........................................................................................................................ 33

Guía de Solución de Problemas................................................................................................................ 34

Especificaciones........................................................................................................................................ 35

Garantía..................................................................................................................................................... 36

iPod

, iPod®Mini, iPod®Nano, iPod®Shuffle (aleatorio), iPod®Classic and iPod®Touch (toque) son

marcas registradas de Apple Computer Inc., registradas en Estados Unidos y otros países.

Table des Maitieres

Cher Client Audiovox................................................................................................................................. 37

Instructions de Securite Importante........................................................................................................... 38

Conformite Avec des Reglements FCC..................................................................................................... 40

Product Features ....................................................................................................................................... 40

Installation ................................................................................................................................................. 41

Emplacement des Controles ..................................................................................................................... 42

iPod

Adaptors.......................................................................................................................................... 44

Operations Radio....................................................................................................................................... 45

Radio Operation ........................................................................................................................................ 46

iPod Docking ............................................................................................................................................. 47

Branchement 1ère et 2ème generation iPod nanos .................................................................................. 48

Sortie Video de l’iPod

.............................................................................................................................. 49

Entrée Auxiliaire ........................................................................................................................................ 50

Reglages Horloge et Calendrier ............................................................................................................... 50

Operations d'Alarme.................................................................................................................................. 51

Soin et Entretien........................................................................................................................................ 52

Guide du Depannage ................................................................................................................................ 53

Specifications ............................................................................................................................................ 54

Garantie..................................................................................................................................................... 55

iPod

,iPod®Mini, iPod®Nano, iPod®Shuffle, iPod®Classic et iPod®Touch sont les marques deposes de

Apple Computer Inc., enregistrées aux Etats-Unis et d'autres pays.

DEAR AUDIOVOX CUSTOMER

Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time your hearing "comfort level" adapts to higher volumes of sound. So what sounds "normal" can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level: Start your volume control at a low setting. Slowly increase the sound until you can hear it comfortably and clearly, and without distortion. Once you have established a comfortable sound level: Set the dial and leave it there. Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime. We Want You Listening For a Lifetime Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic Industries Association's Consumer Electronics Group recommend you avoid prolonged exposure to excessive noise. Customer's Record: The serial number of this product is found on its bottom cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss.

Model Number: CE710CR Serial Number:______________________________

*See Bottom of Unit

WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquid such as vases, shall be placed on the apparatus.

IMPORTANT SAFETY INSTRUCTIONS

THE IMPORTANT SAFETY INSTRUCTIONS SHALL INCLUDE, AS APPLICABLE TO THE APPLIANCE, STATEMENTS THAT CONVEY TO THE USER THE INFORMATION ITEMIZED IN THIS PARAGRAPH:

1. Read these instructions - All the safety and operating instructions should be read before the appliance is operated

2. Keep these instructions - The safety and operating instructions should be kept for future reference.

3. Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow all instructions - All operation and use instructions should be followed.

5. Donotusethisapparatusnearwater-Theappliance should not be used near water; for example, near a bath tub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.

6. Clean only with dry cloth - The appliance should be cleaned only as recommended by the manufacturer.

7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments / accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combinationtoavoid injury fromtip-over.

13. Unplug this apparatus during lightning storms or when unused for a long periods of time.

IMPORTANT SAFETY INSTRUCTIONS

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. Wall and Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

16. Power Lines - An outdoor antenna should be located away from power lines.

17. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electrical Code, ANSI/ NFPA No.70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See figure 1.

FIGURE 1

EXAMPLE OF ANTENNA GROUND ING

AS PER NATION AL

ELECTRIC AL CODE

GROUND CLAMP

ELECTRON IC SERVICE EQUIPMENT

S2898A NE C-NATIONAL ELEC TRIC CODE

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGEUNIT (NEC SECTION 810-20)

GROUNDING CONDUCTOR (NEC SECTION 810-21)

GROUND CLAMP

POWER SERVIC E GROUNDING ELECTRODE SYSTEM (NEC ART 25 0.PART H)

18. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. Power Sources - The appliance should be connected to a power supply only of the type described in

19. the operating instructions or as marked on the appliance. Do not overload wall outlet.

20. Servicing - The user should not attempt to se

rvice the appliance beyond that described in the

operating instructions. All other servicing should be referred to qualified service personnel.

21. All markings are located on the exterior bottom enclosure of the apparatus.

22. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type.

23. The mains plug is used as the disconnect device from the mains.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT. FULLY INSERT THE PLUG TO MAIN POWER SOCKET. S2898A NEC-NATIONAL ELECTRIC CODE

COMPLIANCE WITH FCC REGULATIONS

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

PRODUCT FEATURES

CE710CR is an iPod®Docking Music System which incorporates the following features:

•iPod

• Audio Line-in for Connecting CD Player or Other Digital Audio Player

• 2 Built-in High Fidelity Aluminum Cone Speakers

• Multi-function Back-lit LCD Display

• Interchangeable iPod

• FM Stereo Receiver with 10FM Presets, Digital Tuning and Auto Search Function

• Electronic Volume Control

• Wake to Radio, Alarm or iPod

• Snooze and Sleep Functions

• Built-in Contractible Aux Cord with 3.5mm Aux Plug

• External FM Antenna Jack for Better FM Reception Card Size Remote Control for Radio and iPod

• Output: 2 X 3W MAX.

• Video Line-out provides video signal output when iPod

, iPod®Mini, iPod 1st to 3rd Generation Nano, iPod® Classic and iPod®touch Player /

Recharger

Adaptors

Functions

with video is docked.

INSTALLATION

Clock Back-up Batteries Installation

1. Open the battery compartment door located at the bottom of the unit.

2. Install two DC1.5V 'AAA' (UM-4) batteries (not included) in the battery compartment following the polarity markings shown on it.

3. Replace the battery door on the battery compartment.

NOTE: Please disconnect the main power from the unit before replacing the clock back-up batteries.

WARNING:

• Be sure that the batteries are installed correctly. Wrong polarity may damage the unit.

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.

• Only batteries of the same or equivalent type as recommend are to be used.

• If the unit is not to be used for an extended period of time, remove the battery.

• Do not dispose of batteries in fire, batteries may explode or leak.

• Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

FM Antenna Installation

The FM Antenna Wire is provided in the package. Please see the illustration below for FM Antenna Wire

installation.

Remote Control

Theremotecontroloperates on one CR2032 battery (included). To activate the remote control, remove the insulation tab inserted in the battery compartment.

AC Power

Connect the AC power plug into your household AC power outlet (120VAC/60Hz).

NOTE: This unit is not magnetically shielded and may cause color distortion on the screen of some TVs or video monitors. To avoid this, you may need to move the unit further away from the TV or monitor if unnatural color shifts or image distortion occurs.

Connect the FM Antenna Wire to the antenna terminal at the rear of the main unit

Main Unit

LOCATION OF CONTROLS

Bottom View

Rear View

2021 22 23

1. iPod®Dock

2. iPod

Docking Connector

Top Vi ew

Front View

456738

13 14

16910 11 12

3. POWER On/Off Button - To turn the unit on or off

4. VOLUME +/- Buttons - Adjust the volume level up or down

5. SNOOZE/LIGHT Button - Activate the snooze function; Turn the LCD backlight on or off

6. TUN +/- /iPod / Buttons - Tune the radio channel frequency up or down; iPod

Skip/Search.

Forward/Backward Buttons for Backward, for Forward.

7. CH +/- Buttons - Select the preset radio stations

8. ALARM On/Off Button - Switch the alarm on or off

9. SLEEP Button - Select the time duration of the sleep timer

10. MODE Button - Enter the setting mode

11. MEM/iPod Button - Save the radio preset stations; save settings; iPod

12. FUNCTION Button - Select FM Radio, iPod

mode and AUX (auxiliary input) mode

PLAY/PAUSE

13. LCD Display

14. Remote Infra-red Sensor

15. Pair of Speakers

16. Front control cover

17. AUX in Jack - An Audio Cable with a 3.5mm stereo plug for the connection of external audio device

18. Cord Retracting Wheel - For extending or retracting the auxiliary cord

19. AC power cable and plug

20. Headphone Jack

21. FM Antenna Terminal

22. S-VIDEO Jack - S-Video signal output

23. RCA VIDEO Jack - Composite video signal output

24. Battery Compartment - It is to contain two 'AAA' batteries for clock back-up

25. RESET Button - For resetting the unit

LOCATION OF CONTROLS

Remote Control

1. Infra-red Transmitter

2. POWER On/Off Button

3. VOL +/- Button

4. FUNCTION Button

5. ALARM On/Off Button

6. SNOOZE/LIGHT Button

7. TUN Up/Down Buttons for Down, for Up

8. CH +/- Buttons

9. MEM Button

10. MODE Button

11. SLEEP Button

12. iPod

13. iPod

14. Battery Compartment

Skip/Search Forward/Backward Buttons

for Backward, for Forward.

PLAY/PAUSE

iPod®ADAPTORS

Please see below for the iPod® Adaptor included in the package:

rotpadAdoPisledoMdoPi

Docking Cover

Nano

iPod (1st and 2nd Gen)

Mini

iPod

3Gen iPod 4Gen iPod iPod

3Gen iPod 4Gen iPod

iPod

NOTE: No adaptors are provided for iPod®with video 30GB, 60GB and 80GB, iPod®3Gen Nano, iPod

purchase. They will fit properly into the docking stations of this system.

10/15GB

20GB

Photo 20/30GB

30/40GB

40GB

Photo 40/60GB

Classic and iPod®Touch. Please use the adaptors included with these iPods at time of

RADIO OPERATION

FM Antenna

Connect the detachable FM Antenna Wire to the FM Antenna Terminal as instructed in the section "INSTALLATION". Fully extend the FM Antenna Wire for maximum reception.

Radio Tuning

1. Press the POWER button to turn the unit on.

2. Press the FUNCTION button repeatedly until "FM" mode is reached.

3. In FM radio mod, if necessary, press the MODE button to select STEREO (ST) or MONO FM reception.

4. To manually tune the radio station, repeatedly press the TUN Up/Down buttons.

5. To automatically search the next or previous station with the strongest signal, press and hold the TUN Up/Down buttons until the frequency readout on the display begins to scan and then release the button. The tuner will stop scanning when a strong signal is reached.

NOTE: Use manual tuning to select weaker stations that might be bypassed during automatic tuning. If the automatic search does not stop at the exact frequency, for example, it stops at

100.9MHz instead of 100.8MHz, press TUN +/- to finely tune the exact frequency.

Preset Stations

The unit allows you to store up to 10FM stations in the preset memory positions for easy recalling any time.

1. Press the POWER button to turn on the unit.

2. To activate the radio, press the FUNCTION button to select FM band.

3. Tune to your desired station by pressing the TUN +/- buttons.

4. Press the MEM button. The preset channel number "01" and the icon "MEM" will flash on the display.

5. Select your desired preset number by pressing the CH +/- buttons.

6. After the preset channel number is selected, press the MEM button to confirm your selection. The station is saved in the preset channel now.

7. To store additional stations, repeat steps 3-6.

Radio Broadcast System Selection

When the unit is used in another country with a slightly different radio broadcast system, the unit allows you to select USA, EU and Japan systems.

1. Set the unit to Power Off mode.

2. Press the MODE button repeatedly until the flashing "USA", "EU", or "JP" is seen.

3. Press the TUN +/- button to select one of the broadcasting systems.

4. Press the MEM button to save the setting and exit the setting mode.

NOTE: The following are the specifications of the three radio broadcast systems: USA's Radio Broadcast System

FM 87.5 MHz - 108 MHz, 0.1 MHz tuning step

EU's Radio Broadcast System FM 87.5 MHz - 108 MHz, 0.05 MHz tuning step

Tips for the best reception

• To obtain the best FM reception, fully extend the FM antenna and adjust the direction.

Japan's Radio Broadcast System FM 76.0 MHz - 108 MHz, 0.1 MHz tuning step

iPod DOCKING

This model includes adaptors for adopting different iPod®models. If the docking port will not be used for an extended period of time, it is recommended to cover the docking port by using the "Dock Cover" insert (included).

1. Select a suitable adaptor for your iPod inserted into the docking port by placing the connector on the bottom of the iPod

in the docking bay.

Note: Please be careful when seating the iPod into the docking to avoid damaging the 30-pin connector on iPod or docking system.

2. Press the POWER On/Off button to switch on the docking system.

3. Press the FUNCTION button repeatedly until the indicator "iPod" shows on the display. The iPod start playing and charging automatically.

4. Select your desired EQ and play mode in your iPod

5. Press the VOL +/- button on the docking system to adjust your desired volume level.

NOTE:The volume level cannot be adjusted by the volume control of your iPod®after being docked.

6. The iPod

is charging even during playback.

NOTE:The recharge function still operates in Radio, iPod and AUX mode.

7. To remove the iPod

from the unit, press and hold the PLAY/PAUSE button for three seconds to

switch off the device and then gently remove it from the docking connector.

You may control the playback of your iPod

• Press the PLAY/PAUSE button to pause or resume the iPod

• Press the iPod Skip/Search Forward or Backward button to skip to the next or previous song;

• Press and hold the iPod Skip/Search Forward or Backward button for fast-forwarding or fastrewinding during playback.

and insert it into the docking area. Your iPod®can now be

by:

playback;

onto the connector

will

DOCKING 1stAND 2

First, install the iPod®Nano bracket into the CE710CR dock.

1st Generation iPod nano:

Align your 1st generation iPod®Nano to the LEFT side of the opening in the nano bracket (Figure 1 ). Make sure the 30-pin connector on the bottom of the nano is positioned over the connector in the CE710CR dock prior to seating the nano. Carefully slide the nano down onto the connector in order to insure a secure connection.

GENERATION iPod NANOS

2nd Generation iPod nano:

Align your 2nd generation iPod®Nano in the RIGHT of the opening in the nano bracket (Figure 2 ). Make sure the 30-pin connector on the bottom of the nano is positioned over the connector in the CE710CR dock prior to seating the nano. Carefully slide the nano down onto the connector in order to ensure a secure connection.

Note: Be careful not to damage the connector when docking the nano. Never use force when docking the nano onto the connector.

Figure 1

Figure 2

VIDEO OUT FROM THE iPod

You are able to view videos and photos stored in your 5th Generation iPod®, iPod®3Gen Nano, iPod

Classic and iPod®Touch on a larger television screen or monitor using the Video Output jacks provided on this model.

Two video output jacks are available on this model.

1. S-VIDEO - S-Video signal.

2. RCA VIDEO - composite video signal (most common on standard televisions with video in).

Video Out (For 5th Generation iPods with video, iPod 3Gen nano, iPod classic and iPod touch ONLY)

1. You can connect this unit to a television or other video display that has S-video or composite video input.

2. Securely dock the iPod

with video.

3. Connect the S-video cable into the rear S-video jack or yellow RCA cable to rear RCA video jack on the unit.

4. Connect the other end of the S-video or yellow RCA cable to VIDEO IN of television or video display.

5. Press the FUNCTION button to select iPod

6. Select a movie from your iPod

menu.

mode.

7. iPod: On the main menu choose video then select video setting.

8. iPod: Make sure the TV Out section is set to "ON".

9. iPod: Switch back to the movie library and play the movie of your choice.

Note: For the initial docking of the iPod(3Gen) nano,iPod clasic and iPod touch, you may wait for the finishing of iPod authentication process then the video signal output to your TV screen or monitor.

For Photo view (For iPod with color display ONLY-excludes 1st and 2nd Gen nano)

1. Press the FUNCTION button to select iPod mode.

2. Securely dock the iPod with color display.

3. iPod: At TV make sure set to "ON"

4. iPod: Go to Photo Library and then press play. The slideshow will play on your device.

Note:

1. For the initial docking of the iPod(3Gen) nano,iPod clasic and iPod touch, you may wait for the finishing of iPod authentication process then the video signal output to your TV screen on monitor.

2. The RCA Video input connector on a television is usually color coded yellow to match the color on the AV cable.

3. When playing slideshows or videos, the audio will only playback on the unit speaker.

4. S-video and RCA cables are not included.

AUXILIARY INPUT

The auxiliary input cable and plug are built in the unit and allows users to connect their CD player, MP3 player or other non-dockable iPods to the unit.

1. Keep turning the Cord Retracting Wheel, located at the rear of the unit, to the right and pull out the AUX IN Cable located next to the wheel.

2. Connect the AUX IN Stereo Plug to the Line Out Jack or Headphone Jack of your external audio device.

3. Switch on the audio device.

4. Press the FUNCTION button repeatedly until AUX mode is displayed. The display will show the icon "AUX".

5. Control the volume level by the volume control on the audio device or pressing the VOL +/- on the main unit or the remote control.

NOTE: If you're connected using the Line Out Jack of your external device, then you can only adjust the volume using the CE710CR control. If you're connected using the Headphone Jack of your external device, then you may need to adjust both the volume controls (CE710CR and external device) to get the best volume level.

Press the ON/OFF button to turn off the unit when you finish listening. Don't forget to switch off the power of your external device as well.

CLOCK AND CALENDAR SETTINGS

The clock and calendar can be set in Power Off mode.

Clock Setting

1. Press the MODE button 3 times, the clock starts to flash.

2. Press the TUN +/- button to set the hour.

3. Press the VOL +/- button to set the minute.

4. Press the MEM button to confirm the settings.

12/24 Hour Time Display Mode Setting

1. Press the MODE button repeatedly until the 12/24 Hour Format Setting mode is reached. The flashing '12hr' or '24hr' will be displayed.

2. Press TUN +/- button to select 12 hour or 24 hour time display mode.

3. Press the MEM button to confirm the setting.

Calendar Setting Year

1. Press the MODE button repeatedly until the year setting mode is reached. The year readout flashes now.

2. To set the year, press the TUN +/- button to set the correct year.

3. Press the MEM button to confirm the setting.

Month/Date

1. Press the MODE button repeatedly until the Month/Date setting mode is reached. The readout of the Month/Date flashes now.

2. To set the month, press the TUN +/- button. To set the date, press the VOL +/- button.

3. Press the MEM button to confirm the settings.

ALARM OPERATIONS

Setting the Alarm Time

When the unit is in Power Off mode:

1. Press the MODE button once. The alarm clock display flashes now.

2. Press the TUN +/- button to set the alarm hour and VOL +/- button to set the alarm minute.

3. Press the MODE button again. The alarm icon will flash.

4. Select "Wake to Buzzer", "Wake to Radio" or "Wake to iPod®" by pressing the VOL +/- button.

NOTE:

- When "Wake to Radio" is selected, ensuring that your desired radio station is tuned and the

proper volume level is set.

- When "Wake to iPod®" is selected but your iPod has not been docked, the alarm source will be

redirected to the Buzzer automatically when the alarm time is reached.

5. Press the MEM button to save all the settings and exit the setting mode.

6. To activate the daily alarm, the press the ALARM On/Off button. The icon " " will appear on the display.

7. When the alarm time is reached, the alarm will sound from the selected source immediately.

Wake to Buzzer (BUZ

• After the alarm time is reached, the buzzer alarm will sound immediately for one minute.

• After the first alarm minute, it will switch to Auto Snooze mode. Once the alarm is off, the next alarm will come again after the 10 minute snooze period is completed. This operation will be repeated 3 times. After the third alarm is finished, the alarm will shut off until the same alarm time on the next day.

• To stop the buzzer alarm immediately, press the ALARM On/Off button once.

Wake to Radio (

• The radio will automatically turn on when the alarm time is reached. It starts softly and becomes gradually louder.

• The radio alarm will keep for 60 minutes and then will automatically shut off.

• To stop the radio alarm sound immediately, press the ALARM On/Off button once.

Wake to iPod® (

• Your docked iPod will automatically switch on when the alarm time is reached. It starts softly and becomes gradually louder.

• The iPod playback will keep for 60 minutes and then automatically shut off.

• To stop the iPod playback immediately, press the ALARM On/Off button once.

Snooze Function

• When the alarm sounds, it can be temporarily stopped by pressing the SNOOZE button. The display will show the indicator "SNOOZE".

• The alarm will be delayed for 10 minutes and then come again.

• This manual snooze operation can be repeated only three times.

Sleep Timer

• The Sleep Timer allows you to set the unit to automatically power off after a selected sleep time is set.

• To activate the Sleep Timer and select the sleep time, press the SLEEP button repeatedly. The sleep times available for choosing are: 15, 30, 45 or 60 minutes. The display will show the indicator "SLEEP".

• To switch off the Sleep Timer, press the SLEEP button repeatedly until the SLEEP indicator disappears.

• To switch off the unit before the selected sleep time, press the POWER On/Off button once.

• To check the current sleep time, press the SLEEP button once.

)

RAD)

iPod)

+ 42 hidden pages
