HIGH PERFORMANCE
SUBWOOFERS
MODELS AVW110, AVW111,
AVW121 and AVW122
OWNERS MANUAL
Released 2-25-03
Congratulations on your purchase of the
Subwoofer. The
Rampage
Subwoofers are designed to provide you with high
Rampage
High Performance
quality Bass reproduction required to make your car audio system perform to
its full potential.
RAMPAGE
Dual 4-Ohm (AVW110/121) or Dual 6-Ohm (AVW111/122) voice coil for
maximum flexibility and performance
Double stacked magnet
Chrome plated stamped steel basket (AVW110/121) or Patented die-cast
aluminum basket (AVW111/122)
Patented thermo-cooling motor structure
3-Inch Hi-Temp Kapton voice coil structure (AVW111/122)
Subwoofer Features
SUBWOOFER PARAMETERS
AVW110 AVW111 AVW121 AVW 122
Nominal Power Rating 300 Wrms 350 Wrms 350 Wrms 400 Wrms
Peak Power Rating 600 W 700 W 700 W 800 W
Double Stacked Magnet 110 Oz 110 Oz 150 Oz 150 Oz
Frequency Response 40 Hz-1kHz 40 Hz-1kHz 40 Hz-1kHz 40 Hz-1kHz
Resonant Frequency 55 Hz ± 20% 55 Hz ± 20% 55 Hz ± 20% 55 Hz ± 20%
Woofer Size 10" 10" 12" 12"
Nominal Impedance 4 Ohms x 2 6 Ohms x 2 4 Ohms x 2 6 Ohms x 2
Mounting Depth 6.25" 5.5" 6.5" 5.5"
WARNING: High-powered car audio systems may produce sound
pressure levels that exceed the threshold at which hearing
loss may result. They may also impair a driver’s ability to
hear traffic sounds or emergency vehicles. Use common
sense and practice safe listening habits when listening to
your audio system.
DUAL VOICE COIL WIRING
CAUTION: Never connect only one voice coil of a dual voice coil woofer.
Both must be driven at the same time for proper operation.
Never connect an amplifier to an impedance load lower than
it is rated to handle.
SERIES/PARALLEL MONAURAL CONNECTION
Parallel
result in a total impedance load of 2 Ohms at the amplifier, (See Fig. 1) if your
amplifier is rated to drive 2 Ohms in bridged or one-channel operation. If each of
two dual-voice coil 4-Ohm woofers are connected in parallel and then wired to
wiring for a single, dual-voice coil 4-Ohm woofer in a monaural system will
2
each other in parallel, a 1-Ohm monaural output would result (See Fig. 2). On the
other hand, if your amplifier is rated for 4-Ohm operation in bridged or one-channel
operation, series-connect the woofer voice coils (See Fig. 3). If the amplifier is rated
for 8 Ohms, interconnect the voice coils of the woofer in series as shown to obtain an
8-Ohm monaural output (See Fig. 4).
The same applies for parallel wiring of a single, dual-voice coil 6-Ohm woofer, in
which a total impedance load of 3 Ohms will be seen at the amplifier.
SERIES/PARALLEL STEREO CONNECTION
Series
impedance load of 8 Ohms at each channel of the amplifier (See Fig. 5). Otherwise,
connect one woofer to each channel for 4-Ohm stereo operation (See Fig. 6), or two
parallel-wired woofers (one-per-channel) for 2-Ohm stereo operation (See Fig.7).
The same applies for series wiring of a single, dual-voice coil 6-Ohm woofer, in which
a total impedance load of 12 Ohms will be seen at the amplifier.
wiring of each of two, dual voice-coil 4-Ohm woofers will result in a total
3
INSTALLATION RECOMMENDATIONS
To realize the utmost in sound reproduction from your subwoofer(s), follow these
installation recommendations:
Use a quality large gauge wire to connect your subwoofer to the
amplifier
Use a subwoofer crossover to remove unwanted higher frequencies
Position the enclosure in the rear of the vehicle with the subwoofer
facing rearward to improve bass response and avoid cancellation
of audio frequencies
ENCLOSURE CONSTRUCTION RECOMMENDATIONS
To enhance subwoofer performance, the following general recommendations should
be addressed when constructing the speaker enclosure:
Use 3/4" MDF for your construction material
Glue all joint seams
Screw or nail all joints tight
Brace all walls
DESIGNING AND BUILDING YOUR SPEAKER ENCLOSURE
The following parameters are offered to assist you in designing your own enclosure.
There are many computer software programs available on the market that, along with
this information, will allow you to construct the type of enclosure that best suits your
needs.
To obtain the best possible results, we suggest you use our recommended enclosure
designs and have an automotive sound professional build your enclosure.
4
Parameters AVW111 AVW121 AVW110 AVW122
Fo (Hz) 36.44 35.84 30.33 32.42
Revc (Ohms) 2.7 1.6 1.6 2.7
Levc at 1kHz (mH) 1.44 0.97 1.19 1.48
Qms 4.27 5.72 4.27 4.07
Qes 0.54 0.46 0.32 0.57
Qts 0.48 0.43 0.29 0.50
Vas (Ltrs) 31.98 61.23 39.06 68.84
Spl @ 1W/1M (dB) 86.44 89.67 87.19 87.99
X-Max Linear 12 14 12 14
pk-pk (mm)
5
Recommended Enclosure Volumes
AVW111 AVW121 AVW110 AVW122
SEALED
Minimum sealed (Cu. Ft) 0.35 0.5 0.35 0.75
Maximum sealed (Cu. Ft) 0.75 1.0 0.75 1.25
PORTED
Vented (Cu. Ft) 1.5 2 1.25 2.25
Vented to (Hz) 34 34 34 32
Port Diameter (“) 3 4 3 4
Port Length (“) 8.5 11.5 7.5 12
Number of Ports 1 1 1 1
SQUARE PORT INFO
Port Area (Sq/In) 7 12 7 12
Port Length (") 8.5 11.5 7.5 12
© 2003 Audiovox Electronics Corporation, Hauppauge, NY 11788 128-6685
6
