Audiovox Car DVD Player-Monitor Combo User Manual

LOW PROFILE DVD/TV/SPEAKER PHONE

OWNER’S/INSTALLATION GUIDE

- DVD Player & 10.4” TFT LCD Monitor

- Multi-Function Remote Control

- Built-in Speaker Phone Mode

- Cable Ready 125 Channel Tuner

- Internal Stereo Speakers

- Under Cabinet Mounting

- A/V Input

- 1 -

128-6451

Introduction

Record model number and serial number in the space provided below. Refer to these numbers whenever you call upon your Audiovox dealer regarding this product.

Model No. Serial No.

WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol is intended to alert the

INFORMATION

This equipment generates and uses radio frequency energy and if not installed and used properly; that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limitations for a Class B computing device in accordance with the specifications in Subpart J of Part 15 of the FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

- Connect the equipment to an outlet of a circuit

user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of

- Consult the dealer or on experienced radio/TV

sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance

TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED AC PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET, UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

(servicing) instructions in the literature accompanying the VE1040.

receiver.

different from that to which the receiver is connected.

technicion for help.

- 2 -

Important Safety Instructions

1. Read Instructions - All the safety and operating instructions should be read before the product is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. C l e a n i n g - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol. Use a damp cloth for cleaning.

6. A t t a c h m e n t s - Do not use attachments not recommended by the product manufacturer, as they may cause hazards.

7. Water and Moisture - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, laundry tub, in a wet basement, near a swimming pool, and the like.

8. A c c e s s o r i e s - Do not place this product on an unstable cart, stand, tripod bracket, or table. The product may fail, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

9. A product and cart

10. Ventilation - Slots and openings in the cabinet

11. Power Sources - This product should be

12. Grounding or Polarization - This product may

combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

are provided for ventilation and to ensure reliable operation of the product. They protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided, or the manufacturer’s instructions have been adhered to.

operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your product dealer or local power company. For products intended for operation from battery power or other sources, refer to the operating instructions.

be equipped with a polarized alternatingcurrent line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still cannot be inserted, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

- 3 -

Important Safety Instructions

13. Power-Card Protection - Power-supply cords

should be routed so that they are not likely to be walked on or pinched by items placed upon or against them paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

14. Protective Attachment Plug - The product is

equipped with on attachment plug having overload protection. This is a safety feature. See instruction Manual for replacement of, or resetting the protective device. If replacement of the plug is required, be sure the service technician has uses a replacement plug specified by the manufacturer that has the same overload protection as the original plug.

15. Outdoor Antenna Grounding - If an outside

antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements for the grounding electrode (Refer to the figure on page 5 ).

16. Lightning - For added protection of this product

during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

17. Power Lines - An outside antenna system should

18. O v e r l o a d i n g - Do not overload wall outlets,

19. Object and Liquid Entry - Never push objects of

20. Servicing - Do not attempt to service this product

21. Damage Requiring Service - Unplug this

not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits.

When installing on outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

extension cords, or integral convenience receptacles, as this can result in a risk of fire or electric shock.

any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

yourself as opening or removing covers my expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

product from the wall outlet and refer servicing to qualified service personnel under the following conditions.

A. When the power-supply cord or plug is

damaged.

B. If liquid has been spilled, or objects have

fallen into the product.

C. If the product has been exposed to rain or

water.

- 4 -

Important Safety Instructions

D. If the product does not operate normally by

following the operating instructions. Adjust only those controls that are covered by the operating instructions, as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

E. If the product has been dropped or damaged

in any way.

F. When the product exhibits a distinct change

in performance - this indicates a need or service.

22. Replacement Parts - When replacement parts

are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

23. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

24. Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

25. Heat - The product should be situated away from heat sources such as radiators, heat resistors, or other products (including amplifiers) that produce heat.

- 5 -

Important Safety Instructions

1) Unplug the unit before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

2) Use only Audiovox approved accessories.

3) Do not install this video product where it is likely to be exposed to water.

4) Do not obstruct the slots and openings in the cabinet. They are provided for ventilation and are necessary to ensure reliable operation of the unit and to protect it from overheating. This unit should never be placed near or over a radiator or heat register.

5) Do not overload electrical outlets or use extension cords as this can result in a risk of fire or electric shock.

6) Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

Cable System Installation Marking

NOTE TO CATV SYSTEM INSTALLER :

NOTE TO CATV SYSTEM INSTALLER : This reminder

This reminder is provided to call The CATV

is provided to call The CATV (CABLE-TV) System

(CABLE-TV) System Installer’s Attention to Article

Installer’s Attention to Article 820-40 of The NEC,

820-40 of The NEC, That Provides Guidelines for

That Provides Guidelines for proper Grounding and,

proper Grounding and, In particular, Specified

In particular, Specified that The CABLE Ground shall

that The CABLE Ground shall be Connected to the

be Connected to the grounding system of the

grounding system of the building, As close to the

building, As close to the point of cable entry as

point of cable entry as practical.

practical.

Undercabinet Product Marking

CAUTION

TO REDUCE THE RISK OF FIRE, DO NOT PLACE

ANY HEATING OR COOKING PRODUCT

BENEATH THIS UNIT.

Polarized attachment plug marking

CAUTION

TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Installation marking

7) Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

8) Unplug this unit from the outlet and refer servicing to qualified service personnel under the following conditions:

a) If the unit has been exposed to water. b) If the unit does not operate normally when

following the operating instructions.

c) If the unit has been dropped or the cabinet has

been damaged.

“USE minimun No. 26 AWG wire for telephone interconnect cable”

When used outside the U.S, detachable, rated min. 250 V, 5 A. One end terminates with a grounding, mold-on, attached plug; other end terminates with a mold-on appliance coupler. The cord set should have the appropriate safety approvals for the country in which the equipment will be installed.

- 6 -

Table Of Contents

Before You Begin

Installation

Operation

Remote Control Functions Modes of Operation

Using the Remote Control Functions

Using the Setup Menu

Definition of Terms Troubleshooting Check List Technical Specifications

Introduction..................................................................................... 2

Important Safety Instructions............................................................ 3

Table of Contents ............................................................................ 7

Included in this Kit .......................................................................... 8

Under Cabinet Installation............................................................... 9

Operation And the Function Of Controls

Front Panel Controls..................................................................... 10

Rear Panel Controls...................................................................... 11

LCD Control Functions................................................................... 12

Operation....................................................................................... 13

Channel Tuning Set up................................................................. 13

Positioning the Screen.................................................................. 13

Setting the Time........................................................................... 13

Setting and Activating The Alarm.................................................. 13

Deactivating The Alarm................................................................ 14

Setting the Alarm Tones................................................................ 14

Remote Control Functions................................................................. 15

Modes of Operation......................................................................... 17

Setting the Cable TV Mode........................................................... 17

Setting the Presets (For AM and FM or TV Modes)........................... 17

Setting the Speaker Mode............................................................. 17

Using the Remote Control Functions.................................................. 18

Inserting and Ejecting the Disc....................................................... 18

Playback and Stop....................................................................... 18

Searching for a Specific Scene/ Song by Selecting the Chapter Number... Searching for a Searching for a Specific Scene/ Song by Using Playback Speed Repetitive Playback - To Repeat a

Changing the Subtitle Language.................................................... 19

Changing the Vocal Language...................................................... 19

To Enlarge a Picture..................................................................... 19

Viewing Different Angles.............................................................. 19

Viewing a Menu Installed in Discs................................................. 19

Viewing the Setup Menu.............................................................. 20

Viewing the Playback Time, Title and Chapter Status...................... 20

Using the Setup Menu...................................................................... 21

General Setup............................................................................. 22

Speaker Setup............................................................................. 23

Dolby Digital Setup.......................................................................23

Preferences.................................................................................. 23

Definition of Terms.......................................................................... 24

Troubleshooting Check List.............................................................. 25

Technical Specifications................................................................... 27

Specific

Scene/ Song by Using Chapter

Specific

Section ............................19

............................ 18

....... 18

.................... 18

- 7 -

Included in this kit

1. VE1040 DVD/TVPhone

2. Mounting Template

3. Hardware Bag A. 3/4” Mounting screws (4) B. 1-1/4” Mounting screws (4) C. 1-1/2” Mounting screws (4) D. 3/4” Spacer (4) E. 1/2” Spacer (4) F. 1/4” Spacer (4)

4. AM Antenna

5. Manual

6. Telephone Jack

7. FM Dipole Antenna

8. Remote Control Unit

9. Battery, size AAA(2)

10. Right angle coaxial adapter (for the TV input)

Tools Required

- Philips Head

Screwdriver

- Centerpunch

- 1/8” Drill Bit

- Electric Drill

- Adhesive Tape

- 8 -

Under Cabinet Installation

FRONT VIEW SIDE VIEW

1) Choose an appropriate mounting location underneath a cabinet or shelf. Close proximity to an electrical outlet and a TV antenna or cable connection will facilitate a neat, easy installation.

5 ) Carefully drill four 1/8” holes at the locations

marked above. Place the screws selected through the VE1040 and then through the spacers(if

required from the bottom-up). Do not mount the VE1040 above a range or oven. Be sure that the location chosen will provide adequate access to the electrical

6) Position the VE1040 and screw it in place using the selected screws. Do not overtighten.

connection on the rear of the unit before continuing.

7) Connect your TV antenna or cable system to the antenna connector on the rear of the VE1040.

2) If the location chosen has bottom edge molding it may be necessary to use the mounting spacers provided to effectively lower the VE1040 below

8) Plug the AC wire into connector on the rear of the VE1040 and then into the wall.

or even with the molding. Measure the distance between the bottom and the bottom of the cabinet. For large molding choose a combination

9) If using the speaker phone feature, plug the VE1040 into a phone jack.

of spacers which will allow the VE1040 to be secured to the bottom of the cabinet.

10) Attch the FM Dipole Antenna to the FM Antenna

screws.

3) Measure the thickness of the bottom of the cabinet or shelf and the spacers chosen. Select the shortest screw length which will secure the VE1040 to the bottom of the cabinet.

11) Route the wires safely away from heat and moisture sources and secure them in place using the self adhesive wire mounting clip provided.

4) Cut out the template supplied and tape it in place onto the cabinet surface to be drilled. Center Punch the four holes indicated on the template and remove the template.

- 9 -
