Audiovox CCDF User Manual

Installation Instructions

Model CCDF

Color Camera External Mount

CCDF FEATURES:

l High Resolution, 1/3”CCD Color Camera
l Compact Zinc Alloy Die Cast Body
l Waterproof Housing
l Waterproof Microphone
l Adjustable Mounting Angle
l Wide Angle Lens
l Flush Mount or Surface Mount

128-6951

1 of 12

Color Camera View:

Cable Connector End View:

1

128-6951

2 of 12

Specifications:

1. Signal System: NTSC

2. Voltage: DC12V

3. Current: 80mA

4. Image Sensor: 1/3” CCD Color Sensor
NTSC: 510 X 492 picture elements

5. Horizontal Definition: 420 Lines

6. V iewing Angle: 120 degrees

7. Minimum Illumination: 0.8 LUX

8. Outer Dimensions: 1.18”(W) x 1.10”(H) x 1.65”(D)

9. Weight: 2.5 Oz

2

128-6951

3 of 12

Contents:

3

128-6951

4 of 12
