Audiovox ADVUV630 User Manual

DEST

NAV

PWR-VOL

A/V

INPUT

ADVUV630

NavMate 5 Navigation Instructions

Horizon NavMate 5

NAVMATE 5 INTRODUCTION

We hope that you enjoy using your new ADVUV630 navigation system. This manual is designed to help you get the most out of your system. This navigation system leads you straight to your destination. You can navigate and plan your route with an easy-to-use and intuitive interface, plan your trip to suit your personal preferences and interest s, and fi nd and save (bookm ark) interesting destinations before you begin your trip.

Key Features

• Powered by Horizon NavMate 5

• Tele Atlas Map Data

• 11 million POI (Point Of Interest)

• Speed Sensitive Zoom

• 3D Landmarks

• Female/Male TTS Voice Guidance

• Female/Male Recorded Voice Guidance

• Turn by Turn Voice Guidance

Specifications

• SiRF Prima 600 MHz processor

• SDRAM - 256MB

• WIN CE 6.0

• Storage In ternal SD Card 4 Gigabytes

About GPS and GNSS

The ADVUV630 uses a vehicle GPS (Global Positioning System)-based navigation device which utilizes digital map data to guide you from your selected location A to location B, using location information obtained from a Global Navigation Satellite System (GNSS).

A GNSS consists of a set of satellites that transmit high-frequency radio signals containing time, direction, and distance data that can be picked up by a receiver, a llowing users to pi npoint th eir p recise loca tions a nywhere ar ound the globe. Navigation Satellite Receivers (GPS devices) use this transmitted information to calculate an exact location on the earth. Every point on Earth can be identified by latitude and longitude. The receiver uses the information sent by at least three satellites and determines the coordinates of the receiving device.

By comparing the time the signals were transmitted from the satellites and the time they were recorded, the receiver calculates how far away each satellite is. The distance of the receiver from three or more satellites reflects its

Horizon NavMate 5

position on the surface of the planet. Using these distance measurements, the receiver might also be able to calculate speed, bearing, trip time, distance to destination, altitude, etc. The GPS position may be displayed as a point on a digital map (at least three satellites' signals must be received) and as the GPS device moves the corresponding trace is displayed as well.

Please keep in mind that although the radio signals of navigation satellites will pass through clouds, glass, plastic, and other lightweight materials, satellitenavigation receivers will not work underground or in some enclosed spaces.

Horizon NavMate Navigation / Tele Atlas Map Data

The ADVUV630 is pre-loaded with Horizon NavMate 5 and Tele Atlas map data. The map data covers the continental US.

The initial GPS location lock is best established when your vehicle is parked. If the device is in motion, the signal can take longer to initially connect. Once the initial coordinates are established, the software will follow you as you move and navigate.

NOTE: It may take up to 5 minutes to establish the first connection. Subsequent connections will be faster (30 seconds to 1 minute), but if you have not used the unit for several days or are very far away from the last location you used it, it may take up to 5 minutes again to find a strong signal.

Horizon NavMate 5

SAFETY INFORMATION

User Agreement

When the navigation system is first access, you will see the following message, warning you to operate your navigation system appropriately:

You must agree to the above notice before operating the ADVUV630 navigation system. Touch the bar labeled “Press to ac cept.” to proce ed to the Main Menu.

Driver Safety Rules

The following safety rules must be followed to prevent accidents that can result in injury or death to yourself or others:

• The driver should operate the device only when the vehicle is stopped. Only a vehicle passenger should operate the device while the vehicle is moving. When driving, the need to view the display is minimal. Voice prompts will guide you to your destinations.

• It is your responsibility to comply with all traffic laws.

• The ADVUV630 is designed to assist you in the process of reaching your destination. It is not a substitute for attentiveness and good judgement. It is your responsibility to disregard any unsafe, hazardous, or illegal route suggestions.

• The device does not include, analyze, process, consider, or reflect any of the following: a. Legal restrictions (such as vehicular type, weight, height, width, load

and speed restrictions); b. Road slope or grade, bridge height, width, weight, or other limits; c. Population density; d. Neighborhood quality or safety;

Horizon NavMate 5

e. Availability or proximity of law enforcement, emergency rescue,

medical, or other assistance; f. Construction work zones or hazards; g. Road or lane closures; h. Road, traffic, or traffic facilities' safety or condition; i. Weather conditio ns; j. Pavement characteristics or conditions; k. Special events; l. Traffic congestion.

• While every attempt is made to ensure that the database is accurate, roadways, points of interest, and business and service locatio n s ma y change over time.

• Do not use the ADVUV630 to navigate to a police station, hospit a l, etc. in an emergency. Call 911 for assistance.

• Laws in some states prohibit wearing stereo headphones or may prohibit use or placement of a navigation device while operating a motor vehicle. Please contact your state's Department of Motor Vehicles for information.

Horizon NavMate 5

BASIC OPERATION

Head Unit Button Functions

Accessing the Navigation Software

Press the SRC button and select the NAV icon to access navigation mode.

Selecting / Listening to a Source while Navigating

While navigating, other sources may be selected and listened to such as AMFM Tuner, CD, etc. To listen to another source while navigating, press the SRC button and then select a source from the Source Menu. Navigation voice prompts will be heard automatically, although the navigation map cannot be seen. To view the navigation screen, but continue to listen to the selected source, press the NAV button or choose the navigation source from the SOURCE menu.

Acquiring a Satellite Signal

Drive your vehicle to an open area where the GPS signal can be clearly received and park the vehicle. If the device is in motion, the signal can take longer to initially connect.

With the ignition on, verify that the "GPS" indicator is green. It may take up to 5 minutes to establish the first connection. Subsequent connections will be faster (30 seconds to 1 minute), but if you have not used the unit for several days or are very far away from the last location you used it, it may take up to 5 minutes again to find a strong signal. If you cannot acquire the signal, drive to another location. If the signal is still unobtainable, check your antenna installation.

Once a GPS signal has been established, verify that the information display clock time (time displayed on the radio) matches the navigation system clock. With an established GPS signal, the software will follow you as you move and navigate.

The GPS symbol ( )may change colors indicating the strength of the signal. The GPS symbol colors mean:

• Green - GPS signal is free from obstruction and is being received regularly - at least four satellites are being received.

• Yellow - GPS signal is partially obstructed which means only three satellites are being received.

• Red - GPS signal is unavailable, meaning two or fewer satellites are being received.

Horizon NavMate 5

Using the Keyboard

Keyboard Command Buttons

Table 1: Keyboard Command Buttons

Press to backspace.

Press to switch to City Name entry.

Press to switch to Street Name entry.

Press to switch to Postal Code entry.

Press to add a space when entering a multi-word location.

When applicable, the specials characters button appears to the right of the space button, allowing to complete your entry of a business name. Press to view the special characters keyboard.

Press to confirm current entry and begin navigation.

Press to return to the previous screen.

Look Ahead Feature

Your navigation system offers a convenient interactive look-ahead search function to prevent misspelling. Only keys that lead to a search result can be pressed – all others are greyed out.

Horizon NavMate 5

SPACE

LINE ITEM UP

LINE ITEM DOWN

PAGE UP

PAGE DOWN

After entering the second character, only letters that can be used to spell an existing destination will be available for selection of the third character, the fourth character, and so on.

NOTE: On the keyboard screen, the “SPACE" button is located in the bottom center of the screen. Press the Space button to complete the search for entries with more than one word. For example, to locate Lake Mary, enter "Lake_" and then the "M" will become available for selection.

Selecting from Lists

You will often find it necessary to select items from a list. When viewing a list, the marked item appears highlighted in blue.

• Press the blue LINE ITEM UP / LINE ITEM DOWN arrow buttons on the right side of the screen to navigate the list.

• Use the PAGE UP / PAGE DOWN buttons to move through the list page by page.

• Touch the marked item to select it.

Horizon NavMate 5

NOTE: Some lists keep track of the five most recently used selections, which are placed at the top of the screen. This feature allows you to quickly select popular choices.

Function Buttons

Press the map icon to view your current location on the map or to return to map mode.

Zoom in the map to show a smaller area.

Zoom out the map to show a larger area.

Press the return icon on any screen to return to the previous screen.

Press the Menu icon to access the Main Menu.

After panning map, press to view a list of locations near the selected position.

Horizon NavMate 5

Table 2: Common Command Buttons

Press to repeat voice prompt.

Press to go up one line item while viewing a list.

Press to go down one line item while viewing a list.

Press to view the keyboard for direct entry.

Press to go up one page while viewing a list.

Press to go down one page while viewing a list.

Press to mute voice commands.

Press to begin search based on the selected parameters.

Horizon NavMate 5

Main Menu

The main menu, titled “Select location” is your central point of access to all functions of your navigation system. It allows you to set your destination, manage your favorites and control all settings of your device.

The “Select location” menu consists of the following option s:

• Address or Intersection: Travel to address entered using on-screen

keypad.

• Point of Interest: Browse or search for Point of Interest.

• History: Return to previous destination.

• Favorites: Travel to favorite location.

• Coordinates: Travel to destination specified by coordinates.

• Place on Map: Browse map to choose destination.

• (Home Address): Return to Home Address.

• (Setup): Configure your navigation to suit your needs. Define

general settings (e.g. time, language, or system of measurement), configure your map (e.g. 2D or 3D mode, day or night mode, map complexity) or load a map of a different region, set the route options (e.g . choose to avoid or allow toll roads or ferries, or change the volume (see “Setup Menu” on page 112).

• (Office Address): Route to Office Address.

• (Trip Computer): Display Speed, Trip, Odometer and Clock

readings.

Horizon NavMate 5

Next Maneuver

Next Turn/Junction/Exit Number

Distance to Destination

Distance to Next Maneuver

Time Before Next Maneuver

Estimated

Arrival Time

Repeat

Voice Prompt

Zoom In

Zoom Out

Press for 2D/3D/Split Screen View

Navigation Screen

The map is the core component of your ADVUV630 navigation system. During navigation, it is centered on your current location by default, provided you have a GPS connection.

In Tracking mode, the map follows your actual position (GPS position), displaying information about your geographic position, distance to your destination, etc. The GPS position is indicated by a red/blue arrow.

You can also browse the map, view businesses and other Points of Interest (POI, and then choose them for routing and navigating. The map knows two basic states: Tracking and Browsing.

Map Tracking Screen

During navigation, the screen displays your route (in yellow) and your surroundings. A red/blue arrow identifies your current position. The upcoming maneuver is visualized in the upper left corner, along with the distance and approximate time before that turn. When you come up to a turn, you will hear a voice command at the appropriate time .

Horizon NavMate 5

Adjust Horizon Angle

Miles Per Hour

Current Position Adjust Horizon Angle

GPS Signal Strength

Menu Button

Compass Heading

Current Location Map Location

Mute Voice Prompts

Map Scale

On the left, additional information, including the map scale and compass orientation (N, S, E, W) is displayed.

• To zoom in or out, press the + or – icons (Map Scale indicates zoom

value).

• To return to the Main Menu, press the button.

• To add a POI destination to your route, press the button.

• For one-way streets, the transit direction is indicated with a red ar ro w.

• For more information about navigation, see “Navigating” on page 94.

Horizon NavMate 5

Crosshair Location

Business

Icons

Crosshair

Map Browsing Screen

Touch (and hold) the screen to access Map Browsing Mode. Use a stylus or your finger to browse the map. Your position is identified as the center of the crosshair.

• To zoom in or out, press the + or – icons.

• To return to the map tracking mode, press the button.

Horizon NavMate 5

SPLIT

Press to View Detailed Readings

2D/3D/Split Screen

During navigation or map browsing, you can click the button to switch between 2D (default), 3D and Split Screen map views.

Trip Computer

The Trip Computer provides information about yo ur vehicle speed, trip related timing, elevation, odometer and clock.

Horizon NavMate 5

• Press the “i” icon to view detailed readings for each field.

• Press the Press the / buttons on the right side of the screen to navigate the list.

• Use the / buttons to move through the list page by page.

• Touch the marked item to select it.

• Press the button to reset the current reading.

Horizon NavMate 5

SELECTING A DESTINATION

There are five different ways to find and choose a destination. Some meth ods allow you to select from a list using the arrow keys, while others allow you to search using an on-screen keyboard.

NOTE: If a route is in progress when you exit the navigation system, the unit will prompt “Do you want to resume guidance?” when you resume operation. Press the green check mark to resume or the “X” to cancel and go to the “Main Menu.”

Finding an Address

Access the “Select location” screen to begin locating an address. If you

cannot see the “Select location” screen, press the button.

The “Select location” screen allows you to begin your search by entering the Address or Intersection, a Point of Interest (POI), map Coordinates, or by choosing from your Favorites or History. You may also choose a location by selecting a Place on Map.

Address or Intersection

After choosing the destination State or Province, press the Address or Intersection button to view the City address entry screen. You can locate an

Horizon NavMate 5

address or intersection in the previously selected state beginning with the City, Street Name, or Postal Code.

To toggle between City, Street Name and Postal Code entry, press the

/ / button.

1. Begin entering the city by typing the City, Street Name or Postal Code. The navigation software will utilize it’s look-ahead feature and only offer characters for existing cities as you type. Once the city is recognized as the only possible option based on the characters you entered, you will automatically be prompted for the street.

2. Enter the Stree t name using the same method described above. Once the street name is recognized, you will automatically be prompted for the street number.

3. Enter the street number using the same method descr ibed above.

4. Press the button to select the street number and access the “Start Route” screen.

Point of Interest

The POI finder allows you to quickly find points of interest, like gas stations and restaurants, in a database of millions of POI’s. These places can be near your current position or near a selected State or Province. See “Selecting a Point Of Interest” on page 84 for information about locating a Point of Interest.

History

Previous destinations are automatically saved to memory as “History”. This feature helps you quickly locate the address of and return to a previo u s destination. The origin of the last calculated route is also stored for easy return to your starting point.

Horizon NavMate 5

1. From the “Select location” menu, choose History.

2. A list of recent locations will appear on the screen.

• Press the / buttons on the right side of the screen to navigate the list.

• Use the / buttons to move through the list page by page.

• Press the Garbage Can icon to delete the highlighted item.

3. Press to select a recent destination from the “History” list and view the “Start Route” screen.

4. Continue navigation as instructed in the previous sections.

NOTE: The “History” list stores the last 15 addresses or destinations. Af ter 15 entries, the oldest destination will be deleted and the newest entry added to the top of the list. Recent addresses cannot be deleted manu ally.
