Audiovox aps920 User Manual
Model APS-920
Owner’s Manual
ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors,
hood lid and trunk lid.
2. Press and release Lock/Arm button on the keychain transmitter.
The dash mounted LED begins to flash slowly. Parking Light s
flash one time.
Siren sounds one chirp.
If the siren/horn
trunk, or hood lid ajar. Simply close the opened entry point
sometime after arming, the exclusive, patented, delayed dome light
learn circuit has been programmed and the system detected a open
entry point after the learned delay expired. Again, closing the hood,
trunk, or doors will correct the problem and you do not need to disarm
the system to make the correction. If the siren/horn did not sound
when arming, then the chirps have been turned off and you should refer to the section
titled "ELIMINATING THE ARM/DISARM CHIRPS" in this manual.
NOTE: If selectable feature 9, Chirp Delete From Transmitter, was set to the on position
during installation, then you can selectively defeat the arm & disarm chirps by holding the
transmitters Lock or Unlock button for about 2 seconds.
Note: If Passive Arm Mode was selected on during installation, then 30 seconds af ter the
PROTECTION WHILE THE SYSTEM IS ARMED
Opening any protected door, hood or trunk lid will cause the alarm to immediately sound. The
alarm will continue to sound for 30 seconds, then stop and continue to monitor all protected entry
points. If the thief left a door opened, the alarm will sound for six 30 second cycles, remain armed
and ignore that triggered zone.\
Whenever the system is armed, the dash mounted LED indicator will slowly flash. This serves as a
visual deterrent to the potential thief. The LED is a very low current bulb and will not cause the
vehicle’s battery to drain, even when left unattended for extended periods.
Whenever the system is triggered, the vehicle’s parking lights will flash for the full 30 second alarm
cycle, attracting visual attention to the vehicle.
Optional - Whenever the system is armed, the vehicle’s starting circuit will be bypassed. If the thief
should choose to ignore the siren, the vehicle can not be started.
Any mild impact to the vehicle’s glass will cause the alarm to sound a short series of warning tones.
Any strong impact to the vehicle’s glass will cause the alarm to trigger for the full 30 second alarm
cycle.
NOTE: If the optional interior illumination circuit was installed, the interior light will flash as well
DISARMING THE SYSTEM
1. As you approach the vehicle, press and release the Unlock/Disarm button on the keychain
The dash mounted LED turns off. If passive arming is selected on, the LED will start flashing
If the siren did not sound when disarming, then the chirps have been turned off
and you should refer to the section titled “ELIMINATING THE ARM / DISARM CHIRPS“ in this
Doors Unlock - Optional
NOTE: If the optional Interior illumination feature has been added as an added convenience,
WHILE THE SYSTEM IS SOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security system,
simply press and release any transmitter button other than the Unlock/Disarm button. This action
last vehicle door is closed, the unit will arm automatically.
for the full 30 second alarm cycle.
transmitter.
rapidly, indicating that the system is re-arming automatically. Open any door to suspend the auto-
matic arming. Parking Lights flash two times. I f the parking lights flashed three times, then
the alarm was triggered in your absence. Before turning the key on, examine the LED to identify
which zone was triggered. Siren sounds two chirps. If the siren sounds 4 chirps, then the alarm
was triggered in your absence. Before turning the key on, examine the LED and refer to the
INTRUSION WARNING SIGNALS section of this manual to identify which zone was triggered.
manual.
the system will turn on the interior lights when the system is disarmed.
to provide full protection. If the siren "chirped" three times,
sounds 3 chirps, then you have left a door,
Page 1
128-7852
1 of 12
will turn off the siren yet leave the vehicle fully armed and protected. This feature is particularly
useful if you are aware of children playing near your vehicle that may accidently trigger your security
system. In this case you can cancel the siren sounding without disarming your alarm.
INTRUSION WARNING SIGNALS
This system will inform you if an intrusion attempt has occurred while you were away from the
vehicle. If an intrusion attempt has occurred, the siren will chirp 4 times and the parking lights
will flash 3 times when disarming the system. Enter the vehicle and observe the red dash mounted
LED to identify which zone was triggered.
n If the LED is flashing one time...pause...one time...pause...etc., then an intrusion attempt
was made to the shock sensor, or an accessory triggering device that may have been
added to the system.
o If the LED is flashing two times...pause...two times...pause...etc., then an intrusion at-
tempt was made to a hood or trunk pin switch that was added to the system or to a light
activated entry point if the alarm was installed using the voltage sensing feature.
p If the LED is flashing three times...pause...three times...pause...etc., then an intrusion
attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory and will only be erased
when the ignition key is turned on.
VALET SWITCH
The valet switch allows you to temporarily bypass all alarm functions, eliminating the need to hand
your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all
alarm functions are bypassed, however the remote panic feature and remote door locks will remain
operational. In addition, the parking lights will flash to indicate locking and unlocking. To use the
valet mode, the system must first be disarmed either by using your keychain transmitter or by
activating your personalized manual override code.
1. Enter the vehicle and turn the ignition key to the on position.
2. Press and hold the valet pushbutton switch until the dash mounted LED turns on
solid. The system will remain in the valet mode.
3. To return to normal operation, press and release the pushbutton switch any time the
ignition is on.
NOTE: Always remember to return the system to normal operation. This will ensure that the
MANUALLY OVERRIDING YOUR SYSTEM:
USING THE VALET SWITCH MANUAL OVERRIDE
Y our Security System can be disarmed without the use of the keychain transmitter . This is necessary , since
you will need the ability to operate your vehicle if the transmitter is lost or its battery fails. If your system has
been selected for Valet Switch manual override as indicated on the last p age of this manual, to bypass the
alarm system;
The alarm system will stop sounding and enter the (bypass) mode. You can now start and operate
the vehicle normally.
Typically this override mode is used only if the transmitter has become inoperative.
PROGRAMMING YOUR CUSTOM OVERRIDE CODE:
Unlike override switches easily found, and defeated, this security system allows the consumer to program a
personal override code, offering a higher level of security . To take advantage of this option, programmable
feature # 10 must be selected for the Custom Code Option. Consult your installation center for programming details. The system comes from the factory with a pre-programmed override code of 11. To change
this default override code, do the following:
If the new code was accepted, the unit will report back the newly entered code, by flashing the LED,
first indicating the 10ths digit, pause and then the units digit. The unit will report the new code three
times with a one second pause between each code, then the system will begin arming. If the LED
vehicle remains protected at all times.
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the on position.
3. Within 5 seconds, press and release the valet pushbutton switch.
1. Disarm the system by use of the transmitter, or by use of the emergency override sequence.
Turn the ignition switch to the on position.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on. (The siren or
horn will beep and the lights will flash one time with each ignition switch cycle.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and releasing the
pushbutton switch from 1 up to 9 times.
5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off then on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and releasing the
pushbutton switch from 1 up to 9 times.
7. Finish by turning the ignition switch to the off position.
Page 2
128-7852
2 of 12
flash pattern reports the previously stored code, the new code was not entered correctly. Please
repeat steps 1 through 7 above considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero),
or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire or if the ignition switch is turned off for more then 5 sec-
onds during any of the above steps, the unit will revert back to the last successfully stored
code.
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do the following:
1. Disarm the system by use of the transmitter or by use of the emergency override sequence.
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on. (The siren or
horn will beep and the lights will flash one time.)
5. Within 10 seconds, begin to press and release the pushbutton switch to set the tenths digit.
(As per the example, press and release 5 times to set the tenths digit to 5)
6. Within 10 seconds of the last press of the pushbutton, turn the ignition switch off then on.
7. Within 10 seconds, begin to press and release the pushbutton switch to set the units digit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch to the off position. Immediately observe the LED flash pattern.
You will note the LED flashing five times, pause, and then flash two times, pause. This pattern will
be repeated three times indicating the new code (52) has been accepted and stored in memory.
NOTE: If after step 7, the LED flashes a code other than what was just entered, this indicates that
the code has not been changed. You will have to repeat steps 1 through 7 above being
certain to note the following:
Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no digit
entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5
seconds during any of the above steps, the unit will revert back to the last successfully
stored code.
MANUALLY OVERRIDING YOUR SYSTEM:
USING THE CUSTOM CODE OVERRIDE
Assuming the override code programmed has not been changed, and the default override code of
11 is in the system's memory.
1. Enter the vehicle and turn the ignition switch to the on position.
NOTE: The siren will sound.
2. Within 5 seconds, press and release the pushbutton switch 1 time.
3. Within 5 seconds, turn the ignition switch off then on.
4. Within 5 seconds, press and release the pushbutton switch 1 time.
5. Turn the ignition switch off then on and start the vehicle.
NOTE: If you have changed the programmed override code then substitute your new code tenths
for step 2 above, and units for step 5 above.
PUSHBUTTON VALET/SAFETY CONTROL/PROGRAM SWITCH
The Push-Button valet safety control switch allows you to temporarily disable the remote starting function of
the system. This is recommended whenever the vehicle is being serviced. To place the system in the service/
temporary disabled mode:
1) With the system disarmed/unlocked, and the ignition switch off Press and Hold the Push-Button Switch
on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED begins to flash two short flashes followed by one long flashes and continues this pattern until
returned to normal mode of operation.
This puts the unit into the R/S Override mode indicating that the remote start system is in the service/
temporary disabled mode and will not start from RF or any other input Telematic input or otherwise.
To Exit R/S Override Mode
1) With the system disarmed, Press and Hold the Push-Button Switch on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED turns off indicating that the R/S unit is fully functional one again.
REMOTE CAR FINDER/PANIC
The Lock or Unlock buttons are also used to access the car finder/panic mode. This feature is particularly
useful in a crowded parking lot where finding your car may be difficult to locate, or if there are suspicious
characters hanging about your vehicle. To access this mode, while within range of your car, simply press and
Page 3
128-7852
3 of 12
hold either the lock or unlock button of your transmitter for three seconds. The parking lights will begin to
flash, the siren will sound, and if connected, the vehicle horn will beep making your vehicle audible as
well as more visible. The lights, siren and or horn will stop automatically after 30 seconds. If you wish
to turn off this mode prior to the expiration of the 30 second timer, press and hold for three seconds either the
lock or unlock buttons a second time, or press and release the Trunk/Start button one time.
REMOTE TRUNK RELEASE
If you have electric trunk release in your vehicle and the remote trunk release option was added, simply
press and hold the Key/Trunk button of your keychain transmitter for 3 seconds or until the electric trunk
of your vehicle opens. . .
REMOTE STARTING THE VEHICLE
This unit will not start the vehicle if any one of the following situations exists;
1. To start the vehicle, press and release the Key/Trunk button two times within 2 seconds. The vehicle will
2. When you arrive at the vehicle, turn the ignition key to the ON position (not the spring loaded start
NOTE: The engine will stop running before the pre-programmed run cycle has expired if you perform any
THE OPTION BUTTON of your transmitter may or may not be used with your system but may be used
with a second similar Audiovox Model system that may be installed on a second vehicle in your family.
OPERATING ON AUTOMATIC START UP TIMER MODE
Your system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This
feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm
is to periodically start the engine.
WARNING! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device.
TO BEGIN THE AUTOMATIC START UP TIMER
1. Turn the ignition key on then off.
2. Within 10 seconds, activate the RF start command two times. (Push the
programmed channel button of your keychain transmitter 4 times).
The parking lights will flash and the siren will chirp 2 or 4 times indicating the timed start mode is activated.
The vehicle, on a 2 or 4 hour interval basis, dependent on the number of chirps heard when activated
as described above will automatically start, run for the pre-programmed time (5,10,15 or 20 minutes),
and then shut off. This will continue for 48 hours.
NOTE: The automatic start up timer can also be initiated from the keychain transmitter. To do
this:
1. Start the vehicle using the keychain transmitter by pressing and releasing the
2. Shut off the vehicle using the keychain transmitter by pressing and releasing the second channel
3. Within 10 seconds of step 2, activate the RF start command two times.
The parking lights will flash and the siren will chirp 4 times indicating the timed start mode is activated.
CANCELING THE AUTOMATIC START UP TIMER
To cancel the automatic start up timer do one of the following;
1. Start the vehicle manually with the use of the ignition key and depress the brake pedal.
2. Remote start the vehicle using your keychain RF transmitter.
The vehicle's hood lid is opened. The gear shift selector is not in Park.
The brake pedal is depressed. The safety control switch is in the Off/Override Mode.
start and remain running for the pre-programmed 5,10,15,20 minute run cycle. As a visual indication, the
parking lights will flash or remain on depending on the setting by your installation center.
position), then step on the brake pedal to disengage the remote starter. The vehicle will continue to run,
but now on it's own power.
one of the following functions;
Press and release Key/Trunk button on the keychain transmitter two times within 2 seconds.-
Depress the brake pedal. - Open the vehicle's hood -Place the unit in the safety control disabled
mode.
A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if
prolonged exposure occurs. DO NOT remote start the vehicle if it is garaged.
second channel transmitter button 2 times.
transmitter button 2 times.
(Pushthe second channel button of your keychain transmitter 4 times).
ELIMINATING THE NORMAL ARM / DISARM CHIRPS
As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or
disarm the system, if the feature has been activated, simply by holding the ARM or DISARM
button for two seconds. If you find the normal arming and disarming chirps annoying, they can be
turned off permanently, eliminating the need to hold the ARM / DISARM button for 2 seconds.
Page 4
128-7852
4 of 12
Loading...
