Audiovox 1286458 User Manual

Model APS-255CH

Installation Manual

SELECTABLE FEA TURES

Note : When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver’s door pin

switch in order to begin the passive arming sequence.

RF Programmable Features :

Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps Default

1st Door L/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L 1 Sec. 2nd Accy Lock Auto Lock On Auto Lock Off Auto Lock Off 3rd Accy. UL Auto UL Dr. Auto UL All Auto UL Off Auto UL Off 4th Passive Locks Passive Active Active 5th Passive/Active Arm Passive Arm Active Arm Active Arm 6th Voltage Sense Voltage Sense Hardwire Hardwire 7th Siren/Horn Siren/Horn Siren Only Horn Only Siren/Horn 8th Horn Chirp 10mS 16mS 30mS 16mS 9th Override Method Custom Code Valet Valet 10th Two Step Unlock On Off Off 11th Chirp Delete From Tx On Off Off

T o program these selectable features;

Action System Response

Turn ignition on No response Press and release the valet switch 3 times 1 Chirp - LED 1 flash

First Then On 1 chirp = 1 second door locks

Second Press and release the valet switch 2 chirps = auto locks off

Third Press and release the valet switch 3 chirps = auto unlock off

Fourth Press and release the valet switch 2 chirps = active locks

Fifth Press and release the valet switch 2 chirps = active arming

Sixth Press and release the valet switch 2 chirps = hardwire

Seventh Press and release the valet switch 1 chirp = siren and horn output

Within 3 seconds, turn ignition Off Short chirp, then long chirp

Press transmitter Lock button to change 2 chirps = 3.5 second door locks Press transmitter Lock button to change 3 chirps = 1 sec. lock, dbl 1 sec. unlock

Press transmitter Lock button to change 1 chirp = auto locks on

Press transmitter Lock button to change 1 chirp = auto unlock dr. Press transmitter Lock button to change 2 chirps = auto unlock all

Press transmitter Lock button to change 1 chirp = passive locks

Press transmitter Lock button to change 1 chirp = passive arming

Press transmitter Lock button to change 1 chirp = voltage sense

Press transmitter Lock button to change 2 chirps = siren output only Press transmitter lock button to change 3 chirps = horn output only

128-6458

1 of 16

Eight Press and release the valet switch 2 chirps = horn chirp output 16mS

Press transmitter Lock button to change 3 chirps = horn chirp output 30mS Press transmitter Lock button to change 1 chirp = horn chirp output 10 mS

Ninth Press and release the valet switch 2 chirps = valet switch override operation

Press transmitter Lock button to change 1 chirp = custom code override operation

Tenth Press and release the valet switch 2 chirps = 2 step unlock off

Press transmitter Lock button to change 1 chirp = 2 step unlock on

Eleventh Press and release the valet switch 2 chirps = chirp delete from transmitter inactive

Press transmitter Lock button to change 1 chirp = chirp delete from transmitter active Press and release the valet switch Exit program mode

Turn ignition key off Exit program mode

Note: Once you enter the feature programming mode, do not allow more than 30 seconds to pass between steps, or the

programming will be terminated.

INST ALLATION OF MAJOR COMPONENTS Control Module :

Select a mounting location inside the passenger compartment ( up behind the dash ), and secure using the two screws provided. The control module can also be secured in place using cable ties.

Do not

mount the control module in the engine compartment, as it is not waterproof. Y ou should also avoid mounting the unit directly onto factory installed electronic components. These components may cause RF interference, which can result in poor transmitter range or intermittent operation.

Siren :

Select a mounting location in the engine compartment that is well protected from access below the vehicle. Avoid areas near high heat components or moving parts within the engine compartment. T o prevent water retention, the front or sounding end of the siren must be pointed downward when mounted.

Mount the siren to the selected location using the screws and bracket provided.

Hood or Trunk Pin Switch :

A pin switch is included for use in protecting the hood or trunk ( or hatchback ) of the vehicle. The switch must always be mounted to a grounded, metal surface of the vehicle. It is important to select a location where water cannot flow or collect and to avoid all drip gutters on hood and trunk fender walls. Choose locations that are protected by rubber gaskets when the hood or trunk lid is closed.

The pin switch can be mounted using the bracket provided, or direct mounted by drilling a ¼ “ diameter mounting hole. Keep in mind that when properly mounted, the plunger of the pin switch should depress at least ¼ “ when the hood or trunk lid is closed.

Dash Mounted LED :

A small LED is included that will serve as a visual indicator of the alarm status. It should be installed in the dash, located where it can be easily seen from outside the vehicle, yet not be distracting to the driver.

Once a location has been selected, check behind the panel for wire routing access and to confirm the drill will not damage any existing components as it passes through the panel.

Drill a ¼ “ diameter hole and pass the red and blue wires from the LED through the hole, from the front of the panel. Firmly press the body of the LED into the hole until fully seated.

Valet Switch :

Select a mounting location for the switch that is easily accessible to the driver of the vehicle. The switch does not have to be concealed, however, concealing the switch is always recommended, as this provides an even higher level of security to the vehicle.

The valet switch can be mounted to the lower side of the dash by drilling a ¼ “ diameter hole in the selected location.

Be sure to check behind the dash for adequate clearance for the body of the switch and to confirm that the drill will not damage any existing components as it passes through the dash. You should also make

certain that the back of the switch is accessible for wiring later in the installation.

Page 2

128-6458

2 of 16

Shock Sensor :

Select a solid mounting surface for the shock sensor on the firewall inside the passenger compartment and mount the sensor using the two screws provided. The shock sensor can also be secured to any fixed brace behind the dash using tie straps.

Whichever mounting method is selected, make certain that the sensitivity adjustment is accessible for use later in the installation.

WIRING THE SYSTEM Large 15 Pin Edge Connector :

White Wire : + 12 VDC PULSED PARKING LIGHT OUTPUT ( 15 AMP MAX )

This wire is provided to flash the vehicle’s parking lights. Connect the white wire to the positive side of one of the vehicle’s parking lights.

Red Fused Wire : + 12 VDC CONST ANT BA TTERY SOURCE This wire controls the sensitivity of the voltage sensing circuit, which detects the turning on of an interior

light when a door is opened. It will also detect the switching on of parking or headlamps and in many cases will trigger the alarm when a thermostatically controlled electronic radiator cooling fan switches on.

When installing this system into vehicles with electronic ''after fans'' , it is recommended you disable the voltage sense circuit.

In voltage sensing applications, the closer to the battery that the red wire is connected, the less sensitive the voltage sense circuitry will be. Moving this connection point to the fuse panel will increase the sensitivity, and connecting to the courtesy lamp fuse in the vehicle will provide maximum sensitivity of the voltage sense circuit.

When hardwiring the control module, the voltage sense circuit must be disabled. After wiring of the control module and connecting the Red wire to a fused battery source, be certain program feature # six is set for Hardwire.

Dark Blue Wire : DELA YED 300 mA PULSED OUTPUT / CHANNEL 3 The dark blue wire pulses to ground via an independent RF channel from the keychain transmitter. This is

a transistorized, low current output and should only be used to drive an external relay coil. WARNING: Connecting the dark blue wire to the high current switched output of trunk release circuits,

Connect the dark blue wire to terminal 86 of the AS - 9256 relay (or equivalent 30A automotive relay) and wire the remaining relay contacts to perform the selected function of channel 3.

White w/ Black Trace W ire : POSITIVE OUTPUT TO SIREN Route this wire through a rubber grommet in the firewall, and to the siren location. Connect the white / black wire to the positive wire of the siren. Secure the black ground wire of the siren to

chassis ground. Black Wire : CHASSIS GROUND Connect this wire to a solid, metal part of the vehicle’s chassis. Do not confuse this wire with the thin black

antenna wire that exits the control module independently . Yellow W ire : + 12 VDC IGNITION SOURCE Connect this wire to a source that is live when the key is in the on and crank positions. Be sure that this

source is off when the key is in the off position. Dark Green Wire : ( - ) INST ANT TRIGGER ZONE This is an instant on ground trigger wire. It must be connected to the previously installed hood and trunk pin

switches. Brown Wire : - DOOR TRIGGER If the vehicle’s courtesy light switches have a ( - ) ground output when the door is opened (GM and most

Imports), you must connect this wire to the negative output from one of the door switches.

WARNING : Do not use the brown wire if the vehicle has + 12 volt output type door switches.

Note for vehicles with interior delay lighting see programming under title "Completing The Installation". Purple Wire : + DOOR TRIGGER

If the vehicle’s door courtesy light switches have a + 12 volt output when the door is opened ( most Fords

some remote start trigger inputs, will damage the control module.

( see Purple Wire ).

Page 3

128-6458

3 of 16

and some Imports ), you must connect this wire to the positive output from one of the door switches. In most cases, the purple wire will only need to be connected to one door switch, no matter how many doors the vehicle has.

WARNING : Do not use the purple wire if the vehicle has ground output type door switches.

( see Brown Wire ).

Note for vehicles with interior delay lighting see programming under title "Completing The Installation". Orange Wire : 300 mA GROUND OUTPUT WHEN ARMED - N. C. ST ARTER DISABLE

This wire is provided to control the starter cut relay . Connect the orange wire to terminal 86 of the relay. Connect relay terminal 85 to an ignition wire in the vehicle that is live when the key is in the on and crank positions, and off when the key is in the off position. ( This is where the yellow wire from the alarm should be connected ).

Cut the low current starter solenoid wire in the vehicle, and connect one side of the cut wire to relay terminal 87A. Connect the other side of the cut wire to relay terminal 30.

Note :This is a normally closed starter cut arrangement and when power is removed from the

security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.

Black w/White Trace Wire: LOW CURRENT NEGA TIVE HORN OUTPUT (300mA MAX CURRENT)

The Black w/White trace wire provides a 300mA pulsed output to beep the vehicle's horn. This low current pulsed output should only be connected to the low current switched ground output from the vehicle's horn switch. If the vehicle switches high current ground or + 12 volts to the horn, a relay must be used to operate the vehicle horn. Connect the Black w/White trace wire to terminal #86 of a VF45F1 1 P&B or equivalent 30A automotive relay . Connect terminal #85 to a fused + 12 volt source. Connect the remaining relay contacts 87, 87a and 30 to perform the switching function the vehicle's horn circuit requires.

Dark Blue w/Black Trace Wire: Alternate Channel 3 Output (Dbl. Push Required) This wire is controlled from the transmitter button programmed to the receiver's channel 3. By double

pressing this the transmitter button, this output will become active for 1 second. This is a transistorized, low current ( 300 mA ) output, designed to provide an output only when the transmitter is intentionally operated, such as is the case with remote start add on modules. If you require more than 300mA drive from this output, you must drive an external relay coil, and arrange the relays contacts to preform the specified function.

Dark Green w/ White Trace Wire : Entry Illumination ( 300 mA max. ) The dark green w/ white trace wire provides a 30 second ground signal whenever the system is disarmed,

and pulses ground whenever the system is triggered. It should be used to provide the ( optional ) entry lighting and to flash the vehicle’s dome light while the alarm is sounding. This is a transistorized, low current output and should only be used to drive an external relay coil.

Connect the dark green with white trace wire to terminal 86 of the AS - 9256 relay ( or equivalent 30 A automotive relay ) and wire the remaining relay contacts according to the polarity of the dome light circuit in the vehicle.

NOTE : When wiring this feature in vehicles with factory equipped delay lighting circuits, it is

Light Green Wire : ( - ) Instant Trigger Zone 1

This is an instant on ground trigger wire. This wire ( zone ) should be reserved for connection to optional ground output trigger devices such as motion and / or shock impact sensors.

2 Pin Blue Connector : VALET SWITCH Route the grey and black wires in the 2 pin connector from the valet switch to the control module, and plug

it into the mating blue connector on the side of the module. 2 Pin White Connector : DASH MOUNTED LED Route the red and blue wires in the 2 pin white connector from the LED to the control module, and plug it

into the mating white connector on the side of the module. 4 Pin White Connector : SHOCK SENSOR Route the red, black, blue, and green wires in the 4 pin white connector from the shock sensor to the

control module, and plug one end into the shock sensor, and the other end into the mating white connector on the side of the module.

best to connect to the output of the timer which feeds the dome light, rather than at the door switch. This will ensure that the dome light pulses when the alarm is triggered.

Page 4

128-6458

4 of 16

Red / Green / Red w/Black Trace 3 Pin White Connector : Door Lock Outputs

The Red and Green wires will provide either a pulsed ground output to the factory door lock control relay , or a pulsed + 12 volt output to the factory door lock control relay . In either case, the maximum current draw through these outputs must not exceed 300 mA. The Red w/Black trace wire will provide a pulsed ground only and will only provide an output when the unlock button of the transmitter is pressed a second time after a first unlock command was issued. This is used for second step unlock or all doors unlock in a two step circuit. In this arrangement, Red is used to control the drivers door unlock relay , and the Red/ Black will be used to control unlock of all other doors.

3 Wire Ground Switched Single Step Door Locks

In this application, the red wire provides a ground pulse during arming, or the pulsed ground lock output. Connect the red wire to the wire that provides a low current ground signal from the factory door lock switch to the factory door lock control relay .

The green wire provides a ground pulse during disarming, or the pulsed ground unlock output. Con- nect the green wire to the wire that provides a low current ground signal from the factory door unlock switch to the factory door lock control relay .

Red/Black Not Used.

3 Wire Ground Switched 2 Step Door Locks

The green wire provides the first ground pulse during disarming, or the drivers door pulsed ground unlock output. Connect this wire to the drivers door unlock relay that requires a low current ground signal to unlock only the drivers door. If the vehicle does not have a separate drivers door relay, one will have to be added. Locate the drivers door unlock motor wire and cut it at a convenient location to allow wiring of an optional relay . Connect the door side of the cut wire to terminal 30 of the optional relay added. Connect the vehicle side of the cut wire to terminal 87a of the optional relay added. Connect the green wire of the 3 pin harness to terminal 86 of the optional relay added. Connect terminal 85 of the optional relay added to a fused constant + 12 volt source. Most vehicles door lock/unlock motor legs rest at ground, and switch +12 volts to the door lock/unlock motor legs for operation, if this is the case in the vehicle you are working on, connect the remaining terminal, 87, to a fused + 12 volt source. In the rare instance that the vehicle door lock/unlock motor legs rest at + 12 volts and switches ground to the door lock/unlock motors, connect he remaining terminal, 87, to chassis ground.

The Red/Black wire provides a pulse ground output when the unlock button of the transmitter is pressed a second time after disarming. Connect the Red/Black wire to the wire that provides a low current ground signal from the factory door unlock switch to the factory door lock control relay .

3 Wire Positive Switched Door Locks In this application, the red wire provides a positive pulse during disarming, or the pulsed + 12 volt

unlock output. Connect the red wire to the wire that provides a low current positive signal from the factory

door unlock switch to the factory door lock control relay . The green wire provides a positive pulse during arming, or the pulsed + 12 volt lock output. Connect the

green wire to the wire that provides a low current positive signal from the factory door lock switch to the factory door lock control relay .

3 Wire Positive Switched 2 Step Door Locks

The green wire provides a positive pulse during arming, or the pulsed + 12 volt lock output. Connect the green wire to the wire that provides a low current positive signal from the factory door lock switch to the factory door lock control relay .

The red wire provides a positive pulse during disarming, or the drivers door pulsed positive unlock output. Connect this wire to the drivers door unlock relay that requires a low current positive signal to unlock only the drivers door. If the vehicle does not have a separate drivers door relay , one will have to be added. Locate the drivers door unlock motor wire and cut it at a convenient location to allow wiring of an optional relay . Connect the door side of the cut wire to terminal 30 of the optional relay added. Connect the vehicle side of the cut wire to terminal 87a of the optional relay added. Connect the red wire of the 3

Page 5

128-6458

5 of 16
